Hotpoint BS41X User manual

Instructions for Installation and Use
BS41X
To the Installer
Before installation fill in the product details on the back cover of
this booklet. The information can be found on the rating plate.
To the User
You must read the instructions prior to installing and using the
appliance and then retain them for future reference.
Note: Timer must be set to ‘Time of Day’ and ‘Manual’
before the oven can be used.
Note: Ensure that the oven is securely fixed to the
cabinet before use.

Introduction 3
CONTENTS
For Your Safety – Always 4
For Your Safety – Never 5
Know Your Oven 6
Control Panel 7
Oven Timer Operation 8
Know Your Timer 9
Electronic Clock & Automatic Oven Timer Operation 10 - 13
Grill Pan and Handle 14
Grilling Procedure 15
Using the Oven for Fan Cooking 16 - 17
Using the Oven for Other Functions 18
Temperature Conversion Scale 19
Oven Temperature Charts 20 - 21
Cooking Results Not Satisfactory 22
Care & Cleaning 23 - 26
Installation 27 - 31
Something Wrong? 32
Service Back Cover
2

INTRODUCTION
Your new cooker is guaranteed* and will give lasting service. This guarantee
is only applicable if the appliance has been installed in accordance with the
installation instructions detailed in this booklet.
To help make best use of your cooking equipment,
please read this booklet carefully.
The cooker is designed specifically for domestic use and responsibility will not
be accepted for use in any other installation.
To help remove the 'new' smell, heat up the empty oven(s) to maximum for a
minimum of two to three hours keeping the oven doors closed. Ensure that the
room is well ventilated (e.g. open a window or use an extractor fan) and that
persons who may be sensitive to the odour avoid any fumes. It is suggested that
any pets be removed from the room until the smell has ceased.
This odour is due to any temporary finish on oven linings and elements and also
any moisture absorbed by the insulation.
Note: When the cooker is first used, an odour may be emitted - this will cease
after a short period of use
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with the Users Instruction Book.
(b) Has been properly connected to a suitable supply voltage as stated on
the rating plate attached to this equipment.
(c) Has not been subjected to misuse or accident or been modified or
repaired by any person other than the authorised employee or agent.
(d) Has been correctly installed.
This appliance conforms to the following EEC Directives:
Low Voltage Equipment
73/23/EEC
93/68/EEC
Electromagnetic Compatibility
89/336/EEC
92/31/EEC93/68/EEC
3

FOR YOUR SAFETY
4
When used properly, your appliance is completely safe but as with any
electrical product there are certain precautions that must be observed.
PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR
APPLIANCE.
ALWAYS
●Always make sure you remove all packaging and literature from inside the
oven/grill compartment before switching on for the first time.
●Always make sure you understand the controls prior to using the appliance.
●Always keep children away from the appliance when in use as the surfaces
will get extremely hot during and after cooking.
●Always make sure all controls are turned off when you have finished cooking
and when not in use.
●Always stand back when opening an oven door to allow any build up of
steam or heat to disperse.
●Always use dry, good quality oven gloves when removing items from the
oven/grill.
●Always take care to avoid heat/steam burns when operating the controls.
●Always turn off the electricity supply at the wall switch before cleaning and
allow the appliance to cool.
●Always make sure the shelves are in the correct position before switching on
the oven.
●Always keep the oven/grill door closed when the appliance is not in use.
●Always keep the appliance clean as a build up of grease or fat from cooking
can cause a fire.
●Always follow the basic principles of food handling and hygiene to prevent
the possibility of bacterial growth.
●Always keep ventilation slots clear of obstructions.
●Always refer servicing to a qualified appliance service engineer.
●Always during use the oven becomes hot. Care should be taken to avoid
touching heating elements inside the oven.
SAFETY ADVICE
IN THE EVENT OF A CHIP PAN OR ANY OTHER PAN FIRE:
1. TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH.
2. COVER THE PAN WITH A FIRE BLANKET OR DAMP CLOTH, this will
smother the flames and extinguish the fire.
3. LEAVE THE PAN TO COOL FOR AT LEAST 60 MINUTES BEFORE
MOVING IT. Injuries are often caused by picking up a hot pan and rushing
outside with it.
NEVER USE A FIRE EXTINGUISHER TO PUT OUT A PAN FIRE as the
force of the extinguisher is likely to tip the pan over. Never use water to
extinguish oil or fat fires.

FOR YOUR SAFETY
NEVER
●Never leave children unsupervised where a cooking appliance is installed as
all cooking surfaces will be hot during and after use.
●Never allow anyone to sit or stand on any part of the appliance.
●Never store items above the appliance that children may attempt to reach.
●Never remove the oven shelves whilst the oven is hot.
●Never heat up unopened food containers as pressure can build up causing
the container to burst.
●Never store chemicals, food stuffs or pressurised containers in or on the
appliance, or in cabinets immediately above or next to the appliance.
●Never operate the grill with the door closed as this may cause the appliance
to overheat.
●Never use the appliance as a room heater.
●Never use the grill to warm plates.
●Never dry any items on the oven doors.
●Never install the appliance next to curtains or other soft furnishings.
●Never allow children to play with the oven controls.
5
DISPOSAL OF YOUR PRODUCT
To minimise the risk of injury to children please dispose of your product carefully and
safely. Remove all doors and lids (where fitted). Remove the mains cable (where fitted)
by cutting off flush with the appliance and always ensure that no plug is left in a condition
where it could be connected to the electricity supply.
To help the environment, Local Authority instructions should be followed for the disposal
of your product.

COOKPERIOD
START TIME
1
2
3
5
6
4
MINUTE MINDER
CLOCK SET
Balmoral
FAN OVEN
90
190
150 110
230
130
170
210
FULL GRILL
HALF GRILL
GRILL
KNOW YOUR OVEN
6
Grill Element
Stayclean Liners
2 Oven Shelves
Door Switch
Oven Light
Meat/Grill pan
Oven Fan
Rating plate
Inner Door Glass
❍❍
Grill Control
Oven Control
and Selector
24 Hour Digital
Electronic Clock
and Oven Timer

A gentle flow of air will be blown below the control panel when the oven
or grill is switched on. In some instances this will continue after switch-
ing the oven / grill off. This is not unusual. This helps to keep the control
panel and knobs cool.
The oven light is switched on automatically when the fan oven control
(A) is operated..
The oven has a “Slow Cook Setting” this can be used for slow cooking,
keeping food warm and / or warming plates for a short period. Turn oven
control (A) to 900C
Cooling Fan
Oven Interior
Lights
Slow Cooking
CONTROL PANEL
CONTROL MARKINGS
Note: It is advisable to check that all oven controls have been switched off after
you have finished using the appliance.
7
Control
Knob Description
Oven & Grill Selector
Oven & Grill Selector
& Grill Control
1 = Low
6 = High
Oven & Grill Selector
& Grill Control
1 = Low
6 = High
A
A & B
A & B
Function
Fan Oven
Turning control (A) clockwise allows use of fan oven.When
cooking turn to the required setting. The oven temperature
scale is in degrees centigrade.
Full Grill
Turn control (A) clockwise until the full grill symbol is
indicated. Turn control (B) in either direction to the required
grill setting.
Half Grill
Turn control (A) clockwise until the half grill symbol is
indicated. Turn control (B) in either direction to the required
grill setting.
Note: Resistance will be felt when turning from fan oven operation to full grill / half grill positions
❍❍ ❍❍❍❍❍❍
BA

OVEN TIMER OPERATION
AUTOMATIC COOKING
The Oven can be controlled by the Automatic Timer.
HINTS ON AUTOMATIC COOKING
1. Select foods which will require the same cooking time and temperature.
2. To ensure food does not cool down and require reheating, set the end time so
the food is ready when you require it.
3. Always ensure that meat and poultry is defrosted before placing in the oven.
4. Whenever possible, take food out of the refrigerator and keep it as cool as
possible.
5. If cooking food that requires frying before placing in the oven for automatic
cooking, keep the delay time to a minimum.
6. Never place hot or warm food in the oven for delay start cooking as it could
cause the oven to be warm and produce harmful bacteria in the food.
7. We advise that dishes containing left-over cooked poultry or meat, e.g.
Shepherd's Pie, should not be cooked automatically if there is to be a delay
period.
8. Ensure that delay start times are kept to a minimum to prevent bacterial
growth in food.
9. Wine or beer may ferment and cream may curdle during the delay period so
it is best to add these ingredients just before serving.
10. Foods which discolour should be protected by coating in fat or tossing in
water to which lemon juice has been added, prior to placing food in the oven.
11. Dishes containing liquid should not be filled too full to prevent boiling over.
12. Food should be well sealed (but not airtight) in a container to prevent the loss
of liquid during cooking. Aluminium foil gives a good seal.
13. Always ensure that food is piping hot and cooked thoroughly before serving.
14. Only reheat food once.
8
Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the oven
can be used.

9
KNOW YOUR TIMER
CLOCKFACE
The timer incorporates a 24 hour clock.
Ensure correct time of day is always set, before using your cooker.
PLEASE NOTE THAT THE DISPLAY WILL DIM BETWEEN 22.00
HOURS AND 06.00 HOURS TO PREVENT GLARE.
However, should you operate the timer during these hours the display will
return to normal brightness for a few seconds and then dim again.
SYMBOLS
will light up when you select a Minute Minder Period and will remain
lit for the period set. At the end of the Minute Minder Period, the timer
will emit an audible tone for 2 minutes, the symbol will start to flash
and will continue to flash until the Minute Minder function is cancelled.
This “Cookpot” symbol will light up either:–
– When you press the Cook Period Button and set a length of time for
an Auto Cooking Programme. (It will go out again a few seconds after
you release the timer buttons).
– During the actual Cook Period.
“AUTO” will light up:–
– When the timer is first turned on it will flash. (It will go out when a
time of day is set.
– When an Auto Cooking Programme has been set.
The “Auto” symbol will flash at the end of an Auto Cooking programme
to indicate that the programme has finished.
(When the “Auto” symbol is flashing, to return the oven to Manual
operation, turn the oven controls off, ensure that the correct time
of day is set, and press the “Manual” button twice – The “Auto”
symbol will go out.
Here you can set a time period of up to 23 hours 59 minutes, that will count
down. When it reaches zero, the timer will emit an audible tone.
For Example: If you set 20 minutes, the audible tone will occur 20 minutes
later.
Cook Period is the actual length of time for which, the timer will switch the
oven(s) on as part of an “Auto Cooking” programme.
(e.g. If you set 2 hours, the food will be cooked for 2 hours).
The time of day at which you want an “Auto Cooking” programme to end.
For Example: If you set a “Cook Period” for 2 hours, and “End Time” of
11:00. The timer will switch the oven(s) on at 9:00 and turn the oven(s) off at
11:00. You will hear a audible tone at 11:00, to indicate that the Auto
Cooking Programme has finished.
Notes:
– When setting an Auto Cooking programme you will need to set the oven
controls(s) to the required temperature(s) when you set the timer.
_If an Auto Cooking programme has been set the oven(s) will only operate
during the pre-programmed time.
Needs to be pressed to cancel an Auto Cooking programme and return the
ovens(s) to Manual operation.
Used to adjust the various timer function settings.
Minute Minder
Button
Cook Period Button
End Time Button
Manual Button
“+” and “–” Buttons
Minute
Minder Cook
Period End Time Manual
A
U
T
O
A
U
T
O
Minute
Minder Cook Period End Time Manual
TIMER FUNCTION BUTTONS
AUTO COOKING PROGRAMME

ELECTRONIC CLOCK & AUTOMATIC
OVEN TIMER OPERATION
10
SETTING THE TIME OF DAY
Step 1 Make sure all oven controls are turned Off.
Step 2 Check the electricity supply to the cooker is turned on.
Step 3 When switched on the display will show 0.00 and Auto symbol
will be flashing intermittently.
Step 4 Press & hold in both the “Minute Minder” & “Cook Period” button
together.
Step 5 With the “Minute Minder” & “Cook Period” buttons still held in,
press either the “+” or “–” buttons to set the correct time of day.
Step 6 Release all the buttons simultaneously.
THE TIME OF DAY IS NOW SET.
To change the time of day repeat Steps 4, 5 & 6 above.
Note: You cannot adjust the time of day if the timer has been set
for an Auto Cooking Programme.
SETTING THE MINUTE MINDER
Step 1 Ensure the time of day is set correctly.
Step 2 Press and hold the Minute Minder Button, a symbol will light up.
Step 3 With the “Minute Minder” button held in, set the required Minute
Minder time using the “+” and “–” buttons.
Release all buttons and the timer display will revert back to the time of day.
Bell symbol will remain lit to signify that a Minute Minder period has been set.
At the end of the set time a bleeping sound will be heard, and the
symbol will flash for approximately 2 minutes.
After approximately 2 minutes the bleeping sound will stop and the
symbol will go out automatically.
Step 4 To cancel the bleeping sound within the two minutes press the
Minute Minder button.
A
U
T
O
Minute
Minder Cook Period End Time Manual
Minute
Minder Cook Period End Time Manual
Bell Symbol
Minute
Minder Cook Period End Time Manual
Minute
Minder Cook Period End Time Manual
Note 1 When the Minute Minder has been set, the time remaining can be
checked at any time by simply pressing the Minute Minder button.
Note 2 If necessary the Minute Minder can be cancelled before the tone sounds
by pressing and holding the Minute Minder button and then at the same
time pressing the “–” button until 0.00 appears in the display window.

ELECTRONIC CLOCK & AUTOMATIC
OVEN TIMER OPERATION
11
Step 3 Press and hold in the Cook Period button.
The display will read 0.00 with the cookpot ( ) symbol lit.
Step 4 With the Cook Period button still held in, set the required Cook
Period using the “+” and “–” buttons.
Release the buttons and the timer display will revert to the time of day
with the Auto symbol and Cookpot ( ) symbol lit.
Step 5 Press and hold in the “End Time” button.
The display will read the earliest possible end time for the Cook
Period that you have set above.
The Auto symbol and Cookpot ( ) symbol lit.
Step 6 With the End Time button still held in, use the “+” and “–”
buttons to set the “End Time” (i.e. The time you require the oven
to switch off).
Release all the buttons and the timer will revert back to the time of day.
The “Auto” symbol will remain lit to signify that an Auto Cooking
Programme has been set. The ( ) symbol will go out.
Step 7 Turn the oven control(s) to the required temperature, and if
necessary select the appropriate oven function.
Note: If your appliance has two ovens: When the timer has been
set for one oven it is possible to use the other oven only during the
same Automatic programme.
At the end of the Automatic Cook Period the Auto Symbol will flash and
an intermittent bleeping sound will be heard.
The bleeping sound will continue for approximately 2 minutes unless
cancelled. The “Auto” symbol will continue to flash until the timer is
returned to Manual operation (see below).
Step 8 Press the Manual button to cancel the bleeping sound. (If 2
minutes has not elapsed).
Step 9 Turn the oven control(s) to the OFF position.
Step 10 Press the manual button again to return the oven(s) to Manual
Operation. (The Auto symbol will go out)
AUTO COOKING PROGRAMMES
There are two Auto Cooking programmes that can be selected using your timer:–
(a) To set the timer to switch the oven(s) On and Off Automatically
(b) To set timer to switch on immediately and OFF automatically after a set cook period.
a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY
This allows you to cook at a specified time for a chosen period before the oven
switches off Automatically.
Step 1 Check that the correct time of day is set, if not follow instructions for setting the
time of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).
Cooktop Symbol
A
U
T
O
A
U
T
O
Minute
Minder Cook Period End Time Manual
A
U
T
O

ELECTRONIC CLOCK & AUTOMATIC
OVEN TIMER OPERATION
12
Step 4 Press & hold in the “Cook Period” button, the display will read
0.00 and the cookpot ( ) symbol will light up.
With the Cook Period button still held set the required Cook Period
using the “+” and “–” buttons. Example: 1hr 30 minutes (as shown).
Note: Cook Period is the length of time the food requires to cook.
Step 5 Release all buttons.
The timer display will revert to the time of day with the Auto symbol lit &
Cookpot symbol remaining lit.
At the end of the Cook Period the “Auto” symbol will flash and an
intermittent bleeping sound will be heard.
The bleeping sound will continue for approximately 2 minutes unless
cancelled. The “Auto” symbol will continue to flash until the timer is
returned to Manual operation (see below).
Step 6 Press the manual button to cancel the bleeping.
(If 2 minutes has not elapsed)
Step 7 Turn the oven control(s) to the OFF position.
Step 8 Press the “Manual” button again to return the cooker to Manual
operation. (The Auto symbol will go out).
b) TO SET TIMER TO SWITCH ON IMMEDIATELY AND OFF AUTOMATICALLY
AFTER A SET COOK PERIOD
Step 1 Check that the correct time of day is set, if not follow instructions for setting the time
of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).
Step 3 Turn the oven control(s) to the required temperature, and if necessary select the
appropriate oven function.
A
U
T
O
Minute
Minder Cook Period End Time Manual
Cookpot Symbol
A
U
T
O
A
U
T
O
Minute
Minder Cook Period End Time Manual
A
U
T
O
Minute
Minder Cook Period End Time Manual
Note: Cookpot symbol disappears
Note 1 When cooking automatically the Cook Period can be checked at any time
by simply pressing the Cook Period button.
Note 2 When cooking automatically the End Time can be checked at any time by
simply pressing the End Time button.

ELECTRONIC CLOCK & AUTOMATIC
OVEN TIMER OPERATION
13
OTHER NOTES ON TIMER OPERATION
1. When cooking Automatically the Cook Period can be checked at any time simply by pressing
the Cook Period button.
2. When cooking Automatically the End Time can be checked at any time by simply pressing the
End Time button.
3. Having set a Cook Period and End Time an electronic device stores the information. The device
within the timer will switch the oven(s) on and off at the required times.
4. When setting an Auto Cooking Programme and a mistake is made, to clear:–
(a) Press and hold in the “Cook Period” button.
(b) With the Cook Period button still held in, return the display to by pressing the “–”
button.
(c) Release the “Cook Period” & “–” buttons, and the display will revert to the time of day and
the “Auto” symbol will flash.
(d) Press & release the “Manual” button.
(e) Start the sequence again.
5. If at any time the display shows three flashing zero’s 0.00. It is likely that the electricity supply
to the oven has been interrupted. Reset the timer to the correct time of day.
Food in the oven may, therefore, not have been cooked, before serving check food is
thoroughly heated and completely cooked.
6. To set each function always press and hold the required function button and at the
same time press “+” or “–” buttons.
Note: Between the hours of 22.00 & 06.00 the display dims to prevent glare.
However, if you should operate a button during this period, the timer will return to
normal brightness for a few seconds and then dim again.
A
U
T
O
TO CANCEL AN AUTO COOKING PROGRAMME BEFORE
THE COOK PERIOD HAS FINISHED.
Step 1 Turn the oven control(s) to the OFF position.
Step 2 Press and hold in the “Cook Period” button.
Step 3 With the “Cook Period” button still held in, return the display to
0.00 by pressing the “–” button.
Step 4 Release the “Cook Period” and “–” buttons and the display will
revert to the time of day and the “Auto” symbol will flash.
Step 5 Press the “Manual” button to return the oven(s) to “Manual”
operation. The “Auto” symbol will go out.
A
U
T
O
Note 1 When cooking automatically the Cook Period can be checked at any time by
simply pressing the Cook Period button.

The grill pan handle is detachable from the pan, to facilitate cleaning and storage.
The grill pan handle can be fixed as follows:
Step 1 Remove screw & washers from the grill pan bracket (a).
Step 2 Tilt the handle over the recess (b).
Step 3 Slide it towards the centre of the pan (c).
Step 4 Locate the handle over the bracket (d).
For a fixed handle, replace screw & washers and ensure they are fully
tightened up. If a detachable handle is required, do not replace screw &
washers.
GRILL PAN AND
FOOD GRID
DOOR POSITION FOR
GRILLING
GRILL PAN & HANDLE
14
Note: If a fixed handle is required, the grill pan is unable to be stored in the oven
with the door closed and cannot be used as a meat pan.
Note:Do not grill with the grill/oven door
closed.
Step 1 Step 2 Step 3 Step 4
GRILL PAN FOOD GRID
(a)
(b) (c) (d)

GRILLING PROCEDURE
15
Note: DO NOT allow young children near to the appliance when the grill is in use as
the surfaces get extremely hot.
Step 1 Ensure oven timer is set to manual.
Ensure the oven shelf is in the correct position (see Guide to Grilling
Successfully).
Ensure door is in the grilling position (see grilling page)
Step 2 Turn knob (A) clockwise to full or half grill function.
NOTE: Resistance will be felt when turning from fan oven operation to
full / half grill position.
Step 3 Turn knob (B) clockwise to select the Grill Setting (1–6).
(1=Low, 6=High).
NOTE: When using the grill, a gentle flow of air will be detected coming from
beneath the control panel.
Step 4 After use, turn both controls A & B to their off (0) position and close
the oven door.
Notes:
• Ensure oven timer is set to manual.
• Preheat the grill at setting 6 on the grill control for approximately 5 minutes.
• The grill pan must be placed on the correct shelf and positioned centrally
under the grill element.
• Leave the control at 6 for toast, and for fast cooking of foods.
• For thicker foods requiring longer cooking, turn the switch to a lower setting
after the initial sealing on both sides at 6. The thicker the food, the lower the
control should be set.
• If excessive smoke is emitted reduce the setting.
•Do not line the grill pan with aluminium foil as this increases the amount of
fat spitting.
• Ensure that the Grill Pan is cleaned after use. Excessive fat build-up in the
bottom of the pan could cause a fire hazard.
• After use, always return both controls to their OFF (O) position.
❍❍ ❍❍❍❍❍❍
BA

Since a circulaire fan oven heats up more quickly, and generally cooks food at a lower
temperature than a conventional oven, pre-heating is often unnecessary. For guides on
“pre-heating”, “cooking temperatures” and “cooking times”, see “Oven Temperature
Charts” later in book.
OVEN SHELF POSITIONING FOR FAN OVEN
Most foods will cook satisfactorily on any shelf position, due to even distribution
of heat in the oven, but the shelves must be evenly spaced.
Food or utensils should never be placed directly on the floor of the oven
for cooking as air circulation is restricted.
OVEN UTENSILS
Do not use: Meat pans larger than 375mm x 300mm (15” x 12”)
Baking Trays larger than 325mm x 250mm (13” x10”)
An additional oven shelf can be purchased from your oven supplier if a third
one is required for batch baking. Never use more than three shelves in the oven
as air circulation will be seriously restricted.
TEMPERATURE & TIME
If three shelves are in use to cook large quantities of food, it may be necessary
to increase the cooking times given in the temperature charts by a few minutes,
to allow for the loss of heat due to extra time taken to load the oven, and the
larger mass of food. Baking trays should have an even gap around the oven.
USING THE OVEN FOR FAN COOKING
16
NOTE: Charts are a guide only, to suit personal taste and requirements, it may be
necessary to increase or decrease temperatures by 10˚C. It may also be necessary to
increase or decrease cooking times.
DO NOT allow young children near to the appliance when the oven is in use as the
surfaces get extremely hot.
Fan
Oven

FAN OVEN OPERATION
Step 1 Ensure oven timer is set to manual.
Ensure that the oven shelf is in the correct position.
Place food centrally on the shelf ensuring the oven door is fully
closed.
Step 2 Turn knob (A) clockwise and select the required cooking
temperature . The pilot light (●) will immediately come on, and
remain on until the oven reaches the required temperature. The light
will then automatically go off and on during cooking as the oven
thermostat maintains the correct temperature.
Step 3 After use turn control (A) to its Off (O) position.
NOTE: At the end of a cooking period there may be a momentary puff of
steam when the door is opened. This will disperse in a few seconds
and is a perfectly normal characteristic of an oven with a good door
seal.
USING THE OVEN FOR FAN COOKING
Fan
Oven
17
❍❍ ❍❍❍❍❍❍
BA

“SLOW” SETTING
This is used for slow cooking, keeping food warm and warming plates for short
periods. Extra care should be taken when warming bone china, as it may be
damaged in a hot oven.
ADVANTAGES OF SLOW COOKING ARE:
The oven stays cleaner because there is less splashing.
Timing of food is not as critical, so there is less fear of overcooking.
Inexpensive joints of meat are tenderised.
Fully loading the oven can be economical.
Cooking times can be extended in some cases by up to 2 hours.
The kitchen stays cooler.
OPERATION:
1. Place the prepared food in the main oven and ensure the door is fully closed.
2. Turn knob A to (slow cooking temperature).
STORAGE & RE-HEATING OF FOOD:
1. If food is to be frozen or not used immediately, place it in a clean container and
cool as soon as possible.
2. Always thaw frozen food completely in the refrigerator before re-heating.
3. Always reheat food thoroughly and ensure it is piping hot before serving.
4. Only re-heat food once.
POINTS TO CONSIDER WHEN PREPARING FOOD FOR SLOW COOKING
1. Make sure that the dishes to be used will fit into the oven ensuring enough room
for air to circulate.
2. All dishes cooked on the slow setting will require a minimum of 6 hours,
however, it they are cooked for 1-2 hours longer then deterioration in their
appearance may be noticed.
3. Never cook joints of meat over 2.7kg (6 lb) or poultry over 2.0kg (4lb 8oz).
We do not recommend that joints of meat or poultry are stuffed before cooking
on the slow setting.
4. To seal in the meat juices, always cook meat or poultry at 170oC for 30 minutes
before wrapping in foil and placing on a rack over a tin (to allow good air
circulation) before turning the control to the slow setting and cooking immediately.
5. Always ensure that joints of pork and poultry are thoroughly cooked by checking
with a meat thermometer before serving.
6. Always thaw frozen foods completely before cooking. We do not recommend
placing frozen food in the oven to cook.
7. Always bring soups, liquids and casseroles to the boil before placing in the oven.
8. Ensure that casserole dishes have a good seal (not airtight) and cover to the top
with foil to prevent loss of moisture.
9. Ensure that fruit and vegetables are cut into even sized small pieces to cook
properly.
10. Always adjust seasoning before serving.
11. If using dried red kidney beans it is important that the beans are soaked and
then boiled for a minimum of 10 minutes before using in any dish to destroy any
toxins.
12. When cooking fish or egg dishes it may be necessary to check during cooking to
avoid overcooking.
USING THE OVEN FOR OTHER FUNCTIONS
18
90
DO NOT place food or plates directly on the oven floor as this could damage both the
oven lining and the plates which are being warmed.
90
E
E

oF
Gas
Mark
1/2
1
250 100
120
130
140
160
170
180
200
210
220
120
140
150
160
180
190
200
220
–
–
275
300
325
350
375
400
425
450
475
2
3
4
5
6
7
8
9
Main
Conventional
Oven
Main
Fan
Oven
TEMPERATURE CONVERSION SCALE
19

Fan Oven Cooking
Meat
Beef
Lamb
Pork
Veal
Chicken/Turkey
up to 4kg (8lb)
Turkey up to
5.5kg (12lb)
Turkey over
5.5kg (12lb)
Casserole /
Stews
Food
Temperature
oC
Time
(approx.)
Pre-
heat
No 160/180 20-25 mins per 450g (1lb)
+ 20 mins extra
25 mins per 450g (1lb)
+ 25 mins extra
25 mins per 450g (1lb)
+ 25 mins extra
25-30 mins per 450g (1lb)
+ 25 mins extra
18-20 mins per 450g (1lb)
+ 20 mins extra
13-15 mins per 450g (1lb) e.g.
5kg (11lb) = 143-165 mins
12 mins per 450g (1lb) e.g.
10kg (22lb) = 264 mins
11⁄2- 2 hours
160/180
160/180
160/170
160/180
150/160
150
A140/150
No
No
No
No
No
No
No
Note: Up to three shelves may be used in this oven. The position
of these is not important providing they are evenly spaced.
IF USING ALUMINIUM FOIL
1. Never allow foil to touch sides of oven. 2. Never cover interior with foil.
3. Never cover shelves with foil.
The most accurate method of testing the readiness of joints of meat or whole
poultry is to insert a meat thermometer into the thickest part of a joint of meat,
or the thickest part of poultry thighs, during the cooking period. The meat
thermometer will indicate when the required internal temperature has been
reached.
OVEN TEMPERATURE CHARTS – MEAT
Beef
Rare 60OC Medium 70OC90
OC80 OC90 OC75 OC
Well Done 75OC
Pork Lamb Poultry Veal
20
