Hotpoint SC88X User manual

InstructionsforInstallationandUse
Electric Multifunction Oven
Model SC88X
The Recipe Book
Hotpointhascomeupwithasmallrecipebook-whichispractical,fullofhelpfultipsandeasytouse-tohelpyou
rediscoverthedelightsofcooking.
Itcontainsawidevarietyof handy tips to keep in mind to try out newdisheseffortlessly.
Italsohas 15recipespreprogrammedinto the oven,sothanksto theinteractivedisplay,once you havedonethe
preparationallyou have to doismakeone simple selection.

3
CONTENTS
Introduction
For Your Safety
Know your Oven
The Controls
Setting the Oven to Switch On and Off
Automatically
Cooking Advice
Cooking Chart
Care and Cleaning
Installation
Electrical Connection
After Sales Service
Hotpoint Guarantee
Key Contacts
4
5
6
7-9
9
10
12
13
14-15
16
18
19
Back Cover
Retention of this Instruction Book
ThisInstructionBook must bekepthandyfor reference asitcontainsimportant details onthesafeand proper useofthe
appliance.
Ifyousell orpasstheappliance tosomeoneelse,or movehouseandleave itbehind,makesure thisBookisalso provided
sothenewowner can become familiar withtheapplianceandsafetywarnings.
IftheBookislostor damaged a copy may be obtained from:
GDALTD.,MorleyWay,Peterborough,PE29JB

4
Yournewelectricovenis guaranteed* and will give lasting service. Thisguaranteeisonlyapplicableifthe appliance has
beeninstalled inaccordancewiththe installationinstructionsdetailed inthisbooklet.
Tohelpmake best use ofyourcookingequipment, please read thisbookletcarefully.
Theovenis designed specifically for domesticuseandresponsibilitywill not be acceptedforuseinany other installation.
Introduction
Tohelp removethe'new'smell,heat theemptyoventomaximum temperaturefora minimumoftwotothree hours,keeping
the door/s closed. Ensure that the room is well ventilated (eg. open a window or use an extractor fan) and that persons
whomaybe sensitivetotheodour avoidanyfumes. Itis suggestedthatanypets beremovedfromthe roomuntilthesmell
has ceased.
Thisodourisdueto any temporary finish on oven liningsandelementsandanymoistureabsorbed by the insulation.
Note: When the oven is first used, an odour may be omitted - this will cease after a short period of use.
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with this booklet.
(b) Has been properly connected to a suitable supply voltage as stated on the rating plate, attached to the
appliance.
(c) Has not been subjected to misuse or accident or been modified or repaired by any person other than the
manufacturersauthorised employee or agent.
(d) Has been correctly installed.

5
For Your Safety
ALWAYS:
- make sure you remove all packaging and literature from
insidetheappliance beforeswitchingonfor thefirsttime.
- check the soundness of the appliance after it has been
unpacked.
- make sure you understand the controls before using the
appliance.
- keep children away from the appliance during use, as
surfaceswillgetextremelyhotduringandaftercooking.Care
shouldbetakentoavoidtouchingtheheatingelementsinside
theoven duringuse.
-makesurethecontrolsareturnedoffwhenyouhavefinished
cookingandwhennotin use.
-gripthe handle in thecentrewhenopening the door.
- stand back when opening the door to allow any build up
ofsteamorheattodisperse.
-usedry,goodquality oven gloves when removing items.
- take care to avoid heat/steam burns when operating the
controls.
- switch off the electricity supply at the wall switch, and
allowtocool,before cleaningorperformingmaintenance..
- make sure the shelves are in the correct position before
switchingonthe oven.
-keep thedoorpartiallyopenwhen grilling,butclosedwhen
fangrilling.
-keep the door closed when the applianceis not in use.
- keep the appliance clean as a build up of grease or fat
fromcooking can causeafire.
-followthe basicprinciplesoffood handling andhygieneto
preventthepossibility of bacterialgrowth.
-keepany ventilation slotsclearofobstructions.
When used properly your appliance is completely safe but as with any electrical product there are certain
precautions that must be observed.
PLEASE READ THE BELOW PRECAUTIONS BEFORE USING YOUR APPLIANCE.
Tomaintainthe efficiency and safety ofthisappliance,werecommend you do thefollowing:
-onlycall theServiceCentresauthorised bythemanufacturer.
- always use genuine spare parts.
NEVER:
- attempt to install or repair the appliance without the
assistanceof qualifiedpersonnel.
- operate the "grill" mode kwith the door closed, as this
may cause the appliance to overheat.(Although "Gratin"
fannedgrillmode lis donewiththedoor closed).
- removethe oven shelves whilst the oven is hot.
-allow anyone to sit or stand on any partof the appliance.
-store items abovetheappliance thatchildrenmayattempt
toreach.
-heatupunopened food containers, as pressurecanbuild
upcausingthe container toburst.
-use the appliance to heat up anything other thanfood.
-use the appliance as a room heater.
-usethegrilltowarmplates.
-dryitemson the oven doors.
-installtheappliancenexttocurtainsofothersoftfurnishings.
-allowchildrento play with or tamperwiththecontrols.
-usesteamcleaners.
-usetheovenforstoragepurposes.
-useflammableliquids near the appliance.
-useadapters,multiple sockets and/or extension leads.
- pull on the appliance or the supply able to unplug it from
theelectricaloutlet.
-allowpowercablesofotherappliancestocomeintocontact
withhot parts of this appliance.
- expose the appliance to atmospheric agents, such as
rainorsunlight.
- operate the appliance with wet hands.
-operatetheappliancewhenbarefoot.

6
Know your Oven
A. ControlPanel
B. Function Selector
C. Cooking temperature / time selection knob
D. Electronic programmer
F. GrillPan /BakingTray
G. Oven Shelf
H. Guidesfor sliding theshelves or GrillPan inandout
1. End cooking time setting/ clock/ date
2. Control panel lock / timer / set cooking time
3. Language setting
4. Start cooking / stop cooking / oven light / display
brightness
5. Functiondescription
6. Functionnumber
7. Cooking time
8. End cooking time
9. Graduated temperature scale
10.Energypercentage for grillfunctions
11.Time or temperature / energy percentage
12.Electric elements in use
13.Clock display
14.Programmedcookingindicator
BC
D
250
150
200
100
40
C
PI ZZA
G
A
F
H
250
150
200
100
40
C
PI ZZA
2
61013 912
11 16 151
8
14
7
435

7
The Controls
The 7Chefs ovencombinestheadvantagesofaconvection
ovenwiththoseoffanassistedmodelsinasingleappliance.
It is extremely versatile allowing you to choose easily and
safelybetweendifferentcookingmodes.Thevariousfeatures
offeredby the oven are selected by meansof the function
selector"B"situatedonthe controlpanel.
Setting Time and Date
Selecting the language
Press button 3for a few seconds with the oven turned off.
Thelanguages availableappearinsequenceon thedisplay
panel. Pressbutton 3againtoselectthe desired language.
Setting the clock
Theclockcanonlybe set if the oven is turnedoff.
Aftertheappliancehasbeenconnectedtothepowersupply,
or following a power failure, the clock displays a flashing
12:00orthelasttimememorised.
Thetimecanbe changedbypressingbutton1andresetting
theclockusingknob"C",whichyoucanmodifyonlywhilst
thescrolling writingcrossesthedisplay.
Setting the date
Toupdatethedate,pressandholddownbutton1until the
word"YEAR"comesup on the display.Updatetheyearby
turningknob"C" and then press button 1to set the month,
again using knob "C". Press button 1again to set the day
usingknob"C".Press button 1tomemorisethedateset.
Minute Minder Feature
Thetimercanonly operate when the ovenisturnedoff.
Please remember that the timer does not control the
startingorstoppingoftheoven,it merely sounds a buzzer
when the time is up and can be interrupted at any time
just by pressing a button.
To set the Minute Minder, press button 2, and then make
thenecessaryadjustment using knob "C".
Press button 4to start the timer.
Atalltimes duringtheMinuteMinder operation,youmay:
• adjust its duration using knob "C";
• stop the countdown by pressing button 4for
approximately 3 seconds or turning knob "B" anti-
clockwise;
• enable/disable the control panel lock, by pressing
button 2for at least 3 seconds (see the paragraph
entitled"LockingandUnlockingtheControlPanel").
Lockingand Unlocking theControl Panel
Thisoptionenablestheusertolockallthebuttonsandknobs.
We especially advise you to use this option if there are
children present. To enable the control panel lock, press
button 2for a few seconds. The word "LOCKED" comes
up on the display. To restore the usual commands to the
appliance,justpress button 2againfora few seconds.The
word "UNLOCKED" will come up on the display.
Selecting the display panel brightness
To update the brightness, press and hold down button 4
untiltheword"BRIGHTNESS"comesuponthedisplay.
Turn knob "C" clockwise/anticlockwise to increase/
decrease the brightness of the display panel. A few
seconds after this selection, the oven will be ready for
further instructions.
The oven light
Atanytime, including during pre-heating andcooking,you
canturn the oven light on or offbypressing button4.When
the oven is turned off, the light turns off automatically 10
minutes after the last instructions were entered onto the
control panel.
Cooling ventilation
In order to reduce the external temperature of the oven,
thisappliance hasbeenequippedwith acoolingfan.During
cooking, the fan is always on and a normal flow of air can
be heard exiting between the oven door and the control
panel.
In order to raise the temperature inside the oven more
quickly during pre-heating, the speed of the air outlet is
approximately half the speed of air outlet during cooking.
Ifthereisa hob abovetheoven,thecooling fanmayswitch
itself on automatically to protect the electronic
components, even if the appliance has been switched off.
Note: When cooking is done, the fan stays on until
the oven cools down sufficiently.
How To Choose a Cooking Mode/Function or a Pre-
Set Recipe:
Turnthefunction selector"B"clockwise tochoosefromthe
default cooking modes or from the pre-entered recipes
available(seetherecipebook).
For each cooking mode, the display will indicate the
following:
• the cooking mode name (or that of the recipe);
• the cooking mode number (or that of the recipe);
• the default temperature;
• the heat sources;
Should the recommended temperature not be to your
liking,youcanalwaysadjust it using control "C".
Each cooking mode is also associated with a
recommended cooking time, which you can modify, from
one minute to 10 hours, by pressing button 2and then
turningcontrol "C"tosetittothedesiredvalue. Thecooking
timecanbe adjusted until thescrollingwordingdisappears
completely from the display panel.The selected cooking
time does not include the time required for preheating the
oven.
To start cooking, press cooking start button 4.
With the exception of the "Fast cooking" and "Grill"
modes, the oven will now begin the pre-heating stage,
during which you may still:
• changethe temperaturebyturningcontrol"C";
• change the cookingtime bypressing button 2andthen
turningcontrol"C";
• enable/disable the control panel lock, by pressing but-
ton 2for at least 3seconds (see the paragraph enti-
tled "Locking and Unlocking the Control Panel");
• stopcookingandturn theovenoffbyturningthefunction
selector"B"anti-clockwise.
Note: pre-heatingis performed automatically in the oven,
whichsetsthepre-heatingtime according to the tempera-
tureselected bytheuser. Thedisplaypanelwillfeaturehow
longtheoven will take to preheatbeforecookingstarts.

8
Oncethetemperaturesethasbeenreached,theovenstarts
thecookingstage itself,duringwhichyou maystill:
• changethetemperature by turningcontrol"C";if youin-
creaseit bymorethan 25°C,theoven returnstothe pre-
heatingmode;
• change the cookingtime bypressing button 2andthen
turningcontrol"C";
• enable/disable the control panel lock, by pressing but-
ton 2for at least 3seconds (see the paragraph enti-
tled "Locking and Unlocking the Control Panel");
• stopcookingandturn theovenoffbyturningthefunction
selector"B"anti-clockwise.
Once cooking is finished, the wording "END-READY" will
comeupon the display, and abuzzerwillsound,which will
stopafter 1minute,after youpressabuttonorafteryouturn
one of the two knobs.
Cooking modes
Thecooking modesareselected byturningthefunction
selector"B".
Traditionalf
Positionknob“C”:between40°C and 250°C.
Thetopandbottomheatingelementsareused.Inthismode,
the coolest part of the oven is the centre. The convection
ovenisbest for cooking dishesmadeupof several ingredi-
ents,e.g.tender vealstripswithrice, braisedmeats,stews,
goulash etc. and dishes that need to cook slowly and re-
quirebasting ortheadditionofliquid andcookingusingcov-
ered casserole dishes for oven baking. When cooking in
convection mode, only use one baking tray or shelf at a
time,otherwisethe heat distribution will be uneven. Using
the different shelf position available, you can balance the
amountof heatbetweenthe topandthebottomoftheoven.
Select from among the various shelf positions based on
whetherthedish needs more orlessheatfrom the top.
Pastry g
Positionknob“C”: between 40°C and 250°C.
Therearheating element and thefancomeon, guarantee-
ingdelicateheatdistributeduniformlythroughouttheoven.
Thismode is ideal for baking and cookingdelicate foods -
especiallycakesthatneedtorise-andforthepreparation
ofcertaintartlets on 3 shelvesatthesame time. Here area
few examples: cream puffs, sweet and savoury biscuits,
savourypuffs,Swiss rolls and small portionsofvegetables
augratin,etc…..
In this case, use the baking tray as a dish support and
placeiton the 2nd shelf positionfromtheovenbottom.
Werecommendyoupre-heat the oven before placingyour
dishesinit.
“Fast cooking”h
Positionknob“C”: between 40°C and250°C.
Allthe heating elements are activated alternately, and the
fancomeson,guaranteeingconstant heat distributed uni-
formlythroughouttheoven.
Thismodeisespeciallyrecommendedforcookingpre-packed
foodquickly(aspre-heating is not necessary), suchasfro-
zen or pre-cooked food as well as for a few “home-made”
dishes.
Thebestresultswhencookingusingthe“Fastcooking”mode
areobtainedifyouuseone shelf position only (the second
fromthebottom).
Multi-cooking i
Positionknob“C”: between 40°C and250°C.
All the heating elements are activated alternately and the
fancomes on.Sincetheheatremains constantanduniform
throughout the oven, the air cooks and browns food uni-
formlyoveritsentiresurface. With this mode, you can also
cook various dishes at the same time, as long as their re-
spectivecookingtemperaturesarethesame.Amaximum
of 2 shelves can be used at the same time, following the
instructionsinthe sectionentitled:“CookingOn More Than
OneShelf”.
Thiscookingmode is particularly recommendedfordishes
requiringagratinfinishor for those requiring considerably
prolonged cooking times, such as for example: lasagne,
pastabakes,roastchickenandpotatoes, etc… Moreover,
theexcellent heatdistributionmakesitpossibletouse lower
temperatureswhen cooking roasts.Thisresults inlessloss
ofjuices,meatwhichismoretenderandadecreasein the
lossofweightfor theroast.TheMulti-cookingmodeisespe-
ciallysuited forcookingfish,whichcan bepreparedwiththe
additionofalimitedamountof condiments,thus maintaining
their flavour and appearance. Excellent results can be at-
tainedwhencookingvegetable-based sidedisheslikecour-
gettes,aubergines,peppers etc.
Desserts: this mode is also perfect for baking leavened
cakes.
The"Multi-cooking"modecanalso be used to thaw red or
white meat, fish and bread, by setting the temperature to
80°C. To thaw more delicate foods, set the temperature
controlto60°C.
Pizzaj
Positionknob“C”: between 40°C and250°C.
All the heating elements are activated alternately and the
fancomeson.
The pizza mode is ideal for foods requiring high tempera-
tures to cook, like pizzas and large roasts. Only use one
bakingtrayorshelfatatime.However,ifmorethanoneis
used,thesemust be switched halfwaythroughthecooking
process.
The Controls

9
Setting the Oven to Switch On and Off Automatically
To programme the cooking mode, follow the instructions
below:
•selectthe cooking modebyturning thefunctionselector
"B",andthetemperature byturningcontrol "C".
•set the cooking time by pressing button 2. The
recommended cooking time comes up on the display,
and you can adjust this by turning control "C". Please
remember that the time entered does not include the
necessarypre-heatingstage.
•settheendcookingtimebypressingbutton1.Turncontrol
"C" until the display panel features the time you want
the food to be ready. The display panel will feature the
end cooking time and the start time is calculated by
subtracting the cooking time, as well as the time
necessary for the oven to preheat (automatically
calculated by the appliance according to the cooking
modeselected).
Aftertheseselectionprocedures,thedisplaypanelwill
showthetimeatwhichpreheatingwillcommence(where
required),and thatatwhich cookingwillfinish.Thefinish
time can still be altered up until the cooking mode and
temperaturereappearsonthedisplaypanel.Anyincorrect
data can be corrected simply by repeating the above
instructions.
Thisinformation willnowberemembereduntilyoupress
startorturnselector2.
•pressbutton4tostarttheprogramme.
To modify the settings made, press button 4for
approximately 3seconds and repeat the above
procedures.
Tocancel acooking programme
Tocancel anyprogrammewhichhasbeenentered,turn the
function selector "B" anticlockwise until the word "OFF"
appears on the display panel.
The Controls
Grill k
Positionknob“C”:50%, 75%, 100%.
Thetop centralheatingelement comeson.
Theextremelyhighanddirecttemperatureofthegrillmakes
it possible to brown the surface of meats and roasts while
locking in the juices to keep them tender. The grill is also
highlyrecommendedfordishesthatrequire ahigh tempera-
tureonthe surface:beefsteaks,veal, rib steak,filets,ham-
burgersetc...
Alwaysleavethe ovendoorajarduring cooking.
Note: turnknob“C”andthedisplay willindicatethe 3differ-
entenergypercentageswhichrepresenttheminimum(50%),
medium(75%)andmaximum setting(100%)respectively.
Gratinl (fanned grill)
Positionknob“C”:between40°C and 200°C.
Thetopcentral heatingelementandthe fan comeon.
Thiscombinationof featuresincreasestheeffectiveness of
the heating elements through forced circulation of the air
throughouttheoven.This
helps prevent food from burning on the surface, allowing
theheattopenetraterightinto thefood. Excellentresultsare
achieved with kebabs made with meats and vegetables,
sausages,ribs, lambchops,chicken inaspicysauce,quail,
porkchops, etc.
Allcooking using“Gratin” mustbedone withthe oven
doorshut.
Thismodeisalsoideal for cooking fish steaks, like sword-
fish,tuna etc.

10
Cooking Advice
The oven offers a wide range of alternatives which allows
you to cook any type of food in the best possible way.
Withtime youwilllearntomake thebestuseofthis versatile
cookingappliance andthefollowingare onlyaguide, which
maybevariedaccordingtoyourownpersonaltaste.
Cooking on More Than One Shelf
Ifyouhavetocookfoodonseveralshelves,useeitherthe
“pastry” mode gor the i“Multi-cooking” mode, as
these are the only modes that allow you to do so.
Whencookingdelicatefood onmorethanoneshelf,usethe
“pastry” mode,gwhichallows you tocookon 3 shelves
at the same time (the 1st, 3rd and 5th from the bottom).
Someexamplesare includedinthe“Cooking Chart”.
Whencookingotherfoodonseveralshelves,usethe“Multi-
cooking” modeikeepingthe following suggestions in
mind:
• The oven is fitted with 5 shelves. During fan assisted
cooking,use two ofthethree centralshelves;thelowest
andhighestshelvesreceivethehotairdirectlyandthere-
foredelicate foodstuffscouldbeburnt ontheseshelves.
• As a general rule, use the 2nd and 4th shelf from the
bottom,placingthefoodstuffsthatrequiregreaterheat
on the 2nd shelf from the bottom. For example, when
cookingmeatroaststogether with other food, placethe
roastonthe2ndshelf position from the bottom and the
moredelicate foodonthe 4thshelfpositionfromthebot-
tom.
• When cooking food that require differing times and
temperatures, set a temperature that is somewhere
betweenthetwo temperaturesrequired,placethe more
delicate food on the 4th shelf position from the bottom
andtake thefoodrequiringlesstime outoftheovenfirst.
• Usethe baking tray on the lower shelfposition and the
shelfonthe upper;
Using the“Fast Cooking”Mode
Functional,fastandpracticalforthoseofyouwhouse
frozenorpre-cooked food alongwithotherfood items. You
willfinduseful suggestionsinthe“Cooking Chart” .
Using the Grill
The“7Chefs”ovenoffersyouseveraldifferentgrillingmodes.
Usethe k“grill” mode,with the oven door ajar, plac-
ingthefood inthecentreof the grillpan(situatedon the3rd
or4thshelffromthe bottom), because only the central part
ofthetop heating elementisturnedon.
Tocatchany fat and/orgreasethatmay drip fromtheshelf,
place the baking tray provided on the first shelf from the
bottom.
When using this mode, we recommend you set the tem-
peraturecontrolto thehighestsetting.Lower temperatures
canalso beset,simply bysettingthe temperaturecontrolto
thetemperaturerequired.
Setting l“Gratin”,is extremely useful for grilling foods
rapidly,as thedistributionofheat makesitpossible notonly
tobrownthesurface,butalsotocookthebottompart.
Moreover,it can alsobeused forbrowningfoodsat theend
ofthecookingprocess,suchasaddingthatgratinfinishto
pasta bakes.
When using this mode, place the shelf on the 2nd or 3rd
shelfposition from the bottom (see cooking table) then, to
preventfatand grease fromdrippingontothe bottom ofthe
ovenandthussmokefromforming,placeabakingtrayon
the1st shelfpositionfrom thebottom.
Important:always cook in “Gratin”mode with theoven
door shut. This will allow you both to obtain excellent re-
sultsandtosaveon energy (approximately 10%).
When using this mode, we advise you to set the tempera-
ture control to 200°C, as it is the most efficient way to use
the grill, which is based on the use of infrared rays. How-
ever, this does not mean you cannot use lower tempera-
tures,simply byadjustingthe temperaturecontrolto thede-
siredtemperature.

11
Cooking Fish and Meat
When cooking white meat, fowl and fish, use temperature
settingsfrom180 °Cto200°C.
Forredmeatthatshouldbe well done on the outside while
tenderandjuicy in theinside,itis a goodideatostart with a
hightemperaturesetting(200°C-220°C)forashorttime,then
turntheoven downafterwards.
In general, the larger the roast, the lower the temperature
setting.Placethe meat on the centreoftheshelfand place
thegrillpan/baking tray beneathittocatch the fat.
Makesurethattheshelfisinsertedsothatitisinthecentreof
the oven. If you would like to increase the amount of heat
frombelow,use the lowshelfpositions.
CookingPizza
Forbestresultswhencookingpizza,usesetting jfor“
Pizza Mode”:
• Preheattheovenforat least 10 minutes
• Usea light aluminium pizza pan, placing iton the shelf
supplied with the oven. If the baking tray is used, this
will extend the cooking time, making it difficult to get a
crispycrust;
• Donotopentheovendoorfrequentlywhilethepizzais
cooking;
• If the pizza has a lot of toppings (three or four), we
recommend you add the mozzarella cheese on top
halfwaythroughthe cookingprocess.
• If cooking on more than one shelf (up to 2), we advise
you to use the Multi-cooking Mode ias the Pizza
Mode jwould heat the bottom shelf more than the
others.
Cooking Advice
BakingCakes
When baking cakes, always preheat the oven. Make
sureyouwait untiltheovenhas preheated thoroughly(the
redoven indicator light"E"will goout).Donot openthe
ovendoor duringbakingtopreventthe cakefromdropping.
Ingeneral,if:
Cooked well on the inside but sticky on the
outside
Use less liquid, lower the temperature, and increase
the cooking time.
The pastry sticks to the pan
Grease the pan well and sprinkle it with a dusting of
flour or use greaseproof paper.
Pastry is too dry
Increase the temperature by 10°C and reduce the
cooking time.
Pastry dropped
Use less liquid or lower the temperature by 10°C.
Pastry is too dark on top
Place it on a lower rack, lower the temperature, and
increase the cooking time.
I used more than one level (in the function
"ventilated oven") and they are not all at the same
cooking point
Use a lower temperature setting. It is not necessary to
remove the food from all the racks at the same time.
Pastry has dropped
Place it on a lower shelf, lower the temperature and
It is cooked well on the inside but sticky on the
Use a lower temperature setting. It is not necessary to
remove the food from all the shelves at the same time.
You used more than one shelf (in the Multi-cooking
function) and they are not all at the same cooking point.

12
Setting made Type of food Weig-
ht (in
kg)
Position of
the rack from
the oven
bottom
Preheating
time (min.) Thermostat setting Cooking time
(min.)
1 Traditional
f
Duck
Roast veal or beef
Pork roast
Biscuits (short pastry)
Tarts
1
1
1
-
1
3
3
3
3
3
15
15
15
15
15
200
200
200
180
180
65-75
70-75
70-80
15-20
30-35
2 Pastry
g
Tarts
Fruit cakes
Plum cake
Sponge cake
Stuffed pancakes (on 2 racks)
Small cakes (on 2 racks)
Cheese puffs (on 2 racks)
Cream puffs (on 3 racks)
Biscuits (on 3 racks)
Meringues (on 3 racks)
0.5
1
0.7
0.5
1.2
0.6
0.4
0.7
0.7
0.5
3
2/3
3
3
2-4
2-4
2-4
1-3-5
1-3-5
1-3-5
15
15
15
15
15
15
15
15
15
15
180
180
180
160
200
190
210
180
180
90
20-30
40-45
40-50
25-30
30-35
20-25
15-20
20-25
20-25
180
3 Fast
cooking
h
Frozen food
Pizza
Courgette and prawn pie
Country style spinach pie
Turnovers
Lasagne
Golden Rolls
Chicken morsels
0.3
0.4
0.5
0.3
0.5
0.4
0.4
2
2
2
2
2
2
2
-
-
-
-
-
-
-
Max
200
220
200
200
180
220
15-18
25
30-35
20-25
35
25-30
15-20
Pre-cooked food
Golden chicken wings 0.4 2 - 200 20-25
Fresh Food
Biscuits (short pastry)
Plum cake
Cheese puffs
0.3
0.6
0.2
2
2
2
-
-
-
200
180
210
15-18
45
10-12
4 Multi-
cooking
i
Pizza (on 2 racks)
Lasagne
Lamb
Roast chicken + potatoes
Mackerel
Plum cake
Cream puffs (on 2 racks)
Biscuits (on 2 racks)
Sponge cake (on 1 rack)
Sponge cake (on 2 racks)
Savoury pies
1
1
1
1+1
1
1
0.5
0.5
0.5
1.0
1.5
2-4
3
2
2-4
2
2
2-4
2-4
2
2-4
3
12
10
10
15
10
10
10
10
10
10
15
230
180
180
200
180
170
190
180
170
170
200
15-20
30-35
40-45
60-70
30-35
40-50
20-25
10-15
15-20
20-25
25-30
5 Pizza
j
Pizza
Roast veal or beef
Chicken
0.5
1
1
3
2
2/3
10
10
10
220
220
180
15-20
25-30
60-70
6 Grill
k
Soles and cuttlefish
Squid and prawn kebabs
Cuttlefish
Cod filet
Grilled vegetables
Veal steak
Sausages
Hamburgers
Mackerels
Toasted sandwiches (or
toast)
0.7
0.6
0.6
0.8
0.4
0.8
0.6
0.6
1
n.° 4-6
4
4
4
4
3/4
4
4
4
4
4
-
-
-
-
-
-
-
-
-
-
100%
100%
100%
100%
100%
100%
100%
100%
100%
100%
10-12
8-10
10-15
10-15
15-20
15-20
15-20
10-12
15-20
3-5
7 Gratin
l
Grilled chicken
Cuttlefish 1.5 1.5 2 212 12 200 200 55-60 30-35
N.B.: cooking times are approximate and may vary according to personal taste. When cooking using the grill or
gratin, the dripping pan must always be placed on the 1st oven rack from the bottom.
Cooking Chart
Cooking
Function Shelf position
from bottom of
the oven.
(on 2 shelves)
(on 2 shelves)
(on 2 shelves)
(on 3 shelves)
(on 3 shelves)
(on 3 shelves)
NB. Thecooking times showninthis chart areapproximateand mayvaryaccording to personaltaste.
(on 2 shelves)
(on 2 shelves)
(on 2 shelves)
(on 2 shelves)
(on1 shelf)
Baking
Pastry

13
Care and Cleaning
- Always unplug the appliance from the mains or switch
offthemain switch before alloperations.
Insidethe oven
Werecommendyoucleanyouroveneachtimeyouuseit,
especially after cooking roasts. In fact, it is advisable to
prevent food residue from building up during cooking: the
residue would be re-cooked each time the oven is used
and would char and release smoke and unpleasant
odours.
Oven exterior
Clean the enamelled or stainless steel exterior surfaces of
your oven using a sponge soaked in soapy water, making
sure you rinse and dry these thoroughly, without using
abrasive or corrosive products which could damage them.
Stainless steel
Rinse stainless steel parts and dry them thoroughly using
asoft cloth.Useaspecific non-abrasiveproductto remove
tougher stains,
DONOTusealuminiumfoilto linethebottomoftheoven.
To avoid having to clean the bottom of the oven, you must
never be tempted to line it with some aluminium foil. We
stronglyadviseagainstthis. Thealuminiumfoilsheetin
directcontactwiththeheatedenamelcoatingcouldmelt
and damage the enamel coating inside the oven
irreversibly.
Cleaning the rotisserie and other accessories
Therotisseriecanberemovedcompletelyusing the2wing
nuts.Theelementscomprisingtherotisserieassemblyshould
becleanedtogetherwiththeotheraccessories(bakingtray)
inthesinkusingadampspongeandordinarydetergentorin
yourdishwasher.
Rubber Seal
Thereisarubbersealsurroundingtheovenopeningwhich
guaranteesitsperfectfunctioning. Checktheconditionofthis
seal on a regular basis. If necessary, clean it using warm
wateranddrythoroughly.
DONOTuseabrasiveproductsorobjectstodoso. Should
thesealbecomedamaged,pleasecontactHotpointService
(see KEY CONTACTS, back page). We recommend you
avoidusingtheovenuntilithasbeenrepaired.
Disassembling the oven door
The oven door can easily be removed to clean the space
betweenthe bottomofthedoorand thefrontoftheoven. To
disassemblethedoor,proceedasfollows:
-opentheovendoorfully,
-liftupandturnthesmallleverssituatedonthetwohinges,
-shutthedoor,butnotcompletely,
-grip the door on the two externalsides and pull it towards
you,pullingitoutofitsseat.
Reassemblethedoorbyfollowingthe above procedures
inreverse order.
132
123
Replacing the oven lamp
-Alwaysdisconnecttheappliance from the power supply
beforealloperations.
-Removetheglasscoverof the lamp holder.
-Removethelampandreplaceitwithalampresistantto
hightemperatures(300°C),withthefollowingcharacteristics::
-voltage 230/240 W
- wattage 25 W
- type E 14
- Replace the glass cover and ensure you reposition the
sealcorrectly.
- Reconnect to the power supply.

14
INSTALLATION
Theappliance must beinstalled only bya qualified per-
son in compliance with the instructions provided. The
manufacturerdeclinesallresponsibilityforimproperinstalla-
tion which may harm persons and animals and damage
property.
Important: The power supply to the appliance must be
cut off before any adjustments or maintenance work is
done on it.
Installation of Built-in Ovens
Inorderto ensurethatthebuilt-inappliance functions prop-
erly, the cabinet containing it must be appropriate. The
figure below gives the dimensions of the cut-out for
installation (N.B.: Installation in compliance with the
consumption declaration)
under the counter or in a wall
cabinet unit.
Inordertoensureadequateventilation,thebackpanelofthe
cabinet unit must be removed. Installing the oven so that it
restsontwostripsofwoodispreferable.Iftheovenrestsona
continuous, flat surface, there must be an aperture of at
least45x560mm.
Thepanelsof the adjacent cabinetsmustbemade of heat-
resistant material. In particular, cabinets with a veneer
exterior must be assembled with glues which can with-
stand temperatures of up to 100 °C.
In compliance with current safety standards, contact with
the electrical parts of the oven must not be possible once
it has been installed.
All parts which ensure the safe operation of the appliance
must be removable only with the aid of a tool.
For the correct centring of your appliance, position the 4
tabs on the sides of the oven in correspondence with the
4 holes on the perimeter of the frame.In particular, if the
cabinet side panel:
•is 20 mm thick:the removable part of the tab must be
removed (Fig. A);
•is 18 mm thick: use the first groove, which is factory-
set (Fig. B);
•is 16 mm thick: use the second groove (Fig. C).
Fig.A Fig.B
Fig.C
To fasten the oven to the cabinet, open the door of the
ovenandattach it by insertingthe4wood screws into the4
holeslocated ontheperimeterofthe frame.
595 mm.
595 mm.
24 mm. 545 mm.
5 mm.
567 mm.
23 mm.
593 mm.
45 mm.
558 mm.
N.B.: Installation in compliance with the consumption declaration
595 mm.
595 mm.
24 mm. 545 mm.
5 mm.
567 mm.
23 mm.
575-585 mm.
558 mm.
595 mm.
45 mm.
min.
45 mm.
min.
560 mm.
45 mm.

15
Fastening the oven to the cabinet :
1. Place brackets "A" up against the oven support "B".
2. Placethe tabs "C"up against brackets"A".In particular,
if the cabinet side panel:
•is 16 mm thick:mount the tab so that the number 16 it
features is facing you;
•is 18 mm thick:mount the tab so that the part without
any wording is facing you;
•is 20 mm thick:do not mount the tab.
3. Fasten the brackets andtabs on the ovencabinet side
panel using screws "D".
4. Fasten the oven to the cabinet using the screws and
plastic washers "E".
INSTALLATION
DA
B
D
D
16
16
16
16
C
C
C
E
E

16
Electricalconnection
Theelectrical connectiontothe mainsmustbemadeonthe
appliance. The power voltage and frequency are as
indicatedon theratingplate.
WARNING: THIS APPLIANCE MUST BE EARTHED.
Mounting the power supply cable
Toopen theterminalboard:
•Usingascrewdriver, pressonthetabs situated oneach
sideof theterminalboard cover.
•Pullopen theterminalboard cover.
Tomountthe power supply cable, proceed as follows:
•Unscrewthe cableclampscrew andthecontactscrews.
•Positionthejumpersaccordinglytothetypeofconnection
you wish to make as per the diagrams below.
•Note: The jumpers are factory set for a 230V single
phaseconnection.
•Fasten the power supply cable in the corresponding
cableclampandclosethe cover.
Power cable supply connection to the electrical
mains:
We recommend you use a power supply cable which is
longenoughto allow you to take the oven out of its recess
intheevent of maintenance operations (only use HAR - H
05-RRFqualitycablesfitted with a plug conforming to the
regulationsinforce.
Theplugmustbeaccessibleatalltimes.
Unplug the appliance before all operations, even when
replacing the oven lamp.
Using the appliance without correct earthing is highly
dangerous.
IMPORTANT:
Afterconnectingthe appliance to the flexiblecable,tighten
allthescrews on theterminalboard.
Electrical Connection
Thisapplianceconforms tothefollowingEEC Directives:
LowVoltageEquipment
73/23/EEC
93/68/EEC
ElectromagneticCompatibility
89/336/EEC
93/68/EEC
Inner dimensions of the oven:
width 43.5cm
depth 40.0cm
height 32.0cm
Inner volume of the oven: 56litres
Voltage and frequency of power supply:
230-240V
50-60Hz
2250-2400W
ElectricalConnections:
VoltageFrequency: 230 V-1+N 50Hz
FuseSection: 32A 4mm3
Youcan connect your oven to the systemmeans of a
terminalboard. Refertoaboveinformationfortheminimal
cablesectionsand thecalibrationofthe protective
elementsaccordingtotheconnection.
Iftheapplianceisinstalledwith a junction box, an
omnipolar circuit breaker -withaminimumcontact
openingof3mm-shouldbe installed between the
applianceandthemains.
••• • • •
LN
123 4 5
ENERGY LABEL
Directive 2002/40/EC on the label of electric ovens
NormEN50304
Energyconsumption for Natural convection
heating mode: fConvection
DeclaredenergyconsumptionforForcedconvectionClass
heating mode:gVentilated

17
Notes

GB 18
"No company is better positioned to offer an after sales service on a
Hotpoint appliance than us - the manufacturer"
As part of our commitment to you, all Hotpoint appliances have the added benefit of a fully inclusive parts
and labour guarantee for the first 12 months. In addition to this you also have the advantage of free
replacement parts for the first 5 years when fitted by a Hotpoint
engineer. When the 12 months parts and labour guarantee expires we offer the following after sales
serviceoptions:
Repair Service and Information Help Desk
UK:08709 066066
www.theservicecentre.co.uk
Republicof Ireland:1850 302 200
Note: Our operators will require the Model number and the Serial number of your appliance
Available 364 days a year with a fast, effective and value for money service. We have the largest white
goods repair service in the UK with over 1200 of our own fully trained engineers. All repairs include a parts
and labour guarantee for 12 months from the date of the repair.
If you require any information or have any questions about your appliance, our operators are on hand with
helpand advice.
All this ensures thatyou will receive the bestavailable after sales servicepossible.
Extended Warranties
UK:08709 088 088
www.theservicecentre.co.uk
Republicof Ireland:1850 502 200
Whether you have just one or a number of Hotpoint appliances in your kitchen, we offer two service cover
plans to give you total peace of mind.
● RepairProtection Plan - FREEservice repairsfor asingle Hotpointappliance duringthe period
of cover.
● Kitchen Cover - FREEservicerepairs forall yourHotpoint appliancesless than8
yearsold.
Genuine Parts and AccessoriesUK: 08709 077 077
www.theservicecentre.co.uk
Republicof Ireland:[phone]
A wide range of genuine parts and accessories are available from our hotline or through our web site.
Genuine parts and accessories, extended warranties and service repairs are all
available on our web-site at:
www.theservicecentre.co.uk
AfterSalesService

GB
19
Guarantee
"Satisfaction guaranteed or your money back"
We give you a unique 'satisfaction guaranteed' promise - valid for 90 days - after you have
purchasedyour Hotpoint appliance. If thereis a technical problem simplycall Hotpoint Repair serviceor
visit our web-site at www.theservicecentre.co.uk and where necessary, we will arrange for an
engineer to call. If the technical problem is not resolved under this guarantee, we will replace your
machine or, if you prefer, give you your money back.
All Hotpoint appliances carry a fully inclusive 12 month parts and labour guarantee as well as free
replacement parts for the first 5 years (except microwaves, selected integrated appliances and cooker
hoods, which have a one year guarantee) provided that they are fitted by a Hotpoint engineer.
Guarantee terms and conditions
Your guarantee is only applicable in the United Kingdom or Republic of Ireland and is subject to the
following provisions that your appliance:
● Has been installed and used correctly in accordance with this instruction booklet.
● Hasbeen used solelyfor domestic purposesand is located on domesticpremises (ie. notfor
commercialor trade use).
● Has been properly connected to a suitable electrical supply voltage as stated on the appliance
rating plate.
● Has not been subject to misuse, accident, modified or repaired by anyone other than one of our
ownservice engineers.
For pre purchase information on any other Hotpoint product call: 08701 50 60 70
or visit: www.hotpoint.co.uk
Recycling&DisposalInformation
As part of Hotpoint's continued commitment to helping the environment, Hotpoint reserves the right to
use quality recycled components to keep down customer costs and minimise material wastage.
Pleasedispose ofpackaging andold appliancescarefully.
To minimise risk of injury to children, remove the door, plug and cut mains cable off flush with the
appliance. Dispose of these parts separately to ensure that the appliance can no longer be plugged into
a mains socket, and the door cannot be locked shut.

195.036.397.00 December 2002 Part no. FP146 - 01
Over 1200 trained specialists, directly employed by us, ensure that you can have complete confidence in
both the appliances and services we offer.
Repair Service and Information Desk
UK:08709 066 066
(Open 8 to 8 Mon - Fri, 8 to 6 Sat, 10 to 4 Sun & Bank Holidays)
www.theservicecentre.co.uk
Republicof Ireland:1850 302 200
Note: Our operators will require the following information:
Model number:
Serialnumber:
Extended Warranties
UK:08709 088 088
(Open 8 to 8 Mon - Sun)
www.theservicecentre.co.uk
Republicof Ireland:1850 502 200
Genuine Parts and Accessories
UK: 08709 077 077
(Open 8-30 to 5-30 Mon - Fri & 9 to 12 Sat)
www.theservicecentre.co.uk
Republicof Ireland:[phone]
GeneralDomesticAppliances Limited,Morley Way,Peterborough, PE29JB.
KeyContacts
After Sales Service
