Hotpoint HTH17CBT Manual

Specification Created 4/09
410680
HTH17CBT – Hotpoint®ENERGY STAR®16.6 Cu. Ft. Top-Freezer Refrigerator
Front View Top View
A
G
E
C
F
'94 TMNF Refer
B
D
H
Note: Before installing, consult installation instructions packed with product
for current dimensional data.
Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your left and the
hinges are on your right.
All Top-Freezer No-Frost Left-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your right and the
hinges are on your left.
Height to top of hinge (in.) A 64-3/4
Height to top of case (in.) B 64-1/4
Height to mid-freezer (in.) 54-3/8
Case depth without door (in.) C 25-7/8
Case depth less door handle (in.) D 29-1/8
Case depth with door handle (in.) E 31
Depth with fresh food door open 90° (in.) F 54-7/8
Width (in.) G 28
Width with door open 90° with door handle (in.) H 30-1/2
Each side (in.) 3/4
Top (in.) 1
Back (in.) 1
Air Overall
Clearances Dimensions
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers’
standards.
Listed by
Underwriters
Laboratories
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.

Specification Created 4/09
410680
Features and Benefits
• Upfront temperature controls - Easy-to-use controls are located in an easy-to-reach position
• Adjustable wire shelves - Flexible shelving options can be arranged to handle a variety of foods
• Fixed gallon door shelves - Provides the ideal space for storing gallon containers in the door
• Crisper drawers - Provides the ideal environment for storing your fruits and vegetables
• Deluxe quiet design - Designed to reduce unnecessary sounds in the kitchen
• NeverClean™condenser - Encased coils take the dirty work out of maintaining your refrigerator
• Model HTH17CBTWW – White
• Model HTH17CBTBB – Black
HTH17CBT – Hotpoint®ENERGY STAR®16.6 Cu. Ft. Top-Freezer Refrigerator
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
• Model HTJ17CBTSA – Metallic Silver
