Hotpoint HTM17BBSSA Manual

Specification Created 1/05
410449
®
HTM17BBS – Hotpoint® 16.6 Cu. Ft. Top-Freezer Refrigerator
Front View Top View
A
G
E
C
F
'94 TMNF Refer
B
D
H
R
R
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers’
standards.
Listed by
Underwriters
Laboratories
Note: Before installing, consult installation instructions packed with product
for current dimensional data.
Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your left and the
hinges are on your right.
All Top-Freezer No-Frost Left-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your right and the
hinges are on your left.
Height to top of hinge (in.) A 64-3/4
Height to top of case (in.) B 64-1/4
Height to mid-freezer (in.) 54-3/8
Case depth without door (in.) C 25-7/8
Case depth less door handle (in.) D 29-1/8
Case depth with door handle (in.) E 31
Depth with fresh food door open 90° (in.) F 54-7/8
Width (in.) G 28
Width with door open 90° with door handle (in.) H 30-1/2
Each side (in.) 3/4
Top (in.) 1
Back (in.) 1
Air Overall Clearances Dimensions

Specification Created 1/05
410449
®
Features and Benefits
• Silver Metallic Exterior
• Upfront Temperature Controls - Are positioned up front, close at hand, for maximum convenience and
ease of use
• Adjustable Wire Shelves - Minimizes usable storage space
• Gallon Door Storage - Makes room for milk and any other gallon size containers
• Vegetable/Fruit Crispers - For easy storage of your fruits and vegetables
• NeverClean™ Condenser - Condenser coils are encased, so they don’t require cleaning in normal
operating environments
• Deluxe Quiet Design - Significantly reduces operating noise
• Square Doors - Classic design that’s compatible with any kitchen décor
• Model HTM17BBSSA – Silver Metallic
HTM17BBS – Hotpoint® 16.6 Cu. Ft. Top-Freezer Refrigerator
