HP T2touch PANEL User manual

HP T2 TOUCHPANEL
SERVICE MANUAL
SECHE‐LINGE
MANUEL DE SERVICE
Bandeau HP T2 Touch

HP T2 TOUCHPANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
CONTENTS
1. OVERVIEW AND WORKING PRINCIPLE.............................................................................................4
1.2. Working Principle:....................................................................................................................4
2. TECHNICAL SPECIFICATIONS............................................................................................................5
3. INSTALLATION.................................................................................................................................5
3.1. Issues that should be informed to customer.............................................................................5
4. CONTROL PANEL AND PROGRAM SELECTION TABLE........................................................................6
4.1. Control Panel ...........................................................................................................................6
4.2.Program List..............................................................................................................................6
4.3. Children’s Safety ......................................................................................................................7
5. FAILURE MODES AND SERVICE AUTOTEST .......................................................................................7
5.1. Failure Modes and Warning Leds..............................................................................................8
5.2. Service Autotest Steps..............................................................................................................9
6. DISASSEMBLY................................................................................................................................11
6.1. Top Plate................................................................................................................................11
6.2. Control Panel .........................................................................................................................12
6.3. Control Panel .........................................................................................................................13
6.4. Electronic Card.......................................................................................................................14
6.5. UI Card...................................................................................................................................15
6.6. Side Panel ..............................................................................................................................16
6.7. Supply Cable ..........................................................................................................................18
6.8. Emi Filter................................................................................................................................19
6.9. Rear Cover .............................................................................................................................20
6.10.Pump ....................................................................................................................................21
6.11.Process Fan ...........................................................................................................................23
6.12. Rear Panel............................................................................................................................24
6.13.Rear Isolation Group .............................................................................................................26
6.14. Rear Bearing Group..............................................................................................................27
6.15.Water Tank Housing..............................................................................................................28
6.16. Drum....................................................................................................................................29
6.17. Motor...................................................................................................................................30
6.18.Capacitors.............................................................................................................................32
6.19.Belt .......................................................................................................................................33

HP T2 TOUCHPANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.20. Humidity Sensor...................................................................................................................34
6.21. Door latch ............................................................................................................................35
6.22. Plinth ...................................................................................................................................36
6.23. Cooling Fan ..........................................................................................................................37
6.24. Plinth Cover..........................................................................................................................38
6.25. Door.....................................................................................................................................39
6.26. Drum Bearing Wheel ............................................................................................................40
6.27. Drumlight.............................................................................................................................41
6.28. Front Panel...........................................................................................................................42
6.29. Door NTC..............................................................................................................................43
6.30. Side Bracket .........................................................................................................................44
6.31. Front Shield..........................................................................................................................45
6.32.Front Isolation Foam .............................................................................................................46
6.33. Cable Group .........................................................................................................................47
7. 7. COMPONENT SPECIFICATIONS AND MEASUREMENTS ...............................................................49
7.1. Motor ....................................................................................................................................49
7.1.1. Motor Measurements .........................................................................................................50
7.2. Pump .....................................................................................................................................51
7.2.1 Pump Measurements ...........................................................................................................52
7.3. Electronic Card.......................................................................................................................53
7.4. Door/Compressor NTC Sensor................................................................................................53
7.4.1. Door NTC Sensor Measurements.........................................................................................54
7.5. Compressor............................................................................................................................54
7.5.1. Compressor Measurements ................................................................................................56
7.6. Door Latch .............................................................................................................................57
7.6.1 Door Latch Measurements ...................................................................................................57
7.7. Humidity Sensor.....................................................................................................................58
7.7.1 Humidity Sensor Measurements...........................................................................................58
7.8. Cooling Fan ............................................................................................................................59
7.8.1. Cooling Fan Measurements .................................................................................................60
7.9. Drumlight...............................................................................................................................60
8. TROUBLESHOOTING......................................................................................................................61
.........................................................................................................................................................66

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
1. OVERVIEW AND WORKING PRINCIPLE
1. Top Plate
2. Control Panel
3. Loading Door
4. Plinth
5. Plinth opening slot
6. Ventilation grills
7. Adjustable feet
8. Plinth cover
9. Type plate
10. Lint filter
11. Drawer Cover
1.2. Working Principle:
In the heat pump dryer machine, heated air is sent to the wet laundry in the drum from the
heater side of the coil which called by condenser. The humidity of the laundry is taken and
reaches the cold side of the coil which called by evaporator via filter. With a compressor,
refrigerant is passed through inside of the tubes of coils both condenser and evaporator. A
capillary causes resistance against to refrigerant flow. By this way, the evaporator surface is
cooled and condenser surface is heated. The hot and humid air from the drum is reached cold
evaporator surface and the humidity on it is left as water. The condensing water in the
evaporator is pumped to the water tank by the pump.

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
2. TECHNICAL SPECIFICATIONS
Manufacturer
Vestel White Goods
Capacity (max)
7 kg
8 kg / 9kg
Height
Min: 845mm Max: 855 mm
Min: 845mm Max: 855 mm
Depth
563 mm
609 mm
Width
596 mm
596 mm
Net weight (with plastic door)
44,8 kg
46,8 kg
Net weight (with glass door)
46,8 kg
48,8 kg
Voltage
220-240 V
Working Temp.
+5°C -+35°C
Power
1000 W
3. INSTALLATION
3.1. Issues that should be informed to customer
1. Drying machine must be grounded.
2. Lint filter must be cleaned after each use
3. Water tank must be unloaded after each use
4. Even if the heat exchanger cleaning warning les is not on : clean the heat exchanger
after every 30 drying processes or once a month
5. The amount of laundry should be appropriate to program.
6. Use this product only for laundry with a label that indicates it is suitable for drying.
7. Children should not play with appliance.
8. This product contains environmental friendly but flammable R290 gas. Keep open
flame and fire sources away from the product.
9. Ventilation grills should not be closed.
10. The service life time of tumble dryer is 10 years.
11. Adjustable feet should not be removed.
12. There should not be lockable or sliding door in the installation area
13. Never spray or pour water onto the dryer to wash it. There is a risk of electric shock.
Please ensure that customer reads the user manual
1. Check the environmental conditions. (Voltage, current etc.)
2. Ensure that product is used correctly
3. Check the machine with Service Auto Test.If the system displays failure code, find the
corresponding code in the failure code list then act according to this.
4. Check the electronic connections

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
4. CONTROL PANEL AND PROGRAM SELECTION TABLE
4.1. Control Panel
Display Symbols
4.2.Program List
KNOB POSITION
PROGRAM
1
Cotton Extra Dry
2
Cotton Cupboard Dry
3
Cotton Iron Dry
4
Synthetics Cupboard Dry
5
Synthetics Iron Dry
6
Delicate
7
Time Drying*
8
Baby Care
9
Duvet
10
Sport
11
Mix
12
Wool Refresh
13
Refresh
14
Express 34 ’
15
Shirts 20 ‘
16
OFF
***The machine has humidity sensor that detects whether the laundry dry or not. At the programs
that work with humidity sensor laundry does not dry in fixed time. Duration is constantly updates
according to humidity data taking from laundry.

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
***Time Drying Program: Humidity sensor is deactivated. The program ends when the time is up,
without checking the humidity of the laundry.
***Express 34’/ Shirts 20 ‘: Humidity sensor is activated. The program time may extend, if the
customer use different laundry according to the load in the program description.
Express 34' : 2 kg of cotton shirts spun at a high speed in the washing machine are dried in 45
minutes.
Shirts 20' : 2 to 3 shirts are ready for to be ironed in 30 minutes.
***Delicate: Delicate fabrics are dried for a longer time at a low temperature.
***Wool Refresh / Refresh: Compressor is deactivated. The air is not heated.
4.3. Children’s Safety
There is a child lock option to avoid changes in the programme flow when keys are pressed during
the programme. To activate the child lock, press and hold the "Delicate" and "Anti-Crease" keys
simultaneously for 3 seconds.
When the child lock is active, all keys will be deactivated. Child lock will be deactivated automatically
at the end of the programme. When activating/deactivating the child lock, ‘‘CL’’ will visualize on
display for 2 sec and then becomes off; and an audible warning will be heard.
Warning; when the product is running or the child lock is active, if you turn the programme selection
knob, you will hear an audible warning and ‘‘CL’’ will visualize on display for 2 sec and then becomes
off. Even if you set the programme knob to another programme, the previous programme will
continue running. To select a new programme, you need to deactivate the child lock and then set the
programme selection knob to ‘‘Off’’ position.
Then, you can select and start the desired programme.
5. FAILURE MODES AND SERVICE AUTOTEST
***Service auto test must be run for every service call.

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
5.1. Failure Modes and Warning Leds
Notes For Service autotest:
*Service can not pass the current step before completing the minimum duration
*When minimum duration for each step (5 sec) is completed, filter led makes slow blink to indicate
that service can pass the next step
*For error codes, leds must make fast blink
ERROR CODE REASON
E00 T3 UI board doesn't receive communication from mainboard
E03
Aquaswitch connector is disconnected
E04 Compressor connector is disconnected
E05 Compressor NTC connector is disconnected
E06 Door NTC connector is disconnected
E07
Motor connector is disconnected, motor is locked
E08
Voltage fluctuation
T3 HEAT PUMP MODEL ERROR CODES

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
5.2. Service Autotest Steps
STEPS
Control
Mini
mum
Step
Dura
tion*
Error
code
Led Indication
Possible Errors
The
Routine
to
Enter
Servis
Autotest
Set program knob at position 3.
Push SW5 button.
Keeping SW5 button pushed,
turn program knob to position 1.
After 3 sec, SAU is shown in
display.
Then press Start/Pause button.
Machine enters to service
autotest.
When knob positioned to
program 2, control steps starts.
5 sec
-
Step 2
(Knob
Position
2)
Dryer check Aquaswitch, if
aquaswitch ON go to next step
(pump activation), if aquaswitch
OFF give water tank full error
10sec
E03
-
*Aquaswitch connector
is taken out
*Aquaswitch connector
is short circuit
*Styrofoam is borken or
not
Step 3
(Knob
Position
3)
Pump is on
5 sec
-
-
Service must pour water
to pump reservoir and
check whether water is
pumped to tank.
If water is not pumped
to water tank;
*Pump connector is
taken out
Step 4
(Knob
Position
4)
Motor CCW (Tumble CW)-Motor
stops
10
sec
-
-
Service must check
whether tumble is
moving to CW. If not;
*Motor connector is
taken out
*Motor might be locked
*Motor belt might be
dislocated

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
Step 5
(Knob
Position
5)
Motor CW (Tumble CCW) -Motor
stops
10
sec
-
-
Service must check
whether tumble is
moving to CCW
*If tumble is moving to
CW again, then motor
relay short circuit CCW
Step 6
(Knob
Position
6)
Check Heater NTC if heater NTC
T=255
5 sec
E05
-
*Heater NTC connector
is taken out or short
circuit
Step 7
(Knob
Position
7)
Check Door NTC if heater NTC
T=255
5 sec
E06
-
*Door NTC connector is
taken out or short circuit
Step 8
(Knob
Position
8)
Compressor OFF- Motor CCW
(Tumble CW) OFF- Cooling fan
ON
10
sec
-
-
Service must check
power of at the home
voltage and fan will be
controlled manually by
technical service.
Step 9
(Knob
Position
9)
Compressor ON- Motor CCW
(Tumble CW) -motor off
10
sec
-
-
Service must check
power of at the home
voltage.
Step 9
(Knob
Position
9)
Check conductivity sensor when
door is opened and motor is off
5 sec
E01
-
Service puts his hand on
the humidity sensor
plates and software
checks sensor data
*If sensor data=0,
humidity sensor
connector is taken out
Remove
the last
error
(Knob
Position
1)
5 sec
DEL
DL is visualized
on display and
make fast blink
for 2 sec for
T0.DEL is
visualized on
display and
make fast blink
for 2 sec
When the knop
positioned to program 1,
service will pust the
both SW4 and SW5 for
T0/T1 (child lock mode).
When the knop
positioned to program 1,
service will pust the
both SW2 and SW3 for
T2 (child lock mode).

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6. DISASSEMBLY
6.1. Top Plate
1. Remove two screws that fix the top plate at the back.
2. Remove by pulling the top plate to yourself.

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.2. Control Panel
1. Remove 2 screws from the top
2. After the water tank removed, the plastic screw in the center of the control panel should
be removed.

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.3. Control Panel
1. After removing the screws on the control panel, the control panel is removed as shown in the
photo from the upper support bracket.
2. The cables on the control panel are carefully removed from the cable paths.
3. All sockets which is connected with electronic card must be removed carefully as shown in the
photo.
v
v

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.4. Electronic Card
1. To remove the electronic card box (PCB box) from the control panel, it is necessary to remove 6 tabs.
As shown in the photo, you can take off the tabs with thin screwdriver.
2. The PCB box is separated from the control panel.

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.5. UI Card
1. UI card on control panel is disassembled as shown in photo

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.6. Side Panel
1. Remove 10 screws on side panels

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.6. Side Panel
2. Remove 2 screws from front
3. It should not be forgotten to take bottom screw ( 2 screws)
4. Remove the side plate which is pulled out screws , by pushing up

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.7. Supply Cable
1. Remove the supply cable brown and blue cable socket.
2. Remove the terminals with tool as shown in the photo
3. Remove supply cord by pushing up
3
2
1

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.8. Emi Filter
1. Remove EMI filter sockets
2. Remove the terminals with tool as shown in the photo
3. Remove the EMI filter which is fixed with 2 screws to the rear panel

HP T2touch PANEL
CUSTOMER
SUPPORT
SERVICE MANUAL
6.9. Rear Cover
1. Remove all screws shown in the photo.
