Inglis IH7000 Owner's manual

Congratulations!............................2
Dryer Safety....................................3
Parts and Features........................5
Checking Your Vent........................7
Using Your Dryer
Starting your dryer ....................9
Selecting a cycle and
temperature setting..................10
Loading....................................11
Cycle descriptions..................11
Timed Air cycle........................13
Caring for Your Dryer
Troubleshooting............................17
Assistance or Service ..................19
Warranty ......................................22
8275501
Electric and
Gas Dryers
www.inglis.ca

CONGRATULATIONS!
Congratulations on the purchase of your new appliance. I am confident that our product will provide you with
the same quality, performance, and reliability on which our reputation has been built.
Please take the time to read this guide. It contains many valuable ideas and information that will help you enjoy
this product for many years to come.
Thank you for choosing one of our quality products. You have made an excellent choice.
Sincerely,
Karim Lalani
General Manager
Inglis Limited
If you need assistance or service, first see the “Troubleshooting” section of this book. After checking “Trouble-
shooting” additional help can be found by checking the “Assistance or Service” section.
When calling, you will need to know your appliance’s complete model number and serial number. You can find
this information on the model and serial number label (see diagram in the “Parts and Features” section).
Keep this book and the sales slip together in a safe place for future reference. You must provide proof of
purchase or installation date for in-warranty service.
Model Number __________________________________
Serial Number __________________________________
Date Installed____________________________________
2
Builder/Dealer Name ____________________________
Address ________________________________________
Phone __________________________________________

3
DRYER SAFETY
WARNING: For your safety the information in this manual must be followed to
minimize the risk of fire or explosion or to prevent property damage, personal
injury or death.
– Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your building.
•Clear the room, building or area of all occupants.
•Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
•If you cannot reach your gas supplier, call the fire department.
– Installation and service must be performed by a qualified installer, service agency
or the gas supplier.
continued on next page
You will be killed or seriously injured if you don’t
follow instructions.
You can be killed or seriously injured if you don’t
follow instructions.
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and the word “DANGER” or
“WARNING.” These words mean:
wDANGER
wWARNING
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.

4
WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the
dryer, follow basic precautions, including the following:
•Read all instructions before using
the dryer.
•Do not place items exposed to cooking
oils in your dryer. Items contaminated
with cooking oils may contribute to a
chemical reaction that could cause a
load to catch fire.
•Do not dry articles that have been
previously cleaned in, washed in, soaked
in, or spotted with gasoline, dry-cleaning
solvents, other flammable, or explosive
substances as they give off vapors that
could ignite or explode.
•Do not allow children to play on or in
the dryer. Close supervision of children
is necessary when the dryer is used
near children.
•Before the dryer is removed from service
or discarded, remove the door to the
drying compartment.
•Do not reach into the dryer if the drum
is moving.
•Do not install or store the dryer where
it will be exposed to the weather.
•Do not tamper with controls.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
•Do not repair or replace any part of the
dryer or attempt any servicing unless
specifically recommended in this Use and
Care Guide or in published user-repair
instructions that you understand and
have the skills to carry out.
•Do not use fabric softeners or products
to eliminate static unless recommended
by the manufacturer of the fabric softener
or product.
•Do not use heat to dry articles containing
foam rubber or similarly textured rubber-
like materials.
•Clean lint screen before or after each
load.
•Keep area around the exhaust opening
and adjacent surrounding areas free from
the accumulation of lint, dust, and dirt.
•The interior of the dryer and exhaust vent
should be cleaned periodically by
qualified service personnel.
•See Installation Instructions for grounding
requirements.
DRYER SAFETY

5
*
PARTS AND FEATURES
The drawings in this book may vary from your dryer model. They are designed to show the differ-
ent features of all models covered by this book. Your model may not include all features.
Large side-swing door†
(Reversible door – see Installation
Instructions)
Other doors:
Cycle control
knob
(pp. 9-13)
Model and
serial number
label
(p. 2)
Dryer drum
(p. 15)
Start button
(p. 10)
Temperature
selector†
(p. 9)
Extra tumble
feature selector†
(p. 9)
Lint screen
(p. 14)
Exhaust grill
(p. 17)
Electronic
dryness sensor†
(p. 11)
Wide-opening
hamper door†
Super wide-opening door†
(Reversible door – see Installation
Instructions)
Additional features your dryer may have:
End of cycle signal selector (p. 10)
Drum light (p. 16)
continued on next page
†On some models

6
*
*
*
DRYER MODELS
The control panels from the dryer models covered by this book are shown below.
Models IH7000, IH8000
PARTS AND FEATURES
Model IH8200
Models IH7400, IH8400
Model IH8600
Model IH8800

2. Use a 10.16 cm (4 in) exhaust hood. Smaller
hoods increase drying
times.
7
If the dryer is not properly installed and vented, it will
not be covered under the warranty.
NOTE: Service calls caused by improper venting will
be paid for by the customer, whether it was a paid
installation or self-installed. For paid installation, call
the company that installed the vent for
adjustment.
1. Do not use plastic vent or flexible metal foil vent.
Use 10.16 cm (4 in)
heavy metal or flexible
metal vent. Do not kink
or crush flexible metal
vent. It must be com-
pletely extended to
allow adequate exhaust
air to flow. Check vent
after installation. Refer
to your Installation
Instructions for proper
length requirements of vent.
CHECKING YOUR VENT
Your dryer must be properly installed and vented to achieve maximum drying efficiency and short-
en drying times. Use the minimum recommended installation clearances (found in your Installation
Instructions) to avoid blocking the flow of combustion and ventilation air. Install your dryer in a
well-ventilated room where the temperature is always above 7°C (45°F). Also make sure that your
dryer is leveled. Refer to your Installation Instructions for more information.
VENTING
wWARNING
Fire Hazard
Use a heavy metal vent.
Do not use a plastic vent.
Do not use a metal foil vent.
Failure to follow these instructions can
result in death or fire.
3. The exhaust vent can be routed up, down, left,
right, or straight out the
back of the dryer. Space
requirements are listed
in your Installation
Instructions.
10.16 cm
(4 in)
10.16 cm
(4 in)
10.16 cm
(4 in)
continued on next page

8
VENTING (CONT.)
6. Clean exhaust vent periodically, depending on use,
but at least every 2 years,
or when installing your
dryer in a new location.
•Disconnect vent from
the dryer and clean one
section at a time until
you reach the exhaust
hood.
•Use the hose attach-
ment on your vacuum,
or a pole or wire with a
feather duster or rag attached, to clean out lint.
•Be sure the flapper on the outside end of vent
moves freely.
•When cleaning is complete, be sure to follow the
Installation Instructions supplied with your dryer
for final product check.
4. Use the straightest path possible when routing
the exhaust vent. Use
the fewest number
of elbows and turns.
Allow room when using
elbows or making turns.
Bend vent gradually to
avoid kinking.
5. Use duct tape to seal all joints. Do not use
screws to secure vent.
Lint may catch on
screws.
CHECKING YOUR VENT

9
USING YOUR DRYER
STARTING YOUR DRYER
wWARNING
Explosion Hazard
Keep flammable materials and vapors,
such as gasoline, away from dryer.
Do not dry anything that has ever had
anything flammable on it (even after
washing).
Failure to follow these instructions can
result in death, explosion, or fire.
Before using your dryer, wipe the dryer drum with a
damp cloth to remove dust from storing and shipping.
1. Load clothes loosely into the dryer and close the
door. Do not pack the
dryer; allow space for
clothes to tumble freely.
2. Turn the Cycle Control knob to the recommended
cycle for the type of load
being dried, as described
in the “Cycle descrip-
tions” section.
•Use the Energy
Preferred Automatic
Setting (*) to dry
most loads.
NOTE: On some
models, the Temperature
selector is part of the
Cycle Control knob.
3. If your dryer has a Temperature selector, set it to
the recommended setting for the type of fabric
being dried. The cycle descriptions on the
following pages include temperature setting
suggestions.
4. (OPTIONAL STEP) Your dryer may have an On/Off
Extra Tumble selector. The Extra Tumble feature
protects your clothes from wrinkling when you do
not remove them from the dryer as soon as it
stops.
•Set the Extra Tumble selector to On to tumble
the load without heat every few minutes up to
45 minutes (on some models) after the drying
cycle ends. On some models, you can select
30 min. or 90 min. of extra tumble time.
•A signal will sound every few minutes while
Extra Tumble is running if the End of Cycle
Signal feature is set to On.
•Set the Extra Tumble selector to Off if you do
not want to run this feature.
wWARNING
Fire Hazard
No washer can completely remove oil.
Do not dry anything that has ever had any
type of oil on it (including cooking oils).
Items containing foam, rubber, or plastic
must be dried on a clothesline or by using
an Air Cycle.
Failure to follow these instructions can
result in death or fire.
continued on next page

10
STARTING YOUR DRYER (CONT.)
Stopping and restarting your dryer
You can stop your dryer anytime during a cycle.
To stop your dryer:
Open the dryer door or turn the Cycle Control knob
to Off.
NOTE: The Cycle Control knob should point to an
Off area when the dryer is not in use.
To restart your dryer:
Close the door, select a new cycle and tempera-
ture (if desired), and push the Start button.
SELECTING A CYCLE AND TEMPERATURE SETTING
The following pages describe the drying cycles
on your dryer. The descriptions include suggested
temperature settings and drying times for various
loads.
Cycle and temperature tips
•Make sure you have selected the correct cycle
and temperature for your load.
•Dry most loads using the Energy Preferred
Automatic Setting (*).
•Use the Timed Air cycle, or line dry rubber,
plastic, delicate, and heat-sensitive fabrics.
•If some types of loads in the cycle descriptions
on the following pages have more than one
suggested temperature setting, choose the
lowest setting available on your dryer.
•The last few minutes of all cycles are without
heat to make the load cooler to handle.
Drying tips
•Always follow care label directions when they are
available.
•If you use fabric softener sheets, always use
softener sheets that are labeled as dryer safe and
follow package instructions carefully.
•Remove the load from the dryer as soon as
tumbling stops to reduce wrinkling. This is
especially important for permanent press, knits,
and synthetic fabrics.
5. (OPTIONAL STEP) If your dryer has an End of
Cycle Signal selector, set the selector to On if
you want the dryer to sound a signal when a
cycle is finished.
•The signal is helpful when you are drying
permanent press, synthetics, and other items
that should be removed from the dryer as
soon as it stops.
•On some models, the End of Cycle Signal is
part of the Start button.
•On some models, the signal volume can be
adjusted from Softer to Louder.
6. Push the Start button.
NOTE: Your dryer stops automatically when
a cycle ends.
USING YOUR DRYER

11
USING YOUR DRYER
Loading suggestions
The chart below provides some guidelines on various types of drying loads. Load clothes loosely into the
dryer. Do not pack the dryer; allow space for clothes to tumble freely.
LOADING
Heavy Work Clothes
3 pair pants
3 shirts
4 pair jeans
1 coverall
1 overall
Towels
10 bath towels
10 hand towels
14 wash cloths
1 bath mat
Mixed Load
3 double sheets
4 pillowcases
8 T-shirts
6 pair shorts
2 shirts
2 blouses
8 handkerchiefs
Delicates
3 camisoles
1 quilted robe
4 slips
4 panties
2 bras
2 nighties
1 baby’s dress
CYCLE DESCRIPTIONS
Auto
Use an Auto cycle to dry most loads. Select the cycle
that matches care label
directions. Depending
on your model, the Auto
cycle uses either an
electronic or automatic
control that senses the
moisture in the load and
shuts off the dryer when
the selected dryness is
reached. The Cycle
Control knob does not
move until the load is almost dry. After the cool-
down, the knob automatically turns to an Off area and
tumbling stops.
•If the load is drier than you like, select a setting
closer to MIN the next time you dry a similar load.
•If the load is not as dry as you like, complete
drying using a Timed Dry cycle. Select a setting
closer to MAX the next time you dry a similar load.
Drying time with an Auto cycle varies according to
the type of fabric, size of load, and dryness setting.
Your model may not have all heat settings listed.
Some general guidelines are:
•Use a high heat setting for drying heavyweight
items, such as towels and work clothes.
•Use a medium heat setting for drying medium-
weight items, such as sheets, underwear,
permanent press clothes, and some knits.
•Use a low heat setting for drying lightweight items
such as lingerie, blouses, dresses and some knits.
NOTE: If you have any questions about drying temp-
eratures for various loads, refer to care label directions.
Timed Dry
Use a Timed Dry cycle to complete drying if some
items are damp after the
Auto cycle. A Timed Dry
cycle is also useful for:
•Heavyweight and
bulky items, such as
bed spreads and work
clothes, and large loads
that require a long drying
time. Set your dryer to a
heat setting that matches
the care label directions.
•Lightweight items, such as lingerie, blouses, and
knits that require a short drying time. Set your dryer
for Low heat.
Drying time and temperature will depend on your
dryer model.
Timed Air
(on some models)
Use the unheated Timed Air cycle for items that
require drying without
heat. The chart in the
“Timed air cycle” section
includes examples of
items that require air
drying.
continued on next page

Tumble Press
(on some models)
The Tumble Press feature in the Timed Dry cycle
removes wrinkles from
clothes that have been
packed in a suitcase or
closet, or from items not
removed from the dryer
at the end of a cycle. As
soon as the dryer stops,
fold or put the items on
hangers. Set the Temper-
ature selector to Medium
or Low heat.
Extra Tumble
(on some models)
When you are unable to remove a load from the
dryer as soon as it stops,
wrinkles can form. The
Extra Tumble feature
periodically tumbles,
rearranges, and fluffs the
load to avoid wrinkles.
•You can turn the Extra
Tumble feature On or
Off with a selector. (See
Step 4 in the “Starting
Your Dryer” section). On
some models, you can select 30 min. or 90 min. of
extra tumble time.
•A signal will sound every few minutes while Extra
Tumble is running if the End of Cycle Signal feature
is set to On.
Air Only
(on some models)
Use the unheated Air Only feature for items that
require drying without
heat. Refer to the chart in
the "Timed Air cycle"
section for examples of
items that require air dry-
ing. Set the Temperature
selector to Air Only and
the Cycle Control knob to
the desired Timed Dry
setting.
12
USING YOUR DRYER
CYCLE DESCRIPTIONS (CONT.)
Heavy Dry
(on some models)
Use the Heavy Dry feature in the Timed Dry cycle
to dry large items or
items that are thicker
or heavier than a
regular load (such as
heavy cotton bath
towels or robes.) Set
your Cycle Control
knob to Heavy Dry
and your Temperature
selector to High heat.
Damp Dry
(on some models)
Use the Damp Dry feature in the Timed Dry cycle
to dry items to damp
level or to dry items
that do not require an
entire drying cycle. Two
examples are heavy
cottons, such as jeans,
which you do not want
to become stiff, or cot-
ton clothes which are
easier to press when
damp. Set the
Temperature selector to High heat.
Towels
(on some models)
When you have large loads of towels to dry, you
may want to use the
Towels feature in the
Auto cycle. The Towels
setting allows for more
drying time and auto-
matically shuts off the
dryer when the select-
ed dryness is reached.
The Towels feature
also can be used for
extra heavy items such
as mattress pads and quilts. Set your dryer to a
heat setting that matches the care label directions.

13
TIMED AIR CYCLE
The chart below includes examples of items that
require drying without heat. Use the Timed Air
cycle, or place the items on a line or rack to air dry.
RUBBER, PLASTIC, HEAT-SENSITIVE FABRICS
Foam Rubber – Pillows, padded bras, stuffed toys
•Make sure coverings are securely stitched.
•Shake and fluff pillows by hand several times during the
Timed Air cycle.
•Make sure pillows are completely dry. Foam rubber pillows
take a long time to dry.
Plastic – Shower curtains, tablecloths
Rubber – backed rugs
Olefin, Polypropylene, Sheer nylon
20 to 30
20 to 30
40 to 50
10 to 20
TIMED AIR CYCLE†
(minutes)
TYPE OF LOAD
†Reset cycle as needed to complete drying.
USING YOUR DRYER
•Line dry bonded or laminated fabrics.
•Always follow care label directions when they are
available.

14
CLEANING THE LINT SCREEN
CARING FOR YOUR DRYER
Every load cleaning
The lint screen is located under a lid on top of the
dryer. Clean it before starting each load. A screen
blocked by lint can increase drying time.
To clean:
1. Open the lid and pull the lint screen towards you.
As needed cleaning
Laundry detergents and fabric softeners can cause
a residue buildup on the lint screen. This buildup
can cause longer drying times for your clothes, or
cause the dryer to stop before your load is com-
pletely dry. You may be able to see this buildup,
or the lint may be falling off the screen because it
is clogged.
Clean the lint screen with a nylon brush every six
months or more frequently if it becomes clogged
due to a residue buildup.
Use the following method:
1. Wet both sides of lint screen with hot water.
2. Wet a nylon brush with hot water and liquid
detergent; scrub lint
screen with the brush
to remove residue
buildup.
2. Roll lint off the screen with your fingers. Do not
rinse or wash screen to
remove lint. Wet lint is
hard to remove.
3. Push the lint screen firmly back into place and
close the lid.
IMPORTANT:
•Do not run the dryer with the lint screen loose,
damaged, blocked, or missing. Doing so can
cause overheating and damage to both the dryer
and fabrics.
•Some towels made of synthetic fibers and
natural fibers (polyester and cotton blends) may
shed more lint than other towels, causing your
dryer’s lint screen to fill up faster. Be sure to
remove lint from the lint screen before and after
drying new towels.
•If lint falls off the screen during removal and into
the dryer, check the exhaust hood and remove
the accumulated lint (see “Checking Your Vent”).
3. Rinse screen with hot water.
4. Thoroughly dry lint screen with a clean towel;
replace in dryer.

15
CARING FOR YOUR DRYER
CLEANING THE DRYER INTERIOR
Garments which contain unstable dyes, such as
denim blue jeans or brightly colored cotton items,
may discolor the dryer interior. These stains are not
harmful to your dryer and will not stain future loads of
clothes. It may be helpful to dry unstable dye items
inside out to prevent dye transfer.
To clean dryer drum:
1. Make a paste with powdered laundry detergent
and very warm water.
2. Apply paste to a soft cloth.
OR
Apply a liquid, non-flammable household cleaner
to the stained area and rub with a
soft cloth until all excess dye is
removed.
3. Wipe drum thoroughly with a damp cloth.
4. Tumble a load of clean cloths or towels to
dry drum.
wWARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death,
explosion, or fire.
REMOVING ACCUMULATED LINT FROM INSIDE THE DRYER CABINET
Lint can gather inside the dryer and be a fuel
for fire. Lint should be removed every 2 years, or
more often, depending on dryer usage. Cleaning
should be done by a qualified person.

16
CHANGING THE DRUM LIGHT (ON SOME MODELS)
The dryer light automatically turns on inside the
dryer drum when you open the door.
3. Remove the light bulb by turning it
counterclockwise. 6. Plug in dryer or reconnect power supply.
To change drum light:
1. Unplug dryer or disconnect power.
2. Open the dryer door. Remove the light bulb
cover from the back wall
of the dryer by removing
the screw located in the
lower right corner of the
cover.
CARING FOR YOUR DRYER
4. Replace the bulb with a 10-watt appliance
bulb only.
5. Replace the light bulb cover.

17
TROUBLESHOOTING
COMMON DRYING PROBLEMS
PROBLEM
Not drying
satisfactorily
Dryer will
not run
CAUSE
• Lint screen is clogged with lint.
• Restricted air movement.
Exhaust vent or outside
exhaust hood is clogged with
lint.
• Exhaust vent is crushed or
kinked.
• One fuse is blown or circuit
breaker is tripped. The dryer
will appear to operate, but you
will not get any heat.
• Cycle Control knob or temper-
ature selector is set on air dry.
• Load not contacting the sensor
strips and automatic cycle
ending early.
• Fabric softener sheets blocking
exhaust grill.
• Dryer located in room with
temperature below 7ºC (45ºF).
• Large amount of moisture in
the load.
• Cold rinse water used.
• Load too large and bulky to
dry quickly.
• Power cord not firmly plugged
into a live circuit with proper
voltage.
• Fuses blown or circuit
breakers tripped.
• Using a regular fuse.
• Dryer door not firmly closed.
• Start button not firmly pressed.
• Cycle Control knob set to Off.
SOLUTION
• Clean lint screen.
• Run dryer for 5-10 minutes. Hold hand under out-
side exhaust hood to check air movement. If you
do not feel air moving, clean exhaust system of lint
or replace exhaust vent with heavy metal or flexi-
ble metal vent (see your Installation Instructions).
• Replace with heavy metal or flexible metal vent
(see your Installation Instructions).
• Replace fuse or reset breaker.
• Select the right cycle and temperature for the types
of garments being dried (see “Using your Dryer”).
• Level dryer (see your Installation Instructions).
• Use only one softener sheet per load and only use
it once.
• Move dryer to a location with temperatures above
7ºC (45ºF).
• Expect longer dry times with with items that hold
more moisture (cottons).
• Expect longer dry times.
• Separate load to tumble freely.
• Plug power cord into a live circuit.
• Replace fuses or reset breakers.
• Replace with a time-delay fuse.
• Close dryer door tightly.
• Press Start button again.
• Set knob to a cycle or time.

18
COMMON DRYING PROBLEMS
TROUBLESHOOTING
PROBLEM
Lint in load
Stains on
load
Items
shrinking
Loads are
wrinkled
Odors
Unusual
sounds
CAUSE
• Lint screen is clogged.
• Improper sorting.
• Load is too big or heavy.
• Load is overdried.
• Paper or tissue in pockets.
• Pilling being mistaken for lint.
• Improper use of fabric softener
in washer.
• Drying soiled items.
• Overdrying.
• Poor garment quality.
• Manufacturer’s care label
instructions not followed.
• Overloading.
• Overdrying.
• Load left in dryer at the end of
cycle.
• Household chemicals, paint, or
varnish being drawn into dryer.
• First use of dryer element.
• Thumping of rollers when dryer
has not been used for a while.
SOLUTION
• Clean lint screen. Check for air movement.
• Sort lint givers from lint takers and sort by color.
• Dry smaller loads so lint can be carried to the lint
screen.
• Use correct dryer settings for fabric. Overdrying
can cause lint-attracting static (see “Using Your
Dryer”).
• Clean out pockets before drying.
• Pilling (surface fuzz) is caused by normal wear and
laundering.
• Use fabric softener sheets in dryer. Add at
beginning of cycle when load is cold.
• Items need to be clean before being dried.
• Match dryer settings to fabric type (see “Using
Your Dryer”).
• Check quality of garment before purchasing.
• Follow fabric care label instructions carefully.
• Dry smaller loads that can tumble freely.
• Match dryer settings to fabric type (see “Using
Your Dryer”).
• Remove load as soon as tumbling stops.
• Do not use dryer while these chemical fumes are in
the air.
• Odor will be gone after the first cycle.
• Thump will go away after 5 minutes of drying.

19
ASSISTANCEORSERVICE
IFYOU NEED ASSISTANCE OR SERVICE
2. If you need service†...
Contact Inglis Limited from anywhere in Canada at
1-800-807-6777.
1. If the problem is not due to one of the
items listed in “Troubleshooting”†...
Contact the dealer from whom you purchased your
appliance, or call the Inglis Limited
Consumer Assistance Center
toll free, 8:30 a.m. – 6 p.m. (EST),
at 1-800-461-5681.
FOR FURTHER ASSISTANCE
If you need further assistance, you can write to
Inglis Limited with any questions or concerns at:
Consumer Relations Department
Inglis Limited
1901 Minnesota Court
Mississauga, Ontario L5N 3A7
Please include a daytime phone number in your
correspondence.
†When asking for assistance or service, please
provide a detailed description of the problem,
your appliance’s complete model and serial
numbers, and the purchase date. (See the
“Congratulations” section.) This information
will help us respond properly to your request.

20
NOTES
