Powr-Flite PDH2 Installation and operation manual

OPERATOR’S MANUAL & PARTS LIST
WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL
COMPLETELY BEFORE OPERATING THIS EQUIPMENT.
©Tacony, Inc., All rights reserved
Save These Instructions
HYBRID DRYER
PDH2
PDH2-MAN 02/2021

2
IntroductIon
reference InformatIon
Check the carton for shipping damage. Carefully unpack
and inspect your new Powr-Flite dryer for shipping
damage. Each unit is tested and thoroughly inspected
prior to shipping. If damage is discovered, immediately
notify the transportation company that delivered your
machine and request an inspection. As a manufacturer, we
are unable to act upon any claim for concealed damage;
you must originate the claim. Be sure to keep the carton,
packing inserts, packing lists, and carrier’s receipt until the
inspector has verified your claim.
MANUAL
This manual has important information for the use and safe operation of the dryer. Read this
manual carefully before starting the machine. Keep the manual available at all times and
instruct all operators to read this manual.
Reference Information
Model Number _____________________________
Serial Number _____________________________
Date Purchased _____________________________
Retain this manual as a permanent record of your pur-
chase.
Introduction ...................................................2
Safety Instructions ........................................3
Grounding Instructions .................................4
Operating Instructions ..................................5
Maintenance ..................................................6
Troubleshooting.............................................6
Storage ...........................................................6
Machine Specifications.................................7
Schematic and Parts List..............................8
PROTECT THE ENVIRONMENT
Please dispose of packaging materials in an
environmentally safe way according to local
waste disposal regulations.
Always remember to recycle

3
Safety WarnIngS and PrecautIonS
Read all instructions before using. Save These Instructions.
Following the cleaning instructions will prolong the life of your Powr-Flite Dryer.
When using an electrical appliance, basic precautions should always be followed.
• Use only as instructed in this manual. Use only the recommended attachments and replacement parts.
• Do not leave machine when plugged in.
• Do not leave machine connected to the electricity supply when not in use.
• Do not leave the machine unattended while running.
• Only use accessories or spares specifically designed for use with this appliance.
• The fitting of other accessories or spare parts may affect the machines performance and safety.
• Use only indoors. Do not use outdoors or expose to rain.
• If the unit is not working as it should, has been dropped, damaged, left outdoors, or exposed to water, return it
to a service center before using.
• Do not use with damaged cord or plug.
• Do not kink or twist the power cord.
• Do not pull or carry by the cord, use the cord as a handle, close a door on cord, or pull cord around sharp edges
or corner. Keep cord away from heated surfaces.
• Do not pull on the cord to unplug. Grasp and pull the plug, not the cord. Turn off the dryer before unplugging.
• Do not handle the cord, plug, switch or dryer with wet hands.
• Do not use outlets with inadequate current capacity.
• Do not put any objects into openings. Do not use with any opening blocked. Keep free of dust, lint, hair and
anything that might reduce airflow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
• Do not use near combustible liquids, gases, or dusts, such as gasoline or other fuels, lighter fluid, cleaners, oil-
based paints, or natural gas, or anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• Do not operate near draperies or another material that could block the air intakes.
• Keep air intakes clear. Reduced airflow can cause motor to overheat.
• Keep children and unauthorized persons away from the dryer when in use.
• This machine is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge.
• Do not attempt to service the dryer yourself. Repair by anyone other than an authorized repair service center
may void the warranty.
• Store in dry area.
• Do not use an extension cord with this dryer.
To reduce the risk of fire or electric shock, do not use this fan with any solid-
state speed control device.
WARNING!
WARNING!

4
groundIng InStructIonS
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or service person if you are in doubt
as to whether the outlet is properly grounded. Do not modify the plug provided with
the appliance. If it will not fit the outlet, have a proper outlet installed by a qualified
electrician.
WARNING!
WARNING! The replacement or repair of damaged wiring should only be performed by a qualified
electrician or service engineer from the manufacturer or authorized service center.
This appliance must be grounded. If it should malfunction or breakdown, grounding provides
a path of least resistance for electric current to reduce the risk electric shock. This machine
is equipped with a cord having an equipment -grounding conductor and grounding plug. The
plug must be inserted into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING: Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service person if you are in doubt as to
whether the outlet is properly grounded. Do not modify the plug provided with the appliance - if
it will not fit the outlet, have a proper outlet installed by a qualified electrician.
This appliance is for use on a nominal 115-volt circuit, and has a grounding plug that looks like
the plug illustrated in sketch A.
A

5
oPeratIng InStructIonS
1. Plug in to a standard outlet with the correct voltage and amperage for the unit.
2. Use only on GFCI protected recepticles
3. Place the dryer in the desired operating position.
Daisy Chained
The unit can be daisy chained with up to 4 units on a dedicated 15 amp circuit with
the built in power outlet.
When daisy chaining units, each unit is controlled separately. The daisy chained units are
not controlled by the master unit that is plugged into the wall outlet. Even with the master
unit switch in the OFF position, any daisy chained unit(s) will still have power and may be
turned ON.
The circuit breaker controls both the fan and the outlet. If the circuit breaker trips while units are daisy chained,
remove some of the down stream units, then push in Reset button on circuit breaker. A maximum of 3 units may be
daisy chained off of 1 unit for a total of 4 units per circuit.
Operating Positions
The Hybrid dryer can be used in multiple positions. The PDH2 model can be used in the vertical position (Figure 1),
the horizontal position (Figure 2), with the kickstand (Figure 3), and using the side bumpers (Figure 4).
To ensure objects are not sucked against the intake guard during operation and decrease
airflow, do not place items in front of the intake guard.
3. Set the switch at the desired speed: LOW - I, MEDIUM - I I, or HIGH - I I I.
4. Check for proper operation before leaving the unit unattended.
Do not move or carry the dryer when it is running.
FIG. 1 FIG. 2 FIG. 3 FIG. 4
WARNING!
WARNING!
WARNING!
BUILT-IN POWER OUTLET
CAN DAISY CHAIN 4 PDH2
UNITS TOGETHER

6
maIntenance
Routine maintenance can significantly increase the life of your Hybrid Dryer. The applications and amount of use
varies, so the recommendations listed below are for average-to-high volume use. Constant operation may require
additional maintenance.
Always unplug machine before cleaning, or making any adjustments or repairs.
Before Each Use
1. Inspect power cord for fraying, cuts or damage; do not use if damaged.
2. Remove lint or obstructions from the Intake Guard and Exhaust Port Guard using a vacuum or compressed air.
3. Inspect exterior components (switch, knob, etc.) for damage.
After Each Use
1. Remove any lint or debris from the intake screen.
2. Clean dust and dirt from motor using a vacuum or compressed air.
3. Snugly wrap the power cord around the cord wrap/feet and secure the end of the power cord to itself using the latch on
the plug of the power cord.
4. Clean the exterior with a household all-purpose spray cleaner. Spray the rag, then apply to the surface.
Periodic Maintenance
1. Inspect all electrical connections.
2. Check the power cord for any breaks, fraying, separations, or cuts.
3. Make sure the ground pin or grounding prong is intact.
4. Inspect the motor and fan for build-up of debris, removing the intake screen and fan, cleaning as required.
If the dryer will not turn on:
1. Make sure the power cord is firmly connected to the unit and is in good condition.
2. Make sure the power cord is firmly seated in the wall outlet.
3. If using an extension cord, make sure it is in good condition, proper gauge and firmly connected.
4. Check to see if the building circuit breaker is tripped. If circuit is overloaded, move the unit to another circuit. On PDH2 - check
circuit breaker on unit.
Always store the dryer in a dry place. The dryers can be stacked during storage or transport to minimize the required space. The
stacking guide is located on the top and bottom of each unit.
WARNING!
trouble ShootIng
Storage

7
SPecIfIcatIonS
Specifications and parts are subject to change without notice.
Please refer to www.Powr-Flite.com for the latest schematic drawing and parts list.
EXHAUST PORT
EXHAUST PORT GUARD
INTAKE GUARD
POWER CORD
CORD WRAP
SPEED SWITCH
Model PDH2
Running Amps 2.8
Power 115V
Motor .4 hp
Air Velocity 3,400 FPM
Drying Positions 4 (0°, 5°, 90°, Side)
Housing co-polymer polypropylene
Daisy Chain Capable Yes
Kickstand Yes
Stackable Yes
Power Cord 20 ft. / 6 m
Net Weight 18 lbs. / 8.2 kg
Dimensions 22" x 16.5" x 11.5"/ 56 cm x 42 cm x 29 cm

8
3
1
2
36
34
35
6
32
31
20
33
25
24
22
19
18
12
14
16
17
15
13
21
11
10
26
9
27
8
28
29
7
5
4
20
12
23
18
30

9
SchematIc and PartS lISt
No. Part No. Qty Description
1 X9051 1 Caution Label
2 X8278 2 Screw 8-32 x 1/2”
3 X8976 1 Warning Label
4 X9726-SAN 1 Front Label
5 X8260 2 Nyloc Nut
6 X8897 1 Switch
7 X1023 1 Fan Blade
8 X8871 1 Dryer Discharge Grill
9 X9705 1 Grommet
10 X9700 1 Bottom Housing
11 X8946 2 Rivet
12 PD3B 4 Dryer Foot Tall
13 X9704 2 Screw, Hi-Lo 8-18 x
3.5”
14 X8874 1 Dryer Kickstand
15 X8928 1 Right Foot Kickstand
16 X8261 4 Screw #6 x 1/2”
17 X8929 1 Left Foot Kickstand
18 X9690 3 Screw 8-18 x 1/2”
19 X9676 10 Screw 8-18 x 3/4”
20 X9731 4 Cap
21 X9702 5 Bolt 1/4-20 x 2.75”
22 X8256 2 Nut
23 PX73 2 Screw 8-32 x 1”
24 X8459 1 Serial Number Label
25 X1002 1 Power Cord 14AWG
20’
26 04-0286-0000 1 Cable Clamp
27 X9674-120 1 Motor
115VAC,.43Hp,14Uf
Capacitor
28 X8235 5 Washer
29 X8237 5 Nyloc Nut
30 X9757 1 Wiring Harness w/Plug
31 X1022 1 Circuit Breaker 9Amp
32 X9701 1 Top Housing
33 X9727 1 Warning Label
34 X9831 1 Knob
35 X8903 2 Screw M4 x 6
36 X9728-TOR 1 Switch Label

A Tacony Company
3101 Wichita Court • Fort Worth, TX 76140-1755
1-800-880-2913 • Fax: [phone]
PDH2-MAN 02/2021
For warranty information go to www.Powr-Flite.com
