HP iPod plus HP Specification sheet

USB connector to PC
Headphone jack
Hold switch
iPod
Power Adapter
iPod Dock
(with some models)
Press once to play, press and hold to turn off iPod.
Press once to start a song over, press twice to play
the previous song, press and hold to rewind.
Press once to skip to next song, press and hold to
fast-forward.
Press to go back to previous menu.
FireWire (IEEE 1394)
connector
Click Wheel
Press around outer circle
to browse menu items and
to adjust volume.
Select button
Press center of circle to select.
Import Transfer and PlayBegin
Quick Setup
Step 1 Charge the Battery
Connect your iPod to the iPod Power Adapter
using the iPod Dock Connector to FireWire
Cable . Charge from two to four hours. Remove
the cable when done charging.
Step 2 Install the Software
Insert the iPod CD in your PC and follow the
onscreen instructions to install iTunes and the
iPod software.
When asked by the installer, connect your iPod to
the PC using the iPod Dock Connector to USB 2.0
Cable . It might take a few seconds to be
recognized. See the User’s Guide for other
connection options.
Step 3 Import Music to Your PC
There are three ways to get music into Apple iTunes:
Import music from your PC
• First check to see if you already have music in
iTunes. If you selected to find music files during
setup, your music was imported.
• If not, open iTunes and drag your My Music
folder into the iTunes Library in the Source list.
• See the User’s Guide to learn more about
file types.
Import music from your favorite CD
• Open iTunes.
• Insert your audio CD.
• Select the CD title in the iTunes Source list and
click the Import icon.
Buy music from iTunes (available in some
countries/regions only)
• Open iTunes.
• Make sure you have a live connection to
the Internet.
• Click Music Store in the iTunes Source list.
• Click Account Sign In and follow the instructions.
Step 4 Transfer Music to Your iPod
Make sure your iPod is connected to your PC.
Click File from the iTunes menu bar and select
Update Songs on your iPod.
Step 5 Play
Use the Click Wheel and Select button to browse
for a song. Press the Play or the Select button
and enjoy.
iPod Dock
connector
Press any button to turn on iPod.
© 2004 Hewlett-Packard Development Company, L.P. All rights reserved. Apple, the Apple logo, Firewire,
iPod, and iTunes are trademarks of Apple Computer, Inc., registered in the US and other countries.
For legal or rightholder-authorized copying only. Don’t steal music. 034-2723-A Printed in China
