Insignia NS-BCDCAS1 User manual

User Guide
Boombox with Cassette/CD Player/AM/FM Radio
NS-BCDCAS1
Before using your new product, please read these instructions to prevent any damage.
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 1 Friday, August 9, 2013 7:01 AM

www.insigniaproducts.com 3
Insignia NS-BCDCAS1
Boombox with Cassette/CD/
AM/FM Radio
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setting up your boombox . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using your boombox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Welcome
Congratulations on your purchase of a high-quality Insignia product.
Your NS-BCDCAS1 represents the state of the art in boomboxes and
is designed for reliable and trouble-free performance.
Safety information
To prevent fire or shock hazard, do not plug the power adapter into an
extension cord, receptacle, or other outlet unless the blades can be
fully inserted to prevent blade exposure. To prevent fire or shock
hazard, do not expose this boombox to rain or moisture.
Surge protectors:
We recommend that you use a surge protector when you use the AC
adapter with this boombox. Lightning and power surges ARE NOT
covered under the warranty for this product.
CAUTION: To reduce the risk of electric
shock, do not remove cover (or back). No
user-serviceable parts inside. Refer
servicing to qualified service personnel.
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 3 Friday, August 9, 2013 7:01 AM

4
Insignia NS-BCDCAS1 Boombox with Cassette/CD/ AM/FM Radio
www.insigniaproducts.com
The lightning flash with arrowhead symbol within a
triangle is intended to alert you to the presence of
uninsulated dangerous voltage within your boombox’s
enclosure that may be of sufficient magnitude to
constitute risk of electric shock to persons.
The exclamation point within a triangle is intended to
alert you to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying your boombox.
Read instructions
Read all the safety and operating instructions before you use your
boombox.
Your boombox utilizes a Class 1 laser to
read Compact Discs. Your boombox is
equipped with safety switches to avoid
exposure when the CD door is open and
the safety interlocks are defeated. Invisible
laser radiation is present when the CD
door is open and the system's interlock
has failed or been defeated. You should
avoid direct exposure to the laser beam at
all times. Do not attempt to defeat or
bypass the safety switches.
Warning
To reduce the risk of fire or electric shock, do not expose
your boombox to rain or moisture.
Warning
Any use of the controls or an adjustment to the procedures
other than those specified herein may result in hazardous
radiation.
Caution
Any change or modification to your boombox not expressly
approved by Insignia or its authorized parties could void
your authority to operate your boombox.
Caution
Your boombox should not be exposed to water (dripping or
splashing) and no objects filled with liquids, such as vases,
should be placed on it.
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 4 Friday, August 9, 2013 7:01 AM

5
Insignia NS-BCDCAS1 Boombox with Cassette/CD/ AM/FM Radio
www.insigniaproducts.com
Retain instructions
Retain safety and operating instructions for future reference.
Follow warnings and instructions
Follow all warnings on your boombox and in the operating
instructions. Follow all operating and use instructions.
Placement
When placing your boombox on a lacquered or natural finish, protect
your furniture with a cloth or other protective material.
Avoid exposure to direct sunlight, temperature extremes, and
moisture.
Ventilation
Slots and openings in the cabinet and the back or bottom are
provided for ventilation, reliable operation, and protection from
overheating. These openings must not be blocked or covered. Do not
block the openings by placing your boombox on a bed, sofa, rug, or
other similar surface.
Water and moisture
Do not use your boombox near water. For example, do not use it near
a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
Do not let water slash or drip onto your boombox. Do not place
objects containing liquids, such as a vase, on top of your boombox.
The AC power adapter is used as the disconnect device. It should
remain readily accessible and should not be obstructed during use.
To completely disconnect power, the AC power adapter should be
unplugged from the AC power outlet completely.
The marking plate of the AC adapter is located on the bottom of the
adapter.
Features
Package contents:
•Boombox
• AC power adapter
• User Guide
• Quick Setup Guide
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 5 Friday, August 9, 2013 7:01 AM

6
Insignia NS-BCDCAS1 Boombox with Cassette/CD/ AM/FM Radio
www.insigniaproducts.com
Front panel
# Description Function
1 MEM button In radio mode, press to create/select preset stations.
2(stop) button Press to stop playback.
3(play/pause) button Press to begin CD playback. Press again to pause
playback.
4Standby/ON button Press to turn on your boombox. Press again to return
your boombox to standby mode.
5(source) button Press to select the sound source (RADIO, CD, TAPE,
or AUX).
6 Cassette tape control
buttons
These buttons control tape playback. See Top panel
below for additional information.
VOLUME
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 6 Friday, August 9, 2013 7:01 AM

7
Insignia NS-BCDCAS1 Boombox with Cassette/CD/ AM/FM Radio
www.insigniaproducts.com
7 VOLUME –/+ button Press to lower or raise the volume.
8(next) button In radio mode, press to tune to the next higher station.
In CD mode, press to search/skip to the next track.
9(previous) button In radio mode, press to tune to the next lower station.
In CD mode, press to search/skip to the previous track.
10 BAND/PLAY MODE
button
In radio mode, press to select the radio band (AM or
FM).
In CD mode, press to cycle through the playback
modes (repeat 1, repeat all, or random).
11 Display Shows radio band, playback mode, program mode,
source, volume level, and radio frequency. For
additional information, see “Display.”
12 Cassette door Open to insert a cassette tape into the boombox for
playback.
13 Left and right speakers Produce sound so you can listen to your boombox.
# Description Function
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 7 Friday, August 9, 2013 7:01 AM

8
Insignia NS-BCDCAS1 Boombox with Cassette/CD/ AM/FM Radio
www.insigniaproducts.com
Top panel
# Description Function
1 PAUSE button Press to pause the tape playback. Press again to
resume playback.
2 STOP/ EJECT button Press to stop cassette tape playback. Press again
to open the cassette door.
3FWD button Press to fast forward the cassette tape.
4REW button Press to rewind the cassette tape.
5PLAY button Press to begin cassette tape playback.
6 PRESS TO OPEN Press to open the CD door.
7 CD door Open to place a CD on the spindle for playback.
8 REC button Press to begin cassette tape recording.
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 8 Friday, August 9, 2013 7:01 AM

9
Insignia NS-BCDCAS1 Boombox with Cassette/CD/ AM/FM Radio
www.insigniaproducts.com
Back panel
# Description Function
1 FM antenna wire Provides an improved FM signal. Do not connect
to an outside antenna.
2AUX IN jack Connect an external audio device to this jack.
3DC IN 12V jack Connect the AC adapter (included) to this jack to
operate your boombox on AC power.
4 Headphone jack Connect headphones to this jack to listen to radio/
playback through your headphones.
5 Battery compartment Insert six (6) “D” sized alkaline batteries (not
included) into this compartment to operate your
boombox on battery power.
12
3
4
5
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 9 Friday, August 9, 2013 7:01 AM

10
Insignia NS-BCDCAS1 Boombox with Cassette/CD/ AM/FM Radio
www.insigniaproducts.com
Display
In CD mode—the display shows the current track time elapsed
(during playback), the total number of tracks (in stop mode).
In Radio mode—the display shows the preset selected and the
frequency.
In Tape mode—the display shows “CAS.”
In AUX mode—the display shows “Aud.”
Setting up your boombox
Connecting the AC power adapter
To connect the AC power adapter:
1Make sure that your local AC power source matches the voltage
shown on the plate located on the AC power adapter. If it does not,
consult your dealer or service center.
2Insert the small connector at the end of the AC power adapter
cable into the DC IN jack on the back of your boombox.
3Plug the AC power adapter into a wall power outlet.
Caution
To protect your boombox during thunderstorms, unplug the
AC power adapter from the AC power outlet.
Radio band
Random
playback
activated
Radio program
mode activated
Repeat mode:
On–repeat
current track
Blink–repeat all
tracks
Tuner
frequency unit
Source, volume level, or program
FM Stereo
signal
indicator
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 10 Friday, August 9, 2013 7:01 AM

11
Insignia NS-BCDCAS1 Boombox with Cassette/CD/ AM/FM Radio
www.insigniaproducts.com
Installing the batteries
To install the batteries:
1Turn your boombox over, then open and remove the door to the
battery compartment.
2Insert six (6) “D” size batteries into the battery compartment.
Make sure that you match the + and – symbols on the batteries
with the + and – symbols in the battery compartment.
3Reinstall and close the battery compartment door and return your
boombox to the upright position.
Note
Only use the supplied AC power adapter, which has the
following specifications: DC=12V 1.25A
Unplug both the DC plug and the adapter when not in use.
The batteries are automatically bypassed when the AC
power adapter is used.
- Power Adapter Electrical Specs: 100-240 V ~ 50-60 Hz,
0.7A
- Device Electrical Specs: 12 VDC, 1.25 A
Note
The AC power adapter must be disconnected from the
DC IN jack on the back of your boombox in order for your
boombox to operate on battery power.
Caution
Follow these precautions when using batteries in this
device:
- Use only the size and type of batteries specified.
- Make sure that you follow the correct polarity as indicated
in the battery compartment when installing batteries.
Reversed batteries may cause damage to your boombox.
- Do not mix different types of batteries together (for
example, alkaline, rechargeable, and carbon zinc), or
semi-used batteries with fresh ones.
- If your boombox is not to be used for a long period of time,
remove the batteries to prevent damage or injury from
possible battery leakage.
- Do not try to recharge batteries not intended to be
recharged, because they can overheat and rupture.
(Follow battery manufacturer’s directions.)
- Do not throw batteries into a fire. Dispose of used batteries
as hazardous waste.
NS-BCDCAS1_13-0709_MAN_V1-ENG.fm Page 11 Friday, August 9, 2013 7:01 AM
