HP BL25p - ProLiant - 1 GB RAM User instructions

1. Access Panel 7. Redundant Fan Module
2. Processor 2 Memory Banks C and D 8. Processor 1 Memory Banks A and B
3. Up to two AMD Opteron™ 2000 Series processors (shown
here with 1 processor installed)
9. Smart Array E200i Controller cache module
4. Up to 2 small form factor (SFF) SAS or SATA hot plug hard
disk drives (optional)
10. Optional Dual Port Fibre Channel Adapter (QLogic-based or
Emulex-based)
5. Power On/Standby Button 11. Optional NIC Adapter (single function or multifunction
Gigabit)
6. Front panel LEDs
What's New
What's NewWhat's New
What's New
Support for 36 GB and 72 GB 15K DP Serial Attached SCSI (SAS) SFF Hot Plug Hard Drives
Support for 72 GB and 146 GB10K DP Serial Attached SCSI (SAS) SFF Hot Plug Hard Drives
At A Glance
At A GlanceAt A Glance
At A Glance
This QuickSpecs provides information for the HP ProLiant BL25p G2 server blade only. For more information on HP BladeSystems p-
Class Infrastructure and HP BladeSystem p-Class Interconnect Components, please see the following QuickSpecs:
HP BladeSystem p-Class Infrastructure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12330_na/12330_na.HTML and HP BladeSystem p-Class Interconnect
Components QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12331_na/12331_na.HTML
The HP ProLiant BL25p Generation 2 server blade delivers maximum dual-processor performance, enterprise manageability and
availability, and superior server design to the datacenter.
Processor:
Processor:Processor:
Processor:
Up to two AMD Opteron 2000 Series processors
Supports up to two AMD Opteron processor Model 2220 (2.8 GHz) featuring 1MB Level 2 cache memory per core
Supports both standard (95W) and low power (68W) versions of AMD Opteron 2000 series processors
Processors are connected through 1 GHz HyperTransport™ links
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Overview
DA - 12569 Canada — Version 10 — December 14, 2007 Page 1

ServerWorks HT-1000 and HT-2100 chipsets
Memory:
Memory:Memory:
Memory:
Up to 32 GB of PC2-5300 Registered DDR2 (667 MHz) memory, 8 DIMM slots
Advanced ECC memory support
Supports 2:1 memory interleaving
Storage Controller:
Storage Controller:Storage Controller:
Storage Controller:
Integrated Smart Array E200i Controller with 64 MB cache
Supports RAID 0 and 1
Optional 128MB battery-backed write cache (BBWC) module for internal storage data protection
Internal Drive Support:
Internal Drive Support:Internal Drive Support:
Internal Drive Support:
Up to 2 small form factor (SFF) SAS or SATA hot plug hard disk drives (support for SATA hard drives via Factory
Integration only)
Network Controller:
Network Controller:Network Controller:
Network Controller:
Two (2) embedded NC373i Multifunction Gigabit Server Adapters with TCP/IP Offload Engine for Microsoft Windows
One (1) additional 10/100 NIC dedicated to iLO 2 management
Optional Mezzanine Card support:
Optional Mezzanine Card support:Optional Mezzanine Card support:
Optional Mezzanine Card support:
Supports (1) Fibre Channel card:
Dual Port Fibre Channel Mezzanine (2-Gb) options for SAN connectivity (Choice of Emulex or QLogic)
Supports (1) networking card for two (2) additional Ethernet network ports, choose from the following:
HP NC374m PCI Express Dual Port Multifunction Gigabit Server Adapter for HP BladeSystem with TCP/IP
Offload Engine for Microsoft Windows
HP NC320m PCI Express Dual Port Gigabit Server Adapter for HP BladeSystem
USB Ports:
USB Ports:USB Ports:
USB Ports:
One (1) internal USB 2.0 connector for security key devices and USB drive keys
I/O cable with two (2) USB 2.0 ports, one (1) video port, one (1) iLO 2 port and one (1) kernel debug port. The cable
was specifically designed to aid in initial server image deployment and ships with every HP BladeSystem p-Class server
blade enclosure
Redundancy:
Redundancy:Redundancy:
Redundancy:
The HP BL25p G2 server features five (5) integrated fans for sufficient cooling. The redundant fan design allows for
uninterrupted server operations
Operating Systems:
Operating Systems:Operating Systems:
Operating Systems:
Supports Windows, Linux, Solaris, and VMware ESX Server
Form Factor:
Form Factor:Form Factor:
Form Factor:
The HP ProLiant BL25p G2 server blade plugs vertically into an HP BladeSystem p-Class server blade enclosure.
HP BladeSystem p-Class server blade enclosures with enhanced backplane components might be required depending
on which HP ProLiant server blade model is selected. Please visit the enclosure compatibility matrix at
http://www.hp.com/go/bladesystem/enclosure/compatibility
Management:
Management:Management:
Management:
Integrated Lights-Out 2 (iLO 2) Standard Blade Edition (includes virtual KVM and graphical remote console at no
additional cost)
Enclosures:
Enclosures:Enclosures:
Enclosures:
The HP BladeSystem p-Class server blade enclosure is 6U (10.5-inches) in height, 19-inches wide and holds up to 8 HP
ProLiant BL25p G2 server blades plugged vertically.
Warranty:
Warranty:Warranty:
Warranty:
Protected by HP Services and a worldwide network of HP Authorized Channel Partners. Three-year parts, 3 Year Labor
and 3 Year on-site limited global warranty. Certain restrictions and exclusions apply. SATA hard drives have a one year
warranty.
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Overview
DA - 12569 Canada — Version 10 — December 14, 2007 Page 2

NOTE:
NOTE:NOTE:
NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and
specifications, please visit: http://h71028.www7.hp.com/ERC/downloads/4AA0-7325ENW.pdf
Processors
ProcessorsProcessors
Processors AMD Opteron™ processor Model 2220 (2.8 GHz, 95W)
AMD Opteron processor Model 2218 (2.6 GHz, 95W)
AMD Opteron processor Model 2216 (2.4 GHz, 95W)*
AMD Opteron processor Model 2210 (1.8 GHz, 95W)*
Low Power AMD Opteron processor Model 2216 HE (2.4 GHz, 68W)
Low Power AMD Opteron processor Model 2214 HE (2.2 GHz, 68W)
Low Power AMD Opteron processor Model 2212 HE (2.0 GHz, 68W)*
Low Power AMD Opteron processor Model 2210 HE (1.8 GHz, 68W)
NOTE:
NOTE:NOTE:
NOTE: AMD Opteron 2000 Series processors are 64-bit, dual-core, and support AMD Virtualization™
and DDR2 memory technology. AMD Opteron 2000 Series processors are connected through 1 GHz
HyperTransport™ links.
NOTE:
NOTE:NOTE:
NOTE: *Offered via Factory Integration only.
Upgradeability
UpgradeabilityUpgradeability
Upgradeability Upgradeable to dual processing (2 processors)
Cache Memory
Cache MemoryCache Memory
Cache Memory 1MB Level 2 cache memory per core (2MB total)
Chipset
ChipsetChipset
Chipset ServerWorks HT-1000 and HT-2100
Memory
MemoryMemory
Memory Type PC2-5300 Registered DDR2 DIMMs (667 MHz)
Standard
(Depending on
model)
1 GB (2 x 512 MB)
2 GB (2 x 1 GB)
Maximum 32 GB (8 x 4 GB)
NOTE:
NOTE:NOTE:
NOTE: Memory must be installed in pairs. For additional memory configuration guidelines, see
"Memory" section of this HP BL25p G2 QuickSpecs.
Network Adapter
Network AdapterNetwork Adapter
Network Adapter Two (2) embedded NC373i Multifunction Gigabit Network Adapters
One (1) additional 10/100 NIC dedicated to iLO 2 Management
NOTE:
NOTE:NOTE:
NOTE: Must use a HP BladeSystem p-Class server blade enclosure with enhanced backplane
components to utilize all four possible NIC's (HP P/N's 281404-B22, 243564-B22 or 380625-B22).
Expansion Slots
Expansion SlotsExpansion Slots
Expansion Slots No PCI slots; all features are integrated
NOTE:
NOTE:NOTE:
NOTE: Additional network and fibre channel connectivity is available via optional mezzanine cards.
I/O cable connectors:
I/O cable connectors:I/O cable connectors:
I/O cable connectors:
(2) USB 2.0 ports, (1) video port, (1) iLO 2 port and (1) kernel debug port
(2) I/O cables ship with every HP BladeSystem p-Class server blade enclosure
Tested USB devices (keyboard, mouse, floppy) are listed in the "Options" section of this QuickSpecs.
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Standard Features
DA - 12569 Canada — Version 10 — December 14, 2007 Page 3

Integrated Manageability
Integrated ManageabilityIntegrated Manageability
Integrated Manageability Integrated Lights-Out 2 (iLO 2) Standard Blade Edition (integrated on motherboard)
Virtual KVM based remote console
Virtual media (single server, browser based access only)
Remote Serial Console
Virtual Power Button Control
Virtual Unit ID control
Integrated Remote Console
Dedicated network connectivity
Embedded system health
Browser, command line (SM-CLP) and scripted access
Automatic IP Configuration via DHCP/DNS/WINS
Industry Standard 128-bit Secure Sockets Layer (SSL) and Secure Shell security (SSH)
OS independent hardware health status
IML and iLO Event Logging
Support for 12 user accounts with customizable access privilege
Single sign-on from HP BladeSystem Onboard Administrator
Storage Controller
Storage ControllerStorage Controller
Storage Controller Smart Array E200i
Controller
64MB memory module supports RAID 0 and 1
Supports SAS and SATA disk drives
Available upgrades: 128MB battery-backed write cache (BBWC)
module
Maximum Internal
Maximum InternalMaximum Internal
Maximum Internal
Storage
StorageStorage
Storage (internal drive
cage)
Hot Plug Serial Attach
SCSI (SAS)
292GB SAS 2 x 146GB Serial SCSI
Hot Plug Serial ATA (SATA) 240GB SATA 2 x 120GB Serial ATA
Graphics
GraphicsGraphics
Graphics Integrated ATI RN-50 1280 x 1024 x 16M color (32 MB DDR1 memory)
Graphics Resolution
Graphics ResolutionGraphics Resolution
Graphics Resolution
Supported
SupportedSupported
Supported
Resolution Color Depths Depths 1280 x 1024, 64k, 256,16
1024 x 768, 16.7M, 64k, 256, 16
800 x 600, 16.7M, 64k, 256, 16
640 x 480, 16.7M, 64k, 256, 16
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Standard Features
DA - 12569 Canada — Version 10 — December 14, 2007 Page 4

Fiber Channel on the
Fiber Channel on theFiber Channel on the
Fiber Channel on the
HP ProLiant BL25p G2
HP ProLiant BL25p G2HP ProLiant BL25p G2
HP ProLiant BL25p G2
server blade
server bladeserver blade
server blade
The HP ProLiant BL25p G2 supports one (1) optional fiber channel adapter for SAN connectivity.
Customers are offered a choice of either a QLogic-based or Emulex-based fiber channel adapter. Both
adapters are mezzanine circuit boards which connect directly to the server blade system board. These
optional fiber channel adapters are available via option kits and must be ordered separately.
QLogic-based
Utilizes a QLogic ISP2312 chipset
The HP QLogic-based dual port Fibre Channel Adapter (P/N 361426-B21) is compatible
with the HP ProLiant BL20p G3, BL20p G4, BL25p G2, and BL45p G2 server blades. It
cannot be used with HP ProLiant BL25p G1, BL35p, or BL45p G1 server blades
Includes two small form factor pluggable transceivers with LC connectors for installation
into the Patch Panel 2, CGESM or GbE2 Interconnect Switch (with the Storage Connectivity
Kit)
Emulex-based
Utilizes an Emulex "Thor" chipset
The HP Emulex-based dual port fibre channel HBA (P/N 394757-B21) is compatible with
the HP ProLiant BL20p G3, BL20p G4, BL25p G2, and BL45p G2 server blades. It cannot
be used with HP ProLiant BL25p G1, BL35p, or BL45p G1 server blades
There are no SFP's included in the Emulex mezzanine kit for use with ProLiant BL p-Class
Fibre Channel pass-through interconnects. If you require SFPs for use with an Emulex
mezzanine and a FC pass through interconnect please order an SFP option kit (P/N
397577-B21) which will provide 2 FC SFPs per option kit
Two ports on each Dual-port Fibre Channel Mezzanine Card provide a redundant Fibre Channel
connection to each server blade
Supports up to 2 Gb/s Fibre Channel equipment
Compatible SAN
Compatible SANCompatible SAN
Compatible SAN HP ProLiant BL25p G2 server blades are optimized for StorageWorks MSA, EVA, and XP arrays.
HP ProLiant BL25p G2 server blades are compatible with select 3rd party SANs (please see server
blade storage page for more details):
http://h18000.www1.hp.com/products/servers/proliant-bl/p-class/storage.html
ProLiant Essentials
ProLiant EssentialsProLiant Essentials
ProLiant Essentials
Foundation Pack Software
Foundation Pack SoftwareFoundation Pack Software
Foundation Pack Software
for the ProLiant BL Server
for the ProLiant BL Serverfor the ProLiant BL Server
for the ProLiant BL Server
HP Systems Insight
Manager
HP Systems Insight Manager (HP SIM) provides a unified, secure and
extensible environment to centrally manage servers, storage and other
infrastructure devices across multiple operating system platforms.
Through a single management view, HP SIM provides core management
services that include device discovery and identification, event views, health
monitoring, inventory data collection, software version control and reporting.
HP SIM is built on industry standards and is extensible with value-added
ProLiant Essentials, Integrity Essentials and Storage Essentials software to
meet individual management needs. For more details on HP SIM visit
http://www.hp.com/go/hpsim .
HP SIM provides organizations with the following benefits:
Simplifies and consolidates infrastructure lifecycle management using
task and query based functionality
Provides the foundation for infrastructure automation and
virtualization
Enables IT management based on business processes not hardware
platforms
Lowers infrastructure maintenance cost and frees resources for
innovation
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Standard Features
DA - 12569 Canada — Version 10 — December 14, 2007 Page 5

Maximizes resource utilization with virtualization technologies
Provides a central point of integration between infrastructure and
Enterprise management tools such as HP OpenView
ProLiant Essentials Rapid
Deployment Pack
Rapid Deployment Pack (RDP) is an automated deployment and provisioning
solution for all ProLiant servers. RDP includes the Altiris Deployment Solution
and ProLiant Integration Module featuring ProLiant server pre-configured
events for OS installation, and optimized software drivers, firmware and
management agents. Every RDP CD includes 10-node trial licenses for
evaluation purposes. RDP requires a license for each server deployed and is
available for purchase with blade servers. For more information, visit
http://www.hp.com/servers/rdp .
Insight Management
Agents
Insight Management Agents should be installed on all HP servers to present
system instrumentation, health and configuration information into HP
Systems Insight Manager and the HP System Management Homepage. The
HP System Management Homepage aggregates systems data from Insight
Management Agents and other HP management tools, providing a
consolidated browser-based interface for managing individual servers,
Insight Management Agents and The HP System Management Homepage
are included on ProLiant Support Packs, and can also be installed using the
server profiles provided with the ProLiant Essentials Rapid Deployment Pack.
For additional information about the Management Agents and the HP
System Management Homepage please visit the management Web site at
http://www.hp.com/servers/manage
Subscriber's Choice Subscriber's Choice Driver and Support Alerts/Notifications is a web-based
email subscription service that provides software and driver change
notifications for ProLiant products. Sign up at
http://www.hp.com/go/subscriberschoice
and customize your profile to receive various new alerts as they become
available, on a weekly or monthly basis.
ROMPaq, support
software, and
configuration utilities
The latest drivers and firmware fully optimized and tested for your ProLiant
server and options, available on the RDP Media kit, SmartStart or
downloadable from Software and Drivers download pages, linked from the
SmartStart website at http://www.hp.com/go/support .
Insight Diagnostics The most advanced configuration analysis, reporting and troubleshooting
utilities used by HP and at your fingertips, available in SmartStart.
NOTE:
NOTE:NOTE:
NOTE: For more information regarding ProLiant Essentials Software, please
see the following URL: http://www.hp.com/servers/proliantessentials
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Standard Features
DA - 12569 Canada — Version 10 — December 14, 2007 Page 6

Optional ProLiant
Essentials Value Packs
HP Insight Control management suites and most HP ProLiant Essentials will
include one year of 24 x 7 HP Software Technical Support and Update
Service ensuring rapid access to HP support staff and proactive delivery of
software updates. For more information about this service, please visit:
http://www.hp.com/services/insight .
Optional software offerings that selectively extend the functionality of an
Adaptive Infrastructure to address specific business problems and needs:
Insight Control Environment for BladeSystem
Insight Control Environment for BladeSystemInsight Control Environment for BladeSystem
Insight Control Environment for BladeSystem - is based on HP
Systems Insight Manager and ProLiant Essentials software, and brings
the value of Insight Control to ProLiant customers by delivering
comprehensive health and performance monitoring, remote control,
vulnerability scanning and patch management as well as flexible
deployment and power management through an integrated
installation package and streamlined licensing. For more information,
visit: http://www.hp.com/go/ice
Rapid Deployment Pack
Rapid Deployment PackRapid Deployment Pack
Rapid Deployment Pack (RDP) is an automated deployment and
provisioning solution for all ProLiant servers. RDP includes the ProLiant
Integration Module featuring ProLiant server pre-configured events for
OS installation, and optimized software drivers, firmware and
management agents. Every RDP disc includes 10-node trial licenses
for evaluation purposes. RDP requires a license for each server
deployed and is available for purchase with HP servers. For more
information, visit: http://www.hp.com/servers/rdp .
Server Migration Pack - Universal Edition
Server Migration Pack - Universal EditionServer Migration Pack - Universal Edition
Server Migration Pack - Universal Edition - Upgrading, replacing, or
virtualizing your existing server? Effortlessly transition to new virtual or
physical HP ProLiant servers or BladeSystem with automated, accurate
and affordable migration of OS, application and data. SMP Universal
automates the manual processes required for migrating servers
between physical or virtual platforms, whether migrating to VMware or
Microsoft virtual machines. SMP Universal allows all of the following:
Physical to ProLiant
Physical to virtual
Virtual to virtual
Virtual to ProLiant
Virtual Machine Management Pack
Virtual Machine Management PackVirtual Machine Management Pack
Virtual Machine Management Pack - Get the most out of server
virtualization by unifying the management of physical and virtual
servers in HP Systems Insight Manager. The Virtual Machine
Management Pack plug-in provides central management and control
of VMware and Microsoft virtual machines and provides physical host
to virtual machine association.
NOTE:
NOTE:NOTE:
NOTE: Flexible and volume quantity license kits are available for ProLiant
Essentials Value Packs. Refer to
http://www.hp.com/servers/proliantessentials or the various ProLiant
Essentials Value Pack product QuickSpecs for more information.
Optional Remote
Management
Integrated Lights-Out Select Pack - upgrades the Integrated Lights-Out
processor with scripted and command line virtual media (floppy,
CD/DVD, USB key), historical power reporting and enterprise security
(directory services and two-factor authentication).
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Standard Features
DA - 12569 Canada — Version 10 — December 14, 2007 Page 7

SmartStart
SmartStartSmartStart
SmartStart SmartStart is a tool that simplifies single server setup, providing a rapid way to deploy reliable and
consistent server configurations. SmartStart 7.60 and later can now deploy all HP ProLiant BL25p G2
server blades, using the I/O port with an attached USB CD-ROM device. To obtain a copy of SmartStart
for your blade server, redeem the coupon that is included with your Blade server or order your copy from
the SmartStart web site. For more information, please visit the SmartStart Web site at
http://www.hp.com/servers/smartstart .
SmartStart version supported (minimum): SmartStart 7.60
OS Support
OS SupportOS Support
OS Support Windows Server 2003, Web edition
Windows Server 2003, Server/Standard edition (32 & 64 bit editions)
Windows Server 2003, Enterprise edition (32 & 64 bit editions)
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Solaris 10 (32 & 64 bit editions)
VMware ESX Server 3
NOTE:
NOTE:NOTE:
NOTE: For a complete and up-to-date listing of supported OSs and versions, please visit our OS
Support Matrix at: http://www.hp.com/go/supportos .
NOTE:
NOTE:NOTE:
NOTE: For an up-to-date listing of the latest drivers available for the HP ProLiant BL p-Class, please see:
http://h18004.www1.hp.com/support/files/server/us/family/model/5342.html .
NOTE:
NOTE:NOTE:
NOTE: For a more complete and up-to-date information on Linux support, please visit HP Linux Web
site at: http://h18000.www1.hp.com/products/servers/linux/hpLinuxcert.html .
NOTE:
NOTE:NOTE:
NOTE: For more Linux OS support & certification information, please visit our the ProLiant &
Bladesystem Server Linux matrix http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html
Supported Software
Supported SoftwareSupported Software
Supported Software
Options
OptionsOptions
Options
VMware Virtualization Software
NOTE:
NOTE:NOTE:
NOTE: For more information on HP's Certified and Supported HP ProLiant Servers, please visit the
VMware Server Support Matrix at:
http://h18004.www1.hp.com/products/servers/software/vmware/hpvmwarecert.html
Availability
AvailabilityAvailability
Availability Dual Port Fibre Channel Mezzanine Card (optional) for redundant SAN connection
Two hot plug SAS/SATA hard drive bays and integrated RAID (Smart Array E200i) controller on
every server blade (Battery-backed write cache is optional)
Redundant ROM on every server blade
Advanced ECC Memory support on every server blade - Advanced ECC can actually correct a
multi-bit error (up to 4 bits) that occurs within one memory chip
Redundant fan design on every server blade - The HP ProLiant BL25p G2 server features five (5)
integrated fans for sufficient cooling. A single fan can fail without interrupting server operations
indefinitely
Network adapter teaming (network fault tolerance, transmit load balancing, switch-assisted load
balancing)
Security
SecuritySecurity
Security Power-on password
Administrator's password
Integrated Lights-Out has 12 customizable user accounts and SSL encryption
Integrated Lights-Out can be disabled via a Global Setting
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Standard Features
DA - 12569 Canada — Version 10 — December 14, 2007 Page 8

Factory Express Portfolio
Factory Express PortfolioFactory Express Portfolio
Factory Express Portfolio
for Servers and Storage
for Servers and Storagefor Servers and Storage
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging and custom packaging. HP products supported through Factory Express include: a wide array of
servers and storage: HP Integrity, HP ProLiant & HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to http://www.hp.com/go/factory-express .
HP Enterprise
HP EnterpriseHP Enterprise
HP Enterprise
Configurator
ConfiguratorConfigurator
Configurator
The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio.
This approach is aligned with our strategic direction to meet the needs and expectations of our valued
customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or
an Authorized Partner for assistance.
Service and Support
Service and SupportService and Support
Service and Support This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for
three years from date of purchase. Support for software and initial setup is available for 90 days from
date of purchase. Additional support may be covered under the warranty or available for an additional
fee. Enhancements to warranty services are available through HP Care Pack services or customized
service agreements.
NOTE:
NOTE:NOTE:
NOTE: Server Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support. Additional
information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
NOTE:
NOTE:NOTE:
NOTE: Server Blade Limited Warranty includes 3 year Parts, 1 year Labor, 1-year on-site support. This
warranty supports the HP ProLiant 35p Server Blades.
NOTE:
NOTE:NOTE:
NOTE: Server Blade Enclosure Limited Warranty includes 3 year Parts, 3 year Labor, 3-year on-site
support.
NOTE:
NOTE:NOTE:
NOTE: Server Blade Interconnect Limited Warranty includes 3 year Parts, 3 year Labor, 3-year on-site
support.
NOTE:
NOTE:NOTE:
NOTE: The p-Class SAN switch limited warranty is unique to the SAN switch which includes 1 year
warranty that is upgradeable to 3 years via Care Pack
HP services provide total care and support expertise with committed response designed to meet your IT
and business needs.
The HP Care Pack services ProLiant BL p-Class server blades, cover the server blade and all HP branded
hardware options qualified for the server, purchased at the same time or afterwards, internal to the
server.
HP Care Pack services for HP BladeSystem p-Class server blade enclosure covers the enclosure including
patch panels, HP supported Ethernet interconnects, power enclosure with power supplies and power
distribution.
To fully capitalize on your HP ProLiant servers' capabilities requires a service partner who thoroughly
understands your server technology and systems environment. HP Services, an industry leader in
provision of multi vendor support solutions provides a range of support services designed to meet the
varying needs of business. Whether an SMB or large global corporation HP has a ProLiant server support
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Standard Features
DA - 12569 Canada — Version 10 — December 14, 2007 Page 9

offer to help you speedily deploy and maximize system uptime.
Recommended Service
Recommended ServiceRecommended Service
Recommended Service - Simplify ProLiant solution implementation, maintenance and management.
Support Service
Support ServiceSupport Service
Support Service - 4-Hour Response Coverage, 3-Year, 24 x 7, Same Business Day
Deployment Service
Deployment ServiceDeployment Service
Deployment Service - Installation and Start Up for HP BladeSystem Infrastructure
Enhanced Service
Enhanced ServiceEnhanced Service
Enhanced Service - Optimize service level to increase IT performance and availability
Support Service
Support ServiceSupport Service
Support Service - HP Proactive BladeSystem Service, 1-Year
Deployment Service
Deployment ServiceDeployment Service
Deployment Service - Enhanced Network Installation and Start-up for HP BladeSystem Switches
Installation & Start-Up service for HP BladeSystem Infrastructure plus HP BladeSystem Enhanced Network
Installation and Start-UP as per the Customer Description and/or Data Sheet. To be delivered on a
scheduled basis 8am-5pm, M-F, excluding HP holidays.
For a complete listing of service offerings and information visit:
http://www.hp.com/services/bladesystemservices
http://www.hp.com/go/proliant/carepack
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Standard Features
DA - 12569 Canada — Version 10 — December 14, 2007 Page 10

Dual-Core Models
Dual-Core ModelsDual-Core Models
Dual-Core Models
HP ProLiant BL25p G2
HP ProLiant BL25p G2HP ProLiant BL25p G2
HP ProLiant BL25p G2
2220 DC, 2GB (1P)
2220 DC, 2GB (1P)2220 DC, 2GB (1P)
2220 DC, 2GB (1P)
438211-B21
ProLiant BL25p G2 2218
ProLiant BL25p G2 2218ProLiant BL25p G2 2218
ProLiant BL25p G2 2218
2GB (1P)
2GB (1P)2GB (1P)
2GB (1P)
408666-B21
ProLiant BL25p G2 2216
ProLiant BL25p G2 2216ProLiant BL25p G2 2216
ProLiant BL25p G2 2216
HE 2GB (1P)
HE 2GB (1P)HE 2GB (1P)
HE 2GB (1P)
408665-B21
ProLiant BL25p G2 2214
ProLiant BL25p G2 2214ProLiant BL25p G2 2214
ProLiant BL25p G2 2214
HE 2GB (1P)
HE 2GB (1P)HE 2GB (1P)
HE 2GB (1P)
408664-B21
ProLiant BL25p G2 2210
ProLiant BL25p G2 2210ProLiant BL25p G2 2210
ProLiant BL25p G2 2210
HE 1GB (1P)
HE 1GB (1P)HE 1GB (1P)
HE 1GB (1P)
408663-B21
Processor(s)
Processor(s)Processor(s)
Processor(s) (1) AMD Opteron™ processor Model 2220 (2.8 GHz, 95W) Processor
Option Kit
(1) AMD Opteron processor Model 2218 (2.6 GHz, 95W)
(1) Low Power AMD Opteron processor Model 2216 HE (2.4 GHz, 68W)
(1) Low Power AMD Opteron processor Model 2214 HE (2.2 GHz, 68W)
(1) Low Power AMD Opteron processor Model 2210 HE (1.8 GHz, 68W)
Cache Memory
Cache MemoryCache Memory
Cache Memory 1MB Level 2 cache memory per core (2MB total)
Memory
MemoryMemory
Memory
One of the following
depending on model
2 GB (2 x 1 GB) PC2-5300, Registered DDR2-667
1 GB (2 x 512 MB) PC2-5300, Registered DDR2-667
Network Adapter
Network AdapterNetwork Adapter
Network Adapter Two (2) embedded NC373i Multifunction Gigabit Network Adapters; one (1)
additional 10/100 NIC dedicated to iLO 2 management
Storage Controller
Storage ControllerStorage Controller
Storage Controller Smart Array E200i Controller with 64MB (optional 128MB battery-backed
write cache module available)
Hard Drives
Hard DrivesHard Drives
Hard Drives (2) SFF SAS/SATA drive bays; no hard drives ship standard
Internal Storage
Internal StorageInternal Storage
Internal Storage Up to 292GB SFF SAS (with optional hot plug hard disk drives)
Up to 120GB SFF SATA (with optional hot plug hard disk drives)
Optical Drive
Optical DriveOptical Drive
Optical Drive None
Form Factor
Form FactorForm Factor
Form Factor Up to 8 HP BL25p G2 server blades plug vertically an HP BladeSystem p-
Class server blade enclosure. Please visit the enclosure compatibility matrix
at http://www.hp.com/go/bladesystem/enclosure/compatibility
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Models
DA - 12569 Canada — Version 10 — December 14, 2007 Page 11

NOTE:
NOTE:NOTE:
NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO
product offerings and requirements.
NOTE:
NOTE:NOTE:
NOTE: HP does not allow factory integration of options into standard models listed above.
Configure-to-order servers must start with a CTO Blade.
NOTE:
NOTE:NOTE:
NOTE: This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE:
NOTE:NOTE:
NOTE: FIO indicates that this option is only available as a Factory Installable Option.
Step 1: Base Server Blade Configuration
Step 1: Base Server Blade ConfigurationStep 1: Base Server Blade Configuration
Step 1: Base Server Blade Configuration
Models
ModelsModels
Models HP ProLiant BL25p G2 CTO Blade 404839-B21
Configurable Model ships with:
Configurable Model ships with:Configurable Model ships with:
Configurable Model ships with:
Two (2) embedded NC373i Multifunction Gigabit Network Adapters plus one (1)
additional 10/100 NIC dedicated to iLO 2 management
Integrated Smart Array E200i controller
NOTE:
NOTE:NOTE:
NOTE: Controller cache module selection is required. Select either the standard 64
MB cache module or the optional 128 MB battery-backed write cache (BBWC)
module in step 2 below.
Two small form factor (SFF) SAS or SATA hot plug hard drive bays
Integrated Lights-Out 2 Standard Blade Edition
Step 2: Choose Required Options (one of the following from each list unless otherwise noted)
Step 2: Choose Required Options (one of the following from each list unless otherwise noted)Step 2: Choose Required Options (one of the following from each list unless otherwise noted)
Step 2: Choose Required Options (one of the following from each list unless otherwise noted)
Processors
ProcessorsProcessors
Processors AMD Opteron™ processor Model 2220 (2.8 GHz, 95W) Processor Option Kit, FIO
Base
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 438213-L21 and one 438213-B21.
438213-L21
AMD Opteron processor Model 2218 (2.6 GHz, 95W) Option Kit, FIO Base
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 409380-L21 and one 409380-B21.
409380-L21
AMD Opteron processor Model 2216 (2.4 GHz, 95W) Option Kit, FIO Base
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 409381-L21 and one 409381-B21.
409381-L21
AMD Opteron processor Model 2210 (1.8 GHz, 95W), Option Kit, FIO Base
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 415619-L21 and one 415619-B21.
415619-L21
Low Power AMD Opteron processor Model 2216 HE (2.4 GHz, 68W) Option Kit,
FIO Base
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 415620-L21 and one 415620-B21.
415620-L21
Low Power AMD Opteron processor Model 2214 HE (2.2 GHz, 68W) Option Kit,
FIO Base
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 409383-L21 and one 409383-B21.
409383-L21
Low Power AMD Opteron processor Model 2212 HE (2.0 GHz, 68W) Option Kit,
FIO Base
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 415621-L21 and one 415621-B21.
415621-L21
Low Power AMD Opteron processor Model 2210 HE (1.8 GHz, 68W) Option Kit,
FIO Base
NOTE:
NOTE:NOTE:
NOTE: If 2 processors are desired, select one 432811-L21 and one 432811-B21.
432811-L21
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Configuration Information Factory Integrated Models
DA - 12569 Canada — Version 10 — December 14, 2007 Page 12

Memory
MemoryMemory
Memory HP 1GB REG PC2-5300 2x512MB 1RANK Kit 408850-B21
HP 2GB REG PC2-5300 2x1GB 1RANK Kit 408851-B21
HP 4GB REG PC2-5300 2x2GB 2RANK Kit 408853-B21
HP 8GB REG PC2-5300 2x4GB 2RANK Kit 408854-B21
NOTE:
NOTE:NOTE:
NOTE: Must be installed in pairs. For additional memory configuration guidelines,
see "Memory" section of this HP BL25p G2 QuickSpecs.
Communications
CommunicationsCommunications
Communications 64 MB Cache - FIO Only 405102-B21
128MB Battery-Backed Write Cache with Battery Housing
NOTE:
NOTE:NOTE:
NOTE: Supports the Smart Array E200i Controller.
346914-B21
Step 3: Choose Additional Options for Factory Integration
Step 3: Choose Additional Options for Factory IntegrationStep 3: Choose Additional Options for Factory Integration
Step 3: Choose Additional Options for Factory Integration
NOTE:
NOTE:NOTE:
NOTE: For additional options, please refer to the "options" section below. For server blade enclosures, interconnect options, and
power subsystem options; please see the following QuickSpecs:
HP BladeSystem p-Class Infrastructure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12330_na/12330_na.HTML
and HP BladeSystem p-Class Interconnect Components QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12331_na/12331_na.HTML
And/or refer to the "Options" section below.
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Configuration Information Factory Integrated Models
DA - 12569 Canada — Version 10 — December 14, 2007 Page 13

Communications
CommunicationsCommunications
Communications HP NC320m PCI Express Dual Port Gigabit server adapter for HP BladeSystem 405095-B21
Or upgrade to:
Or upgrade to:Or upgrade to:
Or upgrade to:
HP NC374m PCI Express Dual Port Multifunction Gigabit server adapter for HP
BladeSystem
405094-B21
NOTE:
NOTE:NOTE:
NOTE: There are two mezzanine adapter card connectors on the HP BL25p G2
motherboard. There is a dedicated networking connector which supports one (1)
optional Ethernet NIC mezzanine adapter card, either the HP NC320m PCI Express
Dual Port Gigabit server adapter or the HP NC374m PCI Express Dual Port
Multifunction Gigabit server adapter. The other connector(s) is dedicated for the
optional, fibre channel mezzanine card adapter.
Fibre Channel
Fibre ChannelFibre Channel
Fibre Channel
Adapters
AdaptersAdapters
Adapters
HP QLogic-based dual port Fibre Channel Adapter
NOTE:
NOTE:NOTE:
NOTE: Includes two small form factor pluggable transceivers with LC connectors for
installation into the Patch Panel 2, CGESM or GbE2 Interconnect Switch (with the
Storage Connectivity Kit.)
361426-B21
HP Emulex-based dual port Fibre Channel Adapter for p-Class BladeSystem
NOTE:
NOTE:NOTE:
NOTE: SFPs for use with pass through SAN switches not included with the Emulex-
based Fibre Channel Adapter. If SFPs are required, please order the SFP option kit
(P/N 397577-B21) which includes 2-2Gb SFPs per option kit.
394757-B21
HP 2-2Gb SFP for Fibre Channel pass through kit
NOTE:
NOTE:NOTE:
NOTE: Must select if SFP for use with pass through SAN switches is required when
ordering Emulex based Fibre Channel Mezzanine card for HP p-Class BladeSystem
(P/N 394757-B21).
397577-B21
HP Insight Control and
HP Insight Control andHP Insight Control and
HP Insight Control and
ProLiant Essentials
ProLiant EssentialsProLiant Essentials
ProLiant Essentials
Offerings
OfferingsOfferings
Offerings
Insight Control Environment for BladeSystem
Insight Control Environment for BladeSystemInsight Control Environment for BladeSystem
Insight Control Environment for BladeSystem
HP Insight Control Environment for BladeSystem, No Media 1-Server License including
1 year of 24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: Contains 1 license for each of RDP, PMP, VPM, IPM and iLO Select. Includes
one year of 24 x 7 HP Software Technical Support and Update Service.
NOTE:
NOTE:NOTE:
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.HTML
453484-B21
ProLiant Essentials Value Packs
ProLiant Essentials Value PacksProLiant Essentials Value Packs
ProLiant Essentials Value Packs
NOTE
NOTENOTE
NOTE : Electronic licensing options are available for Insight Control suites and select
ProLiant Essentials software products. Please see the appropriate Insight Control and
ProLiant Essentials QuickSpecs for additional information.
Rapid Deployment Pack
Rapid Deployment PackRapid Deployment Pack
Rapid Deployment Pack
ProLiant Essentials Rapid Deployment Pack No Media 1-Server License including 1
year of 24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: This license allows 1 server to be deployed and managed via RDP. Customer
will receive a printed license entitlement certificate via physical shipment. The license
entitlement certificate must be redeemed online or via fax in order to obtain the
license activation key(s). Includes one year of 24 x 7 HP Software Technical Support
and Update Service.
452151-B21
ProLiant Essentials BL p-Class Server Blade Enclosure with Enhanced Backplane
Components and RDP Software Option Kit - 8 server
NOTE:
NOTE:NOTE:
NOTE: This license allows 8 servers to be deployed and managed. Only available
with the purchase of ProLiant BL p-Class server blade enclosure
(Blade Enclosure QS only)
281404-B22
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Options
DA - 12569 Canada — Version 10 — December 14, 2007 Page 14

NOTE:
NOTE:NOTE:
NOTE: For additional ProLiant Essentials Rapid Deployment Pack License Kits please
see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11053_div/11053_div.HTML
Server Migration Pack - Universal Edition
Server Migration Pack - Universal EditionServer Migration Pack - Universal Edition
Server Migration Pack - Universal Edition
HP Server Migration Pack - Universal Edition, No Media, Physical / Virtual to ProLiant
Single Migration License, including 1 year of 24x7 Technical Support
NOTE:
NOTE:NOTE:
NOTE: This license allows 1 physical to ProLiant or virtual to ProLiant migration.
Customer will receive a printed license entitlement certificate and documentation via
physical shipment. The license entitlement certificate must be redeemed online or via
fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP
Software Technical Support Service
460750-B21
HP Server Migration Pack - Universal Edition, No Media, Physical / Virtual to Virtual
Single Migration License, including 1 year of 24x7 Technical Support
NOTE:
NOTE:NOTE:
NOTE: This license allows 1 physical to virtual or virtual to virtual migration.
Customer will receive a printed license entitlement certificate and documentation via
physical shipment. The license entitlement certificate must be redeemed online or via
fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP
Software Technical Support Service.
460753-B21
HP Server Migration Pack - Universal Edition, No Media, 1-Year Unlimited Migration
License, including 1 year of 24x7 Technical Support
NOTE:
NOTE:NOTE:
NOTE: This license allows unlimited migrations (physical to ProLiant, physical to
virtual, virtual to virtual, and virtual to ProLiant) for one year. Customer will receive a
printed license entitlement certificate and documentation via physical shipment. The
license entitlement certificate must be redeemed online or via fax in order to obtain
the license activation key(s). Includes one year of 24 x 7 HP Software Technical
Support Service
460756-B21
NOTE:
NOTE:NOTE:
NOTE: For additional Server Migration Pack - Universal Edition License Kits please
see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12855_div/12855_div.HTML
Virtual Machine Management Pack
Virtual Machine Management PackVirtual Machine Management Pack
Virtual Machine Management Pack
ProLiant Essentials Virtual Machine Management Pack, No Media, 1-Server License,
including 1 year of 24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: Customer will receive a printed license entitlement certificate via physical
shipment. The license entitlement certificate must be redeemed online or via fax in
order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software
Technical Support and Update Service..
452153-B21
NOTE:
NOTE:NOTE:
NOTE: For additional ProLiant Virtual Machine Management Pack License Kits please
see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12328_div/12328_div.HTML
NOTE:
NOTE:NOTE:
NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials
Value Packs. Refer to http://www.hp.com/servers/proliantessentials or the various
ProLiant Essentials Value Pack product QuickSpecs for more information.
NOTE:
NOTE:NOTE:
NOTE: For more information regarding ProLiant Essentials Software, please see the
following URL: http://www.hp.com/servers/proliantessentials .
Remote Management
Remote ManagementRemote Management
Remote Management
NOTE:
NOTE:NOTE:
NOTE: Electronic licensing options are available for Insight Control suites and select
ProLiant Essentials software products. Please see the appropriate Insight Control and
ProLiant Essentials QuickSpecs for additional information.
ProLiant Essentials Integrated Lights-Out Select Pack
ProLiant Essentials Integrated Lights-Out Select PackProLiant Essentials Integrated Lights-Out Select Pack
ProLiant Essentials Integrated Lights-Out Select Pack
ProLiant Essentials Integrated Lights-Out Select Pack, No Media, 1-Server License 452158-B21
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Options
DA - 12569 Canada — Version 10 — December 14, 2007 Page 15

Featuring:
Featuring:Featuring:
Featuring: sophisticated remote control and security features for HP BladeSystem
servers and ProLiant ML/DL servers in text console environments.
NOTE:
NOTE:NOTE:
NOTE: For additional ProLiant Essentials Integrated Lights-Out Packs please see the
QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12362_div/12362_div.HTML
HP Insight Control Linux
HP Insight Control LinuxHP Insight Control Linux
HP Insight Control Linux
Edition for HP
Edition for HPEdition for HP
Edition for HP
BladeSystem
BladeSystemBladeSystem
BladeSystem
HP Insight Control Linux Edition - MEDIA KIT
NOTE:
NOTE:NOTE:
NOTE: This optional Media pack CD contains the ISO image for the HP Insight
Control Linux Edition management appliance (see support servers below under
"Management appliance (host) supported servers"). Servers must be acquired
separately. For information on HP ProLiant Servers please visit:
http://h18000.www1.hp.com/products/quickspecs/canada/11070.html
NOTE:
NOTE:NOTE:
NOTE: This Media pack is optional because the latest ISO image and latest updates
may be downloaded at no cost from: http://www.hp.com/go/controltower (click on
Download button from this page).
412956-B22
HP Insight Control Linux Edition 1.6 -No Media, 1-Server License, including 1 year of
24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: This license allows one (1) server blade to be deployed and managed via HP
Insight Control Linux Edition.
452155-B21
HP Insight Control Linux Edition 1.6,No Media, 8-Server License, including 1 year of
24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: This license allows eight (8) server blades to be deployed and managed via
HP Insight Control Linux Edition.
452156-B21
HP Insight Control Linux Edition 1.6, No Media, Flexible-Quantity License, including 1
year of 24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: For use with multiple servers (minimum of 5). This part number allows you to
specify the license quantity. When ordering this part number, the quantity ordered will
be the number of licenses embedded in a single activation key. A single kit containing
that key is then delivered to you.
452157-B21
Processor
ProcessorProcessor
Processor AMD Opteron™ processor Model 2220 (2.8 GHz, 95W) Processor Option Kit 438213-B21
AMD Opteron processor Model 2218 (2.6 GHz, 95W) Option Kit 409380-B21
AMD Opteron processor Model 2216 (2.4 GHz, 95W) Option Kit 409381-B21
AMD Opteron processor Model 2210 (1.8 GHz, 95W), Option Kit 415619-B21
Low Power AMD Opteron processor Model 2216 HE (2.4 GHz, 68W) , Option Kit 415620-B21
Low Power AMD Opteron processor Model 2214 HE (2.2 GHz, 68W), Option Kit 409383-B21
Low Power AMD Opteron processor Model 2212 HE (2.0 GHz, 68W), Option Kit 415621-B21
Low Power AMD Opteron processor Model 2210 HE (1.8 GHz, 68W), Option Kit 432811-B21
NOTE:
NOTE:NOTE:
NOTE: AMD Opteron 2000 Series processors are 64-bit, dual-core, and support
AMD Virtualization™ and DDR2 memory technology. AMD Opteron 2000 Series
processors are connected through 1 GHz HyperTransport™ links.
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Options
DA - 12569 Canada — Version 10 — December 14, 2007 Page 16

Memory
MemoryMemory
Memory
(SDRAM DIMMs)
HP 1GB REG PC2-5300 2x512MB 1RANK Kit 408850-B21
HP 2GB REG PC2-5300 2x1GB 1RANK Kit 408851-B21
HP 4GB REG PC2-5300 2x2GB 2RANK Kit 408853-B21
HP 8GB REG PC2-5300 2x4GB 2RANK Kit 408854-B21
NOTE:
NOTE:NOTE:
NOTE: Must be installed in pairs. For additional memory configuration guidelines,
see "Memory" section of this HP BL25p G2 QuickSpecs.
Hard Drives
Hard DrivesHard Drives
Hard Drives Serial Attached SCSI (SAS) SFF Hot Plug
Serial Attached SCSI (SAS) SFF Hot PlugSerial Attached SCSI (SAS) SFF Hot Plug
Serial Attached SCSI (SAS) SFF Hot Plug
HP 72GB 3G SAS 15k SFF DP HDD 418371-B21
HP 72GB 3G SAS 15K SFF SP HDD 431935-B21
HP 36GB 3G SAS 15K SFF DP HDD 418369-B21
HP 36GB 3G SAS 15K SFF SP HDD 431933-B21
HP 146GB 3G SAS 10K SFF DP HDD 418367-B21
HP 146GB 3G SAS 10K SFF HDD 431958-B21
HP 72GB 3G SAS 10K SFF DP HDD 384842-B21
HP 72GB 3G SAS 10K SFF SP HDD 375861-B21
HP 36GB 3G SAS 10K SFF SP HDD 375859-B21
NOTE:
NOTE:NOTE:
NOTE: SAS drives have a 3 year warranty.
NOTE:
NOTE:NOTE:
NOTE: Please see the SAS Hard Drive QuickSpecs for Technical Specifications such
as capacity, height, width, interface, transfer rate, seek time, physical configuration,
and operating temperature:
http://h18000.www1.hp.com/products/quickspecs/12244_na/12244_na.HTML
Serial-ATA (SATA) SFF Hot Plug
Serial-ATA (SATA) SFF Hot PlugSerial-ATA (SATA) SFF Hot Plug
Serial-ATA (SATA) SFF Hot Plug
HP 120GB 1.5G SATA 5.4K SFF HDD 431786-B21
HP 60GB 1.5G SATA 5.4K SFF HDD 379306-B21
NOTE:
NOTE:NOTE:
NOTE: SATA drives have a 1 year warranty. Please see the SATA Hard Drive
QuickSpecs for Technical Specifications such as capacity, height, width, interface,
transfer rate, seek time, physical configuration, and operating temperature:
http://h18000.www1.hp.com/products/quickspecs/11940_na/11940_na.HTML
Controller Cache
Controller CacheController Cache
Controller Cache 128 MB Battery-Backed Cache Enabler
NOTE:
NOTE:NOTE:
NOTE: Supports the Smart Array E200i Controller.
346914-B21
HP BladeSystem p-Class
HP BladeSystem p-ClassHP BladeSystem p-Class
HP BladeSystem p-Class
Other Options
Other OptionsOther Options
Other Options
HP BladeSystem p-Class Diagnostic Station
NOTE:
NOTE:NOTE:
NOTE: The Diagnostic Station allows access to the HP ProLiant p-Class server blades
and the BL p-Class interconnect switch outside of the server blade enclosure. The
option provides power and a data interface so that "offline" upgrade and diagnostic
functions may be performed.
230743-B21
HP StorageWorks
HP StorageWorksHP StorageWorks
HP StorageWorks
Modular Smart Array
Modular Smart ArrayModular Smart Array
Modular Smart Array
1500 cs
1500 cs1500 cs
1500 cs
HP StorageWorks Modular Smart Array 1500 AA986A
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks Modular Smart Array 1500 cs QuickSpecs for
additional options and configuration information at:
http://www.hp.com/go/MSA1500cs
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Options
DA - 12569 Canada — Version 10 — December 14, 2007 Page 17

HP StorageWorks
HP StorageWorksHP StorageWorks
HP StorageWorks
Options
OptionsOptions
Options
HP StorageWorks Fibre Channel Mezzanine Host Bus Adapter 394588-B21
NOTE:
NOTE:NOTE:
NOTE: Support HP ProLiant BL25p/45p Server Blades
Cluster Options
Cluster OptionsCluster Options
Cluster Options ProLiant Cluster Starter Kit 364023-B22
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the ProLiant Cluster Starter Kit please see
the following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11935_na/11935_na.html
HP HA/F200 for Entry SAN Cluster 364026-B22
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the ProLiant Cluster for Entry Level SAN
please see the following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11932_na/11932_na.html
ProLiant Cluster HA/F500 for the Enterprise SAN 364024-B21
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the ProLiant Cluster HA/F500 for
Enterprise SAN please see the following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11933_na/11933_na.html
NOTE:
NOTE:NOTE:
NOTE: For configuration/certification options for the HP Parallel Database Cluster for
Oracle RAC please go to: http://www.hp.com/solutions/highavailability/oracle
HP Serviceguard for Linux ProLiant Cluster, A.11.18 (2 license version - Red Hat EL
4&5, SUSE SLES10)
305199-B27
HP Serviceguard for Linux, A.11.18 (single license version - Red Hat EL 4&5, SUSE
SLES10)
307754-B27
HP Serviceguard for Linux and Red Hat Global File System - 1 year subscription T2798AA#001
HP Serviceguard for Linux and Red Hat Global File System - 3 years subscription T2798AA#003
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the HP Serviceguard for Linux License,
please see the following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11518_na/11518_na.html
USB Options
USB OptionsUSB Options
USB Options HP USB 2-Button Optical Mouse (Carbonite) DC172B
HP USB 04 Standard Keyboard DT528A#ABA
USB 2.0 4-port HUB DG954A
HP 1GB USB 2.0 Floppy Drive Key 442085-B21
HP 256MB USB 2.0 Floppy Drive Key 442084-B21
External USB 2.0 Multi-Bay II Cradle PA509A
Multibay II 9.5mm DVD Drive PA849A
HP Rack 5000 Series
HP Rack 5000 SeriesHP Rack 5000 Series
HP Rack 5000 Series
(Graphite Metallic)
HP 5642 Rack - Unassembled 358254-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the HP Rack 5642 QuickSpecs for additional part numbers and
Technical Specifications such as height, width, depth, weight, and color:
http://h18000.www1.hp.com/products/quickspecs/12074_na/12074_na.HTML
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding Rack Cabinets, please see the following
URL: http://www.hp.com/go/rackandpower .
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Options
DA - 12569 Canada — Version 10 — December 14, 2007 Page 18

HP Rack 10000 G2
HP Rack 10000 G2HP Rack 10000 G2
HP Rack 10000 G2
Series
SeriesSeries
Series (Graphite Metallic)
10647 G2 (47U) Rack Cabinet - Pallet AF031A
10642 G2 (42U) Rack Cabinet - Pallet AF001A
10642 G2 (42U) Rack Cabinet - Shock Pallet AF002A
10642 G2 (42U) Rack Cabinet - Crated AF003A
10642 G2 (42U) Rack Cabinet, with Extension - Shock Pallet AF004A
10636 G2 (36U) Rack Cabinet - Shock Pallet AF011A
10636 G2 (36U) Rack Cabinet - Crated AF012A
10636 G2 (36U) Rack Cabinet, with Extension - Shock Pallet AF013A
10636 G2 (36U) Rack Cabinet, without door - Shock Pallet AF014A
10622 G2 (22U) Rack Cabinet - Pallet AF021A
10622 G2 (22U) Rack Cabinet - Shock Pallet AF022A
10842 G2 (42U) 800mm Wide Rack Cabinet - Pallet AF041A
10842 G2 (42U) 800mm Wide Rack Cabinet - Shock Pallet AF042A
NOTE:
NOTE:NOTE:
NOTE: Please see the Rack 10000 G2 QuickSpecs for additional part numbers and
Technical Specifications such as height, width, depth, weight, and color:
http://h18000.www1.hp.com/products/quickspecs/12402_na/12402_na.HTML
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding Rack Cabinets, please see the following
URL: http://www.hp.com/go/rackandpower .
HP Rack 10000 Series
HP Rack 10000 SeriesHP Rack 10000 Series
HP Rack 10000 Series
(Graphite Metallic)
HP S10614 (14U) Rack Cabinet - Shock Pallet 292302-B22
NOTE:
NOTE:NOTE:
NOTE: Server Blade Enclosures must be field integrated into the 10842 racks. Factory
integration of Server Blade Enclosures into the 10842 is not supported.
HP 10647 (47U) Rack Cabinet - Shock Pallet 245160-B23
HP 10622 (22U) Rack Cabinet - Crated 245163-B23
NOTE:
NOTE:NOTE:
NOTE: xxxxxx-B22 (shock pallet) used to ship racks with equipment installed (by
custom systems, VARs and Channels). xxxxxx-B23 (crated) used for air shipments of
empty racks.
NOTE:
NOTE:NOTE:
NOTE: It is mandatory to use a shock pallet in order to ship racks with equipment
installed.
NOTE:
NOTE:NOTE:
NOTE: Please see the Rack 10000 QuickSpecs for additional part number and
Technical Specifications such as height, width, depth, weight, and color:
http://h18000.www1.hp.com/products/quickspecs/10995_na/10995_na.HTML
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding Rack Cabinets, please see the following
URL: http://www.hp.com/go/rackandpower .
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Options
DA - 12569 Canada — Version 10 — December 14, 2007 Page 19

Monitors and Keyboards
Monitors and KeyboardsMonitors and Keyboards
Monitors and Keyboards TFT7210R Rack Mounted 17" Monitor 348373-B21
TFT7600 Rackmount Keyboard Monitor AG052A
1U Rackmount Keyboard with USB AG072A
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding Rack Options, please see the following
URL: http://www.hp.com/go/rackandpower .
HP KVM Switch Options
HP KVM Switch OptionsHP KVM Switch Options
HP KVM Switch Options Server Console Switch (KVM), 0 x 1 x 8 port 336044-B21
Server Console Switch (KVM), 0 x 2 x 16 port 336045-B21
PS/2 Interface Adapter, 1 pack 262588-B21
PS/2 Interface Adapter, 8 pack 262587-B21
USB Interface Adapter, 1 pack 336047-B21
Serial Interface adapter - 1 Pack with power supply 373035-B21
BladeSystem p-Class KVM Interface Adapter AF100A
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding KVM switches, Serial Console servers,
rack mount monitors, keyboards and all related options please see the following URL:
http://www.hp.com/go/kvm
HP Serial Console Server
HP Serial Console ServerHP Serial Console Server
HP Serial Console Server
Options
OptionsOptions
Options
HP 16 Port Serial Console Server AF101A
HP 48 Port Serial Console Server AF102A
Serial Adapter, RJ45-DB9 DCE Female, 1 Pack AF103A
Serial Adapter, RJ45-DB9 DCE Female, 8 Pack AF110A
NOTE:
NOTE:NOTE:
NOTE: Cat5e cables are required to connect Serial Adapters to Serial Console
Servers. Additional Serial Adapters and Cat5e cables can be found at the following
URL: http://www.hp.com/go/kvm .
Service and Support
Service and SupportService and Support
Service and Support
Offerings
OfferingsOfferings
Offerings (HP Care Pack
Services)
NOTE:
NOTE:NOTE:
NOTE: The HP Care Pack service part numbers below for HP BladeSystem p-Class
server blades, cover the server blade and all HP branded hardware options qualified
for the server, purchased at the same time or afterwards, internal to the server.
Hardware Services On-site Service
Hardware Services On-site ServiceHardware Services On-site Service
Hardware Services On-site Service
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic UD187E
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic UD188E
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,
Electronic
UD189E
NOTE:
NOTE:NOTE:
NOTE: The HP Care Pack service part numbers below for HP BladeSystem p-Class
server blade enclosure covers the enclosure including patch panels, HP supported
Ethernet interconnects, power enclosure with power supplies and power distribution.
Hardware Services On-site Service
Hardware Services On-site ServiceHardware Services On-site Service
Hardware Services On-site Service
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic HC031E
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic HC032E
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,
Electronic
HC033E
NOTE:
NOTE:NOTE:
NOTE: The HP Care Pack service part numbers below covers the HP BladeSystem
Brocade and McData SAN Switches.
Hardware Services On-site Service
Hardware Services On-site ServiceHardware Services On-site Service
Hardware Services On-site Service
QuickSpecs
HP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server BladeHP ProLiant BL25p Generation G2 (G2) Server Blade
HP ProLiant BL25p Generation G2 (G2) Server Blade
Options
DA - 12569 Canada — Version 10 — December 14, 2007 Page 20
