Models SP-DVI-2A and SP-DVI-4A
2 & 4 Port DVI Video Splitter/Extender
December 8, 2005
SP-DVI-2A/4A User’s Manual
H
Ha al ll l R Re es se ea ar rc ch h T Te ec ch hn no ol lo og gi ie es s, , I In nc c. .
UMA1064 Rev. n/c

SW
-
DVI
-
2A/4A User's Manual
2
Trademarks Used In this Manual
Hall Research, HRT, and (logo) are trademarks of Hall Research
Technologies, Inc. Any other trademarks mentioned in this manual are
acknowledged to be the property of the trademark owners.
Federal Communications Commission Statement
This equipment generates, uses and radiates radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. It has been tested and found to comply
with the limits for a Class A computing device, pursuant to Part 15 of the FCC
rules. Harmful interference when operated in a commercial environment.
Operation of this equipment in a residential area may cause interference, in
which case the user, at his own expense, will be required to take whatever
measures are necessary to correct the interference.
European Union Declaration of Conformity
This product has been tested and shown to comply with the
requirements of the European EMC directive 89/336/EEC
1.0 General
Thank you for purchasing Hall Research Technologies’ DVI Video
Splitter/Extender. The Splitters allow routing of a single DVI equipped device
(such as PC) to multiple DVI displays (such as plasma or LCD screens). The
Splitters support single-link, DVI-I (integrated Analog and/or Digital) video
signals at resolutions of up to 1600x1200. The DVI Splitters feature front panel
LED indicator for power on state, plus they can be used to extend the DVI
output to 10 meters (33 ft).
2.0 Features
•Clear & sharp image at resolution up to 1600x1200 (including 1080i).
•Supports both digital and analog DVI signals (DVI-I), allowing you to
connect a DVI-I equipped PC to monitors that have DVI-I or legacy
monitors with VGA inputs only (In this case HD15 to DVI cable will be
necessary)
•Can be cascaded (2-levels deep) for more outputs
•Installs in minutes
•Compliant with the specification of DVI 1.0
•1U rack design for 4-channel version (Model SP-DVI-4A)

2 and 4 Port DVI Switch
3
3.0 Installation
1. Your package includes the Splitter box, a power supply and this Manual (the
4 port Splitter also includes rack-mount kit). You need to purchase an input
cable for connection to your video source and possible output extension
cables to go to your monitors. Hall Research sells high quality DVI cables
and adapters at various lengths.
2. Make sure the PC, the Splitter, and the monitors are all turned off
3. Plug the monitor’s cables into the DVI OUT ports of the Splitter (Note that
at least one monitor needs to be connected to the output 1 of the Splitter)
4. Plug a male-to-male extension cable from PC’s DVI port to the Splitter
5. Plug the supplied power adapter to the unit (The green LED on the front
panel turns on)
6. Turn on the monitors.
7. Turn on the PC.
4.0 Cascade Operation
For more outputs you can connect output #1 of the Splitter to the input of a Slave
Splitter. It is recommended to keep cascading to only 2-levels deep.
5.0 Troubleshooting
Cable Length Limitations
The splitter can accept up to 5 meters of cable on its input and 10 meters on its
output for a total of 15 meters (50 feet total). At long distances if you start to
experience video degradation, you should turn the refresh rate and/or resolution
of the video signal lower.
HDCP (Content Protection) Problems in Home-theatre A/V applications
The Splitter is designed to work with PC’s with DVI outputs. It may or may not
work fine with A/V equipment that has integrated DVI connectors. Hall

SW
-
DVI
-
2A/4A User's Manual
4
Research does not guarantee compatibility with HDCP encoded video sources on
the market. Please contact HRT for information on HDMI (new standard for
home-theatre digital A/V connections) capable equipment.
If you are convinced that the unit is defective …
Do not open or try to repair the unit yourself. There is no customer repairable
items in the unit and you will void your warranty by doing so. Contact HRT
instead.
5.1 Contacting Hall Research and Shipping/Packaging
Contact HRT Support at 714-641-6607 or via email or web. Before you do,
make a record of the history of the problem. We will be able to provide more
efficient and accurate assistance if you have a complete description. If you need
to ship your converter for repair, make sure to get a Return Material
Authorization (RMA) number first.
6.0 Specifications
Standards DVI-I Single Link, Compliant with DDWG DVI 1.0 Standard
Resolutions PC resolutions up to 1600x1200 @ 60 Hz & HDTV to 1080i
Temperature Operating: 32 to 122°F (0 to 50°C);
Storage: –40 to +185°F (–40 to +85°C)
Enclosure Steel
MTBF 90,000 hours (calculated estimate)
Power From utility-power (mains) outlet, through included external
power supply. Output Voltage: 7.5 to 9v DC Center-Positive
1500 ma maximum
Size (wxdxh) 2-Port: 7.9" x 3" x 1.65" 4-Port: 10.6" x 4.1" x 1.65"
Weight 2-Port: 1.4 pounds 4-Port: 2.2 pounds
© Copyright 2005. Hall Research Technologies, Inc.
All rights reserved
