HS HSM 600 User manual

INSTRUCTION FOR USE
HSM 600
INSTRUMENT TABLE
Warning!
Before using this product, read the instructions
carefully. This contains important information re-
garding user safety.

IoU HSM600-V21-00e.doc 1/22 11.06.2019
1 Introduction
With your decision to purchase an HSM 600 instrument table, you have placed a high degree of trust
in us. We thank you for that. You have chosen a well-engineered product and modern design.
Technical changes in the sense of further developments and product improvements are subject to
change without notice.
1.1 Purpose of use
The HSM 600 instrument table is designed for use in ophthalmic practices, eye clinics and practices of
optometrists and opticians as a carrier for ophthalmological examination equipment.
1.2 Areas of applications of the device
This device is intended for use in professional healthcare facilities such as medical practices and op-
tometrist and optician premises. It must not be operated in the vicinity of high-frequency surgical sys-
tems and within shielded rooms of ME systems for nuclear spin tomography. Portable radio frequency
devices such as mobile phones or other RF telephone accessories, including antennas, may affect the
function of medical devices. Such devices must always be at least 30 cm away from any part of the
instrument. Failure to observe this precaution may impair the proper functioning of the instrument.
Do not use in emergency- and operating rooms.
1.3 Contraindications
For examinations with this instrument table no absolute contraindications are known. Professional
judgment and caution are appropriate.

IoU HSM600-V21-00e.doc 2/22 11.06.2019
Content
1Introduction............................................................................................................................ 1
1.1 Purpose of use......................................................................................................................... 1
1.2 Areas of applications of the device.......................................................................................... 1
1.3 Contraindications ..................................................................................................................... 1
2Symbols.................................................................................................................................. 4
3General environmental conditions....................................................................................... 5
4Shipment................................................................................................................................. 5
4.1 Transport.................................................................................................................................. 5
4.2 Unpacking................................................................................................................................ 5
4.3 Installation of the devices!........................................................................................................ 6
4.4 Liability for function or damage................................................................................................ 6
5Device safety.......................................................................................................................... 6
6Overview instrument tables HSM 600.................................................................................. 7
7Assembly / Installation HSM 600.......................................................................................... 8
7.1 Connecting the lifting column................................................................................................... 8
7.2 Mounting the lifting column.................................................................................................... 10
7.3 Mounting base plate............................................................................................................... 11
7.4 Leveling HSM 600 Instrument table....................................................................................... 12
7.5 Octopus 600 instrument table (special version)..................................................................... 13
7.6 Installation of optional trays (PC tray or standard tray) ......................................................... 13
7.7 Screw sets.............................................................................................................................. 14
8Commissioning / Operation / Decommissioning.............................................................. 15
8.1 Commissioning HSM 600 ...................................................................................................... 15
8.2 Operation HSM 600 ............................................................................................................... 15
8.3 Transport of the HSM 600...................................................................................................... 16
8.3.1 Short distances ...................................................................................................................... 16
8.3.2 Longer distances.................................................................................................................... 16
8.4 Decommissioning HSM 600................................................................................................... 16
8.5 Technical data........................................................................................................................ 17
8.6 Dimensions / Weights ............................................................................................................ 17
9Maintenance / fuse replacement / cleaning / wipe disinfection ...................................... 18
9.1 Maintenance........................................................................................................................... 18
9.2 Fuse replacement .................................................................................................................. 18
9.3 Cleaning................................................................................................................................. 18
9.4 Wipe disinfection.................................................................................................................... 19
10 Legal regulations / classification / disposal / standards ................................................. 19
10.1 Legal regulations.................................................................................................................... 19
10.2Classification.......................................................................................................................... 19
10.3 Disposal ................................................................................................................................. 19
10.4 Standards............................................................................................................................... 19
11 Notes and declaration regarding electromagnetic compatibility (EMC) ........................ 20
11.1 General information ............................................................................................................... 20
11.2 Interfering emissions.............................................................................................................. 20
12 Classification........................................................................................................................ 20

IoU HSM600-V21-00e.doc 3/22 11.06.2019
Figures
Figure 1 Connection lifting column; disassembly metal cover........................................................... 8
Figure 2 Connecting lifting column; connect earthing cable, secure cable with cable tie. ................ 9
Figure 3 Connecting the lifting column; mounting the cable whip and the earthing cable. ............... 9
Figure 4 Connecting the lifting column; mounting the metal cover.................................................... 9
Figure 5 Connection column; connection power cable and mounting column................................ 10
Figure 6 Connection column; fixing the column with 8 screws........................................................ 10
Figure 7 Mounting the Base Plate; preparation............................................................................... 11
Figure 8 Mounting the base plate; inserting and tightening the 4 Screws....................................... 11
Figure 9 Mounting the base plate; wiring and securing with cable ties........................................... 12
Figure 10 Leveling HSM 600 Instrument table. ................................................................................. 12
Figure 11 Assembly Octopus 600 instrument table (special version) ............................................... 13
Figure 12 Mounting optional shelves................................................................................................ 13
Figure 13 Screws and cable ties........................................................................................................ 14
Figure 14 Fuse replacement; fuses F1 and F2.................................................................................. 18
Tables
Table 1 Symbols.............................................................................................................................. 4
Table 2 Environmental conditions ................................................................................................... 5
Table 3 Overview instrument tables HSM 600................................................................................ 7
Table 4 Technical data .................................................................................................................. 17
Table 5 Dimensions/Weight (without packaging and optional attachments)................................. 17
Table 6 Interference emissions (Standard table 1) ....................................................................... 20

IoU HSM600-V21-00e.doc 4/22 11.06.2019
2 Symbols
Follow instructions for use
Disconnect from the power before opening
Warning! Always follow the instructions.
Electrical appliances of protection class I,
protective earth,
CE Certificate of Conformity
Manufacturer
Year
Serial number
Reference
Application part of type B
Note Disposal
Warning! Electricity
Forbidden! In case of non-observance danger.
Important notes
Table 1 Symbols

IoU HSM600-V21-00e.doc 5/22 11.06.2019
3 General environmental conditions
Before using the instrument tables HSM 600 for the first time, please read the operating instructions.
The instrument table may only be operated in compliance with the instructions for use.
Transport
Temperature
from
-10 C°
to
+70 C°
Air pressure
from
500 hPa
to
1060 hPa
Humidity
from
10%
to
65 %
to
Storage
Temperature
from
-10 C°
to
+70 C°
Air pressure
from
500 hPa
to
1060 hPa
Humidity
from
10%
to
65 %
to
Use
Temperature
from
+10 C°
to
+35 C°
Air pressure
from
700 hPa
to
1060 hPa
Humidity
from
10%
to
65 %
Table 2 Environmental conditions
4 Shipment
4.1 Transport
Transport, lifting or shifting work
For all Transport, lifting or shifting work, all relevant safety complies with regulations.
This also means that only suitable and tested hoists may be used!
Uneven ground
Note that on an uneven floor or similar.
The goods must be secured professionally against slipping sideways!
Transport on EURO pallet
The table components are usually delivered on EURO pallets. Only suitable pallet trucks or
heavy-duty wheeled boards may be used to transport or move the pallets be used.
During transport and storage, the following general environmental conditions apply:
• Dry
• Frost free
• Dust-proof
• Corrosion resistant (for example saltwater)
4.2 Unpacking
Before unpacking the goods, check that the packaging shows traces of improper handling or damage.
If so, notify the carrier that delivered the goods to you.
Create a log of any damaged parts.
Leave the instrument tables or parts in the packaging for a few hours before unpacking
(Condensation). After unpacking the goods must be checked for damage. Defective instrument tables
or parts must be returned in appropriate packaging.

IoU HSM600-V21-00e.doc 6/22 11.06.2019
4.3 Installation of the devices!
Forbidden!
Never use electric instrument tables in hazardous areas where volatile solvents (alcohol,
petrol, etc.) and flammable anesthetics are used.
Warning!
The unit must be installed in such a way that it can be disconnected from the power supply at
any time.
The instrument table may not be set up and operated in damp rooms. Avoid dripping and splashing
water. Assembly and disassembly as well as repair, maintenance and repair work may only be carried
out by Haag Streit or by authorized technical service of Haag Streit sales partners.
If an external device is connected, must this be done in accordance with standard EN 60601-1.
Only original HS spare parts may be used.
4.4 Liability for function or damage
If the instrument table is changed or repaired by unauthorized persons or if improper maintenance is
carried out, the manufacturer is not liable. In addition, all warranty claims expire.
The product must be handled in accordance with the instructions for use. Improper handling may
result in damage to the product. This will void all warranty claims.
If a product damaged by improper handling continues to be used, this can lead to personal injury. The
manufacturer is not liable in this case.
5 Device safety
The assembly and installation of the instrument table is carried out exclusively by trained specialist
persons. The power cable must only be connected to a correctly installed power supply. This must be
installed in accordance with the VDE guidelines.
Risk of electric shock
In order to avoid the risk of electric shock, this device may only be connected to a
supply network with protective conductor.
The instrument table must be checked according to EN 62353 (IEC 62353) before
commissioning. In the event of damage from electrical cables, the instrument table must be
disconnected from the power and must secured against unintentional operation.
Power voltage
The power voltage on the nameplate must match the local voltage.
Other power voltages will damage the table.
Opening the table (column)
The instrument table must be disconnected from the power before opening by pulling the
power plug. (Put it into a de-energized state)
Be sure to check that there is no voltage before starting any further work.
Impairment of EMC
Operation of other electrical equipment in the immediate vicinity or stacked may adversely
affect EMC. The situation must be evaluated by the system designer.
The requirements of standards EN 60601-1 and EN 60601-1-2 must be observed.
External devices
If an external device is connected, this has to be done in consideration of the
standard EN 60601-1. The connection of further electrical devices to the internal multiple
socket leads to the installation of a ME system, which can result in a reduced degree of safety.
The requirements of EN 60601-1 must be complied with.
The user must report serious incidents relating to the product to the manufacturer and
the competent authority.

IoU HSM600-V21-00e.doc 7/22 11.06.2019
6 Overview instrument tables HSM 600
Table 3 Overview instrument tables HSM 600
BX900
7220613 230V
7220614 120V
7220615 230V LAN
7229616 120V LAN
SL LARGE
7220609 230V
7220610 120V
7220611 230V LAN
7220612 120V LAN
SL PS LED SMALL
7220601 230V
7220602 120V
7220603 230V LAN
7220604 120V LAN
SL RM 02 SMALL
7220605 230V
7220606 120V
7220607 230V LAN
7220608 120V LAN
OCTOPUS 600
7220625 230V
7220626 120V
7220627 230V LAN
7220628 120V LAN
OCTOPUS 900
7220621 230V
7220622 120V
7220623 230V LAN
7220624 120V LAN
LENSTAR 900
7220617 230V
7220618 120V
7220619 230V LAN
7220620 120V LAN

IoU HSM600-V21-00e.doc 8/22 11.06.2019
7 Assembly / Installation HSM 600
Connectors/Accessories
Check: the connecting parts of the accessories are tightened.
Danger! Instability can cause equipment to fall and be damaged.
Assembly, Maintenance
Instrument table may only be mounted, repaired or replaced by trained specialist personnel.
Improper installation can lead to hazards, electric shock or mechanical instability.
Device modifications
The instrument tables may not be altered without the permission of the manufacturer.
Only original spare parts may be used for repairs.
7.1 Connecting the lifting column
Check power voltage!
The lifting column is supplied in 230 V or 120 V with or without LAN cabling. Please compare
the power voltage with the existing voltage on the label.
Columns with LAN option
Columns with LAN option have an integrated LAN cable prefabricated with RJ45 socket in the
column below and RJ45 extender on the column above. LAN cables must be preassembled
according to 8connecting the lifting column, earthing cable.
Place the HSM 600 table-top with the back facing upwards. Make sure that the downward facing top is
on soft material (to avoid damage or scratches).
Figure 1 Connection lifting column; disassembly metal cover
Only remove the two screws (M6x16) on the side of the lifting column.
Slide the metal cover to the right. The cover can now be easily removed through the wide openings.
Note:
It is not necessary to remove complete the other 6 screws (3 each on the right and left side).
.
(M6x16)

IoU HSM600-V21-00e.doc 9/22 11.06.2019
Figure 2 Connecting lifting column; connect earthing cable, secure cable with cable tie.
Plug the green-yellow earthing cable into one of the two cable lugs of the device column (see arrow
Figure 2 Connecting lifting column; connect earthing cable, secure cable with cable tie). Then
secure the cable with a cable tie.
Figure 3 Connecting the lifting column; mounting the cable whip and the earthing cable.
Insert the cable and the ground cable into the cable duct.
Figure 4 Connecting the lifting column; mounting the metal cover.
2 x M6x16

IoU HSM600-V21-00e.doc 10/22 11.06.2019
7.2 Mounting the lifting column
The lifting column is fully retracted during transport. Connect the lifting column to the power supply.
Before inserting the screws, move the lifting column approx. 5 cm upwards.
Switch the lifting column ON (toggle switch "green" illuminated). Press the black rocker switch to raise
the lifting column. (Operation HSM 600, page15).
Figure 5 Connection column; connection power cable and mounting column.
Place the lifting column on the 8 predrilled holes (4 holes each on the right and left side).
Now insert the 8 screws:
4x M6x16 (on the front panel)
4x M6x25 incl. washer (at the rear of the column)
Note:
Fix the lifting column with the 8 screws.
Tighten the screws firmly!
Figure 6 Connection column; fixing the column with 8 screws.
Connect power cable
Drive up the
column 5 cm
4 x M6 x 16
4 x M6 x 25

IoU HSM600-V21-00e.doc 11/22 11.06.2019
7.3 Mounting base plate
Wheels are preinstalled at the factory (on the doctor's side there are wheels with brakes).
Note:
The stable base plate weighs 24 kg!
Two persons are required for safe installation.
Figure 7 Mounting the Base Plate; preparation.
Before further installation, please be within easy reach: 4 screws
(M6x45 incl. washer) and hexagon socket screwdriver.
Figure 8 Mounting the base plate; inserting and tightening the 4 Screws.
Inserting the 4 screws (M6x45 incl. washers)
Note!
Tighten all 4 screws firmly and check that they are properly tightened.
4x M6x45

IoU HSM600-V21-00e.doc 12/22 11.06.2019
Figure 9 Mounting the base plate; wiring and securing with cable ties.
Connect the appliance plug of the lifting column to a local power supply cable.
Insert the power connection cable into the cable holder and fix it with a cable tie.
Fix the green-yellow ground cable to the base plate.
(1x screw M4x10 with spring washer, washer and toothed washer are preassembled).
7.4 Leveling HSM 600 Instrument table
The HSM 600 tables are factory leveled and are supplied with the named washers and
mounted wheels on the base plates. The mounted wheels are secured with screw locking lac-
quer.
If the HSM 600 table plate is not in the scale (e.g. uneven floor), the se can be levelled using 6
washers Ø 8.4 mm. A maximum of 3 washers per wheel are permitted.
Note:
Before starting work, carefully place the HSM 600 instrument table on a thick foam base.
Figure 10 Leveling HSM 600 Instrument table.
A maximum of 3
washers per
wheel are per-
mitted.

IoU HSM600-V21-00e.doc 13/22 11.06.2019
7.5 Octopus 600 instrument table (special version)
Install the lifting column and base plate as described above.
Figure 11 Assembly Octopus 600 instrument table (special version)
Remove the metal cable cover.
Pass the cable whip through the opening of the table-top and reinstall the cable cover. (Tighten both
screws firmly)
7.6 Installation of optional trays (PC tray or standard tray)
Figure 12 Mounting optional shelves
Note!
A suitable set of screws is supplied with each shelf.
Insert the green-yellow earthing cable into the cable duct and plug the earthing cable into one of the
two cable lugs on the lifting column. Then tie the cable with a cable tie.
Insert the 4 screws M4x10 and tighten them firmly.
For double installation from PC storage and standard storage compartment, 4 additional screws
M4x10 (ISO 7380) incl. nuts and washers are included in the scope of delivery.
Earthing cable
Double installation
PC shelf (doctor side)
4x M4x10

IoU HSM600-V21-00e.doc 14/22 11.06.2019
7.7 Screw sets.
Figure 13 Screws and cable ties
Base bag
2 x cable ties
1x SCREW SET 1
1x SCREW SET 2
SCREW SET 1 (base plate)
4x screws M6x45 incl. 4 washers (DIN 912)
SCREW SET 2 (lifting column)
4x screws M6x16 (DIN 912); for control panel on device column
4x screws M6x25 incl. washers (DIN 912); for lifting column

IoU HSM600-V21-00e.doc 15/22 11.06.2019
8 Commissioning / Operation / Decommissioning
Attention! For load operation
Height adjustment of the instrument table Execute load operation for a maximum of 1 minute,
then pause for at least 9 minutes.
Attention! Operation
Operation only by qualified and trained personnel.
Training is the responsibility of the operator.
8.1 Commissioning HSM 600
If the instrument table HSM 600 is connected to the power, it is ready for operation.
WARNING! Risk to clamp!
Before changing the table height, make sure that the movement path is free of extremities
of the patient (e.g. legs) or of obstacles. If this is not done, there is a risk of clamping the
patient's thighs or other extremities or other things.
8.2 Operation HSM 600
The HSM 600 instrument table has an electromotive lifting column. The control panel is mounted at
the top of the table-top front (operator side). The height can be adjusted via the rocker switch (right). A
green illuminated toggle switch (left) is the "ON/OFF" switch.
Figure 13 Operating the HSM600 Rocker and toggle switch (operator side)
Switch
Table on-off
Switch
Table up-down

IoU HSM600-V21-00e.doc 16/22 11.06.2019
8.3 Transport of the HSM 600
Risk of damage to persons and table-top appliances
Before camouflage sports, all equipment on the table must be removed, as slipping and falling
can damage people and equipment on the table.
8.3.1 Short distances
Watch your step! Note cable length
Limited cable lengths can damage the cable or plug by pulling it. After transport to the desired
position, snap the brakes back into place.
Release the brakes on the 2 wheels and move the table to the desired position.
8.3.2 Longer distances
Watch your step! Note cable length
Limited cable lengths can damage the cable or plug by pulling it. After transport to the desired
position, engage the brakes again.
Place the table board in the lowest position and disconnect the power cable from the power supply.
Loosen the locking device on the doctor's side and roll to the desired position.
8.4 Decommissioning HSM 600
When the HSM 600 is taken out of operation, disconnect the instrument table from the power supply
by pulling the power plug.

IoU HSM600-V21-00e.doc 17/22 11.06.2019
8.5 Technical data
Electrics
230 V (see type label*)
input voltage
230 V 50/60 Hz / 900 VA
output voltage
230 V 50/60 Hz / 850 VA
120 V (see type label*)
input voltage
120 V 50/60 Hz / 750 VA
output voltage
120 V 50/60 Hz / 700 VA
Fuses:
230 V Version
2 x T4.0 AL /250V
120 V Version
2 x T6.3 AL / 250V
degree of protection
IP 20
protection class
I
Mechanics
wheels**
4
Weight load (kg)
50
stroke length
300 mm
lifting speed
15 mm/s
*The type label is located on the underside of the control panel (operator side).
** The HSM 600 instrument table for Octopus 600 has 4 adjustable feet (no wheels).
Table 4 Technical data
8.6 Dimensions / Weights
Type HSM 600 for Slit Lamp small
Tabletop dimension (mm)
860 x 440
Height (min/max in mm)
680 / 980
Weight (kg)
46
Type HSM 600 for Slit Lamp large
Tabletop dimension (mm)
1150 x 440
Height (min/max in mm)
680 / 980
Weight (kg)
49
Type HSM 600 for BX 900
Tabletop dimension (mm)
1150 x 440
Height (min/max in mm)
680 / 980
Weight (kg)
49
Type HSM 600 for Lenstar
Tabletop dimension (mm)
1150 x 440
Height (min/max in mm)
680 / 980
Weight (kg)
49
Type HSM 600 for Octopus 900
Tabletop dimension (mm)
1080 x 480
Height (min/max in mm)
700 / 1000
Weight (kg)
54
Type HSM 600 for Octopus 600
Tabletop dimension (mm)
560 x 640 mm
Height (min/max in mm)
625 / 925
Weight (kg)
32
Table 5 Dimensions/Weight (without packaging and optional attachments)
Note:
The HSM 600 instrument table does not come with a power cord.
To connect the HSM 600 instrument table to the local power supply, use only country-specific
power cables.

IoU HSM600-V21-00e.doc 18/22 11.06.2019
9 Maintenance / fuse replacement / cleaning / wipe disinfection
9.1 Maintenance
The HSM 600 instrument tables are virtually maintenance free and require minimal maintenance to
function to your complete satisfaction for as long as possible. However, we recommend that mainte-
nance be carried out by authorized service technicians every three years. HAAG STREIT or your local
sales partner will be happy to give you further information.
Repeat testing after repair from medical electrical devices according to DIN EN 62353 (IEC 62353) are
prescribed by HS DOMS GMBH every two years.
Observe the country-specific regulations.
9.2 Fuse replacement
Fuse replacement
Only fuses as described in the corresponding table under chapter "Technical data" may be
used.
The fuses F1 and F2 are located on the right side of the control panel below the tabletop. (Page 17)
Voltage 230 V = 2 x T4.0 AL / 250V
Voltage 120 V = 2 x T6.3 AL / 250V
Disconnect the power cord.
Unlock the fuse holder with a screwdriver and pull out the holder.
Replacing the fuse
Replace the fuse holder and lock it with the screwdriver.
Reconnect the power cable.
Figure 14 Fuse replacement; fuses F1 and F2.
9.3 Cleaning
Warning!
Avoid liquids. Do not use solvents, alcohol, corrosive or abrasive agents.
It is enough to wipe the HSM 600 instrument table with a soft, dry cloth.
The table can also be cleaned with a lint-free cloth moistened with a mild soap solution.

IoU HSM600-V21-00e.doc 19/22 11.06.2019
9.4 Wipe disinfection
The plastic-coated surfaces and the aluminium-anodised surface of the lifting column cladding are
suitable for wipe disinfection. From HS DOMS GMBH for wipe disinfection the following products are
released:
Cleaning work/wiping disinfection
No liquid may enter the instrument table or the operating element during cleaning work/wiping
disinfection. Always switch off the "On/Off" toggle switch (see page 15) before starting this
work. The switch lighting must not light up). Before switching on the lift table again, make sure
that it has dried out.
Meliseptol rapid - Rapid disinfectant Ref. 18564
Meliseptol Foam pure - Ref.19171
(Manufacturer: Braun Melsungen AG D-34209 Melsungen, www.bbraun.de
Incidin liguid Ref. 3011340
(Manufacturer: Ecolab Deutschland GmbH, Ecolab-Allee 1,40789 Monheim am Rhein
www.ecolab.com
Aseptix Sterimax Wipes Ref. SMXWI100
Aseptix Sterimax Spray Ref. SMX750
(Manufacturer: Aseptix BV 3632 AD Loenen aan de Vecht/Netherland www.aseptix.com
Bacillol 30 Foam Ref. 981307
Bacillol 30 Tissues Ref. 981312
(Manufacturer: BODE Chemie GmbH D-22525 Hamburg www.bode-chemie.com
10 Legal regulations / classification / disposal / standards
10.1 Legal regulations
The HSM 600 instrument tables are designed and manufactured according to the following standards
EN 60601-1, EN 60601-1-2 Production, inspection, assembly, maintenance and repair in accordance
with applicable EU regulations.
The EN 60601-1 standard must be observed when combining various medical and / or non-medical
electrical devices.
Conformity of the HSM 600 instrument table with Directive 93/42/EEC is confirmed by the CE marking.
A copy of the declaration of conformity and the EMC information (electromagnetic compatibility) can
be requested from HS DOMS GMBH.
The statutory accident prevention regulations must be observed.
10.2 Classification
EN 60601 Protection class I
CE Directive 92/42/EEC Class I
10.3 Disposal
Electrical and electronic equipment must be disposed of separately from household waste!
This appliance was put on the market after 13. 08. 2005. Disposal is carried out via the local collection
point or via your Hague Dispute Sales Partner.
10.4 Standards
EN 60601-1
EN 60601-1-2
