Huadean BWC-T1 User manual

BWC-T1
User manual

Content
1. Introduction................................................................................................................................... 1
2. Structure design.............................................................................................................................2
2.1 Front view............................................................................................................................. 2
2.2 Back view..............................................................................................................................3
3. Device operation............................................................................................................................ 4
3.1 Live view window.................................................................................................................4
3.2 Main menu.............................................................................................................................4
4. Device using....................................................................................................................................9

1
1. Introduction
BWC-T1 is a lightweight design body worn camera specifically designed for Law Enforcement.
The camera features real time HD video, 1080P recording, and a high resolution still image
capture visible on the LCD screen for instant playback; The rugged design is resilient to withstand
demanding work environments faced by law enforcement officers, corrections, military and
security detail.
Package Contents
＊Body worn camera
＊USB cable
＊USB poser adapter
＊CD with manual and software
＊Universal metal clip

2
2. Structure design
2.1 Front view
Item
Name
Description
1
Charge indicator
Solid red means camera is recharging, solid green means
camera recharged well.
2
IR light
Record clear image in HD in low light situations. 10 meters
visible.
3
Lighting light
Short press the power on/off button to enable the light for
auxiliary lighting.
4
REC Microphone
Capture the environment voice during the recording mode.
5
Menu button
Press the button to enter into the configure menu to modify
the parameters.
6
Playback button
Press the button to enter into the playback interface during
the live view mode, review video, image and audio files.
7
ON/OFF button
Press this button to start up camera or turn off camera.
8
Status indicator
Red blinking means video recording, yellow blinking means
audio recording, solid green means standby.
9
IR Sensor
The sensor will detect the brightness of the environment,
and then activate the IR light and switch to night vision
mode..
10
HDMI port
Connects to LCD screen to see the video output.
11
USB port
Connects to USB cable for charging or connection to PC.

3
2.2 Back view
item
Name
Description
12
Line hole
The hole to a line to mount the camera
13
Video REC button
Press this button to start the video recording
14
Audio REC button
Press the button to start the audio recording only.
15
Snapshot button
Press this button to start capture the snapshots, even
during video recording mode.
16
PTT button
Press to communication via connected walkie-talkie
17
Clip slot
Put the clip in to fix the clip
Speaker
For voice playback, and voice report.
Pogo pin
The interface for docking, walkie-talkie and external
battery connection.

4
3. Device operation
3.1 Live view window
The body worn camera LCD screen is a small monitor to display various camera information
and operation status.
Item
Name
Description
1
Recording resolution
The resolution that camera recording
2
Video recording icon
Yellow means recording
3
Snapshot icon
Yellow means snapshot success
4
Date/Time
The current date/time
5
The remain recording time
How long the storage can recording
6
Battery status
The current status of the battery
7
Storage size
The current size of the storage
8
Officer ID number
The officer ID of this camera
3.2 Main menu
In preview mode, press to enter into main menu interface, press / to select the
option menu, and then press to confirm the operation, and then press / to
select the sub-options, and then press to active the option.

5
Menu list:
1. Video resolution 2. Video quality 3. Video clip 4. Pre-recording 5.Post-recording
6. Photo pixel 7. Snapshot 8. Brightness 9. Screen off 10. Volume
11. Indicate sound 12. Key sound 13. Hourly report 14. Indicator light 15. White
light 16. IR mode 17. Auto shutdown 18. Motion detect 19. Start logo
20. Default setting 21. Video loop 22. Udisk mode 23. Security password
24. Language
Menu
Options
Video resolution
720P30, 848P30, 1 1080P30
Video quality
Low, Medium, High
Video clip
10min, 20min, 30min, Auto
Pre-recording
ON, OFF
Post-recording
OFF, 5sec, 10sec, 30sec, 1min ,2min, 5min, 10min
Photo pixel
5M, 8M, 10M, 12M, 16M, 21M, 32M
Snapshot
2 PCS, 3 PCS
Brightness
Low, Medium, High
Screen off
OFF, 30sec, 1min, 3min, 5min
Volume
0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
Indicator sound
Voice, Beep
Key sound
ON, OFF
Hourly report
ON, OFF
Indicator light
ON, OFF
White light
ON, OFF
IR mode
OFF, Manual, Auto
Auto shutdown
OFF, 10min, 20min, 30min, 60min
Motion detect
ON, OFF
Start logo
ON, OFF
Default setting
ON, OFF
Video loop
ON, OFF
Udisk mode
ON, OFF
Security password
ON, OFF
Language
English, 日本語, Español, русский
Motion detect
ON, OFF

6
1. Video resolution
The body worn camera offers five different recording resolutions. Resolution and frame rate
options feature a proper balance between video quality and maximizing amount of video stored.
Options
Display resolution
Images per second
720P30
1280*720
30
848P30
848*480
30
1080P30
1920*1080
30
2. Video quality
Select video quality based on the need of quality video recording. High means the best quality,
which will encoding with big bit rate.
3. Video clip
Video clip selection defines the length of each video segment, and this option only is used for
video recording, invalid for audio recording.
Sub-option: Auto, 10 minutes, 20 minutes, 30 minutes; auto means it will create a file in almost
2GB size, and the time is about one hour, depends the video resolution.
4. Pre-recording
Pre-recording saves an additional seconds of video before the video recording button is pressed,
and the additional seconds is about 30 seconds. After the option of pre-recording is enabled, the
camera can not snapshot, but the snapshot will work during the video recording.
For example, we set the value between setting the pre-recording and pressing the video recording
as X, if X <30s, the camera will save an additional video for X seconds before the video recording
button is pressed, if X>=30s, the camera will save an additional video for 30 seconds before the
video recording button is pressed.
5. Post-recording
Post-recording means how long the camera should continue to record after the video recording
button is pressed to stop recording.
6. Photo pixel
The photo pixel provides options for still image resolution.
7. Snapshot

7
In preview mode, Long press the snapshot button to shoot the selected number of pictures,
and you can set the option as 2 PCS, 3 PCS. When video recording is working, the option will not
work.
8. LCD brightness
Adjust the body camera LCD brightness to fit lighting situation for better image and video view.
10 is highest level.
9. Screen off
Switch off the screen after a certain time if there is any operation, which will save the power
consumption.
10. Volume
select volume level option to increase or decrease all the volume of camera, including playback,
key sound, indicate sound and so on.
11. Indicator sound
This option means when the user do the operations with camera, It will give the accordingly
response,beep or voice, and it will applied to the operations as follow:
1. Start/Stop video recording;
2. Start/Stop audio recording;
3. Power on/off the camera;
4. Low battery;
5. Inadequate storage space;
13. Key sound
Select to turn the key tone ON of OFF when you press the keys.
14. Hourly report
Select to turn the hourly notice ON or OFF, it will give the voice report hourly if the switch is ON.
15. Indicator light
Select to turn all the LED ON or OFF, including the status LED and power LED.
16. White light
Select to turn the white LED ON or OFF.
17. IR mode
If the users choose manual mode, when the camera is using video recording or in preview mode,,

8
long press M key to active it or inactive it.
If the users choose auto mode, the IR will work when the environment is dark, similarly, when the
environment is bright, the IR will be closed automatically.
18. Auto shutdown
Turn off the camera after a certain time if there is any operation.
19. Motion detect
If there is something moving in the screen when the device is in preview mode, the video
recording will work automatically, otherwise, the video recording will stop working automatically.
20. Start logo
Select to turn the start logo ON or OFF, it means the logo picture will be shown when camera start
up and shutdown.
21. Default setting
When it is set as ON, the camera will auto-reboot to clear all the settings of menu, but all the
playback files will still in the camera.
12. Video loop
When you create one new video recording file, if the file size is more than the remaining storage
of camera, the camera will delete the most original file, so that the new file can be saved.
22. Udisk mode
Select to turn removable disk mode function as ON or OFF, when it’s ON, connect the camera to a
PC, it will turn to a removable disk automatically.
23. Security password
Select to turn security password ON or OFF.
When it is ON, it will require the password when the users go to playback mode and menu mode,
and the default password is 000000.
24. Language
The language will be applied to the screen display and all the voice notice, and the users can
choose English, 日本語, Español, русский.

9
4. Device using
1. Turning On the Camera
In power off status, long press for 3 seconds, the camera will be turn on and enter into
preview mode automatically. Meanwhile, the status indicator will turn green.
2. Turning Off the Camera
In preview mode, long press for 3 seconds, the camera will save the current status and
power off. Meanwhile, the status indicator will turn off.
3. Snapshot
In preview mode, press to take a photo; long press to take more photos
continuously, the quantity of photo can be configure in the menu. There is a crack sound when
a photo was taken, and the photo will be saved in JPG format automatically.
4. One Touch Snapshot
In power off status, long press to turn on the camera and a photo will be taken. The
status indicator will turn red and flash. The photo will be saved in JPG format automatically.
5. Recording Video
In preview mode, short press to start recording. Meanwhile, the status indicator will
turn red and flash, and the recording icon will turn to yellow. Short press again to stop
recording, and the video will be saved in MP4 format automatically.
Remark: During video recording, long press “Audio REC” button to mark the video as important video,
press again to cancel it. And press “Snapshot” button to zoom in and zoom out.
6. One Touch Video Recording
In power off status, long press to turn on the camera and it will start recording.
Meanwhile, the status indicator will turn red and flash, recording icon will turn to yellow.
Press again to stop recording, and the video will be saved in MP4 format

10
automatically.
7. Audio Recording
In preview mode, press to start audio recording. Meanwhile, the status indicator will
turn to yellow and flash. Press again, the camera will stop audio recording, and the
audio will be saved in WAV format automatically.
8. One Touch Audio Recording
In powered off status, long press , the camera will be turn on and start audio recording.
Meanwhile, the status indicator will turn yellow and flash. Press again, the camera will
stop audio recording, and the audio will be saved in WAV format automatically.
9. IR Mode
When the users set the IR as manual mode, In preview mode or during recording a video, long
press to switch to IR mode. Long press again to exit from IR mode.
10. White light
White light is used for auxiliary illumination when the brightness of environment is not good.
In power on status, short press to turn on the white light, and short press again
to turn it off.
11. Playback
In the preview mode, press to enter into the playback interface. The move left icon is
and the move right is , press to confirm your selection, press to
exit, as the figure shown:
Left→ video Right→ photo OK→ playback Exit→ menu
12. Menu configuration
In preview mode, press to enter menu interface, press / to select the
option menu, and then press to confirm the operation, and then press / to
select corresponding icon, and then press to active the option.

11
13. Charging the Battery
This camera has a chargeable battery built in. In case of low battery, please connect this
camera to power supply for battery charging.
Connect this camera and adapter via USB cable, and connect adapter to power supply to
charge the battery. In charging status, the status indicator will turn red. Once the battery is
fully charged, the status indicator will turn green.
