Hulk HU6511 User manual

lithium-ion
jump starter
PORTABLE EMERGENCY
POWER SUPPLY
12V
user manual
HU6511
Up to
PETROL
10L
Up to
DIESEL
7.0L
18,000mAh
2,000amp

caution
Please read the user manual carefully and
use the product correctly based on the user
manual so that you can be familiar with the
product more conveniently and quickly!

caution TECHNICAL SPECIFICATIONS
Capacity: 66.6 Wh
Dimensions: 183 (L) x 119 (W) x 45.6 mm (H)
Weight: 2kg
Battery: Lithium-Ion
Output voltage: 12V to 19V
Output ports: USB -5V 2.1A
Auto jump starter -12V
Electronic - 12/19V 3.5A
Input Charging Ports: 3.5mm -18V 1.5A
Start current: 1200A
Peak Current: 2000A
Operating Temperature: -20˚C to +60˚C
Charging times: 240V Wall Charger: 3~4 hours
12V DC Charger: 5~6 hours
2

IMPORTANT SAFETY INFORMATION
PLEASE read this entire manual before attempting to use the product.
WARNING:
1. Do not damage, drop or crush this item. Do not attempt to use the jump starter if it
has been damaged in any way.
2. Do not charge this item in wet conditions (rain, snow, damp). Do not use this product
in explosive environments (dust, bilge, gaseous fumes, or flammable materials).
3. Do not burn or Incinerate this product, It may explode, causing personal injury or damage.
Taxic fumes and other potentially harmful materials are created when the battery is burned.
4. Do not disassemble this product. It may result in risk of fire, electric shock or exposure
to battery chemicals.
5. Do not insert foreign objects into any input or output ports. This item may short circuit.
Any metal that comes in contact with the jumper cable port may short circuit. Short
circuiting this product will damage the battery and may cause personal injury or fire.
6. This is a Lithium ion battery. In the unlikely event that this product leaks battery
chemicals. Do not allow contact with skin, eyes or mouth as It may cause personal injury
or burns. If skin Is exposed to battery chemicals, wash with soap and water and rinse
with vinegar.If your eyes come in contact with battery chemicals immediately flush with
water and then see a medical professional.
7. When recharging this item, make sure the area is well ventillated. Please do not smoke
or allow open flames near a charging battery.
8. Never jump start a frozen battery.
9. Please keep the product away from and out of reach of children.
10. Do not expose the battery to temperatures over over +60˚C or below -20˚C.
11. If the unit needs to be disposed of for any reason. It must be disposed of properly
by calling your nearest lithium-ion battery recycle facility.
12. If the product malfunctions or is having problems, discontinue use and return to
the place of purchase.
13. Store this unit in a cool dry location.
14. This unit is not designed to be used in place of a vehicle battery.
15. This unit is not designed to be used as a car battery charger. It is for jump starting only.
3

WARNING:
Warning. Always properly ventilate the area before attempting to start the
engine, hook up a Jump starter or start the jump starting process DO NOT use
this product near or in the presence of propane tanks, natural gas or any other
explosive fumes that may accumulate, especially in low or enclosed areas.
Note that the lead acid battery may vent potentially explosive gases during
the process of cranking the engine. - ALWAYS KEEP THE AREA WELL
VENTILATED to eliminate potentially explosive gases before performing any
jump starting process.
1. Shield eyes with protective safety glasses or safety goggles.
2. Make sure the ignition switch in the vehicle to be jumped Is in the off position
before attaching cables.
3. Always put the ground (Black) cable on a non-moving engine ground point.
Never connect clamps to the carburetor or fuel Injection system as a ground
point.
WARNING:
DO NOT crank the engine for more than 4 continuous seconds while the unit
is connected to the battery. If the engine fails to crank or start there may be
a problem other than a discharged battery.
4

5
GENERAL INFORMATION
The HULK Professional Series HU6512 Jump Start is capable of starting
Diesel engines up to 7L & Petrol engines up to 10L.
Compatible With:
The HULK Professional Series Jump Starter has 66.6wh of capacity for
charging laptops, mobile phones, portable gaming devices, MP3/MP4 players,
cameras, tablets and other electronic devices. It charges at 2 times the rate
of a typical AC wall outlet. It also has an LED flashlight with 3 modes.
Recharging the Jump Starter Unit:
240V AC - Plug the charging jack of the wall charger into the charge port of
the jump start (8) then plug the wall charger into a power socket and turn on.
The device is charging when the LED battery indicator “IN” flashes red.
12V DC - Plug the charging jack of the of the cigarette lighter charger into
the charge port of the jump start (8) then plug the cigarette lighter end into
a power socket. When the unit is fully charged, the LED battery level will be
at 100%.

6
Note: Full recharge of the unit should take between 4-6 hours depending
upon battery level. We recommend charging the unit every 6 months for
optimum performance.
LED Flashlight Operation:
Press and hold the power button (4) for three seconds to turn on the fashlight.
Press the power button (4) again for slow flash and again for SOS fast flash.
Press again to turn off.
Charging Electronic Devices:
Turn the on/off button (9) to the on position. Insert the included 4 in 1 cable
or other USB cable into one of the USB ports (6) and the other end into the
device being charged. (mobile phone, tablet, camera, or other electronic device).
Charging Laptop Devices:
Turn the on/off button (9) to the on position. Insert the included cable into the
12V (7)or 19V (5) port and the other end (with the correct adatpor fitted) into
into the device being charged.
Please check that the correct voltage, 12V or 19V, for your device has been
selectected, the charge voltage is on the label on the rear of your device.

1
9
V
5
V/2
.
1
A
5
V/2
.
1
A
1
2
V
O
N
/
O
F
F
7
FUNCTION ON SMART BATTERY JUMPER CABLE
1. Reverse polarity connection: Solid Red LED with fast 2 short beep.
2. Short-circuit protection: Solid Red LED with long beep (Beeping as 3.3Hz Frequency).
3. Over-heat protection: Solid red LED with Long beep (Beeping as 2Hz Frequency).
4. Over-discharging protection: Solid red LED with fast 2 short beep.
5. Green/Red LED flashing: Searching for status of connection.
6. Green Led: Correct connection after one beep
PRODUCT FEATURES
1. LED display 2. Flashlight 3. Battery terminal socket
4. Power button 5. 19V - 3.5A output 6. 5V - 2.1A output
7. 12V - 4A output 8. 18V/1.5A input 9. Power ON/OFF
3
2
45
6
7
89
1
Note: The jump start LED display will shut down after 20 seconds of inactivity.
Press the power button (4) to reactivate.

PACKAGE CONTENTS
8
Carry Case Jumper Cables
Car ChargerPower Adaptor 3 in 1 Mobile Adaptor
Laptop Adaptors

QUICK START GUIDE: JUMP STARTER
IMPORTANT:
If jump starter does not jump start the engine, the jump starter may not have
sufficient charge OR the jumper cable may be improperly connected to the
vehicle battery.
NOTE:
When connecting cables: If there is an improper connection, a solid RED LED
will appear on the Smart Cable and the unit will emit an audible alarm.
If you are hearing the alarm this means that the unit is not connected properly
and will not start the vehicle. Reset this alarm by pressing the overide button
for 3 seconds.
9
Before attempting to jump start your vehicle, please read your vehicle owners manual
to insure there are no specific steps needed.
DO NOT crank the engine for more than 4 continuous seconds while the unit is connected
to the battery. If the engine fails to crank or start, there may be a problem other than a
discharged battery.
1st step:
2nd step:
5th step:4th step:
3rd step:
6th step:
Ensure the jump start unit has
more than 30% capacity.
Connect the red clamp to the positive “+”
terminal of the battery and the black
clamp to the negative “-” terminal of
the battery or another earth point.
Remove the battery clamp from
the jump starter and car battery.
Insert the battery clamps into
the jump starter.
If connection fails (green LED does not
illuminate solid) press the override
button for 3 seconds to reset.
When the green LED illuminates
start the vehicle, do not crank engine
for longer than four (4) seconds.

10
JUMP STARTING A VEHICLE
1. Refer to your vehicle’s owners manual for proper jump start location.
2. Check the battery terminals to ensure they are clean and free from any
debris for best connection.
3. Identify the positive “+” and negative “-” terminals of the battery before
connecting the clamps.
4. Make sure jump starter battery has at least 30% charge.
5. Plug the jumper cables into the jump starter output port
(next to the LED light).
6. Turn Switch to the “ON” position
7. Connect cables to your vehicle’s battery by first connecting the “+” positive/
red cable clamp to the “+” positive/red cable terminal on your vehicle’s
battery. Next connect the “-” negative/black cable clamp to the “-” negative/
black terminal on your vehicle’s battery. Where possible connect the earth
clamp to a chassis earth or non moving engine earth.
8. Turn the ignition key to the on position, so that the unit will detect a current
draw and activate properly. For push button ignition systems, push the
ignition button twice without depressing the brake, to engage the smart
cable.
9. When the LED on the smart battery cable is solid green there is a correct
connection to start the vehicle.
10. If LED’s are blinking red, solid red or alternating red/green then see
smart battery cable function on page 7.
11. Once you have a proper connection, start the engine
NOTE: This unit uses advanced safety jumper cables which provide short
circuit protection, reverse polarity protection and temperature limits.
Please ONLY use the jumper cables supplied with this unit to ensure
safety and best results.
12. Disconnect clamps Immediately after starting vehicle.

11
WARRANTY INFORMATION
• We offer a limited warranty for this product against any defects in material and
workmanship for a period of 12 months from the date of purchase by the end
user/consumer. Return to the place of purchase for warranty or repairs.
The conditions of the warranty are as follows:
• The warranty is only valid upon presentation of the original receipt (from dealer/
retailer) by the original purchaser with the product to be repaired or replaced.
• The warranty is void if the serial number, date of purchase and label has been
removed.
• The warranty does not cover damage or product failure resulting from normal wear
and tear, physical abuse, improper installation, misuse, modification or repairs by
unauthorized third parties.
• We do not assume responsibility for any loss or damage incurred during shipment
or as a result of a force majeure.
• We are not liable for any incidental or consequential damages arising from the
use or misuse of this product.
• All warranty claims are limited to repair or replacement of the defective product
and at the sole discretion of Automotive Imports.
• If we replace the product, the product will be covered for the remaining time of
the original warranty period.
• Consumable components such as batteries are not covered by the warranty.

12
Warranty Card
ONE YEAR LIMITED WARRANTY
Customer Name
Maintenance Date
Serial NO.
Tel
Address
Seller
Purchase Date
Model
Description of Product

Manufactured and Packaged for
Automotive Imports Pty Ltd
22 – 28 Lexton Road, Box Hill
Victoria, Australia
AUS: www.hulk4x4.com.au
NZ: www.hulk4x4.co.nz
Caution:
Please read the user manual carefully
