Hultafors HDL 80 User manual

HDL 80
Operating instructions EN

INCLUDED IN DELIVERY WITH THE HDL 80
1. Laser distance measurement instrument
2. Belt bag
3. AAA batteries
4. Flat-head screwdriver
5. Quick start guide
1
2
3
2.1 FUNCTION BUTTONS
2.2 DISPLAY
234
1
5
7
6
8
1
13
14
15
16
2
3
5
6
7 8 9 10
11 12
}
4
4
2 3

Operating manual
HDL 80/Laser Distance Measurement
Instrument
1.1 Signal words and their meaning
DANGER
For an imminent danger that could lead to
serious injury or death.
WARNING
For a possibly dangerous situation that could
lead to serious injury or death.
CAUTION
For a possibly dangerous situation that could
lead to slight injury or property damage.
NOTE
For application notes and other useful
information
1.2 Pictograms and other information
1.2.1 WARNING SIGNS
Warning of dangers in general
1. General information
1.2.2 Symbols
Read instructions before use
Batteries and devices may not be
disposed of with household waste
Do not throw batteries into the fire
Warning signs on battery Do not
heat the battery above 60 °C.
Class 2 laser device
Do not look into the laser beam!
About this manual
Congratulations on the purchase of your
new HDL 80! You have acquired a Hultafors
measurement instrument, which can make
your work easier, faster and more precise. To
utilize the complete functionality range of this
measurement instrument, and to ensure a
safe operation, please observe the following
instructions:
Please read these operating manual before
starting to use the device.
Always keep the operating manual near the
device.
Only hand over the device to other persons
together with the operating manual.
Never render the attached warning signs
unreadable.
Contents
1. General information
2. Description
3. Technical data
4. Safety instructions
5. Laser safety / classification
6. Startup
7. Operation
8. Maintenance, storage and transportation
9. Scope of delivery and accessories
10. Troubleshooting
11. Disposal
12. Warranty
13. EC conformity declaration
4 5

1.2 Function Buttons
1 ON/Measure button
2 Function button
3 Min/Max and continuous measurement
4 Add/subtract
5 Memory
6 Measurement edge
7 Backlighting/unit of measurement
8 OFF/Delete button
2.2 Display
1 Laser ON
2 Front measurement edge
3 Back measurement edge
4 Side measurement edge
5 Continuous measurement of distance
6 Error messages
7
8
9
10
11 Battery status
12 Memory
13 Measured value 1
14 Measured value 2
15 Measured value 3
16 Last measured value
2. Description
}
Area, volume, indirect 2-
and 3-point measurement
2.3 Intended Use
is instrument is designed to measure
distances. e measured value, setting, and
instrument status can be viewed on the display.
A laser beam is emitted and then sent back to
the laser distance measurement instrument
from a reflected surface. is is used to calculate
the distance. e range depends on the model of
the laser distance measurement instrument, on
reflectivity, and on the properties of the reflective
surface.
3. Technical Data
3.1 General
Measurement range 0.2–80 m*
Accuracy ± 1.5 mm**
Unit of measurement m, in, , +in
Laser class 2
Laser type 635 nm, < 1 mW
Protection rating IP54
Laser auto-shutdown 30 s
Instrument auto-shutdown 180 s
Operating duration up to 5000 measurements***
Battery type 2 x AAA 1.5 V
Operating temperature 0 to +40°C
Storage temperature -10°C to +60°C
Dimensions (H x W x D) 115 x 52 x 32
Weight with batteries 140 g
*when measuring targets with 100% reectivity (e.g., a painted white wall), with low backlighting and an operating temperature of 25°C.
**at 0.2–10 m; distances between 10 m and 80 m may cause the maximum tolerance to decrease by 0.1 mm/m.
***when used at room temperature.
6 7

4. Safety instructions
3.2 Functions
• Individual measurement
• Min/Max measurement
• Continuous measurement
• Area measurement
• Volume measurement
• Indirect 2-point measurement
• Indirect 3-point measurement
• Addition
• Subtraction
• Measured value memory
• Unit of measurement
• 4-line display with backlighting
4.1 Area of responsibility
4.1.1 MANUFACTURER
Hultafors is responsible for the safe delivery
condition of the product, including the operating
manual and the original accessories.
4.1.2 OPERATOR
e operator is responsible for using the product
as intended, the deployment of his personnel,
their training and the operational safety of the
product.
• He understands the safety
information which is stated on the
product and the instructions which
are contained in the operating
manual.
• He shall comply with local regulations relating
to safety and accident prevention regulations as
well as worker protection laws and regulations.
• He shall immediately notify Hultafors if safety-
related issues should develop on the product
or during its utilization.
• He shall ensure that the product is not utilized
any further if defects become evident, and he
will have the product repaired professionally.
4.2 IMPROPER USE
• Use of the device and the accessories without
instruction.
• Use of third-party accessories or additional
equipment.
• Use outside of the intended limits
(see Chapter
3/Technical data)
.
• Use under extreme temperature fluctuations
without an adequate acclimatization.
• Disabling of safety devices and removal of
hazard notices and labels.
• Unauthorized opening of the device.
• Performance of modifications or alterations
the device or the accessories.
• Deliberate blinding of third parties.
• Inadequate safeguarding at the installation
site.
4.3 UTILIZATION LIMITATIONS
e HDL 80 is suitable for a continuous use in an
atmosphere which can be inhabited by humans.
• Do not operate the product in explosion-prone
or corrosive environments.
• Inform the local safety authorities and
safety experts before working in hazardous
environments, in close proximity to electrical
installations or similar surroundings.
8 9

4.4 Usage Hazards
4.4.2 BATTERIES
DANGER
Strong mechanical influences, can lead
to a leakage, fire or explosion of the
batteries or trigger the release of toxic
substances.
• Batteries and rechargeable batteries may not
be opened or exposed to mechanical loads.
• Repairs have to be exclusively performed by
Hultafors
WARNING
High ambient temperatures and
immersion into liquids can cause
a leakage, fire or explosion of the
batteries or trigger the release of toxic
substances.
• Protect batteries and rechargeable batteries
from mechanical influences during transport.
• Do not overheat batteries and rechargeable
batteries or expose them to fire.
• Avoid the ingress of moisture into batteries
and rechargeable batteries.
• Do not use damaged batteries or rechargeable
batteries. Perform a proper disposal
(see Chapter 11/Disposal) .
WARNING
A short-circuiting or unintended use can
cause batteries to overheat and create
an injury or fire hazard.
4.4.1 GENERAL
WARNING
Missing or incomplete instructions may
result in improper or incorrect use.
is can cause accidents with serious
damages to persons, property, assets
and the environment.
• Follow the manufacturer‘s and operator‘s
safety instructions.
• Protect equipment and accessories from
access through children.
WARNING
Blinding by laser radiation can indirectly
lead to serious accidents, especially
for people who are driving a vehicle or
operating machinery.
• Do not set up the laser beam and the laser
plane at eye level or aim at people.
CAUTION
A fall, longer storage, transportation or
other mechanical eects can lead to
erroneous measurement results. Check
the unit for damage before use.
Do not use damaged equipment.
• Repairs have to be exclusively performed by
Hultafors
• Do not transport or store batteries in the
pockets of garments.
• Do not bring the battery contacts in contact
with jewelery, keys, or other electrically
conductive objects.
• Do not charge the batteries.
• Do not discharge the batteries through short-
circuiting.
• Do not solder the batteries within the device.
• Do not mix old and new batteries, and do not
mix batteries from dierent manufacturers or
with a diering type designation.
WARNING
If disposed of improperly third parties
can possibly be seriously injured and
the environment polluted. e burning
of plastic components generates toxic
fumes which may impair health of people.
Batteries/rechargeable batteries may
explode if they are damaged or heated
excessively, and thereby cause poisoning,
burning, corrosion or environmental
contamination.
If disposed of negligently unauthorized
persons are able to use the product
improperly.
• e product may not be disposed of together
with household waste. Perform a proper
disposal of the device and the accessories
(see
Chapter 12/Disposal)
.
• Protect the product at all times from access
through unauthorized persons, and especially
children.
4.5 Electromagnetic compatibility (EMC)
e electromagnetic compatibility is the ability
of the product to function in an environment
with electromagnetic radiation and electrostatic
discharges were are present, without causing an
electromagnetic interference for other devices.
4.5.1 INTERFERENCE FOR OTHER DEVICES
THROUGH HDL 80
Although the product meets the strict requirements
of the relevant directives and standards, Hultafors
can not completely exclude the possibility of
interference with other devices (for example,
when using the product in combination with third-
party devices, such as field computers, personal
computers, wireless devices, mobile phones,
certain cables or external batteries).
• When using computers and radio equipment
make sure to observe to the vendor-
specific information about electromagnetic
compatibility.
• Only use original Hultafors equipment and
accessories.
4.5.2 INTERFERENCE OF THE HDL 80
THROUGH OTHER DEVICES
Although the product meets the strict requirements
of the relevant directives and standards, Hultafors
can not entirely exclude the possibility that an intense
electromagnetic radiation in the immediate vicinity of
radio transmitters, two-way radios, diesel generators,
etc. can distort the measurement results.
• When performing measurements under these
conditions check the plausibility of the results.
10 11

5. Laser safety/classification
e HDL 80 emits a visible laser point.
e product corresponds to the Laser Class 2
according to DIN EN 60825-1:2007
Laser Class 2:
When using Class 2 laser devices the eye is
protected by the eyelid closure reflex or evasive
reactions in case of a random and short-term
exposure.
WARNING
Looking directly into the beam with
optical aids (e.g. binoculars, telescopes)
can be dangerous.
CAUTION
Looking into the laser beam may be
hazardous to the eye.
• Do not look into the laser beam.
• Do not aim the laser beam at other people.
Labeling on the device:
• Do not remove the type plate!
6. Getting Started
6.2 Belt bag
e laser instrument can be stowed in a belt
pouch for transport. It must be removed from
the pouch when taking measurements.
6.1 Batteries
1. Open the battery compartment cover on the
back of the instrument using a screwdriver.
2. Insert the batteries into the instrument,
observing the correct poles.
3. Close the battery compartment cover
(tighten the screw by hand using a
screwdriver).
Use only AAA batteries (1.5 V).
Remove the batteries if the instrument is
not used over a longer period of time.
12 13

7. Operation
7.2 Applications
7.2.1 INDIVIDUAL MEASUREMENT
1. Switch on the laser instrument.
2. Direct the laser point at the target.
3. Press the ON/Measure button.
As soon as an audible signal is emitted, the
measurement is complete and the distance can
be seen on the display. To calculate additional
distances, press the Measure button again.
7.2.2 MIN/MAX MEASUREMENT
1. Switch on the laser instrument.
2. Direct the laser point at the target.
3. Press the Min/Max and continuous
measurement button..
e minimum and maximum values are shown
on the display. To stop the measurement, simply
press the ON/Measure button.
7.1 Getting Started
7.1.1 SWITCHING THE INSTRUMENT ON AND
OFF
On:
• Hold down the ON/Measure button for 2
seconds to switch the laser instrument on.
O:
• Hold down the OFF/Delete button for 2
seconds to switch the laser instrument o.
7.1. 2 B ACK
Press the OFF/Delete button once to undo the
last action. Press the OFF/Delete button twice to
exit the current function and return to individual
measurement mode.
7.1.3 SETTING THE MEASUREMENT PLANE
Press the Measurement edge button to toggle
between using the front, back, or side of the
instrument. e selection is indicated by an
arrow on the display. e back of the instrument
is set as the measurement edge by default. Each
time the instrument is restarted, the back of the
instrument is reset as the measurement edge.
7.2.3 CONTINUOUS MEASUREMENT
1. Switch on the laser instrument.
2. Direct the laser point at the target.
3. Press the Min/Max and continuous
measurement button.
e laser instrument measures the distance and
shows it on the bottom line of the display.
7.2.4 AREA MEASUREMENT
1. Switch on the laser instrument.
2. Press the Function button until the display
for area measurement appears.
3. Measure the length and then the
width separately using the individual
measurement method. e laser beam
remains switched on between the two
measurements.
Once the second measurement is complete,
the area is automatically calculated and shown
on the bottom line of the display. e individual
measured values are shown in measured value
lines 1 and 2. e perimeter is also shown in
measured value line 3.
7.2.5 VOLUME MEASUREMENT
1. Switch on the laser instrument.
2. Press the Function button until the display
for volume measurement appears.
3. Measure the length, the width, and then
the height separately using the individual
measurement method. e laser beam
remains switched on between the three
measurements.
Once the third measurement is complete, the
volume is automatically calculated and shown
on the bottom line of the display. e individual
measured values are shown in measured value
lines 1, 2, and 3.
7.2.6 INDIRECT 2-POINT MEASUREMENT
1. Switch on the laser instrument.
2. Press the Function button until the display
for indirect 2-point measurement appears.
3. Measure the two points separately using
the individual measurement method. e
laser beam remains switched on between
the two measurements.
Once the second
measurement is complete,
the length is automatically
calculated and shown
on the bottom line of the
display. e individual
measured values are
shown in measured value
lines 1 and 2.
the first distance
the second distance
the perimeter
the area
14 15

CAUTION
e two points measured must be in line
and the second measurement must be
taken at a right angle to the measured
surface; otherwise measured values
may be incorrect.
7.2.7 INDIRECT 3-POINT MEASUREMENT
1. Switch on the laser instrument.
2. Press the Function button until the display
for indirect measurement appears.
3. Measure the three points separately using
the individual measurement method. e
laser beam remains switched on between
the three measurements.
Once the third measurement is complete, the
length is automatically calculated and shown
on the bottom line of the display. e individual
measured values are shown in measured value
lines 1, 2, and 3.
7.2.8 ADDITION
1. Switch on the laser instrument.
2. Direct the laser point at the target.
3. Take an individual measurement.
4. Press the Add/subtract button to add the
next individual measurement (plus symbol +
appears on the display).
5. Take an individual measurement.
e laser instrument shows the result on the
bottom line of the display. is process can be
repeated indefinitely.
7.2.9 SUBTRACTION
1. Switch on the laser instrument.
2. Direct the laser point at the target..
3. Take an individual measurement.
4. Hold down the Add/subtract button for 2
seconds to subtract the next individual
measurement (minus symbol - appears on
the display).
5. Take an individual measurement.
e laser instrument shows the result on the
bottom line of the display. is process can be
repeated indefinitely.
7.2.10 MEASURED VALUE MEMORY
1. Switch on the laser instrument.
2. Press the Memory button.
e Add/subtract button can now be used to view
the last 20 measured values.
CAUTION
e three points measured must run
in a line and the second measurement
must be taken at a right angle to the
measured surface; otherwise measured
values may be incorrect.
7.2.11 UNIT OF MEASUREMENT
1. Switch on the laser instrument.
2. Press the Memory button.
e Add/subtract button can now be used
to view the last 20 measured values.
e unit of measurement switches from meters
(m) to feet (). Holding down the Backlighting/
unit of measurement button for 2 seconds again
switches the unit of measurement from feet ()
to inches (in). Holding down the Backlighting/
unit of measurement button for 2 seconds again
switches the unit of measurement from inches
(in) to feet and inches (+in). Holding down the
Backlighting/unit of measurement button for 2
seconds again switches the unit of measurement
from feet and inches (+in) back to meters (m).
Each time the instrument is restarted, the unit of
measurement is reset to meters (m).
7.2.12 BACKLIGHTING
1. Switch on the laser instrument.
2. Press the Backlighting/unit of
measurement button to switch the
backlighting on or o.
Each time the instrument is restarted, the
backlighting is switched on.
Each time the instrument is restarted, the
backlighting is switched on.
7.3 Guidance for Operation
e laser instrument must not be moved during
measurements. A fixed mounting surface with
a stop is therefore recommended. e laser
emission area and the reception range must not
be obscured during measurements.
Depending on the measured surface, it cannot
be guaranteed that all measurements are
completely accurate. Avoid surfaces that are
textured, reflective, transparent, or porous.
16 17

8. Maintenance, storage and transportation
9.1 Scope of delivery HDL 80
1 Laser distance measurement instrument
2 Batteries
1 Belt bag
1 Quick start guide
9.2 ACCESSORIES (optional)
LB laser goggles
TP target plate
Further information on accessories can be found
at www.hultafors.com
9. Scope of delivery and accessories
8.1 Cleaning
• Wipe o the dirt with a so damp cloth.
• Check the outlet openings of the laser
regularly, and gently clean them if necessary.
Do not touch the glass with your fingers.
• Do not use aggressive cleaning agents or
solvents.
• Do not immerse the device into water!
• Clean and dry wet equipment, accessories
and transport containers prior to packaging
them. Only pack equipment again when it is
completely dry.
• Keep plug connections clean and protected
from moisture.
8.2 Storage
8.2.1 GENERAL
• e equipment may only be stored within
the specified temperature limits
(see Chapter
3/Technical data)
.
• Aer a prolonged storage check the accuracy
of the measuring device before using it.
8.2.2 BATTERIES
• For storage, remove the batteries from the
device.
• e storage should preferably be performed in
a dry environment at room temperature
(see Chapter 3/Technical data) .
• Protect from moisture and humidity. Dry
wet or damp batteries before the storage, or
respectively before usage.
8.3 Transport
8.3.1 GENERAL
e device may be damaged through strong
vibrations or by falling.
• Never transport the product loosely. Always
use the original packaging or an equivalent
transport container.
• Switch o the measuring device before
transporting it.
• Check the unit for damages before use.
8.3.2 BATTERIES
When transporting or shipping batteries, the
operator is responsible for complying with the
applicable national and international laws and
regulations.
• Before shipping, remove the batteries from the
device.
18 19

10. Troubleshooting 11. Disposal
Error Possible Cause Remedy
204 • Calculation error • Check specifications.
Repeat process.
208 • Overvoltage • Contact supplier.
220 • Battery empty • Replace battery.
252 • Temperature too high • Allow instrument to cool to
the specified temperature.
253 • Temperature too low • Allow instrument to warm up to
the specified temperature.
255 • Reception signal too weak • Increase reflectivity of target.
256 • Reception signal too strong • Limit reflectivity of target.
261 • Outside of measurement range • Observe measurement range
given in specifications.
500 • Component error • Switch instrument on and o
repeatedly.
• If the error continues, contact
the supplier.
If disposed of improperly third parties can
possibly be seriously injured and the
environment polluted.
e burning of plastic components generates
toxic fumes which may impair health of people.
Batteries/rechargeable batteries may explode
if they are damaged or heated excessively, and
thereby cause poisoning, burning, corrosion or
environmental contamination.
If disposed of negligently unauthorized persons
are able to use the product improperly.
Measuring tools, accessories and packaging
must be recycled in an environmentally-friendly
manner.
e product as well as the
accessories - especially the
batteries and rechargeable
batteries - may not be disposed
of with household waste.
• Perform a proper disposal
of the device and the
accessories.
• Only dispose of batteries in
a discharged state.
• Observe the country-specific
disposal requirements.
Only for EU countries
Electric tools may not be
disposed of with household
waste!
According to the European
Directive 2002/96/EC
on Waste Electrical and
Electronic Equipment and its
implementation in national law,
no longer usable electrical and
electronic equipment must be
collected separately and recycled
in an environmentally friendly
manner.
20 21

12. Manufacturer‘s Guarantee 13. EC conformity declaration
Declaration of Conformity
We Hultafors Group AB, Hultaforsvägen 21, Hultafors
declare under our sole responsibility that the Product(s)
HDL 80
to which this declarations relates is in conformity with the following standards.
HDL 80:
• EN 55022: 2010
• EN 61000
• EN 55024: 2010
• EN 60825-1:2007
Following the provisions of Directive(s)
Electromagnetic compatibility 2004/108/EC
Low Voltage Directive 2006/95/EC
„e manufacturer warrants to the original
purchaser who is stated on the guarantee
card, the freedom from defects for the device
for a period of two years, with the exception
of batteries, as of the point in time the device
is handed over. e guarantee is limited to
repairs and/or replacements at manufacturer‘s
discretion. Defects which are caused through
improper handling by the purchaser or third
parties, natural wear and optical flaws that
do not aect the usability of the equipment,
are not covered by this guarantee. Claims
under this guarantee can only be invoked if the
device is submitted along with the guarantee
card, completely filled out by the dealer, dated
and provided with the company stamp. If the
guarantee claim is justified, the manufacturer
shall bear the transport costs. e duration
of the guarantee will not be extended through
repair or spare parts work which is carried out
within the scope of the guarantee.
Further claims are excluded, unless there are
provided by the respective national legislation. In
particular the manufacturer shall not be liable for
any direct, indirect, incidental or consequential
damages, losses
or expenses in connection with
the use or because of the inability to use the tool
for any purpose whatsoever. Implied warranties for
the usage or suitability for a particular purpose are
expressly excluded.“
22 23

MARCH 2018 v.1
