Hummer 2006 H2 User manual

Seats and Restraint Systems ........................... 1-1
Front Seats ............................................... 1-2
Rear Seats ............................................... 1-6
Safety Belts ............................................. 1-14
Child Restraints ....................................... 1-32
Airbag System ......................................... 1-58
Restraint System Check ............................ 1-69
Features and Controls ..................................... 2-1
Keys ........................................................ 2-3
Doors and Locks ....................................... 2-8
Windows ................................................. 2-17
Theft-Deterrent Systems ............................ 2-21
Starting and Operating Your Vehicle ........... 2-24
Mirrors .................................................... 2-39
OnStar
®
System ...................................... 2-48
Universal Home Remote System ................ 2-50
Storage Areas ......................................... 2-54
Sunroof .................................................. 2-61
Vehicle Personalization ............................. 2-63
Instrument Panel ............................................. 3-1
Instrument Panel Overview .......................... 3-4
Climate Controls ...................................... 3-22
Warning Lights, Gages, and Indicators ........ 3-29
Driver Information Center (DIC) .................. 3-45
Audio System(s) ....................................... 3-61
Driving Your Vehicle ....................................... 4-1
Your Driving, the Road, and Your Vehicle ..... 4-2
Towing ................................................... 4-59
Service and Appearance Care .......................... 5-1
Service ..................................................... 5-3
Fuel ......................................................... 5-5
Checking Things Under the Hood ............... 5-10
Rear Axle ............................................... 5-43
Four-Wheel Drive ..................................... 5-44
Front Axle ............................................... 5-45
Bulb Replacement .................................... 5-46
Windshield Wiper Blade Replacement ......... 5-52
Tires ...................................................... 5-53
Appearance Care ................................... 5-105
Vehicle Identification ............................... 5-114
Electrical System .................................... 5-114
Capacities and Specifications ................... 5-124
Maintenance Schedule ..................................... 6-1
Maintenance Schedule ................................ 6-2
Customer Assistance and Information .............. 7-1
Customer Assistance and Information ........... 7-2
Reporting Safety Defects ........................... 7-14
Index ................................................................ 1
2006 HUMMER H2 Owner Manual M

GENERAL MOTORS, GM, the GM Emblem, HUMMER,
the name HUMMER, H2 and the H2 Design are
registered trademarks of General Motors Corporation.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes
after that time without further notice. For vehicles first
sold in Canada, substitute the name “General Motors of
Canada Limited” for HUMMER whenever it appears
in this manual.
Keep this manual in the vehicle, so it will be there if it is
needed while on the road. If the vehicle is sold, leave
this manual in the vehicle.
Canadian Owners
A French language copy of this manual can be obtained
from your dealer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
How to Use This Manual
Many people read the owner manual from beginning to
end when they first receive their new vehicle. If this
is done, it can help you learn about the features
and controls for the vehicle. Pictures and words work
together in the owner manual to explain things.
Index
A good place to quickly locate information about the
vehicle is the Index in the back of the manual. It is an
alphabetical list of what is in the manual and the
page number where it can be found.
Litho in U.S.A.
Part No. 06H2 A First Printing
©
2005 General Motors Corporation. All Rights Reserved.
ii

Safety Warnings and Symbols
There are a number of safety cautions in this book. We
use a box and the word CAUTION to tell about things
that could hurt you if you were to ignore the warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
In the caution area, we tell you what the hazard is.
Then we tell you what to do to help avoid or reduce the
hazard. Please read these cautions. If you do not,
you or others could be hurt.
You will also find a circle
with a slash through it in
this book. This safety
symbol means “Do Not,”
“Do Not do this” or “Do Not
let this happen.”
iii

Vehicle Damage Warnings
Also, in this manual you will find these notices:
Notice: These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by your vehicle’s warranty, and it could be costly. But
the notice will tell what to do to help avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors
or in different words.
There are also warning labels on the vehicle. They use
the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along
with the text describing the operation or information
relating to a specific component, control, message,
gage, or indicator.
If you need help figuring out a specific name of a
component, gage, or indicator, reference the
following topics:
•Seats and Restraint Systems in Section 1
•Features and Controls in Section 2
•Instrument Panel Overview in Section 3
•Climate Controls in Section 3
•Warning Lights, Gages, and Indicators in Section 3
•Audio System(s) in Section 3
•Engine Compartment Overview in Section 5
iv

These are some examples of symbols that may be found on the vehicle:
v

✍NOTES
vi

Front Seats ......................................................1-2
Power Seats ..................................................1-2
Power Lumbar ...............................................1-3
Heated Seats .................................................1-3
Reclining Seatbacks ........................................1-4
Head Restraints .............................................1-5
Rear Seats .......................................................1-6
Heated Seats .................................................1-6
60/40 Split Bench Seat ...................................1-6
Third Row Seat (SUV) ....................................1-7
Safety Belts ...................................................1-14
Safety Belts: They Are for Everyone ................1-14
Questions and Answers About Safety Belts ......1-18
How to Wear Safety Belts Properly .................1-19
Driver Position ..............................................1-19
Safety Belt Use During Pregnancy ..................1-26
Right Front Passenger Position .......................1-27
Rear Seat Passengers ..................................1-27
Rear Safety Belt Comfort Guides ....................1-29
Safety Belt Extender .....................................1-31
Child Restraints .............................................1-32
Older Children ..............................................1-32
Infants and Young Children ............................1-35
Child Restraint Systems .................................1-38
Where to Put the Restraint .............................1-42
Lower Anchors and Tethers for
Children (LATCH) ......................................1-43
Securing a Child Restraint in a Rear
Seat Position ............................................1-52
Securing a Child Restraint in the Right
Front Seat Position ....................................1-54
Airbag System ...............................................1-58
Where Are the Airbags? ................................1-60
When Should an Airbag Inflate? .....................1-62
What Makes an Airbag Inflate? .......................1-63
How Does an Airbag Restrain? .......................1-63
What Will You See After an
Airbag Inflates? .........................................1-63
Airbag Off Switch ..........................................1-65
Servicing Your Airbag-Equipped Vehicle ...........1-68
Adding Equipment to Your Airbag-Equipped
Vehicle ....................................................1-69
Restraint System Check ..................................1-69
Checking the Restraint Systems ......................1-69
Replacing Restraint System Parts
After a Crash ............................................1-70
Section 1 Seats and Restraint Systems
1-1

Front Seats
Power Seats
The power seat controls are located on the outboard
edge of the front seats.
Horizontal Control: This control adjusts the
seat cushion.
•Raise or lower the front of the seat by raising or
lowering the forward edge of the control. Raise
or lower the rear of the seat by raising or lowering
the rear edge of the control.
•Move the seat forward or rearward by moving the
whole control toward the front or toward the rear
of the vehicle.
•Lower or raise the entire seat cushion by moving
the whole control up or down.
Vertical Control: This control adjusts the seatback.
Move the reclining front seatback rearward or forward by
moving the control toward the rear or toward the front
of the vehicle. This adjusts the angle of the seatback.
For more information on the reclining seatbacks,
see Reclining Seatbacks on page 1-4.
Your vehicle has a memory function which allows seat
settings to be saved and recalled. See Memory Seat
on page 2-63 for more information.
1-2

Power Lumbar
Your vehicle’s seats have power lumbar.
You can increase or
decrease lumbar support
in an area of the lower
seatback with this control,
located on the outboard
sides of the front seat(s).
To increase support, press and hold the front of the
control. To decrease support, press and hold the rear of
the control. Let go of the control when the lower
seatback reaches the desired level of support.
You can also reshape the side wing area of the lower
seatback for more lateral support.
To increase support, press and hold the top of the
control. To decrease support, press and hold the bottom
of the control. Let go of the control when the lower
seatback reaches the desired level of support.
Your vehicle may have a memory function which allows
seat settings to be saved and recalled. See Memory
Seat on page 2-63 for more information.
Heated Seats If your vehicle has this
feature, the buttons are
located on the front doors.
The engine must be
running for the heated
seats to work.
To heat the entire seat, press the horizontal button with
the heated seat and seatback symbol. Press the button to
cycle through the temperature settings of high, medium
and low and to turn the heated seat off. Indicator lights
will be lit to designate the level of heat selected: three for
high, two for medium, and one for low.
To heat only the seatback, press the vertical button with
the heated seatback symbol. An indicator light on the
seatback button will be lit to designate that only the
seatback is being heated. Additional presses of the
seatback button will cycle through the heat levels for the
seatback only. Press the horizontal button again to heat
the whole seat.
The heated seats will be canceled after the ignition is
turned off. If you still want to use the heated seat feature
after you restart your vehicle, you will need to press
the heated seat button again.
1-3

Reclining Seatbacks
The front seats have a recline feature which is described
earlier. See Power Seats on page 1-2.{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts cannot do their
job when you are reclined like this.
The shoulder belt cannot do its job. In a
crash, you could go into it, receiving neck or
other injuries.
The lap belt cannot do its job either. In a crash
the belt could go up over your abdomen. The
belt forces would be there, not at your pelvic
bones. This could cause serious internal
injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety
belt properly.
Do not have a seatback reclined if your vehicle is moving.
1-4

Head Restraints
Adjust your head restraint so that the top of the restraint
is closest to the top of your head. This position
reduces the chance of a neck injury in a crash.
Pull the head restraint up to raise it. Push the head
restraint down to lower it.
Each front head restraint can also be tilted forward to
four positions by pulling on it.
A click will sound after each tilt position is reached.
Pull the head restraint forward, past the last position, to
release it to the upright position.
The rear seat head restraints are also adjustable up and
down, but they do not tilt.
1-5

Rear Seats
Heated Seats
If your vehicle has this
feature, the buttons used
to control this feature
are located on the back of
the center console. The
engine must be running for
the heated seat feature
to work.
To heat the seat cushion, press the button to cycle
through the temperature settings of high and low. Press
the button a third time to turn the feature off. An
indicator light will glow for each heat setting when the
feature is operating.
The heated rear seats will shut off automatically when
the ignition is turned off.
60/40 Split Bench Seat
The 60/40 split bench seats can be folded to give you
more cargo space.
Folding the Seatbacks
The seatbacks (SUV only) are equipped with rearward
folding head restraints. When the seatback is being
folded down, the head restraint will automatically
fold rearward.
To fold the rear seat, do the following:
1. Make sure that nothing is under or in front of
the seat. 2. Pull up on the strap
loop located at the rear
of the seat cushion
and pull the seat
cushion up and fold
it forward.
3. Pull the seatback forward and fold it down until it
is flat.
If the seatback cannot fold flat because it interferes
with the cushion, try moving the front seat forward
and/or bringing the front seatback more upright.
4. Repeat the steps for the other half of the 60/40 split
bench seat.
1-6

Returning the Seats to an
Upright Position
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted will not provide
the protection needed in a crash. The person
wearing the belt could be seriously injured.
After raising the rear seatback, always check
to be sure that the safety belts are properly
routed and attached, and are not twisted.
To return the seat(s) to the upright position, do
the following:
1. Lift the seatback up and push it rearward all
the way.
2. Lower the seat cushion until it latches into position.
3. Pull forward on the seatback and up on the
seat cushion to make sure the seat is securely
in place.
4. Return the head restraints (SUV only) to the
upright position.
Third Row Seat (SUV)
Entering or Exiting the Third Row Seat
If your vehicle has a third row seat, you must fold
the second row seat down before entering or exiting the
third row. See “Folding the Seatbacks” under 60/40
Split Bench Seat on page 1-6 earlier in this section for
instructions.
The third row seatback can be folded and the entire
seat can be tilted or removed from the vehicle.
1-7

Folding the Seatback
To fold the seatback, do the following:
1. Pull up on the release
lever labeled 1, located
on the rear of the
seatback, and push the
seatback forward.
Unfolding the Seatback
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
To return the seatback to the passenger position, do
the following: 1. Pull up on the release
lever labeled 1 and
then pull up on
the seatback until the
seatback locks into
the upright position.
2. Push forward on the seatback to make sure it is
locked into position.
1-8

Tilting the Seat
1. Fold the seatback forward using the instructions
listed previously. 2. Unlatch the seat from
the floor by pulling up
on the lever labeled 2,
located on the rear
of the seat.
3. Lift the rear of the seat up from the floor and push it
forward until it locks into place. You will not be able
to unlatch the seat from the floor unless the
seatback is folded down.
The seat will now remain locked in the upright position.
Returning the Seat from a Tilted to an
Upright Position
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
1-9

To return the seatback to an upright position, do the
following:
1. Pull the lever labeled 3 toward you.
2. While still holding lever 3 toward you, grasp the top
of the seat and pull it toward you slightly.
3. Let go of lever 3 and pull the seat completely down.
4. Push down on the seat firmly. Try pulling it up to
be sure it is locked into place.
5. Pull up on the release
lever labeled 1 and
then pull up on
the seatback until the
seatback locks into
the upright position.
1-10

Removing the Seat
To remove the seat, do the following:
1. Open the liftgate. 2. Fold the seatback
forward onto the seat
cushion by using
the lever labeled 1.
The seat cannot
be removed unless the
seatback is folded.
3. To unlatch the rear of
the seat from the floor,
pull up on the release
lever labeled 2, at
the rear of the seat,
and lift the rear of
the seat up from
the floor.
1-11

4. Squeeze the release handle while pulling the seat
out of the slots on the floor.
5. While holding the rear of the seat up, roll the seat
out of the vehicle.
Reinstalling the Seat
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
{CAUTION:
A seat that is not locked into place properly
can move around in a collision or sudden stop.
People in the vehicle could be injured. Be sure
to lock the seat into place properly when
installing it.
1-12

{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted will not provide
the protection needed in a crash. The person
wearing the belt could be seriously injured.
After raising the rear seatback, always check
to be sure that the safety belts are properly
routed and attached, and are not twisted.
To reinstall the seat, do the following:
1. While holding the rear of the seat up, slide the front
wheels into the slots on the floor. The front latches
should lock into place. If the latches do not lock,
try tilting the rear of the seat upward.
2. Once the latches are engaged, pull up on the lever
labeled 3 to allow the seat to drop into place.
3. Pull up on the lever labeled 1 to return the seatback
to its upright position.
4. Push and pull on the seat to make sure it is locked
into place. The seatback cannot be raised to the
upright position unless the seat is secured to
the floor.
1-13

Safety Belts
Safety Belts: They Are for Everyone
This part of the manual tells you how to use safety
belts properly. It also tells you some things you should
not do with safety belts.
{CAUTION:
Do not let anyone ride where he or she cannot
wear a safety belt properly. If you are in a
crash and you are not wearing a safety belt,
your injuries can be much worse. You can hit
things inside the vehicle or be ejected from it.
You can be seriously injured or killed. In the
same crash, you might not be, if you are
buckled up. Always fasten your safety belt,
and check that your passengers’ belts are
fastened properly too.
{CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a
collision, people riding in these areas are more
likely to be seriously injured or killed. Do not
allow people to ride in any area of your vehicle
that is not equipped with seats and safety
belts. Be sure everyone in your vehicle is in a
seat and using a safety belt properly.
1-14
