Hunter Premium PRO 4G User manual

1
Instruction manual for scouting trail camera
Gebrauchsanleitung Scouting Trail Camera
Riistakameran Käyttöohje
Hunter Premium
PRO 4G

2
3
1.1 What’s in the Box?
• Trail camera “Hunter Premium PRO”
• Instruction manual
• USB cable
• Mounting strap
• Antenna
If any item is missing, contact
your local dealer for assistance.
Please note that batteries, SIM and
SD-card are sold separately!
1.2 How to Get the Camera Ready?
1.2.1 Insert the batteries
Open camera house and insert the batteries
as electrodes marked in battery case.
Note! 12AA Alkaline or Ni-MH are
recommended. For better performance,
pls choose the “Battery Type” of the
batteries in using (set in the menu, see
detailed description under point 4.5 below).
1.2.2 Insert the SD card
Use 8-32GB SD card. Please insert it
with correct direction as marked.
Note! Maximum 32 GB!
English
1. Quick Start

2
3
1.2.3 Mount the antenna and insert SIM card
1.3 Setting up the camera
1.3.1 Power on the camera
Switch to ON; camera is ready to work upon motion triggers (screen will
not light up upon “ON”). You can mount it out to work directly after this if
default settings are preferred.
1.3.2 Configure camera settings
Switch to SETUP, screen will light up. Press M key, you will enter the
menu to view & change settings. Please press arrow keys for
navigation and OK key to confirm settings.
Note! Please switch to ON to activate the camera after you get
preferred settings.
1.3.3 How to connect the camera to network
Different from non-transmitting models, the 4G model has a signal
“Searching” process when you switch the power key to SETUP.
If it comes with a signal bar and no other pop-up, it means the network
is auto-matched and no manual setup is needed. Fill in phones/emails
in “Send to”, you will be able to receive photos upon motion triggers.
(Note that ^means Save.)

4
5
If it comes with a pop-up “SIM Auto Match failed…”, please go to “SIM
Auto Match” under “4G”, select “Manual”, and fill in local operator APN
details in “Manual Setup”, the camera will connect to their network to
send photos.
Note! This camera can send photos to 2 phones & 2 emails. It’s set to
send photos to phones via MMS, and to emails via SMTP (data). If you
prefer more personalized way of sending, please configure in menu
accordingly.
1.3.4 Function test
To test the camera operation:
1. Slide the Power Switch to SETUP and wait for the camera to
connect to the operator (4G signal strength indicator is shown on
the screen).
2. Press the OK button once. The camera will take a photo, save on the
SD card, and transmit the photo to your phones/ emails.
3. Follow the sequence of events on the screen. If camera configura-
tion is correct the screen will show message “Send Succeed”.

4
5
2. Camera parts
2.1 Front of camera
Antenna
28 IR LEDs
(58 in total)
PIR sensor
30 IR LEDs
(58 in total)
Indicator light
Light sensor
(day/night)
Lens

6
7
2.2 Bottom of camera
SD Card Slot
DC in
USB Port
Battery Slot
SIM CARD
golden part faces
front housing
side
Battery Slot
Power switch
(ON/ OFF/ SETUP test mode)
LCD colorful screen
MENU button
Navigation buttons / OK button
2.3 Inside of camera

6
7
3. Introduction
With contents in previous pages, believe you’ve already got a brief idea
about how this camera works. Before more details presented, here we
want to thank you for choosing one of our easy operation highly qua-
lified products. You now may enjoy the excellences reflected on this
series product. This 12MP HD digital camera was totally R&D by our
diligent and smart engineers based on feedbacks and requirements
from customers globally. May you also enjoy and adore this product as
we do. And our company is always open-minded with willing to adopt
creative ideas from you.
3.1 Fully functionality introduction
Förutom alla funktioner du kan få med andra, liknande kameror
syftar den här till att erbjuda dig en stabil kvalitetsprodukt med bra
användarupplevelse och många extrafunktioner, som SIM-inställning
auto-match, daglig rapport, fjärrkontroll med APP (IOS och Android),
15 m (50 fot) osynligt verklig mörkerseendeförmåga, 0,4 s aktiverings-
tid och 1 foto/sek (upp till 5 foton per aktivering) multi-shot för att
fånga objektets hela rörelseförlopp (stöldskyddsbevis), användarvän-
lig driftmeny etc.
3.2 Power supply
3.2.1 Batteries
Camera runs on 6 or 12 AA size batteries (9-12V power supply to ensure
camera well performance of all functions); can work with alkaline and
high-quality NiMH rechargeable batteries. But we suggest to run camera
with NiMH batteries only as performance of alkaline batteries is much
poorer than NiMH batteries. Pls also choose the battery type you’re
using in the menu option “Battery Type” to reach longer operation time.
Batteries should be inserted with correct electrode position as marked
on the housing. Upside down batteries electrodes may cause device
malfunction. Also, we strongly recommend changing the batteries
when power icon on camera screen or photo stamp is empty.

8
9
Note! Don’t mix batteries types! Different batteries to be used in came-
ra may cause permanent damage which also violates warranty policy!
Due to different settings, objects activities within camera detection
zone, different brands and quality of batteries, and user environment,
temperature etc; we’re not able to list out exact number of photos and
videos that camera can achieve.
So given table below only shows approximate number of photos or
videos camera can take with 12AA alkaline batteries; better
performance can be given by 12 AA rechargeable NiMH batteries.
12AA Alkaline Batteries
IR LEDs On
Photos/day Working time Video clips shot per day Working time
Max IR 100 pics 91 days 10 secs video clips/10 klipp 85 days
Mid IR 100 pics 86 days
Min IR 100 pics 80 days
IR LEDs Off
Photos/day Working time Video clips shot per day Working time
Photo 100 pics 113 days 10 secs video clips/10 klipp 228 days
Test Condition: LCD screen off. Mode: “Power On” _PIR intelligent automatically
monitoring; 4G Off.
3.2.2 Solar panel
To bring users better using experience, our engineers designed this camera to
be able to work with most standard 12V/2A lithium battery build-in solar panels.
Note that the camera cannot handle dual power sources, so the batteries must
be removed from the camera if the solar panel is connected. Hunter Solar Panel
(Article no: TL20100) is recommended.

8
9
3.2.3 Power adaptor – Security surveillance purpose
This camera can also be powered by an external 12V/ 2A DC adapter.
Note that the AA size batteries are removed when power adapter is
used. Electrical power is recommended for security purposes. Hunter
Power Adapter (Article no: TL20130) or Hunter Power Cable (Article
no: TL20110, TL20120) is recommended. The DC plug specification is
4.0 x 1.7mm.
3.3 SD card selection
Using a memory card is required to operate the camera. When the
camera is ”ON” and no memory card is used, the screen displays ”No
card”. The SD slot of the camera has a 32 GB memory capacity. Before
inserting or removing the memory card, the camera must be turned
”OFF”. Failing to do so may cause loss of or damage the pictures/ videos
already recorded from the memory card. When the SD card is full, the
viewing screen shows ”Memory Full”. The following data shows an
approximate quantity of photos which can be recorded by the camera
depending on the memory card capacity.
Chart below will show you the approximate capacity of different size
SD cards. Pls check to see which size card can fit your needs best.
Number of pics 4 GB 8 GB 16 GB 32 GB
5 MP 3 585 7 492 15 307 30 936
8 MP 2 294 4 798 9 794 19 795
12 MP 1 613 3 371 6 887 13 919
Number of video hours
640x480 00:22:28 00:46:57 01:35:56 03:13:52
HD 00:16:13 00:33:53 01:09:14 02:19:56
FHD 00:08:31 00:17:48 00:36:20 01:13:21

10
11
3.4 USB connection
When camera is connected via USB cable; screen display “MSDC”,
press “Menu” once, “MSDC” turns to “PC Cam”, camera now can be
used as a PC camera; press “Menu” again, camera exits PC camera mode.
3.5 Attention!
1. Insert the SD memory card correctly, camera does not support SD
card hot swap (insertion).
2. Please use high-quality AA batteries in order to prevent battery
cells from corrosion of leaked acid.
3. Use right adaptor (12V/2A) of this camera to supply power, and do
not invert the electrode when put in batteries.
4. In Test mode, camera will automatically power off in 3 mins if
there is no keypad touching.
5. Don’t interrupt power supply during system upgrade, please deliver
it back to factory if the device doesn’t work after upgrading.
6. Do not frequently insert or pull out SD card and battery or plug in
and out the adaptor when the camera is on.
7. Do not have any floating objects, such as leaves, strings, or ribbons
in the 3M motion detection zone of cameras, to avoid mistaking
photograph or videos.
8. Do not keep camera next to hot irrelevant objects, air conditioner
exhaust vents, and light, etc. to avoid mistaking photos or videos.
9. Camera is with a 100° FOV lens which means more flash is needed
to get better night time images than the average 52° FOV lens from
market; that’s why 58pcs 60° IR LEDs are used on this camera.
But ensure these 58pcs IR LEDs can give enough flash to back the
wide angle lens up that high qualified AA batteries must be applied
accordingly to deliver enough amperage to power the illuminator
consistently in dark environments.
10. Programmed Date/Time can be saved in camera for 12 hours as
long as camera was powered 1 hour above.

10
11
3.6 Key features
1. 0.45 seconds trigger speed.
2. Wide lens model: 100 degrees FOV lens; 80 degrees PIR angle.
3. 12 MP/1080 P@30 FPS.
4. Programmable 5/8/12 Megapixel high-quality resolution.
5. 58 pcs invisible IR LEDs, offer 20 meters (65 feet) real night vision
distance.
6. Crystal clear day & night photo/video quality.
7. 1 photo burst per second to get full moving track of object.
8. Support multiple functions: adjustable PIR sensitivity, Multi-shot
(1–5 photos per trigger), programmable delay between motions,
Time Lapse, Timer, stamp of (camera ID, date/time, temperature,
moon phase) on every single photo.
9. Available operation temperature: -25° to 60°.
10. Built-in 2.0” TFT color screen.
11. With MMS/4G/SMTP/FTP function, camera can transmit photos to
1–2 preset mobile phones and 1–2 email per trigger.
12. SMS to realize various remote configurations.
13. SMS to enable camera to shoot a photo and send back instantly.
14. Optional small size (640 x 480) and large size (1920 x 1440)
Email/FTP photos.
15. APP available in IOS & Android APP store.

12
13
4. Operation List
4.1 Video/photo playback
Turn “Power Switch” to SETUP position to enter test mode, press
arrow button “↑” to enter Playback; press “←” and “→” for selection,
“OK” to play photo/video.
A) Press button “↑” again to exit.
B) In Playback Mode, press “MENU” button to delete files, or format
SD card; press “MENU” again to exit.
4.2 Delete
A) Delete one: delete selected photo/video. Press “OK” to choose,
press “↑” and “↓”for selection, “Yes” to confirm, “No” to exit to
previous page.
B) Delete All.
4.3 Format of SD Card
A) No
B) Yes: to format SD card via camera. Press “←” and “→” for selection,
“Yes” to confirm, “No” to exit to previous page.
4.4 Auto power off
In Test mode, camera will automatically power off in 3 mins if there
is no keypad touching. Please manually turn ON it as if you want to do
some further configuration.
Note! Camera stay in “Test” mode if camera is in Menu configuration
pages.

12
13
4.5 Operation menu
Test mode, Press “Menu” once to enter camera setting menu; to navi-
gate setting interface by pressing “←”, “↑”, “→”, or “↓”, press “OK” for
selection, “Menu” to exit to previous page, and “Menu” to switch alpha/
digits/ symbols.
Note! For some settings, user needs to press “Menu” to save & exit the
configuration after pressing “OK” to confirm; (Cam ID, Deley, Time
Lapse, Timer, Password)
Cam ID
Select “ON”, press “OK”, to set 4 digits/alphabets for each camera.
Such function can help user to identify photos are from where and
which camera.
Cam Mode
Photo, PIC+VIDEO, Video
1) Photo: camera shoots photos only based on configured Multi-shot &
Image Size.
2) “PIC+VIDEO”, camera shoots photo(s) first, then video upon same
trigger event based on Video Length/Size and Multi-shot/ Image
Size user configured.
3) Video: camera shoots videos only based on configured Video Length/Size.
Cam
4G 4G

14
15
IR LEDs
All/Part
All: All 58pcs IR LEDs will work in dark environment.
Part: Bottom 30pcs IR LEDs will be turned off.
Image Size
5 MP (2560 x 1 920), 8 MP (3264 x 2448), 12 MP (4 032 x 3024)
Night Mode
1) Min. Blur: Short exposure time to minimize motion blur for better
image quality; shortened IR flash range.
2) Max. Range: Longer exposure time to extend IR flash range for
better night vision; lower image quality.
3) Balanced: Combination of above 2 options.
Multi-shot
Programmable 1–5 photos per trigger.
Video size
1280 x 720, 640 x 480, 1 920 x 1 080
Video length
0– 59 secs.

14
15
PIR
Sensitivity
High, Middle, Low
Higher sensitivity is 1) more sensitive to movements by small-er
subjects; 2) longer detection distance; 3) easier for sensor to detect
difference between body heat and outdoor tempera-ture; 4) easier to
trigger camera to record. In high tempera-ture environment, body heat
of subjects and environment temperature is hard to tell by camera,
suggest settingHigh.
Delay
Select “ON”, press “OK”, to set a time interval that you desire between
photos/videos upon motion. This option avoid camera taking too many
photos or videos.
Example: Camera will wait 1 minute between photo/video recordings
with motion if pre-set time interval is 00:01:00
Configurable delay time: 00:00:05–23:59:59.
Note! Pls don’t turn ON Time Lapse and Delay simultaneously!
4G

16
17
Time lapse
Select “ON”, press “OK”, to set the interval; PIR sensor of camera will
be turned off; camera will shoot pics or video clips automatically upon
the interval user set.
Configurable interval: 00:00:05–23:59:59.
Note! Pls don’t turn ON Time Lapse and Delay simultaneously!
Timer
Select “ON”, press “OK”, to set the beginning time and end time (hour/
minute); camera will only work during the time period user set.
i.e.: 15:00 – 18:00; camera only works during 15:00 – 18:00.
4G
4G Switch
4G function can be turned off.
SIM Auto Match
1) Camera will automatically enter MMS &4G setups when the SIM
card is inserted.
2) If ”SIM Automatch failed, pls enter setups manually” pops up on
screen, pls switch “SIM Auto Match” to “Manual” mode, then enter
MMS &4G setups in “Manual Setup”.

16
17
Manual Setup
Pls enter setups below manually in “Manual” mode if your local
operator can’t be automatically matched by camera itself.
MMS Setup
Pls contact your operator for URL/ APN/ IP/ Port (Username and
Password if required); and enter these info manually.
We’ll add the needed operator info into “SIM Auto Match” list
whenever we’re informed with the detail effective information.
1) Note! 1. With MMS setups added, camera can send photos to preset
phones/ email. If MMS is with wrong information entered, then
phones/ email accounts will not be able to receive photos from
camera.
2) Email box receive photos from camera via SMTP only when SMTP
is ON.
4G Setup
Enter your local operator’s 4G APN, and corresponding Username and
Password.
Note! Only with 4G setups added, can SMTP and FTP functions work.
Note! it’s not a must to enter Username and Password of APN. But some
operators may require this password access to enable GPRS function.
For details, pls contact your local operator.
MMS
ON/OFF
You can simply choose to allow pics to be sent to your phone number
via MMS by switch ON/ OFF MMS function here.

18
19
SMTP Setup
Camera comes with default SMTP setups; you only need to enter
receiving email accounts in “Send to”.
Pls finish setups below if you’d like to use your own SMTP server.
1) Enter your mailbox server IP i.e: Hotmail IP: smtp.live.com.
Gmail IP: smtp.gmail.com.
2) Enter your mailbox port: Port of most mailbox is 25; pls enter your
mailbox corresponding port.
3) Enter your mailbox password access.
Note!
A) SMTP only send photos to preset emails; if SMTP is with wrong
information entered, then emails will not be able to receive photos
from camera.
B) MMS stops sending photos to email when SMTP is set to work.
FTP Setup
1) Enter your FTP server IP, i.e:
FTP Server IP: ftp://dianwan2008.gicp.net/
Enter: dianwan2008.gicp.net
Gmail IP: smtp.gmail.com
2) Enter your FTP server port: Port of most FTP server is 21; plz enter
your FTP server corresponding port.
3) Enter your FTP server password access.
Note! FTP only upload photos to preset FTP account; if FTP is with
wrong information entered, then FTP account will not be able to receive
photos from camera. Send to:
Phone: Enter recipients’ phone numbers (1–2)
Email: Enter recipients’ email accounts(1–2)

18
19
SIM PIN
You can ignore description below if your SIM has been activated
already.
Phase “Pls input PIN-Code” will not pop up after signal search if your
SIM is activated.
1) Camera will check if inserted SIM card is activated during signal
search in “Test” mode.
2) If SIM is not activated, “Pls input PIN-Code” will pop up on screen
after signal search.
3) Then “SIM PIN” will turn to be configurable in “4G” page of Menu;
4) Enter PIN code in “SIM PIN”; camera will auto power off. Camera
will activate SIM card automatically during signal search when you
restart the camera after you enter the PIN code.
Note!
1) “Pls input PIN-Code” will pop up again if wrong PIN code is entered.
2) Pls re-try your PIN code as if you see “Pls input PIN-Code” after
signal search.
3) SIM is normally limited to be activated 3 times; it’ll be locked if PIN
code entered are all wrong during these 3 times trial. So we suggest
you to double confirm your PIN code before you try again.
4) Pls insert SIM card into your phone to unlock it by using its PUK code
after 3 times trial of activation based on steps above.

20
21
SMTP/ FTP Pic size
Pictures sent via SMTP and FTP are in optional size as 640 x 480,
or 1920 x 1 440.
Note!
1) Camera will only send photos to preset phone numbers via MMS.
2) Camera will only send photos to preset email(s) via MMS if SMTP is
not configured.
3) Camera will only send photos to preset email accounts via SMTP
(GPRS) if SMTP is set.
Max Num/Day
Default: unlimited.
Optional: 1–99, i.e: user chooses 50, then cameras will only send 50 pics
every day. All the rest photos will only be stored in SD card.
SMS Ctrl
1) By Trigger: (Suggest for AA battery power). Camera will only be able
to change & save setups remotely when camera is triggered to shoot
photos/ videos.
2) All the Time: (Suggest using when Power adapter connected as this
option will consume huge battery power.) Camera GPRS module
stand-by all the time; so camera setups can be changed and saved
whenever you sent the remote SMS setup commands.
Daily Report
1) OFF
2) ON: Choose ON to enter to set up a time when you want camera to
send you the Daily Report.
Contents contain in Daily Report: Device IMEI Number, CSQ (Signal
Strength): 0–31, Camera ID, Temperature, Date & Time, Battery Left
Volume, SD Card Info, Total Pics Taken by Cam, Pics Sent by Cam.
