Huntington 24025HNT User manual

Outdoor Gas Barbeque/Grill
Gril À Gaz
Assembly Manual and Parts List
Manuel De Montage et Liste De Pieces
1-800-387-8643
FOR OUTDOOR USE ONLY
UTILISER À L'EXTÉRIEUR SEULEMENT
MADE IN USA
FABRIQUÉ EN USA
Onward Manufacturing Company (LTD)
Canada: 585 Kumpf Drive
Waterloo, ON N2V1K3
USA: 1 Fiesta Drive
Dickson, TN 37055-7716
SP5560-37 Rev B
www.omcbbq.com
30030HNT
24025HNT 24025HNTW
24025
(4) (2) (2)
30030
1
2
(2) (2)
(4)
3
4
(2) (2) (2)
(2)
5
6
A
A
A
B
C
!
7
8
A
(2)
(1)
(2)
9
10
11
12
(2)
A
13
14
ITEM # PART
#
DESCRIPTION DESCRIPTION 24025HN
T
24025HNT
W
30030HN
T
1 SM5010-1B CASTING TOP COUVERCLE DU GRILL 1 1 -
SM51A-1B --1
2 SM43-2B CASTING BOTTOM FOND DU FOYER 1 1 -
SM5003-2B --1
3 10081-F607 NAMEPLATE PLAQUE D'IDENTIFICATION 1 1 1
4 SP5021-3 GRID-WARMING RACK GRILLE 1 1 -
SP5022-3 --1
5 SP124A-3 GRID GRILLE 1 1 -
SP43A-3 --1
6 SM5072-9 FLAV-R-WAVE FLAV-R-WAVE 1 1 1
7 SM191A-12 BURNER ASM ENSEMBLE DE BRULEUR 1 1 -
SM190A-12 --1
8 SP5016-20 ELECTRODE ELECTRODE 1 1 1
9 SP5038-19B LID HANDLE POIGNEE 1 1 1
10 SP5001-40 CASTING STANDOFF SUPPORT DE GUIDON 2 2 2
20 SM5401-42B CONTROL COVER PANNEAU DE CONTROLE 1 1 1
21 SP5124-4 CONTROL ASM LP SOUPAPE 1 1 -
SP5130-4 --1
22 10114-12 HOSE & REGULATOR LP - QCC1 YUYAU ET REGULATEUR PL - QCC1 1 1 1
23 SP11-7 CONTROL KNOB BOUTON DE CONTROL 2 2 2
24 10342-21 IGNITOR ALLUMEUR 1 1 1
30 SM5069-9 HEAT SHEILD PROTECTION LA CHALEUR 1 1 1
32 SM5038-8B BENT LEG JAMBE COUDÉE 4 4 4
35 SM5397A-42B SUPPORT CASTING LEFT SUPPORT DU FOYER GAUCHE 1 1 1
36 SM5398A-42B SUPPORT CASTING RIGHT SUPPORT DU FOYER DROIT 1 1 1
39 SM5004A-6B BRACE - UPPER REAR SUPPORT ARRIERE 1 1 1
40 10711-E401R BASE BASE 1 1 1
46 SM5066-6B BRACKET - CYLINDER LP SUPPORT DU RESERVOIR PL 1 1 1
47 SP21-6 CYLINDER CLAMP CYLINDER DE SERRAGE 1 1 1
50 10711-T451B SHELF - SIDE PLANCHETTE LATERALE 2 2 -
30260130 --2
54 10956-E601 FRONT PANEL PANNEAU AVANT - 1 1
55 SP5018-18 SCREW #10 VIS #10 - 2 2
56 10892-608 WHEEL ROUE 2 2 2
77 S15111 GREASE CUP HOLDER PORTE CONTENANT A GRAISSE 1 1 1
78 11494-148 LEG PLUG PLUG JAMBE 2 2 2
80 SP25-16 1/4-20 WING NUT ECROU PAPILLON 1/4-20 2 2 2
81 Y-11560 BOLT 1/4-20 x 1 1/2 BOULON 1/4-20 x 1 1/2 8 8 8
83 SP5021-18 CARRIAGE BOLT 1/4-20 x 5/8 BOULON 1/4-20 x 5/8 1 1 1
85 Y-11214 TINNERMAN CLIP CLIP TINNERMAN 2 2 2
88 Y-11598 WING NUT 1/4-20 ECROU PAPILLON 1/4-20 1 1 1
91 Y-11968 SCREW 3/8-16 x 1 3/4 VIS 3/8-16 x 1 3/4 2 2 2
92 Y-12285 NUT 3/8 ECROU 3/8 2 2 2
93 Y-29320 SCREW 10-24 x 1 3/4 VIS 10-24 x 1 3/4 2 2 2
94 32010190 SCREW 10-24 x 1/2 VIS 10-24 x 1/2 2 2 2
95 Y-29304 SCREW 10-24 x 3/8 VIS 10-24 x 3/8 2 2 2
96 S21061 WING NUT 10-24 ECROU PAPILLON 10-24 2 2 2
97 10240-13 PIN GOUPILLE 2 2 2
98 S21233 COTTER PIN GOUPILLE 2 2 2
99 SP5007-15 CLIP CLIP 1 1 -
SP5004-15 --1
101 SP23-16 NUT 10-24 ECROU 10-24 2 2 2
1
3
10
9
94
7
77
39 46
47
30
2
80
80
32
32
40
98
81
54
81
21
78
97
32
81
35
36
55
32
50
6
5
4
88
83
93
8
24
22
95
20
81
92
91
81
85
96
99
50
55
101
23
50
56
