Husqvarna 968999254 / iZ4217TSKAA User manual

Parts manual Models:
968999254 / iZ4217TSKAA
968999255 / iZ4817TSKAA
968999256 / iZ4821TKAA
968999257 / iZ5223TKAA
968999258 / iZ5223TKOA
968999259 / iZ6123TKAA
MANUAL NO. 539110841 REV. 05 (03/16/05)

2
MODELNUMBER _______________________________
SERIALNUMBER _______________________________
DATE PURCHASED _____________________________
DEALER ADDRESS _____________________________
NOTES:
©2005 Husqvarna. All rights reserved.
Beatrice, NE. Printed in U.S.A.

3
SECTION
PAGE
HYDRAULICASSEMBLY(TL).......................................................................................................... 4
MODELS:968999256, 968999257,968999258, 968999259
HYDRAULICASSEMBLY(TE)- MODELS:968999254, 968999255 ................................................. 5
FRAMEASSEMBLY ........................................................................................................................ 6 - 7
SEATASSEMBLY-MODELS:968999256,968999257,968999258, 968999259 ............................. 8
SEATASSEMBLY- MODELS:968999254,968999255 ..................................................................... 9
KAWASAKIENGINEASSEMBLY-MODELS:968999256, 968999257,968999259 ........................ 10
KAWASAKI17HP ENGINEASSEMBLY- MODELS: 968999254,968999255................................. 11
KOHLERENGINEASSEMBLY-MODEL: 968999258 ..................................................................... 12
MOTIONCONTROLASSEMBLY...................................................................................................... 13
PARK BRAKEASSEMBLY(TL) -MODELS:968999256,968999257,968999258, 968999259......... 14
PARK BRAKEASSEMBLY(TE)- MODELS:968999254,968999255 .............................................. 15
CASTERARM
MODELS:968999254, 968999255,968999256, 968999257,968999258 ...................................... 16
CASTERARM
MODEL: 968999259..................................................................................................................... 17
42” DECKASSEMBLY..................................................................................................................... 18 - 19
48” DECKASSEMBLY..................................................................................................................... 20 - 21
52” DECKASSEMBLY..................................................................................................................... 22 - 23
61” DECKASSEMBLY..................................................................................................................... 24 - 25
DECK LIFTASSEMBLY ................................................................................................................... 26
WIRINGASSEMBLIES .................................................................................................................... 27
DECALASSEMBLY......................................................................................................................... 28
LIFTPEDAL ..................................................................................................................................... 29
ROPS .............................................................................................................................................. 30
ACCESSORIES ............................................................................................................................... 31 - 38
WIRINGDIAGRAMS ........................................................................................................................ 40 - 41
PARTSDESCRIPTION ..................................................................................................................... 42 - 50
CONTENTS
NOTE: ALLFASTENERSAREGRADE5 UNLESSOTHERWISE SPECIFIED.

4
HYDRAULICASSEMBLY (TL)
REF.
REF.
MODELS: 968999256, 968999257, 968999258, 9689992259
539 10 68-96 (x 4)
539 10 31-19 (x 8)
539 10 23-96 (x 4)
539 10 31-15 (x 4)
539 10 31-19 (x 8)
539 10 12-37 (x 4)
539 10 31-16 (x 4)
539 11 06-49 (x 2)
539 11 08-37
539 10 31-16 (x 4)
539 10 12-37 (x 4)
539 10 31-19 (x 8)
539 10 68-96 (x 4)
539 10 31-19 (x 8)
539 10 23-96 (x 4)
539 10 31-15 (x 4)
539 10 31-18 (x 8)
539 10 12-38 (x 5)
539 10 31-17 (x 6)
539 99 05-46
539 10 68-87
539 10 27-17 (x 4)
539 10 11-77 (x 2)
539 99 07-30
539 10 31-17 (x 6)
539 10 12-38 (x 5)
539 10 31-18 (x 8)
539 11 18-14
539 97 69-79
539 99 06-13
539 99 05-88539 10 32-56
539 99 05-46 (x 4)
539 99 05-17
539 10 13-31
539 10 22-36
539 10 34-27
539 97 69-98
539 99 05-50
539 10 34-33
539 99 05-82 (x 4)
539 10 43-88
539 97 66-95
539 97 66-88
539 10 31-18 (x 8)
539 10 51-68
539 10 12-02
539 10 50-24
539 99 05-80 (x 6)
539 99 05-98 (x 8)
539 10 47-22
539 10 26-06
539 10 33-16
539 97 69-78 (x 8)
539 99 05-80 (x 6)
539 99 00-72 (x 2)
539 10 69-33
539 99 00-52 (x 2)
539 10 11-65
539 10 31-18 (x 8)
539 10 12-38 (x 5)
539 10 31-17 (x 6)
539 10 11-76

5
HYDRAULICASSEMBLY (TE)
MODELS: 968999254, 968999255
539 10 68-96 (x 4)
539 10 68-96 (x 4)
539 10 31-19 (x 8)
539 10 12-37 (x 4)
539 10 31-16 (x 4)
539 10 31-18 (x 8)
539 11 08-37
539 10 12-38 (x 5)
539 10 31-17 (x 6)
539 10 31-18 (x 8)
539 99 05-46 (x 4)
539 10 11-77 (x 2)
539 10 27-17 (x 4)
539 99 05-82 (x 4)
539 10 68-87
539 97 69-79
539 99 06-13
539 10 32-56 539 99 05-88
539 99 07-30
539 99 05-17
539 10 13-31
539 10 22-36
539 10 34-27
539 97 69-98
539 99 05-50
539 10 34-33
539 99 05-46
539 10 43-88
539 97 66-95
539 10 47-22
539 10 33-16
539 10 26-06
539 11 18-14
539 11 06-49 (x 2)
539 10 31-19 (x 8)
539 10 23-96 (x 4)
539 10 31-15 (x 4)
539 10 31-17 (x 6)
539 10 12-38 (x 5)
539 10 31-18 (x 8)
539 10 12-02
539 10 50-24
539 10 31-18 (x 8)
539 10 51-68
539 10 69-33
539 99 00-52 (x 2)
539 99 00-72 (x 2)
539 99 05-80 (x 6)
539 97 69-78 (x 2)
539 10 11-65
539 10 31-17 (x 6)
539 10 12-38 (x 5)
539 10 31-18 (x 8)
539 97 66-88
539 10 11-76

6
MAIN FRAME ASSEMBLY
REF.BATTERY
539 10 68-99
539 10 51-69 (x 2)
539 99 06-92 (x 27)
539 99 01-84 (x 6)
539 99 06-92 (x 27)
539 99 06-92 (x 27)
539 99 01-84 (x 6)
539 10 52-24
539 99 05-80 (x 10)
539 10 50-39 (x 4)
539 99 03-65 (x 5)
539 11 08-19 (x 2)
539 10 47-63 (x 2)
539 10 44-11 (x 2)
539 10 25-87 (x 5)
539 99 02-09 (x 6)
539 99 06-92 (x 27)
539 99 06-92 (x 27)
539 10 69-41
539 99 06-92 (x 27)
539 99 02-09 (x 6)
539 99 07-17 (x 10)
539 10 44-11 (x 2)
539 11 15-73
539 97 77-78 (x 3)
539 99 06-92 (x 27)
539 99 07-17 (x 10)
539 97 69-78 (x 6)
539 11 10-98
539 97 69-98 (x 2)
539 10 26-19 (x 2)
539 97 69-34 (x 10)
539 11 08-06 RIGHT
539 10 41-97 (x 2)
539 10 25-19 (x 2)
539 99 03-33 (x 2)
539 10 41-99 (x 2)
539 10 25-02 (x 6)
539 99 06-92 (x 27)
539 10 28-45 (x 8)
539 99 06-92 (x 27)
539 99 07-17 (x 10)
539 99 02-09 (x 6)
539 11 08-07 LEFT

7
MAIN FRAME ASSEMBLY
539 10 80-16
539 99 03-62 (x 4)
539 99 00-52 (x 10)
539 99 05-98 (x 12)
539 99 04-11 (x 2)
539 10 27-33
539 10 17-68
539 10 75-41
539 11 11-47
539 97 69-77 (x 4)
539 10 32-75
539 97 69-34 (x 10)
539 99 01-87 (x 2)
539 99 06-92 (x 27)
539 10 55-27
539 10 55-27 RIGHT TANK
539 91 22-22 (x 6)
539 10 52-81 TO ENGINE
539 10 26-79
539 10 55-30 LEFT TANK
539 10 61-88 (x 2)
539 99 05-98 (x 4)
539 99 00-52 (x 10)
539 99 05-80 (x 4)
539 10 12-02
539 10 50-24
539 11 08-15
539 99 07-17 (x 10)
539 97 69-34 (x 10)
539 11 08-14
539 10 44-10 RIGHT
539 10 44-09 LEFT
539 91 22-22 (x 6)
539 10 26-50 (x 2)
539 11 08-13 (x 4)
539 10-69 59
539 10 45-25
539 99 03-65

8
SEATASSEMBLY
MODELS: 968999256, 968999257, 968999258, 968999259
539 11 20-35
RIGHT
539 11 20-37
539 11 20-36 LEFT
539 11 19-46
539 11 06-44
539 99 08-70 (x 2)
539 11 06-46 539 11 06-45
539 99 07-17 (x 4)
539 99 03-65 (x 5)
539 11 08-19 (x 2)
539 11 08-16
539 11 10-26 .........1......SEAT BELT (NOT SHOWN0
539 10 87-45 .........1......SWITCH/SNAPMOUNTKIT(NOTSHOWN)
539 11 14-34 .........1......BACK,HARDPLASTIC PREM SEAT (NOTSHOWN)
539 11 20-34 (x 2)
Torque 49-55 ft./lbs.

9
SEATASSEMBLY
MODELS: 968999254, 968999255
539 10 87-44
539 11 06-44
539 99 08-70 (x 2)
539 11 06-46
539 11 08-21
539 11 06-45
539 10 01-43 (x 2)
539 10 75-23
539 99 08-39 (x 2)
539 10 25-93 (x 4) 539 10 44-11 (x 4)
539 99 03-65 (x 5)
539 11 08-19 (x 2)
539 11 10-26 ....................... 1 .......SEAT BELT(NOTSHOWN)
539 10 43-92 ....................... 1 .......SEAT HARNESS (NOTSHOWN)
539 97 68-56 ....................... 1 ....... WIRE TIE (NOT SHOWN)

10
KAWASAKI ENGINE ASSEMBLY
TOFUEL
FILTER
TOFUEL
VALVE
TO BATTERY
TO STARTER
CHAMFERSIDE UP
TOWARDENGINE
PULLEYSIDE DOWN
WHITE
VIOLET GRAY
GRAY
WHITE
VIOLET
MODELS: 968999256, 968999257, 968999259
539 99 02-47
TORQUETO
50 FT./LBS.
539 10 72-71 (x 10)
539 99 07-17 (x 20) 539 99 06-92 (x 6)
539 99 07-17 (x 20)
539 99 07-17 (x 20)
539 10 69-57 (x 2)
539 10 69-57 (x 2)
539 99 02-09 (x 6)
539 99 07-17 (x 20)
539 99 07-17 (x 20)
539 10 98-67
539 97 69-78 (x 5)
539 99 00-72 (x 2)
539 99 00-53 (x 2)
539 10 17-14
539 99 07-17 (x 20)
539 10 68-19
539 99 06-69 (x 4)
539 10 52-81
539 99 06-92 (x 6)
539 99 06-92 (x 6)
539 99 02-09 (x 6)
539 10 69-61 (x 4)
539 10 69-62
539 10 69-61 (x 4)
539 10 44-15
539 10 56-37
539 91 27-57
539 10 69-92
539 10 56-37
GRAY
539 99 11-20
539 10 23-35
539 10 68-80

11
KAWASAKI 17 HP ENGINE ASSEMBLY
TOFUEL
FILTER
TOFUEL
VALVE
TO BATTERY
TO STARTER
CHAMFERSIDE UP
TOWARDENGINE
PULLEYSIDE DOWN
MODELS: 968999254, 968999255
WHITE
VIOLET GRAY
GRAY
WHITE
VIOLET
GRAY TORQUETO
50 FT./LBS.
539 10 72-71 (x10)
539 10 72-71 (x10)
539 10 69-57 (x2)
539 10 69-57 (x2)
539 10 52-81
539 10 98-67
539 99 02-09 (x6)
539 10 69-61 (x4)
539 99 06-92 (x6)
539 99 06-92 (x6)
539 10 23-35
539 10 69-61 (x4)
539 99 07-17 (x20)
539 99 07-17 (x20)
539 99 06-92 (x6)
539 99 07-17 (x20)
539 10 69-62
539 99 07-17 (x20)
539 97 69-78 (x5)
539 99 07-17 (x20)
539 99 02-09 (x6)
539 99 06-69 (x4)
539 10 17-14
539 99 00-53 (x2)
539 99 00-72 (x2)
539 10 56-37
539 10 68-19
539 10 56-37
539 91 27-57
539 10 69-92
539 10 56-37
539 99 02-47
539 99 11-20
539 10 58-04

12
KOHLER ENGINEASSEMBLY
TOFUEL
FILTER
TOFUEL
VALVE
TOENGINE
CHAMFERSIDE UP
TOWARDENGINE
PULLEYSIDE DOWN
WHITE
VIOLET
RED
RED WHITE
VIOLET
MODEL: 968999258
TORQUETO
50 FT./LBS.
539 10 72-71 (x10) 539 10 72-71 (x10)
539 10 69-57 (x2)
539 10 69-57 (x2)
539 99 07-17 (x20)
539 99 07-17 (x20)
539 99 06-92 (x6)
539 99 07-17 (x20)
539 99 07-17 (x20)
539 10 13-62
539 10 13-64
539 99 06-69 (x4)
539 10 68-19
539 99 07-17 (x20)
539 99 06-92 (x6)
539 99 02-09 (x6)
539 10 69-61 (x4)
539 10 69-61 (x4)
539 99 02-09 (x6)
539 99 06-92 (x6)
539 91 27-57
539 10 69-92
539 10 56-37 539 10 68-80
539 99 02-47
539 99 11-20
539 10 44-16
539 10 56-37
539 10 72-71 (x10)
539 10 49-80

13
MOTION CONTROLASSEMBLY
REF.
REF.BRAKE
LEVER WLDMT.
539 10 25-92 (x 2)
539 11 08-27
539 10 47-63 (x 2)
539 10 25-93 (x 4)
539 99 05-63 (x 4)
539 11 10-39
539 10 30-03
539 10 19-49 (x 2)
539 10 86-59
539 97 69-79 (x 6)
539 97 69-52 (x 4)
539 11 10-31
539 11 09-43 (x 4)
539 11 06-04 (x 2)
539 99 10-73 (x 2)
539 10 35-47 (x 2)
539 97 69-98 (x 2)
539 99 01-84 (x 7)
539 99 02-23 (x 6)
539 10 83-94
539 99 01-96
539 10 47-63 (x 2)
539 11 09-43 (x 4)
539 11 06-07 (x 4)
539 97 69-34 (x 4)
539 99 07-17 (x 4)
539 11 08-11 (x 2)
539 99 01-84 (x 7)
539 11 06-07 (x 4)
539 11 06-07 (x 4)
539 99 07-30 (x 6)
539 10 10-80 (x 2)
539 10 26-78 (x 2)
539 11 09-43 (x 4)
539 11 06-03 (x 2)
539 11 08-26
539 99 01-84 (x 7)
539 11 06-06 (x 2)
539 11 10-30
539 11 06-07 (x 4)
539 11 08-11 (x 2)
539 99 01-84 (x 7)
539 10 32-64 (x 2)
539 11 06-38 (x 2)
539 11 06-06 (x 2)

14
MODELS: 968999256, 968999257, 968999258, 968999259
PARK BRAKEASSEMBLY (TL)
539 99 03-65 (x 4)
539 97 77-03 (x 4)
539 97 74-65 (x 2)
539 10 69-71
539 99 01-55 (x 10)
539 97 74-65 (x 2)
539 97 77-03 (x 4)
539 99 03-65 (x 4)
539 10 50-36
539 10 86-16
539 10 11-51
539 10 86-19
539 10 50-29
539 97 69-78 (x 2)
539 99 05-80 (x 2)
539 92 37-87
539 97 69-79
539 99 06-13
539 99 06-37
539 99 03-65 (x 4)
539 97 77-03 (x 4)
539 97 74-65 (x 2)
539 99 01-55 (x 10)
539 10 69-72 (x 2)
539 10 28-21 (x 2)
539 99 05-17 (x 4)
539 99 05-17 (x 4)
539 10 28-17 (x 2)
539 99 01-55 (x 10)
539 10 13-32 (x 8)
539 10 69-89 (x 2)
539 11 08-23 (x 2)
539 10 14-68 (x 2)
539 10 42-88 (x 2)
539 99 02-58 (x 4) 539 10 13-31 (x 4)
539 99 06-22 (x 4)
539 10 69-90 (x 2)
539 10 67-91
539 99 01-18
539 99 05-17 (x 4)
539 97 69-98 (x 2)
539 10 35-47
539 99 03-65 (x 4)
539 10 27-46 (x 4)
539 10 68-73 (x 2)
539 99 02-54 (x 4)
539 10 11-73 (x 8)
539 10 28-22 (x 2)
539 10 24-15 (x 2)
539 10 69-69
539 99 05-63 (x 4)
539 10 27-97 (x 2)
539 97 69-79 (x 4)
539 10 68-83 (x 2)(COMPLETE)
(FOR MODELS: 986999256,
968999257, 968999258)
539 10 74-31
(FOR MODELS: 986999256,
968999257, 968999258)
539 10 59-83
539 10 54-86
(FOR MODEL 968999259)
539 91 22-34
539 10 88-81(x 2)(COMPLETE)
(FOR MODEL 968999259)

15
PARK BRAKEASSEMBLY (TE)
MODELS: 968999254, 968999255
539 10 86-14 (x 2)
(COMPLETE)
539 10 74-32
539 91 22-34
539 10 93-44
539 99 06-37
539 99 06-13
539 97 69-79 (x 5)
539 99 05-80 (x 2)
539 97 69-78 (x 2)
539 10 50-29
539 10 11-51
539 92 37-87
539 10 86-16
539 10 50-36
539 99 03-65 (x 2)
539 97 77-03 (x 2)
539 97 74-65 (x 2)
539 99 01-55
539 10 86-37
539 97 74-65 (x 2)
539 99 03-65 (x 2)
539 99 05-63 (x 4)
539 10 27-97 (x 2)
539 97 69-79 (x 5)
539 97 69-79 (x 5)
539 10 27-97 (x 2)
539 99 05-63 (x 4)
539 10 86-21
539 97 77-03 (x 2)
539 10 13-31 (x 16)539 10 86-19
539 99 06-22 (x 8)
539 10 11-09 (x 2)
539 10 11-73 (x 4)
539 10 13-32 (x 8)
539 10 85-54 (x 2)
539 10 35-27 (x 2)
539 10 13-31 (x 16)
539 99 02-97 (x 2)

16
CASTERARM
MODELS: 968999254, 968999255, 968999256, 968999257, 968999258
539 10 25-35
539 10 28-52
539 10 28-89
539 10 25-43 (x 2)
539 10 14-74
539 99 08-39 (x 4)
539 10 01-43 (x 4)
539 10 69-86
539 10 25-43 (x 2)
539 10 28-51
539 10 45-71
539 10 28-55
539 10 13-31
539 10 45-72
(COMPLETE)
539 10 25-46 539 91 22-34
539 10 28-56
539 10 24-84 (x 2)
539 97 69-97
539 10 45-73

17
CASTERARM
MODEL: 986999259
539 10 25-35
539 10 28-89
539 10 28-52
539 10 25-43 (x 2)
539 10 14-74
539 99 08-39 (x 4)
539 10 01-43 (x 4)
539 10 83-31
539 10 25-43 (x 2)
539 10 28-51
539 10 45-71
539 10 28-55
539 10 13-31
539 10 45-72
(COMPLETE)
539 10 25-46
539 91 22-34
539 97 69-97
539 10 28-56
539 10 24-85 (x 2) BEARING
539 10 24-84 (x 2) END CAPS
539 10 45-73

18
NOTE:
TORQUE TO 90 FT/LBS
3 PLACES
42” DECK ASSEMBLY
NOTE:
TORQUETO
45 FT/LBS
3 PLACES
539 10 96-63 RIGHT
539 10 96-64 LEFT
539 11 07-36
539 99 06-92 (x 2)
539 11 07-31
539 99 03-65
539 99 06-92 (x 2)
539 10 76-27 (x 2)
539 10 32-57 (x 2)
539 10 32-57 (x 2)
539 11 07-35
539 99 05-17 (x 4)
539 97 69-79 (x 4)
539 10 32-58
539 10 32-95 (x 2)
539 99 05-82
539 99 05-17
539 10 13-31
539 10 32-56
539 99 05-50
539 97 69-98 (x 4)
539 10 32-30
539 10 34-27 539 99 08-39 (x 8)
539 10 25-82 (x 8)
539 10 26-41 (x 4)
539 10 11-75 (x 8)
539 10 11-75 (x 8)
539 97 69-98 (x 4)
539 10 87-66 (x 3)
539 99 02-47 (x 3)
539 10 65-04 (x 3)
539 10 72-76 (x 3)
539 99 08-39 (x 8)
539 99 07-17 (x 20)
539 11 15-60
539 10 22-43
539 10 34-33
539 10 87-73 (x 3)
539 99 06-27 (x 12)
539 10 33-03 (x 2)
539 10 26-12 (x 2)
539 10 84-50
539 10 87-54 (x 2)
539 10-87 58 (x 2)
539 97 73-26
539 10-87 58 (x 2)
539 10 87-54 (x 2)
539 10 84-49
539 10 87-59
539 10 96-81 (x 3)
539 99 03-33 (x 3)
539 10 32-99 (x 3)
539 10 25-82 (x 8)
539 11 13-75
539 10 96-60 (x 2)

19
42” DECK ASSEMBLY
539 10 26-43
539 10 27-54 (x 2)
539 10 26-98 (x 2)
539 99 05-17 (x 4)
539 97 69-79 (x 4)
539 11 08-32
539 97 69-34 (x 8)
539 99 07-17 (x 20)
539 99 07-17 (x 20)
539 99 07-17 (x 20)
539 97 69-34 (x 8)
539 97 69-34 (x 8)
539 99 01-88 (x 10)
539 99 01-88 (x 10)
539 99 01-88 (x 10)
539 99 01-88 (x 10)
539 11 16-23
539 11 16-25
539 10 55-32 (x 2)

20
NOTE:
TORQUE TO45 FT/LBS
3 PLACES
NOTE:
TORQUE TO 90 FT/LBS
3 PLACES
48” DECK ASSEMBLY
539 10 86-86 RIGHT
539 11 07-36
539 99 06-92 (x 2)
539 11 07-32
539 99 06-92 (x 2)
539 99 03-65
539 10 76-27 (x 2)
539 11 07-35
539 10 33-03 (x 2)
539 10 26-12 (x 2)
539 10 22-43
539 10 34-33
539 10 84-50
539 10 87-54 (x 2)
539 10 87-58 (x 2)
539 97 73-26
539 10 87-73 (x 3)
539 10 87-58 (x 2)
539 10 87-54 (x 2)
539 10 84-49
539 10 87-59
539 10 03-40 (x 3)
539 99 06-27 (x 12)
539 99 03-33 (x 3)
539 10 32-99 (x 3)
539 11 18-12
539 99 07-17 (x 21)
539 99 08-39 (x 8)
539 10 25-82 (x 8)
539 10 72-76 (x 3)
539 10 65-04 (x 3)
539 99 02-47 (x 3)
539 10 87-66 (x 3)
539 97 69-98 (x 4)
539 97 69-98 (x 4)
539 10 32-30
539 10 11-75 (x 8)
539 10 32-57 (x 2)
539 10 34-27
539 99 05-50
539 10 13-31
539 10 32-56
539 99 05-17
539 99 05-82
539 10 32-95 (x 2)
539 99 05-17 (x 5)
539 97 69-79 (x 5)
539 10 32-57 (x 2)
539 10 32-58
539 11 13-76
539 10 26-41 (x 4)
539 10 86-87 LEFT
539 10 96-60 (x 2)
