Husqvarna CTH126 Setup guide

581 06 00-02
ILLUSTRATED PARTS LIST
MODEL NO. 96051000803
CUSTOMER CATALOG NO. CTH126
PRODUCT NO. 960 51 00-08
47
47

2
6
2
1
3
11
4
10
5
9
8
7
wheel_art_1-tex
WHEELS AND TIRES
KEY PART
NO. NO. DESCRIPTION
11
9
1 581 57 81-01 Decal, Operators
2 581 62 73-01 Decal, Hood Logo
3 581 57 97-01 Decal, Warning Eng. Symbols
4 532 43 99-53 Decal, Hood Panel
5 581 57 96-01 Decal, Chassis Hot Muffler
8 532 44 25-48 Decal, Rpl
9 532 14 50-05 Decal, Battery Dnge/Poi
10 581 57 80-01 Decal, Saddle Brake Parking
11 581 57 94-01 Decal, Warning DFlect/Ctfingr
12 581 58 00-04 Decal, Mower V-Belt Schematic
12
41
8
22
5
10
13
3
5
KEY PART
NO. NO. DESCRIPTION
13 581 72 40-01 Decal, Brake/Clutch Symbol
17 532 43 74-10 Decal, BS Engine
- - 581 72 48-01 Decal, Bypass
- - 532 44 14-09 Pad, Footrest, LH
- - 532 44 14-10 Pad, Footrest, RH
- - 532 43 40-53 Manual Oper. Euro
- - 532 43 40-54 Manual Oper. Scand
- - 532 43 40-55 Manual Oper. E-Bloc
- - 532 43 40-56 Manual Oper. Baltic
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
1 532 05 91-92 Cap Valve Tire
2 532 06 51-39 Stem Valve
3 532 42 52-61 Rim Asm 6 x 3.25 Front
4 532 42 16-52 TubeFront13x5-6(ServiceItemOnly)
5 532 12 34-10 Tire F T 13 x 5.0 - 6
6 532 12 49-57 Fitting Grease (Front Wheel Only)
7 532 12 49-59 Bearing Flange (Front Wheel Only)
8 532 17 50-39 Cap Axle Blk 1 50 x 1 00
9 532 10 62-30 Tire R 16 x 6.5
10 532 00 71-54 Tube Rear (Service Item Only)
11 532 42 52-62 Rim Asm 8 x 5.375 Rear
- - 532 14 43-34 Sealant, Tire (10 oz. Tube)
17
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
DECALS
27
27

3
M
FUSE
STARTER
SOLENOID
BATTERY
REVERSE SWITCH (NOT IN REVERSE)
SEAT SWITCH (NOT OCCUPIED)
FULL BAG
IGNITION
UNIT
HOUR
METER
CHASSIS HARNESS
CONNECTOR (C1)
(MATING SIDE)
DASH HARNESS
CONNECTOR (C1)
(MATING SIDE)
FUEL
LINE
FUEL SHUT-OFF
SOLENOID
(IF SO EQUIPPED)
C1
S
M
B
G
L
2
3
1
6
A2
A1
M
SPARK
PLUGS GAP
(2 PLUGS ON
TWIN CYL. ENGINES)
(OPTIONAL)
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE RE-INSTALLED TO
PROPERLY SECURE YOUR
WIRING.
SCH19
IGNITION SWITCH
CIRCUITPOSITION
OFF
B+A1
RUN/OVERRIDE
B+S+A1START
M+G+A1
B+A1RUN
“MAKE”
L+A2
PTO SWITCH
(DISENGAGED)
BLACK
BLACK /WHITE
BLUE
BLUE BLACK
GREEN
BLACK
YELLOW
BLK/WHT
BLACK
BLK/WHT
DER
WHITE
WHITE
GRAY
GRAY
BLACK
YELLOW
POWER OUTLET
(OPTIONAL)
12V
BLACK
BLUE
BLACK
BROWN
HEADLIGHTS
LIGHT SWITCH
ORANGE
CLUTCH/BRAKE
(PEDAL UP)
WHITE
GREEN
GREEN
BLUE RED
BAG PRESENT SWITCH
(BAG ATTACHED)
SHORTING CONNECTOR
BAG FULL SWITCH
(NOT FULL)
9
BUZZER
BLACK
BLACK
BLACK
BLUE BLACK
5
6
C1
4
C1
BROWN
8
C1
DER RED
1
2
3
654
98
123
456
89
ELECTRIC CLUTCH
BLACKRED
REGULATOR STATOR
28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)
CHARGING SYSTEM OUTPUT
9-16AMPDC@3600 RPM
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
SCHEMATIC
38
38

4
30
33
34
22
79 21
26
40
71
16
S04S
90
28
55
With Service Minder Option
4646
2
43
27
99
25
108
107
106
29
141
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
ELECTRICAL
32
32

5
KEY PART
NO. NO. DESCRIPTION
1 532 16 34-65 Battery
2 874 76 04-12 Bolt Hex Head 1/4-20 x 3/4
8 532 41 97-91 Box Battery
16 532 17 61-38 Switch Interlock Push-In
21 532 40 02-52 Harness Socket Light w/4152J
22 532 00 41-52 Bulb Light
25 532 41 66-94 Cable Starter
26 532 17 51-58 Fuse
27 873 51 04-00 Nut Keps Hex 1/4-20 unc
28 532 42 16-86 Cable, Ground
29 532 40 15-45 Switch, Seat
30 532 19 33-50 Switch, Ign
33 532 41 19-35 Key/Chain
34 532 11 07-12 Switch Light/Reset
40 532 42 95-33 Harness Ign. Dash
43 532 19 25-07 Solenoid
46 532 40 17-63 Gauge
50 532 17 46-51 Switch PTO
55 817 06 05-12 Screw Thdrol 5/16-18 x 3/4 TYTT
71 532 42 94-12 Harness Ign. Chassis
79 532 17 52-42 Socket Asm. Bulb
90 532 43 53-95 Cover Terminal
99 817 67 04-12 Screw 1/4-20 x 3/4
106 532 17 48-14 Nut Speed 1/4-20
107 532 42 10-61 Switch Snapmount No #2
108 532 42 10-62 Switch Snapmount NC
141 532 41 69-77 Kit T2 ROS
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
ELECTRICAL
32
32

6
137
177 175
130
151
234
214
234
205 202 25
203
206
14
297
191
204
15 130
130
18
176
176
182
130
150
176
5
137
3
238
239
52
217
189
189
152
68
213
218
228
228
194
288
180
58
189
189
chassis-tex_TEX LT HUSQ_61_r1
282
162
287
162
308
159
309
159
159
311
284
310
283
199
282
37
282
194
194
36
36
68
68
68
68
183
183
236
236 34
235
235
319
159
159
62
334
118
119
118
119
306
125
146
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
CHASSIS AND ENCLOSURES
39
39

7
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
3 581 05 63-01 Logo
5 532 43 89-66 Dash
14 532 44 12-67 Hood
15 532 44 14-28 Lens LH
18 532 44 13-68 Grille
25 532 44 14-27 Lens RH
34 580 91 09-01 Plate Engine
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 44 14-19 Fender
52 873 68 05-00 Nut Crown Lock 5/16
58 532 41 22-80 Drawbar Upper
62 872 11 06-08 Bolt 3/8-16 x 1 Gr. 5
68 817 49 05-08 Screw Thdrol. 5/16-18 x 1/2
125 581 68 48-01 Clip Fuel Line
118 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga.
119 873 68 06-00 Nut Crownlock 3/8-16 unc
130 532 41 63-58 Screw #10 x 0.750 BOS Thread
137 532 40 75-90 Bumper Dash
146 581 85 79-01 Bolt
150 532 40 66-62 Air Duct
151 532 40 78-07 Bracket Pivot
152 532 19 95-35 Shield Browning
159 817 00 06-12 Screw Hex Wsh Thdr 3/8-16 x 3/4
162 532 14 24-32 Screw Hex Wsh. Hi-Lo 1/4 x 1/2 unc
175 532 19 94-72 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8
177 532 19 52-28 Bushing Steering
180 532 41 46-85 Chassis
182 532 40 71-76 Dash Lower
183 874 52 05-20 Bolt 5/16-18 x 1-1/4
189 817 00 05-12 Screw 5/16-18 x 3/4
191 532 41 65-01 Insert Reflective RH
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
199 532 41 87-39 Plate Deck Lift
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
CHASSIS AND ENCLOSURES
39
39
202 532 44 13-42 Vent Side Hood RH
203 532 44 13-43 Vent Side Hood LH
204 532 44 13-75 Vent Top Hood
205 532 44 13-44 Skirt Side RH
206 532 44 13-45 Skirt Side LH
213 874 76 05-12 Bolt 5/16-18 x 3/4
214 532 19 91-45 Clip Retainer
217 532 40 91-67 Rod Pivot Hood
218 532 19 63-95 X-Piece Hood Stop
228 532 19 51-61 Stud Fastener
234 532 40 47-42 Bumper Hood
235 532 40 61-29 Spacer Fender
236 873 93 05-00 Nut Lock 5/16-18 unc
238 532 44 13-74 Trim
239 532 40 48-83 Clip Tinnerman
282 532 41 41-10 Clip Retainer
283 532 44 05-31 Console Deck Lift
284 532 44 05-30 Console Shift
287 817 60 04-06 Screw Hex Washead 1/4-20 x 3/8
297 532 40 66-65 Insert Reflective LH
306 873 90 06-00 Nut Lock
308 532 17 18-77 Bolt 5/16-18 unc x 3/4
309 532 43 02-46 Backplate Bagger SRD
310 532 44 66-36 Bracket Hangar Bag LH
311 532 44 66-37 Bracket Hangar Bag RH
319 532 17 46-62 Bracket Actuator Bagger
334 532 44 25-37 Bracket Engine

8
185
161
185
51
231
170
drive-tex_T2_pedal_28_r1
186
64
188
35
184
167
160
42
221
210
211
166
211
214
215
153
153
222
29
15
159
163
189
49
187
50
51
52
51
17
56
114
122
121
80
125
125
216
143
183
205
205
2
1
2
37
33
73
73 99
116
159
116
263
268 275
197
196
190
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
DRIVE
40
40

9
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 – – – – – – Transaxle, Hydro Gear T2-BABC-
1X2B-1GX1 (421645) (Order parts
from transaxle manufacturer.)
2 532 12 35-83 Key Square
15 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga.
17 532 19 72-96 Spring, Brake
29 532 42 32-39 Rod, Brake
33 812 00 00-01 Ring E
35 532 40 10-31 Rod, Brake, Park
37 532 12 17-49 Washer 25/32 x 1-1/4 x 16 Ga.
42 532 12 48-72 Cover, Foot Pedal
49 872 11 06-14 Bolt
50 532 19 43-27 Pulley Idler Flat
51 873 90 06-00 Lock Nut 3/8-16
52 532 19 43-26 Idler V-Groove Offset
56 532 12 59-07 V-Belt, Drive
64 532 19 78-65 Shaft Asm. Pedal Brake Control
73 874 49 05-44 Bolt Hex 5/16-18 Gr. 5
80 581 55 07-01 Strap Torque
99 532 40 84-18 Rod Spring Bypass
114 873 80 05-00 Nut Lock 5/16-18 unc
116 873 90 05-00 Nut Lock Hex Flange 5/16-18
121 532 17 56-11 Bracket Strap Torque
122 872 01 05-20 Bolt 5/16-18 x 2.50
125 817 00 05-12 Screw 5/16-18 x 3/4
143 817 49 05-08 Screw THDROL 5/16-18 x 1/2
153 532 12 47-88 Retainer Spring 1"
159 876 02 04-12 Pin Cotter 1/8 x 3/4
160 532 16 94-84 Retainer Clip
161 532 10 57-09 Spring, Return, Clutch
163 532 41 33-22 Rod Control
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
DRIVE
40
40
166 532 42 91-64 Nut Push .625
167 532 40 52-57 Latch Brake Parking
170 532 41 34-30 Keeper Belt Centerspan
183 532 15 69-72 Spacer Axle
184 532 44 14-07 Handle Parking Brake
185 872 11 06-22 Bolt
186 532 19 43-21 Spacer Retainer
187 819 13 32-10 Washer
188 532 19 43-23 Link Clutch Ground Drive
189 532 19 43-17 Bellcrank Ground Drive
190 532 19 43-18 Keeper Bellcrank Ground Drive
196 817 00 06-16 Screw 3/8-16 x 1
197 532 19 58-04 Link Clutch Anti-Rotation
205 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
210 532 40 09-80 Rocker Asm. Pedal Control
211 532 12 01-83 Bearing Nylon
214 532 42 12-63 Pedal Pad Forward
215 532 41 94-82 Pedal Reverse
216 532 19 61-31 Bracket Pulley Idler
221 532 40 31-87 Retainer Spring Clip Handle
222 879 21 20-10 Washer 21/32 x 1-1/4 10 Ga.
231 532 40 72-87 Idler V-Groove 1.688" Offset
263 817 00 06-12 Screw Hexwsh THDR 3/8-16 x 3/4
268 532 18 24-02 Guard, Muffler
275 819 13 16-14 Washer

10
21
20
OPTIONAL EQUIPMENT
Spark Arrester
29
37
28
37
12
11
41
42
85
9
90
84
45
1
69 2
79
18
15
97
96
122
engine-tex_BS_32
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
ENGINE
24
24

11
KEY PART
NO. NO. DESCRIPTION
1 – – – – – – Engine BS Model No. 21R707-0006-B1 (585403801)
(Order parts from engine manufacturer.)
2 532 17 97-58 Muffler
9 532 19 43-19 Keeper Belt Engine
11 532 18 05-05 Clutch
12 532 19 43-38 Pulley Engine
15 581 28 99-01 Tank Fuel 1.5
18 532 43 02-20 Cap Asm
20 532 18 38-97 Control Throttle
21 532 41 63-58 Screw #10 x 0.750 BOS Thread
28 532 13 70-40 Fuel Line
29 532 13 71-80 Spark Arrester Kit
37 532 12 34-87 Clamp Hose
41 532 12 61-97 Washer 1-1/2 x 15-32 x .250
42 810 04 07-00 Washer Lock Hvy HLCL SPR 7/16
45 873 51 04-00 Nut Keps Hex 1/4-20 unc
69 532 16 52-91 Gasket
79 532 19 23-34 Screw Socket HD 5/16 - 18 x 75
84 817 06 06-20 Screw 3/8-16 x 1-1/4
85 532 17 39-37 Bolt Hex 7/16-20 x 4 Gr. 5-1.5
90 817 00 06-16 Screw 3/8-16 x 1
96 819 09 14-16 Washer 9/32 x 7/8 x 16 Ga.
97 817 67 04-12 Screw 1/4-20 x 3/4
122 532 42 19-22 Extension Drain Oil
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
ENGINE
24
24
Engine Power Rating Information
The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive Engi-
neers) code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance has been obtained and cor-
rected in accordance with SAE J1995 (Revision 2002-05). Torque values are derived at 3060 RPM; horsepower values are
derived at 3600 RPM. Actual gross engine power will be lower and is affected by, among other things, ambient operating
conditions and engine-to-engine variability. Given both the wide array of products on which engines are placed and the va-
riety of environmental issues applicable to operating the equipment, the gas engine will not develop the rated gross power
when used in a given piece of power equipment (actual “on-site” or net power). This difference is due to a variety of factors
including, but not limited to, accessories (air cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.), application
limitations, ambient operating conditions (temperature, humidity, altitude), and engine-to-engine variability. Due to manu-
facturing and capacity limitations, Briggs & Stratton may substitute an engine of higher rated power for this Series engine.

12
61
steering-tex_STDHRS_10_r1
19
60
59
58
5
62
15
14
13
13
53
8
70
68
69
16
28
28
13
22
64
4
15
14
35
6
74
9
8
74
7
9
87
67
67
66
74
74
6
2
63
63
57
63
1
21
71
72
33
45
20
26
122
122
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
STEERING ASSEMBLY
41
41

13
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 532 43 97-40 Wheel, Steering Husq SR
2 532 41 81-68 Axle Asm., Front
4 532 41 68-45 Spindle Asm., LH
5 532 41 68-46 Spindle Asm., RH
6 532 12 49-31 Bearing, Race Thrust Hardened
7 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
8 812 00 00-29 Ring, Klip #T5304-75
9 532 12 12-32 Cap, Spindle
13 532 12 17-49 Washer, 25/32 x 1-1/4 x 16 Ga.
14 810 04 06-00 Washer, Lock Hvy Hlcl Spr 3/8
15 873 54 06-00 Nut, Crown Lock 3/8-24 unf
16 532 42 93-73 Shaft Steering
19 532 19 47-29 Plate Steering
20 532 44 14-25 Boot, Steering
21 532 18 67-37 Adapter, Wheel Steering
22 532 42 05-37 Steering Support Lower
26 532 43 97-43 Insert, Wheel Steering Husq SR
28 817 00 06-12 Screw 3/8-16 x 3/4
33 810 04 05-00 Washer Lock 5/16
35 532 19 47-32 Gear, Sector Plate
45 819 11 38-12 Washer 11/32 x 3/8 x 12 Ga.
53 532 18 89-67 WasherHardened.793x1.637x.060
57 532 40 74-65 Bracket Upstop
58 532 19 47-47 Bolt Shoulder Sector Pivot CFM
59 532 19 47-48 Washer Thrust Sector Steering
60 873 97 10-00 Nut Flange Lock 5/8-11
61 532 19 47-40 Draglink, LH
62 532 19 47-41 Draglink, RH
63 817 00 05-12 Screw 5/16-18 x 3/4
64 532 19 98-49 Retainer Clip Spring Steering
66 871 02 07-48 Bolt Hex Fghd 7/16-14 x 3 Serr
67 532 19 47-37 Bushing PM Front Axle
68 873 90 07-00 Nut Lock Flange 7/16-14 Gr. 5
69 532 19 91-62 Washer 1.5 x .505 x .118
70 532 41 70-65 Bracket Deck Susp. Front
71 532 19 07-52 Shaft Extension Steering
72 532 42 89-82 Bolt Fin Hex 5/16-18 x 4 w/Patch
74 532 12 49-37 Bearing
122 532 44 49-62 Cap Gear Sector
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
STEERING ASSEMBLY
41
41

14
6
38
2
4
3
33
34
35
36
38
26
1
5
17
43
18
19
20
25
24
22
23
11
11 11
26
20
32
9
10 14
15
16
13
8
tex-deck_SRD_13_r2
27
73
42
42
29
74
72
11
76
80
80
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
MOWER DECK
44
44

15
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 532 44 20-48 Deck Weldment 30"Srd
2 532 19 51-61 Stud Fastner W/'D'anti-Rotation
3 873 90 05-00 Nut Lock Hex Flange 5/16 - 18
4 532 41 76-45 Bracket Clutch Cable
5 817 00 05-10 Bolt 5/16-18
6 532 41 88-63 Arm Susp Mower Rear Srd
8 532 42 02-52 Arm Idler 30"Srd
9 532 19 90-92 Spacer Retainer
10 817 00 06-16 Screw 3/8 - 16 x 1 Smgml Tap/R Blk
11 532 13 77-29 Screw Thd Roll 1/4 - 20 x 5/8
13 872 11 06-12 Bolt Carr Sh 3/8 - 16 x 1 - 1/2 Gr. 5
14 532 15 60-85 Keeper Belt Idler
15 532 14 67-63 Pulley Idler V-Groove Dim 4.25
16 873 90 06-00 Nut Lock FlG 3/8 - 16 unc
17 532 40 02-34 Nut Flange Lock Top
18 532 18 76-90 Washer Spacer Mandrel
19 532 11 04-85 Bearing Ball Mandrel
20 532 17 39-84 Screw Thd Roll Dod Pt Hex
22 532 17 58-20 Pulley Idler Flat
23 817 49 06-28 Screw Thdrol 3/8 - 16 x 1-3/4
24 819 13 20-12 Washer 13/32 x 1 - 1/4 x 12 Ga
25 532 42 02-53 Keeper Belt 30"Srd
26 532 42 02-55 Cover Mandrel Mwr 30"Black
27 532 41 92-71 V-Belt Drive
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
MOWER DECK
44
44
29 532 42 08-95 Hinge Pin
32 532 19 72-51 Spring Mower Drive
33 532 18 72-81 Housing Mandrel 4pt Service
34 532 19 28-72 Shaft Asm Mndrl N/Greaseable 38
35 532 41 92-74 Blade
36 532 19 30-03 Bolt/Washer Asm 7/16 - 20 unf
38 532 19 65-39 Bolt Shoulder
42 817 00 06-12 ScrewHexwshTHDR3/8-16 x 3/4BL
43 532 41 68-77 Pulley Mandrel 6 5 Pd 30"
72 532 41 72-36 Chute Upper SRD 30R
73 532 42 52-74 Chute Lower SRD 30R
74 532 12 46-70 Retainer Spring
76 532 41 55-98 Washout Port
80 532 42 30-62 Palnut 1/4
- - 532 19 28-70 Mandrel Assembly (Includes
Housing (key#33), Shaft Assembly
(key#34), and Bearing (key#19)
Only - Pulley/Nut/Washer And Blade
Bolt/Washers Not Included)
- - 532 44 42-69 Replacement Mower Complete

16
7
3
87
10
88
2
113
90 98
97
97
lift-tex_18_r4
91
87
100
89
87
89
101*
*Key 91 may be substituted for Key 101
2 532 42 20-27 Shaft Asm., Lift
3 532 19 52-31 Lever Asm., Lift RH
7 580 96 23-01 Grip, Lever
10 532 19 63-14 Spring Torsion
87 532 19 42-09 Pin Cotter 7/16 Bow Tie Lock
88 532 41 07-10 Spring Lift Assist
89 819 19 19-12 Washer Clear
90 532 19 42-08 Pin Cotter 5/16 Bow Tie Lock
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
91 532 19 51-81 Link Lift Susp Mower Rear
97 817 00 06-12 Screw 3/8-16 x 3/4
98 532 19 52-64 Link Lift Susp. Front Mower
100 873 93 06-00 Nut Centerlock 3/8-16
101 532 40 70-03 Link Asm. Lift Fixed
113 819 17 19-12 Washer 17/32 x 1-3/16 x 12 Ga.
KEY PART
NO. NO. DESCRIPTION
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
MOWER LIFT
45
45

17
2
6
1
40
10
37
37
21
21
3
41
7
8
7
8
seat-tex_7A-vgt
44
43
8
8
6
1 532 43 98-19 Seat
2 532 18 01-66 Bracket Pivot Fender
3 532 14 06-75 Strap, Asm Fender
6 873 80 06-00 Nut, Lock w/Ins. 3/8-16 unc
7 532 12 41-81 Spring, Seat Cprsn
8 532 17 18-77 Bolt 5/16-18 unc x 3/4 w/Sems
10 532 19 69-77 Pan, Seat
21 532 17 18-52 Bolt, Shoulder 5/16-18
37 873 80 05-00 Nut, Lock 5/16-18 unc
40 532 19 76-61 Handle Slide Seat
41 532 19 82-00 Spring Latch Seat
43 874 76 06-12 Bolt 3/8-16 x 3/4
44 819 13 38-12 Washer 13/32 x 2-3/8 x 12 Ga.
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
SEAT ASSEMBLY
42
42

18
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
BAGGER
46
46
25
25
26
7
14
20
14
23
10
20
17
12
18
26
14
22
SRD_BAGGER_8_r1
15
3
2
7
23
8
4
12
11
7
11
16
22
14
21 12
7
1
29
6
28
27
7
23
7
23
13
9
5

19
TRACTOR - - MODEL NO. CTH126 (96051000803), PRODUCT NO. 960 51 00-08
BAGGER
46
46
1 532 42 86-10 Tube Handle Bagger SRD
2 532 44 13-58 Applique
3 532 41 38-08 Nut Push
4 532 43 96-12 Frame Asm Bagger Top
5 532 41 76-32 Frame Asm Top Bagger SRD
6 532 12 68-75 Drilled Rivit
7 873 90 04-00 Nut Hex Flange 1/4-20 unc
8 532 44 12-61 Bagger Top
9 532 41 76-29 Insert Handle Bagger
10 532 41 71-90 Frame Front
11 532 41 71-88 Tubing Brace Bagger
12 532 42 17-93 Nut Square 1/4
13 532 42 17-80 Screw 1/4 x 1.150 HXWSH
14 532 42 18-00 Bolt Shoulder HX WSH 1/4 x 1.150
15 532 42 18-01 Screw #8 Flathead
16 532 42 15-66 Deflector Bagger
17 532 42 17-49 Lever Bagger Full
18 532 42 17-50 Paddle Bagger Full
20 585 36 88-01 Screw Hex Cap 1/4-20 x 1.375
21 532 42 99-81 Bag Asm SRD
22 532 14 24-32 Screw Hex WSH Hi-Lo 1/4 - 1/2 unc
23 872 04 04-10 Bolt Carr 1/4-20 unc x 1-1/4
25 532 42 16-14 Spring Latch Bagger
26 817 49 04-12 Screw Hex Thdrol 1/4-20 x 3/4
27 532 42 12-62 Grommet, Rubber SRD
28 532 16 57-87 Grip Handle Black
29 532 19 42-08 Pin Cotter 5/16 Bow Tie Lock
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm

10.03.13 BD/TH
