OWNER'S MANUAL
LR122

2
I. GENERAL OPERATION
• Read, understand, and follow all instructions in the
manualandonthemachinebeforestarting.
• Onlyallowresponsibleadults,whoarefamiliarwiththe
instructions, to operate the machine.
• Clear the area of objects such as rocks, toys, wire,
etc., whichcouldbepickedupandthrownbytheblade.
• Besuretheareaisclearofotherpeoplebeforemowing.
Stop machine if anyone enters the area.
• Nevercarrypassengers.
• Do not mow in reverse unless absolutely necessary.
Alwayslookdownandbehindbeforeand whileback-
ing.
• Beawareofthemowerdischargedirectionanddonot
point it at anyone. Do not operate the mower without
either the entire grass catcher or the guard in place.
• Slowdownbeforeturning.
• Never leave a running machine unattended. Always
turn off blades, set parking brake, stop engine, and
removekeysbeforedismounting.
• Turnoffbladeswhennotmowing.
• Stopenginebeforeremovinggrasscatcherorunclog-
gingchute.
• Mow only in daylight or good artificial light.
• Donotoperatethemachinewhileundertheinfluence
of alcohol or drugs.
• Watch for traffic when operating near or crossing
roadways.
• Useextracarewhenloadingorunloadingthemachine
into a trailer or truck.
• Dataindicatesthatoperators,age60yearsandabove,
are involved in a large percentage of riding mower-
relatedinjuries. Theseoperatorsshouldevaluatetheir
ability to operate the riding mower safely enough to
protect themselves and others from serious injury.
II. SLOPE OPERATION
Slopes are a major factor related to loss-of-control and
tipover accidents, which can result in severe injury or
death. Allslopesrequireextracaution. Ifyoucannotback
up the slope or if you feel uneasy on it, do not mow it.
DO:
• Mow up and down slopes, not across.
• Remove obstacles such as rocks, tree limbs, etc.
• Watchforholes,ruts,orbumps. Uneventerraincould
overturnthe machine. Tallgrass can hideobstacles.
• Useslowspeed. Choosealowgearsothatyouwillnot
have to stop or shift while on the slope.
• Followthemanufacturer’srecommendationsforwheel
weights or counterweights to improve stability.
• Use extra care with grass catchers or other attach-
ments. Thesecanchangethestabilityofthemachine.
• Keepallmovementontheslopes slow and gradual . Do
not make sudden changes in speed or direction.
• Avoid starting or stopping on a slope. If tires lose
traction, disengage the blades and proceed slowly
straight down the slope.
Safe Operation Practices for Ride-On Mowers
IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS.
FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH.
SAFETY RULES
DONOT:
• Donot turnonslopesunlessnecessary,andthen,turn
slowly and gradually downhill, if possible.
• Donot mowneardrop-offs,ditches,orembankments.
Themower couldsuddenlyturnover ifawheelis over
the edge of a cliff or ditch, or if an edge caves in.
• Do not mow on wet grass. Reduced traction could
cause sliding.
• Donot trytostabilizethemachinebyputtingyourfoot
ontheground.
• Do not use grass catcher on steep slopes.
III. CHILDREN
Tragicaccidentscanoccuriftheoperatorisnotalerttothe
presence of children. Children are often attracted to the
machine and the mowing activity. Never assume that
children will remain where you last saw them.
• Keep children out of the mowing area and under the
watchfulcare ofanotherresponsibleadult.
• Bealertandturnmachineoffifchildrenenterthearea.
• Before and when backing, look behind and down for
smallchildren.
• Nevercarrychildren. Theymayfalloffandbeseriously
injuredorinterferewithsafemachineoperation.
• Neverallow childrentooperate themachine.
• Useextracarewhenapproachingblindcorners,shrubs,
trees, or other objects that may obscure vision.
IV. SERVICE
• Use extra care in handling gasoline and other fuels.
Theyare flammable andvapors are explosive.
- Useonlyanapprovedcontainer.
- Never remove gas cap or add fuel with the engine
running. Allowenginetocoolbeforerefueling. Donot
smoke.
- Neverrefuelthemachineindoors.
- Never store the machine or fuel container inside
wherethereisanopenflame,suchasawaterheater.
• Never run a machine inside a closed area.
• Keep nuts and bolts, especially blade attachment
bolts, tight and keep equipment in good condition.
• Nevertamperwithsafetydevices. Checktheirproper
operationregularly.
• Keep machine free of grass, leaves, or other debris
build-up. Clean oil or fuel spillage. Allow machine to
coolbeforestoring.
• Stopandinspecttheequipmentifyoustrikeanobject.
Repair,ifnecessary,beforerestarting.
• Never make adjustments or repairs with the engine
running.
• Grass catcher components are subject to wear, dam-
age, and deterioration, which could expose moving
parts or allow objects to be thrown. Frequently check
components and replace with manufacturer's recom-
mendedparts,whennecessary.
• Mowerbladesaresharpandcancut. Wraptheblade(s)
or wear gloves, and use extra caution when servicing
them.
• Checkbrakeoperationfrequently. Adjustandservice
asrequired.

3
• Besuretheareaisclearofotherpeoplebeforemowing.
Stop machine if anyone enters the area.
• Never carry passengers or children even with the
blades off.
• Do not mow in reverse unless absolutely necessary.
Alwayslookdownandbehindbeforeandwhilebacking.
• Nevercarrychildren.Theymayfalloffandbeseriously
injuredorinterferewithsafemachineoperation.
• Keep children out of the mowing area and under the
watchfulcare ofanotherresponsibleadult.
• Bealertandturnmachineoffifchildrenenterthearea.
• Before and when backing, look behind and down for
smallchildren.
• Mow up and down slopes (15° Max), not across.
• Remove obstacles such as rocks, tree limbs, etc.
• Watchforholes,ruts,orbumps.Uneventerraincould
overturn the machine. Tall grass can hide obstacles.
• Useslowspeed.Choosealowgearsothatyouwillnot
have to stop or shift while on the slope.
• Avoid starting or stopping on a slope. If tires lose
traction, disengage the blades and proceed slowly
straightdown the slope.
• Ifmachinestopswhilegoinguphill,disengageblades,
shift into reverse and back down slowly.
• Donotturnonslopesunlessnecessary,andthen,turn
slowly and gradually downhill, if possible.
CAUTION: Donotcoastdownahillin
neutral, you may lose control of the
tractor.
CAUTION: Towonlytheattachments
that are recommended by and com-
ply with specifications of the manu-
facturerofyourtractor. Usecommon
sensewhentowing. Operateonlyat
thelowestpossiblespeedwhenona
slope. Tooheavy of a load, while on
aslope,isdangerous. Tirescanlose
traction with the ground and cause
you to lose control of your tractor.
Lookforthissymboltopointoutimportant
safety precautions. It means CAUTION!!!
BECOME ALERT!!! YOUR SAFETY IS IN-
VOLVED.
WARNING
The engine exhaust from this product con-
tains chemicals known to the State of Cali-
forniatocausecancer,birthdefects,orother
reproductive harm.
CAUTION: Inordertopreventacciden-
talstartingwhensettingup,transport-
ing, adjusting or making repairs, al-
ways disconnect spark plug wire and
placewirewhereitcannotcontactspark
plug.
Safe Operation Practices for Ride-On Mowers
SAFETY RULES

4
PRODUCT SPECIFICATIONS
GASOLINE CAPACITY 1.4 GALLONS
AND TYPE: UNLEADED REGULAR
OILTYPE(API-SF/SG/SH): SAE 30 (Above 32°F)
SAE 5W-30 (Below 32°F)
OILCAPACITY: 3 PINTS
SPARK PLUG: CHAMPION RJ19LM
(GAP: .030")
VALVE CLEARANCE: INTAKE: .005" - .007"
EXHAUST: .009" - .011"
GROUND SPEED (MPH): FORWARD:
1ST .8
2ND 1.8
3RD 2.7
4TH 4.5
REVERSE: 1.4
TIRE PRESSURE: FRONT: 14 PSI
REAR: 12 PSI
CHARGING SYSTEM: 3 AMPS BATTERY
5 AMPS HEADLIGHTS
BATTERY: AMP/HR: 20
MIN. CCA: 130
CASESIZE: U1R
BLADE BOLT TORQUE: 27–35 FT. LBS.
CONGRATULATIONS onyourpurchaseofanewtractor.
Ithasbeendesigned,engineeredandmanufacturedtogive
youthe bestpossibledependabilityand performance.
Should you experience any problem you cannot easily
remedy, please contact your nearest authorized
servicecenter/department Wehavecompetent,well-trained
technicians and the proper tools to service or repair this
tractor.
Please read and retain this manual. The instructions will
enableyoutoassembleandmaintainyourtractorproperly.
Always observe the “SAFETY RULES”.
CUSTOMER RESPONSIBILITIES
• Read and observe the safety rules.
• Followaregularscheduleinmaintaining,caringforand
usingyour tractor.
• Followtheinstructionsunder“CustomerResponsibili-
ties” and “Storage” sections of this owner’s manual.
WARNING: This tractor is equipped with an internal
combustionengineandshouldnotbeusedonornearany
unimproved forest-covered, brush-covered or grass-cov-
eredlandunlesstheengine’sexhaustsystemisequipped
withasparkarrestermeetingapplicablelocalorstatelaws
(ifany). Ifasparkarresterisused,itshouldbemaintained
ineffective working order by the operator.
In the state of California the above is required by law
(Section 4442 of the California Public Resources Code).
Otherstatesmayhavesimilarlaws.Federallawsapplyon
federal lands. A spark arrester for the muffler is available
through your nearest Sears Authorized Service Center/
Department (SeeREPAIRPARTSsectionofthismanual).
SAFETY RULES ..................................................... 2-3
PRODUCT SPECIFICATIONS.................................... 4
CUSTOMER RESPONSIBILITIES .................. 4, 14-16
ASSEMBLY............................................................. 6-8
OPERATION.......................................................... 9-13
MAINTENANCE SCHEDULE.................................... 14
SERVICE AND ADJUSTMENTS ......................... 17-21
STORAGE ................................................................ 22
TROUBLESHOOTING ......................................... 23-24
REPAIR PARTS - TRACTOR .............................. 26-42
WARRANTY ............................................................. 46
TABLE OF CONTENTS

5
UNASSEMBLEDPARTS
(1) Large Flat
Washer
(1)
Locknut
5/16-18
(1) Hex Bolt 5/16-18 x 1-1/4
(1) Hex Bolt
3/8-16 x 1
(1) Lock
washer
3/8
Steering
Wheel Insert
Steering
Extension
Shaft
Steering
Sleeve
Steering Wheel
Steering
Wheel
Adapter
(1) Washer
17/32 x 1-3/16 x 12 Gauge
Seat
(1) Shoulder
Bolt 5/16-18
(1) Lock
Washer 1/2
(1) Hex Bolt
1/2-13 x 1
Mulcher Plate
(2) Keys
Keys
Slope Sheet

6
ASSEMBLY
TOOLS REQUIRED FOR ASSEMBLY
Asocketwrenchsetwillmakeassemblyeasier. Standard
wrench sizes are listed.
(1) 9/16"wrench Pliers
(1) 3/4"wrench Tirepressuregauge
(2) 1/2"wrenches Utility knife
When right and left hand are mentioned in this manual, it
means when you are in the operating position (seated
behindthesteeringwheel).
TO REMOVE TRACTOR FROM
CARTON
UNPACKCARTON
• Remove all accessible loose parts and parts cartons
fromcarton.
• Cut fromtop tobottom,alonglines onallfourcorners
of carton and lay panels flat.
• Check for any additional loose parts or cartons and
remove.
BEFOREREMOVING TRACTOR FROM SKID
ASSEMBLE EXTENSION SHAFT
• Slide extension shaft onto lower steering shaft. Align
mounting holes in extension and lower shafts and
install 5/16 hex bolt and locknut. Tighten securely.
INSTALLSTEERINGWHEEL
• Positionfrontwheelsofthetractorsotheyarepointing
straightforward.
• Remove steering wheel adapter from steering wheel
and slide adapter onto steering shaft extension.
• Slidesteeringwheeladapterontosteeringshaftexten-
sion.
• Position steering wheel so cross bars are horizontal
(left to right) and slide onto adapter.
• Assemble large flat washer, 3/8 lock washer, 3/8 hex
bolt and tighten securely.
• Snap steering wheel insert into center of steering
wheel.
• Remove protective materials from tractor hood and
grill.
IMPORTANT: CHECKFORANDREMOVEANYSTAPLES
IN SKID THAT MAY PUNCTURE TIRES WHERE
TRACTOR IS TO ROLL OFF SKID.
STEERING
WHEEL
INSERT 3/8 HEX BOLT
3/8 LOCK WASHER
LARGE FLAT
WASHER
ADAPTER
5/16 HEX BOLT
STEERING
SLEEVE
5/16 LOCKNUT
LOWER
STEERING
SHAFT
EXTENSION SHAFT
FIG. 1
FIG. 2
HOW TO SET UP YOUR TRACTOR
CHECKBATTERY (SeeFig.2)
• Lift seat pan to raised position and open battery box
door.
• If this battery is put into service after month and year
indicated on label (label located between terminals)
chargebatteryforminimumofonehourat6-10amps.
(See "BATTERY" in CUSTOMER RESPONSIBILI-
TIES sectionofthismanualforcharginginstructions).
BATTERY
BOX DOOR
SEAT PAN
LABEL
TERMINAL TERMINAL

7
ASSEMBLY
INSTALL SEAT (See Fig. 3)
Adjust seat before tightening adjustment bolt or optional
knob.
• Removeadjustmentbolt,lockwasherandflatwasher
(or knob, if so equipped) securing seat to cardboard
packing and set aside for assembly of seat to tractor.
• Pivot seat upward and remove from the cardboard
packing. Removethe carboard packing and discard.
• Place seat on pan and assemble shoulder bolt.
• Assemble loosely adjustment bolt, lock washer and
flat washer (or knob, if so equipped). Do not tighten.
Tightenshoulderboltsecurely.
• Lower seat into operating position and sit on seat.
• Slideseatuntilacomfortablepositionisreachedwhich
allowsyoutopressclutch/brakepedalallthewaydown
(See Fig. 5).
• Get off seat without moving its adjusted position.
• Raise seat and tighten adjustment bolt or knob se-
curely.
SEAT PAN
FLAT
WASHER
SEAT
SHOULDER
BOLT
LOCK
WASHER
ADJUSTMENT
BOLT
KNOB
(IF SO EQUPPED)
FIG. 3
TO ROLL TRACTOR OFF SKID (See Opera-
tionsection,page9forlocationandfunction
of controls)
• Pressliftleverplungerandraiseattachmentliftleverto
its highest position.
• Release parking brake by depressing clutch/brake
pedal.
• Place gearshift lever in neutral (N) position.
• Roll tractor forward off skid.
• Removebandingholding discharge guard up against
tractor.
TODRIVE TRACTOR OFF SKID (See Opera-
tionsection,page9forlocationandfunction
of controls)
WARNING:Beforestarting,read,understandandfollowall
instructionsintheOperationsectionofthismanual.Besure
tractorisinawell-ventilatedarea.Besuretheareain front
of tractor is clear of other people and objects.
NOTE: Youmaynow roll or drive your tractor offtheskid.
Follow the appropriate instruction below to remove the
tractor from the skid.
• Be sure all the above assembly steps have been
completed.
• Check engine oil level and fill fuel tank with gasoline.
• Sitonseatinoperatingposition,depressclutch/brake
pedaland set the parking brake.
• Place gear shift lever in neutral (N) position.
• Pressliftleverplungerandraiseattachmentliftleverto
its highest position.
• Start the engine. After engine has started, move
throttle control to idle position.
• Depressclutch/brakepedalintofull"BRAKE"position
and hold. Move gearshift lever to 1st gear.
• Slowly release clutch/brake pedal and slowly drive
tractor off skid.
• Applybraketostoptractor,setparkingbrakeandplace
gearshiftlever in neutralposition.
• Turn ignition key to "OFF" position.
Continue with the instructions that follow.
INSTALL MULCHER PLATE (See Fig. 4)
• Raise and hold deflector shield in upright position.
• Placefront of mulcherplate over frontof mower deck
opening and slide into place, as shown.
• Hookfrontlatchhook onto hexbolton frontofmower
deck.
• Hookrearlatchhook ontohexbolt on back of mower
deck.
CAUTION: Do not remove discharge
guard from mower. Raise and hold
guard when attaching mulcher plate
and allow it to rest on plate while in
operation.
TO CONVERT TO BAGGING OR
DISCHARGING
Simply remove mulcher plate and store in a safe place.
Yourmower isnowreadyfordischarging orinstallationof
optional grass catcher accessory.
NOTE: Itisnotnecessarytochangeblades. Themulcher
bladesaredesignedfordischargingandbaggingalso.
LATCH
HOOKS
MULCHER
PLATE
DEFLECTOR
SHIELD
FIG. 4

8
ASSEMBLY
CHECK TIRE PRESSURE
Thetiresonyourtractorwereoverinflatedatthefactoryfor
shipping purposes. Correct tire pressure is important for
bestcuttingperformance.
• Reducetirepressureto14PSIinfronttiresand12PSI
in rear tires.
CHECK DECK LEVELNESS
Forbestcuttingresults,mowerhousingshouldbeproperly
leveled. See “TO LEVEL MOWER HOUSING” in the
Service and Adjustments section of this manual.
CHECK FOR PROPER POSITION OF ALL
BELTS
See the figures that are shown for replacing motion and
mower blade drive belts in the Service and Adjustments
section of this manual. Verify that the belts are routed
correctly.
CHECK BRAKE SYSTEM
After you learn how to operate your tractor, check to see
that the brake is properly adjusted. See “TO ADJUST
BRAKE” in the Service and Adjustments section of this
manual.
3 CHECKLIST
BEFORE YOU OPERATE AND ENJOY YOUR NEW
TRACTOR,WEWISHTOASSURETHATYOURECEIVE
THEBESTPERFORMANCEANDSATISFACTIONFROM
THISQUALITYPRODUCT.
PLEASEREVIEWTHEFOLLOWINGCHECKLIST:
✓All assembly instructions have been completed.
✓Noremaining loose parts in carton.
✓Batteryisproperlypreparedandcharged. (Minimum
1 hour at 6 amps).
✓Seat is adjusted comfortably and tightened securely.
✓Alltiresareproperlyinflated. (Forshippingpurposes,
the tires were overinflated at the factory).
✓Be sure mower deck is properly leveled side-to-side/
front-to-rear for best cutting results. (Tires must be
properlyinflatedforleveling).
✓Checkmoweranddrivebelts. Besuretheyarerouted
properlyaroundpulleysandinsideall belt keepers.
✓Checkwiring. Seethatallconnectionsarestillsecure
andwiresareproperlyclamped.
WHILELEARNINGHOWTOUSEYOURTRACTOR,PAY
EXTRAATTENTIONTOTHEFOLLOWINGIMPORTANT
ITEMS:
✓Engine oil is at proper level.
✓Fuel tank is filled with fresh, clean, regular unleaded
gasoline.
✓Become familiar with all controls - their location and
function. Operate them before you start the engine.
✓Be sure brake system is in safe operating condition.

9
OPERATION
IGNITION SWITCH: Used for starting and stopping the
engine.
THROTTLE/CHOKE CONTROL: Used for starting and
controllingenginespeed.
CLUTCH/BRAKEPEDAL:Usedfordeclutchingandbrak-
ingthe lawn rider andstarting the engine.
GEARSHIFT LEVER: Selects the speed and direction of
thelawnrider.
Your tractor conforms to the safety standards of the American National Standards Institute.
KNOW YOUR TRACTOR
READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR.
ComparetheillustrationswithyourTractortofamiliarizeyourselfwiththelocationofvariouscontrolsandadjustments.Save
thismanualforfuturereference.
LIGHT SWITCH: (If so equipped) Turns headlights on or
off.
PARKINGBRAKELEVER:Locksclutch/brakepedalinto
thebrakeposition.
ATTACHMENT CLUTCH LEVER: Used to engage the
mowerblades.
MOWERLIFTLEVER:Usedtoraiseandlowerthemower
deck.
FIG. 5
CLUTCH/BRAKE PEDAL
IGNITION SWITCH
ATTACHMENT CLUTCH
LEVER
THROTTLE/CHOKE CONTROL
PARKING BRAKE LEVER GEAR SHIFT
LEVER
FUEL CAP
MOWER LIFT
LEVER
LIGHT SWITCH
(IF SO
EQUIPPED)

10
OPERATION
Theoperationofanytractorcanresultinforeignobjectsthrownintotheeyes,whichcanresult
insevereeyedamage. Alwayswearsafety glasses oreyeshields beforestartingyour tractor
andwhilemoving.Werecommendawidevisionsafetymaskoverspectaclesorstandardsafety
glasses.
HOW TO USE YOUR TRACTOR
TOSET PARKING BRAKE (See Fig.6)
Yourtractorisequippedwithanoperatorpresencesensing
switch. When engine is running, any attempt by the
operator to leave the seat without first setting the parking
brake will shut off the engine.
• Depressclutch/brakepedalintofull“BRAKE”position
andhold.
• Placeparkingbrakelever in“ENGAGED”positionand
releasepressurefromclutch/brakepedal. Pedalshould
remainin“BRAKE”position. Makesureparkingbrake
will hold tractor secure.
CLUTCH/BRAKE
PEDAL “BRAKE”
POSITION
ATTACHMENT
CLUTCH
LEVER
“ENGAGED”
PARKING BRAKE “ENGAGED”
“DISENGAGED”
“DISENGAGED”
FIG. 6
IGNITION
SWITCH
GEAR SHIFT
THROTTLE/
CHOKE
CONTROL
FIG. 7
TO ADJUST MOWER CUTTING HEIGHT
(See Fig. 8)
The position of the attachment lift lever determines the
cuttingheight. Thepositionoftheattachmentliftlevercan
be adjusted by moving the height adjustment knob to
desiredposition.
• Withliftleverback and locked in highest position, pull
outtheadjustmentknobandmovetodesiredposition.
• Move attachment lift lever out and forward to adjust-
mentknob.
TO MOVE FORWARD AND BACKWARD
(See Figs. 6 and 7)
Thedirectionandspeedofmovement iscontrolledbythe
gearshift lever.
• Start tractor with clutch/brake pedal depressed and
gearshiftleverin neutral (N) position.
• Move gearshift lever to desired position.
• Slowlyreleaseclutch/brakepedaltostart movement.
IMPORTANT: BRINGTRACTORTOACOMPLETESTOP
BEFORE SHIFTING OR CHANGING GEARS. FAILURE
TODOSOWILLSHORTENTHEUSEFULLIFEOFYOUR
TRANSAXLE.
STOPPING (See Fig. 6 and 7)
MOWERBLADES-
• Tostopmowerblades,moveattachmentclutchleverto
“DISENGAGED”position.
GROUNDDRIVE-
• Tostopgrounddrive,depressclutch/brakepedalinto
full “BRAKE” position.
• Move gearshift lever to neutral (N) position.
ENGINE-
• Move throttle control to slow position.
NOTE: Failuretomovethrottlecontroltoslowpositionand
allowingenginetoidlebeforestoppingmaycauseengineto
“backfire”.
• Turn ignition key to “OFF” position and remove key.
Always remove key when leaving tractor to prevent
unauthorizeduse.
• Never use choke to stop engine.
IMPORTANT: LEAVINGTHE IGNITION SWITCH INANY
POSITION OTHER THAN "OFF" WILL CAUSE THE
BATTERY TO BE DISCHARGED, (DEAD).
NOTE: Undercertain conditions when tractor is standing
idlewiththeenginerunning,hotengineexhaustgasesmay
cause “browning” of grass. To eliminate this possibility,
alwaysstopenginewhenstoppingtractorongrassareas.
CAUTION: Always stop tractor com-
pletely,asdescribedabove,beforeleav-
ing the operator's position; to empty
grasscatcher,etc.
TO USE THROTTLE CONTROL(See Fig. 7)
Always operate engine at full throttle.
• Operating engine at less than full throttle reduces the
batterychargingrate.
• Fullthrottleoffersthebestbaggingandmowerperfor-
mance.

11
OPERATION
TO OPERATE MOWER (See Figs. 8 and 9)
Yourtractor isequippedwithanoperatorpresencesensing
switch. Anyattemptbytheoperatortoleavetheseatwith
theenginerunningandtheattachmentclutchengagedwill
shut off the engine.
• Select desired height of cut.
• Start mower blades by engaging attachment clutch
control.
• TOSTOPMOWERBLADES-disengageattachment
clutch control.
CAUTION: Do not operate the mower
withouteithertheentiregrasscatcher,
on mowers so equipped, or the dis-
charge guard in place.
ATTACHMENT
CLUTCH LEVER
“ENGAGED”
POSITION
ATTACHMENT
CLUTCH LEVER
“DISENGAGED”
POSITION
ADD GASOLINE
• Fill fuel tank. Use fresh, clean, regular unleaded
gasolinewithaminimumof87octane. (Useof leaded
gasolinewillincreasecarbonandleadoxidedeposits
and reduce valve life). Do not mix oil with gasoline.
Purchasefuelinquantities that can be used within 30
days to assure fuel freshness.
IMPORTANT: WHEN OPERATING IN TEMPERATURES
BELOW32°F(0°C),USEFRESH,CLEANWINTERGRADE
GASOLINE TO HELP INSURE GOOD COLD WEATHER
STARTING.
TO TRANSPORT
• Raise attachment lift to highest position with attach-
ment lift control.
• Whenpushingortowingyourtractor,besuregearshift
lever is in neutral (N) position.
• Do not push or tow tractor at more than five (5) MPH.
NOTE: To protect hood from damage when transporting
yourtractoronatruckoratrailer,besurehoodisclosedand
securedtotractor. Useanappropriatemeansoftyinghood
to tractor (rope, cord, etc.).
TOWING CARTS AND OTHER ATTACH-
MENTS
Tow only the attachments that are recommended by and
comply with specifications of the manufacturer of your
tractor. Use common sense when towing. Too heavy of a
load,whileonaslope,isdangerous.Tirescanlosetraction
withthegroundandcauseyoutolosecontrolofyourtractor.
BEFORE STARTING THE ENGINE
CHECK ENGINE OIL LEVEL
• Theengineinyourtractor hasbeenshipped,fromthe
factory, already filled with summer weight oil.
• Check engine oil with tractor on level ground. See
enginemanualforfurtherinstructions.
• For cold weather operation you should change oil for
easierstarting(Seeenginemanual).
• Tochangeengineoil,seetheCustomerResponsibili-
ties section in this manual.
FIG. 9
FIG. 8
6
3
2
1
ATTACHEMENT
LIFT LEVER ATTACHMENT
HEIGHT
ADJUSTMENT
KNOB
TO OPERATE ON HILLS
CAUTION: Do not drive up or down
hills with slopes greater than 15° and
do not drive across any slope.
• Choosetheslowestspeed beforestartingupordown
hills.
• Avoid stopping or changing speed on hills.
• If slowing is necessary, move throttle control lever to
slowerposition.
Thecuttingheightrangeisapproximately1"to3-1/2''. The
heightsaremeasuredfromthegroundtothebladetipwith
theenginenotrunning. Theseheightsareapproximateand
may vary depending upon soil conditions, height of grass
and types of grass being mowed.
• Theaveragelawnshouldbecuttoapproximately2-1/2
inches during the cool season and to over 3 inches
during hot months. For healthier and better looking
lawns,mowoftenand aftermoderategrowth.
• For best cutting performance, grass over 6 inches in
height should be mowed twice. Make the first cut
relatively high; the second to desired height.
• Ifstoppingisabsolutelynecessary,pushclutch/brake
pedal quickly to brake position and engage parking
brake.
• Movegearshift leverto1stgearandbesureyouhave
allowed room for tractor to roll slightly as you restart
movement.
• Torestartmovement,slowlyreleaseparkingbrakeand
clutch/brakepedal.
• Make all turns slowly.

12
OPERATION
TO START ENGINE (See Fig. 5)
When starting the engine for the first time or if the engine
has run out of fuel, it will take extra cranking time to move
fuel from the tank to the engine.
• Sitonseatinoperatingposition,depressclutch/brake
pedaland set parking brake.
• Place gear shift lever in neutral (N) position.
• Moveattachment clutch to“DISENGAGED” position.
• Move throttle control to choke position.
NOTE: Before starting, read the warm and cold starting
proceduresbelow.
• Insert key into ignition and turn key clockwise to
“START” position and release key as soon as engine
starts. Do not run starter continuously for more than
fifteensecondsperminute.Iftheenginedoesnotstart
after several attempts, move throttle control to fast
position,waitafewminutesandtryagain.Ifenginestill
does not start, move the throttle control back to the
choke position and retry.
WARMWEATHERSTARTING(50°Fandabove)
• Whenenginestarts,movethethrottlecontroltothefast
position.
• Theattachmentsandgrounddrivecannowbeused.If
theenginedoesnotaccepttheload,restarttheengine
andallowittowarmupforoneminuteusingthechoke
asdescribedabove.
COLDWEATHERSTARTING(50°Fandbelow)
• Whenenginestarts,allowenginetorunwiththethrottle
control in the choke position until the engine runs
roughly,thenmovethrottlecontroltofastposition.This
may require an engine warm-up period from several
seconds to several minutes, depending on the tem-
perature.
• The attachments can also be used during the engine
warm-upperiod.
NOTE: If at a high altitude (above 3000 feet) or in cold
temperatures(below32F)thecarburetorfuelmixturemay
needtobeadjustedforbestengineperformance.See“TO
ADJUSTCARBURETOR”intheServiceandAdjustments
section of this manual.
FIG. 10
WARNING: Experience indicates that alcohol blended
fuels (called gasohol or using ethanol or methanol) can
attractmoisturewhichleadstoseparationandformationof
acids during storage. Acidic gas can damage the fuel
system of an engine while in storage. To avoid engine
problems, the fuel system should be emptied before
storageof30daysorlonger. Drainthegas tank,startthe
engineand let it run until the fuellines and carburetor are
empty. Usefreshfuelnextseason. SeeStorageInstruc-
tions for additional information. Never use engine or
carburetorcleanerproducts inthefueltankorpermanent
damagemay occur.
CAUTION: Fill to bottom of gas tank
filler neck. Do not overfill. Wipe off
any spilled oil or fuel. Do not store,
spill or use gasoline near an open
flame.
MOWINGTIPS
• Mower should be properly leveled for best mowing
performance. See“TOLEVELMOWERHOUSING”in
the Service and Adjustments section of this manual.
• The left hand side of mower should be used for
trimming.
• Drivesothatclippingsaredischargedontotheareathat
has been cut. Have the cut area to the right of the
machine. Thiswillresultinamoreevendistributionof
clippingsand more uniform cutting.
• Whenmowinglargeareas,startbyturningtotheright
so that clippings will discharge away from shrubs,
fences,driveways,etc. Afteroneortworounds,mow
in the opposite direction making left hand turns until
finished (See Fig. 10).
• If grass is extremely tall, it should be mowed twice to
reduce load and possible fire hazard from dried clip-
pings. Makefirstcutrelativelyhigh;thesecondto the
desiredheight.
• Do not mow grass when it is wet. Wet grass will plug
mowerandleaveundesirableclumps. Allowgrassto
drybeforemowing.
•Alwaysoperateengineatfullthrottlewhenmowing
toassurebettermowingperformanceandproperdis-
chargeofmaterial. Regulategroundspeedbyselect-
ing a low enough gear to give the mower cutting
performance as well as the quality of cut desired.
• When operating attachments, select a ground speed
thatwillsuittheterrainandgivebestperformanceofthe
attachmentbeingused.

13
MULCHING MOWING TIPS
IMPORTANT: FOR BEST PERFORMANCE, KEEP
MOWER HOUSING FREE OF BUILT-UP GRASS AND
TRASH. CLEAN AFTER EACH USE.
• The special mulching blade will recut the grass clip-
pings many times and reduce them in size so that as
theyfallontothelawntheywilldisperseintothegrass
and not be noticed. Also, the mulched grass will
biodegrade quickly to provide nutrients for the lawn.
Alwaysmulchwithyour highestengine(blade) speed
as this will provide the best recutting action of the
blades.
• Avoidcuttingyourlawnwhenitiswet. Wetgrasstends
toformclumpsandinterfereswiththemulchingaction.
Thebesttimetomowyourlawnistheearlyafternoon.
Atthistimethegrasshasdriedandthenewlycutarea
will not be exposed to the direct sun.
•Forbestresults,adjustthemowercuttingheightsothat
the mower cuts off only the top one-third of the grass
blades (See Fig. 11). For extremely heavy mulching,
reduceyourwidthofcutoneachpassandmowslowly.
• Certain types of grass and grass conditions may
require that an area be mulched a second time to
completely hide the clippings. When doing a second
cut, mow across or perpendicular to the first cut path.
• Changeyourcuttingpatternfromweektoweek. Mow
northtosouthoneweekthenchangetoeasttowestthe
nextweek. Thiswillhelppreventmattingandgraining
of the lawn.
MAX 1/3
FIG. 11
OPERATION

14
CUSTOMERRESPONSIBILITIES
LUBRICATION CHART
À CLUTCH/BRAKE
PIVOT
À THROTTLE
PLATE
À ATTACHMENT
CLUTCH
LEVER
À HOOD HINGES
 ENGINE
À ATTACHMENT
LIFT ARM
PIVOT
À AXLE PIVOT
À SAE 30 OR 10W30 MOTOR OIL
Á GENERAL PURPOSE GREASE
 REFER TO CUSTOMER RESPONSIBILITIES“ENGINE”
SECTION
À ATTACHMENT
CLUTCH PIVOT
À CLUTCH
PIVOT
À GEARSHIFT
PIVOTS
IMPORTANT: DO NOT OIL OR GREASE THE PIVOT
POINTS WHICH HAVE SPECIAL NYLON BEARINGS.
VISCOUSLUBRICANTSWILLATTRACTDUSTANDDIRT
THAT WILL SHORTEN THE LIFE OF THE SELF-
LUBRICATINGBEARINGS. IFYOUFEELTHEYMUSTBE
LUBRICATED, USE ONLY A DRY, POWDERED
GRAPHITE TYPE LUBRICANT SPARINGLY.
GENERAL RECOMMENDATIONS
Thewarrantyonthistractordoesnotcoveritemsthathave
been subjected to operator abuse or negligence. To
receivefullvaluefromthewarranty,operatormustmaintain
tractor as instructed in this manual.
Some adjustments will need to be made periodically to
properlymaintainyourtractor.
AlladjustmentsintheServiceandAdjustmentssectionof
thismanualshouldbecheckedatleastonceeachseason.
• Onceayearyou shouldreplacethe sparkplug,clean
or replace air filter, and check blades and belts for
wear. A new spark plug and clean air filter assure
properair-fuelmixtureandhelpyourenginerunbetter
andlast longer.
BEFORE EACH USE
• Check engine oil level.
• Checkbrakeoperation.
• Checktirepressure.
• Checkoperatorpresenceand
interlocksystemsfor proper operation.
• Check for loose fasteners.
Á FRONT WHEEL
BEARING ZERK
(IF EQUIPPED)
Á FRONT WHEEL
BEARING ZERK
(IF EQUIPPED)
BEFOREEACHUSE
T
R
A
C
T
0
R
Adjust Motion Drive Belt(s) Tension
Inspect Muffler/Spark Arrester
Lubrication Chart
Check Brake Operation
Clean Air Filter
Change Engine Oil
Replace Air Filter Paper Cartridge
Replace Spark Plug
Check Battery Level
Check Tire Pressure
Clean Battery and Terminals
FILL IN DATES
AS YOU COMPLETE
REGULAR SERVICE
MAINTENANCE SCHEDULE
EVERY 8 HOURS EVERY 25 HOURS EVERY 50 HOURS
EVERY 100 HOURS
EVERY SEASON
SERVICE DATES
Check for Loose Fasteners
BEFORE STORAGE
Check Engine Oil Level
Clean Engine Cooling Fins
Sharpen/Replace Mower Blades
Check Operator Presence and
Interlock Systems
Clean Air Screen
1 - Change more often when operating under a heavy load or in high ambient temperatures.
2 - Service more often when operating in dirty or dusty conditions.
3 - If equipped with oil filter, change oil every 50 hours.
4 - Replace blades more often when mowing in sandy soil.
E
N
G
I
N
E
Replace Oil Filter (If equipped)
Check Transaxle Cooling
Adjust Blade Belt(s) Tension
Replace Fuel Filter
1
4
2
2
2
2
5 - If equipped with adjustable system.
6 - Not required if equipped with maintenance-free battery.
7 - Tighten front axle pivot bolt to 35 ft.-lbs. maximum.
Do not overtighten.
1 ,
12,3 ,
2
5
5
6
7

15
CUSTOMERRESPONSIBILITIES
TRACTOR
Alwaysobservesafetyruleswhenperforminganymainte-
nance.
BRAKE OPERATION
Iftractor requires morethan six (6)feet stopping distance
athighspeedinhighestgear,thenbrakemustbeadjusted.
(See “TO ADJUST BRAKE” in the Service and Adjust-
ments section of this manual).
TIRES
• Maintainproperairpressureinalltires-14PSIinfront
tires and 12 PSI in rear tires.
• Keep tires free of gasoline, oil, or insect control
chemicalswhich can harm rubber.
• Avoid stumps, stones, deep ruts, sharp objects and
other hazards that may cause tire damage.
NOTE: To seal tire punctures and prevent flat tires due to
slowleaks,tire sealant may be purchasedfrom your local
parts dealer. Tire sealant also prevents tire dry rot and
corrosion.
OPERATOR PRESENCE SYSTEM
Be sure operator presence and interlock systems are
working properly. If your tractor does not function as
described,repairtheproblemimmediately.
• The engine should not start unless the clutch/brake
pedalisfullydepressedandattachementclutchcontrol
is in the disengaged position.
• When the engine is running, any attempt by the
operator to leave the seat without first setting the
parking brake should shut off the engine.
• Whentheengineisrunningandtheattachmentclutch
is engaged, any attempt by the operator to leave the
seat should shut off the engine.
• Theattachmentclutchshouldneveroperateunlessthe
operator is in the seat.
BLADE CARE
Forbestresultsmowerbladesmustbekeptsharp. Replace
bentordamagedblades.
BLADE REMOVAL (See Fig. 12)
• Raise mower to highest position to allow access to
blades.
• Removehexbolt,lockwasherandflatwashersecuring
blade.
• Installnewor resharpenedbladewithtrailingedgeup
towards deck as shown.
IMPORTANT: TO ENSURE PROPER ASSEMBLY,
CENTER HOLE IN BLADE MUST ALIGN WITH STAR ON
MANDREL ASSEMBLY.
• Reassemble hex bolt, lock washer and flat washer in
exact order as shown.
• Tighten bolt securely (27-35 Ft. Lbs. torque).
IMPORTANT: BLADEBOLTISGRADE8HEATTREATED.
FIG. 13
5/8" BOLT
OR PIN BLADE
CENTER HOLE
MANDREL
ASSEMBLY
BLADE
TRAILING EDGE
UP
FLAT WASHER
LOCK
WASHER
HEX BOLT (GRADE 8)*
*A GRADE 8 HEAT TREATED BOLT CAN BE
IDENTIFIED BY SIX LINES ON THE BOLT HEAD.
FIG. 12
CENTER
HOLE
STAR
TO SHARPEN BLADE (See Fig. 13)
NOTE: Wedonotrecommendsharpeningblade-butifyou
do, be sure the blade is balanced.
Care should be taken to keep the blade balanced. An
unbalancedbladewillcauseexcessivevibrationandeven-
tualdamagetomowerandengine.
• Thebladecanbesharpenedwithafileoronagrinding
wheel. Donotattempttosharpenwhileonthemower.
• Tocheckbladebalance,youwillneeda5/8"diameter
steelbolt,pin,oraconebalancer. (Whenusingacone
balancer, follow the instructions supplied with bal-
ancer.)
NOTE: Donotuseanailforbalancingblade. Thelobesof
the center hole may appear to be centered, but are not.
• Slidebladeontoanunthreadedportionofthesteelbolt
orpin and holdtheboltorpin parallel withtheground.
If blade is balanced, it should remain in a horizontal
position. If either end of the blade moves downward,
sharpen the heavy end until the blade is balanced.
BATTERY
Your tractor has a battery charging system which is
sufficientfornormaluse. However,periodicchargingofthe
battery with an automotive charger will extend its life.
• Keepbattery and terminals clean.
• Keep battery bolts tight.
• Keep small vent holes open.
• Rechargeat 6-10amperesfor 1 hour.

16
CUSTOMERRESPONSIBILITIES
FIG. 14
CLAMP
FUEL FILTER
AIR FILTER
Yourenginewillnotrunproperlyandmaybedamagedby
usingadirtyairfilter. Removecartridgeevery25hoursand
tapgentlytoclean. Replacepapercartridgeonceayearor
afterevery100hoursofoperation,moreoftenifusedinvery
dusty, dirty conditions.
• Removeknobsand cover.
• Removecartridgenutandcleanorreplacecartridge.
• Reassembleandtightensecurely.
NOTE: Do not attempt to oil the paper cartridge. See
enginemanual.
V- BELTS
CheckV-Belts for deteriorationand wear after100 hours.
Replace if necessary. The belts are not adjustable. Re-
place belts if they begin to slip from wear.
TRANSAXLE COOLING
Keeptransaxlefreefrombuild-upofdirtandchaffwhichcan
restrict cooling.
ENGINE
LUBRICATION
Changetheoilafterevery25hoursofoperationoratleast
onceayearifthetractorisnotusedfor25hoursinoneyear.
Refertoenginemanual.
MUFFLER
Inspectandreplacecorrodedmufflerandsparkarrester(if
equipped)asit could create a fire hazardand/ordamage.
SPARK PLUGS
Replace spark plugs at the beginning of each mowing
season or after every 100 hours of operation, whichever
occursfirst. Sparkplugtypeandgapsettingare shownin
yourenginemanual.
IN-LINE FUEL FILTER (See Fig. 14)
Fuelfiltershouldbereplacedonceeachseason. Iffuelfilter
becomes clogged, obstructing fuel flow to carburetor,
replacementisrequired.
• With engine cool, remove filter and plug fuel line sections.
• Place new fuel filter in position in fuel line.
• Be sure there are no fuel line leaks and clamps are
properlypositioned.
• Immediately wipe up any spilled gasoline.
CLEAN AIR SCREEN
Air screen must be kept free of dirt and chaff to prevent
enginedamagefromoverheating. Cleanwithawirebrush
or compressed air to remove dirt and stubborn dried gum
fibers. See engine manual.
ENGINE COOLING FINS
Remove any dust, dirt or oil from engine cooling fins to
prevent engine damage from overheating. See engine
manual.
CLEANING
• Clean engine, battery, seat, finish, etc. of all foreign
matter.
• Keepfinishedsurfacesandwheelsfreeofallgasoline,
oil, etc.
• Protect painted surfaces with automotive type wax.
Wedo not recommend using agarden hose to cleanyour
unit unless the electrical system, muffler, air filter and
carburetorarecoveredtokeepwaterout. Waterinengine
can result in a shortened engine life.
TO CLEAN BATTERY AND TERMINALS
Corrosionand dirt on the battery and terminalscancause
thebattery to “leak” power.
• Openbatteryboxdoor.
• Disconnect BLACK battery cable first then RED
battery cable and remove battery from tractor.
• Rinse the battery with plain water and dry.
• Cleanterminalsandbatterycableendswithwirebrush
untilbright.
• Coatterminalswith grease or petroleum jelly.
• Reinstallbattery(See“REPLACINGBATTERY”inthe
SERVICE AND ADJUSTMENTS section of this
manual).

17
TO LEVEL MOWER HOUSING
(See Figs. 17-20)
Adjustthemowerwhiletractorisparkedonlevelgroundor
driveway. Makesuretiresareproperlyinflated. Iftiresare
over or under inflated, you will not properly adjust your
mower.
NOTE: One rotation of trunnion nut is equivalent to ap-
proximately1/8inchofheightchange. Besureupper and
lowernutsaretightenedagainsttrunnionafteradjustment
hasbeencompleted.
SERVICEANDADJUSTMENTS
CAUTION: BEFOREPERFORMINGANYSERVICEORADJUSTMENTS:
• Depressclutch/brakepedal fully andset parking brake.
• Place gearshift lever in neutral (N) position.
• Place attachment clutch in “DISENGAGED” position.
• Turn ignition key “OFF” and remove key.
• Make sure the blades and all moving parts have completely stopped.
• Disconnectsparkplugwirefromsparkplugandplacewirewhereitcannotcomeincontactwith
plug.
MOWER UPSTOP ADJUSTMENT
(See Fig. 16)
• Raiseattachmentlift lever to highest (transport) posi-
tion.
• Measure distance from top of mower deck to lower
flange of chassis (dim. “A”).
• Dim. “A” should be 3-3/8 to 3-1/2 inches.
• To adjust dim. “A”, if required, lower mower to lowest
position. Removewasher and retainer springin trun-
nion,thenwithdrawtrunnionpinfrombracket. Loosen
trunnionlocknutandrotatetrunnioncounterclockwise
on lift link to increase dim. “A” or clockwise on lift link
to decrease dim. “A”.
NOTE: Each full turn of trunnion will change dim. “A” by
1/16 inch.
• Tightentrunnionlocknut.
• Re-inserttrunnionintobracketwithpinpointingtoL.H.
side of tractor. Re-install washer and retainer spring.
• Raiseliftlevertohighestpositionandrecheckdim.“A”.
Repeat adjustment if necessary.
“A”
LOWER FLANGE
OF CHASSIS
TOP OF MOWER DECK
WASHER
BRACKET
FRONT LIFT TRUNNION
FIG. 16
REAR LIFT
LINKS
BELT
ENGINE
PULLEY
MOWER
CLUTCH
ARM
MOWER
CLUTCH
SPRING RETAINER
SPRING
WASHER
FIG. 15
MOWER
STABILIZER
LINK
FRONT LIFT LINK
TRACTOR
TO REMOVE MOWER (See Fig. 15)
Mowerwillbeeasiertoremovefromtherightsideoftractor.
• Park tractor on a level surface and engage parking
brake.
• Remove key from ignition.
• Be sure that attachment clutch lever is in “DISEN-
GAGED”position.
• Lower mower deck to lowest cutting position.
• Removeretainerspringandwasherthatholdsmower
clutch spring to the mower clutch arm.
• Disconnect mower clutch spring from mower clutch
arm.
• Remove retainer springs and washers from mower
stabilizer link.
• Remove retainer springs and washers from rear lift
links.
• Removeretainerspringandwasherfromfrontliftlink.
• Withdraw front lift link, rear lift links and mower stabi-
lizer link from brackets.
• Removebelt from engine pulley.
• Raise mower lift handle to transport position.
• Turn front tires to left.
• Slide mower deck out on right side of tractor.
RETAINER
SPRING
TRUNNION
LOCKNUT
TO INSTALL MOWER (See Fig. 15)
• Reverseremovalinstructions.

18
1-1/2"
SERVICEANDADJUSTMENTS
6
3
2
1
FIG. 17
ATTACHMENT
LIFT LEVER
ATTACHMENT
HEIGHT
ADJUSTMENT
KNOB
“B” “C”
LEFT
SIDE
LEFT REAR
LIFT LINK
RIGHT
SIDE LOWER FLANGE
OF MOWER DECK
UPPER TRUNNION
NUT
LOWER TRUNNION
NUT
REAR LIFT LINK
TRUNNION
“E”
LOWER FLANGE
OF MOWER DECK MOWER HOUSING
“D”
VIEWED FROM FRONT OF TRACTOR
GROUND LINE
GROUND LINE
REAR LIFT
LINK
FIG. 18
FIG. 19
FIG. 20
• Place attachment height adjustment knob in position
“3”(SeeFig. 18).
• Lowerattachmentliftlevertoheightadjustmentknob.
SIDE-TO-SIDEADJUSTMENT(See Figs. 18 and 19)
• Measuredistancefromgroundtolowerflangeofmower
deckonbothsidesofmower(dim.“B”&“C”). Dim.“B”
& “C” should be the same.
Level mower side-to side by adjusting the left rear lift link.
• Toraiseleftsideofmower, loosen upper trunnion nut
andtightenlowertrunnionnut.
• Tolower left sideofmower,loosenlower trunnion nut
andtightenuppertrunnionnut.
FRONT-TO-BACKADJUSTMENT(SeeFigs.19and20)
To obtain the best cutting results, the mower housing
should be adjusted so the rear is approximately 1/4" to
3/4" higher than the front when the mower is in height
adjustmentposition“3”.
• Measure distance from ground line to lower flange of
deckat right frontandrightrear(dim. “D” &“E”)inline
with front and rear tires.
Raiseorlowerrearofmowerhousingbyadjustingtheright
rear lift link.
• Toraiserearofmowerhousing,loosenuppertrunnion
nutand tightenlowertrunnion nut.
• To lower rear of mower housing, loosen the lower
trunnionnutandtightenuppertrunnionnut.
• Recheckside-to-sideadjustment.
OPERATING ARM
FIG. 21
TO ADJUST BRAKE (See Fig. 21)
Your tractor is equipped with an adjustable brake system
which is mounted on the right side of the transaxle.
Iftractor requires morethan six (6)feet stopping distance
athighspeed inhighestgear,thenbrakemustbeadjusted.
• Depressclutch/brakepedalandengageparkingbrake.
• Measure distance between brake operating arm and
nut “A” on brake rod.
• Ifdistanceisotherthan1-1/2",loosenjamnutandturn
nut “A” until distance becomes 1-1/2". Retighten jam
nut against nut “A”.
• Roadtesttractorforproperstoppingdistanceasstated
above. Readjustif necessary. If stopping distance is
still greater than six (6) feet in highest gear, further
maintenance is necessary. Contact your nearest
authorizedservicecenter/department.
WITH PARKING BRAKE “ENGAGED”
NUT “A”
JAM NUT

19
TOADJUSTSTEERINGWHEELALIGNMENT
Ifsteeringwheelcrossbars arenothorizontal (lefttoright)
whenwheelsarepositionedstraightforward,removesteer-
ingwheelandreassembleperinstructionsintheAssembly
section of this manual.
FRONT WHEEL TOE-IN/CAMBER
The front wheel toe-in and camber are not adjustable on
your tractor. If damage has occurred to affect the front
wheel toe-in or camber, contact your nearest authorized
servicecenter/department.
TO REMOVE WHEEL FOR REPAIRS
(See Fig. 23)
• Block up axle securely.
• Removeaxlecover,retainingringandwasherstoallow
wheelremoval(rearwheelcontainsasquarekey-Do
not lose).
• Repairtireandreassemble.
• Onrear wheels only: align grooves in rear wheel hub
and axle. Insert square key.
• Replace washers and snap retaining ring securely in
axlegroove.
• Replaceaxlecover.
NOTE: To seal tire punctures and prevent flat tires due to
slowleaks,tire sealant may be purchasedfrom your local
parts dealer. Tire sealant also prevents tire dry rot and
corrosion.
SQUARE KEY
(REAR WHEEL ONLY)
FIG. 23
SERVICEANDADJUSTMENTS
TO REPLACE MOTION DRIVE BELT
(See Fig. 22)
Thetractor drivebeltmaybereplaced withouttools. Park
the tractor on level area. Engage parking brake. For
assistance,thereisabeltinstallationguidedecalonbottom
side of left footrest.
• Engageparkingbrake.
• Lower attachment lift lever to “lowest” position.
• Turn front wheels fully to left or right.
• Disconnect mower drive belt at engine pulley.
• Disconnect motion drive belt at clutching idler.
• Disconnectmotiondrivebeltattransaxle.Pushabove
transaxlepulley.
• Disconnect motion drive belt at frame belt keeper.
• Disconnectmotiondrivebeltatenginepulley.Thread
beltbelowmowerdrivesheaveandthroughenginebelt
keeperandenginepulley.
• Removebelt.
• Installnewbeltby reversing above procedure.
• Make sure that belt is inside all belt keepers.
IMPORTANT: REPLACE ONLY WITH SPECIFIED BY
ORIGINAL EQUIPMENT MANUFACTURER.
MOWER
DRIVE
SHEAVE
CLUTCH
PEDAL
SHAFT
MOWER LIFT
SHAFT
CLUTCHING
IDLER
FRAME BELT
KEEPER
TRANSAXLE
PULLEY
MOWER
DRIVE
BELT
ENGINE
PULLEY
ENGINE
BELT
KEEPER
FIG. 22
WASHERS
RETAINING
RING
AXLE COVER

20
FIG. 24
POSITIVE TERMINAL
CHASSIS
POSITIVE TERMINAL
CHARGED
BATTERY
CABLES
NEGATIVE TERMINAL
NEGATIVE TERMINAL
REPLACING BATTERY
(See Figs. 25 and 26)
CAUTION: Donot short battery termi-
nalsbyallowingawrenchoranyother
objecttocontactboth terminals atthe
sametime.Beforeconnectingbattery,
remove metal bracelets, wristwatch
bands,rings,etc.
Positive terminal must be connected
firsttopreventsparkingfromacciden-
tal grounding.
• Lift seat pan to raised position and open battery box
door.
• Disconnect BLACK battery cable first then RED bat-
tery cable and carefully remove battery from tractor.
• Install new battery with terminals in same position as
oldbattery.
• FirstconnectREDbatterycabletopositive(+)terminal
withhexboltandkepsnutasshown.Tightensecurely.
• ConnectBLACKgroundingcabletonegative(-)termi-
nal with remaining hex bolt and keps nut. Tighten
securely.
• Closebattery box door.
FIG. 25
FIG. 26
SEAT PAN
BATTERY
BOX DOOR
KEPS NUT
HEX
BOLT
POSITIVE (RED)
CABLE NEGATIVE (BLACK) CABLE
SERVICEANDADJUSTMENTS
TOSTARTENGINEWITHAWEAKBATTERY
(See Fig. 24)
CAUTION: Lead-acidbatteries gener-
ateexplosivegases. Keepsparks,flame
andsmokingmaterialsawayfrombat-
teries. Always wear eye protection
whenaroundbatteries.
If your battery is too weak to start the engine, it should be
recharged. (See "BATTERY" in the CUSTOMER RE-
SPONSIBILITIES section of this manual).
If “jumper cables” are used for emergency starting, follow
thisprocedure:
IMPORTANT: YOURTRACTORISEQUIPPEDWITHA12
VOLT NEGATIVE GROUNDED SYSTEM. THE OTHER
VEHICLE MUST ALSO BE A 12 VOLT NEGATIVE
GROUNDED SYSTEM. DO NOT USE YOUR TRACTOR
BATTERY TO START OTHER VEHICLES.
TO ATTACH JUMPER CABLES -
• ConnecteachendoftheRED cable to the POSITIVE
(+) terminal of each battery, taking care not to short
against chassis.
• Connect one end of the BLACK cable to the NEGA-
TIVE (-) terminal of fully charged battery.
• Connect the other end of the BLACK cable to good
CHASSISGROUND, awayfromfueltankandbattery.
TO REMOVE CABLES, REVERSE ORDER -
• BLACKcablefirstfromchassisandthenfromthefully
chargedbattery.
• RED cable last from both batteries.
