Husqvarna LTH2142 User manual

532 44 15-84 Rev. 7
ILLUSTRATED PARTS LIST
MODEL NO. 96041022300
CUSTOMER CATALOG NO. LTH2142
PRODUCT NO. 960 41 02-23

2
2 532 14 08-37 Decal, Brake Parking Sandle
3 581 62 73-01 Decal, Hood
4 532 19 68-41 Decal, Warning Engine Syms
5 532 16 03-96 Decal, V-Belt Sch.
6 532 15 97-36 Decal, Chassis Hot Muffler
7 532 18 21-66 Decal, Mower Cutfinger Symbol
9 532 16 88-69 Decal, Tick Mark
10 532 40 03-89 Decal, Warning Symbols CE
11 532 14 50-05 Decal, Bat Dan/Poi P/L Sym
12 532 17 83-02 Decal, Oper. Cruise Symbols
13 532 44 15-55 Decal, Sidepnl
15 532 15 97-37 Decal, Brake/Clutch Symbol
17 532 19 63-57 Decal, Cutfinger Warning
18 532 12 44-33 Decal, 80 DBA
19 532 43 37-74 Decal, Replacement
- - 532 16 25-98 Decal, Drawbar Load Limit
- - 532 16 69-60 Decal, Bypass Lt Hydro
- - 532 41 08-05 Pad, Footrest LH
- - 532 41 08-06 Pad, Footrest RH
- - 532 44 15-83 Manual, Operator's (English)
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
5
9
33
2
7
WHEELS & TIRES
1 532 05 91-92 Cap Valve Tire
2 532 06 51-39 Stem Valve
3 532 10 62-22 Tire F Ts 15 x 6 0 - 6 Service
4 532 05 99-04 Tube Front (Service Item Only)
5 532 13 83-36 Rim Asm 6" Front Silver Service
6 532 12 49-57 Fitting Grease (Front Wheel Only)
7 532 12 49-59 Bearing Flange (Front Wheel Only)
8 532 13 83-37 Rim Asm 8" Rear Silver Service
9 532 12 20-82 Tire R Ts 20 x 10-8 C Service
10 532 12 49-26 Tube Rear (Service Item Only)
11 532 17 50-39 Cap Axle Blk 1 50 x 1 00
- - 532 14 43-34 Sealant, Tire (10 oz. tube)
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
6
2
1
5,8
4,10
3,9
11
7
wheel_1
10
11
13
19
6
15
6
4
12
17
18
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
DECALS
27
27

3
NOTES
M
FUSE
STARTER
SOLENOID
BATTERY
ELECTRIC CLUTCH
CLUTCH/BRAKE
(PEDAL UP)
REVERSE SWITCH
(NOT IN REVERSE)
SEAT SWITCH
(NOT OCCUPIED)
SHORTING
CONNECTOR
CHASSIS
HARNESS
IGNITION
UNIT
HOUR
METER
REGULATOR
CHASSIS HARNESS
CONNECTOR
(MATING SIDE)
DASH HARNESS
CONNECTOR
(MATING SIDE)
LIGHT
SWITCH
HEADLIGHTS
STATOR
FUEL
LINE
FUEL SHUT-OFF
SOLENOID
(IF EQUIPPED)
JUNCTION
CONNECTOR
PTO SWITCH
(DISENGAGED)
S
M
B
G
L
2
3
1
6
A2
A1
M
6
3
52
41
6
5
4
3
2
1
SPARK
PLUGS GAP
(2 PLUGS ON
TWIN CYL. ENGINES)
28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)
CHARGING SYSTEM OUTPUT
9-16AMPDC@3600 RPM
(OPTIONAL)
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE RE-INSTALLED TO
PROPERLY SECURE YOUR
WIRING.
SCH12
IGNITION SWITCH
CIRCUIT
POSITION
OFF
B+A1
RUN/OVERRIDE
B+S+A1
START
M+G+A1
B+A1
RUN
“MAKE”
L+A2
POWER OUTLET
(OPTIONAL)
12V
A
AMMETER
(OPTIONAL)
BLACK
BLACK /WHITE
ORANGE
RED
BROWN
BLUE
BLUE
BLACK
BLACK
BLACKBLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
RED
RED
RED
RED
WHITE
WHITE
WHITE
GRAY
GRAY
BLACK
BLACK
B
A
G
H
D
FC
E
PTO SWITCH
B
A
H
D
C
E
BLUE BLACK
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
SCHEMATIC
38
38

4
43
41
27
25
30
33
22
79 21
40
71
34
16
42
T12S
2
90
With 12V Outlet Option
59
103
With Service Minder Option
4646
26
102
29
28
55
105
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
ELECTRICAL
32
32

5
KEY PART
NO. NO. DESCRIPTION
1 532 16 34-65 Battery
2 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4
8 532 19 32-28 Box Battery
16 532 17 61-38 Switch Interlock
21 532 40 02-52 Harness Asm Light w/4152J
22 532 00 41-52 Bulb Light #1156
25 532 41 28-94 Cable Battery 6 Ga. Red 14.5
26 532 17 51-58 Fuse 20 AMP
27 873 51 04-00 Nut Keps Hex 1/4-20 Unc
28 532 19 88-85 Cable 18" Rear. BATT.
29 532 40 15-45 Switch Seat
30 532 19 33-50 Switch Ignition
33 532 41 19-33 Key/Chain
34 532 11 07-12 Switch Light
40 532 40 11-04 Harness Ign.
41 817 72 04-08 Bolt Hex Hd. Fin 1/4-20 x 1/2 Gr. 5
42 532 13 15-63 Cover Terminal Red
43 532 19 25-07 Solenoid
46 532 40 17-63 Hourmeter
50 532 17 46-51 Switch PTO
55 817 06 05-12 Screw 5/16-18 x 3/4
71 532 40 04-49 Harness Ign. Chass. Tex
79 532 17 52-42 Socket, Asm. Bulb
90 532 43 53-95 Cover Terminal Battery
102 532 40 44-54 Harness Pigtail K46 TEX ROS
105 532 40 75-68 Switch Reverse TT Pedal Control
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm.
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
ELECTRICAL
32
32

6
37
180
chassis-tex_lt husq_8_r4
177
68
213 213
218
194
194
228
228
159
159
194
52
217
189
189
152
162
282
282
282
176
176
176
137
137
5
130 150
175
36
36
285
182
286
283
199
284
68
68
68
68
183
183
236
236
34
235
235
234
206
203
234
205
202 25
14
191
297
204
15
3
130
239
238
18
130
287
130
130
151
214
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
CHASSIS AND ENCLOSURES
39
39

7
3 532 40 50-12 Logo
5 532 40 75-94 Dash
14 532 41 10-73 Hood
15 532 41 10-79 Lens LH
18 532 42 69-63 Grille
25 532 41 10-78 Lens RH
34 532 19 61-25 Plate Engine
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 41 63-07 Fender
52 873 68 05-00 Nut Crown Lock 5/16
68 817 49 05-08 Screw THDROL 5/16-18 x 1/2
130 532 41 63-58 Screw #10 x 0.750 BOS Thread
137 532 40 75-90 Bumper, Dash
150 532 40 75-37 Air Duct
151 532 40 78-07 Bracket Pivot
152 532 19 95-35 Shield Browning
159 817 00 06-12 Screw Hex Wsh Thdr 3/8-16 x 3/4
162 532 14 24-32 Screw
175 532 19 94-72 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8
177 532 19 52-28 Bushing Steering
180 532 19 54-57 Chassis
182 532 40 71-76 Dash Lower
183 874 52 05-20 Bolt 5/16-18 unc x 1-1/4
189 817 00 05-12 Screw 5/16-18 x 3/4
191 532 41 65-01 Insert Reflective RH
194 873 90 05-00 Nut Lock Hex Flange 5/16-18 NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
199 532 41 34-85 Plate Deck Lift
202 532 41 10-75 Vent Side Hood RH
203 532 41 10-74 Vent Side Hood LH
204 532 41 17-68 Vent Top Hood
205 532 41 10-76 Skirt Side RH
206 532 41 10-77 Skirt Side LH
213 874 76 05-12 Bolt 5/16-18 x 3/4
214 532 19 91-45 Clip Retainer
217 532 40 91-67 Rod Pivot Hood
218 532 19 63-95 X-Piece Hood Stop
228 532 19 51-61 Stud Fastener
234 532 40 47-42 Bumper Hood
235 532 40 61-29 Spacer Fender
236 873 93-05-00 Nut Lock 5/16-18 unc Center
238 532 41 11-19 Trim
239 532 40 48-83 Clip Tinnerman
282 532 41 41-10 Clip Retainer
283 532 41 63-16 Console Deck Lift
284 532 41 78-87 Console Control Pedal
285 532 41 63-15 Console Insert RH
286 532 41 63-17 Console Insert LH
287 817 60 04-06 Screw Hex Washead 1/4-20 x 3/8
297 532 40 66-65 Insert Reflective LH
- - 532 43 18-83 Kit Bumper
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
CHASSIS AND ENCLOSURES
39
39

8
52
51
170
216
143 171
225
125
drive-tex_K46_pedal_69_r1
2
2
73
73 33
205
1
116
33
230
230
183
183
205
116
56
64
188
161
35
184
167
160
42
29
15
159
159
221
186
189
49
187
50
51
52
51
190
185
125
226
227
125
80 125
210
214
215
153
166
211
222
17
163
153
99
196
197
211
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
DRIVE
40
40

9
KEY PART
NO. NO. DESCRIPTION
1 – – – – – – Transaxle, TUFFTORQ K46 BT
(Order parts from transaxle
manufacturer)
2 532 12 35-83 Key
15 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga.
17 532 41 36-78 Spring, Brake
29 532 40 38-06 Rod, Brake
33 812 00 00-01 Ring E
35 532 40 10-31 Rod, Brake, Park
42 532 12 48-72 Cover, Foot Pedal
49 872 11 06-14 Bolt
50 532 19 43-27 Pulley Idler Flat
51 873 90 06-00 Lock Nut 3/8-16
52 532 19 43-26 Idler V-Groove 910" Offset
56 532 13 09-69 V-Belt, Drive
64 532 19 78-65 Shaft Asm. Pedal Brake Control
73 874 49 05-40 Bolt Hex Flghd 5/16-18 x 2-1/2 G5
80 532 44 06-19 Bracket Strap Torque
99 532 41 57-42 Rod Spring Bypass
116 873 90 05-00 Nut Lock Hex Flange 5/16-18
125 817 00 05-12 Screw 5/16-18 x 3/4
143 817 49 05-08 Screw 5/16-18 x 1/2
153 532 12 47-88 Retainer Spring
159 876 02 04-12 Pin Cotter 1/8 x 3/4
160 532 16 94-84 Retainer Clip
161 532 10 57-09 Spring, Return, Clutch
163 532 44 82-75 Rod Pedal Control
166 532 42 91-64 Nut Push
167 532 40 52-57 Latch Brake Parking
170 532 19 43-22 Keeper Belt Centerspan
171 872 11 06-16 Bolt RDHD SQNK 3/8-16 unc x 2
183 532 13 70-57 Spacer Split
184 532 40 97-47 Handle Parking Brake
185 872 11 06-22 Bolt RDHD 3/8-16 unc x 2-3/4 Gr. 5
186 532 19 43-21 Spacer Retainer
187 819 13 32-10 Washer
188 532 19 43-23 Link Clutch Ground Drive
189 532 19 43-17 Bellcrank Ground Drive
190 532 19 43-18 Keeper Bellcrank Ground Drive
196 817 00 06-16 Screw 3/8-16 x 1
197 532 19 58-04 Bracket Clutch Anti-Rotation
205 532 12 17-48 Washer
210 532 40 09-80 Rocker Asm. Pedal Control
211 532 12 01-83 Bearing Nylon
214 532 42 12-63 Pedal Forward
215 532 40 17-23 Pedal Reverse
216 532 19 61-31 Bracket Pulley Idler
221 532 40 31-87 Retainer Spring Clip Handle
222 879 21 20-10 Washer 21/32 x 1-1/4 x 10 Ga.
225 532 40 33-19 Keeper Belt Trans.
226 532 40 15-64 Bracket Mount Torque
227 817 49 05-12 Screw Thdrol 5/16-18 x 3/4
230 532 18 89-67 Washer Hardened
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
DRIVE
40
40

10
21
20
OPTIONAL EQUIPMENT
Spark Arrester
29
37
28
37
engine-tex_BS_44
12
11
41
42
85
9
90
84
45
1
18
15
97
96
94
69
79
2
87
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
ENGINE
24
24

11
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 – – – – – – Engine Briggs 33M777-2495-G1
(439011)(Order parts from engine
manufacturer)
2 532 18 86-55 Muffler
9 532 19 43-20 Keeper Belt Engine
11 532 18 05-05 Clutch, Ogura
12 532 40 50-97 Pulley Engine
15 532 40 75-45 Tank Fuel 1.5
18 532 43 02-20 Cap Fuel
20 532 18 38-97 Control Throttle
21 532 41 63-58 Screw #10 x 0.750 BOS Thread
28 532 13 70-40 Fuel Line
29 532 13 71-80 Spark Arrester Kit
37 532 12 34-87 Clamp Hose
41 532 12 61-97 Washer 1-1/2 OD. x 15/32 ID x 250
42 810 04 07-00 Wahser Lock Hvy HLCL Spr. 7/16
45 873 51 04-00 Nut Keps Hex 1/4-20 unc
69 532 16 52-91 Gasket
79 532 19 23-34 Screw Socket HD. 5/16-18 x .75
84 817 06 06-20 Screw 3/8-16 x 1 1/4
85 532 17 39-37 Bolt Hex 7/16-20 x 4 x Gr. 5-1.5 Thr
87 532 17 18-77 Bolt 5/16-18 X 3/4
90 817 00 06-16 Screw 3/8-16 x 1
94 581 88 09-01 Tube Exhaust
96 819 09 14-16 Washer 9/32 x 7/8 x 16 Ga.
97 817 67 04-12 Screw 1/4-20 x 3/4
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
ENGINE
24
24
Engine Power Rating Information
The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive Engi-
neers) code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance has been obtained and cor-
rected in accordance with SAE J1995 (Revision 2002-05). Torque values are derived at 3060 RPM; horsepower values are
derived at 3600 RPM. Actual gross engine power will be lower and is affected by, among other things, ambient operating
conditions and engine-to-engine variability. Given both the wide array of products on which engines are placed and the va-
riety of environmental issues applicable to operating the equipment, the gas engine will not develop the rated gross power
when used in a given piece of power equipment (actual “on-site” or net power). This difference is due to a variety of factors
including, but not limited to, accessories (air cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.), application
limitations, ambient operating conditions (temperature, humidity, altitude), and engine-to-engine variability. Due to manu-
facturing and capacity limitations, Briggs & Stratton may substitute an engine of higher rated power for this Series engine.

12
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
STEERING ASSEMBLY
41
41
61
35
19
60
59
58
5
62
15
14
13
13
53
8
70
68
69
16
28
28
13
22
64
4
15
14
6
9
87
9
87
67
67
66
6
118
118
118
118
2
63
57
57
63
71
21
20
45
33
72
1
26
steering-tex_HUSQSR_19

13
KEY PART
NO. NO. DESCRIPTION
1 532 41 64-80 Wheel, Steering
2 532 41 35-91 Axle Asm., Front
4 532 40 30-87 Spindle Asm., LH
5 532 40 30-88 Spindle Asm., RH
6 532 12 49-31 Washer, Thrust
7 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
8 812 00 00-29 Ring, Klip #T5304-75
9 532 12 12-32 Cap, Spindle
13 532 12 17-49 Washer 25/32 x 1-1/4 x 16 Ga.
14 810 04 06-00 Washer, Lock Hvy Hlcl Spr 3/8
15 873 54 06-00 Nut, Crown Lock 3/8-24 unf
16 532 42 93-73 Shaft Steering
19 532 19 47-29 Plate Steering
20 532 41 11-39 Boot, Steering
21 532 18 67-37 Adapter, Wheel Steering
22 532 42 05-37 Strg.
26 532 41 59-87 Insert, Wheel Steering
28 817 00 06-12 Screw 3/8-16 x 3/4
33 810 04 05-00 Washer Lock 5/16
35 532 19 47-32 Gear, Sector Plate
45 819 11 38-12 Washer 11/32 x 3/8 x 12 Ga.
53 532 18 89-67 WasherHardened.793x1.637x.060
57 532 40 74-65 Bracket Upstop
58 532 19 47-47 Bolt Shoulder Sector Pivot CFM
59 532 19 47-48 Washer Thrust Sector Steering
60 873 97 10-00 Nut Flange Lock 5/8-11
61 532 19 47-40 Draglink, LH
62 532 19 47-41 Draglink, RH
63 817 00 05-12 Screw 5/16-18 x 3/4
64 532 19 98-49 Retainer Clip Spring Steering
66 871 02 07-48 Bolt Hex Fghd 7/16-14 x 3 Serr
67 532 19 47-37 Bushing PM Front Axle
68 873 90 07-00 Nut Lock Flange 7/16-14 Gr. 5
69 532 19 91-62 Washer 1.5 x .505 x .118
70 532 19 61-97 Bracket Deck Susp. Front
71 532 19 07-52 Shaft Extension Steering
72 532 42 89-82 Bolt Fin Hex 5/16-18 x 4 w/Patch
118 532 40 60-13 Bushing
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
STEERING ASSEMBLY
41
41

14
15
14
13
11
8
68
30
31
32
33
145
190
34
55 56
57
62
188
189
1
69
21
21
21
69
69
20
59
40
19
19
6
6
42_D_elec-Tex_17_r2
21
24
25
26
27
29
23
189
188
36
40
241
242
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
MOWER DECK
44
44
117 119
116
118
117
116
118
119

15
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 532 40 29-99 Mower Deck Assembly, 42"
6 532 19 51-86 Arm Susp. Rear
8 532 19 30-03 Bolt/Washer Asm 7/16-20 unf
(The following Blades are available)
11 532 13 89-71 Blade Mower 42” Hi-Lift
(for bagging and discharging)
13 532 19 28-72 Shaft Assembly, Mandrel
14 532 18 72-81 Housing, Mandrel
15 532 11 04-85 Bearing, Ball, Mandrel
19 532 19 65-39 Bolt, Shoulder
20 532 15 97-70 Baffle, Vortex
21 873 68 05-00 Nut
23 532 19 25-57 Bracket, Deflector Mower 42"
24 532 10 53-04 Cap, Sleeve 80 x 112 Blk Mower
25 532 19 70-26 Spring, Torsion, Deflector
26 532 11 04-52 Nut, Push Phos & Oil
27 532 40 30-04 Shield, Deflector 42" Blk
29 532 13 14-91 Rod, Hinge 42" 6 75 W/G
30 532 17 39-84 Screw Thdrol
31 532 18 76-90 Washer, Spacer Mower Vented
32 532 15 35-35 Pulley, Mandrel
33 532 40 02-34 Nut, Toplock
34 872 11 06-12 Bolt Carr SH 3/8-16 x 1-1/2 Gr. 5
36 532 19 73-79 Pulley Idler Flat
40 873 90 06-00 Nut Lock 3/8-16
55 532 43 71-10 Arm, Idler
56 532 19 90-92 Spacer, Retainer
57 817 00 06-16 Screw 3/8-16 x 1
59 532 14 10-43 Guard TUV Idler
62 872 11 06-16 Bolt Rdhd Sqnk 3/8-16 unc x 2
68 532 14 49-59 V-Belt, 42" Mower
69 872 14 05-05 Bolt, Carriage 5/16-18 x 5/8
116 532 12 48-42 Bolt, Shoulder
117 532 18 86-06 Wheel, Gauge
118 873 90 06-00 Nut Centerlock 3/8-16 unc
119 819 12 14-14 Washer 3/8 x 7/8 x 14
145 532 19 31-97 Pulley, Idler, Flat
188 532 19 51-61 Stud Fastner W/D Anti-Rotation
189 873 90 05-00 Nut Lock Hex Flange 5/16-18
190 532 19 72-51 Spring Mower Drive
241 532 15 29-27 Screw TT #10-32.5 3/8 Flange
242 532 41 55-98 Port Washout
- - 532 19 28-70 Mandrel Assembly (Includes Housing
Shaft and Shaft Hardware Only -
Pulley Not Included)
- - 532 40 12-24 Replacement Mower, Complete
(Std. deck Order separately gauge
wheel components Key Nos. 116-119)
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
MOWER DECK
44
44

16
7
3
87
10
88
2
89
90 98
97
97
lift-tex_17_r3 *Key 91 may be substituted for Key 101
91
101*
87
100
89
89
87
2 532 42 20-27 Shaft Asm., Lift
3 532 19 52-31 Lever Asm., Lift RH
7 532 41 15-55 Grip, Lever
10 532 19 63-14 Spring Torsion
87 532 19 42-09 Pin Cotter 7/16 Bow Tie Lock
88 532 41 07-10 Spring Lift Assist
89 819 19 19-12 Washer Clear Zinc
90 532 19 42-08 Pin Cotter 5/16 Bow Tie Lock
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
91 532 19 51-81 Link Lift Susp Mower Rear
97 817 00 06-12 Screw Hex WSH THDR 3/8-16 x 3/4
98 532 19 52-70 Link Lift Susp. Front Mower
100 873 93 06-00 Nut Centerlock 3/8-16
101 532 40 70-03 Link Asm. Lift Fxd
KEY PART
NO. NO. DESCRIPTION
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
MOWER LIFT
45
45

17
1 532 42 40-67 Seat
2 532 18 01-66 Bracket Pivot Fender
3 532 14 06-75 Strap, Asm Fender
6 873 80 06-00 Nut, Lock w/Ins. 3/8-16 unc
7 532 12 41-81 Spring, Seat Cprsn
8 532 17 18-77 Bolt 5/16-18 unc x 3/4 w/Sems
10 532 19 69-77 Pan, Seat
21 532 17 18-52 Bolt, Shoulder 5/16-18
37 873 80 05-00 Nut, Lock 5/16-18 unc
40 532 19 76-61 Handle Slide
41 532 19 82-00 Spring Latch Seat
43 874 76 06-12 Bolt Fin Hex 3/8-16 unc x 3/4
44 819 13 38-12 Washer 13/32 x 2-3/8 x 12 Ga.
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
2
6
1
40
10
37
37
21
21
3
41
7
8
7
8
8
8
seat-tex_6.5SL_1_r1
44
43
TRACTOR - - MODEL NO. LTH2142 (96041022300), PRODUCT NO. 960 41 02-23
SEAT ASSEMBLY
42
42

06.10.13 CL
