EN User Manual
Washing Machine
QW36S114

CONTENTS
1. SAFETY INFORMATION............................................................................................3
2. SAFETY INSTRUCTIONS..........................................................................................4
3. PRODUCT DESCRIPTION........................................................................................ 7
4. TECHNICAL DATA.....................................................................................................7
5. INSTALLATION.......................................................................................................... 8
6. ACCESSORIES........................................................................................................11
7. CONTROL PANEL................................................................................................... 12
8. DIAL AND BUTTONS............................................................................................... 14
9. PROGRAMMES ...................................................................................................... 16
10. SETTINGS..............................................................................................................20
11. BEFORE FIRST USE............................................................................................. 20
12. DAILY USE.............................................................................................................20
13. HINTS AND TIPS................................................................................................... 25
14. CARE AND CLEANING..........................................................................................27
15. TROUBLESHOOTING............................................................................................32
16. CONSUMPTION VALUES......................................................................................35
17. QUICK GUIDE........................................................................................................ 37
18. ENVIRONMENTAL CONCERNS........................................................................... 38
DEAR CUSTOMER
Thank you for choosing this Husqvarna-Electrolux product. We have created it to
give you impeccable performance for many years, with innovative technologies that
help make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.husqvarna-electrolux.se/support
Register your product for better service:
www.husqvarna-electrolux.se
Buy Accessories, Consumables and Original spare parts for your appliance:
www.husqvarna-electrolux.se/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.husqvarna-electrolux.se2

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Children should be supervised to ensure that they do
not play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
ENGLISH 3

•This appliance is intended to be used in household
and similar applications such as:
–staff kitchen areas in shops, offices and other
working environments;
–by clients in hotels, motels, bed & breakfast and
other residential type environments;
–areas for communal use in blocks of flats or in
launderettes.
•The appliance maximum load is 10 kg. Do not exceed
the maximum load of each programme (refer to the
“Programmes” chapter).
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Remove all the packaging and the
transit bolts including rubber bush
with plastic spacer.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
www.husqvarna-electrolux.se4

future they must be reattached to lock
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Follow the installation instructions
supplied with the appliance.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
• Do not install the appliance directly
above a floor drain.
• Do not spray water on the appliance
and do not expose it to excessive
humidity.
• Do not install the appliance where the
appliance door cannot be fully
opened.
• Do not put a closed container to
collect possible water leakage under
the appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• WARNING: This appliance is
designed to be installed / connected
to a grounding connection in the
building.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Water connection
• The inlet water shall not exceed
25 °C.
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• Do not use an extension hose if the
inlet hose is too short. Contact the
Authorised Service Centre for the
replacement of the inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing
of the appliance with the use of water
in the factory.
• You can extend the drain hose to
maximum 400 cm. Contact the
Authorised Service Centre for the
other drain hose and the extension.
• Make sure that there is access to the
tap after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Follow the safety instructions on the
detergent packaging.
ENGLISH 5

• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber
parts of the washing machine.
Prewash such fabrics by hand before
loading them into the washing
machine.
• Do not touch the glass door while a
programme operates. The glass can
get hot.
• Make sure that all metal objects are
removed from the laundry.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 10 years after the model
has been discontinued: motor and
motor brushes, transmission between
motor and drum, pumps, shock
absorbers and springs, washing drum,
drum spider and related ball bearings,
heaters and heating elements,
including heat pumps, piping and
related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware
including reset software, door, door
hinge and seals, other seals, door
locking assembly, plastic peripherals
such as detergent dispensers. Please
note that some of these spare parts
are only available to professional
repairers, and that not all spare parts
are relevant for all models.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
www.husqvarna-electrolux.se6

3. PRODUCT DESCRIPTION
3.1 Appliance overview
1 2 3 9
5
6
7
4
10
8
11 12
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
8Drain hose
9Inlet hose connection
10 Mains cable
11 Transit bolts
12 Hose support
00000000
00A
Mod. xxxxxxxxx
000V ~ 00Hz 0000 W
910000000 00
A
B
C
Prod.No.
D
The rating plate reports the model name (A) ,
product number (B), electrical ratings (C) and
serial number (D).
4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59,6 cm /84,7 cm /57,6 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
ENGLISH 7

Level of protection against ingress of solid particles and
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against mois‐
ture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
8 bar (0.8 MPa)
Water supply 1) Cold water
Maximum Load Cotton 10 kg
Spin Speed Maximum spin speed 1351 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
1. Open the door. Remove all the items
from the drum.
Accessories delivered
with the appliance may
vary depending on the
model.
2. Put the packaging element on the
floor behind the appliance and
carefully put it down onto its rear
side. Remove the polystyrene
protection from the bottom.
1
2
CAUTION!
Do not lay washing
machine on its front.
3. Put the appliance back into an
upright position. Remove the power
supply cable and the drain hose from
the hose holders.
www.husqvarna-electrolux.se8

WARNING!
It is possible to see
water flowing from the
drain hose. This is
because the washing
machine has been
tested at the factory.
4. Remove the three transit bolts and
pull out the plastic spacers.
We recommend that
you keep the
packaging and the
transit bolts for any
transport of the
appliance.
5. Put the plastic caps, that you find in
the user manual bag, in the holes.
5.2 Information for
installation
Positioning and levelling
Adjust the appliance correctly to prevent
vibration, noise and movement of the
appliance when it operates.
1. Install the appliance on a flat hard
floor. The appliance must be levelled and
stable. Make sure that the appliance
does not touch the wall or other units and
there is air circulation below the
appliance.
2. Loosen or tighten the feet to adjust the
level. All feet must rest firmly on the floor.
WARNING!
Do not put cardboard, wood
or equivalent materials
below the appliance feet to
adjust the level.
The inlet hose
CAUTION!
Make sure there is no
damage to hoses and there
are no leaks from the
couplings. Do not use an
extension hose if the inlet
hose is too short. Contact
the service centre for a
replacement inlet hose.
1. Connect the water inlet hose to the
back of the appliance.
20º20º
45º45º
2. Position it toward left or right
depending on the positon of the water
tap. Make sure that the inlet hose is not
in vertical position.
3. If necessary, loosen the ring nut to set
it in the correct position.
4. Connect the water inlet hose to the
cold water tap with 3/4'' thread.
WARNING!
The inlet water shall not
exceed 25 °C.
Water drainage
ENGLISH 9

The drain hose should stay at a height of
no less than 60 cm and not more than
100 cm.
You can extend the drain
hose to maximum 400 cm.
Contact the authorised
service centre for the other
drain hose and the
extension.
It is possible to connect the drain hose in
different ways:
1. Make a U shape with the drain hose
and put it around the plastic hose guide.
2. On the edge of a sink - Fasten the
guide to the water tap or to the wall.
Make sure that the plastic
guide cannot move when the
appliance drains and the
drain hose end is not
immersed in the water.
There may be a return of
dirty water into the
appliance.
3. If the end of the drain hose looks like
this (see the picture), you can push it
directly into the stand pipe.
4. To a stand pipe with vent hole - Insert
the drain hose directly into a drain pipe.
Refer to the illustration.
The end of the drain hose
must always be ventilated ,
i.e. the inner diameter of the
drain pipe (min. 38 mm -
min. 1.5") must be larger
than the external diameter of
the drain hose.
5. Without the plastic hose guide, to a
sink spigot- Put the drain hose in the
spigot and tighten it with a clamp. Refer
to the illustration.
Make sure that the drain hose makes a
loop to prevent particles going into the
appliance from the sink.
www.husqvarna-electrolux.se10

ø16
1
W011
2
Connect the drain hose to the spigot and
tighten it with a clamp. Make sure that
the drain hose makes a loop to prevent
particles going into the appliance from
the sink.
6. Position the hose directly to a built-in
drain pipe in the room wall and tighten it
with a clamp.
5.3 Water-stop device
The inlet hose has a water stop device.
This device prevents water leaks in the
hose because of its natural ageing.
The red sector in the window «A» shows
this fault.
A
If this occurs, close the water tap and
contact the authorized service centre to
replace the hose.
5.4 Electrical connection
At the end of installation you can connect
the mains plug to the mains socket.
The rating plate on the inner edge of the
appliance door and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are
compatible with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any
other appliances in use.
Connect the appliance to an earthed
socket.
The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install
this appliance, contact our Authorised
Service Centre.
The manufacturer does not accept any
responsibility for damage or injury
through failure to comply with the above
safety precaution.
6. ACCESSORIES
6.1 Available from authorised
dealer
Read carefully the instructions supplied
with the accessory.
ENGLISH 11

Only appropriate
accessories approved by
HUSQVARNA ensure the
safety standards of the
appliance. If unapproved
parts are used, any claims
will be invalidated.
6.2 Fixing plate kit
If you install the appliance on a plinth
that is not an accessory supplied by
HUSQVARNA, secure the appliance in
the fixing plates.
Read carefully the instructions supplied
with the accessory.
6.3 Stacking kit
The tumble dryer can be stacked on the
top of the washing machine only by
using the correct stacking kit.
WARNING!
Do not put the tumble dryer
under the washing machine.
Verify the compatible
stacking kit by checking the
depth of your appliances.
7. CONTROL PANEL
7.1 Special features
Your new washing machine meets all
modern requirements for an effective
treatment of laundry with low water,
energy and detergent consumption and
will care for fabrics.
• The AutoAdjust System detects the
laundry load weight defining the
programme duration in 30 seconds.
The washing programme is tailored to
the laundry load and the type of fabric
without consuming more time, energy
and water than necessary. Read the
paragraph "The AutoAdjust load
detection " for more details.
7.2 Control panel description
23 4 5
11 10 7
1
6
89
www.husqvarna-electrolux.se12

1Programme dial
2Display
3Delay Start touch button
4Time Manager touch button
5Start/Pause touch button
6Easy Iron touch button
7Extra Rinse touch button
8Stain touch button
9Spin reduction options touch button
• No Spin option
• Rinse Hold option
• Night option
10 Temp. touch button
11 On/Off push button
7.3 Display
A B C D
E
FG
ADoor locked indicator.
BDelay start indicator.
CThe digital indicator can show:
• Programme duration (e. g. ).
• Delay time (e. g. ).
• Cycle end ( ).
• Warning code (e.g. ).
DTime Manager bars level indicator.
EDrum clean indicator.
FChild safety lock indicator.
GAdd garments indicator. Illuminates at the beginning of the
Wash phase, while the user can still pause the appliance
and add more laundry.
ENGLISH 13

8. DIAL AND BUTTONS
8.1 Introduction
The options/functions are
not available with all
washing programmes.
Check the compatibility
between options/functions
and washing programmes in
the "Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set incompatible options/
functions.
8.2 On/Off
Press this button for a few seconds to
activate or deactivate the appliance. Two
different tunes sound while switching the
appliance on or off.
As the Stand-by function automatically
deactivates the appliance after several
minutes to reduce the energy
consumption, you may need to activate
the appliance again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
8.3 Temp.
When you select a washing programme,
the appliance automatically proposes a
default temperature.
The indicator Cold = cold water.
The indicator of the set temperature
comes on.
8.4 Spin
When you set a programme, the
appliance automatically sets the
maximum spin speed allowed except
programme Denim.
Additional spin options:
•No Spin . The related indicator
comes on.
Set this option to deactivate all spin
phases. The appliance performs only
the draining phase of the selected
washing programme. Set this option
for very delicate fabrics. The rinse
phase uses more water for some
washing programmes
•Rinse Hold . The related indicator
comes on.
The final spin is not performed. The
water of the last rinse is not drained
out to prevent the fabrics from
creasing. The washing programme
ends with water in the drum.
The door stays locked and the drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
If you touch the Start/Pause
button, the appliance performs the
spinning phase and drains the water.
•Night . The related indicator
comes on.
The intermediate and the final
spinning phases are suppressed and
the programme ends with water in the
drum. This helps to reduce creasing.
The door stays locked. The drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are
available. In some programmes the
rinses are performed with more water.
If you touch the Start/Pause
button, the appliance performs only
the draining phase.
The appliance empties the
water out automatically after
approximately 18 hours.
8.5 Stain
Touch this button to add the stain phase
to a programme.
The corresponding indicator above the
touch button illuminates.
Use this option for laundry with hard
stains to remove.
When you set this option, put the stain
remover into compartment .
www.husqvarna-electrolux.se14

This option increases the
programme duration.
This option is not available
with a temperature lower
than 40 °C.
8.6 Permanent Extra Rinse
With this option you can add a few rinses
according to the selected washing
programme.
Use this option for people with allergies
to detergent residues and with sensitive
skin.
This option increases the
programme duration.
The corresponding indicator above the
touch button illuminates and also stays
permanently on during next cycles until
this option is deactivated.
8.7 Easy Iron
The appliance carefully washes and
spins the laundry to prevent the creases.
The appliance decreases the spin speed,
uses more water and adapts the
programme duration to the type of
laundry.
The related indicator comes on.
8.8 Delay Start
With this option you can delay the start of
a programme to a more convenient time.
Touch the button repeatedly to set the
required delay. The time increases in
steps of 1 hour up to 20 hours.
The display shows the indicator and
the selected delay time. After touching
the Start/Pause button, the appliance
begins the countdown and the door is
locked.
8.9 Time Manager
With this option you can reduce the
programme duration depending on the
load size and the degree of soiling. This
adjustment should be made after the
setting of Temp. and Spin .
When you set a washing programme, the
display shows the default duration and
dashes.
Touch Time Manager button to
reduce the programme duration
according to your needs. The display
shows the new programme duration and
a number of dashes will decrease
accordingly:
suitable for a full load of normally
soiled garments.
a quick cycle for a smaller lightly
soiled garments (max. half load
recommended).
the shortest cycle to freshen up a
small amount of laundry.
The Time Manager is available only with
the programmes in the table.
indicator
Eco 40-60
Cottons
Synthetics
1) ■ ■ ■
■ ■ ■
■ ■ ■
1) Defaullt duration for all programmes.
8.10 Start/Pause
Touch the Start/Pause button to
start, pause the appliance or interrupt a
running programme.
ENGLISH 15

9. PROGRAMMES
9.1 Programme Chart
Programme
Default temper‐
ature
Temperature
range
Reference
spin speed
Spin speed
range
Maximum
load
Programme description
(Type of load and level of soiling)
Eco 40-60
40 °C 1)
1400 rpm
(1400- 800
rpm)
10 kg White cotton and fast-coloured cotton.
Normally soiled items. The energy con‐
sumption decreases and the time of the
washing programme is extended, ensur‐
ing good washing results.
Cottons
40°C
90°C - Cold
1400 rpm
(1400- 800
rpm)
10 kg White cotton and coloured cotton. Nor‐
mally, heavily and lightly soiled items.
Synthetics
40°C
60°C - Cold
1200 rpm
(1200- 800
rpm)
4 kg Synthetic items or mixed fabric items.
Normally soiled items.
Delicates
30°C
40°C - Cold
1200 rpm
(1200- 800
rpm)
2 kg Delicate fabrics such as acrylics, vis‐
cose and mixed fabrics requiring gen‐
tler washing. Normally and lightly soiled
items.
Wool/Silk
40 °C
40°C - Cold
1200 rpm
(1200- 800
rpm)
1,5 kg Machine washable wool, hand washa‐
ble wool and other fabrics with «hand
washing» care symbol2).
Rinse 1400 rpm
(1400- 800
rpm)
10 kg To rinse and spin the laundry. All fab‐
rics, except woollens and very delicate
fabrics. Reduce the spin speed accord‐
ingly to the type of laundry.
Spin/Drain
3)
1400 rpm
(1400 -800
rpm)
10 kg All fabrics, except woollens and deli‐
cate fabrics. To spin the laundry and to
drain the water in the drum.
CleanBoost
60 °C
1400 rpm
(1400- 800
rpm)
10 kg White cotton items. This programme re‐
moves micro-organisms thanks to a
washing phase with the temperature
maintained above 60°C for several mi‐
nutes. This helps remove germs, bacte‐
ria, micro-organism and particles. An ad‐
ditional rinsing phase ensures a proper
removal of detergent residues and pol‐
lens/allergenic items. In this way the
wash is more effective.
www.husqvarna-electrolux.se16

Programme
Default temper‐
ature
Temperature
range
Reference
spin speed
Spin speed
range
Maximum
load
Programme description
(Type of load and level of soiling)
Outdoor
30 °C
40 °C - Cold
1200 rpm
1200 rpm -
800 rpm
2 kg4)
1 kg5)
Do not use fabric softener
and make sure that there
is no softener residue in
the detergent dispenser.
Outdoor clothing, technical, sport fab‐
rics, waterproof and breathable jack‐
ets, shell jackets with a removable
fleece or inner insulation. The recom‐
mended laundry load is 2 kg.
This programme can also be used as wa‐
ter-repellent restoring cycle, specifically
tailored for treating clothes with a hydro‐
phobic coating. To perform the water-re‐
pellent restoring cycle, proceed as fol‐
lows:
• Pour the washing detergent in the
compartment .
• Pour a special water-repellent restorer
for fabric in the drawer compartment
for fabric softener .
• Reduce the laundry load to 1 kg.
To further improve the wa‐
ter-repellent restoring ac‐
tion, dry the laundry in a
tumble dryer by setting the
Outdoor drying pro‐
gramme (if available and if
the garment care label
permits tumble drying).
Duvet
40 °C
60°C- Cold
800 rpm
(800- 800
rpm)
3 kg Special programme for synthetic or
feather and down filled blanket, duvet,
bedspread and so on. Use liquid delicate
detergent, like wool detergent
Sport
30 °C
40°C - Cold
1200 rpm
(1200- 800
rpm)
4 kg Synthetic and delicate items. Lightly
soiled items or items to refresh.
ENGLISH 17

Programme
Default temper‐
ature
Temperature
range
Reference
spin speed
Spin speed
range
Maximum
load
Programme description
(Type of load and level of soiling)
Denim
30 °C
40 °C - Cold
800 rpm
(1200 - 800
rpm)
3 kg Special programme for Denim clothing
with delicate washing phase to mini‐
mize colour fading and marks. For bet‐
ter care a reduced load size is recom‐
mended.
Rapid 20min
30 °C
40 °C - 30 °C
1200 rpm
(1200- 400
rpm)
1,5 kg Cotton and synthetic items . Lightly
soiled or worn only once.
60min Easy‐
Wash
30°C
60°C - 30°C
1400 rpm
(1400- 800
rpm)
5 kg Cotton and fast-coloured synthetic items.
Complete washing programme that, in
only 60 minutes, washes the daily soiled
laundry intensively and ensures a good
washing performance in a short time.
1) According to Commission Regulation EU 2019/2023, this programme at 40 °C is able to clean normal‐
ly soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
For the reached temperature in the laundry, the programme duration and other data,
please refer to 'Consumption Values' chapter.
The most efficient programmes in terms of energy consumption are generally those that
perform at lower temperatures and longer duration.
2) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
3) Set the spin speed. Make sure it is suitable for the type of fabric being washed. If you set the No Spin
option then only the drain phase is available.
4) Washing programme.
5) Washing programme and waterproofing phase.
Programme options compatibility
Programme
OPTIONS
Eco 40-60 ■ ■ ■ ■ ■ ■ ■
Cottons ■ ■ ■ ■ ■ ■ ■ ■ ■
Synthetics ■ ■ ■ ■ ■ ■ ■ ■ ■
Delicates ■ ■ ■ ■ ■ ■
Wool/Silk ■ ■ ■ ■
www.husqvarna-electrolux.se18

Programme
OPTIONS
Rinse ■ ■ ■ ■ ■
Spin/Drain ■ ■ ■
CleanBoost ■ ■ ■ ■ ■ ■
Outdoor ■ ■ ■ ■ ■
Duvet ■ ■
Sport ■ ■ ■ ■ ■ ■
Denim ■ ■ ■ ■ ■ ■ ■ ■
Rapid 20min ■ ■ ■
60min EasyWash ■ ■ ■ ■ ■
Suitable detergents for washing programmes
Programme Universal
powder1)
Liquid Uni‐
versal
Liquid for
coloureds
Delicates
woollens Special
Eco 40-60 ▲ ▲ ▲ -- --
Cottons ▲ ▲ ▲ -- --
Synthetics ▲ ▲ ▲ -- --
Delicates -- -- -- ▲ ▲
Wool/Silk -- -- -- ▲ ▲
CleanBoost ▲ ▲ ▲ -- --
Outdoor -- -- -- ▲ ▲
Duvet -- -- -- ▲ ▲
Sport -- ▲ ▲ -- ▲
Denim -- -- ▲ ▲ ▲
Rapid 20min
60min EasyWash ▲ ▲ ▲ -- --
1) At temperature higher than 60 °C the use of powder detergent is recommended.
▲ = Recommended -- = Not recommended
ENGLISH 19

10. SETTINGS
10.1 Acoustic signals
This appliance has different acoustic
signals, that operate when:
• You activate the appliance (special
short tune).
• You deactivate the appliance (special
short tune).
• You touch the buttons (click sound).
• You make an invalid selection (3 short
sounds).
• The programme is completed
(sequence of sounds for about 2
minutes).
• The appliance has a malfunction
(sequence of short sounds for about 5
minutes).
To deactivate/activate the acoustic
signals set a one of the programme,
touch the and the buttons
simultaneously for about 2 seconds. The
display shows On/Off
If you deactivate the
acoustic signals, they
continue to operate when
the appliance has a
malfunction.
10.2 Child Lock
With this option you can prevent children
from playing with the control panel.
• To activate/deactivate this option,
hold down the button until
comes on/goes off on the display.
The appliance will default to this option
after you switch it off.
The Child Lock function may not be
available for a few seconds after
switching the appliance on.
11. BEFORE FIRST USE
1. Make sure that the electrical power is
available and the water tap is open.
2. Pour a small quantity of detergent
into the compartment marked by .
3. Set and start a programme for cotton
at the highest temperature without
any laundry in the drum.
This removes all possible dirt from the
drum and the tub.
12. DAILY USE
WARNING!
Refer to Safety chapters.
12.1 Activating the appliance
1. Connect the mains plug to the mains
socket.
2. Open the water tap.
3. Press the On/Off button for a few
seconds to activate the appliance.
A short tune sounds.
12.2 Loading the laundry
1. Open the appliance door.
2. Empty the pockets and unfold the
items before you put them in the
appliance.
3. Put the laundry in the drum, one item
at a time.
Do not put too much laundry in the drum.
4. Close the door firmly.
www.husqvarna-electrolux.se20
