Hussmann CHINO TY3 Original operating instructions
/CHINO
TY3, TY4 (ENTYCE)
ISLAND CASE
SELF-CONTAINED
REV. 0917
Installation
& Operation
Manual
TY3, TY4
(ENTYCE)
ISLAND CASE
SELF-CONTAINED
INSTALLATION & OPERATION GUIDE
2
Table of Contents
General Informa•on 5
Cut and Plan Views 6
Spec Sheet 8
Installa•on 13
Close-o• Removal 15
Li•ing Instruc•ons 16
Electrical 19
Electrical Wiring Diagram Index 19
Wiring Daigrams 20
Parameter Programmed Report 40
Controller Informa•on and Manual 42
Maintenance 66
Service Tips 67
User Informa•on 68
3
1. Do Not Push, Pull, Adjust, or Manipulate the Entyce case by any glass component.
• Doing so will result in severe damage to such components
• Glass or Acrylic Breakage may result in serious injury
• See lifting and transport instructions for proper moving technique ref. pg 7.
2. Never stand on the Entyce Top, Deck, or any Shelves for any reason.
These surfaces are not steps and are not designed to support such loads.
• Misusing these surfaces as steps will result in damage to the case
• Misusing these surfaces as steps may result in serious injury to the user
• These surfaces are intended for the storage and merchandising of food products
• Use a ladder or designed structure to work above the case (Do not lean on case)
Maintenace
Case cleaning
• WARNING! DO NOT USE WATER HOSES! A self contained case emp•es
into an evaporator pan that WILL OVERFLOW IF TOO MUCH WATER IS
INTRODUCED during cleaning.
• To insure long life, proper sanita•on and minimum maintenace costs, the
case should be thoroughly cleaned frequently. SHUT OFF FAN BEFORE
CLEANING: turn controller dial to full counter-clockwise, or shut o• case
power at the source.
• USE WATER AND MILD DETERGENT FOR EXTERIOR USE ONLY
• Wipe interior with damp non abrasive cloth. Soap and hot water are not
enough to kill bacteria; a sani•zing solu•on must be included with each
cleaning process to eliminate bacteria.
• Clean any visible debris on-or near the case drain (drain is located under
the deck pans).
• DO NOT USE A CHLORINATED CLEANER ON ANY SURFACE.
• DO NOT USE ABRAISIVES OR STEEL WOOL SCOURING PADS (these will
mar the •nish)
• DO NOT USE A CLEANING OR SANITIZING SOLUTION THAT HAS AN OIL
BASE (these will dissolve the butyl sealants) or an AMMONIA BASE (this
will corrode the copper components of the case)
Filter Replacements
• REPLACE FILTER EVERY 6 MONTHS, or as needed. A dirty/clogged air
•lter restricts the air"ow. this will result in warmer temperatures in the
case, and premature compressor failure.
Service
• SCHEDULE SERVICE EVERY 6 MONTHS. To maintain good refrigerator
performance, a refrigera•on service technician should regularly clean
the discharge Honeycomb and remove any accumilated dirt from the
condenser coil and condensate evaporator pan.
• POOR AIR CIRCULATION THROUGH THE CONDENSER WILL RESULT IN
POOR REFRIGERATION PERFORMANCE, IN INCREASED PRODUCT TEM-
PERATURES, AND PERMANENT COMPRESSOR FAILURE
• Dirt accumila•on inside the condensate evaporator pan will reduce the
pan’s capacity and reduce the e#ciency of the heater causing a burned
out heater an an over"ow of defrost water onto the store "oor.
Tips and Troubleshoo!ng
Before calling for service:
• Check power. Ensure reliable electrical power supply to the
equipment.
• Check shelf loading. Overstocking will adversely a•ect case
performance.
• If Frost is collec•ng on •xture or product, verify that store Hu-
midity Control is working properly, and that no outside doors or
windows allow moisture into store.
Installa!on
Store Condi!ons
• Case is designed to operate at temperatures 80°F at 55% rela-
•ve humidity. Case must be kept in that environment to ensure
case performance and product safety.
• DO NOT posi•on the case near HVAC vent. a minimum of 15’
clearance is required.
• DO NOT posi•on the case near an entrance door. Outside
Ambient condi•ons have adverse a•ect on refrigera•on per-
formance.
• DO NOT posi•on case against ceiling or so#t. a minimum
clearnace of 8” above the unit is required for proper compres-
sor discharge air"ow.
• DO NOT block case front panel vent (supplies cri•cal intake
air"ow to the compressor). INTAKE AIR temperature should
not exceed 80°F.
For prompt service when contac•ng the factory regarding
problems, be sure to have the Case Model and Serial Number
handy. This imforma•on is on a platelocated on itself.
www.hussmann.com (909) 590-4910 (800) 395-9229
1H62575650
5
Case Descrip•on:
This Booklet specifically covers the
following models:
- TY3
- TY4
Descrip•on: The ENTYCE-SC model series are mul•-deck, spot merchandisers designed for medium
temperature applica•ons such as: Deli/Dairy/Beverage. They are available as either remote type models,
which require separate condensing unit connec•ons, or self-contained models. Each self-contained model will
have it’s own condensing unit, factory installed beneath the display area of the case ready for opera•on when
electrical service is connnected.
Shipping Damage: All equipment should be thoroughly examined for shipping damage before and during
unloading. This equipment has been carefully inspected at our factory and the carrier has assumed
responsibility for safe arrival. If damaged, either apparent or concealed, claim must be made to the carrier.
Apparent Loss or Damage: If there is an obvious loss or damage, it must be noted on the freight bill or express
receipt and signed by the carrier’s agent; otherwise, carrier may refuse claim. The carrier will supply necessary
claim forms.
Concealed Loss or Damage: When loss or damage is not apparent un•l a!er all equipment is uncrated, a claim
for concealed damage is made. Make request in wri•ng to carrier for inspec•on within 15 days, and retain all
packaging. The carrier will supply inspec•on report and required claim forms.
Loca•on/Store Condi•ons: The refrigerated merchandisers have been designed for use only in air condi•oned
stores where temperature and humidity are maintained either 75°F ambient and 55% RH or 80°F aND 55% RH . DO
NOT allow air condi•oning, electric fans, ovens, open doors or windows (etc.) to create air currents around the
merchandiser, as this will impair its correct opera•on.
Shortages: Check your shipment for any possible shortages of material. If a shortage should exist and is found
to be the responsibility of Hussmann Chino, no•fy Hussmann Chino. If such a shortage involves the carrier,
no•fy the carrier immediately, and request an inspec•on. Hussmann Chino will acknowledge shortages within
ten days from receipt of equipment.
Hussmann Chino Product Control: The serial number and shipping date of all equipment has been recorded
in Hussmann’s files for warranty and replacement part purposes. All correspondence pertaining to warranty
or parts ordering must include the serial number of each piece of equipment involved, in order to provide the
customer with the correct parts.
This equipment is to be installed
to comply with the applicable
NEC, Federal, State , and Local
Plumbing and Construction
Code ha ving jurisdiction.
ATTENTION
INSTALLER
/CHINO
A publication of HUSSMANN®Chino
13770 Ramona Avenue • Chino, California 91710
(909) 628-8942 FAX
(909) 590-4910
(800) 395-9229
Keep this booklet with the case at all times for future reference.
General Informa•on
6
Cut and Plan Views
7
221/2
(572)
471/2
(1206)
715/8
(1819)
121/8
(308)
243/8
(619)
12(305)
8(203)
571/2
(1461)
27(686)
TY3-6 25
(635)
267/8
(683)
35
(889)
30
(762)
Elec
Drain
Drain
Refrig
C
L
C
L
155/8
(397)
715/8
(1819)
73
(1854)
361/4
(921)
217/8
(556)
41/2 (114)
41/2 (114)
91/8
(234)
155/8
(397)
205/8
(524)
205/8
(524)
41/2
(114)
91/8
(234)
41/2
(114)
3
(76)
drains centered
to straight side
TY3-6X(case length) E - Flat End Merchandiser
Optional
End
Panel
1
1/8
(29)
84
(2164)
108
(2743)
60
(1524)
961/4 (2445) 1201/4 (3054) 1441/4 (3664)
Elec
Elec
Drain
Drain
Refrig
Refrig
C
L
C
L
155/8
(397)
715/8
(1819)
217/8
(556)
361/4
(921)
Drains centered
to straight side
361/4
(921)
217/8
(556)
41/2
(114) 91/8
(234)
41/2
(114)
155/8
(397)
205/8
(524)
205/8
(524)
41/2
(114)
91/8
(234)
41/2
(114)
24(610) 48(1219) 72(1829)
96(2438) 120(3048) 144(3658)
961/2(2452) 1201/2(3061) 1441/2(3670) 1681/2(4280) 1921/2(4890) 2161/2(5499)
Junction
Compartment
TY3-6X(case length) I - Island Merchandiser
TY3-6 6' wide Merchandiser
8
! "##""$%&'&&(
&&&
""%""%"
&&$$&&
&&&&&&&
&$$&&&&
&$$$$&&
&$&&
&$$&&&&&
!"#$%&'(
)&
)&&
)
)$&
)&&
)&
(((
*
&*
*
$*
()
*
$*
*
+(((
) ("
&
)
((
*
(,
*
(
$
$
""+(
"
$
(""
"
%%%%%
&$+$&+&
"
-*" +
++
Spec Sheet
9
!! "#$%$$&$'$'$$( # #
'$((""((("$$$
!"#$%&')(('($''' ()!*'!!**!!*'!+
)*''',)
'#"$*""$*$$$'')+'!'''!-%.!-%,'"!/01!-%+','"!01!-%+,+
10
!""!!#$%$$&$
'$
'
$
$(!!#!!#! '((($$($$$$('($$$('$$$$'$$
!"#$%&'(
)(('($$)$'($)(('('$ (((
(
)'('!!)!((
##
*&+*&,(#-./*&)!!!(
)(,(#./*&0!!1(((!$$(,(00
(!!!!**$
(
(
111
(
20
!
!1
(
!
11
! "##""$%&%%'%%% """""
%%%$%%%
%$(%(%%
%$$%(($((%%
$$%%$$%%
%$$$$(%%
!"#$%&')%$%)%)$%)%)$%
'''
(
'!!
')
*
'
%
+*!
,!!!
--
-'
!''-'$
*%
$
(%
)'"!./0!1%
)'"!./023.43&
5'
)'"!/0!1%
)'"!./023.43&
$
5
%
$
*
!-
*$
*%
"
5
!'
5'!
'
*
!1%
6
!1%1%
7
23.43&
''
12
!
"#
$%&&'$"&&& """""
&&&$&&&
&$(&(&&
&$$&(($((&&
$$&&$$&&
&$$$$(&&
!"#$%&'
)&$&
)&
)$&
)&
)$&
'''
$
$
$
(&
!'!(%
)
!(%(%
*
+,-.,&
'/
0
'
&
1'
/'"!23!(%
/'"!-23+,-.,&
1'!
'''
/'"!-23!(%/'"!-23+,-.,&
1'
$
0
1
&
!!4'!*$*&
5
!
0
4''60!4'!!44
13
Do Not Install the Vented Panels of the
self-contained model against a wall or
other storage fixture.
Located in the lower front and rear of the self-contained
models are vented panels. These panels allow air circulation
to the condensing unit. Blocking or restricting air circulation
through these panels can cause poor performance and
damage the refrigeration system.
Exterior Loading
These models have not been structurally designed to support
excessive external loading. Do not walk on their tops;
This could cause serious personal injury and damage to
the fixture.
Leveling
A LEVEL CASE IS NECESSARY TO INSURE PROPER
OPERATION AND WATER DRAINAGE.
Note: To avoid removing concrete flooring, begin
lineup leveling from the highest point of the store
floor.
Store Conditions
• Case is designed to operate at temperatures at either
75°F at at 55% relative humidity or 80°F at 55% relative
humidity. Case must be kept in that environment to
ensure case performance and product safety.
• Do not position the case near an HVAC vent.
• Do not position the case near an entrance door. Out-
side ambient conditions may have an adverse aect on
the refrigeration performance, a minimum of 15’clear-
ance is required from doors.
• Do not position the case tight against a ceiling or sot.
A minimum clearance 10”above the unit is required for
proper compressor discharge air ow.
• Do not block case front panel vent (supplies critical
intake air ow to the compressor)
BEFORE SERVICING
ALWAYS DISCONNECT ELECTRICAL
POWER AT THE MAIN DISCONNECT
WHEN SERVICING OR REPLACING ANY
ELECTRICAL COMPONENT.
This includes (but not limited to) Fans, Heater
Thermostats, and Lights.
Uncrating the Stand
Place the fixture as close to its permanent position as
possible. Remove the top of the crate. Detach the walls from
each other and remove from the skid. Unbolt the case from
the skid. The fixture can now be lifted off the crate skid. Lift
only at base of stand!
It is the contractor’s responsibility to install
case(s) according to local construction and
health codes.
ATTENTION
INSTALLER
Condensate Pan Setup and Maintaintence
Setup:
There are two condensate evaporator pans on this unit. The drain pipes from the case feed into the “Primary Condensate
Pan”. This condensate pan will turn on when the float switch level is triggered. If the volume of water is above the capac-
ity of this pan, excess water will flow into the “Secondary Condensate Pan”. Both the Primary and Secondary condensate
pans are placed into a metal receiver. The metal receiver is there to collect excess water that may overspill in case of (a)
failure of the condensate pans or (b) store conditions being above design specification causing more condensate water to
be formed than expected.
Maintaintence:
Care must be taken to ensure that the condensate pans operate properly at the store. These units are designed to oper-
ate at either 75°F ambient and 55% RH or 80°F ambient and 55% RH. If stores are operating above this condition, case
performance will be severely affected. If such a condition is noted, the metal receiver under the condensate pans must be
checked periodically to see if excess water is being collected. If water has accumulated, water must be siphoned out of
the receiver. Care must be taken while performing this step. Unit power should be shut off for electrical safety. Once water
has been removed and metal receiver is dried out, unit power can be turned back on.
See pg 7. Figure 1 / Figure 2
Installa•on
14
Clearances
Minimum Clearances for Self-Contained cases are to be followed as instructed for proper placement inside store
locations.
- Intake and exhaust clearances are to be a minimum of 8’ when placed next to a solid wall.
- Height clearance measured from floor follows as a minimum of 10’ vertically.
- Minimum of 36” clearance if near an open aisle is required for proper cycle ventilation.
(Assumed 8’ clearance from solid wall)
Figure1 Figure2
15
Step 1
Slide bottom of close-off in upward motion
to remove from tabs.
Step 2
Pull Close-off in outward then downward
motion to completely remove side panel
close-off
Step 3
Once side panel close-off has been removed
from case four screws will be visible which
fasten the round close-off to the case.
Remove the four screws 2 on each end to
remove the end close-off.
Close-off Removal
16
Entyce Lifting and Transport Instructions
72.68
34.42
Lift Zone
J-Bar Zone
Jack Points
Dollies
under each
Base Leg
1. The Entyce can be lifted by a forklift only at the specied location in the diagram
Improper placement of forks may damage
drainage piping. Use a spotter when placing forks.
Make sure that piping will not be damaged.
Use J-Bars or Jacks if Forks cannot be used safely
WARNING
2. Remove close-os and lower body panels before lifting with a fork. Serious damage will occur if the body panels are
not removed.
• Remove the end case lower and bottom panels rst
• Then remove the side case lower and bottom panels
• A Phillips head screwdriver/drill is needed for lower and bottom panel removal
3. Make sure that fork spacing and width will not damage drain, piping, or electrical lines
4. Be sure that the forks are long enough to support beyond the center of the case. Check for proper balance before
moving. A minimum fork length of 36”is recommended for 68”wide cases
5. The Entyce can be raised at one end with a forklift to allow the placement of rollers or dollies. See gure on page 13
for J-bar and jacking instructions
6. Never drag or push the Entyce by ANY COMPONENT including ANY GLASS COMPONENT. This will result in damage
to the base, and possibly damage to other components
7. Evenly support the entire base structure on rollers or dollies before attempting to move. Each Base Leg must have
its own dollie to properly support the case.
Li•ing Instruc•ons
17
8. If using J-Bars, use the specied jacking points to raise the case
• Raise one side of the case rst.
• Use as many J-Bars as possible to lift from the base channels
• A minimum of 2 J-Bars is required
• Place Dollies and chock wheels before lifting the other side. Be sure that the dollies are evenly spaced to carry to
weight of the case
9. If using Floor-jacks or Bottle-jacks, use the recommended lifting points located at the underside of the case
• These points will be visible channels
• Lift simultaneously to place dollies or rollers
18
Do not Jack or
lift at any point
J-Bar lift points
8. If using J-Bars, use the specied jacking points to raise the case
• Raise one side of the case rst.
• Use as many J-Bars as possible to lift from the base channels
• A minimum of 2 J-Bars is required
• Place Dollies and chock wheels before lifting the other side. Be sure that the dollies are evenly spaced to carry to
weight of the case
Do not Jack or
lift at any point
9. For Dollies use recommended lift points, each Base Leg will need a Dollie for proper support.
RECOMMENDED NO FORKLIFT UNDER TUB.
-Using a forklift may damage condensing unit, Refrigeration Piping , Electrical Conduit, or
Drainage Components
19
Field Wiring and Serial Plate Amperage
Field Wiring must be sized for component amperes printed
on the serial plate. Actual ampere draw may be less
than specified. Field wiring from the refrigeration control
panel to the merchandisers is required for refrigeration
thermostats. Case amperes are listed on the wiring
diagram, but always check the serial plate.
BEFORE SERVICING
ALWAYS DISCONNECT ELECTRICAL
POWER AT THE MAIN DISCONNECT
WHEN SERVICING OR REPLACING ANY
ELECTRICAL COMPONENT.
This includes (but not limited to) Fans, Heaters
Thermostats, and Lights
DANGER
.
CASE MUST BE GROUNDED
NOTE: Refer to label affixed to case to determine the actual
configuration as checked in the “TYPE INSTALLED” boxes.
Standard lighting for all refrigerated models will be full length
LED Lights located within the case at the top.
Model Tier Description Size Diagram #
Entyce TY3 TY3-3X4.5E-S 4.5’ 3043372_A
TY3-4X4E-S 4’ 3043374_A
TY3-4X6E-S 6’ 3043375_A
TY3-4X6E-S 240/50/1 6’ 3043376_A
TY3-4X6I-S 240/50/1 6’ 3043377_A
TY3-4X6I-S 6’ 3043378_A
TY3-4X8I-S 8’ 3043379_A
TY3-4X10I-S 10’ 3043380_A
TY3-5X7I-S 7’ 3043381_A
TY3-6X8I-S 8’ 3043382_A
TY3-6X10I-S 10’ 3043383_A
TY3-6X12I-S 12’ 3043384_A
TY4 TY4-4X8I-R 8’ 3041655_B
TY4-4X6E-R 6’ 3042584_A
TY4-4X4E-S 4’ 3042639_A
TY4-3X5.5-E-S 5.5’ 3042640_A
TY4-4X6I-S 6’ 3042641_A
TY4-4X6E-S 6’ 3042642_A
TY4-4X8IS 240/50/1 8’ 3042643_A
TY4-4X10I-S 10’ 3042644_A
Electrical
Electrical Wiring Diagram Index
20
HUSSMANN_GDF_1.1 SHEET SIZE D
MATERIAL - N/A
THIRD
ANGLE
PROJECTION
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES.
DRAWN BY -CRAIG BOOREY
APPROVED BY - CRAIG BOOREY
TOLERANCES ARE:
DECIMALS .XX u.03, .XXX u.010
ANGLES u2v
DATE DRAWN - 9-5-17 ECN-CAP-0008239
REVIEWED BY -CRAIG BOOREY REF -
3043372
DIAGRAM-TY3-3X4.5
E-S
REV ECN DATE REVISION DESCRIPTION REV BY CHKD BY APPR BY
A ECN-CAP-0008239 2017/09/05 RELEASED TO PRODUCTION CB CB CB
REVISION HISTORY
NOTES:
CASE MUST BE GROUNDED
WHEN PASSING WIRES THROUGH METAL HOLES A GROMMET MUST BE USED A
SHEET 1 OF 1
BUNDLE
ORANGE
EVAPORATOR FAN
12W 0.30A @ 120VAC (4)
0477655
LIGHT SWITCH
125-01-0307
CONDENSING UNIT
COPELAND®
FFPA-0172-CFV-072
R404A
1H96225500
CONDENSING UNIT
RLA= 12.6 A
LRA= 55.0A
MCC= 17.2A
SAFETY
SWITCH
FLOAT SWITCH
G
EVAPORATOR PAN
1500W 6.25A @ ~ 240 VAC
1H79831550
L1
L1 N
L1
N
L2
G
L2
Black 8G.
Red 8 G.
White 12 G.
Green 8 G.
BLK#14
WHT#14
TERMINAL BLOCK
125-01-0295
LIGHT CIRCUIT
.43A 46.6W @ 120V
MMM
BUNDLE
BROWN
M
1.5' L.E.D. LIGHT
LED-DRIVER
RED +
BLUE -
ANTI-SWEAT HEATER
50W .46A@ 120 VAC
0497590
L1 N
BUNDLE
PURPLE
G
L2
L1
N
OPTIONAL
POWER
CORD
PLUG
NEMA
L14-30P
1H82233550
15A
15 AMP FUSE
125-01-8604
FUSE HOLDER
125-01-8605
LEFT HAND
CONDENSER FAN
3' L.E.D. LIGHT
1.5' L.E.D. LIGHT
1' L.E.D. LIGHT
1' L.E.D. LIGHT
CIRCUI T#2
~120 VAC - 1Ø -60 Hz
CIRCUIT #2
NOTE: CASE MUST BE
GROUNDED
15.0L1
L2
L3
120 V
LOADING
GFCI DUPLEX
125-01-3178
W G BK
3' L.E.D. LIGHT
3' L.E.D. LIGHT
3' L.E.D. LIGHT
3' L.E.D. LIGHT
3' L.E.D. LIGHT
BUNDLE
BLUE
L1
L2
L1
SWITCH
MOTOR START
SQ "D"
125-01-0271
RELAY TYCO
T92P7A22-240
1804241
DANFOSS® CONTROLLER
AK-CC 210 115V # 084B8534
1H56892500
Danfoss®AK-CC 210
DEF.COMP.
120 VAC
NOTE: WIRES AT
CONTROL
INPUTS/OUTPUTS
14GA MAX
N
L2
BLK # 12
RED# 12
M
WHT # 12
DISCHARGE AIR
SENSOR AKS-12
COIL OUT
SENSOR AKS-11
CIRCUIT #1
L1
L2
LOADING
18.4
16.4
208V 240V
21.3
18.9
Wiring Daigrams
This manual suits for next models
1
Table of contents
Other Hussmann Monitor manuals
