Wincor Nixdorf BA71-R User manual

BA71R
10.4" TFT LCD Monitor
Operating Manual

We would like to know your opinion on this publication.
Please send us a copy of this page if you have any constructive criticism.
We would like to thank you in advance for your comments.
With kind regards,
Order No. (BA71R-3): 01750218568B
Your opinion:

BA71R
10.4” TFT LCD Monitor
Operating Manual
Edition March 2013

All brand and product names mentioned in this document are trademarks of their
respective owners.
Copyright ©Wincor Nixdorf International GmbH, 2013
The reproduction, transmission or use of this document or its contents is not
permitted without express authority.
Offenders will be liable for damages. All rights, including rights are created by
patent grant or egistration of a utility model or design, are reserved.
Delivery subject to availability; technical modifications possible.

Contents
Manufacturer’s Declaration and Approval........................... 1
FCC-Class A Declaration............................................................ 1
Warning.................................................................................... 1
Caution ..................................................................................... 1
Safety Instructions.................................................................... 2
Disclaimer................................................................................. 2
Introduction....................................................................... 3
Before Installing Your Monitor................................................. 3
Unpacking................................................................................. 3
About Your Monitor ................................................................. 4
Precautions............................................................................... 4
Handling ............................................................................... 4
Cleaning................................................................................ 4
Storage ................................................................................. 4
Technical Specification .......................................................5
Specification ............................................................................. 5
Factory-Preset Modes .............................................................. 8
Signal Connector Pin Assignments ........................................... 9
Installation....................................................................... 11
Installing the Monitor............................................................. 11
Control Functions ...................................................................14
Adjustment ...................................................................... 16
Adjusting The Monitor ........................................................... 16
Adjustment procedure ........................................................... 16
Auto-Adjustment....................................................................17
On-Screen-Display Mode .......................................................17
Description ......................................................................... 18

BA71R-3 Operating Manual
1
Manufacturer’s Declaration and Approval
FCC-Class A Declaration
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy.
If not installed in accordance with the instructions in this manual,
harmful interference to radio communication may occur. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment dose cause interference to radio and
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Re-orient or relocate the receiving antenna.
Increase the space between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
the one which the receiver is connected.
Consult the dealer or an experienced radio / TV technician for
help.
Warning
Use only shielded cables to connect I/O devices to this equipment.
Caution
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
Use only RF shielded cable to connect this monitor to a
computer device.

2
BA71R-3 Operating Manual
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
This device may not cause harmful interference, and
this device must accept any interference received, including
interference that may cause undesired operation.
Safety Instructions
The main plug isolates this equipment from the main supply.
Unplug this product from the wall outlet before cleaning.
Never push objects of any kind, or spill liquid of any kind into
this product.
Do not attempt to service this product yourself. As opening or
removing covers may expose you to dangerous voltage points
or other risks. Refer all servicing to qualified service personnel.
The power supply cord serves as a power disconnect device for
pluggable equipment, the socket outlet should be installed near
the equipment and should be easily accessible.
Disclaimer
This company makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and
specifically disclaims any warranties, merchantability or fitness
for any particular purpose. Further, this company reserves the
right to revise this publication and to make changes from time
to time in the contents hereof without obligation of this company
to notify an person of such revision or changes.
All brand or product names are trademarks or registered
trademarks of their respective companies.

BA71R-3 Operating Manual
3
Introduction
Before Installing Your Monitor
Read this manual cover to cover.
Pay attention to all warnings and cautions.
Do not use computer components not recommend by the
manufacturer.
Do not attempt to service the monitor yourself. If a problem
occurs, contact the manufacturer’s authorized service center.
Unpacking
Open the shipping carton and check the contents. If any items are
missing or damaged, contact your dealer immediately.
The package should include the following items:
10.4" TFT LCD Monitor.
Power cord. (option)
Signal cable (option)
Adapter (option)
User manual
Parts parcel
DVI cable (for DVI mode). (option)
Touch screen driver CD (option, for touch screen monitor)
Touch screen driving module (for touch screen monitor)

4
BA71R-3 Operating Manual
About Your Monitor
This monitor is a microprocessor-controlled, color monitor which
uses a 10.4" TFT LCD panel.
Precautions
Handling
The monitor must be treated with caution and not be exposed
to impact and shock.
If the monitor has a strength glass on screen. Never rub it with
a hard, stiff object or tool for the panel is easily scratched. Your
monitor is protected by one glass filter.
Every effort has been made to protect the screen, however the
monitor is an extremely fragile product.
Cleaning
The display area is highly prone to scratching. Do not use ketone
type material (ex. Acetone), ethyl alcohol, toluene, ethyl acid or
methyl chloride to clean the screen. It might permanently
damage the screen. Desirable cleaners are water, IPA (IsoPropyl
Alcohol) or Hexane.
Do not let water or oil penetrate the monitor. Even if drops are
spilled and left for a long time, staining and discoloration may
occur.
Keep food particles and fingerprints away from the display area.
Storage
Do not store the monitor in temperatures higher than 60 °C
(140 °F) or humidity higher than 85%.
Store in a dark place, keep away from sunlight and ultra violet
(UV) radiation.

BA71R-3 Operating Manual
5
Technical Specification
Specification
Overall Dimension (H x W x D)
With T-Joint
234.9 x 251.2 x 69 mm
(Shipping weight 2.2 kgs)
Monitor Only
192 x 251.2 x 37 mm
(Shipping weight 1.7 kgs)

6
BA71R-3 Operating Manual
With Standard Base +
Add-On Base
239 x 251.2 x 170 mm
(Shipping weight 3.1 kgs)
With Standard Base
229 x 251.2 x 98.5 mm
(Shipping weight 2.0 kgs)

BA71R-3 Operating Manual
7
Scan Frequencies
Horizontal 31 KHz to 60 KHz.
Vertical 56 Hz to 75 Hz.
Panel Specification Please refer to attached
specification sheet.
Power
Input 100 ~ 240VAC. (Auto-Sensing)
Frequency: 50 Hz / 60 Hz.
Consumption 7.5 Watts Maximum. (On)
0.5 Watts Maximum (with adapter)
(Power Saving and Power Off)
Video connector 15-Pin Mini D-Sub.
Video Signals
Video Analogue R.G.B 0.7Vp-p / 75 .
Sync Separate, Positive or Negative TTL.
Display Data Channel
Compatibility VESA DDC 1/2B. (Option)
Operations
User Controls On / Off Power Button, Menu, Up,
Down, Enter /Mode.
On Screen Display Brightness, Contrast, Auto Adjust,
Phase, Clock, H-position, V-position,
Sharpness, Color Temperature, Lan-
guage, OSD Adjust, Input Select,
Recall.
Control Type Digital.
Environmental Limits
Operating Temp. 0 °C to 40 °C. (32 °F to 104 °F)
Storage Temp. -20 °C to 60 °C. (-4 °F to 140 °F)
Transport Temp. -20 °C to 60 °C. (-4 °F to 140 °F)
Operating Humidity 10% to 85% without condensation.
Storage Humidity 10% to 85% without condensation.

8
BA71R-3 Operating Manual
Transport Humidity 10% to 85% without condensation.
Agency Approval
EMI FCC and CE.
Safety CCC, BSMI.
Design and specifications are subject to change without notice.
Factory-Preset Modes
The table shows standard settings that have been pre-adjusted at
the factory for accurate display. These setting are stored in the
monitor’s memory.
Mode Resolution FH KHz FV Hz
Mode 1 640*350 31.469 70.087
Mode 2 720*400 31.469 70.087
Mode 3 640*480 31.469 59.940
Mode 4 640*480 37.861 72.809
Mode 5 640*480 37.500 75.000
Mode 6 800*600 35.156 56.250
Mode 7 800*600 37.879 60.317
Mode 8 800*600 48.077 72.188
Mode 9 800*600 46.875 75.000
Mode 10 1024*768 48.363 60.004
Mode 11 1024*768 56.467 70.069
Mode 12 1024*768 60.023 75.029
*** Mode 10~ Mode 12：Non Panel standard timing
The product has been tested and deemed compliant
to U.S. and Canadian product safety standards.

BA71R-3 Operating Manual
9
Signal Connector Pin Assignments
Power Connector
Input DC 12V
Note:
The power connector has straight and right angle type for option.
R.G.B Signal Connector
Pin 1
Analog Red Input
Pin 2 Analog Green Input
Pin 3 Analog Blue Input
Pin 4
Ground
Pin 5 Digital Ground
Pin 6 Analog Red Ground
Pin 7
Analog Green Ground
Pin 8 Analog Blue Ground
Pin 9 NC
Pin 10 Sync Ground
Pin 11 Ground
Pin 12
SDA (DDC Data)
Pin 13
H. Sync
Pin 14 V. Sync
Pin 15
SCL (DDC CLK)

10
BA71R-3 Operating Manual
Digital Signal Connector
Pin 1 T.M.D.S Data2-
Pin 2
T.M.D.S Data2+
Pin 3
T.M.D.S Data2 Shield
Pin 4
NA
Pin 5
NA
Pin 6
DDC Clock
Pin 7
DDC Data
Pin 8
NA
Pin 9 T.M.D.S Data1-
Pin 10
T.M.D.S Data1+
Pin 11 T.M.D.S Data1 Shield
Pin 12 NA
Pin 13 NA
Pin 14 +5V Power
Pin 15
Ground
（
return for +5V, Hsync, and Vsync
）
Pin 16
Hot Plug Detect
Pin 17
T.M.D.S Data0-
Pin 18
T.M.D.S Data0+
Pin 19
T.M.D.S Data0 Shield
Pin 20
NA
Pin 21
NA
Pin 22
T.M.D.S. Clock Shield
Pin 23 T.M.D.S. Clock+
Pin 24 T.M.D.S. Clock-

BA71R-3 Operating Manual
11
Installation
Installing the Monitor
The monitor is equipped with an auto-sensing power supply for
voltage ranges from 100 ~ 240 VAC, 50 / 60 Hz. Confirm the line
voltage designation on the rear panel of the monitor.
Follow these steps to install the monitor:
Before you connect the cables, make sure that the monitor and
the systems power switches are OFF.
Plug one end of the 15-pin/24-pin signal cable to the monitor
and the other end to the video signal connector in the back of
the system. Tighten the two screws of the cable connector on
both ends.
Connect the power to the monitor through the AC / DC adapter.
Connect the power cord on the AC outlet.

12
BA71R-3 Operating Manual
Install the VESA stand:
The rear cover is suitable for other stand or arm if they meet
VESA standard of 75 x 75 mm VESA holes.
The max. screw length is 8 mm.
The min. screw length is 6 mm.
Install the T-Joint to platforms:
Insert the T-joint into the footed stand or the tubular stand of
the POS system (1).
Fasten the screw into place (2).
Use hands to loosen the adjusting nut and adjust the display to
a suitable view angle. Then fasten the adjusting nut (3).
The angle of the screen can be adjusted from a horizontal
position to a vertical position without any tools.

BA71R-3 Operating Manual
13
Install the base to platforms:
There are two holes on the base for fixing the base on the
platform, such as desktop, shall of POS system, wall etc..
Users should not apply unspecified screw into this hole for fixing
the monitor.
The elevation angle is up to 90° for wall mount. For stand-up
using, the elevation angle is limited to 30° to avoid toppling
down from missing center-of-gravity position.
The angle can be up to 90° when the monitor includes Add-On-
Base.

14
BA71R-3 Operating Manual
Control Functions
The monitor control functions are located on the right side of the
screen. They are shown in the figure below and described in the
following paragraphs.
The Control Key Description :
Power Switch
Activate the On-Screen-Display function / Return
menu / Exit./Key Lock Key Lock: Press the Menu
button more than 15 sec, Menu, UP and Down
buttons will be locked; then press Menu button
again for more than 15 sec for unlock.
Move / Adjustment up – Select Key
Move / Adjustment down- Select key
Enter / Auto Adjustment
POWER
MENU
UP
DOWN
ENTER/MODE

BA71R-3 Operating Manual
15
Description:
Power Switch.
Use the power switch to turn the power ON or OFF. We
recommend turning your system power on first, then the
LCD monitor.
Menu
Press the Menu key to activate the On Screen Display mode. (It
is a toggle key) Press twice to turn off the OSD. After 20 sec idle
time, the OSD screen will automatically turn off.
Select Key
The two keys have two sets of functions:
When OSD mode is activated (when “MENU” key is pressed),
the two keys are used to select the adjustment items.
When adjustment item is selected, the two keys are defined
to decrease or increase the values of each selected item.
Enter/ Auto Adjustment.
VGA and DVI mode
When the light-bars moves to the item, the key can be used
to select it, and ready to adjust.
VGA mode
Press this key can do the auto adjustment function.
