Eizo FlexScan L760T-C User manual

For U.S.A, Canada, etc. (rated 100-120 Vac) Only
FCC Declaration of Conformity
We, the Responsible Party EIZO NANAO TECHNOLOGIES INC.
5710 Warland Drive, Cypress, CA 90630
Phone: [phone]
declare that the product Trade name: EIZO
Model: FlexScan L760T-C
is in conformity with Part 15 of the FCC Rules. Operation of this product is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures.
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
* Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note
Use the attached specified cable below or EIZO signal cable with this monitor so as to keep
interference within the limits of a Class B digital device.
- AC Cord
- Shielded Signal Cable
- Stereo mini-jack cable
Canadian Notice
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de le classe B est comforme à la norme NMB-003 du Canada.

User’s Manual
Touch Panel Color LCD Monitor
It shall be assured that the final system is in compliance
to IEC60601-1-1 requirements.

English
SAFETY SYMBOLS
This manual uses the safety symbols below. They denote critical information. Please read them
carefully.
WARNING
Failure to abide b
y
the information in a WARNING ma
y
result in serious in
j
ur
y
and
can be life threatening.
CAUTION
Failure to abide by the information in a CAUTION may result in moderate injury
and/or property or product damage.
Indicates a prohibited action.
Indicates to ground for safety.
• Product specifications may vary depending on the region. Confirm the specifications in the
manual written in the language of the region of purchase.
• Power supplied equipment can emit electromagnetic waves, that could influence, limit or
result in malfunction of the monitor. Install the equipment in a controlled environment, where
such effects are avoided.
• This is a monitor intended for use in a medical setting.
Copyright© 2005-2008 EIZO NANAO CORPORATION All rights reserved. No part of this
manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any
means, electronic, mechanical, or otherwise, without the prior written permission of EIZO
NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or
information confidential unless prior arrangements are made pursuant to EIZO NANAO
CORPORATION's receipt of said information. Although every effort has been made to ensure
that this manual provides up-to-date information, please note that EIZO monitor specifications
are subject to change without notice.
VGA is a registered trademark of International Business Machines Corporation.
VESA is a registered trademark or a trademark of Video Electronics Standards Association in
the United States and other countries.
Mac is a registered trademark of Apple Inc.
TouchWare is a trademark of 3M in the United States and other countries.
Windows and Windows Vista are registered trademarks of Microsoft Corporation in the United
States and other countries.
ScreenManager, FlexScan and EIZO are registered trademarks of EIZO NANAO
CORPORATION in Japan and other countries.
2

English
TABLE OF CONTENTS
PRECAUTIONS ...................................................................................4
1. INTRODUCTION .....................................................................................9
1-1. Features ........................................................................................................9
1-2. Package Contents..........................................................................................9
1-3. Controls & Connectors ..............................................................................10
2. CABLE CONNECTION ......................................................................... 12
2-1. Before connecting .......................................................................................12
2-2. Connecting the signal cable ........................................................................13
2-3. Touch Operation.........................................................................................15
2-4. Connecting two PCs to the monitor............................................................15
3. ScreenManager....................................................................................16
3-1. How to use the ScreenManager ..................................................................16
3-2. Adjustments and Settings............................................................................17
3-3. Useful Functions .........................................................................................18
4. ADJUSTMENT ...................................................................................... 20
4-1. Screen Adjustment ......................................................................................20
4-2. Color Adjustment .......................................................................................23
5. ATTACHING A STAND .......................................................................... 25
6.TROUBLESHOOTING........................................................................... 26
7. CLEANING............................................................................................30
8. SPECIFICATIONS.................................................................................31
9. GLOSSARY...........................................................................................34
APPENDIX/ANHANG/ANNEXE ..................................................................i
TABLE OF CONTENTS
3

English
PRECAUTIONS
IMPORTANT!
• This product has been adjusted specifically for use in the region to which it was
originally shipped. If operated outside the region to which it was originally shipped,
the product may not perform as stated in the specifications.
• To ensure personal safety and proper maintenance, please read this section and the
caution statements on the unit (refer to the figure below).
[Location of the Caution Statements]
[Symbols on the unit]
Symbol Location This symbol indicates
Front
Control panel
Power button
Press to turn the monitor’s power on or off.
Rear
Name Plate
Alternating current
Rear Alerting electrical hazard
Rear Caution
Refer to SAFETY SYMBOLS section in this
manual.
4PRECAUTIONS

English
WARNING
If the unit begins to emit smoke, smells like something is burning, or
makes strange noises, disconnect all power connections immediately
and contact your dealer for advice.
Attempting to use a malfunctioning unit may result in fire, electric shock, or
equipment damage.
Do not open the cabinet or modify the unit.
O
p
enin
g
the cabinet or modif
y
in
g
the unit ma
y
result in fire, electric shock, or
burn.
Refer all servicing to qualified service personnel.
Do not attempt to service this product yourself as opening or removing covers
may result in fire, electric shock, or equipment damage.
Keep small objects or liquids away from the unit.
Small objects accidentally falling through the ventilation slots into the cabinet
or spillage into the cabinet may result in fire, electric shock, or equipment
damage.
If an object or liquid falls/spills into the cabinet, unplug the unit immediately.
Have the unit checked by a qualified service engineer before using it again.
Place the unit at the strong and stable place.
A unit placed on an inadequate surface may fall and result in injury or
equipment damage.
If the unit falls, disconnect the power immediately and ask your dealer for
advice. Do not continue using a damaged unit. Using a damaged unit may
result in fire or electric shock.
OK
Use the unit in an appropriate location.
Not doing so may result in fire, electric shock, or equipment damage.
* Do not place outdoors.
* Do not place in the transportation system (ship, aircraft, trains, automobiles,
etc.)
* Do not place in a dusty or humid environment.
* Do not place in a location where water is splashed on the screen (bathroom,
kitchen, etc.).
* Do not place in a location where the steam comes directly on the screen.
* Do not place near heat generating devices or a humidifier.
* Do not place in an inflammable gas environment.
PRECAUTIONS
5

English
WARNING
To avoid danger of suffocation, keep the plastic packing bags away
from babies and children.
Use the enclosed power cord and connect to the standard power outlet
of your country.
Be sure to remain within the rated voltage of the power cord.
Not doing so may result in fire or electric shock.
Power Supply: 100-120/200-240 Vac 50/60Hz
To disconnect the power cord, grasp the plug firmly and pull.
Tugging on the cord may damage and result in fire or electric shock.
OK
The equipment must be connected to a grounded main outlet.
Failure to do so may result in fire or electric shock.
Use the correct voltage.
* The unit is designed for use with a specific voltage only. Connection to
another voltage than specified in this User’s Manual may cause fire, electric
shock, or equipment damage.
Power Supply: 100-120/200-240 Vac 50/60Hz
* Do not overload your power circuit, as this may result in fire or electric
shock.
Handle the power cord with care.
* Do not place the cord underneath the unit or other heavy objects.
* Do not pull on or tie the cord.
If the power cord becomes damaged, stop using it. Use of a damaged cord
may result in fire or electric shock.
Never touch the plug and power cord if it begins to thunder.
Touching them may result in electric shock.
When attaching an arm stand, please refer to the user’s manual of the
arm stand and install the unit securely.
Not doing so may cause the unit to become unattached, which may result in
in
j
ur
y
or e
q
ui
p
ment dama
g
e. When the unit is dro
pp
ed,
p
lease ask
y
our dealer
for advice. Do not continue using a damaged unit. Using a damaged unit may
result in fire or electric shock. When reattaching the tilt stand, please use the
same screws and tighten them securely.
6PRECAUTIONS

English
WARNING
Do not touch a damaged LCD panel directly with bare hands.
The liquid crystal that may leak from the panel is poisonous if it enters the
eyes or mouth.
If any part of the skin or body comes in direct contact with the panel, please
wash thoroughly.
If some physical symptoms result, please consult your doctor.
Lamps contain mercury, dispose according to local, state or federal
laws.
CAUTION
Handle with care when carrying the unit.
Disconnect the power cord and cables when moving the unit. Moving the unit
with the cord attached is dangerous. It may result in injury.
When handling the unit, grip the bottom of the unit firmly with both
hands ensuring the panel faces outward before lifting.
Dropping the unit may result in injury or equipment damage.
OK
Do not block the ventilation slots on the cabinet.
* Do not place any objects on the ventilation slots.
* Do not install the unit in a closed space.
* Do not use the unit laid down or upside down.
Blocking the ventilation slots prevents proper airflow and may result in fire,
electric shock, or equipment damage.
Do not touch the plug with wet hands.
Doing so may result in electrical shock.
Use an easily accessible power outlet.
This will ensure that you can disconnect the power quickly in case of a
problem.
Periodically clean the area around the plug.
Dust, water, or oil on the plug may result in fire.
Unplug the unit before cleaning it.
Cleaning the unit while it is plugged into a power outlet may result in electric
shock.
If you plan to leave the unit unused for an extended period, disconnect
the power cord from the wall socket after turning off the power switch
for the safety and the power conservation.
PRECAUTIONS
7

English
Notice for this monitor
This product is suited to creating documents, viewing multimedia content, and other general
purposes.
In order to suppress the luminosity change by long-term use and to maintain the stable
luminosity, use of a monitor in lower brightness is recommended.
The LCD panel is manufactured using high-precision technology. However, missing pixels or lit
pixels may appear on the LCD panel, this is not malfunction.
Percentage of effective pixels: 99.9994% or higher.
The backlight of the LCD panel has a fixed life span. When the screen becomes dark or begins to
flicker, please contact your dealer.
Do not scratch or press on the panel with any sharp objects, such as a pencil or pen as this may
result in damage to the panel. Do not attempt to brush with tissues as this may scratch the panel.
When the screen image is changed after displaying the same image for extended periods of time,
an afterimage may appear. Use the screen saver or timer to avoid displaying the same image for
extended periods of time.
When the monitor is cold and brou
g
ht into a room or the room tem
p
erature
g
oes u
p
q
uickl
y
, dew
condensation may occur inside and outside the monitor. In that case, do not turn the monitor on
and wait until dew condensation disappears, otherwise it may cause damage to the monitor.
To use the monitor comfortably
An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor
according to the environmental conditions.
Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.
8PRECAUTIONS

English
1. INTRODUCTION
Thank you very much for choosing an EIZO Color Monitor.
1-1. Features
• Dual inputs compliant
• DVI (p.34) Digital input (TMDS (p.35)) compliant.
• Horizontal scanning frequency: Analog input 30 - 81 kHz
Digital input 30 - 65 kHz
Vertical scanning frequency: Analog input 49.5 - 75.5 Hz
Digital input 59 - 61 Hz (VGA text: 70 Hz)
Resolution: 1 M pixels (1280 dots x 1024 lines)
• Auto Adjustment compliant
• Support to sRGB (p.35) standard
• The height adjustable stand incorporated
• Touch Panel provided
• Touch Panel Pointer “TP1” is available (optional, p.15)
1-2. Package Contents
Please contact your local dealer for assistance if any of the listed items are missing or
damaged.
•LCD Monitor
•Power Cord
•Signal Cable (MD-C87)
•Touch Panel Cable (FD-C38)
•User’s Manual
•ScreenManager Quick Reference
•LIMITED WARRANTY
•EIZO Touch Panel Disk (CD-ROM)
(Contents: touch panel drivers TouchWare (for Windows 2000/XP) and MT 7 (for
Windows Vista), and Installation Guides)
NOTE
• Please retain the packing materials for future transference.
• Regarding installing touch panel drivers and cautions, please refer to the Installation
Guides in the CD-ROM.
1. INTRODUCTION
9

English
1-3. Controls & Connectors
Front
ENTERAUTO
SIGNAL
1 - 2
(3) (4) (5)
(2) (6) (7)
(1)
(8)
MODE
(1)ScreenManager®Monitor Adjustment menu (p.16)
(2)SIGNAL1-2
Input Signal
Selection Button
Switch the input signals when connecting 2
PCs. (p.15)
(3)MODE Mode Button Show or switch the color mode. (p.23)
(4)AUTO Auto Adjustment
Button
Adjust the screen to appropriate condition
automatically. (analog input only)
(5)ENTER Enter Button Show the ScreenManager on the screen.
Confirm the setting / adjustment function.
Save the adjustment values.
(6)
Control Buttons
(Left, Down, Up,
Right)
Select the desired function.
Increase and decrease the adjustment value.
(7) Power Switch ON or OFF the monitor’s power.
(8)
Power Indicator Indicate monitor’s operation status.
Blue: Operation
Flashing blue: Last 15 min. of operation
time before entering the power off state.
(p.18)
Flashing yellow slowly: Power off
Control Panel
10 1. INTRODUCTION

English
Rear
(9) (10) (11) (12)
(14) (15)
(13)
(9) Power Connector Connect the power cord.
(10) DVI-D Connector
(SIGNAL1)
Connect the optional digital cable.
(11)
D-Sub mini 15 pin
Connector
(SIGNAL2)
Connect the enclosed analog cable (MD-
C87)
(12)
RS-232C port Connect the enclosed touch panel cable
(FD-C38).
(13) Hole for TP1 Hole for installing the lead of the TP1
(Optional Touch Panel Pointer).
(14)
Security Lock Slot Allows for connection of a security cable.
This lock supports Kensington’s MicroSaver
security system.
(15) Stand (Detachable) The LCD monitor can be used with an other
stand by removing the stand (see page 25).
Bottom
1. INTRODUCTION
11

English
2. CABLE CONNECTION
2-1. Before connecting
Before connecting your monitor to the PC, change the display screen settings (resolution
(p.35) and frequency) in accordance with the charts below.
NOTE
• The lower display modes like 640x 480, automatically enlarge to the maximum
display mode (1280 x 1024), and some lines of the characters may become fuzzy. In
this case, use <Smoothing> function (p.22) to make the lines clear.
• When your computer and display support VESA DDC, the suitable resolution and
the refresh rate are set by just plugging your display into the computer without any
manual settings.
Analog Input
Resolution Frequency Dot Clock Remarks
320 ×200 70 Hz VGA Mode13
640 ×480 ～75 Hz VGA, VESA
720 ×400 70 Hz VGA TEXT
800 ×600 ～75 Hz VESA
1024 ×768 ～75 Hz VESA
1152 ×864 75 Hz VESA
1280 ×960 60 Hz VESA
1280 ×1024 ～75 Hz
135 MHz(Max)
VESA
Digital Input
Resolution Frequency Dot Clock Remarks
640 ×480 60 Hz VGA
720 ×400 70 Hz VGA TEXT
800 ×600 60 Hz VESA
1024 ×768 60 Hz VESA
1280 ×1024 60 Hz
109 MHz
(Max)
VESA
12 2. CABLE CONNECTION

English
2-2. Connecting the signal cable
NOTE
• Be sure that the power switches of both the PC and the monitor are OFF.
1. Plug the signal cable into the connector at the rear of the monitor
and the other end of the cable into the video connector on the PC.
After connecting, secure the connection with the screw-in fasteners.
Analog Input
Signal Cable Connector of PC PC
Signal Cable (enclosed, MD-
C87)
Video Output
Connector/ D-Sub
mini 15 pin
Input Connecor
(monitor)/ D-Sub
mini 15 pin
• Standard graphics card
Digital Input
Signal Cable Connector of PC PC
FD-C39 (Optional)
Video Output
Connector DVI-I
Input Connecor
(monitor)/ DVI
• Digital Graphics card
2. Plug the enclosed touch panel cable (FD-C38) into the RS-232C port
of the monitor. Then, plug the other end of the cable into the COM
port of the PC.
3.Power Cord 2.Touch Panel Cable
1.Signal Cable
Analog Signal Input Connecter
Digital Signal Input Connecter
2. CABLE CONNECTION
13

English
14 2. CABLE CONNECTION
3. Plug the power cord into the power connector on the rear of the
monitor. Then, plug the other end of the cord into a power outlet.
WARNING
Use the enclosed power cord and connect to the standard
power outlet of your country.
Be sure to remain within the rated voltage of the power cord.
Not doing so may cause in fire or electric shock.
The equipment must be connected to a grounded main
outlet.
Not doing so may cause in fire or electric shock.
4. Turn on the monitor’s main power and then switch on the PC's
power.
The monitor’s power indicator will light up (blue).
If an image does not appear, refer to the “6. TROUBLESHOOTING” (p.26) for
advice.
5. Install the touch panel driver TouchWare (for Windows 2000/XP) or
MT 7 (for Windows Vista) depending on your OS.
NOTE
• Regarding installing touch panel drivers and cautions, please refer to the
Installation Guides in the CD-ROM.
• When selecting the Calibration Type at the installing the TouchWare, select “2-
point calibration”.

English
NOTE
• Whenever finished, turn off the PC and the monitor. Disconnecting the monitor
from the power supply is recommended to save energy completely.
• Adjust brightness of the screen depending on the brightness of your environment.
Too dark or too bright of a screen can cause eyestrain.
• Be sure to take adequate rests. A 10-minute rest period each hour is suggested.
2-3.Touch Operation
Point and touch with one finger only.
NOTE
• Do not touch the screen while turning on the PC and the monitor. Touch the screen
one second later after appearing the image.
• For the users with gloves, we recommend to use touch panel pointer, “TP1”
(optional). Regarding the installation, please refer to the User’s Manual of TP1.
2-4. Connecting two PCs to the monitor
Two PCs can be connected to the monitor through the DVI and the D-Sub mini 15 pin
connector on the back of the monitor.
Selecting the active input
The Input Signal Selection Button on the control panel can be used to select either Signal
1 or Signal 2 as the active input at any time. Every time the button is pressed, the input
changes. When switching the signal, the kind of the input signal (Signal1 or 2/Analog or
Digital) is displayed for a few seconds on the right top corner of the screen.
ENTERAUTO
SIGNAL
1 - 2 MODE
Input Signal Selection Button
2. CABLE CONNECTION
15

English
3. ScreenManager
3-1. How to use the ScreenManager
ENTERAUTO
SIGNAL
1 - 2 MODE
1. Entering the ScreenManager
Press the Enter Button once to display the main menu of the ScreenManager.
2. Making Adjustments and Settings
(1) Select the desired sub menu icon using the Control Buttons and press the Enter
Button. The sub menu appears.
(2) Use the Control Buttons to select the desired setting icon and press the Enter
Button. The setting menu appears.
(3) Use the Control Buttons to make all required adjustments and press the Enter
Button to save the settings.
3. Exiting the ScreenManager
(1) To return to the main menu, select the <Return> icon or press the Down
Button twice, followed by the Enter Button.
(2) To exit the ScreenManager, select <Exit> icon or press the Down Button twice,
followed by the Enter Button.
NOTE
• Double clicking the Enter Button at any time also exits the ScreenManager menu.
Auto Adjustment Button Enter Button
Control Buttons
Left, Down, Up, Right
ScreenManager
Main Menu
16 3. ScreenManager

English
3-2. Adjustments and Settings
The following table shows all the ScreenManager’s adjustment and setting menus.
“*” indicates adjustments of analog input only.
Main menu Sub menu Reference
Clock *
Phase *
Position *
Range Adjustment *
Screen
Smoothing
4-1. Screen Adjustment (p.20)
Brightness
Color Mode
•Custom
Temperature
Gamma
Saturation
Hue
Gain
Reset
Color
•sRGB
4-2. Color Adjustment (p.23)
Input Signal Set the input signal selection of
automatic or manual (p.19)
Off Timer Set the power save (p.18)
VGA Selection Select the display mode. (p.27)
Menu Position Adjust the menu position.
Translucent Set the transparency of the menu.
Menu Off Timer Set the menu displaying time.
Others
Reset Return to the factory default settings.
(p.32)
Information Information Review the ScreenManager’s settings,
model name, serial number and usage
time*1.
Language English, German,
French, Spanish,
Italian and Swedish
Select the ScreenManager’s language.
*1 Due to the inspection on the factory, the usage time may not “0 hour” at shipping.
3. ScreenManager
17

English
3-3. Useful Functions
Adjustment Lock
Use the “Adjustment Lock” function to prevent any accidental changes.
Locked function • Auto Adjustment Button adjustments and settings in the
ScreenManager.
Unlocked function • Adjustment of brightness by the Control Buttons.
• Input Signal Selection Button
• Mode Button
[To lock]
(1) Switch off the monitor’s power by the power switch on the control panel.
(2) Press on the Auto adjustment button while switching on the monitor’s power.
[To unlock]
(1) Switch off the monitor’s power by the power switch on the control panel.
(2) Hold down the Auto adjustment button once again and turn the power back on.
Off Timer
The off timer function causes the monitor to automatically enter a power off state after
a predetermined amount of time has lapsed. This function was created to reduce
afterimage characteristics that are particular to LCD monitors when the monitor screen
is left on for a long period without use.
[Procedure]
(1) Select <Off Timer> in the ScreenManager <Others> menu.
(2) Select “Enable” and press the Right and Left Buttons to adjust the “On Period” (1
to 23 hours).
[Off timer system]
PC Monitor Power Indicator
On Period (1H - 23H) Operation Blue
Last 15 min. in “On period” Advance Notice *1 Blue Flashing
“On period” expired Power off Flashing yellow slowly
*1 Advance notice (Power Indicator flashing blue) will be given 15 minutes before the monitor
automatically enters the “Power Off” mode. To delay entering the “Power Off” mode, press
the power switch during the advance notice period. The monitor will continue to operate for
an additional 90 minutes.
[Power Resumption Procedure]
Press the power switch.
18 3. ScreenManager
