Hustler Turf Equipment Mini FasTrak™
Optional catchers help the FasTrak
and Mini FasTrak maintain a
professional quality lawn.
The Hustler Mini FasTrakTM is not exactly what it seems to be.
Zipping around a birdbath,accelerating across a wide-open
stretch of bluegrass,now disappearing through a backyard
gate,this mower follows in the storied tradition of the first
zero-turning-radius lawnmower ever built, a 36-inch cut,
homeowner Hustler originally sold in 1964.And now,40-some
years later, we’ve come full-circle together.
You need professional quality of cut from a durable,operator-
friendly mower with a footprint accessible to tiny,out-of-the-
way parcels of lawn.And Hustler has responded with the time-
saving productivity,the golf-course finish, and the minimal
maintenance that homeowners require. And all in a mower with
a most pleasant surprise on its price tag.
The compact,very affordable Mini FasTrak brings to
the mowing of smaller, tightly congested spaces all the
advantages of far larger commercial units, the Hustler mowers
proven across five decades of hard, hard professional and
governmental use.Look here for a lifetime of dependable
performance powered by Honda and Kohler engines,with
heavy-duty construction bumper to bumper on an over-built
frame -- no lightweight stampings,no occasional welds here as
is too often the case with cheap imitators.
Own the Hustler Mini FasTrak. And let the neighbors pretend
not to notice.
YOU LITTLE IMPOSTER, YOU.
Engine
Model OHV Honda Kohler Kohler
Horsepower 16 15 17
No.of Cylinders 2 1 1
Displacement 32.3 cu in (530 cc) 29.1 cu in (477 cc) 32.6 cu in (535 cc)
Compression Ratio 8.3:1 8.5:1 8.5:1
Max.Torque 26.9 ft lbs @ 2500 rpm 27.0 ft lbs @ 2200 rpm 30.8 ft lbs @ 2200 rpm
Models Available 16/36, 16/42 15/36 17/42
Electrical System 12 volt, 15 amp regulated
Ignition Electronic
Fuel Capacity 6 US gal (22.71 L)
Transmission Dual hydrostatic, Hydro-Gear EZT
Forward Speeds 0-7 mph (0-11.26 kph), infinitely variable
Reverse Speeds 0-3.5 mph (0-5.63 kph), infinitely variable
Steering PatentedTwin-lever,SmoothTrak™ steering provides
independent control of each drive wheel.Speed, forward,
reverse,brake, and true zero-degree-radius turns are all
controlled with hand-operated controls
(Patent # 6729115B2-FT)
Brakes
Service Hydrostatic dynamic braking
Parking Sprocket and cog.Patent-pending integral park brake
system (when steering levers are placed in off position,park
brakes are automatically engaged)
Seat Molded vinyl seat,deluxe high back. Optional armrests.
Accessories
Mulch Kit Recycles clippings under deck allowing
clippings to be cut and recut,then discharged down
into the grass.Reduces handling of clippings, improves
appearance,and recycles nutrients back to the soil.
Rear and side-mounted catching systems, hour meter
Specifications subject to change without notice.
Form No. 7943 88 4-06
Hustler Turf Equipment • Hesston, Kansas 67062 • 1-800-395-4757
For more information : www.hustlerturf.com
Engine Model OHV Honda OHV Honda Kohler Kohler
Horsepower/Deck 16 hp/36 16 hp/42 15 hp/36 17 hp/42
Tires
Front Casters 11 x 4 - 5, rib tread 11 x 4 - 5, rib tread 11 x 4 - 5, rib tread 11 x 4 - 5, rib tread
Rear Drive 18 x 8.50 - 8, turf tread 18 x 9.50 - 8,tur f tread 18 x 8.50 – 8, turf tread 18 x 9.50 - 8,turf tread
Mower 36 in side-discharge 42 in side-discharge 36 in side-discharge 42 in side-discharge
Width 36 in (111.76 cm) 42 in (132.08 cm) 36 in (111.76 cm) 42 in (132.08 cm)
Blades 1, 20.5 in x 2.5 in x .20 in 2, 20.5 in x 2.5 in x .20 in 1,20.5 in x 2.5 in x .20 in 2,20.5 in x 2.5 in x .20 in
1, 13.75 in x 2.5 in x .20 in 1, 13.75 in x 2.5 in x .20 in
Blade Tip Speed 18,200 fpm 18,200 fpm 18,200 fpm 18,200 fpm
Cut Height 1.5 in to 4 in, .25 in increments 1.5 in to 4 in, .25 in increments 1.5 in to 4 in, .25 in increments 1.5 in to 4 in,.25 in increments
(3.81 cm to 10.16 cm, .64 cm) (3.81 cm to 10.16 cm, .64 cm) (3.81 cm to 10.16 cm,.64 cm) (3.81 cm to 10.16 cm, .64 cm)
Dimensions
Height 38 in (96.52 cm) 37.3 in (94.74 cm) 37.3 in (94.74 cm) 37.3 in (94.74 cm)
Length 72.5 in (184.15cm) 74 in (187.96 cm) 74 in (187.96 cm) 74 in (187.96 cm)
Width Overall 35.9 in (91.19 cm) w/chute up 41.6 in (105.66 cm) w/chute up 41.6 in (105.66 cm) w/chute up 41.6 in (105.66 cm) w/chute up
Tire-to-tire width 35.5 in (90.17cm) 37.75 in (95.89 cm) 37.75 in (95.89 cm) 37.75 in (95.89 cm)
Net Weight 552 lbs (250.33 kg) 572 lbs (259.4 kg) 552 lbs (250.33 kg) 572 lbs (259.4 kg)

• A 3-year bumper-to-bumper warranty-parts & labor
• Lifetime warranty on the tractor frame
• Lifetime warranty on the leading edge of the deck
• 3-years on the blade-spindle bearings
• 3-years on front-caster-fork bearings
BEST WARRANTY* IN THE BUSINESS
* See dealer for details on Hustler warranties.
PROFESSIONAL MOWING COMES HOME™
IN A MORE COMPACT SIZE AND PRICE!
MINI FASTRAK IS SMALL IN SIZE, BUT LARGE IN FEATURES
The welded frame
is the strongest ever
built for the residential
market and comes with
a lifetime warranty
Honda or Kohler engines provide plenty of high-torque power
The maintenance-free EZT transmissions are the heart
and soul of the Mini FasTrak’s SmoothTrakTM steering
Heavy-duty welded decks come with a lifetime warranty on the leading edge The fuel tanks come with an integrated site gauge
allowing you to check your fuel level at a glance
LET’S CRASH SOME GATES The very first zero-radius-turning
lawnmower ever introduced was the Hustler 36. It was a 36-inch cut, homeowner mower first
sold in 1964.Now,40 years later, the Hustler has come full circle with the introduction of the
Mini FasTrak™ – a homeowner unit with a choice of 36 or 42-inch mowing decks.
With the introduction of the Mini FasTraks,now professional mowing is within the reach of
even smaller lawns.With 36 and 42-
inch mowing decks,more and more
homeowners will know the time-
saving,zero-degree-turning
productivity,the beautiful
finished appearance,and
the minimal service and
maintenance that Hustler
has made famous.
A FEW MORE REASONS WHY WE’RE THE BEST!
• Heavy-duty construction, – the Mini FasTrak’s over-built, welded frame alone setting it
apart from cheap imitators with their lightweight stampings and occasional welds
• 36”and 42” side-discharge/mulching decks that will produce the best
looking lawn in your neighborhood
• Foot-assisted deck lift system is designed to
be the easiest to use in the industry
• Adjustable (fore/aft,up/down) steering levers
for ideal positioning.
• Increased cooling capacity for the hydrostats
– no routine overheating on slopes as is the
case with would-be competitors
• SmoothTrak™ Steering – a steering system
that simply must be felt to be believed,far
smoother and easier to operate than any other
on the market
Along with a more compact size, the Mini FasTrak also carries a smaller pricetag. Contact your
local dealer to see how inexpensively you can bring professional mowing home to your yard.
With the compact Mini Z,gates are no
longer an obstacle to your riding mower.
