HYPER WELLBEING Eden Premium User manual

Eden Premium
4 Person Near Infrared Sauna
Assembly Instructions

INTRODUCTION:
Firstly, thank you for purchasing one our lovely saunas, we’re sure you’re going to
love the benefits of Near Infrared in our sauna for many years to come. The
following is a brief guide on how to assemble the sauna.
Note: Many parts of the sauna are heavy and so two strong people are
recommended to assemble the sauna.
1
Hyper Wellbeing - Sauna Assembly Instructions
Unpacking the sauna
Carefully unpack the sauna parts from the boxes and lean the sauna sides, back
and front walls against the wall in the area where the sauna is going to be
assembled.
IMPORTANT: When lifting the glass front wall use extreme caution to ensure the
glass door doesn’t swing open, lean the glass front wall over slightly to ensure the
door remains closed during unpacking and during fitment to the sauna (having
someone available to ensure the door doesn’t open during handling is also
worthwhile if possible)

3
2Locate the sauna base and sit on the floor in the final location the sauna is
intended to be located. Place the word "REAR" on the base toward the rear
wall. Place the rear wall of the sauna near the sauna base and lean against
the wall as shown below (note the cables should be positioned at the top)
Place the bottom of the rear wall up onto the base and locate centrally.
Have someone hold the rear wall in place.
Hyper Wellbeing - Sauna Assembly Instructions

Repeat per step 4 above for the other wall, making sure to carefully align
and engage the alignment groove on the corresponding wall sections and
clip all clips up fully
5
4Place one of the side walls onto the base and up against the rear wall as
shown below, carefully align the corners and aligning grooves on both wall
sections and clip together (please note if the clips don’t close fully then the
wall is not correctly aligned – start at the top and work down as it’s easier to
align the top clips first) All clips must be latched before starting on another
wall. Note: the cables should be located at the top of the side walls and the
heater on the side wall located as shown below
Hyper Wellbeing - Sauna Assembly Instructions

7
6Fit the vertical seat member as shown below with the heater facing out
and face the word UP towards the top. The side walls need to be slightly
spread apart to do this. Keep the walls spread apart for the next step
Plug in the lower heater wires as shown above before fitting the seat top
Hyper Wellbeing - Sauna Assembly Instructions

9
8Fit the seat top while the side walls are still spread apart. Bring the side
walls together and align the seat top with the dressed edge to the front.
Fit 2 long screws provided to secure the seat top to the seat vertical
member
Carefully fit the glass front wall (refer to warning at step 1 regarding the
glass door opening during handling) with the side walls. Carefully align
the corners and clip all clips to the closed position.
Hyper Wellbeing - Sauna Assembly Instructions

10 Lift and fit the roof to the sauna. If the roof is a tight fit just unclip the upper
most wall clips until the roof sits down fully and then re-clip the top wall
clips. (The lights should be positioned to the front) ALL cables must be fed
from the sauna up through the corresponding holes in the roof and plugged
in as shown below
Hyper Wellbeing - Sauna Assembly Instructions

12
11
Fit the Near Infrared heaters. Firstly
locate left and right heaters
accordingly as marked
Plug in the heaters to the
corresponding plug outlet
Hyper Wellbeing - Sauna Assembly Instructions

14
13
Next, align the heater tops with the
Velcro on the front wall and fit both
heaters
Fit the wall mounted O3 / Ioniser unit. Note: Short screws supplied must be
used to secure this to the wall
Hyper Wellbeing - Sauna Assembly Instructions
15 Plug the sauna into any standard 10 amp outlet and turn on at the sauna
control panel. At this point both Near Infrared heaters should start emitting a
beautiful Red Near infrared light.

Hyper Wellbeing - Sauna Assembly Instructions
Simultaneously press the
temperature (+ & -) Buttons to
change from Fahrenheit to
Celsius.
