Hypercom IEN 1000 Application guide

Hardware Reference
Version 1.5
Integrated Enterprise Network
940043-002

Hypercom, Inc.
2851 West Kathleen Road
Phoenix, Arizona 85023
USA
Corporate Telephone: [phone]
Corporate Fax: [phone]
TRADEMARKS: Hypercom has attempted throughout the Integrated Enterprise Network Reference Library to distinguish
proprietary trademarks from descriptive terms by following the capitalization style used by the manufacturer.
Every effort has been made to supply complete and accurate information. However, Hypercom assumes no responsibility for its
use, nor any infringement of the intellectual property rights of third parties which would result from such use.
Copyright 1997 by HYPERCOM®, INC.
Manufactured in the United States of America

©HYPERCOM, INC. 1993 - 1997. All Rights Reserved.
Hypercom, the Hypercom Logo and Integrated Enterprise Network are registered trademarks of Hypercom,
Inc. This publication is proprietary to Hypercom, Inc., and is intended solely for the contractual use of
Hypercom customers. This publication may not be reproduced or distributed for any purpose without the
written permission of Hypercom, Inc.
NOTICE
Hypercom, Inc., reserves the right to make changes to specifications at any time and without notice. The
information furnished in this publication by Hypercom, Inc., is believed to be accurate and reliable, however,
no responsibility is assumed by Hypercom, Inc., for its use.
This document applies to the Hypercom Integrated Enterprise Network system and supporting software.
FCC NOTICE
The Hypercom devices described herein generates and uses radio frequency energy. If not installed and used
properly, they may interfere with radio and television reception.
These devices have been tested and certified to comply with the limits for a Class A digital device, as defined in
Part 15 of the Federal Communications Commission (FCC) rules. Class A limits are designed to provide
reasonable protection against radio/television interference in a business environment.
To comply with FCC regulations, you must use shielded cables with these devices. Operation with unapproved
equipment or unshielded cables is likely to result in interference with radio or television reception. Changes
made to these devices without the approval of Hypercom, Inc., could void your authority to operate them.
These devices may cause interference even though they meet Class A limits. If there is interference, try to
eliminate it by:
n
Reorienting or relocating the receiving antenna of the radio or television.
n
Increasing the distance between the receiver and the Hypercom equipment.
n
Connecting the device to an outlet on a circuit different from that to which the receiver is connected.
Repair work on these devices must be done only by Hypercom, Inc., or a Hypercom authorized repair station.

TABLE OF CONTENTS
940043-002 INTEGRATED ENTERPRISE NETWORK I
Table of Contents
CHAPTER 1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
IEN Hardware Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Chapter 2 - Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Chapter 3 - Port Processors and Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Chapter 4 - Cables and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Chapter 5 - System Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Chapter 6 - IEN 1000 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
CHAPTER 2 CHASSIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Chassis Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
IEN 1000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
IEN 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
IEN 3000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
IEN 4000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
IEN 5000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20

TABLE OF CONTENTS
II IEN HARDWARE REFERENCE 940043-002
Bus Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
High-Speed Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Standard Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
TDM Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
Chassis Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
T1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
2-Wire E&M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Dial/Leased Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
10Base-T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Token Ring UTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
RS485 LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
V.35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
V.24 RS232C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-29
10Base-2 LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
Token Ring STP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
RS485 LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
CHAPTER 3 PORT PROCESSORS/MODULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Port Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Physical Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
CID15H/CID15H-A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
CID61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
CID61-Dual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
CID63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
CIM15H-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
DLA14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
DSX11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
DTC11-E1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27
DTC11-LHO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27
LET61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
LET61B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
LET61H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
LTR61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-32

TABLE OF CONTENTS
940043-002 INTEGRATED ENTERPRISE NETWORK III
LTR61B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-32
LTR61H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-32
Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-35
CIR01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-35
CIV01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
DES10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-37
DLZ01-C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-38
DLZ10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-39
DSU63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-40
DVF18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-41
HDM14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
HDM28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-45
ISD01-ST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-46
ISD01-U . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-47
PCM14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-48
PCM28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-49
MEM61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-50
IEN 1000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-51
CPA03 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-54
DSU56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-56
LET10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-57
LTR10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-58
HUB08 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-59
MAU08 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-60
IDT10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-61
CHAPTER 4 CABLE SPECIFICATIONS & ADAPTERS . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Selecting Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Cable Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Type A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Type ALG-2W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Type ALG-PD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

TABLE OF CONTENTS
IV IEN HARDWARE REFERENCE 940043-002
Type B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Type D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Type D6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
Type DDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Type HB2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Type HB3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Type ISDN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Type P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
Type RIRO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
Type RJ11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
Type T1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
Type T1K . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
Type T1-45-M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Type T1-15-XF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Type T1-45-XF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28
Type T(63) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Type TR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
Type UET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31
Type UTR-45-M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Type V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33
Type VF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
Type VM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
Type VNN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37
Type VX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38
Type Y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39
Type YA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-41
Type Y(63) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-43
Type 2VE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
HUB08/LET10 PATCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-48
Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-50
LEC01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-50
LAU01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-51

TABLE OF CONTENTS
940043-002 INTEGRATED ENTERPRISE NETWORK V
T1/PCM Line Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-52
CHAPTER 5 SYSTEM CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Bus Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
IEN 2000 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Bus Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
High-Speed Bus Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
IEN 3000 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Bus Clock Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
DIP Switch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Bus Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
High-Speed Bus Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
IEN 4000 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Bus Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
High-Speed Bus Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
IEN 5000 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Bus Clock Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
DIP Switch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
Bus Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
High-Speed Bus Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
CHAPTER 6 SYSTEM CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
IEN 1000 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Software Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
WAN Port Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
IENView Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

TABLE OF CONTENTS
VI IEN HARDWARE REFERENCE 940043-002

CHAPTER 1
Introduction
In This Chapter
IEN Hardware Reference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

INTRODUCTION
940043-002 INTEGRATED ENTERPRISE NETWORK 1-3
IEN HARDWARE REFERENCE
The IEN Hardware Reference is your comprehensive guide to referencing the Hypercom IEN
chassis, port processors and modules, cables and adapters, and system configuration.
The IEN Hardware Reference contains the following chapters:
Chapter 2 - Chassis
This chapter describes the Hypercom solutions for network switches/routers. This chapter
describes the IEN 1000, IEN 2000, IEN 3000, IEN 4000, and IEN 5000 chassis.
Chapter 3 - Port Processors and Modules
This chapter describes the Hypercom port processors and modules. It includes block
diagrams, bus communications, and jumper settings.
Chapter 4 - Cables and Adapters
This chapter describes the Hypercom solutions for connectivity. This chapter includes a
cable matrix and detailed specifications on Hypercom cables and adapters.
Chapter 5 - System Configuration
This chapter describes the Hypercom bus extension and node configuration. It includes bus
clock settings and multi-chassis configurations.
Chapter 6 - IEN 1000 Configuration
This chapter describes the Hypercom IEN 1000 chassis. It includes additional system
configuration examples.

CHAPTER 1
1-4 IEN HARDWARE REFERENCE 940043-002

CHAPTER 2
Chassis
In This Chapter
Chassis Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
IEN 1000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
IEN 2000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
IEN 3000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
IEN 4000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
IEN 5000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Bus Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Chassis Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24

CHASSIS
940043-002 INTEGRATED ENTERPRISE NETWORK 2-3
CHASSIS SPECIFICATIONS
Table 2-1 lists the Hypercom IEN chassis specifications.
Table 2-1 IEN Chassis Specifications
(TXLSPHQW ,(1 ,(1 ,(1 ,(1 ,(1
AC (90-130 or
185-255 VAC
48-400Hz) 20VA 35VA 35VA 125VA 140VA
DC 43-56 VDC N/A N/A N/A N/A 110W
Little fuse Part
Number/ Rating 218025 2.5A 250V 218025 2.5A 250V 218025 2.5A 250V 216004 4A 250V 218005 5A 250V
Heat Dissipation AC 15W 30W 30W 150W 110W
Heat Dissipation DC N/A N/A N/A N/A 90W
Width 19in.
483mm 19in. 483mm 10-7/8 in. 276mm 17in. 432.3mm 19in. 483mm
Depth 14in.
360mm 14.0in. 355.61mm 17-3/4in. 451mm 12.5in. 304.8mm 21-7/8in. 556mm
Height 1-7/8in.
29mm 1.75in. 44.46mm 6-1/8in. 156mm 5.25in. 133.35mm 5-1/8in. 130mm
Weight 4.25lbs
1.9Kg 15.0lbs 6.7Kg 11.1lbs 5Kg 19lbs 8.486Kg 26lbs 11.8Kg
Operating
Temperature 32-104° F 0 - 40° C 32-104° F 0 - 40° C 32-104° F 0 - 40° C 32-104° F 0 - 40° C 32-104° F 0 - 40° C
Humidity 25-95% non-
condensing 25-95% non- condensing 25-95% non- condensing 25-95% non- condensing 25-95% non- condensing
Specifications are subject to change without notice.

CHAPTER 2
2-4 IEN HARDWARE REFERENCE 940043-002
SAFETY PRECAUTIONS
This section describes the safety precautions necessary to install the Hypercom IEN series
products.
The IEN chassis is Safety Class 1 equipment provided with a protective ground terminal. An
uninterruptedly safety ground must be provided from the 110VAC supply to the IEN chassis
power connector. Whenever it is likely that the protection has been impaired, the
equipment must be made inoperative and secured against any unintended operation.
Equipment servicing, adjustment, maintenance, or repair must be performed only by
qualified personnel.
CAUTION: Electrical Safety: Observe all normal electrical safety practices when operating
any equipment attached to an active power source.
Authorized Service: Covers or ground connections must be removed by a
Hypercom authorized service technician.
Fire Hazard: To avoid fire hazard, only use fuses with the required current rating
and of the specified chassis type for replacement. See “Chassis Specifications” on
page 3 for information on fuse requirements for each chassis.
Equipment Damage: If you are using analog voice, do not plug 48 volt voice
interfaces into RS232 or V.35 ports. If the wrong adapter interfaces or cables are
installed in the IEN chassis ports, equipment damage can occur.
Electostatic Damage: Before performing any maintenance on the chassis or the
port processors, ensure that you wear a static strap and are grounded to the IEN
chassis.

CHASSIS
940043-002 INTEGRATED ENTERPRISE NETWORK 2-5
IEN 1000
The IEN 1000 chassis supports one WAN and one serial port. The IEN 1000 chassis can
function as a simple bridge, bridge-router, or access device for a downstream controller or
terminal (SDLC, Bisync). Due to its design flexibility, the IEN 1000 chassis can have three
additional serial ports, an Ethernet or Token Ring router port, an eight-port UTP hub or an
eight-port Token Ring multiple access unit (MAU), data compression, data encryption,
integrated DSU, and 14.4Kbps dial backup.

CHAPTER 2
2-6 IEN HARDWARE REFERENCE 940043-002
Front Panel
The IEN 1000 chassis is a single port frame relay access device (FRAD) controller capable of
interfacing with multiple protocols. Each interface status is presented on the front panel in
the form of LED indicators and a two-line by 20-character display. Figure 2-1 illustrates the
front panel of the IEN 1000 chassis.
Figure 2-1 IEN 1000 Front Panel
WAN/Port 1 This status window contains LED indicators for the WAN and serial port 1 transmit and
receive status.
Optional
Serial Ports The Optional Serial Ports contain LED indicators for serial port 2, 3, and 4 transmit and receive status.
Node ID The Node ID contains four 16-position rotary switches used for configuration and
addressing.
HUB
Interface The HUB Interface contains LED indicators for the partition and link status of each port on the HUB08/16 or MAU.
HUB08 Refer to Chapter 3, LET10 for more information about the Ethernet
upgrade module.
MAU08 Refer to Chapter 3, LTR10 for more information about the Token Ring
upgrade module.
RUN Indicator The RUN Indicator contains an LED which flashes to indicate the CPU is running.
LAN Interface The LAN Interface contains LED indicators for the Ethernet or Token Ring LAN interface
transmit and receive status.
Power
Indicator The Power Indicator contains an LED that indicates power is applied.
Menu Display The Menu Display is a two-line by 20-character display used to provide port status and the
software revision.
Menu Select/
Reset Button The Menu Select/Reset Button is used to scroll through the Menu Display. Pressing and holding the Menu Select/Reset Button for five seconds resets the IEN 1000.
