OWNER' S MANUAL

Operation

Maintenance

Specifications

All information in this Owner’s Manual is current at the time

of publication. However, HYUNDAI reserves the right to make

changes at any time so that our policy of continual product

improvement may be carried out.

This manual applies to all models of this vehicle and includes

descriptions and explanations of optional as well as standard

equipment.

As a result, you may find material in this manual that does not

apply to your specific vehicle.

Please note that some models are equipped with Right-Hand

Drive (RHD). The explanations and illustrations for some

operations in RHD models are opposite of those written in this

manual.

Your HYUNDAI should not be modified in any way. Such modifications may

adversely affect the performance, safety or durability of your HYUNDAI

and may, in addition, violate conditions of the limited warranties covering

the vehicle. Certain modifications may also be in violation of regulations

established by the Department of Transportation and other government

agencies in your country.

CAUTION: MODIFICATIONS TO YOUR HYUNDAI

Your vehicle is equipped with electronic fuel injection and other electronic

components. It is possible for an improperly installed/adjusted two-way radio

or cellular telephone to adversely affect electronic systems. For this reason,

we recommend that you carefully follow the radio manufacturer’s instructions

or consult your HYUNDAI dealer for precautionary measures or special

instructions if you choose to install one of these devices.

The vehicle is equipped with a device of the system Pan-european eCall

which calls emergency services. Any self-or unauthorized interference in the

system Pan-european eCall, in vehicle systems and its components, installing

of equipment which is not recommended by vehicle manufacturer and/or in

authorized HYUNDAI dealerships can cause incorrect operation (of the device

of) the system Pan-european eCall, making erroneous calls, causing failure

of the device (in cars) in case of traffic accident or other accidents, when you

need emergency care.

This may be dangerous and threaten your life!

TWO-WAY RADIO OR CELLULAR

TELEPHONE INSTALLATION

WARNING! (IF EQUIPPED)

This manual includes information titled as DANGER, WARNING, CAUTION and

NOTICE.

These titles indicate the following:

DANGER

DANGER indicates a hazardous situation which, if not avoided, will result in

death or serious injury.

WARNING

WARNING indicates a hazardous situation which, if not avoided, could result

in death or serious injury.

CAUTION

CAUTION indicates a hazardous situation which, if not avoided, could result

in minor or moderate injury.

NOTICE

NOTICE indicates a situation which, if not avoided, could result in vehicle

damage.

SAFETY AND VEHICLE DAMAGE WARNING

Table of contents

Foreword

Vehicle information

Safety system

Instrument cluster

Convenient features

Driving your vehicle

Driver assistance system

Emergency situations

Maintenance

Index

Introduction

FOREWORD

Congratulations, and thank you for choosing HYUNDAI. We are pleased to welcome

you to the growing number of discerning people who drive HYUNDAIs.We are very

proud of the advanced engineering and high-quality construction of each HYUNDAI

we build.

Your Owner’s Manual will introduce you to the features and operation of your new

HYUNDAI. To become familiar with your new HYUNDAI, so that you can fully enjoy it,

read this Owner’s Manual carefully before driving your new vehicle.

This manual contains important safety information and instructions intended to

familiarize you with your vehicle’s controls and safety features so you can safely

operate your vehicle.

This manual also contains information on maintenance designed to enhance safe

operation of the vehicle. It is recommended that all service and maintenance on your

car be performed by an authorized HYUNDAI dealer. HYUNDAI dealers are prepared

to provide high-quality service, maintenance and any other assistance that may be

required.

This Owner’s Manual should be considered a permanent part of your vehicle, and

should be kept in the vehicle so you can refer to it at any time. The manual should

stay with the vehicle if you sell it to provide the next owner with important operating,

safety and maintenance information.

HYUNDAI MOTOR COMPANY

CAUTION

Severe engine and transmission damage may result from the use of poor quality

fuels and lubricants that do not meet HYUNDAI specifications. You must always use

high quality fuels and lubricants that meet the specifications listed on Page 2-14 in

the Vehicle Specifications section of the Owner’s Manual.

publication may be reproduced, stored in any retrieval system or transmitted in

any form or by any means without the prior written permission of HYUNDAI Motor

Company.

HOW TO USE THIS MANUAL

We want to help you get the greatest possible driving pleasure from your vehicle.

Your Owner’s Manual can assist you in many ways. We strongly recommend that you

read the entire manual. In order to minimize the chance of death or injury, you must

read the DANGER, WARNING and CAUTION sections in the manual.

Illustrations complement the words in this manual to best explain how to enjoy your

vehicle. By reading your manual, you will learn about features, important safety

information, and driving tips under various road conditions.

The general layout of the manual is provided in the Table of Contents. Use the

index when looking for a specific area or subject; it has an alphabetical listing of all

information in your manual.

Sections: This manual has 9 chapters plus an index. Each section begins with a brief

list of contents so you can tell at a glance if that section has the information you want.

SAFETY MESSAGES

Your safety, and the safety of others, is very important. This Owner’s Manual provides

you with many safety precautions and operating procedures. This information alerts

you to potential hazards that may hurt you or others, as well as damage to your

vehicle.

Safety messages found on vehicle labels and in this manual describe these hazards

and what to do to avoid or reduce the risks.

Warnings and instructions contained in this manual are for your safety. Failure to

follow safety warnings and instructions can lead to serious injury or death.

Introduction

Throughout this manual DANGER, WARNING, CAUTION, NOTICE and the SAFETY

ALERT SYMBOL will be used.

This is the safety alert symbol. It is used to alert you to potential physical

injury hazards. Obey all safety messages that follow this symbol to avoid

possible injury or death. The safety alert symbol precedes the signal

words DANGER, WARNING and CAUTION.

DANGER

DANGER indicates a hazardous situation which, if not avoided, will result in death

or serious injury.

WARNING

WARNING indicates a hazardous situation which, if not avoided, could result in

death or serious injury.

CAUTION

CAUTION indicates a hazardous situation which, if not avoided, could result in

minor or moderate injury.

NOTICE

NOTICE indicates a situation which, if not avoided, could result in vehicle damage.

FUEL REQUIREMENTS

Gasoline engine

Unleaded

For Europe

For the optimal vehicle performance, we recommend you use unleaded gasoline

which has an octane rating of RON (Research Octane Number) 95 / AKI (Anti Knock

Index) 91 or higher. You may use unleaded gasoline with an octane rating of RON

91-94 / AKI 87-90 but it may result in slight performance reduction of the vehicle. (Do

not use methanol blended fuels)

Except Europe

Your new vehicle is designed to use only unleaded fuel having an Octane Rating of

RON (Research Octane Number) 91 / AKI (Anti-Knock Index) 87 or higher. (Do not use

methanol blended fuels)

Your new vehicle is designed to obtain maximum performance with UNLEADED FUEL,

as well as minimize exhaust emissions and spark plug fouling.

CAUTION

NEVER USE LEADED FUEL. The use of leaded fuel is detrimental to the catalytic

converter and will damage the engine control system’s oxygen sensor and affect

emission control.

Never add any fuel system cleaning agents to the fuel tank other than what has

been specified (We recommend that you consult an authorized HYUNDAI dealer for

details.)

WARNING

• Do not “top off” after the nozzle automatically shuts off when refueling.

• Always check that the fuel cap is installed securely to prevent fuel spillage in the

event of an accident.

Introduction

Leaded (if equipped)

For some countries, your vehicle is designed to use leaded gasoline. When you are

going to use leaded gasoline, we recommend that you ask an authorized HYUNDAI

dealer.

Octane rating of leaded gasoline is same with unleaded one.

Gasoline containing alcohol and methanol

Gasohol, a mixture of gasoline and ethanol (also known as grain alcohol), and gasoline

or gasohol containing methanol (also known as wood alcohol) are being marketed

along with or instead of leaded or unleaded gasoline.

Do not use gasohol containing more than 10% ethanol, and do not use gasoline or

gasohol containing any methanol. Either of these fuels may cause drivability problems

and damage to the fuel system, engine control system and emission control system.

Discontinue using gasohol of any kind if drivability problems occur.

Vehicle damage or driveability problems may not be covered by the manufacturer’s

warranty if they result from the use of:

1. Gasohol containing more than 10% ethanol.

2. Gasoline or gasohol containing methanol.

3. Leaded fuel or leaded gasohol.

CAUTION

Never use gasohol which contains methanol. Discontinue use of any gasohol

product which impairs drivability.

Other fuels

Using fuel additives such as:

- Silicone fuel additive

- MMT (Magnanese, Mn) fuel additive

- Ferrocene (iron-based) fuel additive

- Other metallic-based fuel additives

may result in cylinder misfire, poor acceleration, engine stalling, damage to the

catalyst, or abnormal corrosion, and may cause damage to the engine resulting in a

reduction in the overall life of the powertrain.

NOTICE

Damage to the fuel system or performance problem caused by the use of these

fuels may not be covered by your New Vehicle Limited Warranty.

Use of MTBE

HYUNDAI recommends avoiding fuels containing MTBE (Methyl Tertiary Butyl Ether)

over 15.0% vol. (Oxygen Content 2.7% weight) in your vehicle.

Fuel containing MTBE over 15.0% vol. (Oxygen Content 2.7% weight) may reduce

vehicle performance and produce vapor lock or hard starting.

CAUTION

Your New Vehicle Limited Warranty may not cover damage to the fuel system and

any performance problems that are caused by the use of fuels containing methanol

or fuels containing MTBE (Methyl Tertiary Butyl Ether) over 15.0% vol. (Oxygen

Content 2.7% weight.)

Do not use methanol

Fuels containing methanol (wood alcohol) should not be used in your vehicle. This

type of fuel can reduce vehicle performance and damage components of the fuel

system, engine control system and emission control system.

Fuel Additives

HYUNDAI recommends that you use unleaded gasoline which has an octane rating of

RON (Research Octane Number) 95 / AKI (Anti Knock Index) 91 or higher (for Europe)

or Octane Rating of RON (Research Octane Number) 91 / AKI (Anti-Knock Index) 87 or

higher (except Europe).

For customers who do not use good quality gasolines including fuel additives

regularly, and have problems starting or the engine does not run smoothly, one

bottle of additive added to the fuel tank according to the maintenance schedule is

recommended (refer to chapter 9, “Normal Maintenance Schedule”).

Additives are available from your authorized HYUNDAI dealer along with information

on how to use them. Do not mix other additives.

Operation in foreign countries

If you are going to drive your vehicle in another country, be sure to:

• Observe all regulations regarding registration and insurance.

• Determine that acceptable fuel is available.

Introduction

VEHICLE MODIFICATIONS

• This vehicle should not be modified. Modification of your vehicle could affect its

performance, safety or durability and may even violate governmental safety and

emissions regulations.

In addition, damage or performance problems resulting from any modification may

not be covered under warranty.

• If you use unauthorized electronic devices, it may cause the vehicle to operate

abnormally, wire damage, battery discharge and fire. For your safety, we

recommend that you do not use unauthorized electronic devices.

VEHICLE BREAK-IN PROCESS

By following a few simple precautions for the first 1,000 km (600 miles) you may add

to the performance, economy and life of your vehicle.

• Do not race the engine.

• While driving, keep your engine speed (rpm, or revolutions per minute) between

2,000 rpm and 4,000 rpm.

• Do not maintain a single speed for long periods of time, either fast or slow. Varying

engine speed is needed to properly break-in the engine.

• Avoid hard stops, except in emergencies, to allow the brakes to seat properly.

• Don’t tow a trailer during the first 2,000 km (1,200 miles) of operation.

RETURNING USED VEHICLES (FOR EUROPE)

HYUNDAI promotes an environmentally sound treatment for end of life vehicles and

offers to take back your Hyundai end of life vehicles in accordance with the European

Union (EU) End of Life Vehicles Directive.

You can get detailed information from your national HYUNDAI homepage.

Exterior overview (I)....................................................................................... 2-2

Exterior overview (II)...................................................................................... 2-3

Interior overview (I) ....................................................................................... 2-4

Interior overview (II) ...................................................................................... 2-5

Instrument panel overview (I).......................................................................2-6

Instrument panel overview (II).......................................................................2-7

Engine compartment.....................................................................................2-8

Dimensions.....................................................................................................2-11

Engine specification ......................................................................................2-11

Bulb wattage ................................................................................................. 2-12

Tires and wheels ...........................................................................................2-13

Air conditioning system................................................................................2-14

Tire load and speed capacity ......................................................................2-14

Gross vehicle weight.....................................................................................2-15

Luggage volume ...........................................................................................2-15

Recommended lubricants and capacities ..................................................2-16

Recommended sae viscosity number .................................................................. 2-18

Vehicle identification number (VIN)............................................................2-19

Vehicle certification label.............................................................................2-19

Tire specification and pressure label.......................................................... 2-20

Engine number............................................................................................. 2-20

Air conditioner compressor label ................................................................2-21

Fuel label ....................................................................................................... 2-21

Declaration of conformity ........................................................................... 2-22

2. Vehicle information

2-2

Vehicle information

EXTERIOR OVERVIEW (I)

1. Hood..............................................................................................................................................5-36

2. Headlight ..................................................................................................................................... 9-69

3. Front fog light .............................................................................................................................. 9-73

4. Tires and wheels......................................................................................................................... 9-43

5. Outside rearview mirror .............................................................................................................. 5-24

6. Front windshield wiper blades ................................................................................................... 9-37

7. Windows ....................................................................................................................................... 5-27

8. Front ultrasonic sensors.............................................................................................................7-128

The actual shape may differ from the illustration.

OBC3010001





Front view

• 5 Door

2-3

EXTERIOR OVERVIEW (II)

1. Antenna.........................................................................................................................................5-94

2. Doors..............................................................................................................................................5-13

3. Fuel filler door..............................................................................................................................5-39

4. Rear ultrasonic sensors ..............................................................................................................7-126

5. High mounted stop light ............................................................................................................ 9-84

6. Rear view camera* .....................................................................................................................7-103

7. Rear window wiper blade* ..........................................................................................................9-38

8. Tailgate ......................................................................................................................................... 5-37

The actual shape may differ from the illustration.

OBC3010002





Rear view

• 5 Door

2-4

Vehicle information

INTERIOR OVERVIEW (I)

The actual shape may differ from the illustration.

OBC3010003

1. Door handle ...................................................................................................................................5-15

2. Outside rearview mirror control switch ..................................................................................... 5-25

3. Outside rearview mirror folding button .....................................................................................5-26

4. Power window switches..............................................................................................................5-28

5. Power window lock button ..........................................................................................................5-31

6. Hood release lever.......................................................................................................................5-36

7. Headlight leveling device switch ................................................................................................ 5-47

8. Heated steering wheel switch.................................................................................................... 5-22

9. Idle Stop and Go on/off switch ..................................................................................................6-45

10. Electronic Stability Control(ESC) switch ..................................................................................6-38

11. Tire pressure monitoring system(TPMS) switch........................................................................ 8-11

12. Fuse box ......................................................................................................................................9-53

13. Steering wheel............................................................................................................................5-20

14. Seats..............................................................................................................................................3-4

15. Instrument panel illumination control switch ............................................................................4-4





Left-hand drive

2-5

INTERIOR OVERVIEW (II)

The actual shape may differ from the illustration.

OBC3010003R

1. Door handle ...................................................................................................................................5-15

2. Outside rearview mirror control switch .....................................................................................5-26

3. Outside rearview mirror folding button ..................................................................................... 5-25
