Hyundai Genesis 2009 User manual

영
어
/
미
국
2009 Owner’s Manual
SERVICE STATION INFORMATION FUEL :
UNLEADED gasoline only
Pump Octane Rating of 87 (Research Octane Number 91) or higher.
FUEL TANK CAPACITY US.GAL (IMP.GAL., LITER)
3.8L-19.25(16.04,73)
4.6L-20.3(16.92,77)
TIRE PRESSURE :
See the label on the driver’s side of the center pillar outer panel.
OTHER TIRE INFORMATION :
See pages 7-31 through 7-43
HOOD RELEASE:
Pull handle under left side of dash.
ENGINE OIL :
API grade SJ, SL or ABOVE / ILSAC grade GF-3 or ABOVE and fuel
efficient oil. Use SAE 5W-20, 5W-30 or 10W-30 if normal temperatures
are above 0 F(-18 C). See page 8-4 or 8-5.
AUTOMATIC TRANSMISSION :
3.8L-USE Only ATF 9638, NWS 9638.
4.6L-USE Only ATF M 1375,4
o Car will not start ................................................................................6-3
o Flat tire .............................................................................................6-12
o Warning light/chime comes on.............................................4-49~4-67
o Engine overheats...............................................................................6-6
o Towing of your vehicle ...................................................................6-20
o Starting the engine............................................................................5-9
o Driving tips for first 1,200 miles (2,000 km) ....................................1-5
o Scheduled maintenance ...................................................................7-7
o Reporting safety defects ...................................................................8-9
QUICK INDEX
A3MO-EU85C
(영어 미국)
/
영
어
/
미
국
2009 Owner’s Manual
SERVICE STATION INFORMATION FUEL :
UNLEADED gasoline only
Pump Octane Rating of 87 (Research Octane Number 91) or higher.
FUEL TANK CAPACITY US.GAL (IMP.GAL., LITER)
3.8L-19.25(16.04,73)
4.6L-20.3(16.92,77)
TIRE PRESSURE :
See the label on the driver’s side of the center pillar outer panel.
OTHER TIRE INFORMATION :
See pages 7-31 through 7-43
HOOD RELEASE:
Pull handle under left side of dash.
ENGINE OIL :
API grade SJ, SL or ABOVE / ILSAC grade GF-3 or ABOVE and fuel
efficient oil. Use SAE 5W-20, 5W-30 or 10W-30 if normal temperatures
are above 0 F(-18 C). See page 8-4 or 8-5.
AUTOMATIC TRANSMISSION :
3.8L-USE Only ATF 9638, NWS 9638.
4.6L-USE Only ATF M 1375,4
o Car will not start ................................................................................6-3
o Flat tire .............................................................................................6-12
o Warning light/chime comes on.............................................4-49~4-67
o Engine overheats...............................................................................6-6
o Towing of your vehicle ...................................................................6-20
o Starting the engine............................................................................5-9
o Driving tips for first 1,200 miles (2,000 km) ....................................1-5
o Scheduled maintenance ...................................................................7-7
o Reporting safety defects ...................................................................8-9
QUICK INDEX
A3MO-EU85C
(영어 미국)
/

Please consult your Owner's Handbook & Warranty Information booklet for your vehicle's spe-
cific warranty coverage.
The maintenance requirements for your new Hyundai are found in Section 7. As the owner, it is your
responsibility to see that all maintenance operations specified by the manufacturer are carried out at
the appropriate intervals. When the vehicle is used in severe driving conditions, more frequent main-
tenance is required for some operations. Maintenance requirements for severe operating conditions
are also included in Section 7.
WARRANTIES FOR YOUR HYUNDAI VEHICLE
RESPONSIBILITY FOR MAINTENANCE
EN hma cover.qxd 11/27/2006 5:07 PM Page 2

OWNER'S MANUAL
Operation
Maintenance
Specifications
All information in this Owner's Manual is current at the time of publication.
However, Hyundai reserves the right to make changes at any time so that
our policy of continual product improvement may be carried out.
This manual applies to all Hyundai models and includes descriptions and
explanations of optional as well as standard equipment. As a result, you
may find material in this manual that does not apply to your specific vehi-
cle.
BH hma foreword.qxd 4/11/2008 5:36 PM Page 1

F2
Your Hyundai should not be modified in any way. Such modifications may adversely affect the per-
formance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited
warranties covering the vehicle. Certain modifications may also be in violation of regulations estab-
lished by the U.S. Department of Transportation and other federal or state agencies.
Your vehicle is equipped with electronic fuel injection and other electronic components. It is possible
for an improperly installed/adjusted two-way radio or cellular telephone to adversely affect electronic
systems. For this reason, we recommend that you carefully follow the radio manufacturer's instruc-
tions or consult your Hyundai dealer for precautionary measures or special instructions if you choose
to install one of these devices.
CAUTION: MODIFICATIONS TO YOUR HYUNDAI
TWO-WAY RADIO OR CELLULAR TELEPHONE INSTALLATION
BH hma foreword.qxd 4/11/2008 5:36 PM Page 2

F3
This manual includes information titled as WARNING, CAUTION and NOTICE.
These titles indicate the following:
✽✽NOTICE
This indicates that interesting or helpful information is being provided.
SAFETY AND VEHICLE DAMAGE WARNING
WARNING
This indicates that a condition may result in harm, serious injury or death to you or other
persons if the warning is not heeded. Follow the advice provided with the warning.
CAUTION
This indicates that a condition may result in damage to your vehicle or its equipment if the
caution is not heeded. Follow the advice provided with the caution.
BH hma foreword.qxd 4/11/2008 5:36 PM Page 3

F4
FOREWORD
Thank you for choosing Hyundai. We are pleased to welcome you to the growing number of discriminating people who drive
Hyundais. The advanced engineering and high-quality construction of each Hyundai we build is something of which we're very
proud.
Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it care-
fully because the information it contains can contribute greatly to the satisfaction you receive from your new car.
The manufacturer also recommends that all service and maintenance on your car be performed by an authorized Hyundai deal-
er. Hyundai dealers are prepared to provide high-quality service, maintenance and any other assistance that may be required.
HYUNDAI MOTOR COMPANY
Note : Because future owners will also need the information included in this manual, if you sell this Hyundai, please leave the man-
ual in the vehicle for their use. Thank you.
Copyright 2008 Hyundai Motor Company. All rights reserved. No part of this publication may be reproduced, stored in any retrieval
system or transmitted in any form or by any means without the prior written permission of Hyundai Motor Company.
CAUTION
Severe engine and transmission damage may result from the use of poor quality fuels and lubricants that do not meet
Hyundai specifications. You must always use high quality fuels and lubricants that meet the specifications listed on Page
8-4 in the Vehicle Specifications and consumer information section of the Owner's Manual.
BH hma foreword.qxd 4/11/2008 5:36 PM Page 4

F5
Guide to Hyundai Genuine Parts
1. What are Hyundai Genuine Parts?
Hyundai Genuine Parts are the same
parts used by Hyundai Motor
Company to manufacture vehicles.
They are designed and tested for the
optimum safety, performance, and reli-
ability to our customers.
2. Why should you use genuine parts?
Hyundai Genuine Parts are engi-
neered and built to meet rigid manu-
facturing requirements. Using imita-
tion, counterfeit or used salvage parts
is not covered under the Hyundai New
Vehicle Limited Warranty or any other
Hyundai warranty.
In addition, any damage to or failure of
Hyundai Genuine Parts caused by the
installation or failure of an imitation,
counterfeit or used salvage part is not
covered by any Hyundai Warranty.
3. How can you tell if you are purchas-
ing Hyundai Genuine Parts?
Look for the Hyundai Genuine Parts
Logo on the package (see below).
Hyundai Genuine Parts exported to
are packaged with labels written only
in English.
Hyundai Genuine Parts are only sold
through authorized Hyundai
Dealerships.
A100A01L A100A02L A100A04L
A100A03L
BH hma foreword.qxd 4/11/2008 5:36 PM Page 5

BH hma foreword.qxd 4/11/2008 5:36 PM Page 6

1
2
3
4
5
6
7
8
I
Introduction
Your vehicle at a glance
Safety features of your vehicle
Features of your vehicle
Driving your vehicle
What to do in an emergency
Maintenance
Specifications, Consumer information,
Reporting safety defeccts
Index
table of contents
BH hma foreword.qxd 4/11/2008 5:36 PM Page 7

1
How to use this manual / 1-2
Fuel requirements / 1-3
Vehicle break-in process / 1-5
Vehicle data collection and event data
recorders / 1-6
Indicator symbols on the instrument cluster / 1-7
Introduction
BH hma 1.qxd 4/14/2008 5:41 PM Page 1

Introduction
21
A010000AHM
We want to help you get the greatest
possible driving pleasure from your vehi-
cle. Your Owner’s Manual can assist you
in many ways. We strongly recommend
that you read the entire manual. In order
to minimize the chance of death or injury,
you must read the WARNING and CAU-
TION sections in the manual.
Illustrations complement the words in this
manual to best explain how to enjoy your
vehicle. By reading your manual, you
learn about features, important safety
information, and driving tips under vari-
ous road conditions.
The general layout of the manual is pro-
vided in the Table of Contents. A good
place to start is the index; it has an alpha-
betical listing of all information in your
manual.
Sections: This manual has eight sections
plus an index. Each section begins with a
brief list of contents so you can tell at a
glance if that section has the information
you want.
You will find various WARNINGs,
CAUTIONs, and NOTICEs in this manu-
al. These WARNINGs were prepared to
enhance your personal safety.You should
carefully read and follow ALL procedures
and recommendations provided in these
WARNINGs, CAUTIONs and NOTICEs.
✽✽NOTICE
ANOTICE indicates interesting or help-
ful information is being provided.
HOW TO USE THIS MANUAL
WARNING
A WARNING indicates a situation in
which harm, serious bodily injury or
death could result if the warning is
ignored.
CAUTION
A CAUTION indicates a situation in
which damage to your vehicle could
result if the caution is ignored.
BH hma 1.qxd 4/14/2008 5:41 PM Page 2

13
Introduction
A020101ABH-EU
3.8 engine
Your new vehicle is designed to use only
unleaded fuel having a pump octane
number ((R+M)/2) of 87 (Research
Octane Number 91) or higher.
4.6 engine
Your new vehicle is designed to use only
unleaded fuel having a pump octane
number ((R+M)/2) of 87 or higher.
For improved vehicle performance, pre-
mium unleaded fuel with a Pump Octane
Rating of 91 (Research Octane Number
95) or higher is recommended.
Your new vehicle is designed to obtain
maximum performance with UNLEADED
FUEL, as well as minimize exhaust emis-
sions and spark plug fouling.
A020103AUN-EU
Gasoline containing alcohol and
methanol
Gasohol, a mixture of gasoline and
ethanol (also known as grain alcohol),
and gasoline or gasohol containing
methanol (also known as wood alcohol)
are being marketed along with or instead
of leaded or unleaded gasoline.
Do not use gasohol containing more than
10% ethanol, and do not use gasoline or
gasohol containing any methanol. Either
of these fuels may cause drivability prob-
lems and damage to the fuel system.
Discontinue using gasohol of any kind if
drivability problems occur.
Vehicle damage or drivability problems
may not be covered by the manufactur-
er’s warranty if they result from the use
of:
1. Gasohol containing more than 10%
ethanol.
2. Gasoline or gasohol containing
methanol.
3. Leaded fuel or leaded gasohol.
FUEL REQUIREMENTS
CAUTION
Never add any fuel system cleaning
agents to the fuel tank other than
what has been specified. (Consult
an authorized HYUNDAI dealer for
details.)
WARNING
• Do not "top off" after the nozzle
automatically shuts off when
refueling.
• Tighten the cap until it clicks,
otherwise the Malfunction
Indicator Light “ ” will illumi-
nate.
• Always check that the fuel cap is
installed securely to prevent fuel
spillage in the event of an acci-
dent.
BH hma 1.qxd 4/14/2008 5:41 PM Page 3

Introduction
41
"E85" fuel is an alternative fuel com-
prised of 85 percent ethanol and 15 per-
cent gasoline, and is manufactured
exclusively for use in Flexible Fuel
Vehicles. “E85” is not compatible with
your vehicle. Use of “E85” may result in
poor engine performance and damage to
your vehicle's engine and fuel system.
HYUNDAI recommends that customers
do not use fuel with an ethanol content
exceeding 10 percent.
A020104AEN
Use of MTBE
HYUNDAI recommends avoiding fuels
containing MTBE (Methyl Tertiary Butyl
Ether) over 15.0% vol. (Oxygen Content
2.7% weight) in your vehicle.
Fuel containing MTBE over 15.0% vol.
(Oxygen Content 2.7% weight) may
reduce vehicle performance and produce
vapor lock or hard starting.
A020105AUN
Do not use methanol
Fuels containing methanol (wood alco-
hol) should not be used in your vehicle.
This type of fuel can reduce vehicle per-
formance and damage components of
the fuel system.
A020106AEN
Gasolines for cleaner air
To help contribute to cleaner air,
HYUNDAI recommends that you use
gasolines treated with detergent addi-
tives, which help prevent deposit forma-
tion in the engine. These gasolines will
help the engine run cleaner and enhance
performance of the Emission Control
System.
A020107AUN
Operation in foreign countries
If you are going to drive your vehicle in
another country, be sure to:
• Observe all regulations regarding reg-
istration and insurance.
• Determine that acceptable fuel is avail-
able.
CAUTION
Your New Vehicle Limited Warranty
may not cover damage to the fuel
system and any performance prob-
lems that are caused by the use of
fuels containing methanol or fuels
containing MTBE (Methyl Tertiary
Butyl Ether) over 15.0% vol.
(Oxygen Content 2.7% weight.)
CAUTION
Never use gasohol which contains
methanol. Discontinue use of any
gasohol product which impairs dri-
vability.
CAUTION
Your New Vehicle Limited Warranty
does not cover damage to the fuel
system or any performance prob-
lems caused by the use of “E85” fuel.
BH hma 1.qxd 4/14/2008 5:41 PM Page 4

15
Introduction
A030000AUN
No special break-in period is needed. By
following a few simple precautions for the
first 600 miles (1,000 km) you may add to
the performance, economy and life of
your vehicle.
• Do not race the engine.
• While driving, keep your engine speed
(rpm, or revolutions per minute)
between 2,000 rpm and 4,000 rpm.
• Do not maintain a single speed for long
periods of time, either fast or slow.
Varying engine speed is needed to
properly break-in the engine.
• Avoid hard stops, except in emergen-
cies, to allow the brakes to seat prop-
erly.
• Don't let the engine idle longer than 3
minutes at one time.
• Don't tow a trailer during the first 1,200
miles (2,000 km) of operation.
VEHICLE BREAK-IN PROCESS
BH hma 1.qxd 4/14/2008 5:41 PM Page 5

Introduction
61
A040000AEN
Your Hyundai vehicle is equipped with
many high technology, electronically
controlled systems that help to
ensure your vehicle operates properly
and provides the performance that
you expect. These systems utilize
computers to monitor the operation of
various systems and components and
help to control their operation. These
computerized system operations are
wide-ranging and involve components
to reduce emissions, to continuously
evaluate the readiness of the air bag
and seat belt pre-tensioner systems,
to determine when the air bag and
seat belt pre-tensioner systems
should be deployed and then to acti-
vate the deployment, and if equipped,
to operate anti-lock braking, traction
control and electronic stability control
to assist the driver to control the vehi-
cle in difficult driving situations.
These systems electronically store
information that is useful to service
technicians when they need to diag-
nose and repair these systems.
Additional information is stored only
when a crash occurs that results in
the deployment of the air bags or seat
belt pre-tensioners. This type of data
storage is done by devices called
event data recorders (EDR).
After a crash event, the air bag and
seat belt pre-tensioner computer sys-
tem, known as the Supplemental
Restraint System Control Module
(SRSCM) or Air bag Control Unit
(ACU), may record some information
about the condition of the vehicle and
how it was being operated. This infor-
mation consists of data related to seat
belt usage and if there was diagnostic
information in the air bag or seat belt
systems at the time that a crash
occurred, and if the ACU sensed that a
crash of sufficient severity occurred
to require seat belt pre-tensioner or
air bag deployment.
To retrieve this information, special
equipment is needed and access to
the vehicle or the device that stores
the data is required. Hyundai will not
access information about a crash
event or share it with others except:
• in response to an official request of
police or similar government office,
or
• with the consent of the vehicle
owner or, if the vehicle is leased,
with the consent of the lessee, or
• as part of Hyundai’s defense of liti-
gation, or
• as required by law.
VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS
BH hma 1.qxd 4/14/2008 5:41 PM Page 6

17
Introduction
INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER
Seat belt warning light
High beam indicator
Turn signal indicator
ABS warning light
Parking brake & Brake fluid
warning light
Engine oil pressure warning light
ESC indicator
ESC OFF indicator
Malfunction indicator light
Air bag warning light
Cruise indicator (if equipped)
Cruise SET indicator
(if equipped)
Immobilizer indicator
Low fuel level warning light
* For more detailed explanations, refer to “Instrument cluster” in section 4.
Charging system warning light
Low windshield washer fluid
level warning light (if equipped)
A050000ABH-EU
Door ajar warning light
AFLS malfunction indicator
(if equipped)
Tail light indicator
Trunk ajar warning light
Front fog light indicator
(if equipped)
ESC
ESC
OFF
AFLS
OFF
TPMS (Tire Pressure Monitoring
System) malfunction indicator
Low tire pressure telltale
Low tire pressure position indi-
cator (if equipped)
BH hma 1.qxd 4/14/2008 5:41 PM Page 7

2
Interior overview / 2-2
Instrument panel overview / 2-3
Engine compartment / 2-4
Your vehicle at a glance

Your vehicle at a glance
22
INTERIOR OVERVIEW
B010000ABH-EU
OBH018001N
1. Door lock/unlock button ....................4-16
2. Power window switches ....................4-23
3. Outside rearview mirror control
switch ................................................4-46
4. Trunk lid release switch.....................4-20
5. Fuel filler lid release button...............4-28
6. Hood release lever............................4-27
7. Parking brake....................................5-19
8. Brake pedal.......................................5-18
9. Accelerator pedal .......................5-6, 5-9
10. Parking assist button* .....................4-68
11. Adaptive front lighting system
OFF button* ....................................4-76
12. ESC OFF button .............................5-23
13. Instrument panel illumination control
knob ................................................4-49
14. Light control/Turn signals................4-72
15. Steering wheel manual tilt or Power tilt
control*............................................4-38
16. Steering wheel ................................4-37
* : if equipped

23
Your vehicle at a glance
INSTRUMENT PANEL OVERVIEW
OBH018002N
B020000ABH-EU
1. Instrument cluster.............................4-47
2. Horn .................................................4-38
3. Driver’s front air bag.........................3-44
4. Wiper/Washer...................................4-77
5. Ignition switch or Engine start/stop
button*.........................................5-4, 5-7
6. Climate control system.....................4-84
7. Digital clock ....................................4-104
8. Hazard warning flasher switch..4-71, 6-2
9. Shift lever .........................................5-11
10. Central control panel*...................4-107
11. Seat warmer or Climate control seat*
..................................................3-7, 3-9
12. Passenger’s front air bag ...............3-44
* : if equipped

Your vehicle at a glance
42
ENGINE COMPARTMENT
OBH018003L
B030000ABH
* The actual engine room in the vehicle may differ from the illustration.
1. Engine coolant reservoir...................7-17
2. Radiator cap .....................................7-18
3. Brake fluid reservoir..........................7-19
4. Air cleaner.........................................7-22
5. Engine oil dipstick .............................7-15
6. Engine oil filler cap ...........................7-15
7. Windshield washer fluid reservoir.....7-21
8. Fuse box ...........................................7-44
9. Power steering fluid reservoir
(with EHPS) ......................................7-20
10. Power steering fluid reservoir
(without EHPS) ...............................7-20
11. Jumper terminal ................................6-4
■■3.8 Engine
