Thank you for purchasing this multimedia
system.
This user's manual explains how to use
the Hyundai Motor multimedia system.
Before using the product, read the con-
tents of this user's manual carefully and
use this product safely.
•
The screens shown in this manual may
differ with the actual screens of the
product.
•
The design and specification of this
product may change without prior noti-
fication for product improvement.
•
When transferring the vehicle to
another individual, include this user's
manual so that the next driver can con-
tinue its use.
Precaution for safe usage
•
Driving while distracted can result in a
loss of vehicle control, that may lead to
an accident, severe personal injury, and
death. The driver’s primary responsibil-
ity is in the safe and legal operation of a
vehicle, and use of any handheld devices,
other equipment, or vehicle systems which
take the driver’s eyes, attention and focus
away from the safe operation of a vehicle
or which are not permissible by law should
never be used during operation of the
vehicle.
•
Do not operate the multimedia system
while driving.
•
Do not disassemble, assemble, or modify
the multimedia system.
•
Do not watch the screen for prolonged
periods of time while driving.
•
Set the volume to a level which allows the
driver to be aware of external conditions.
•
Do not operate the multimedia system for
prolonged periods of time with the vehicle
ignition in ACC. Such operations may lead
to battery discharge.
•
Be cautious not to spill water or introduce
foreign objects into the device.
•
Do not cause severe shock to the device.
Direct pressure onto the front side of the
monitor may cause damage to the LCD or
touch panel.
•
In case of product malfunction, please
contact your place of purchase or service
center.
•
When cleaning the touch screen, make
sure to turn off the device and use a dry
and smooth cloth. Never use tough materi-
als, chemical cloths, or solvents (alcohol,
ammonia, benzene, thinners, etc.) as such
materials may damage the device panel or
cause color and quality deterioration.
All Map Database cannot be copied without permission.
Important Notice: This is protected by U.S. copyright laws. All rights not expressly granted are reserved.
You may not otherwise reproduce, modify, and distribute the content without Hyundai MnSoft, Inc's prior written consent.
H_LMFC_G3.0[USA_N]AVN COVER.indd 4-5H_LMFC_G3.0[USA_N]AVN COVER.indd 4-5 2015-07-22 오후 2:09:222015-07-22 오후 2:09:2

Read the following safety cautions for
your safety.
Before using the product, read the contents of this user's
manual carefully and use this product safely.
※ The design and specifications of this product may change with-
out prior notification for product and service improvement.
The actual features in the vehicle may differ from the illustrations.
For more accurate information about the vehicle, please refer to
the catalogue.
Notations used within this User's
Manual
Safety Warnings
•
Failure to observe the instructions within this category could result
in damage to the vehicle.
Safety Cautions
• Failure to observe the safety instructions within this category could
result in accident related injuries or damage to the vehicle.
i
Information
•
Information and tips that provide additional user convenience in
using the product
NOTICE
•
Information on specific features that facilitate proper product use and
functional understanding
•
Information on terminology used within this manual
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-1H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-1 2015-07-22 오후 2:11:122015-07-22 오후 2:11:1

2
1 Basic
Warnings and Cautions
Warning
...........................................................
1-2
Caution
............................................................
1-3
Key Product Features
Key Product Features
................................
1-4
Component Names and Functions
Head Unit
........................................................
1-6
Steering Wheel Remote Controller
.......
1-8
Starting the System for the First Time
Turning the System On/Off
....................
1-10
Turning the System On
...........................
1-10
Turning the System Off
...........................
1-10
Resetting the System
...............................
1-11
Battery Warning Message
......................
1-11
2 Audio
FM/AM Mode
Basic Mode Screen
...................................
2-2
Basic Mode Screen (HD RadioTM
reception ON)
...............................................
2-3
Starting Mode
.............................................
2-4
Using SEEK
................................................
2-4
Using TUNE
.................................................
2-4
Selecting Presets
........................................
2-4
Saving Radio Frequency
.........................
2-5
Saving Manually
..........................................
2-5
Saving Automatically
..................................
2-5
Scanning Radio Frequency
....................
2-5
Using the Menu Buttons
...........................
2-6
Preset Scan
.................................................
2-6
Text On/Text Off
..........................................
2-6
HD RadioTM Mode
About HD RadioTM Technology
...............
2-7
Starting Mode
...............................................
2-8
Operating HD RadioTM Mode
..................
2-8
Selecting a Frequency
...............................
2-8
Using TUNE
.................................................
2-8
Selecting through Preset
...........................
2-9
Song-Tagging
..............................................
2-9
HD RadioTM Digital Broadcast On/Off
..
2-9
XM Mode
Basic Mode Screen
...................................
2-10
Starting Mode
..............................................
2-11
Using SEEK
..............................................
2-11
Using TUNE
..............................................
2-11
Selecting Presets
.....................................
2-11
Selecting through Channel/Category
List
..............................................................
2-12
Saving XM Channels
................................
2-12
Saving Manually
.......................................
2-12
Using the Menu Buttons
..........................
2-12
Search
.......................................................
2-13
Preset Scan
..............................................
2-13
Scan
...........................................................
2-13
Disc
About Disc
...................................................
2-14
Precautions upon Handling Discs
.........
2-14
Table of Contents
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-2H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-2 2015-07-22 오후 2:11:162015-07-22 오후 2:11:1

Table of Contents l 3
Supported Disc Formats
.........................
2-15
Disc/Content Format Compatibility
.......
2-15
Before Playing an MP3 Disc
..................
2-17
CD Mode
Basic Mode Screen
...................................
2-19
Starting Mode
.............................................
2-20
Playing a CD
.............................................
2-20
Fast-forwarding or Rewinding CDTracks
..
2-20
Searching CD Tracks
..............................
2-21
Using the Menu Buttons
.........................
2-21
Repeat
.......................................................
2-21
Shuffle
........................................................
2-21
Scan
...........................................................
2-22
Info On/Info Off
.........................................
2-22
MP3 CD Mode
Basic Mode Screen
...............................
2-23
List Menu Screen
....................................
2-25
Starting Mode
...........................................
2-26
Playing MP3
..............................................
2-26
Selecting MP3 files
..................................
2-27
Using the Menu Buttons
.........................
2-28
Copy
...........................................................
2-28
Repeat
.......................................................
2-28
Shuffle
........................................................
2-28
Scan
...........................................................
2-28
Info On/Info Off
.........................................
2-29
Using Menus within the List Screen
..
2-29
Moving between Lists
............................
2-29
Moving between Folders
........................
2-30
Returning to Current Location
..............
2-30
USB Mode
About USB
..................................................
2-31
Before Playing a USB MP3
....................
2-31
USB MP3 Information and Precautions
.
2-33
Basic Mode Screen
................................
2-34
USB Music Mode
.....................................
2-34
USB Image Mode
....................................
2-36
Menu List Screen
......................................
2-37
Starting USB Music Mode
....................
2-38
Playing USB Music
..................................
2-38
Searching USB Music Files
...................
2-39
Using the Menu Buttons
.........................
2-39
Copy
...........................................................
2-39
Repeat
.......................................................
2-40
Shuffle
........................................................
2-40
Scan
...........................................................
2-40
Info On/Info Off
.........................................
2-41
Starting USB Image Mode
....................
2-41
Searching USB Image Files
...................
2-41
Using the Menu Buttons
.........................
2-42
Slideshow Interval
....................................
2-42
Rotating Image
.........................................
2-42
Adjusting Image Size
.............................
2-43
Saving Image
............................................
2-43
Viewing Info
..............................................
2-43
iPod Mode
Using iPod Devices
..................................
2-44
Steps upon Initial Connection
................
2-45
Supported iPod Devices
.........................
2-45
Basic Mode Screen
..................................
2-46
Starting Mode
.............................................
2-47
Playing iPod
..............................................
2-47
Searching iPod
........................................
2-47
Selecting iPod Files
.................................
2-48
Searching iPod Files
...............................
2-49
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-3H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-3 2015-07-22 오후 2:11:172015-07-22 오후 2:11:1

4
Using the Menu Buttons
.........................
2-49
Repeat
.......................................................
2-49
Shuffle
........................................................
2-49
Info On/Info Off
.........................................
2-49
AUX Mode
Starting Mode
.............................................
2-50
Connecting an External Device
...........
2-50
Bluetooth® Audio Mode
Basic Mode Screen
..................................
2-51
Using Bluetooth®Audio Mode
...............
2-52
Starting Mode
.............................................
2-52
Playing Bluetooth®Audio
........................
2-52
Selecting Bluetooth®Audio Files
...........
2-53
Setting Connection
..................................
2-53
My Music Mode
Basic Mode Screen
..................................
2-54
Starting Mode
.............................................
2-55
Playing My Music
.....................................
2-55
Selecting My Music
..................................
2-55
Using the Menu Buttons
.........................
2-56
Repeat
.......................................................
2-56
Shuffle
........................................................
2-56
Scan
...........................................................
2-56
Info On/Info Off
.........................................
2-57
Using Menus within the List Screen
..
2-57
Moving between Lists
..............................
2-57
Returning to Current Location
................
2-58
Deleting Files
............................................
2-58
3 Navigation
Before Use
Precautions for Safe Driving
..................
3-2
Operating the Navigation
.........................
3-3
About the Map
.............................................
3-4
About Map Scale
.........................................
3-4
About Map Icons
.........................................
3-4
About Map Database
.................................
3-4
About Map Updates
....................................
3-4
About Voice Guidance
..............................
3-5
Voice Guidance
...........................................
3-5
About GPS
....................................................
3-6
Starting Navigation
Map Screen
...................................................
3-7
Initial Screen
.................................................
3-8
Current Position
..........................................
3-8
Map Display Settings
.................................
3-9
Changing Map Scale
..................................
3-9
Map Menu
.................................................
3-10
Adjusting Navigation Volume
.................
3-10
POI Display
...............................................
3-10
Editing POI Icons
.....................................
3-11
Searching POIs
........................................
3-11
Adding a My Place
...................................
3-12
Using the Navigation
Destination Search
..................................
3-13
Address
.....................................................
3-14
Previous Destinations
.............................
3-14
POI (Point of Interest) Search
................
3-15
POI Name Search
...................................
3-15
Gas Station
...............................................
3-16
Restaurants
..............................................
3-16
Emergency
................................................
3-17
My Places
..................................................
3-17
Table of Contents
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-4H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-4 2015-07-22 오후 2:11:172015-07-22 오후 2:11:1

Table of Contents l 5
Phone Number
.........................................
3-18
Intersection Search
..................................
3-18
Exit/Entrance
............................................
3-19
Coordinates
..............................................
3-19
Setting a Destination
...............................
3-19
Route Calculation
....................................
3-21
Demo
........................................................
3-21
Add Waypoint
...........................................
3-22
Route Recalculation
................................
3-22
Cancel Route
............................................
3-22
Route Guidance
........................................
3-23
Preliminary Guidance Mode
...................
3-23
Intersection Zoom Mode
.........................
3-24
Highway Mode
.........................................
3-24
Turn List Mode
.........................................
3-24
Route Menu
...............................................
3-25
Cancel Route
............................................
3-26
Route Overview
........................................
3-26
Route Info
..................................................
3-27
Route Option
............................................
3-27
Detour
........................................................
3-28
Avoid Streets
............................................
3-28
Edit Route
.................................................
3-28
Avoid Area
.................................................
3-29
Map Logos and Landmarks
Logo/Landmarks
.......................................
3-30
Logo
...........................................................
3-30
2D Landmarks
..........................................
3-32
4 Bluetooth® Handsfree
Before Use
Before Using the Bluetooth®Handsfree...4-2
What is Bluetooth® Wireless Technology?
..
4-2
Basic Mode Screen
When no Phones Have Been Paired
..
4-4
Pairing from the Bluetooth®Device
..........
4-5
When a Phone is Already Paired
..........
4-6
When Pairing Additional Device
...............
4-7
Using Bluetooth
®
Wireless Technology
When There is a Connected Device
.......
4-8
Status Bar Icons
..........................................
4-8
During a Call
.................................................
4-9
Status Bar Icons
..........................................
4-9
Making/Answering Calls
..........................
4-10
Calling by Dialing a Number
..................
4-10
Making a Call from Speed Dial
..............
4-10
Calling through Redial
.............................
4-11
Making a Call from Call History
.............
4-11
Answering a Call
......................................
4-12
Rejecting a Call
........................................
4-12
Operating Menus during a Call
.............
4-13
Switching Call to Bluetooth®Phone
......
4-13
Switching Call to Handsfree
...................
4-13
Ending a Call
............................................
4-14
Switching to Call Waiting
........................
4-14
Setting Mic Volume
..................................
4-15
Adjusting the Ring/Call Volume
.............
4-15
Contacts
........................................................
4-16
Mobile Contacts Screen Configuration 4-17
Downloading Mobile Phone Contacts
..
4-18
Checking Mobile Contacts Details
........
4-19
Adding as a Favorite
...............................
4-19
Favorites
......................................................
4-20
Calling Favorites
......................................
4-20
Selecting/Deleting Favorites
..................
4-20
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-5H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-5 2015-07-22 오후 2:11:172015-07-22 오후 2:11:1

6
Searching Contacts
.................................
4-21
Call History
..................................................
4-22
Entering Call History Screen
..................
4-22
Call History Screen Configuration
.........
4-22
Downloading Call History
.......................
4-23
Viewing Call History Information
...........
4-24
Setting Bluetooth®Connection
.............
4-24
Connections Menu
...................................
4-25
Connecting a Device
...............................
4-25
Pairing a New Device
..............................
4-26
Disconnecting a Device
..........................
4-27
Deleting a Device
.....................................
4-27
Setting Auto Connection
.........................
4-28
5 Voice Recognition
Using Voice Recognition
Using Voice Recognition
..........................
5-2
Creating a suitable cabin environment
...
5-2
Starting Voice Recognition
......................
5-3
Starting Voice Recognition
.......................
5-3
Skipping Prompt Messages
......................
5-3
Re-starting Voice Recognition
..................
5-4
Ending Voice Recognition
.......................
5-4
Using Voice Recognition
..........................
5-5
Adjusting Voice Recognition Volume
..
5-5
Illustration on Using Voice Recognition
(Setting Home as the Destination)
.......
5-6
Voice Command Lists
Voice Command List
.................................
5-7
Help Command List
....................................
5-7
Audio System Command List
................
5-8
FM/AM Radio
...............................................
5-8
XM Radio
.....................................................
5-9
CD(Audio Type)
..........................................
5-9
CD(MP3 Type)
.........................................
5-10
USB Music
................................................
5-10
iPod
............................................................
5-11
My Music
...................................................
5-11
Others
........................................................
5-11
Phone Command List
..............................
5-12
Navigation Command List
......................
5-12
Destination
.................................................
5-12
Map
.............................................................
5-13
POI Category List
......................................
5-14
Table of Contents
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-6H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-6 2015-07-22 오후 2:11:172015-07-22 오후 2:11:1

Table of Contents l 7
6 Information
XM Data
About XM Data
............................................
6-2
About XM Data Service
.............................
6-2
Weather Data Service
................................
6-3
Traffic Data Service
....................................
6-4
Stocks Data Service
...................................
6-5
Sports Data Service
...................................
6-6
GPS Information
About GPS (Global Positioning System)
..
6-7
When GPS Info Cannot Be Used
............
6-7
Errors Unavoidable Due to System
Characteristics
.............................................
6-7
Viewing GPS Info
.......................................
6-8
Help
Viewing Help
................................................
6-9
7 Other Features
Rear camera display
About Rear Detection Camera
...............
7-2
Operating sequence of the Rear Camera
..
7-2
8 Setup
Using Setup
Basic Mode Screen
....................................
8-2
Starting Mode
...............................................
8-3
Sound
.............................................................
8-3
Setting Balance/Fade
.................................
8-3
Setting Bass/Mid/Treble
.............................
8-3
Setting Volume Ratio
.................................
8-4
Advanced
.....................................................
8-4
Setting Beep
................................................
8-5
Display
............................................................
8-5
Adjusting Brightness
...................................
8-5
Setting Display Mode
.................................
8-5
HD RadioTM Reception
..............................
8-6
Phone
.............................................................
8-6
Connections
................................................
8-7
Change Passkey
.........................................
8-7
Vehicle Information
.....................................
8-8
Restore Factory Settings
...........................
8-8
Navigation
.....................................................
8-9
Main
..............................................................
8-9
Display
.......................................................
8-10
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-7H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-7 2015-07-22 오후 2:11:172015-07-22 오후 2:11:1

8
Route Search
............................................
8-11
Guidance
...................................................
8-11
Default
.......................................................
8-12
My Places
.....................................................
8-13
My Places
..................................................
8-13
Favorite Places
.........................................
8-13
Home and Office
......................................
8-14
Speed Alerts
.............................................
8-14
Traffic Setup
................................................
8-15
Voice Recognition Settings
....................
8-16
Clock Settings
.............................................
8-16
Time
...........................................................
8-16
View
...........................................................
8-17
Picture Frame
............................................
8-17
Keyboard
.....................................................
8-18
Language
....................................................
8-18
System Update
...........................................
8-19
Display Off
...................................................
8-20
9 Appendix
Appendix
Product Specification
................................
9-2
Before Thinking There is a Product Defect ...9-4
Before Thinking the Product Has
Malfunctioned
...............................................
9-5
Troubleshooting
..........................................
9-6
FAQ
.................................................................
9-8
About Pairing Mobile Phones
...................
9-8
About Making/Answering Phone Calls
....
9-9
About
Bluetooth® Wireless Technology/Head
Unit Use Environment
................................
9-9
Table of Contents
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-8H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-8 2015-07-22 오후 2:11:172015-07-22 오후 2:11:1

CAUTIONS upon Using SD Cards
Ejecting and Inserting SD Cards
• Ejecting and inserting SD cards while the multimedia system is operating may result
in SD Card or System errors. To eject or insert the SD card, first turn off the multime-
dia system and the vehicle ignition.
• Eject/insert SD cards only to update the multimedia system with a new version.
※When an SD Card with the new version is inserted, then system update will
occur automatically
Usage of SD Cards
• The SD Card is formatted to include only Map and new system update files.
• The SD Card cannot be used to save and play Music.
• Do not add, delete, or format files within the SD Card.
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-9H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-9 2015-07-22 오후 2:11:172015-07-22 오후 2:11:1

iPod®
iPod®is a registered trademark of Apple Inc.
Bluetooth®Wireless Technology
The Bluetooth®Wireless Technology word mark and logos are reg-
istered trademarks owned by Bluetooth®Wireless Technology SIG,
Inc. and any use of such marks by Hyundai is under license.
A Bluetooth®Wireless Technology enabled cell phone is required
to use Bluetooth®Wireless Technology. Bluetooth®Wireless
Technology phone compatibility can be checked by visiting www.
hyundaiusa.com.
HD Radio™ Technology
HD RadioTM Technology manufactured under license from iBiquity
Digital Corporation. U.S. and Foreign Patents.
HD Radio™ and the HD, HD Radio, and "Arc" logos are proprietary
trademarks of iBiquity Digital Corp.
H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-10H_LMFC_G3.0[USA_N]AVN Part 0.indd 1-10 2015-07-22 오후 2:11:172015-07-22 오후 2:11:1

CAR MULTIMEDIA SYSTEM
•
Warnings and Cautions
•
Key Product Features
•
Component Names and Functions
•
Starting the System for the First Time
Basic
1
H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-1H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-1 2015-07-22 오후 2:16:012015-07-22 오후 2:16:0

1-2
Warnings and Cautions
WARNING
•
Even when receiving route guidance
from the multimedia system, please
abide by actual traffic, road regulations,
and any road signs. Following only the
Navigation route guidance may lead to
violations of actual traffic and road regu-
lations and lead to traffic accidents.
•
Do not stare at the screen while driv-
ing. Staring at the screen for prolonged
periods of time could lead to traffic
accidents, and result in severe personal
injury or damage to the vehicle.
•
Do not operate the multimedia system
while driving, such as entering POIs or
conducting route searches. Such acts
could lead to accidents, fire, or electric
shock. Park the vehicle before operating
the device.
•
Do not disassemble, assemble, or
modify the multimedia system. Such acts
could result in accidents, fire, or electric
shock.
•
Use caution not to spill water or intro-
duce foreign objects into the device.
Such acts could lead to smoke, fire, or
product malfunction.
•
Please refrain from use if the screen is
blank or no sound can be heard as these
signs may indicate product malfunction.
Continued use in such conditions could
lead to accidents (fires, electric shock)
or product malfunctions.
•
Do not touch the antenna during thunder
or lightening as such acts may lead to
lightning induced electric shock.
•
Do not stop or park in parking-restricted
areas to operate the product. Such acts
could lead to traffic accidents.
•
For most Audio and multimedia modes,
the display will not operate when the
vehicle is in motion. For your safety, first
park the vehicle to watch or view the
screen. (The screen will operate when
the parking brake is set to ON for man-
ual transmission vehicles and when set
to P or Parking Brake On state for auto
transmission vehicles.)
H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-2H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-2 2015-07-22 오후 2:16:062015-07-22 오후 2:16:0

Warnings and Cautions
Basic l 1-3
CAUTION
Pay attention to traffic conditions while driv-
ing.
• In some instances, the navigation may pro-
vide guidance through restricted areas.
• Operating the device while driving could lead
to accidents due to a lack of attention to exter-
nal surroundings. First park the vehicle before
operating the device. In addition, the touch
screen may not work for some functions when
the vehicle is in motion. The touch screen
feature will be supported once the vehicle has
stopped.
• Adjust the volume to levels that allow the
driver to hear sounds from outside of the vehi-
cle. Driving in a state where external sounds
cannot be heard may lead to accidents.
• Pay attention to the volume setting when turn-
ing the device on. A sudden output of extreme
volume upon turning the device on could lead
to hearing impairment. (Adjust the volume to
a suitable levels before turning off the device.)
• If you want to change the position of
device installation, please inquire with
your place of purchase or service mainte-
nance center.
• Technical expertise is required to install or
disassemble the device.
• Turn on the car ignition before using this
device. Do not operate the multimedia
system for long periods of time with the
ignition turned off as such operations may
lead to battery discharge.
• Upon using the multimedia system for
more than 10 minutes with the car engine
turned off, a warning will be displayed.
After 10 minutes, the warning will be dis-
played for 3 seconds every 1 minute.
• Do not subject the device to severe shock
or impact. Direct pressure onto the front
side of the monitor may cause damage to
the LCD or touch screen.
• When cleaning the device, make sure
to turn off the device and use a dry and
smooth cloth.
• Never use tough materials, chemical
cloths, or solvents(alcohol, benzene, thin-
ners, etc.) as such materials may damage
the device panel or cause color/quality
deterioration.
• When experiencing product malfunctions,
inquire with your place of purchase or ser-
vice maintenance center.
• Prevent caustic solutions such as per-
fume and cosmetic oil from contacting the
dashboard because they may cause dam-
age or discoloration.
H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-3H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-3 2015-07-22 오후 2:16:082015-07-22 오후 2:16:0

1-4
This device is an multimedia system equipped with a multifunctional disc player that supports Radio (FM1, FM2, AM), HD Radio technology,
Audio CD, MP3, USB, iPod, and Audio, Aux, and My Music features. The WIDE VGA LCD provides a high quality resolution while the powerful
and rich sound system adds to the driving enjoyment.
Display
TFT
• Provides high quality sound and video through a Wide TFT-LCD Display using an LED Back Light
• Touch screen for maximum user convenience
Radio
Digital Tuner Feature
• Digital Tuner using PPL method that supports memory of 6 broadcast stations for each AM, FM1, and FM2 modes
Integrated Antenna (RADIO+NAVI)
• Outstanding reception via integrated antenna with high sensitivity
Radio broadcast station name
• Displays broadcast station names when available
HD Radio/Satellite Radio feature
• Supports HD Radio reception and Satellite Radio (XM)
Multimedia
Player
Support for various Media Formats
• Support for various media formats, including Radio, audio MP3 CD, USB, iPod and AUX
• Supports USB, iPod, and Bluetooth®Audio Streaming modes
My Music
• Supports copying of music stored within DISC MP3 or USB into My Music (internal memory) mode
USB Image
• Copy to view and save images saved in USB devices
Key Product Features
H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-4H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-4 2015-07-22 오후 2:16:092015-07-22 오후 2:16:0

Key Product Features
Basic l 1-5
Navigation
Voice Guidance
• Voice route guidance to conveniently reach set destinations
• Various map scales that enables drivers to accurately view map and surrounding areas
Automatic Correction for Current Location
• Automatically corrects current position using map matching and GPS information
Miscellaneous
Bluetooth® Wireless Technology
• Convenient use of Bluetooth®Handsfree by using buttons within the steering wheel
Digital Screen Control Features
• Easy control of features through touch screen options
Steering wheel
• Control over audio features, voice recognition and Bluetooth®through the steering wheel for increased convenience
H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-5H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-5 2015-07-22 오후 2:16:092015-07-22 오후 2:16:0

1-6
Head Unit
1
4
2
3
6
5
Component Names and Functions
Name Description
1
FM/AM
• Selects FM/AM mode
• Each time the key is pressed, the mode is changed in order
of FM1 →FM2 →AM →FM1
2
SAT
Converts to XM mode
• Each time the key is pressed, the mode is changed in order
of XM1 →XM2 →XM3 →XM1
3
MEDIA
• Displays CD, MP3, USB, iPod, AUX, Bluetooth®Audio
Streaming, My Music modes
• If the media is not connected or a disc is not inserted, corre-
sponding modes will be disabled
4
∧
SEEK
TRACK
∨
When key is pressed shortly. (under 0.8 seconds)
• In FM/AM mode, scans and receives the previous/next
frequency
• In XM mode, plays the previous/next channel
• In CD/MP3/USB/iPod/My Music modes, changes the track,
file or chapter
When key is pressed and held. (over 0.8 seconds)
• In FM/AM mode, changes frequencies while pressed. Upon
release, scans and receives the next frequency
• In XM mode, continuously changes the channel until the key
is released and plays the current channel
• In CD/MP3/USB/iPod/My Music modes, rewinds or fast-
forwards the track or file
5
INFO
SETUP Displays the INFO/SETUP mode screen
6
PHONE Takes user to phone screen
H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-6H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-6 2015-07-22 오후 2:16:092015-07-22 오후 2:16:0

Component Names and Functions
Basic l 1-7
9
11
13
15
12
10
7
8
Name Description
7
Press to insert or eject disc
8
PWR
VOL
• When power is off, press to turn power on
• When power is on, press and hold (over 1.2 seconds) to turn
power off
• When power is on, press shortly (under 1.2 seconds) to turn
Audio off
• Turn left/right to control volume
9
CLOCK
Displays current time and date
10
TUNE
• In FM/AM mode, changes the frequency
• In XM mode, changes the channel
• In CD, MP3, USB, iPod, My Music modes, changes the track,
file or chapter
11
MAP
VOICE Displays the map for the current position
12
DEST Displays the Destination setup menu
13
ROUTE Displays Route menu screen
14
RESET Resetting the system
15
SD Card insert slot
14
H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-7H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-7 2015-07-22 오후 2:16:092015-07-22 오후 2:16:0

1-8
Component Names and Functions
Steering wheel
Name Description
1
VOL+
VOL-
Controls the volume
2
Λ V
When keys are pressed shortly. (under 0.8 seconds)
• In FM/AM mode, scans and receives the previous/next
frequency
• In XM modes, searches broadcast channels saved to
Presets
• In CD/MP/USB/iPod/My Music modes, changes the track,
file or chapter
When keys are pressed and held. (over 0.8 seconds)
• In FM/AM mode, changes frequencies while pressed.
Upon release, scans and receives the next frequency
• In XM modes, automatically searches broadcast channels
• In CD/MP3/USB/iPod/My Music modes, rewinds or fast
forwards the track or file
3
MODE
• Each time this key is pressed, the mode is changed in
order of FM1 →FM2 →AM →XM1 →XM2 →XM3 →
USB or iPod →AUX →Bluetooth®Audio →My Music
• If the media is not connected or a disc is not inserted,
corresponding modes will be disabled
• Press and hold the key (over 0.8 seconds) to turn the
Audio system on/off
• When power is off, press the key to turn power back on
4
MUTE Mutes the sound
1
2
3
4
※The actual feature in the vehicle may differ from the illustration.
H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-8H_LMFC_G3.0[USA_N]AVN Part 1.indd 1-8 2015-07-22 오후 2:16:102015-07-22 오후 2:16:1
