REMOTE START OWNER’S GUIDE
WARNING
It is the responsibility of the vehicle operator to ensure that their vehicle is parked in a safe and responsible manner.
1. When leaving the vehicle, it is the user’s responsibility to ensure that the gearshift lever is in “Park” in order to avoid accidents
upon remote starting. (Note: Make sure that the vehicle cannot start in “Drive”.)
2. It is the user’s responsibility to ensure that the remote starter is disabled or put into valet mode before servicing.
FCC COMPLIANCE
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate this device.
CAUTION:
REMOTE START OWNER’S GUIDE
INTRODUCTION
TABLE OFCONTENTS:
Congratulations on your purchase of a Remote Start system. This easy-to-use manual details the operation
instructions and benefits of the Remote Start System. Should you have questions regarding this system that this
manual does not address, please contact your local dealer.
Using the Remote Start
Description of Remote Start Fob
Button Functions
Remote-Starting your Vehicle
Remote-Starting
Driving Off
Vehicle Presets
Heater
Windshield Wipers and Headlights
Remote Start Features
Remote Start Error Diagnostic
Valet/Service Mode
Pairing Remote Start Fob
Battery Replacement
for Remote Start Fob
Troubleshooting Poor Transmitter Range
Remote Start Run Time
10
9
8
7
5
4
4
3

4
3
Using The Remote Control
Description of Remote Start Fob
Button Functions
Note:Make sure to press button only after LED lighting ends to activate each feature properly.
kcoLemit1sserP
roods’revirdkcolnUsemit2sserP
Press 2 times x 2Unlock all doors
pots/tratsetomeRsdnoces2dloH
Lock/Unlock
Note: Press the button 1 time on the
transmitter to lock the vehicle.
Press the button 2 times to unlock the
driver’s door, and 2 additional times to
unlock all doors.
START/STOP:
Note : Remote Engine Start -
Press the button 1 time and then,
within 3 seconds, press and hold
the button for 2 seconds.
Remote Engine Stop - Press
and hold the button for 2 seconds.
Lock, Unlock and Remote
Starting icon is displayed with
one LED color.
Button ImageButtonLED/icon Feature
4
Driving Off
With the vehicle running remotely, press the button 2 times to unlock the driver’s door, enter the vehicle and performthe
following to drive off:
1) Insert the vehicle’s key tothe IGNITION, turn tothe ON position and press the brake pedal.
The vehicle is now ready to drive.
Note:The Factory Key Fob will NOTfunction during Remote Start operation.
The engine will shut off if either of the following occurs;
1) The drive off procedure is not initiated within 30 seconds of opening any door, within 50 seconds of opening tailgate / trunk.
2) The brake is pressed without the vehicle key in the ignition in the ON position.
If the vehicle turnns off, simply start the vehicle using the normal starting procedure as detailed in the vehicle’s owner’s manual.
Remote Starting your Vehicle
Remote Starting
Using Remote Start Fob
1. Press button 1 time, the lock icon will display. Within 3 seconds, press and hold the button for 2 seconds,
the key icon will flash and the vehicle will start.
2. Remote Stop - Press and hold button for 2 seconds. The key icon will flash and the engine will turn off.
Note:Make sure to press a button only after LED lighting ends to activate each feature properly.
Vehicle Presets
Heater
When leaving the vehicle, it is recommended to preset the climate controls in preparation for the next remote start. The climate
controls for the fan should not be left on HIGH. It is recommended to leave the setting on LOW or MEDIUM instead.
Windshield Wipers, Headlights
Certain vehicles require the windshield wipers and headlights circuits to become energized while running under remote start. When
leaving the vehicle you must ensure that the windshield wipers and headlights switches are OFF. Leaving the headlights switch ON
on certain types of vehicles could cause them to remain ON even after remote starter shutdown, resulting in a dead battery.
Leave Windshield Wipers off to avoid damaging the wipers/motor with remote start.

6
5
Remote Start Features
Remote StartError Diagnostic
If remote engine start fails, the vehicle will not start and the horn will sound the corresponding number of times to identify the
reason for the failed remote start listed below;
Number of horn chirpsRemote Start Error
1Hood open
2KEY IN or Ignition ON
3Valet mode
4Brake Applied
5Tailgate/Trunk open
6Door open
Valet/Service Mode
Valet/Service mode is used to prevent the system from unexpectedly starting the engine while being serviced.
When your vehicle is in Valet Mode, the remote starter functions are disabled. If the vehicle needs to be serviced, or if you park it
indoors, the Valet Mode will prevent the engine from being remote-started accidentally.
Remote Start Features
To Engage Valet Mode/Service Mode:
1) Insert the vehicle’s key to the IGNITION, turn to the ON position.
2) Press and hold the vehicle brake pedal.
3) Press and hold the remote button for 2 seconds, Vehicle’s exterior lights will flash and horn will sound once.
The valet mode is engaged.
To Exit Valet Mode/Service mode (Return the system to its normal operating mode):
1) Insert the vehicle’s key to the IGNITION, turn to the ON position.
2) Press and hold the vehicle brake.
3) Press and hold the remote button for 2 seconds, Vehicle’s exterior lights will flash and horn will sound twice.
The valet mode will be off .

8
7
Pairing Remote Start Fob
The Remote Start Fobs in the Remote Start Kit are paired with the main module at the time of production.
There is no need to pair the Fobs at the time of the first installation.
1. Pairing requirement cases
Key loss or replacement due to malfunction
Replacement of main controller in a vehicle
Purchase of spare Remote Start Fob
2. Pairing conditions
1) Open driver’s door and tailgate/trunk.
2) Insert the key into the ignition. Turn the key from OFF to ON position 5 times within 5 seconds.
3) Within 5 seconds, Press button on the 1st Remote Start Fob 1 time.
4) After registering the 1st Remote Start Fob, within another 5 seconds, Press button on the next Remote Start Fob 1 time.
5) Verify that all Fobs are functioning correctly by performing Lock / Unlock function.
NOTE:
1) System can recognize up to 3 remotes.
2) If a new Fob, or additional Fob, is needed later, the Fob pairing process should be done with the original Fob,
or oldest available Fob.
Pairing Remote Start Fob
5X REMOTE
START
FOB X1
Battery Replacement for Remote Start Fob
The two (2) 3-Volt Lithium battery (Model: CR2025) supplied in your remote control transmitter will last approximately 3 years,
depending on usage. When the batteries begin to weaken, the Remote Start Fob LEDs will no longer flash per operation and the
range of the remote transmission distance will be decreased. Replacement batteries are available at local electronics stores.
Follow the instructions below to change the remote control battery:
1. Use a coin or small screwdriver to pry the remote control halves apart.
2. Remove the old batteries and replace with 2 new CR2025 batteries.
3. Be sure to observe the (+) sign when inserting the new batteries.
4. Before assembling the transmitter case, you should test the remote control by performing a remote start operation.
Note: Recycle or dispose of the old batteries according to local laws or regulations.
