i-PRO WV-S65302-Z2 Installation guide

Basic Information
Network Camera
“<Control No.: C****>” used in these documents should be used to search for information on our
technical information website (https://i-pro.com/global/en/surveillance/training-support/support/
technical-information) and will guide you to the right information.
• microSDXC/ microSDHC/ microSD memory card is described as microSD
memory card.
• The external appearance and other parts shown in this manual may differ
from the actual product within the scope that will not interfere with normal
use due to improvement of the product.
About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (accessory): Provides information about “Precautions”, “Precautions for
installation” and the installation method.
• Basic Information (this document): Provides information about “Precautions for use”, “Parts and
functions” and “Detail specifications”.
• Operating Instructions (Refer to the link on the following product information website):
Explains how to perform the settings and how to operate this camera.
https://i-pro.com/global/en/surveillance/training-support/documentation-database-list
WV-S65302-Z2 / WV-U65302-Z2
Model No. WV-S65302-Z2, WV-S65301-Z1
WV-S65301-Z1S
(Heavy salt damage resistance)
WV-U65302-Z2, WV-U65301-Z1

2
Contents
Limitation of liability....................................................................................................................... 3
Disclaimer of warranty................................................................................................................... 3
About notations............................................................................................................................. 4
System requirements for a PC ...................................................................................................... 4
Network security ........................................................................................................................... 5
Precautions for use ....................................................................................................................... 6
Parts and functions ....................................................................................................................... 9
Insert / remove a microSD memory card .................................................................................... 14
Troubleshooting........................................................................................................................... 16
Detail specifications .................................................................................................................... 18

3
Limitation of liability
THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF
THE THIRD PARTY'S RIGHT.
THIS PUBLICATION COULD INCLUDE TECHNICAL INACCURACIES OR TYPOGRAPHICAL
ERRORS. CHANGES ARE ADDED TO THE INFORMATION HEREIN, AT ANY TIME, FOR THE
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S).
Disclaimer of warranty
IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT
FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES,
INCLUDING BUT NOT LIMITED TO BELOW:
(1) ANY LOSS OR DAMAGE, INCLUDING WITHOUT LIMITATION, DIRECT OR INDIRECT,
SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR RELATING TO THE
PRODUCT;
(2) ANY INCONVENIENCE, LOSS, OR DAMAGE CAUSED BY INAPPROPRIATE USE OR
NEGLIGENT OPERATION OF THE USER;
(3) ALL MALFUNCTIONS OR TROUBLES FROM UNAUTHORIZED DISASSEMBLE, REPAIR OR
MODIFICATION OF THE PRODUCT BY THE USER, REGARDLESS OF THE CAUSE OF THE
MALFUNCTION OR TROUBLE;
(4) INCONVENIENCE OR ANY LOSS ARISING WHEN IMAGES ARE NOT DISPLAYED, DUE TO
ANY REASON OR CAUSE INCLUDING ANY FAILURE OR PROBLEM OF THE PRODUCT;
(5) ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS OR DAMAGE, ARISING
OUT OF THE SYSTEM COMBINED BY THE DEVICES OF THIRD PARTY;
(6) ANY CLAIM OR ACTION FOR DAMAGES BROUGHT BY ANY PERSON OR ORGANIZATION
AS A PHOTOGRAPHED SUBJECT DUE TO VIOLATION OF PRIVACY CONCERNING A
SURVEILLANCE CAMERA'S PICTURE OR SAVED DATA, FOR SOME REASON (INCLUDING
USE WHEN USER AUTHENTICATION ON THE AUTHENTICATION SETTING SCREEN IS SET
TO OFF), BECOMING PUBLIC OR BEING USED FOR ANY PURPOSE;
(7) LOSS OF REGISTERED DATA CAUSED BY ANY FAILURE (INCLUDING INITIALIZATION OF
THE PRODUCT DUE TO FORGOTTEN AUTHENTICATION INFORMATION SUCH AS A USER
NAME AND PASSWORD).

4
About notations
Some functions are expressed with the following notations in this document.
U65302
The functions with this notation are available when using the WV-S65302-Z2 series and
WV-U65302-Z2 series.
U65301
The functions with this notation are available when using the WV-S65301-Z1 series and
WV-U65301-Z1 series.
C
Clear dome cover
G
Smoke dome cover
W
i-PRO white body
B
Black body
System requirements for a PC
CPU: Intel®CoreTM Processor family
- Intel®CoreTM i5-6500 or faster
- Intel®CoreTM i7-6700 or faster recommended
Memory: 4 GB (2 GB x 2, Dual Channel) or more recommended.
Network interface: 10BASE-T/100BASE-TX 1 port
Audio interface: Sound card (when using the audio function)
Monitor: Image capture size: 1024 x 768 pixels or more
Color: 24-bit True color or better
OS: Microsoft Windows 11
Microsoft Windows 10
Web browser: Microsoft Edge
Firefox
Google ChromeTM
Others: Adobe®Reader®or Acrobat Reader®
(It is necessary to view the PDF file.)
IMPORTANT:
• For information on the operation verification of web browsers, refer to our technical information
website <Control No.: C0132>.
• When using a PC that does not meet the above requirements, displaying of images may
become slower or the web browser may become inoperable.
• Audio may not be heard if a sound card is not installed on a PC. Audio may be interrupted
depending on the network environment.

5
Network security
As you will use this unit connected to a network, your attention is called to the following security
risks.
① Leakage or theft of information through this unit
② Use of this unit for illegal operations by persons with malicious intent
③ Interference with or stoppage of this unit by persons with malicious intent
It is your responsibility to take precautions such as those described below to protect yourself
against the above network security risks.
• Use this unit in a network secured by a firewall, etc.
• If this unit is connected to a network that includes PCs, make sure that the system is not
infected by computer viruses or other malicious entities (using a regularly updated anti-virus
program, anti-spyware program, etc.).
• To prevent unauthorized access, use user-authentication, set user names and passwords, and
limit which users can log in.
• Apply measures such as user authentication to protect your network against leakage or theft of
information, including image data, authentication information (user names and passwords),
alarm mail information and DDNS server information.
• After the unit is accessed by the administrator, make sure to close the browser.
• Change the administrator password periodically. Additionally, save user authentication informa-
tion (user names and passwords) in such a way that it is kept out of the hands of third parties.
• Do not install the camera in locations where the camera or the cables can be destroyed or
damaged by persons with malicious intent.

6
When the product is accessible from the
Internet
To prevent unauthorized access, note the fol-
lowing.
• Leave user authentication turned on.
• Periodically change passwords that are
used to access the product.
Refer to the Operating Instructions for
information about how to change pass-
words.
To keep on using with stable performance
Do not use this product in hot and humid con-
ditions for a long time. Failure to observe this
causes component degradation resulting in life
shortening of this product. Do not expose this
product to direct heat sources such as a
heater.
<WV-S65301-Z1S>
When installing over oceans or in coastal
streets
• Periodically inspect the camera when
installing it in coastal areas or areas that
are sprayed with snow-melting agent.
(Replace parts as necessary.)
• When installing this product in coastal
areas and area that are sprayed with
snowmelting agent that are not exposed to
rainwater, periodically clean by rinsing to
remove adhered salt.
Usage such as switching the power ON/
OFF frequently could lead to failure of the
camera.
Handle this product with care.
Do not drop this product, nor apply shock or
vibration to the product. Failure to observe this
may cause trouble.
Do not subject dome cover to strong
impact.
Doing so may cause damage or immersion.
Do not directly touch the lens and dome
cover with your bare hands.
A dirty dome cover or lens causes deterioration
of picture quality.
When an error is detected, this product
will restart automatically.
This product will be inoperable for around
2minutes after the restart just as when the
power is turned on.
About the automatic status detection function
When this product malfunctions due to exoge-
nous noise, etc. for 30 seconds or more, the
product will automatically restart and will return
to normal state. When the product is restart,
initialization will be carried out as when the
power of the product is turned on. When the
product repeatedly resets, exogenous noise
level around the product may be high and that
may cause malfunction. Contact your dealer
for instructions.
Periodically images on the screen appear
to be distorted
When the camera is installed in a location
where it is subject to small vibrations (for exam-
ple, when it is installed near devices that
vibrate), images may appear distorted and
stretched lengthways. This phenomenon is a
characteristic of image pickup devices that use
CMOS sensors and is caused by the relation-
ship between the periodic movements of the
camera and the timing that the image sensor
reads images. This is not a problem with the
camera. To reduce the possibility of this phe-
nomenon occurring, install the camera in a
secure location.
About the ventilation opening
• This product has 4 ventilation openings to
keep the inside of the camera at a low
humidity level.
• Depending on conditions such as temper-
ature, humidity or the climate, condensa-
tion may form and it may take time to
dehumidify.
Precautions for use

7
• The ventilation openings are located on the
side of the camera.
To maintain the dehumidification function
properly, do not caulk (fill gaps with seal-
ants or other materials) the gaps between
the decorative covers.
Ventilation
opening
(4 places)
We shall not be liable for content compen-
sation, losses of recorded or edited con-
tent and any direct or indirect consequent
damages caused by failure to record or
edit due to faults with this unit or the
microSD memory card. In addition, the
same provisions apply after unit is reparied.
About the CMOS image sensor
• When continuously shooting a bright light
source such as a spotlight, the color filter
of the CMOS image sensor may become
deteriorated and this may cause discolor-
ation. Even when changing the fixed
shooting direction after continuously
shooting a spotlight for a certain period,
the discoloration may remain.
• When shooting fast-moving subjects or
performing panning/tilting operations,
objects crossing the shooting area may
look to be bending askew.
Cleaning this product body
Be sure to turn off the power before cleaning.
Failure to observe this may cause injury.
Do not use benzine, thinner, alcohol, or any
other types of solvents or detergents.
Otherwise, it may cause discoloration. When
using a chemical cloth for cleaning, read the
caution provided with the chemical cloth
product.
• Do not loozen or remove screws unless
instructed to do so in the product docu-
mentation.
• The camera position may be moved inad-
vertently while cleaning the camera body.
Restart the product or refresh the camera
position (position refresh) to correct the
camera position. Refer to the Operating
Instructions for further information.
Cleaning the lens
Use a lens cleaning paper (used to clean cam-
era lenses or lenses of spectacles). When using
solvent, use an alcohols solvent and do not
use a glass cleaner or a thinner.
Cleaning of the dome cover
Use lens cleaning paper (used to clean camera
or spectacles lenses) to remove any dirt on the
dome cover. (If dust or the like is adhered at
this time, the dome cover may get scratched.
We recommend rinsing for stubborn stains.)
Consumable parts
The following are consumables: Replace them
in accordance with their operating lifetimes.
Their operating lifetimes vary depending on the
usage environment and conditions. The oper-
ating lifetimes below are just guides for when
using the camera at +35 °C {95 °F}.
Lens unit, panning motor, tilting motor, slip ring,
flat cable for tilting: Approx. 3.7 million opera-
tions (Approx. 20000 hours)
* When continuing the action of moving the
set position for a long period, dust may
accumulate in a slip ring. It can be
prevented by executing the position refresh
action regularly (about once a week) using
the schedule setting.
Refer to our technical information website
<Control No.: C0125>) for slip ring information.

8
AVC Patent Portfolio License
THIS PRODUCT IS LICENSED UNDER THE
AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL USE OF A CONSUMER OR
OTHER USES IN WHICH IT DOES NOT
RECEIVE REMUNERATION TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE AVC
STANDARD (“AVC VIDEO”) AND/OR (ii)
DECODE AVC VIDEO THAT WAS ENCODED
BY A CONSUMER ENGAGED IN A PER-
SONAL ACTIVITY AND/OR WAS OBTAINED
FROM A VIDEO PROVIDER LICENSED TO
PROVIDE AVC VIDEO. NO LICENSE IS
GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION
MAY BE OBTAINED FROM MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
Lens and pan/tilt head
If a lens and pan/tilt head are not performed for
a long period of time, the grease coating inside
these parts may become sticky. That may
obstruct the parts from moving. To prevent
this, move the lens or pan/tilt head periodically.
Or perform position refresh periodically in the
manner described in “Position refresh”.
Position refresh
During the use for a long period of time, the
preset positions may become inaccurate.
When “Position refresh” is set for the created
schedule, the camera position will be corrected
periodically.
Refer to the Operating Instructions for how to
perform the settings.
Tilt angles and the zoom ratio
This product is used at a tilt angle higher than
about 0 °, depending on the zoom rate used,
images may become distorted or the upper
parts of the images may become dark.
In this case, adjust the zoom rate or tilt angle
as necessary.
Product disposal/transfer
Data saved on this product or a storage device
used with this product may lead to personal
information leakage. When it is necessary to
dispose or give this product to someone, even
when for repair, make sure that there is no data
on this product.
When abandoning the memory media, it is rec-
ommended to destroy it physically after deleting
data by PC.
Effects on images and image quality
Under the following conditions, image quality
may deteriorate or images may become difficult
to see.
• When there are raindrops on the dome
cover due to wind during rainfall.
• When there is snow on the dome cover
due to wind during snowfall. (varies
depending on the amount and quality of
snowfall).
• When the dome cover is dirty due to dust
in the air or vehicle exhaust.
About HEVC (High Efficiency Video Coding)
patents
Covered by one or more claims of the HEVC
patents listed at patentlist.accessadvance.
com.
Router
When connecting this product to the Internet,
use a broadband router with the port forward-
ing function (NAT, IP masquerade).
Refer to the Operating Instructions for further
information about the port forwarding function.
Time & date setting
It is necessary to set the time & date before
putting this product into operation. Refer to the
Operating Instructions for descriptions of how
to perform the settings.

9
[1] RJ45 Ethernet cable
Connect an RJ45 Ethernet cable (category 5e or better, straight, 4 pairs (8 pins)) to the camera.
IMPORTANT:
• Use all 4 pairs (8 pins) of the Ethernet cable.
• The maximum cable length is 100 m {328 feet}.
• Make sure that the PoE+ / PoE device in use is compliant with IEEE802.3at / IEEE802.3af
standard.
• When connecting both the 12 V DC power supply and the PoE+ / PoE device for power supply,
12V DC will be used for power supply.
• When the Ethernet cable is disconnected once, reconnect the cable after around 2seconds.
When the cable is quickly reconnected, the power may not be supplied from the PoE+ / PoE
device.
Parts and functions
■Cables
The following are descriptions when using the model WV-U65302-Z2.
[3] Audio in
(white)
[4] Audio out
(black)
< 1 m {3.28 feet} (Mic)
< 10 m {32.8 feet} (Line)
< 10 m {32.8 feet}
ALARM IN2 (red)
GND (black)
12 V DC (red)
GND (black)
ALARM IN3 (gray)
ALARM IN1 (green)
[1] RJ45 Ethernet cable (PoE+ / PoE),
category 5e or better, straight, 4 pairs (8 pins)
<100 m {328 feet}
RJ45 network terminal
[2] 2P power cable
(WV-QCA501A accessory)
[5] 4P alarm cable
(WV-QCA501A accessory)
I/O Cable connection terminal
[2] Power supply
cable
[5] EXT I/O
cable

10
[2] Power supply cable / 2P power cable (WV-QCA501A accessory)
Connect the output cable of the DC power supply to the 2P power cable.
IMPORTANT:
• Be sure to use the 2P power cable provided with WV-QCA501A.
• Be sure to fully insert the 2P power cable into the power supply cable. Otherwise, it may dam-
age the camera or cause malfunction.
• When installing the camera, make sure that excessive force is not applied to the power cable.
• Be sure to use an AC adaptor compliant with the Specifications (written in the indication label
on the bottom side of this unit) regarding power source and power consumption.
[3] Audio input cable (white)
Connect a microphone or the line out of an external device using a stereo mini plug ( ø 3.5 mm).
<For microphone input>
• Recommended microphone (locally procured): Plug-in power type
(Sensitivity of microphone: –51 dB to –38 dB (0 dB=1 V/Pa,1 kHz))
• Input impedance: Approx. 2 kΩ (unbalanced)
• Supply voltage: 2.5 V ±0.5 V
• Recommended cable length: Less than 1 m {3.28 feet}
<For line input>
• Input level for the line input: Approx. –10 dBV
• Recommended cable length: Less than 10 m {32.8 feet}
[4] Audio output cable (black)
Connect an external speaker* using a stereo mini plug (ø3.5 mm). (Audio output is monaural.)
• Output impedance: Approx. 600 Ω (unbalanced)
• Recommended cable length: Less than 10m {32.8feet}
• Output level: –20 dBV * Use a powered speaker.
Note:
• The audio output can be switched to the monitor output. Refer to the Operating Instructions for
descriptions of how to switch the output.
• The video output is set to NTSC in the default settings of the camera. If you want to change the
video output setting to PAL, refer to the Operating Instructions.
IMPORTANT:
• Connect/disconnect the audio cables and turn on the power of the camera after turning off the
power of the audio output devices. Otherwise, loud noise may be heard from the speaker.
• Make sure that the stereo mini plug is connected to this cable. When a monaural mini plug is
connected, audio may not be heard.
When connecting a monaural speaker with amplifier, use a locally procured conversion cable
(mono-stereo).

11
[5] EXT I/O cable / 4P alarm cable (WV-QCA501A accessory)
Note:
• Off, input, and output of the ALARM IN2 and 3 can be switched by configuring the setting.
Refer to the Operating Instructions for further information about the ALARM IN2 and 3 settings
(“Off”, “Alarm input”, “Alarm output” or “AUX output”).
<Ratings>
• Alarm input1 / Black & white input / Auto time adjustment input, Alarm input2, Alarm input3
Input specification: No-voltage make contact input (4 V - 5 V DC, internally pulled up)
OFF: Open or 4 V - 5 V DC
ON: Make contact with GND (required drive current: 1mA or more)
• Alarm output, AUX output
Output specification: Open collector output (maximum applied voltage: 20 V DC)
OPEN: 4 V - 5 V DC by internal pull-up
CLOSE: Output voltage 1 V DC or less (maximum drive current: 50 mA)
4P alarm cable
GND (Black)
ALARM IN3 (Alarm input3 / AUX output) (Gray)
ALARM IN2 (Alarm input2 / Alarm output) (Red)
ALARM IN1 (Alarm input1 / Black & white input / Auto time adjustment input)
(Green)
IMPORTANT:
• Install external devices so that they do not exceed the rating of the network camera.
• When using the ALARM IN2 and/or 3 as the output terminals, ensure they do not cause signal
collision with external signals.

12
■Indicators and buttons
A INITIAL SET button (Initializing / NTSC PAL switch button)
Follow the steps below to initialize the network camera.
(1) Turn off the power of the camera.
When using a PoE+ / PoE hub, disconnect the Ethernet cable from the camera. When
using an external power supply, disconnect the 2P power cable (WV-QCA501A accessory)
from the power supply cable (12 V DC).
(2) Turn on the power of the camera while pressing the INITIAL SET button, and make sure to
release the button after approximately 15 seconds. In about 2 minutes later, the camera
will start up and the settings including the network settings will be initialized. Retry if the
camera does not start up normally.
IMPORTANT:
• When the camera is initialized, the settings including the network settings will be initialized.
Before initializing the settings, it is recommended to write down the settings in advance.
• Do not turn off the power of the camera during the process of initialization. Otherwise, it may
fail to initialize and may cause malfunction.
• When the INITIAL SET button is pressed (less than 1 second) to switch the output signal of the
MONITOR OUT, the MONITOR OUT can be switched for the NTSC monitor PAL monitor.
B LINK indicator
• When the camera is able to communicate with
the connected device
Lights orange
C ACT indicator
• When data is being sent via the network camera Blinks green (accessing)
②LINK indicator (orange)
③ACT indicator (green)
④SD ERROR indicator (red)
①INITIAL SET button

13
D SD ERROR indicator
• When an error status is detected Lights red
* SD memory card error detection conditions: Write error, read error, etc.
Note:
• Lighting/blinking LED can be turned off with the software settings at any time. (The initial state
is lighting or blinking.) Set the LED to be solid off if necessary, depending on the installation
conditions. ( Operating instructions on our product information website)

14
Note:
• Use a microSD memory card dedicated to i-PRO cameras.
• Refer to the Operating Instructions on our product information website for further information
about the microSD memory card settings.
■Insert a microSD memory card
A Remove the enclosure from the camera. (Refer to installation procedure leaflet)
B Insert the microSD memory card until it makes a clicking sound.
C After inserting the microSD memory card, turn on the power of the camera and check that the
SD ERROR indicator lights/blinks, and then lights off.
Insert / remove a microSD memory card
D Attach the enclosure to the camera.

15
■Remove a microSD memory card
When removing a microSD memory card, reverse the procedure.
• Before removing the microSD memory card, make sure to select “Not use” for “SD memory
card” on the [SD memory card] tab of “Basic” page on the setup menu first. (☞Operating
Instructions)
Note:
• Refer to the Operating Instructions for further information about the microSD memory card
settings.
• When using a microSD memory card, format it using this product. Recorded data on the
microSD memory card will be deleted when formatted.
If an unformatted microSD memory card or a microSD memory card formatted with other
devices is used, this product may not work properly or performance deterioration may be
caused. Refer to the Operating Instructions for how to format a microSD memory card.

16
Before asking for repairs, check the symptoms with the following table.
Contact your dealer if a problem cannot be solved even after checking and trying the solution in the
table or a problem is not described below.
Symptom Cause/solution Reference
pages
Power is not turned on.
When using a PoE+ / PoE device for power supply
• Are the PoE+ (IEEE802.3at compliant) / PoE
(IEEE802.3af compliant) device and the RJ45 (female)
network cable of the camera connected using a Ether-
net cable (category 5e or better)?
Check whether the connection is appropriately estab-
lished.
• Depending on the PoE+ / PoE device, the power sup-
ply will stop when the demanded power exceeds its
total power limit for all PoE+ / PoE ports.
Refer to the operating instructions of the PoE+ / PoE
device in use.
Installation
Guide
When using DC power supply
• Is the 2P power cable (WV-QCA501A accessory) firmly
inserted into the power supply cable of the camera?
Confirm the power plug is firmly connected.
• Is the AC adaptor in use compliant with the Specifica-
tions?
Check the Specifications regarding AC adaptor.
The camera does not
move to the preset
positions accurately.
• When the preset positions become inaccurate during
use, it is possible to correct the positions by executing
the position refresh function.
In addition, when “Position refresh” is set for the cre-
ated schedule, the camera position will be corrected
periodically. In some situations, reconfigure the preset
positions.
Operating
Instructions
When the camera is
panning/tilting, the
camera stops panning/
tilting and mechanical
noise comes from the
camera.
• The camera position may have become inaccurate.
Carry out the refresh position function from the [Default
reset] tab of the “Maintenance” page of the setup
menu.
Operating
Instructions
The camera starts
panning unpredictably.
• This may be caused by noise.
Check the exogenous noise level around the camera. 6
• The position refresh may be done automatically to
improve the positional accuracy of PAN, TILT and
ZOOM when turned on in low temperature, which is
not a failure.
−
Troubleshooting

17
Symptom Cause/solution Reference
pages
The LINK indicator
does not light in
orange even when the
Ethernet cable is con-
nected to the camera.
• Is the Ethernet cable connected appropriately?
Connect the Ethernet cable appropriately.
• Is the hub or router connected to the camera operating
appropriately?
Check if the hub or router in use is operating appropriately.
• Is the Ethernet cable connected to the camera broken?
Replace the cable with another one.
9
SD ERROR indicator
lights red.
This indicator lights up red when data cannot be
saved on the microSD memory card.
• Has the inserted microSD memory card been format-
ted on a PC?
Use a microSD memory card formatted on the camera.
Or install the software to format the microSD memory
card on the PC.
Refer to our technical information website <Control
No.: C0105> for further information about the software
to format the microSD memory card on the PC.
• Is the inserted microSD memory card faulty?
Replace the card with a normal one.
13
Audio input contains
noise.
• Check the following.
• Grounding of the camera, a switching hub or
peripheral devices are not done.
• The camera is used near an electrical power line.
• The camera is used near a device which produces
strong magnetic field or radio waves (such as near
a TV/radio antenna, a motor of an air conditioning
system, a transformer, etc.)
When audio input still contains noise even after check-
ing the above possibilities, use a powered microphone
or connect audio output with low output impedance.
Installation
Guide
Auto focus (AF) can
not be automatically
adjusted.
• In the following locations or with the following subjects,
the focus may not be able to be automatically adjusted.
In this case, manually adjust the focus from the software
screen.
• When the subject moves a lot
• When there are large changes to the lighting intensity
• When the light level is low
• When the subject or location is extremely bright or
reflective
• When viewing through windows
• When the dome cover is in a locations where it
can easily become dirty
• Locations where there is not much contrast such
as a white wall
• When there is harsh flickering
Operating
Instructions

18
Detail specifications
• Basic
Power source*1, *5: 12 V DC
PoE (IEEE802.3af compliant), PoE+(IEEE802.3at compliant)
Power consumption*1:■When using at TILT rotation speed 350 °/S
12 V DC: 1.3 A/ Approx. 15.6 W
PoE 48 V DC: 270 mA/ Approx. 12.95 W (Class 0 device)
■When using at TILT rotation speed 500 °/S
PoE+ 54 V DC: 340 mA/ Approx. 18.4 W (Class 4 device)
Operating environment
Ambient operating temperature:
Ambient operating humidity:
–30 °C to +55 °C {–22 °F to +131 °F}
(Power On range: –20 °C to +55 °C {–4 °F to +131 °F})
10 % to 100 % (no condensation)
Storage environment
Storage temperature:
Storage humidity:
–30 °C to +60 °C {–22 °F to +140 °F}
10 % to 95 % (no condensation)
EXT I/O terminals*5: ALARM IN1
(Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)
ALARM IN2 (Alarm input 2/ ALARM OUT) (x1)
ALARM IN3 (Alarm input 3/ AUX OUT) (x1)
Audio input*5: ø3.5 mm stereo mini jack
For microphone input: Recommended applicable microphone: Plug-in power type
(Sensitivity of microphone: –51 dB to –38 dB (0 dB=1 V/Pa, 1 kHz))
Input impedance: Approx. 2 kΩ (unbalanced)
Supply voltage: 2.5 V ±0.5 V
For line input: Input level: Approx. –10 dBV
Audio output*2, *5: ø3.5 mm stereo mini jack (Audio output is monaural.)
Output impedance: Approx. 600 Ω (unbalanced)
Output level: –20 dBV
Waterproof*3: IP66 (IEC 60529), Type 4X (UL50E)
NEMA 4X compliant
Shock resistance: IK10 (IEC 62262)
Wind resistance: Up to 40 m/s {approx. 89 mph}
Dimensions:
U65302
Maximum diameter: ø165 mm × 153 mm (H)
{ø6-1/2 inches × 6-1/32 inches (H)}
Dome radius 63.5 mm {2-1/2 inches}
U65301
Maximum diameter: ø165 mm × 139 mm (H)
{ø6-1/2 inches × 5-15/32 inches (H)}
Dome radius 63.5 mm {2-1/2 inches}
Mass:
U65302
Approx. 1.7 kg{3.75 lbs.}
U65301
Approx. 1.6 kg{3.53 lbs.}

19
Finish: Main body:
U65302
<WV-S65301-Z1><WV-U65301-Z1>
Aluminum die cast, black and PC resin
W
B
<WV-S65301-Z1S>
Aluminum die cast, black and PC resin
W
(The heavy salt damage resistance coating)
Outer fixing screws: Stainless steel (Corrosion-resistant treatment)
Dome cover: PC resin,
C
G
(Transmittance: 45 %)
Others: Tamper-resistant enclosure*4
NEMA TS2 Compliant
Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C (165 °F)
<WV-S65301-Z1S>
Heavy salt damage resistance specifications (ISO 14993 compliant)
*1 Refer to our technical information website <Control No.: C0106> for further information about
Power source and Power consumption information.
*2 The audio output can be switched to the monitor output. Refer to the “Operating Instructions”
on our product information website for descriptions of how to switch the output
.
*3 Only when installation work is properly performed according to the Installation Guide and
appropriate waterproof treatment is performed.
*4 Component that has a structure on which the screws that are accessible after installation
cannot be screwed or unscrewed using an ordinary screwdriver.
*5 When using a 12 V DC power supply of this product, EXT I/O terminal, audio input, and audio
output, I/O cable (option: WV-QCA501A) is required.
• Camera
Image sensor: Approx. 1/2.8 type CMOS image sensor
Effective pixels: Approx. 2.1 megapixels
Scanning area: 5.57 mm (H) × 3.13 mm (V) {7/32 inches (H) × 1/8 inches (V)}
Scanning system: Progressive
Minimum illumination:
C
Color: 0.011 lx {0.00102 footcandle}
(30IRE, F1.6, Maximum shutter: Off (1/30 s), AGC: 11)*
0.015 lx {0.00139 footcandle}
(50IRE, F1.6, Maximum shutter: Off (1/30 s), AGC: 11)
0.001 lx {0.00009 footcandle}
(50IRE, F1.6, Maximum shutter: max. 16/30 s, AGC: 11)*
BW: 0.006 lx {0.00056 footcandle}
(50IRE, F1.6, Maximum shutter: Off (1/30 s), AGC: 11)
0.0004 lx {0.00004 footcandle}
(50IRE, F1.6, Maximum shutter: max. 16/30 s, AGC: 11)*
G
Color: 0.03 lx {0.00279 footcandle}
(30IRE, F1.6, Maximum shutter: Off (1/30 s), AGC: 11)*
0.045 lx {0.00418 footcandle}
(50IRE, F1.6, Maximum shutter: Off (1/30 s), AGC: 11)
0.003 lx {0.00028 footcandle}
(50IRE, F1.6, Maximum shutter: max. 16/30 s, AGC: 11)*
BW: 0.017 lx {0.00158 footcandle}
(50IRE, F1.6, Maximum shutter: Off (1/30 s), AGC: 11)
0.0011 lx {0.0001 footcandle}
(50IRE, F1.6, Maximum shutter: max. 16/30 s, AGC: 11)*
* Converted value

20
Intelligent Auto: On/Off
Super Dynamic*1: On/Off
The level can be set in the range of 0 to 31.
Dynamic range: Max. 144 dB
(Super Dynamic: On, Level: 31)
Maximum gain: The level can be set in the range of 0 to 11.
Adaptive black stretch: The level can be set in the range of 0 to 255.
Back light compensation (BLC)/
High light compensation (HLC):
BLC/ HLC/ Off
The level can be set in the range of 0 to 31.
(only when Super Dynamic/ Intelligent Auto: Off)
Fog compensation: On/Off
The level can be set in the range of 0 to 8.
(only when Intelligent Auto / Auto contrast adjust: Off)
Light control mode setting: Outdoor scene/ Indoor scene (50 Hz)/ Indoor scene (60 Hz)/
Fix shutter
Shutter speed: [60fps mode]
1/60Fix, 1/100Fix, 1/120Fix, 1/250Fix, 1/500Fix, 1/1000Fix,
1/2000Fix, 1/4000Fix, 1/10000Fix
[30fps/ 15fps mode]
1/30  Fix, 3/120  Fix, 2/100Fix, 2/120Fix, 1/100Fix, 1/120Fix,
1/250 Fix, 1/500Fix, 1/1000Fix, 1/2000Fix, 1/4000Fix, 1/10000Fix
[50fps mode]
1/50Fix, 1/100Fix, 1/250Fix, 1/500Fix, 1/1000Fix, 1/2000Fix,
1/4000Fix, 1/10000Fix
[25fps/ 12.5fps mode]
1/25Fix, 3/100Fix, 2/100Fix, 1/100Fix, 1/250Fix, 1/500Fix,
1/1000 Fix, 1/2000Fix, 1/4000Fix, 1/10000Fix
Maximum shutter: [60fps mode]
Max.1/4000 s, Max.1/2000 s, Max.1/1000 s, Max.1/500 s,
Max.1/250 s, Max.1/120 s, Max.1/100 s, Max.2/120 s, Max.1/30 s,
Max.2/30 s, Max.4/30 s, Max.6/30 s, Max.10/30 s, Max.16/30 s
[30fps/ 15fps mode]
Max.1/4000s, Max.1/2000s, Max.1/1000s, Max.1/500s,
Max.1/250s, Max.1/120s, Max.1/100s, Max.2/120 s,
Max.2/100s, Max.3/120s, Max.1/30s, Max.2/30s, Max.4/30s,
Max.6/30s, Max.10/30s, Max.16/30s
[50fps mode]
Max.1/4000 s, Max.1/2000 s, Max.1/1000 s, Max.1/500 s,
Max.1/250 s, Max.1/100 s, Max.2/100 s, Max.1/25 s, Max.2/25 s,
Max.4/25 s, Max.6/25 s, Max.10/25 s, Max.16/25 s
[25fps/ 12.5fps mode]
Max.1/4000s, Max.1/2000s, Max.1/1000  s, Max.1/500s,
Max.1/250s, Max.1/100s, Max.2/100s, Max.3/100 s, Max.1/25s,
Max.2/25s, Max.4/25s, Max.6/25s, Max.10/25s, Max.16/25s
Color/BW: Off/ On/ Auto1/ Auto2/ Auto3(SCC)
White balance: ATW1/ ATW2/ AWC
Digital noise reduction: The level can be set in the range of 0 to 255.
Stabilizer: On/Off
