i-PRO WV-U85402-V2L User manual

C
o
v
e
r
User manual
Network cameras
Ver 1.002.000

Contents
1 Introduction ………………………………………………………………… 1
1.1 About User Manuals ………………………………………………………… 1
1.2 Compatible models and symbols in this manual ……………………………… 1
1.3 Abbreviation ………………………………………………………………… 3
1.4 Disclaimer …………………………………………………………………… 4
1.5 For trademarks and registered trademarks ………………………………… 4
1.6 NETWORK RELATIONSHIP ………………………………………………… 5
1.7 Instructions for use …………………………………………………………… 5
2 Operation …………………………………………………………………… 9
2.1 Initial Setting ………………………………………………………………… 9
2.2 Initial setting (Multi-directional/PTZ integrated camera) …………………… 14
2.3 Viewing images from a PC …………………………………………………… 19
2.3.1 View camera images ……………………………………………………… 20
2.3.2 About live image pages …………………………………………………… 27
2.4 Viewing images from mobile/tablet terminals ……………………………… 59
2.4.1 Viewing images from mobile devices (smartphones, etc.) ………………… 59
2.4.2 View images from a tablet terminal ………………………………………… 80
2.5 Manually save images on the SD memory card ……………………………… 106
2.6 Operation when alarm is generated ………………………………………… 107
2.6.1 Alarm type ………………………………………………………………… 107
2.6.2 Operation when alarm is generated ………………………………………… 108
2.7 Display the log list …………………………………………………………… 109
2.8 Play back images on the SD Memory Card ………………………………… 113
2.8.1 When playing JPEG images stored on the SD Memory Card ……………… 115
2.8.2 Play back the image of the stream stored on the SD Memory Card ……… 117
3 Setting ……………………………………………………………………… 122
3.1 Displaying the configuration panel from the PC ……………………………… 122
Contents
i

3.1.1 How to display ……………………………………………………………… 122
3.1.2 How to operate ……………………………………………………………… 123
3.1.3 Setting Panel Screen ……………………………………………………… 123
3.2 [Basic] to perform basic settings …………………………………………… 125
3.3 [Stream] for setting images ………………………………………………… 126
3.4 [Image quality] for setting image quality …………………………………… 128
3.5 [Zoom] for setting EX zoom ………………………………………………… 130
3.6 [Zoom] for set zoom/focus ………………………………………………… 130
3.7 [Audio] for setting sound …………………………………………………… 132
3.8 [Alarm] to set alarm ………………………………………………………… 132
3.9 [Detailed setting] for switching to advanced settings and setting related to the
displayed images ……………………………………………………………… 134
4 Advanced settings ………………………………………………………… 136
4.1 About network security ……………………………………………………… 136
4.1.1 Security function of the unit ………………………………………………… 136
4.2 Displaying the camera settings menu from the PC ………………………… 137
4.2.1 How to display ……………………………………………………………… 137
4.2.2 How to operate ……………………………………………………………… 139
4.2.3 Camera Advanced Menu Screen …………………………………………… 140
4.3 [Ext. software] for managing and scheduling advanced software ………… 143
4.3.1 [Software mng.] for installing, uninstalling, and upgrading function extension
software …………………………………………………………………… 144
4.3.2 [Operation sched.] for scheduling extended software ……………………… 149
4.3.3 [Control log] to check the [Control log] of the function extension software
………………………………………………………………………………… 151
4.4 [Easy Setup] to use easy setting …………………………………………… 152
4.4.1 [Easy installation] where easy installation is performed ………………… 152
4.4.2 [Internet] to set up an Internet-based disclosure system ………………… 155
4.4.3 [Event action] for setting events …………………………………………… 158
4.5 [Basic] for basic setup of the machine ……………………………………… 184
4.5.1 [Basic] to perform basic settings …………………………………………… 184
4.5.2 [SD memory card] for setting SD Memory Cards ………………………… 191
4.5.3 [Alteration detection] for detecting tampering …………………………… 203
4.5.4 How to set up falsification detection ……………………………………… 206
Contents
ii

4.5.5 [Overlay image] to set overlays …………………………………………… 206
4.6 [Image/Audio] for setting images and sound files …………………………… 211
4.6.1 [Image] to set the imaging modes ………………………………………… 211
4.6.2 [Image] for setting JPEG images …………………………………………… 214
4.6.3 [Image] for setting up streams ……………………………………………… 220
4.6.4 [Image quality] to set the image quality …………………………………… 231
4.6.5 [Audio] for setting sound …………………………………………………… 274
4.7 Set PTZ ……………………………………………………………………… 277
4.7.1 [Cam. Function] for setting the operation of cameras …………………… 277
4.7.2 [Position] for setting positions ……………………………………………… 282
4.7.3 Set auto-tracking (Auto-tracking screen) ………………………………… 299
4.7.4 Set Auto Track Alarm (Auto Track Alarm screen) ………………………… 305
4.8 Configure the multi-screen settings[Multi-screen] ………………………… 307
4.9 [Alarm] to set the alarm ……………………………………………………… 309
4.9.1 [Alarm] to set alarm operation ……………………………………………… 309
4.9.2 [Alarm] for setting the output terminal …………………………………… 313
4.9.3 [Alarm] to change the aux name …………………………………………… 314
4.9.4 [Alarm] to set alarm linkage operation ……………………………………… 315
4.9.5 [VMD area] for setting motion detection ………………………………… 322
4.9.6 [VMD area] to set the motion detection area ……………………………… 331
4.9.7 [SCD area] to set up undesired detection ………………………………… 333
4.9.8 [SCD area] to set up undesired detection areas ………………………… 335
4.9.9 [Audio detection] for setting sound detection ……………………………… 337
4.9.10 [Notification] to set alarm notification …………………………………… 339
4.10 [User mng.] to set authentication ………………………………………… 345
4.10.1 [User auth.] to configure user-authentication …………………………… 345
4.10.2 [Host auth.] to configure host-authentication …………………………… 348
4.10.3 [System] to set preference streams ……………………………………… 349
4.10.4 [IEEE 802.1X] to configure IEEE 802.1X ………………………………… 350
4.10.5 [Data encryption] for setting up data encryption ………………………… 356
4.11 Networking configuration [Network] ……………………………………… 360
4.11.1 Networking [Network] ……………………………………………………… 361
4.11.2 [Advanced] for advanced networking settings …………………………… 366
4.11.3 Setting up HTTPS ………………………………………………………… 397
4.11.4 How to configure DDNS …………………………………………………… 398
Contents
iii

4.12 [Schedule] for scheduling …………………………………………………… 404
4.12.1 How to set the schedule ………………………………………………… 410
4.12.2 How to Delete Schedule ………………………………………………… 413
4.12.3 How to change the image quality based on the time of sunrise/sunset … 415
4.13 [Maintenance] to maintain the machine …………………………………… 416
4.13.1 [System log] to check the system logs …………………………………… 416
4.13.2 [Upgrade] to upgrade the software ……………………………………… 417
4.13.3 [Status] for checking the status ………………………………………… 419
4.13.4 [Default reset] to initialize and restart the computer …………………… 423
4.13.5 [Data] to back up/restore configuration logs …………………………… 424
4.14 Viewing Our Support Website [Support] …………………………………… 425
5 Other ……………………………………………………………………… 427
5.1 System Log Display ………………………………………………………… 427
5.2 Trouble!? ……………………………………………………………………… 432
5.3 Directory structure of SD Memory Card …………………………………… 441
5.3.1 Directories of PTZ Camera and Compact Camera ………………………… 441
5.3.2 Directory Configuration of Multi-directional Camera ……………………… 441
6 Change history ……………………………………………………………… 442
Ver 1.000.000 (2023.02.15) ………………………………………………………… 442
Ver 1.001.000 (2023.03.08) ………………………………………………………… 442
Ver 1.002.000 (2023.09.12) ………………………………………………………… 442
Contents
iv

[Note:]
・Refer to the catalog specifications for the functions installed in each model.
・[used] in this document[<Control number: Cxxxx>] is the number used to search
for the relevant information in our technical information website.
https://i-pro.com/products_and_solutions/en/surveillance/learning-and-
support/knowledge-base/technical-information
・Screen photographs are used according to the guidelines of Microsoft Corporation.
・This document describes the operation when using the Japanese version of
Google Chrome as a representative. For confirmation of the operation of the
corresponding Web browser, please refer to our Technical Information Web site<
Control No.: C0132>.
1 Introduction
1.1 About User Manuals
This manual describes the operation and setting methods of the software that runs this machine.
The description of the camera screen and function used in this manual is not limited to a specific
model, but includes various cameras. Therefore, the description screen and camera screen may
differ depending on the model you use.
This manual explains how to operate and configure a camera using a web browser. For camera
settings, we recommend using the i-PRO setup tool (iCT). By using the i-PRO Setup Tool (iCT),
you can configure up to 1024 cameras simultaneously and you can efficiently configure the
cameras. For the i-PRO Configuration Tool, please refer to our Technical Information Website<
Control No. C0133>.
1.2 Compatible models and symbols in this manual
The corresponding models in this manual are described in the model column in the table below.
The functions restricted by this manual refer to the models that can be used with the following
symbols and terminology. Functions for which this symbol is not used are supported by all models.
1 Introduction
1.2 Compatible models and symbols in this manual
1

Symbol Term Aircraft type
[PTZ] PTZ cameras WV-X86531-Z2_PTZ、 WV-X86530-
Z2_PTZ、
WV-S66700-Z3L、 WV-X66700-
Z3LS、 WV-S66700-Z3、 WV-
X66700-Z3S、
WV-S66600-Z3L、 WV-X66600-
Z3LS、 WV-S66600-Z3、 WV-
X66600-Z3S、
WV-S66300-Z4L、 WV-X66300-
Z4LS、 WV-S66300-Z3L、 WV-
X66300-Z3LS、 WV-S66300-Z4、
WV-X66300-Z4S、 WV-S66300-Z3、
WV-X66300-Z3S
[Rapid PTZ] Rapid PTZ Camera WV-S66700-Z3L、 WV-X66700-
Z3LS、 WV-S66700-Z3、 WV-
X66700-Z3S、
WV-S66600-Z3L、 WV-X66600-
Z3LS、 WV-S66600-Z3、 WV-
X66600-Z3S、
WV-S66300-Z4L、 WV-X66300-
Z4LS、 WV-S66300-Z3L、 WV-
X66300-Z3LS、 WV-S66300-Z4、
WV-X66300-Z4S、 WV-S66300-Z3、
WV-X66300-Z3S
[Rapid
PTZ-8M(4K)]
Rapid PTZ cameras (X/S series,
Image capture size: 8M (4K))
WV-S66700-Z3L、 WV-X66700-
Z3LS、 WV-S66700-Z3、 WV-
X66700-Z3S
[Rapid PTZ-6M] Rapid PTZ Camera(X/S Series, Image
capture size: 6MP)
WV-S66600-Z3L、 WV-X66600-
Z3LS、 WV-S66600-Z3、 WV-
X66600-Z3S
[Rapid PTZ-2M] Rapid PTZ Camera(X/S Series, Image
capture size: 2MP)
WV-S66300-Z4L、 WV-X66300-
Z4LS、 WV-S66300-Z3L、 WV-
X66300-Z3LS、 WV-S66300-Z4、
WV-X66300-Z4S、 WV-S66300-Z3、
WV-X66300-Z3S
1 Introduction
1.2 Compatible models and symbols in this manual
2

[MULTI] Multi-directional cameras WV-X86531-Z2_MULTI、 WV-
X86530-Z2_MULTI
WV-S85702-F3L、 WV-S85402-V2L
WV-U85402-V2L
[MULTI4] Multi-directional cameras (4 eyes) WV-X86531-Z2_MULTI
[MULTI3] Multi-directional cameras (3 eyes) WV-X86530-Z2_MULTI
[MULTI2] Multi-directional cameras (2 eyes) WV-S85702-F3L、 WV-S85402-V2L
WV-U85402-V2L
[MULTI2S] Multi-directional cameras (2-eye
S-series)
WV-S85702-F3L、 WV-S85402-V2L
[MULTI2U] Multi-directional cameras (2-eye
U-series)
WV-U85402-V2L
[MULTI_PTZ] Multi-directional + PTZ WV-X86531-Z2_PTZ、 WV-X86530-
Z2_PTZ、
WV-X86531-Z2_MULTI、 WV-
X86530-Z2_MULTI
[Compact] Compact Dome cameras WV-X35402-F2L、 WV-X35302-
F2L、
WV-S35402-F2L、WV-S32402-F2L
、
WV-S35302-F2L、 WV-S32302-F2L
[CompactX] Compact Dome cameras (X-series) WV-X35402-F2L、 WV-X35302-F2L
[CompactS] Compact Dome cameras (S-series) WV-S35402-F2L、WV-S32402-F2L
、
WV-S35302-F2L、 WV-S32302-F2L
[Comp
actX･S-4M]
Compact Dome cameras (X/S series,
Image capture size: 4MP)
WV-X35402-F2L、
WV-S35402-F2L、 WV-S32402-F2L
[Comp
actX･S-2M]
Compact Dome cameras (X/S series,
Image capture size: 2MP)
WV-X35302-F2L、
WV-S35302-F2L、 WV-S32302-F2L
1.3 Abbreviation
This document uses the following abbreviations.
The Japanese version of Microsoft Windows 10 is called Windows 10.
The Japanese version of Microsoft Windows 11 is called Windows 11.
The microSDXC/microSDHC/microSD memory card is called an SD card or SD memory card.
Universal Plug and Play is designated UPnP™ or UPnP.
1 Introduction
1.3 Abbreviation
3

1.4 Disclaimer
● The purpose of this product is to obtain images for monitoring specific areas. This product
alone is not intended to prevent crimes.
● In no event shall we be liable for the following:
① Any incidental, special or consequential damages or damages arising directly or indirectly
in connection with the Goods
② Inconvenience, damage or damage caused by improper or inadvertent use by the customer
or damage to the product
③ Any failure or fault which has occurred, whether or not caused by the customer's
disassembly, repair or modification of the Goods
④ Any inconvenience, damage, or damage incurred due to the inability to display images for
any reason or cause, including a failure or malfunction of the Product
⑤ Failure or inconvenience, damage, or damage caused by a system combined with a third
party device
⑥ Claims or claims for damages caused by infringement of privacy by an individual or
organization that has become the subject of a picture as a result of the use of surveillance
images and records made public for some reason (including use with the User Authentication
Off).
⑦ The stored information is lost for some reason (including when the Product is initialized
due to forgetting the authentication information such as user name and password)
1.5 For trademarks and registered trademarks
● Microsoft, Windows, Windows Media, Microsoft Edge, and ActiveX are registered
trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
● Intel, Intel Core is a trademark of Intel Corporation or its subsidiaries in the United States
and/or other countries.
● Adobe, Acrobat Reader and Adobe Reader are trademarks of Adobe.
● SDXC Logos are trademarks of SD-3C, LLC.
● iPad and iPhone are trademarks of Apple Inc. registered in the United States and other
countries.
● Android and Google Chrome are trademarks of Google LLC.
1 Introduction
1.5 For trademarks and registered trademarks
4

● Firefox is a trademark of the Mozilla Foundation in the United States and other countries.
● QR Code is a registered trademark of DENSO WAVE CORPORATION.
● Other company names and product names described in this manual are trademarks or
registered trademarks of each company.
1.6 NETWORK RELATIONSHIP
Since this equipment is connected to the network, it may be damaged as follows.
① Leakage or leakage of information via the machine
② Malicious operation of the Aircraft by a malicious third party
③ Interference or stoppage of the Aircraft by a malicious third party
In order to prevent such damage, take adequate network security measures including the following
measures under the responsibility of the customer.
● Use the machine on a secure network using firewalls, etc.
● Confirm that computer viruses and malicious programs are regularly checked and
exterminated when the computer is connected to the system.
● Use user authentication, set user names and passwords, and restrict users who can log in to
protect against unauthorized attacks.
● In order to prevent image data, authentication information (user name, password), alarm mail
information, DDNS server information, etc. from being leaked on the network, measures are
taken to restrict access by user authentication.
● Be sure to close all browsers after administrators have accessed the machine.
● The password of the administrator is changed periodically. In addition, authentication
information (user name, password) shall be appropriately stored so that it is not visible to
third parties.
● Do not install the equipment or cables in a place where they are easily destroyed.
1.7 Instructions for use
When using the machine via the Internet
In order to prevent unintended access by third parties,
● Keep the user authentication setting [On].
1 Introduction
1.7 Instructions for use
5

● Change the password for accessing the computer periodically. Refer to the following for how
to change.
→4.10.1 [User auth.] to configure user-authentication
For long-term stable performance
Do not use the product in a place with high temperature and high humidity for a long time.
Degradation of parts shortens the life of the product.
Improve the heat dissipation in the installation area and prevent direct exposure to heat such as
heating.
If the power supply is turned off and on repeatedly, failure of the equipment may result.
Handle with care
Do not drop or apply strong shock or vibration. Failure to heed this warning may result in failure.
Do not touch the dome cover directly.
If dirty, image quality may deteriorate.
When an error is detected, restart automatically.
The computer automatically restarts when an error is detected for some reason. When restarting,
the operation cannot be performed for approximately 2 minutes as it was when the power was
turned on.
Operation status detection function
If abnormal operation is continued for 30 seconds or longer due to external noise or the like during
operation, the computer will restart automatically and return to normal operation. The restart
operation is the same as when the power is turned on. However, if the restart occurs frequently,
external noise may be generated frequently in the installation environment of this equipment.
Consult your dealer as soon as possible, as this may cause a malfunction.
Periodic distortion of the screen
If the camera is installed in a place where it vibrates in small increments (for example, close to a
vibrating device), the screen may periodically become distorted to extend and contract lengthwise.
This is a characteristic phenomenon that occurs when the CMOS sensor is used for the image
pickup device. It is caused by periodic movement of the screen and the timing of reading out the
image from the image sensor, and it is not an error in the camera. Reassess the installation
condition and ensure the stability of the camera body to alleviate the problem.
We shall not be liable for any loss of, or direct or indirect damage caused by, any compensation,
recording, or editing of the contents that could not be correctly recorded or edited due to a defect
in the machine or the microSD memory card. The same shall apply to the case of repair of the
Aircraft.
CMOS sensor
1 Introduction
1.7 Instructions for use
6

● If a portion of the screen is bright, such as spot light, the color filter inside the CMOS sensor
may deteriorate, resulting in discoloration. When the direction of fixed monitoring is
changed, spot light on the previous screen will change color and remain.
● When you shoot a fast-moving object, you may see the object bending diagonally across the
screen.
Temperature sensorWith respect to
The built-in temperature sensor is used to measure the temperature inside the camera.
For maintenance
Turn off the power before starting operation. Doing so may result in injury.
Do not apply or use organic solvents such as benzene and thinner. The case may become
discolored. Follow the precautionary statement when using chemical foil.
● Do not loosen or remove the screws not specified in the operation manual.
● [PTZ Cameras]
Be sure to refresh the position or restart the this product since the camera may have been
turned after maintenance. For details, please refer to the following.
→4.13.4 [Default reset] to initialize and restart the computer
Cleaning the dome cover
If the dome cover is dirty, clean it with a lens cleaning paper (for cleaning cameras and eyeglasses).
Picture shaking correction function
Depending on the installation location, the shaking correction function may not be sufficiently
effective.
Consumables
In some models, consumables are included in parts.
Refer to the web guide for consumables.
Motor operation noise
Depending on the operation speed of the pan or tilt, the operation sound may become louder. If
you are concerned about the operation sound from the auto pan, you can improve it by lowering
the set speed of the auto pan.
About the AVC Patent Portfolio License
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL USE OF A CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE
REMUNERATION TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD
("AVC VIDEO") AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE
1 Introduction
1.7 Instructions for use
7

IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM
MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
Position Refresh
[PTZ Cameras]
If the watch is used for a long time, the preset position may be misaligned. It is recommended to
set position refresh using the schedule function and periodically correct camera misalignment.
Refer to the following instructions for setting.
→4.12 [Schedule] for scheduling
In the event the Aircraft is transferred or disposed of
The contents of the information recorded on the computer and the contents of the information
recorded on the storage media used with the computer may correspond to "personal information."
When handing over the unit to a third party for disposal, transfer, repair, etc., pay careful
attention to the handling. When discarding the storage media, it is recommended to physically
destroy the data after deleting it with a PC, etc.
Connection to the Internet
The Aircraft cannot be connected directly to communication lines (including public wireless LANs)
of telecommunications carriers (mobile carriers, fixed carriers, Internet providers, etc.). When
connecting the computer to the Internet, be sure to connect via a router.
Protection of personal information
Personal information shot using the system is subject to the Personal Information Protection Law.
Handle video information properly in accordance with the law.
※Refer to the "Guidelines for the Act on the Protection of Personal Information (General Rules)"
of the Personal Information Protection Committee for examples corresponding to personal
information.
About HEVC(High Efficiency Video Coding) patents
Covered by one or more claims of the HEVC patents listed at patentlist.accessadvance.com.
About Routers
When connecting this product to the Internet and using a router, use a broadband router with a
port forwarding function (NAT, IP Mascalade). For an overview of the port forwarding feature, see
the following.
→4.11.1 Networking [Network]
Time Setting
The this product must be set to the time prior to starting operation. For the time setting, refer to
the following.
→2.1 Initial Setting
→2.2 Initial setting (Multi-directional/PTZ integrated camera)
1 Introduction
1.7 Instructions for use
8

2 Operation
2.1 Initial Setting
Administrator registration
The administrator registration screen is displayed when the camera is first accessed (or when the
camera is initialized).
Enter an administrator's user name and password to ensure that there are no mistakes. Use the
following login.
2 Operation
2.1 Initial Setting
9

・ [User name (1 to 32 characters)]
Enter an administrator username.
・Number of characters that can be entered:1 to 32 characters
・Characters that cannot be entered:Double-byte and single-byte symbols&: ; ￥
・ [Password (8 to 32 characters)]/[Retype password]
Enter the administrator's password.
・Number of characters that can be entered:8 to 32 characters
・Characters that cannot be entered:Double-byte and single-byte symbols&
2 Operation
2.1 Initial Setting
10

[Note:]
・Enter case-sensitive data.
・Use at least three of the following passwords: uppercase alphabetic characters,
lowercase alphabetic characters, numbers, and symbols.
・Configure the password so that it does not contain the user name.
[Important]
・If the set user name or password is lost, the camera must be initialized. When the
camera is formatted, all settings will be cleared. Keep the user name and password
out of the eyes of third parties. Refer to the Web Guide for the formatting
method.
・Change the password periodically.
・Do not use other cameras, devices, or other passwords.
After registering the user name and password of the administrator, the Language/Datetime
setting screen is displayed.
Language/Datetime Settings
2 Operation
2.1 Initial Setting
11

Language/Datetime Settings
・ [Menu language]
Select the first language that appears when you access the camera from the list below.
[Auto]/[English]/[Japanese]/[Italian]/[French]/[German]/[Spanish]/[Chinese]/[Russian]/
[Portuguese]
[Auto] automatically selects the languages used by the browser. If your computer is not
compatible with the language, the English language is selected.
・ [Time display format]
Select the time display method from 24h/12h.
・ [Date/time display format]
Select the date display format. If [Date/time] is set to [13:10:00 on April 1, 2021], the display
formats are as follows.
・DD/MM/YYYY: 01/04/2021 13:10:00
2 Operation
2.1 Initial Setting
12

[Important]
・If you need to set the time more accurately in system operation, use the NTP
server.
→4.11.2.3 Set up an NTP server
[Note:]
・If you want to set whether or not to display the date and time on the images, use
the [Basic] pages in the Advanced menu.
→4.5 [Basic] for basic setup of the machine
・MM/DD/YYYY: 04/01/2021 13:10:00
・DD/Mmm/YYYY: 01/Apr/2021 13:10:00
・YYYY/MM/DD: 2021/04/01 13:10:00
・Mmm/DD/YYYY: Apr/01/2021 13:10:00
・ [Date]
Click the button to set the camera date.
Click to get the date of the PC and display it.
・ [Time]
Click the button to enter the camera time.
Click to acquire the time of the PC and display it.
・ [Date/time position]
Select the position where the date and time are displayed on the image.
• [Upper left]: Displayed in the upper left corner of the window.
• [Lower left]: Displays in the lower left corner of the window.
• [Upper center]: Displayed in the center of the window.
• [Lower center]: Displays at the bottom center of the window.
• [Upper right]: Displayed in the upper right corner of the window.
• [Lower right]: Displays in the lower right corner of the window.
・ [Time zone]
Select the time zone for the camera area.
・ [Summer time(daylight saving)]
Use [In], [Out] and [Auto] to specify whether to use Daylight Saving Time. Set in the region
where Daylight Saving Time is used.
• [In] sets the time to Daylight Saving Time. [*] is displayed in the time display.
• [Out] cancels Daylight Saving Time.
• [Auto] switches to Daylight Saving Time according to the start date and time and end date
2 Operation
2.1 Initial Setting
13

settings (month, week, day of the week, and time).
・ [Start time & date] [End time & date]
When [Auto] is selected in [Summer time(daylight saving)] Setting, the start date and time of
Daylight Saving Time and the end date and time of Daylight Saving Time are set in Month,
Week, Day of Week, and Time.
Screen settings
・ [Character color]
Select the background color of the operation panels and advanced menus from the [Light]
[Dark].
・ [Operation panel layout]
Select the position of the control panel from [Right], [Left], and [Lower].
2.2 Initial setting (Multi-directional/PTZ integrated camera)
Administrator registration
The administrator registration screen is displayed when the camera is first accessed (or when the
camera is initialized).
Enter an administrator's user name and password to ensure that there are no mistakes. Use the
following login.
2 Operation
2.2 Initial setting (Multi-directional/PTZ integrated camera)
14

・ [Set to both cameras]
When the setting is performed with the checkbox checked, the [User name] and [Password]
entered into the PTZ camera are also set for the Multi-directional camera.
If you want to set up different administrator information for the PTZ camera and the
2 Operation
2.2 Initial setting (Multi-directional/PTZ integrated camera)
15
