I-Tech Bluetooth Virtual Keyboard User manual

1
Bluetooth Virtual Keyboard
For Palm OS5
User Guide v1.7

2
Table of Contents
Introduction ................................................................................. 4
G ENERAL P RODUCT D ESCRIPTION ..................................................................4
L ASER S AFETY P RECAUTION ..........................................................................4
D ISCLAIMER ..................................................................................................5
T RADEMARKS ...............................................................................................5
Getting Started ............................................................................ 6
Y OUR V IRTUAL K EYBOARD ............................................................................6
O VERVIEW ....................................................................................................6
S WITCHING O N ..............................................................................................7
Virtual Keyboard your PalmOS5 PDA/Phone and Bluetooth ... 8
I NSTALLING THE DRIVER ON YOUR P ALM OS5 D EVICE .......................................8
P REPARING YOUR KEYBOARD FOR PAIRING .....................................................9
Y OUR KEYBOARD IS NOW READY FOR PAIRING . ................................................9
P AIRING WITH YOUR DEVICE ......................................................................... 10
A PPLICATION D EMONSTRATION ....................................................................12
Exploring the VKB Driver.......................................................... 13
VKB F ORM .................................................................................................13
Battery Level...........................................................................................13
Projection intensity.................................................................................. 14
Sound Effects .........................................................................................14
P ROPERTIES F ORM ......................................................................................15
Sensitivity................................................................................................ 15
Reset to Default ......................................................................................15
Time-Outs ...............................................................................................15
A UTO R EPEAT F ORM ....................................................................................16
Enable AutoRepeat................................................................................. 16
Repeat Rate............................................................................................ 16
Initial Repeat Delay.................................................................................16
S PECIAL S HORT -C UTS F ORM .......................................................................17
T HE A BOUT F ORM .......................................................................................17
G ENERAL H ANDLING I NSTRUCTION ...............................................................18
M ICRO - SWITCH ............................................................................................ 18
G ENERAL M AINTENANCE .............................................................................18
R ESETTING THE KEYBOARD TO FACTORY SETTINGS ........................................18
P REPARING THE KEYBOARD TO BE PAIRED WITH A DIFFERENT DEVICE ..............18
Troubleshooting ........................................................................ 19

3
Specifications............................................................................ 20
Short-Cuts.................................................................................. 22

4
Introduction
Congratulations on choosing the VKB Virtual Keyboard for PalmOS5
handheld. The keyboard will allow the effortless composition of documents
and e-mails and will turn your PDA/Phone into a truly indispensable tool
whether in the office or on the go.
Please take a few minutes to review the simple operating instructions in
order to get the most out of your keyboard.
General Product Description
The Virtual Keyboard is a miniature, stand-alone accessory that emulates
the function of a standard, full-sized keyboard. The Virtual Keyboard can
connect via Bluetooth to almost any information appliance, including: PCs,
Tablet PCs, Laptops, PDAs and Smartphones, with the use of an
appropriate driver.
Laser Safety Precaution
The Virtual Keyboard device emits two laser beams. One beam (red) projects
the keyboard image, and the other beam (invisible) is used for sensing the
touched keys.
The radiation levels of both laser beams do not exceed the Accessible
Emission Limits of Class 1, as defined by the international standard IEC
60825-1 (A2) and the American standard 21 CFR 1040.10. The Virtual
Keyboard device is, therefore, a “Class 1 Laser product”.
This means that the Virtual Keyboard device is safe under reasonably
foreseeable conditions of operation.
Although the emitted laser beams are safe (as defined in the above
standard), it is highly recommended not to stare directly into laser beams.

5
Disclaimer
The manufacturer shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the furnishing,
performance or use of this material. This document contains proprietary
information, which is protected by international patent applications and
copyright. All rights reserved. No part of this document may be photocopied,
reproduced or translated without prior written consent of the manufacturer.
The manufacturer reserves the right to revise this publication and to make
changes from time to time in the contents hereof without obligation to notify
any person of such revision or change. The manufacturer also reserves the
right to change the specifications without notice.
Trademarks
PalmOS is a registered trademark of Palm Inc.
VKB Virtual Keyboard is a registered trademark of VKB Inc.
Bluetooth is a registered trademark of Bluetooth SIG.

6
Getting Started
Your Virtual Keyboard
Unpack and inspect your Virtual Keyboard. Take a few moments to
familiarize yourself with device using the diagram below.
Overview
Figure 1 – Getting to know your Virtual Keyboard
Before using your Virtual Keyboard:
•Ensure that you remove all protection materials including the
protection sheet on the laser windows.
•Your Virtual Keyboard will need to be charged for at least 2
hours.
Power Key
Charging
Socket
Status indicator
(LED)
Reset
button
Keyboard projection window
Keyboard sensing
receiver window

7
Switching On
Place the Virtual Keyboard on a flat surface with the Keyboard projection
and sensing windows facing you. To switch it on press the On/Off button,
located on the upper-left hand side.
Once the unit is switched on an image of a keyboard is projected on to the
surface. Notice that the keyboard image is the basic English keyboard,
including 4 Arrow keys, 1 Control, 2 Shift keys, 1 Alt and a VKB dedicated
Fn function key.
A two-color LED located at the top of the unit indicates the current status of
the Virtual Keyboard, where:
Colour Status/Cause Action
Blinking
Blue
Virtual Keyboard is
ready to pair to a
Bluetooth device
Long Flash
Blue
Virtual Keyboard is
paired to a Bluetooth
device
Blinking
Red
Virtual Keyboard’s
battery is low.
Recharge the
Virtual Keyboard
Solid Red The area of the
projected keyboard is
exposed to direct
sun-shine or some other
source of direct light.
Move the Virtual
Keyboard to a
shaded location
Table 1 – Functional Status Indicator

8
Virtual Keyboard your PalmOS5 PDA/Phone and Bluetooth
The Virtual Keyboard (VKB) is equipped with Bluetooth, a short-ranged
radio communications technology which allows the device to communicate
with your PalmOS5 PDA/Phone up to 10 meters away without the need for
a physical connection.
As with all Bluetooth devices, to connect with your PalmOS5 PDA/Phone
you will need to do the following:
Pair your PalmOS device with the virtual keyboard…
…open the VKB Driver to set up a connection…
…and connect.
The first time you use your Virtual Keyboard with a PalmOS5 device you will
also need to install some software, called a driver, on the PalmOS5 device.
Installing the driver on your PalmOS5 Device
1. Install the Palm Quick Install program that is provided with
your PalmOS device.
2. Insert the Bluetooth Virtual Keyboard & User Guide Disk into a
CD-ROM drive on your computer. (The CD should run
automatically however if it does not start by itself, please open
the CD and run setup.exe)
3. Select the PalmOS5 device, which matches yours.

9
4. Select Install Software and follow the onscreen instructions
to install the software onto your PalmOS5 device.
5. The next time you perform a HotSync the VKB Driver will be
installed on your PalmOS5 device.
Preparing your keyboard for pairing
Place the Virtual keyboard on a flat surface and turn it on. The blue LED at
the top should flash at about once a second. This signifies that the Virtual
Keyboard is currently “unpaired” with any device. If this is not the case,
please see “Resetting the Device for Bluetooth Pairing” on page 18.
Your keyboard is now ready for pairing.

10
Pairing with your device
1. Tap the Bluetooth icon on your PalmOS5 PDA/Phone
2. Tap the On button
3. Tap the Prefs or Setup Devices button
4. Tap the Trusted Devices button
Ensure the VKB is in paring mode
1. Tap Add Device
2. Select VKB Keyboard and tap OK
3. Listen for the “beep” on the Virtual Keyboard, then, using the
keyboard projected by the Virtual Keyboard enter a passkey of
between 1 and 8 numbers on the projected keyboard and press
return [].
4. Repeat the passkey on the Palm device and tap OK
5. Tap the Home button and tap the VKB program.
6. Open the Menu and select Connections from the list.
Figure 2 – Select Connection Window
7. Select Bluetooth from the drop down list.
8. Open the Menu and select VKB, then select Enable Keyboard

11
Figure 3 – Virtual Keyboard Driver Dialogue
9. Select Yes on the Bluetooth Setup dialogue box (select No on all
subsequent connections).
10. Select the VKB Keyboard from the list and tap OK
The blue LED will go on to show your successful connection. Your Virtual
Keyboard is now connected to the PalmOS5 device.
You are now ready to use the keyboard.

12
Application Demonstration
Open any application and start typing.
Figure 4 - Memo editing demonstration screen

13
Exploring the VKB Driver
Go to the Home Page, locate the software driver on your PalmOS5
PDA/phone.
Figure 5 - Screen for VKB Application Icon
VKB Form
Open the VKB page by clicking on the VKB icon.
Figure 6 - VKB Main Form
Battery Level
The battery level, displays the current level of the battery in the Virtual
Keyboard. Use this indicator to check when the Virtual Keyboard required
charging.

14
Projection intensity
You may adjust the intensity of the projected keyboard to so that it is visible
in different light conditions. You may select from between Low, Medium and
High settings.
Sound Effects
The Virtual Keyboard can be set up to emit a “key-click” whenever you
press a key on the projected virtual keyboard. Using the checkboxes you
can set the key-click to be emitted by your PDA/phone and/or the Virtual
Keyboard.
Move between this and the other pages of the VKB driver using the Menu
Figure 7 - VKB Menu Details

15
Properties Form
Figure 8 - VKB Properties Form
Sensitivity
You can adjust the sensitivity of the Virtual Keyboard’s key-press detection.
The default value for this parameter is 10, however you may need to adjust
this for optimal use. If you are experiencing missed key presses, try raising
the sensitivity setting. If you are experiencing extra key presses, try
lowering the sensitivity.
Reset to Default
Pressing the Reset To Default button will cause the Virtual Keyboard and
driver to reset the sensitivity to the keyboard’s factory settings.
Time-Outs
To conserve the battery of the Virtual Keyboard it can be set to switch off
automatically if it has not been used for a while. There are two separate
settings which may be adjusted to suit you. Projection Timeout switches off
the projected keyboard. Auto Timeout switches off the whole device. When
a period exceeding the Projection Timeout has elapsed without typing on
the keyboard, the projection will automatically turn off. Pressing anywhere
will cause the keyboard to be projected again. When the Auto Time-Out has

16
elapsed the Virtual Keyboard will switch off. If this occurs, press the button
on the Virtual Keyboard to turn it on again.
AutoRepeat Form
Figure 9 - VKB AutoRepeat Form
The AutoRepeat feature employed by the VKB Driver allows the system to
automatically repeat a key that is being pressed.
Enable AutoRepeat
Selecting the Enable AutoRepeat checkbox switches the AutoRepeat
function on and off.
Repeat Rate
The rate at which the key depression occurs is set using the Repeat Rate
slider.
Initial Repeat Delay
The period before the key press is repeated can be set between 1 and 4
seconds using Initial Repeat Delay drop down box.

17
Special Short-Cuts Form
The Short-Cuts form, displays the Virtual Keyboard’s special combination
keys, which may be accessed without exiting the application you may be
working with.
The About Form
The About Form displays the Virtual Keyboard Driver’s software version as
well as the software version of the Virtual Keyboard. If you have
encountered, and are reporting a problem, please relay information
displayed on this page.
Remarks : the displayed screen is for reference, for detail please browse
i.Tech website : http://www.itechdynamic.com

18
General Handling Instruction
Micro-switch
The device is equipped with a micro-switch which disables the Virtual
Keyboard lasers when the device is picked up. This is a safety measure. Do
not attempt to override this micro-switch.
General Maintenance
•Avoid touching the keyboard sensing receiver window.
•Never touch the keyboard projection element.
•Avoid exposing the keyboard to moisture or extreme
temperatures.
•Do not disassemble or try to touch the inside of the device.
•Do not attempt to charge the device with a different charger
than the one provided by VKB.
•If the windows become dirty clean only with a soft, lint free dry
cloth. Do not use any solvents or cleaners.
Resetting the keyboard to factory settings
•Turn the keyboard on and gently insert the end of a sharp object into
the reset hole found under the rubber flap on the right side of the
keyboard. Press for about half a second and then remove the clip.
•After about 2 seconds, the keyboard will emit a short “beep” and the
LED will flash blue.
•Pick up the keyboard and wait for it to turn off,
•Place the Virtual Keyboard back on the flat surface and turn it on.
•The Virtual Keyboard is now ready for pairing.
Preparing the keyboard to be paired with a different device
Once the keyboard has been paired and connected to a host device, to
pair the keyboard with a different host device, turn the keyboard on, and on
the projected image press the keys 

+Fn+B simultaneously for 3
seconds. The keyboard will emit a short beep and the LED will flash blue to
indicate it is ready for pairing with another device.

19
Troubleshooting
Problem Possible cause Corrective action
My keyboard is connected,
but little or no keys are
being detected
The detection sensitivity is to low. Raise the detection sensitivity setting and try again.
When typing, multiple
and/or erroneous keys are
displayed in addition to
those I have pressed.
The detection sensitivity setting is too
high.
Lower the detection sensitivity setting and try again.
Device is not resting on a firm flat
surface
Reposition device to a firm surface.
My device doesn’t emit
sounds when pressing a
key
Sound affects, on your PalmOS5
device, have not been enabled.
Enable Sound affects on the device, Preferences System
Sound.
My keyboard is turned on
but no image appears.
Device is not charged Charge device
Device is overheated Move device to a cooler location and wait a few minutes
Device is not resting on a firm flat
surface
Reposition device to a firm surface and verify that the
micro-switch is fully depressed.
Micro-switch stuck Clean micro-switch

20
Specifications
Light source Red diode laser
Keyboard layout 63 key / full sized QWERTY layout
Keyboard size 295 x 95mm projected keyboard size
Keyboard position 60mm from VKB unit
Projection surface Non-reflective, opaque flat surface
Keyboard
Projector
Visibility Good contrast up to 600 lux ambient
illumination
Ambient
illumination
Works under all standard indoor
illuminations up to 600 lux
Detection rate Up to 400 characters per minute
Detection
algorithm
Multiple keystroke support
Effective
keystroke
Approximately 2mm
Keystroke
Sensor
Operating surface Any firm flat surface with no protrusions
greater than 1mm
Bluetooth
Specification
Bluetooth v1.1 class 2
Bluetooth Profile
Supported
HID and SPP
Range of
Frequency
2.4GHz Spectrum
Transmission
range
9m
Bluetooth
Number of
supported
passkeys
5
