IAI CV-M77 User manual

RGB Color
Progressive Scan Camera
CV-M77
Operation Manual
Camera: Revision B
Manual: Version 2.1
M77BmanMay11.doc
JPT 11-05-04

CV-M77
- 1 -
Table of Contents
1. General......................................................................................................... 2
2. Standard Composition ....................................................................................... 2
3. Main Features ................................................................................................. 2
4. Locations and Functions..................................................................................... 3
5. Pin Assignment................................................................................................ 4
5.1. 12-pin Multi-connector (DC-IN/Trigger) ....................................................................... 4
5.2. 6 pin Multi-connector (RS-232C/Trigger)...................................................................... 4
5.3. 9 pin D-sub connector (RGB/SYNC) ............................................................................ 5
5.4. Principle diagram for input and output jumpers............................................................. 5
5.4. Input output Circuits ............................................................................................. 6
6. Functions and Operations ................................................................................... 7
6.1. Basic operation modes ........................................................................................... 7
6.1.1. High frame rate. ........................................................................................... 7
6.2. Input/Output of HD/VD Signal .................................................................................. 8
6.2.1. Input of External HD/VD signals ......................................................................... 8
6.2.2. Output of Internal HD/VD signals ....................................................................... 8
6.3. Continuous operation............................................................................................. 9
6.4. Trigger modes ....................................................................................................10
6.4.1. Edge Pre-select Trigger ..................................................................................11
6.4.2. Pulse Width Control Trigger.............................................................................12
6.4.3. Frame Delay Readout EPS ...............................................................................13
6.4.4. Frame Delay Readout PWC ..............................................................................14
6.4.5. Long Time Exposure ......................................................................................15
6.5. Other functions...................................................................................................16
6.6. Request functions................................................................................................17
6.7. Save and Load functions ........................................................................................17
7. Configuring the Camera ................................................................................... 18
7.1. Setting by Switch and Jumper .................................................................................18
7.1.1 Rear Switch .................................................................................................18
7.1.2. Internal Switch setting ...................................................................................18
7.1.3. Jumper settings ...........................................................................................20
7.1.4. Jumper table ..............................................................................................21
7.2. RS-232C control ..................................................................................................22
7.3. Command Protocol...............................................................................................23
8. Camera Control Tool for CV-M77......................................................................... 24
8.1. Control Tool Windows ...........................................................................................24
8.2. Camera Control Tool Interface ................................................................................25
7.3.3. Using the Camera Control Tool .........................................................................27
9. External Appearance and Dimension .................................................................... 28
10 Specifications............................................................................................... 29
10.1. Specification table .............................................................................................29
10.2. Spectral sensitivity .............................................................................................30
11. Appendix ................................................................................................... 30
11.1. Precautions ......................................................................................................30
11.2. Typical Sensor Characteristics................................................................................30
11.3. References.......................................................................................................30
12. Users Record ............................................................................................... 31

CV-M77
- 2 -
1. General
The CV-M77 camera is a compact RGB color progressive scan camera designed for automated
imaging applications. The 1/3" CCD sensor with square pixels and primary mosaic filter offers a
superb image quality and the built-in DSP assures high color reproduction.
The camera incorporates several triggered modes and various shutter functions to capture
moving objects and to control the light. All camera mode settings can be controlled via an RS-
232C interface or by the switch at the rear of the camera.
The CV-M77 camera is ideal for demanding color applications such as color inspection, gauging
and color printing.
Revision B is updated with the high framerate read out mode.
The latest version of this manual can be downloaded from: www.jai.com .
The latest version of the Camera Control Tool software can be downloaded from: www.jai.com .
2. Standard Composition
The standard camera composition consists of the camera main body.
3. Main Features
• New 1/3” full frame progressive scan interline transfer CCD
• RGB Primary color mosaic filter(Bayer) and DSP for excellent color reproduction
• 1034 (h) x 779 (v) 4.65µm square pixels (1028 x 768 pixels read out) – XGA format
• 25 full frames 1028 (h) x 770 (v) RGB video output per second
• Fast frame readout of every third line in the full frame
• 74 fps 1028 (h) x 242 (v) RGB video output
• Internal, external HD/VD or random trigger synchronization
• Edge pre-select and pulse width controlled external trigger modes
• Programmable shutter speed from 1.5 H to 791 H
• Long time exposure with external VD pulse interval
• Frame delay readout for edge pre-select and pulse width controlled shutter
• Exposure enable EEN, write enable WEN and pixel clock output
• Short ASCII commands for fast mode setup via serial port
• Setup by Windows 98/NT/2000/XP software via RS 232C

CV-M77
- 3 -
4. Locations and Functions
1 Lens mount of C-mount type. *1)
2 1/3" CCD sensor with primary color mosaic filter. (Bayer filter).
3 R Gain Potentiometer. To adjust Red gain level manually.
4 B Gain Potentiometer. To adjust Blue gain level manually.
5 MG Gain Potentiometer. To adjust Master gain level manually.
6 6 pin connector for RS 232C signals, input of ext. trigger pulse and WEN output.
7 12 pin connector for +12V DC power and HD/VD input/output.
8 9 pin D-Sub connector for RGB video output, video sync. and pixel clock output.
9 Switch to set shutter speed and function mode.
10 Screw holes for tripod mounting plate (optional plate)
11 4 M3 mounting threads. *2)
*1) Note: Rear protrusion on C-mount lens must be less than 6mm (0.24-inch approx.)
*2) Note: Notice depth of thread is only 5mm. Too long screws may harm inside electronics.
Fig. 1. Locations

CV-M77
- 4 -
5. Pin Assignment
5.1. 12-pin Multi-connector (DC-IN/Trigger)
Type: HR10A-10R-12PB-01
(Hirose) male. Pin no. Signal Remarks
1 GND
2 +12 V DC input
3 GND
4 Iris video output Video for lens iris control. (With comp sync.)
Can only be used in normal continuous mode.
5 GND
6 HD input/output SW-S301.1 “ON” for 75Ωtermination,
SW-S303.1 “OFF” for HD output
7 VD input/output SW-S301.2 “ON” for 75Ωtermination,
SW-S303.2 “OFF” for VD output
8 GND
9 NC/Pclk out PCLK out: JP305 “short”, JP306 “open”
Do not output Pclk if not used!
10 GND/NC/WEN out NC: JP309 and JP310 “open”.
GND: JP308 “open” JP309 and JP310 “short”
11 Trigger input
/NC/+12V
NC: JP401 and JP301* “open”.
+12V DC JP401 “short” and JP301* “open”
12 GND
(Seen from rear of camera.)
3
4
5
6
7
8
9
10
11 12
1
2
Fig. 2. 12-pin connector.
Notes:
Factory settings in bold italic
*1) Signals on pin no. 4 and 6 can be changed by jumpers.
See “7. Configuring the Camera” for more information
*2) Do not input ext. VD in trigger modes
*)JP301 is “short” by a capacitor
5.2. 6 pin Multi-connector (RS-232C/Trigger)
Type: HR10A-7R-6PB (Hirose) male.
(Seen from camera rear.)
Fig. 3. 6-pin connector
Pin no. Signal Remarks
1 TXD out RS-232C
2 RXD in RS-232C
3 GND
4 NC/GND GND if JP402 short. *1)
5 Ext. Trig input
6 EEN out
/WEN out WEN out if JP312 open, JP311 short. *1)
Notes:
Factory settings in bold italic
*1) Signals on pin no. 4 and 6 can be changed by jumpers.
See “7. Configuring the Camera” for more information.
1
2
34
5
6

CV-M77
- 5 -
5.3. 9 pin D-sub connector (RGB/SYNC)
Pin No. Signal Remarks
1 NC/VD in VD input: JP303 “open” and JP304 “short”
2 GND
3 R output
4 G output
/Sync on G
Sync. on G: SW302-3 “ON” or SY=1
5 B output
6 HD input
/HD output
HDinput: SW303-1 “ON”.
HDout: SW303-1 “OFF”
7 Sync output
/WEN output
WEN output: SW302-4 “ON” or WS=1
8 GND
9 NC/Pclk PCLK output: JP305 “open” and JP306 “short”
Do not output Pclk if not used!
Fig. 4. 9-pin connector
Notes:
Factory settings in bold italic
*1) Signals on pin no.1, 4, 6, ,7 and 9 can be changed by jumpers.
See “7. Configuring the Camera” for more information.
5.4. Principle diagram for input and output jumpers
The below diagram shows the input output circuits with jumpers for alternative pin connections.
It can be useful for control of jumpers and connections. Jumpers are shown in factory settings.
GND
JP305
JP402
JP401
NC/GND 4/6
NC/Pclk 9/12
NC/Trig/+12v 11/12
NC/Pclk 9/9
Trig 5/6
VDin/VDout 7/12
NC/VDin 1/9
EEN/W EN 6/6
HDin/VDout 6/12
HDin 6/9
WEN/GND 10/12
+12VGND
JP306
JP301
JP304
JP303
JP307
JP312
JP311
JP308
JP309
JP310
Pclk
Trigger
VD in
HD in
HD out
VD out
EEN
WEN
Connectors
Camera circuit
SW
303-1
SW
303-2
75
75
75
SW 301-2
SW301-1
SW301-3
pin#/Connector
/6. 6pin HR
/12. 12pin HR
/9. 9pin sub-D
Jumper and switch
in factory setting
JP302
Fig. 5. Input and output jumpers and signals

CV-M77
- 6 -
5.4. Input output Circuits
In the following schematic diagrams the input and output circuits for video and timing signals
are shown. For alternative connections refer to “7. Configuring the Camera”. Jumper settings
are shown as for factory default.
RGB video output
The video output signal is a RGB video signal.
The signal level is 0.7Vpp from 75Ω. The video
output is DC coupled.
Composite sync. is selectable on the green
video signal via software or the internal switch
302-3. The sync. signal level is 0.3Vpp.
Iris video output
A video signal for lens iris control is found on
pin 4. 12-pin connector. The signal is with
composite sync. It is ac coupled from a 75Ω
source. It can only be used for iris control in
normal continuous mode.
Fig. 6. Video outputs
Trigger input
The trigger input is AC coupled. To allow a
long wide pulse width, the input circuit is a
flip-flop, which is toggled by the negative and
positive differentiated spikes cause buy the
falling and rising edge. The input signal level
is 4V ±2V. The trigger input impedance is 1.2
kΩor 75Ωselectable via the internal switch
S301-3.
Fig. 7. Trigger input
HD and VD input
The HD and VD input circuit can be 75Ω
terminated via the internal switch S301-1 and
S301-2.
The input signal level is 4V ±2V.
Fig. 8. HD and VD inputs
HD, VD, PCLK, WEN and EEN output
The output circuits for these signals are 75Ω
complementary emitter followers. The single
circuit delivers a TTL signal. The output level
≥4 V from 75Ω(no termination).
Fig. 9. HD, VD, PCLK and EEN output
DC level with
75 Ωtermination
GND
75 Video
Output 400 mV
DC level with
75 Ωtermination
GND
75 Video
Output
GND
75 Video
Output 400 mV
GND
75 Iris
Video
GND
75 Iris
Video

CV-M77
- 7 -
6. Functions and Operations
6.1. Basic operation modes
Apart from the standard continuous operation mode, the CV-M77 features four external
triggering modes and a long time exposure mode. In all modes the camera can be synchronized
to an external sync. The shutter time can be selected from 12 fixed steps, or from 788 steps
with 1H resolution. In triggered mode it can also be controlled by the trigger pulse width.
The frame delayed readout can operate in either edge pre-selected trigger, or pulse width
controlled shutter mode.
Switches can set most modes and functions locally. All modes and functions can be remote
controlled by RS-232C control.
Alternative connections for input and output signals can be done by internal jumpers.
For details: refer to “7. Configuring the Camera”.
6.1.1. High frame rate.
From revision C, the CV-M77 camera has a new readout mode. It is the high frame rate mode.
Here only every third line is read out. The 2 lines between are dumped. In this way the Bayer
RGB mosaic pattern is unchanged. The DSP interpolation algorithm for RGB color output can still
be used.
The figures below shows the CCD sensor in normal mode and high frame rate mode. In high
frame rate, the vertical ccd register is clocked with 3 times higher rate. But only the signals
from every third line is transferred to the horizontal ccd register for read out. Signals from the
lines between are dumped.
The horizontal resolution is unchanged, but the vertical resolution is reduced to 1/3.
The advantages are:
Frame rate 3 times higher
The image is sampled from the whole sensor area
Horizontal resolution unchanged
Xsub
Horizontal ccd register
R
G
B
Video
coder
Vertical ccd register
Shutter
Photo diode
(pixel)
Xsg1
G
G
G
G
G
G
G
G
G
R
R
R
R
R
R
B
B
B
Normal V-clock
High frame rate V-clock
Xsub
Horizontal ccd register
Video
coder
R
G
B
Vertical ccd register
Shutter
Photo diode
(pixel)
Xsg1
Normal V-clock
G
G
G
G
G
G
G
G
G
R
R
R
R
R
R
B
B
B
Xsub
Horizontal ccd register
R
G
B
Video
coder
Vertical ccd register
Shutter
Photo diode
(pixel)
Xsg1
G
G
G
G
G
G
G
G
G
R
R
R
R
R
R
B
B
B
Normal V-clock
High frame rate V-clock
Xsub
Horizontal ccd register
R
G
B
Video
coder
Vertical ccd register
Shutter
Photo diode
(pixel)
Xsg1
G
G
G
G
G
G
G
G
G
R
R
R
R
R
R
B
B
B
Normal V-clock
High frame rate V-clock
Xsub
Horizontal ccd register
Video
coder
R
G
B
Vertical ccd register
Shutter
Photo diode
(pixel)
Xsg1
Normal V-clock
G
G
G
G
G
G
G
G
G
R
R
R
R
R
R
B
B
B
Xsub
Horizontal ccd register
Video
coder
R
G
B
Vertical ccd register
Shutter
Photo diode
(pixel)
Xsg1
Normal V-clock
G
G
G
G
G
G
G
G
G
R
R
R
R
R
R
B
B
B
CCD with normal readout. CCD with high frame rate readout.

CV-M77
- 8 -
6.2. Input/Output of HD/VD Signal
6.2.1. Input of External HD/VD signals
This setting is factory pre-set. The video output is synchronized with external HD/VD signals if
applied. If no ext. HD signal is input, the camera will switch to the internal X-tal controlled HD
sync. If no ext. VD is connected, the camera will continue with its internal VD.
For details: refer to “7. Configuring the Camera”.
To use this mode:
Set function: SW 303.1 and 303.2 to ON for external HD/VD input. Factory default.
SW 301.1 and 301.2 to OFF for TTL level for HD/VD. Factory defaults
SW 301.1 and 301.2 to ON for 75 Ωtermination of HD/VD..
Input: Ext. HD in on pin 6 on 12-pin connector. 4.0 Vp-p ±2.0V.
Ext. VD in on pin 7 on 12-pin connector. 4.0 Vp-p ±2.0V.
Important notes on using this mode
External sync system should follow the camera scanning system.
The ext. HD/VD phase relations should follow as shown in fig. 10.
Fig. 10. External VD and HD phase relation
6.2.2. Output of Internal HD/VD signals
Internal HD/VD signals can be output for synchronizing external equipment.
For details: refer to “7. Configuring the Camera”.
To use this mode:
Set function: SW 303.1 and 303.2 to OFF for internal HD/VD output.
Output: Int. HD out on pin 6 on 12-pin connector. 4.0 Vp-p from 75Ωsource.
Int. VD out on pin 7 on 12-pin connector. 4.0 Vp-p from 75Ωsource.

CV-M77
- 9 -
6.3. Continuous operation
This mode is used for applications that do not require asynchronous external trigger, but run in
continuous operation.
Mode setting and all other settings can be done via RS 232C control if rear switch SW1-10 is ON.
Mode setting and some other settings can be done by switch if rear switch SW1-10 is OFF.
For details: refer to “7. Configuring the Camera”.
To use this mode: RS SW1-
Set function: Trigger mode to “Normal” TR=0 5, 6, 7 OFF
Shutter to “Normal” or “Programmable” SM=0, SM=1
“Shutter speed” SH=0 through 11 1, 2, 3, 4
“Programmable exposure” PE=3 through 791
Other functions
Input: Ext. HD in on pin 6 on 12-pin connector. 4.0 Vp-p ±2.0V. (If used).
Ext. VD in on pin 7 on 12-pin connector. 4.0 Vp-p ±2.0V. (If used).
Important notes on using this mode
External sync system should follow the camera scanning system.
The ext. HD/VD phase relations should follow as shown in fig. 10.
1028 (h) effective pixels in continuous mode. 1016 (h) in trigger modes.
1ck = 40ns
Note! 1016ck in trigger mode
s
Fig. 11. Horizontal timing
Fig. 12. Vertical timing

CV-M77
- 10 -
6.4. Trigger modes
The CV-M77 camera features 4 external triggering modes:
1 Edge Pre-Select. (EPS). Asynchronous reset and exposure start by an ext. trigger pulse.
2 Pulse Width Control. (PWC). Exposure control by the low period of the ext. trigger pulse.
3 Readout Delay EPS. Triggered EPS exposure. Readout controlled by external VD signal.
4 Readout Delayed PWC. Triggered PWC exposure. Readout controlled by external VD signal.
These external triggering modes operate with H non-reset. In H non-reset, the exposure will be
synchronized to the internal HD, and the exposure will start at the first HD after the negative
going edge of the trigger. Refer to fig. 13. The exposure stops 0.5 H after the last HD pulse.
To avoid the <1H exposure jitter caused by this delay, it is recommended to synchronize the
external trigger to HD as shown in fig. 14.
The trigger input can be TTL level or 75 ohm terminated by setting the specific S301 switch on
the PK 8308 board to OFF or ON (see switch settings). When 75 ohm terminated the signal input
level is 4.0 Vp-p ±2.0V.
Mode setting and all other settings can be done via RS 232C control if rear switch SW1-10 is ON.
Mode setting and some other settings can be done by switch if rear switch SW1-10 is OFF.
For details: refer to “7. Configuring the Camera”.
Important notes on using this mode
Number of effective pixels per line in trigger modes are 1016 (h).
Trigger
Exposure
EDGE PRE-SELECT
shutter time Read out
int. HD
H non-reset
Fig. 13. H non –reset trigger
Fig. 14. External trigger and HD phase relation

CV-M77
- 11 -
6.4.1. Edge Pre-select Trigger
This trigger mode operates in H non-reset mode. In H non-reset mode the exposure will start at
the first internal HD after the trigger. The trigger input should be longer than or equal to 2 HD
(102 µsec.). The external trigger pulse initiates the capture, and the exposure time
(accumulation time) is governed by the fixed shutter speed set up by the rear panel DIP-switches
or via RS-232C control. The EEN pulse indicates the actual exposure time. The resulting video
signal will start to be read out after the selected shutter time. The WEN pulse indicates the start
of valid video signal. Refer to timing charts for details. A new trigger pulse must not be applied
before the video read out has finished. If the camera is synchronized to an external HD signal,
there are some requirements to the phase between the ext. HD and the Ext. trigger. The falling
edge of the trigger should be less than 8 µsec before the falling edge of the ext. HD and less
than 2 µsec after the falling edge of the ext. HD (see fig. 14.). Otherwise the jitter will be too
high.
Mode setting and all other settings can be done via RS 232C control if rear switch SW1-10 is ON.
Mode setting and some other settings can be done by switch if rear switch SW1-10 is OFF.
For details: refer to “7. Configuring the Camera”.
To use this mode: RS SW1-
Set function: Trigger mode to “Edge Pre-Select” TR=1 5 ON, 6, 7 OFF
Shutter to “Normal” or “Programmable” SM=0, SM=1
“Shutter speed” SH=0 through 11 1, 2, 3, 4
“Programmable exposure” PE=3 through 791
Polarity and other functions
Input: Ext. trigger in on pin 5 on 6-pin con. (Or 11 on 12 pin). 4.0 Vp-p ±2.0V.
Ext. HD in on pin 6 on 12-pin connector. 4.0 Vp-p ±2.0V. (If used).
Important notes on using this mode
• The start of exposure will start synchronized to the internal H signal. The start may be
shifted max 1H. To avoid this shift (1H jitter), synchronize the camera to an external HD
and make sure that the trigger pulse aligns to the HD as shown in fig. 14.
• The trigger pulse width should be >2H to <2000H.
• A new trigger must not be applied before WEN is high.
Fig. 15. Vertical timing for Edge Pre-select

CV-M77
- 12 -
6.4.2. Pulse Width Control Trigger
This trigger mode where the length of the trigger pulse determines the exposure time operates
in H non-reset mode. In H non-reset mode the trigger pulse and the HD signal are synchronized.
The exposure will start at the first HD pulse after the falling edge of the external trigger signal.
The exposure ends 0.5 H after the HD following the rising edge of the external trigger signal.
The trigger pulse must be longer than >1H (51µsec) and shorter than 2000 H. To avoid jitter the
camera should be synchronized to an external HD. There are some requirements to the phase
between the ext. HD and the Ext. trigger. The falling edge of the trigger should appear in the
interval less than 8 µsec before the falling edge of the ext. HD and less than 2 µsec after the
falling edge of the ext. HD and the rising edge off the trigger should be fall in the interval 8 µsec
before the rising edge of the ext. HD and 2 µsec after rising edge of the ext. HD. (See figure
14.).
The EEN pulse indicates the actual exposure time.
The resulting video signal will start to be read out after the rising edge of the external trigger
signal. The WEN pulse indicates the start of valid video signal. Refer to timing charts for details.
A new trigger pulse must not be applied before the video read out has finished.
Mode setting and all other settings can be done via RS 232C control if rear switch SW1-10 is ON.
Mode setting and some other settings can be done by switch if rear switch SW1-10 is OFF.
For details: refer to “7. Configuring the Camera”.
To use this mode: RS SW1-
Set function: Trigger mode to “Pulse Width Control” TR=2 1, 2 ON, 3 OFF
Polarity and other functions
Input: Ext. trigger in on pin 5 on 6-pin con. (Or 11 on 12 pin). 4.0 Vp-p ±2.0V.
Ext. HD in on pin 6 on 12-pin connector. 4.0 Vp-p ±2.0V. (If used).
Important notes on using this mode
• The start of exposure will start synchronized to the internal H signal. The start may be
shifted max 1H. To avoid this shift (1H jitter), synchronize the camera to an external HD
and make sure that the trigger pulse aligns to the HD as shown in fig. 14.
• The trigger pulse width should be >1H to <2000H.
• A new trigger must not be applied before WEN is high.
Fig. 16. Vertical timing for Pulse Width Control

CV-M77
- 13 -
6.4.3. Frame Delay Readout EPS
This trigger mode operates in H non-reset mode. In H non-reset mode the exposure will start at
the first internal HD after the trigger. The trigger input should be longer than or equal to 2 HD
(102 µsec.). The external trigger pulse initiates the capture, and the exposure time
(accumulation time) is governed by the fixed shutter speed set up by the rear panel DIP-switches
or via RS-232C control. The EEN pulse indicates the actual exposure time.
The resulting video signal will first start to be read out after the input of an external VD signal.
The readout delay should not be to long due to visible dark current noise generated in the CCD
sensor. The WEN pulse indicates the start of valid video signal. Refer to timing charts for details.
A new trigger pulse must not be applied before the video read out has finished.
If the camera is synchronized to an external HD signal, there are some requirements to the
phase between the ext. HD and the Ext. trigger. The falling edge of the trigger should be less
than 8 µsec before the falling edge of the ext. HD and less than 2 µsec after the falling edge of
the ext. HD (see fig. 14.). Otherwise the jitter will be too high.
Mode setting and all other settings can be done via RS 232C control if rear switch SW1-10 is ON.
Mode setting and some other settings can be done by switch if rear switch SW1-10 is OFF.
For details: refer to “7. Configuring the Camera”.
To use this mode: RS SW1-
Set function: Trigger mode to “Fame Delayed readout EPS” TR=3 1 ON, 2 OFF, 3 ON
Shutter to “Normal” or “Programmable” SM=0, SM=1
“Shutter speed” SH=0 through 11 1, 2, 3, 4
“Programmable exposure” PE=3 through 791
Polarity and other functions
Input: Ext. trigger in on pin 5 on 6-pin con. (Or 11 on 12 pin). 4.0 Vp-p ±2.0V.
Ext VD on pin 7 on 12 pin con. (Or 1 on 9 pin ). 4.0 Vp-p ±2.0V.
Ext. HD in on pin 6 on 12-pin connector. 4.0 Vp-p ±2.0V. (If used).
Important notes on using this mode
• The start of exposure will start synchronized to the internal H signal. The start may be
shifted max 1H. To avoid this shift (1H jitter), synchronize the camera to an external HD
and make sure that the trigger pulse aligns to the HD as shown in fig. 14.
• The trigger pulse width should be >2H to <2000H.
• External sync system should follow the camera scanning system.
• A new trigger must not be applied before WEN is high.
Fig. 17. Vertical timing for Frame Delay readout EPS

CV-M77
- 14 -
6.4.4. Frame Delay Readout PWC
This trigger mode operates in H non-reset mode. In H non-reset mode the trigger and HD is
synchronized. The exposure will start at the first HD pulse after the falling edge of the external
trigger signal. The exposure ends 0.5 H after the HD following the rising edge of the external
trigger signal. The trigger pulse must be longer than >1H. To avoid jitter, the camera should be
synchronized to an external HD. There are some requirements to the phase between the ext. HD
and the Ext. trigger. The falling and rising edge off the trigger should be within 8 µsec. before
the falling and rising edge of the ext. HD pulse and not later than 2µsec after the falling and
rising edge of the HD pulse (see fig. 14.). The EEN pulse indicates the actual exposure time.
The resulting video signal will first start to be read out after the input of an external VD signal.
The readout delay should not be to long due to visible dark current noise generated in the CCD
sensor. The WEN pulse indicates the start of valid video signal. Refer to timing charts for details.
A new trigger pulse must not be applied before the video read out has finished.
Mode setting and all other settings can be done via RS 232C control if rear switch SW1-10 is ON.
Mode setting and some other settings can be done by switch if rear switch SW1-10 is OFF.
For details: refer to “7. Configuring the Camera”.
To use this mode: RS SW1-
Set function: Trigger mode to “Frame Delayed readout PWC” TR=5 1, 2, 3 ON
Polarity and other functions
Input: Ext. trigger in on pin 5 on 6-pin con. (Or 11 on 12 pin). 4.0 Vp-p ±2.0V.
Ext VD on pin 7 on 12 pin con. (Or 1 on 9 pin ). 4.0 Vp-p ±2.0V.
Ext. HD in on pin 6 on 12-pin connector. 4.0 Vp-p ±2.0V. (If used).
Important notes on using this mode
• The start of exposure will start synchronized to the internal H signal. The start may be
shifted max 1H. To avoid this shift (1H jitter), synchronize the camera to an external HD
and make sure that the trigger pulse aligns to the HD as shown in fig. 14.
• The trigger pulse width should be >2H to <2000H.
• External sync system should follow the camera scanning system.
• A new trigger must not be applied before WEN is high.
Fig. 18. Vertical timing for Frame Delay readout PWC

CV-M77
- 15 -
6.4.5. Long Time Exposure
The exposure time is the interval between 2 ext. VD pulses sent to the VD input of the camera.
The exposure starts after input of the first ext. VD pulse, and ends after the next input of the
ext. VD pulse, which again starts a new exposure.
The long time exposure is a continuous process where each external VD pulse will synchronize
the camera, stop on exposure, start a new exposure and read out the previous accumulated
signal. The exposure can be selected in intervals of complete vertical timing periods (=792H)
This long time exposure mode operates in H non-reset mode. In H non-reset mode the external
VD signal and the internal HD signal are synchronized. The exposure will start at the first HD
pulse after the falling edge of the external trigger signal. See figure 14. for the phase
relationship between ext. HD and ext. VD pulses.
Mode setting and all other settings can be done via RS 232C control if rear switch SW1-10 is ON.
This mode can not be set by switch!
For details: refer to “7. Configuring the Camera”.
To use this mode: RS
Set function: Trigger mode to “Long Time Shutter” TR=4
Polarity and other functions
Input: Ext VD on pin 7 on 12 pin con. (Or 1 on 9 pin ). 4.0 Vp-p ±2.0V.
Ext. HD in on pin 6 on 12-pin connector. 4.0 Vp-p ±2.0V. (If used).
Important notes on using this mode
• External sync system should follow the camera scanning system.
• External VD and HD phase relation should follow as shown in fig. 10.
• Depending of the temperature, it is not recommended to use integration >2 seconds.
Fig. 19. Vertical timing for Long Time Exposure

CV-M77
- 16 -
6.5. Other functions
Mode setting and all other settings can be done via RS 232C control if rear switch SW1-10 is ON.
Mode setting and some other settings can be done by switch if rear switch SW1-10 is OFF.
For details: refer to “7. Configuring the Camera”.
!! Do not adjust analogue settings unless you have knowledge to video adjustments!!
Shutter Mode. SM.
This function will select if the shutter time is selected from the 12 fixed values with Shutter, or
from the 788 steps in Programmable exposure.
Shutter. SH.
Selects the shutter time from a list with 12 fixed values. (Also by switch.)
Programmable Exposure. PE.
Select the shutter time with 1H (51µs) steps from a list with 788 steps.
High frame rate. DR. (Draft mode).
In this mode only every third lines is read out. The lines between are dumped. The resulting
frame rate is about 3 times higher.
WEN polarity. WP.
Will invert the WEN output polarity. Default is active low.
EEN polarity. EP.
Will invert the EEN output polarity. Default is active low.
WEN/SYNC. WS.
Switch between WEN or composite sync on pin #7 on 9pin sub-D connector. (Also by switch.)
G on SYNC. SY.
If SY=1, the green output video will have composite sync added. pin #4 on 9pin sub-D connector.
(Also by switch.)
AGC. AS.
This command will switch the gain control between manual and automatic gain control (AGC).
With manual gain, the gain level is adjusted with Master gain. (Red gain and Blue gain for color
balance). With AS=1 (Auto) the video output level is automatic controlled by an AGC circuit. It
will try to keep the video output level constant. The reference for this level is set by the AGC
parameter AG.
AGC level. AG.
This parameter is the reference for the automatic gain control if AS=1.
Master Gain. GA.
This parameter adjust the RGB video output level if AS=0.
Red Gain. RG.
This parameter adjust the manual color balance with the red video level if WB=0.

CV-M77
- 17 -
Blue Gain. BG.
This parameter adjust the manual color balance with the blue video level if WB=0.
White balance. WB.
This function selects the color balance. Manual, Auto or 2 fixed values. (Also by switch.)
Auto white balance. AW.
If the white balance is set to automatic (WB=1), the white balance will be automatic adjusted
every time the command AW=0 is received.
Master set-up level. SU.
This parameter adjust the RGB video set-up level.
Red set-up level. RS.
This parameter is for fine adjust of the red set-up level.
Blue set-up level. BS.
This parameter is for fine adjust of the blue set-up level.
White clip level. WC.
This parameter sets the clipper level for RGB video output. It will prevent signal peaks from
highlighted spots to be output. The normal clip level is set to 0.8 volt on a 75Ωterminated video
output.
Gamma select. GS.
This commands selects the video gamma to be 1 of 3 values.
6.6. Request functions.
The following commands are for transmission and identification.
Echo Back. EB=1.
If on, the camera will echo back the RS-232C transmission.
Version Number. VN.
If received, the camera will send back its firmware version number as a 3 digits number.
6.7. Save and Load functions
The following commands are for store and load camera settings in the camera EEPROM.
Load settings. LD.
This command will load previous stored settings to the camera. 1 user setting can be stored in
the camera EEPROM. 1 factory setting is also stored in the camera. The settings stored in the
user area, is used as default settings at power up.
Save Settings. SA.
This command will store the actual camera settings to a user area in the camera EEPROM.
EEPROM Area. EA.
The command will return the last used area. (Factory or user).

CV-M77
- 18 -
7. Configuring the Camera
Before changing any switch settings or jumper settings turn off the power.
7.1. Setting by Switch and Jumper
7.1.1 Rear Switch
The factory setting for the SW-1 switch on the rear panel of the camera is OFF: The electronic
shutter is OFF, the external trigger modes are OFF, gamma is OFF (=1.0), the AGC is OFF and the
RS-232C control is disabled.
seconds
OFF ON
1
2
3
4
5
6
7
8
CONTROL
SHUTTER
GAMMA
< > >
< < >
< >
Manual < >
Local RS232C
Auto
<
<
<
<
<
<
<
<
>
<
<
>
<
>
<
<
>
<
<
>
>
<
>
>
1/25 (Off)
1/50
1/125
1/250
1/500
1/750
1/1000
1/1500
>
<
<
>
<
<
1/2000
1/3000
EXT.
TRIGGER
Off
Edge
pre select
Pulse
width
10
9
GAIN
< >
< >
SW 1
1.0 0.45
1/4000
1/10,000
>>
<><><
><>
<><>
<<
>>
Fr. DELAY Off On
Fig. 20. Rear switch setting
7.1.2. Internal Switch setting
On the PK8308 board inside the camera three switches exist. S301, S302 and S303.
The switch settings determine
• Termination of external trigger, VD and HD signals
• Color temperature
S302
S301
S303
• Composite sync. on green video signal
• WEN OFF/ON at DSUB connector
• Input/Output of VD and HD signals
Fig. 21. Internal switch position on PK8303A

CV-M77
- 19 -
SW301
The SW301 switches (1-3) in “ON” position activates
75Ωtermination of ext. HD and ext. VD signals and it
activates 75Ωtermination of an ext. trigger signal.
The factory setting is “OFF” enabling TTL signal
termination for all three signals.
Fig. 22. Switch 301 HD, VD and trigger termination
SW302
The SW302 switch has the following functions: The switches (1-2) determines the color
temperature, the switch (3) activates Composite sync. on the green video signal and the switch
(4) outputs the WEN signal at the DSUB connector.
The white balance is dependent on the color temperature of the light.
The available settings are shown in the below table.
Fig. 23. Switch 302. White balance, sync on G and WEN
The S302-3 switch adds in “ON” position the composite sync. signal to the green video signal.
The factory setting is “OFF” leaving the green RGB signal without sync. signals.
The S302-4 switch outputs in “ON” position the WEN signal via pin 7 of the 9-pin DSUB
connector. The factory setting is “OFF”. In the “OFF” position the camera outputs the
composite sync. signal via pin 7 of the 9-pin DSUB connector.
SW303
The SW303 switch switches between output of internal HD/VD
signals and input of external HD/VD signals. The factory setting
is input of external HD/VD signals (SW303-1 and SW303-2 in
“ON” position). The “ON” position is towards switch SW301.
Fig. 24. Switch 303. HD/VD input/output
S301
TTL ↔75Ω
OFF ON
HD: 1
VD: 2
TRIG: 3
NC: 4
S302
OFF ↔ON
White - 1
Balance 2
Sync. on G: 3
WEN: 4
S303
output
↔input
OFF ON
HD: 1
VD: 2
S302-1 S302-2 Color temperature
OFF OFF Manual. 2600-6000K (factory setting)
OFF ON Invalid setting
ON OFF 4600K
ON ON 5600K
Table of contents
