iBeam OnSite Fixed Series User manual

© 2001-2014 iBEAM Systems, Inc. Specifications are current as of 4/1/14 and may c ange wit out notice.
w w w . i b e a m s y s t e m s . c o m 8 0 0 . 4 0 3 . 0 6 8 8
iBEAM
®
OnSite Fixed™ Construction Camera
INSTALLATION INSTRUCTIONS
Getting Started
Remove all components from shipping box.
Install the Camera and Camera-Side Antenna
Attach the camera arm to the mounting surface (pole or wall) using the supplied hardware.
Attach camera enclosure to the camera arm.
Attach camera-side bridge antenna to mounting surface.
Plug the camera enclosure into 120V AC power.
Install the Network-Side Antenna
Attach network-side bridge antenna to mounting surface.
(Antennas should face each other.)
Connect antenna to modem and power using the POE adapter as shown on other side.
Configure your Network
Your network must be configured to allow outside traffic to the camera. The most common method for this is to
use port forwarding on your network’s router to forward all outside requests on port 80 to the camera’s network
IP address. See other side for the camera’s network IP addresses.

© 2001-2014 iBEAM Systems, Inc. Specifications are current as of 4/1/14 and may c ange wit out notice.
iBEAM
®
OnSite Fixed™ Construction Camera
INSTALLATION DIAGRAM
MOUNTING
BRACKET
8’ POWER
CORD
**YOUR NETWORK MAY VARY. CONSULT YOUR NETWORK ADMINISTRATOR.
Your iBEAM Construction Camera system has been programmed with the IP addresses you provided:
Camera: _________________________ Wireless Bridge (camera side): ________________________
Wireless Bridge (camera side): ________________________
Your network administrator must configure your router to allow access to the camera at the IP address above.
w w w . i b e a m s y s t e m s . c o m 8 0 0 . 4 0 3 . 0 6 8 8
LONG-RANGE
WIRELESS
BRIDGE ANTENNA
W/ BRACKET
ITEMS IN BLUE ARE
INCLUDED WITH iBEAM
ONSITE FIXED CAMERA
EQUIPMENT. ALL OTHER
ITEMS ARE PROVIDED BY
CUSTOMER.
OUTDOOR
ENCLOSURE
iBEAM ONSITE
FIXED CAMERA
MODEM/ ROUTER/
SWITCH/FIREWALL
INTERNET
CONNECTION WITH
STATIC PUBLIC IP
ADDRESS
LONG-RANGE
WIRELESS
BRIDGE ANTENNA
W/ BRACKET
50’ NETWORK
CABLE
6’ POWER
CORD
6’ NETWORK
CABLE
