ICE COBOTICS i-SYNERGY i28BTL+ Programming manual

Operator & Parts Manual
Automatic Scrubber
8210042
REV.04 (05-2022)
i28BTL+
i28BTL+-CY
i32BTL+
www.icecobotics.com
www.icerental.com

2ICE i28BTL / i28BTL-CY / i32BTL
OPERATOR MANUAL
HOW TO ORDER PARTS
Only use ICE Company supplied or equivalent parts. Parts and supplies may be ordered
online,by phone, by fax or by mail.
1. Identify the machine model.
2. Identify the machine serial number from the data label.
3. Ensure the proper serial number is used from the parts list.
4. Identify the part number and quantity.
Do not order by page or reference numbers.
5. Provide your name, company name, customer ID number,billing and shipping address,
phone number and purchase order number.
Please ll out at time of installation for future reference.
Model No.
Serial No.
Machine Options
Sales Rep.
Sales Rep. Phone No.
Customer ID Number
Installation Date
READ OPERATOR MANUAL CAREFULLY!
ICE Company Limited
XiangShi Road LiaoBu DongGuan GuangDong China
Tel: 0769 - 81869000
Fax:0769 - 81863000
Specifications and parts are subject to change without notice.
IMPORTANT: To ensure full warranty protection, please ll out & return
your warranty card.
PROTECT THE ENVIRONMENT
Please dispose of packaging materials,old machine components
such as batteries, hazardous uids, including antifreeze and oil, in an
environmentally safe way according to local waste disposal regulations.
Always remember to recycle.

ICE i28BTL / i28BTL-CY / i32BTL 3
OPERATOR MANUAL
SAFETY PRECAUTIONS......................................................................................................4
MACHINE COMPONENTS...................................................................................................5
PANEL COMPONENTS...................................................................................................6
i-synergyTM INTRDUCTION................................................................................................7
MACHINE SETUP & INSTALLATION....................................................................................7
MACHINE OPERATION.................................................................................................8
WHILE OPERATING MACHINE..........................................................................................8
TANK DRAINING..................................................................................................................9
BATTERY CHARGING........................................................................................................10
PREVENTATIVE MAINTENANCE......................................................................................10
CYLINDERICAL BRUSH MODEL.......................................................................................11
CLINDERICAL ASSEMBLY INSTRUCTIONS....................................................................12
FAULT CODE & SOLUTION................................................................................................14
BASIC TROUBLESHOOTING............................................................................................15
TECHNICAL SPECIFICATION............................................................................................16
PARTS LIST..............................................................................................................17-42
WEAR AND TEAR PARTS.................................................................................................43
WIRING DIAGRAM.............................................................................................................44
TABLE OF CONTENTS

4ICE i28BTL / i28BTL-CY / i32BTL
OPERATOR MANUAL
SAFETY PRECAUTIONS
This machine is intended for commercial use. It
is designed exclusively to scrub hard oors in an
indoor environment and is not constructed for any
other use. Only use recommended accessories.
All operators shall read, understand and
exercise the following safety precautions:
1. Do not operate machine:
-Unless trained and authorized.
-Unless you have read and understand the
operators manual.
-In ammable or explosive areas.
-If not in proper operating condition.
-In outdoors areas.
2. Before starting machine:
-Make sure all safety devices are in place
and operate properly.
3. When using machine:
-Go slow on inclines and slippery
surfaces.
-Follow all safety guidelines.
-Be very careful when using the machine in
reverse.
-Reduce speed when turning.
-Report and x any damage to machine prior
to operating it.
-Never allow children to play on or
around.
-Do not operate on inclines that exceed 5%
(3°).
4. Before leaving or servicing machine:
-Stop on level surface.
-Turn o󰀨 machine.
5. When servicing machine:
-Read operators manual thoroughly prior to
operating or servicing this machine.
-Use manufacturer supplied or approved
replacement parts.
-Secure machine with wheel blocks prior to
jacking the machine up.
-Use approved jack or hoist to safely elevate
the machine.
-Disconnect batteries prior to working on
machine.
-Avoid moving parts. Do not wear loose tting
clothing while servicing machine.
WARNING: Fire or Explosion Hazard.
Keep sparks and open ames away! Keep
battery compartment open when charging.
WARNING: Flammable materials can
cause an explosion or re. Do not use
ammable materials in tanks.
WARNING: Flammable materials or
reactive metals can cause explosion or re.
Do not pick up.

ICE i28BTL / i28BTL-CY / i32BTL 5
OPERATOR MANUAL
MACHINE COMPONENTS
1. Control handle
2. Control panel (See penal components)
3. Recovery tank drain hose
4. Emergency stop button
5. Circuit breaker, Controller
6. Circuit breaker, Brake
7. Hose ll port
8. Squeegee lift lever
9. Wheels, 8 Inch
10. Filter assembly
11. Vacuum hose
12. Solution tank level / Drain hose
13. Ball valve
14. On-board battery charger
15. Squeegee assembly
16. Caster, 2 inch, Squeegee adjustment
17. Control handle start bail
18. i-synergyTM, ID card scanning area
19. Lithium-ion batteries
20. Recovery tank support stand
21. Vacuum motor, 24VDC
22. Cup holder
23. Recovery tank cover
24. Recovery tank
25. ICE logo
26. Bucket ll port/ Clean-out port
27. Solution tank
28. LED light
29. Front cover
30. Brush & Pad realease plunger
31. Scrub head adjusting bolt
32. Scrub head skirt
33. Scrub head assembly
34. Parking brake (Option)
17
1514
13
1211109
5
4
3
19 20 21
23
24
25
27
29
22
28
2
1
16 30 31 32 33
26
34
6
7
8
18

6ICE i28BTL / i28BTL-CY / i32BTL
OPERATOR MANUAL
PANEL COMPONENTS
01 Date&Time
02 Battery meter
03 Setting button
04 Solution ow adjusting button
05 Vacuum motor button
06 1-step starting button
07 Work mode select button
08 Scrub head pressure adjusting button
09 Speed adjusting button
10 Timer

ICE i28BTL / i28BTL-CY / i32BTL 7
OPERATOR MANUAL
i-synergyTM collects operational data from
cleaning machines and transmit the information
to ICE’s server. The ICE server generates daily
reports and send them to designated end users
by email. From these reports, end users will
have information about machines’ usage and
even specic timings.
Besides, i-synergyTM also collects data on
lithium-ion battery, vacuum motor, brush
deck motor, transaxle, and other electrical
components at least once every minute when
the machine is in use and even during battery
charging.
i-synergyTM will send notications instantly
to the ICE server in case of any malfunction.
ICE maintenance personnel will receive a
SMS within minutes from the ICE server for
immediate servicing.
UNCRATING MACHINE
Be sure and check packing carton for any damage.
Immediately report any damage to carrier. Check
the contents of package to ensure that the
following items are included:
• Machine
• Lithium-ion Batteries
• Squeegee assembly
• 2-Pad Drivers
• 2-Brushes
INSTALLING BATTERIES
The machine uses the Lithium-ion batteries,
the batteries are already in the machine upon
delivery; However you will need to connect the
Lithium ion batteries to the machine.
WARNING: Fire or Explosion Hazard.
Keep sparks and open ames away! Keep
battery compartment open when charging.
1. Turn o󰀨 the machine.
2. Open recovery tank to gain access to battery
compartment.
3. Carefully place the Lithium-ion batteries into the
compartment. Place the battery brace at the
rear of the batteries.
DO NOT DROP BATTERIES INTO
COMPARTMENT!
4. Plug the batteries connector to the machine
adaptor, connect machine i-synergyTM COM
port with the batteries.
MACHINE SET UP
PRE-OPERATION CHECKS
1. Sweep or dust mop the surface to be cleaned.
2. Check battery meter to make sure batteries are
fully charged. (See BATTERY CHARGING)
3. Check that squeegee is properly installed.
4. Check that brushes / pads is properly installed.
INSTALLING BRUSHES OR PADS
1. Turn o󰀨 the 1-Step scrub head up/dwon button
(Panel components, item #12) and Raise the
Scrub head o󰀨 the oor, then stop machine on
the level surface, ensure the machine is turned
o󰀨.
2. If using the Pad Driver, rst attach the
appropriate pad to the pad driver surface.
3. Align the pad driver or brush under the motor
hub and push it upward to engage.
4. To remove the pad driver or brush, raise the
scrub head and push the pad release plunger
(Machine components, item #30) downward.
MOUNTING THE SQUEEGEE ASSEMBLY
1. Lift the squeegee lift lever (Machine
components, item #8)to the upward position.
2. Mount the squeegee assembly to the squeegee
pivot bracket. make sure the knobs are
completely seated into the slots before securing
knobs.
3. Connect the vacuum hose to the squeegee
assembly. Loop the hose by using the hose clip
provided.
4. Check the squeegee blades for proper
adjustment.
i-synergyTM INTRODUCTION
MACHINE SET UP & INSTALLATION

8ICE i28BTL+ / i28BTL+-CY / i32BTL+
OPERATOR MANUAL
FILLING THE SOLUTION TANK
The machine is equipped with a hose ll-port
(Machine components, item #7) at the rear of
the machine, and a bucket ll-port (Machine
components, item #26)located under the recovery
tank. Before accessing the bucket ll-port make
sure that the recovery tank is empty.
Fill the solution tank to the "100L" level on the
solution tank sight gauge. When using the bucket
ll-port, stop lling when the level reaches the
bottom edge of the ll-port.
Convertional scrubbing - Fill solution tank
with water (not to exceed 60°C/140°F. Pour a
recommended cleaning detergent into the solution
tank according to mixing instructions on the
container)
NOTE: When lling the solution tank with a bucket,
make sure that the bucket is clean. Do not use the
same bucket for lling and draining the machine.
WARNING: Do not put any ammable
materials into solution tank. this can cause an
explosion or a re. Only use recommended
cleaning chemicals. Contact your janitorial
supply distributor for recommendations on
proper chemicals.
WARNING: Do not operate machine
unless you have read and understand this
manual.
1. Swipping the ID card (Machine components, item
#18) to turn on the machine.
2. Check the LED display screen (Panel
components, item #4), if there are fault condes
(Panel components, item #18) and the Fault
indicator (Panel components, item #1) in blink,
please DO NOT operate the machine unless the
faults have been eliminated (please see FAULT
CODES AND ELIMINATE section).
3. Turn on the 1-Step scrub head up/down
button, the scrub head will be lowered down
automatically.
4. Lower squeegee assembly to the oor by
lowering the Squeegee lift lever.
5. Check the solution ow indicator (Panel
components, item #9), press the Solution ow
adjusting button (Panel components, item #10) to
get a desired solution ow.
NOTE: Solution will not begin to ow until the
control handle bail is pulled.
6. Turn on the Vacuum motor switch(Panel
components, item #8).
7. Pull the Control handle bail (machine
components, item #17) backwards to start
scrubbing .The machine will automatically propel
forward. To reverse the machine, simply push
the control handle bail forward.
NOTE: Raise squeegee when reversing machine.
8. The scrubbing speed can be adjusted, press
the Speed increase/ decrease button (Panel
components, item #14, #16) to a desired speed.
NOTE: 45-60 meters (150-200 ft)per minute is
the recommended scrubbing speed.
9. The brush pressure can be adjusted, press the
Brush pressure increase/ decrease button
(Panel components, item #3,#6) to get a
desired brush pressure.
10. To stop scrubbing, release the control handle
bail, turn o󰀨 the 1-Step scrub head up/down
button to raise he scrub head assembly, raise
the squeegee assembly.
WARNING: Fire Or Explosion Hazard. Do
Not Pick Up Flammable Materials Or Reactive
Metals.
1. Go slow on inclines and slippery surfaces. Do not
operate the machine on inclines that exceed 5%
(3°).
2. Do not keep the machine in the same position with
pad / brush spinning, keep the machine moving to
prevent damage to oor nish.
3. If the squeegee assembly leaves streaks on the
oor, raise the squeegee o󰀨 the oor and wipe the
blades down with a damp cloth. Pre-sweep the
area to prevent leaving streaks on the oor.
4. Pour a recommended defoamer into the recovery
tank if excessive foam appears.
WARNING: Do not allow foam to enter the
oat shut-o󰀨 screen, vacuum motor damage will
result. Foam will not activate the oat shut-o󰀨
screen.
5. Occasionally check the battery meter(Panel
components, item #2). when the battery is very
low, stop scrubbing and recharge the batteries.
WARNING: When battery meter is in the
red, do not continue to operate the machine.
Battery damage may result.
MACHINE OPERATION
WHILE OPERATING MACHINE

ICE i28BTL / i28BTL-CY / i32BTL 9
OPERATOR MANUAL
6. When the solution tank runs empty, press the
1-Step switch raise the brush head. Keep the
squeegee down and continue to vacuum until all
the dirty water is picked up.
NOTE: Brush motors will not work when
the scrub head assembly raised.
NOTE: See TANK DRAINING section to learn
how to drain recovery and solution tanks.
CIRCUIT BREAKER / FUSES
The machine is equipped with 2 resettable circuit
breakers(machine components, item #5, item#
6) to protect the main controller from damage. If
the circuit breakers should trip, it can't be reset
immediately. You must rst determine what caused
the breaker to trip, and allow the motor to cool
down and then you can manually reset the circuit
breakers.
The machine is also equipped with a 150A fuse
to protect the Lithium-ion batteries from damage.
When replacing a fuse never substitute a higher
Amps rated fuse than specied.
HOUR METER
The hour meter (Panel machine components, item
#17) records the number of total hours the brush
motor has been powered on. Use the hour meter
to determine when to perform recommended
maintenance procedures and to record service
history.
EMERGENCY STOP BUTTON/ BRAKE
The machine is equipped with an Electromagnetic
Brake Mechanism on the Transaxle. When in
case of Emergency, release the Control Handle
bail or strike the Emergency stop button (Machine
components, item #4), the machine will be braked
and then stop. Reset the emergency stop button,
turn on the machine, and then pull the control
handle bail, the machine will be restart.
NOTE: The machine can not be moved unless the
Main Power and the Control Handle bail be turned
on.
WARNING: Do Not Change the Default
Settings of the Electromagnetic Brake
Mechanism unless Authorized, otherwise it
may cause Machine Damage or Personal Injury.
Contact the Authorized Service center for
machine repairs.
1. Turn the machine o󰀨.
2. With the squeegee and scrub head in their "up"
position, transport machine to approved area for
draining tank(s).
DRAINING THE RECOVERY TANK
Any time scrubbing is completed, or when relling
solution tank, the recovery tank should be drained
and cleaned.
WARNING: If the recovery tank is not
drained when the solution tank has been
relled, foam or water may enter the oat shut-
o󰀨 screen and cause damage to the vacuum
motor.
1. While holding the drain hose (Machine
components, item #3) upward, remove the cap
and lower hose to drain.
2. Open the recovery tank cover and rinse out the
tank. Use a rag to remove any excess dirt.
3. Clean the oat shut-o󰀨 screen and debris tray
located in the recovery tank .
DRAINING THE SOLUTION TANK
Any time scrubbing operation is completed, the
solution tank should be drained and cleaned.
1. Pull the solution tank level hose(Machine
components, item #12) o󰀨 the hose tting, this
will allow the solution to ow freely into a bucket
or oor drain.
2. Remove the cover of the lter assembly
(Machine components, item #10) to drain the
solution tank, check the lter screen and clean
up it if necessary.
3. Rinse the solution tank with clean water after
every use. This will help prevent chemical
buildup and clogging of the solution lines.
4. After rinsing out the tank, securely reconnect
the tank level hose to the hose tting, replace
the lter assembly cover and be sure the
lter screen and the "O" ring is in the correct
position.
TANK DRAINING

10 ICE i28BTL / i28BTL-CY / i32BTL
OPERATOR MANUAL
BATTERY CHARGING
WARNING: Fire Or Explosion Hazard.
Keep Sparks and Open Flame Away. Keep
Battery Compartment Propped Open When
Charging.
Only use ICE supplied or approved batteries
charger, use unapproved charger may cause
damage to the batteries and machine.
Batteries chargers specications:
• Applicable to charging Lithium-ion batteries
• Automatic shut o󰀨 circuit
• Output current of 30 Amps
• Output voltage of 24 volts
1. Place machine in a well ventilated area.
2. Turn the machine o󰀨.
3. Connect the charger's AC power supply cord to
a properly grounded receptable.
4. Prop up the recovery tank by the support stand
(Machine components, item #20) for ventilation
when charging.
5. The charger will automatically begin to charge
and will automatically shut o󰀨 once the batteries
are fully charged.
6. Upon completion of charging, disconnect the
AC power supply cord.
WARNING: Before performing any
maintenance on the machine, be sure that
the power is turned o󰀨, or the batteries are
disconnected!
WARING: Repairs are to be completed
by Authorized service centers only. Any repairs
completed by unauthorized persons will avoid
the warrenty.
DAILY MAINTENANCE
1. Remove pad driver/ brush and clean with
approved cleaner.
2. Drain recovery and solution tanks completely
and rinse out with clean water. Visually check
the recovery tank for debris and clean out as
necessary.
3. Raise the squeegee assembly o󰀨 oor and wipe
it down with a damp towel. Be sure to store the
squeegee in the up position.
4. Remove the oat shut-o󰀨 assembly and rinse it
out with clean water.
5. Clean machine with an approved cleaner and a
damp towel.
6. Recharge the batteries.
7. Check the condition of the squeegee blade
wiping edge, rotate blade if worn.
MONTHLY MAINTENANCE
1. Clean the battery tops to prevent corrosion.
2. Check for loose battery cable connections.
3. Inspect and clean the recovery tank cover seal.
Replce it if damaged.
4. Lubricate all grease points and pivot points with
silicon spray and approved grease.
5. Check the machine for loose nuts and bolts.
Check the machine for leaks.
MACHINE STORAGE
1. Always store the machine indoors.
2. Always store the machine in a dry area.
3. Always store the machine in its upright position.
4. Always store the machine with the pad driver/
brush raised o󰀨 the oor.
5. Always store the machine with the squeegee
assembly raised o󰀨 the oor.
6. If storing in an area which may reach freezing
temperatures, be sure to drain all uids from the
machine prior to storage. Any damage caused
by freezing temperatures will not be covered by
the warranty.
7. Drain the recovery tank.
8. Drain the solution tank of all uid.
PREVENTATIVE MAINTENANCE

ICE i28BTL / i28BTL-CY / i32BTL 11
OPERATOR MANUAL
INSTALL BRUSH
1. Raise scrub head o󰀨 the oor and turn o󰀨 the
power.(remove key)
2. Remove brush door from scrub head by
loosening the knob.
3. Attach brush door to the brush end that has the
double row of bristles to install brush.
4. Check the brushes to ensure they are properly
adjusted.
INSPECT THE BRUSH PATTERN
After installing a new set of cylindrical brushes
check the brush pattern to ensure proper brush
adjustment.
1. Measure the distance from the front edge
of the scrub head to the oor and from the
back edge of the scrub head to the oor.The
measurements should be the same.
2. To level the scrub head, loosen the lock nut and
turn the leveling screw clockwise to lower the
rear of the scrub head or counter--clockwise to
lower the front.
3. Position the machine on a dry dusty oor or
apply a powdered substance, such as chalk.
4. Adjust the speed control knob to "zero"( )
5. Shut o󰀨 the solution ow.
6. Pull the control handle bail to create a brush
pattern on the oor.
7. Raise the scrub head and pull the machine
away.
8. Observe the brush pattern on oor. If the brush
pattern is uneven or tapered, adjustment is
required.
TO ADJUST A TAPPERED BRUSH PATTERN
1. Remove the brush door from the brush.
2. Hold the brush plug shaft with a wrench and
loosen the 6mm hex screw.
3. To lower the brush end, turn the shaft clockwise
for the front brush and counter--clockwise for
the rear brush. Retighten hex screw.
4. Recheck brush pattern.
NOTE: Replace brushes when worn to 5/8”
(15mm).
CYLINDRICAL BRUSH MODEL

12 ICE i28BTL / i28BTL-CY / i32BTL
OPERATOR MANUAL

ICE i28BTL / i28BTL-CY / i32BTL 13
OPERATOR MANUAL

14 ICE i28BTL / i28BTL-CY / i32BTL
OPERATOR MANUAL
FAULT CODE & SOLUTION
The machine is equipped with a LED display screen
(Panel components, item # 4), the LED screen will
display the operating hours (Panel components,
item # 17) and the battery level status (see Panel
components, item # 2).
When the machine detects a fault, there will be a
Fault code (Panel components, item #18) & Fault
message (Panel components, item #11) display
on the LED screen, and the Fault indicator (Panel
components, item #1) will ash continuously,
accompany an audible alarm Occasionally.
Once fault occuring, please DO NOT continue
operate the machine unless the fault are eliminated.
Turn o󰀨 the machine, then to solve the fault, the
fault code & message will be eliminated when
machine restart.
If the fault is occurred frequently, or the fault can't
be eliminated, please contact ICE service center.
Please refer to the below table to determine the
fault cause and the solution.
FAULT
CODE FAULT MESSAGE FAULT CAUSE SOLUTION
F03 Bru Actt O.L.
RESTART! Scrub head lifting actuator is overload
Turn o󰀨 the machine,after a moment,
RE-START machine.
F04 Vac Mtr O.L.
RE-START! Vacuum motor overload
F05 Left Bru Mtr O.L.
RE-START! Left brush motor is overload
F06 Right Bru Mtr O.L.
RE-START! Right brush motor is overload
F07 Propel Mtr O.L.
RE-START! Propel motor overload
F08 RecTank Full Recovery tank is full Drain the Recovery tank
F10 Batt Low
Charge Batt Battery is low Charge the battery
F11 Batt Empty
Charge Batt NOW Battery is empty Charge the battery NOW
F12 Brake Wiring Error Bad Brake wiring Check the brake wiring
F14 Replace Brake Assy Bad Brake assembly Replace the brake assembly
F16 Control Unit Overheat!
Wait Control Unit Overheat Turn o󰀨 the machine,after a moment, RE-START machine
F17 Replace Control Unit Control Unit Fault Replace the control unit
F20 Check Left Brush motor Bad left brush motor Check left brush motor/ wiring
F21 Check Vac Mtr Bad Vacuum motor or wiring Check the vacuum motor / Wiring
F22 Check Soln Solenoid Solution solenoid wiring fault Check the wiring & Contactors
F23 Replace Soln solenoid Bad Solution solenoid Replace the solution solenoid
F24 Check Propel Motor Bad propel motor Check the propel motor / Wiring
F25 Check Right Brush motor Bad right brush motor Check right brush motor/ wiring
F40 Check Proximity Sw Proximity switch fault Check the Proximity switch
F41 Release Handle Operation mistake Release the control handle bail
F42 Replace Control Unit Bad Control Unit Replace the control unit
F43 Turn Dead Sw O󰀨
RE-START! Emergency stop button activated Release emergency stop button and restart machine
F44 Replace Control Unit
Bad Control Unit Contact service center, Replace the
Control Unit
F45 Return Control Unit
F46 Return Control Unit
F47 Return Control Unit
F48 Return Control Unit

ICE i28BTL / i28BTL-CY / i32BTL 15
OPERATOR MANUAL
PROBLEM CAUSE SOLUTION
Machine will not
operate
Control handle bail not pulled Pull control handle bail
Batteries need to be charged Charge batteries
Bad lithium-ion batteries Replace batteries
Emergency stop button activated Reset Emergency stop botton
Main PCB fuse blown Contact ICE service center
Faulty i-synergyTM module Contact ICE service center
Brush motor will
not operate
1-STEP scrub head up/down switch is o󰀨 Turn on the 1-STEP switch
Battery meter lockout activated Recharge batteries
Faulty control handle bail switch Contact ICE service center
Faulty brush motor or wiring Contact ICE service center
Worn Motor carbon brushes Contact ICE service center
Machine does
not propel
the Control handle bail not pulled Pull the control handle bail
Faulty transaxle motor or wiring Contact ICE service center
Worn Motor carbon brushes Contact ICE service center
Vacuum motor
will not operate
Faulty vacuum motor or wiring Contact ICE service center
Worn Motor carbon brushes Contact ICE service center
Little or no
solution ow
Ball valve set too low or shut o󰀨 Turn on the ball valve
Solution ow control knob set too low or
shut o󰀨
Adjust solution control ow knob
Clogged solution tank lter or solution
hose
Clean solution tank filter or flush out
solution hose
Clogged solution Solenoid valve Remove valve and clean
Poor water pick
up
Recovery tank is full Drain recovery tank
Loose drain hose cap Tighten cap
Clogged oat shut-o󰀨 screen located in
recovery tank
clean screen
Clogged squeegee assembly Clean squeegee assembly
Worn squeegee blades Replace or rotate squeegee blades
Incorrect squeegee blade deection Adjust squeegee blade height
Loose vacuum hose connections Secure hose connections
Clogged vacuum hose Remove clogged debris
Damaged vacuum hose Replace vacuum hose
Recovery tank cover not in place Properly position cover
Damaged recovery tank cover seal Replace seal
Faulty vacuum motor Contact ICE service center
Low battery charge Recharge batteries
Short run time
Low battery charge Fully recharge batteries
Defective batteries Replace batteries
Batteries need maintenance See BATTERY MAINTENANCE
Faulty battery charger Repair or replace battery charger
Down pressure lever is set for extra scrub
head pressure
Lower down pressure lever
BASIC TROUBLESHOOTING

16 ICE i28BTL / i28BTL-CY / i32BTL
OPERATOR MANUAL
TECHNICAL SPECIFICATIONS
MODEL i28BTL-CY i28BTL i32BTL
DIMENSIONS - L 61.02 in / 1,550 mm 62.21 in / 1,580 mm
DIMENSIONS - W 30.51 in / 775 mm 34.06 in / 865 mm
DIMENSIONS - H 44.49 in / 1,130 mm 44.49 in / 1,130 mm
WEIGHT 352.74 lbs / 160 Kg 374.79 lbs / 170 Kg
WEIGHT WITH BATTERIES 484 lbs / 220 Kg 506.7 lbs / 230 Kg
SOLUTION TANK CAPACITY 26.42 Gal / 100 L
RECOVERY TANK CAPACITY 31.7 Gal / 120 L
SQUEEGEE WIDTH Standard: 40.5 in / 1,030 mm
Option: 44.5 in / 1,130 mm
Standard: 46.5 in/1,185 mm
Option: 44.5 in / 1,130 mm
CLEANING PATH WIDTH 28 in / 700 mm 32 in / 800 mm
PRODUCTIVITY RATE 30,667 ft2 / 2,850 m2h 34,983 ft2/ 3,250 m2h
DRIVE SYSTEM Transaxle, 24VDC, 0.27 hp / 200 W
TRAVEL SPEED, MAXIMUM Cleaning: 65 m/Min Transporting: 72 m/Min
213.25 ft/min 236.22 ft/Min
MINIMUM AISLE TURN 63 in / 1600 mm
PAD/BRUSH PRESSURE 0 ~ 79.37 lbs
0 ~ 36 kg
39.68 lbs / 18 kg
79.37 lbs / 36 kg
119.05 lbs / 54 kg
SOLUTION FLOW RATE 0 ~ 0.66 Gal / Min
0 ~ 2.5 L/Min
BRUSH / CYLINDERICAL
MOTORS
0.75 hp / 560W × 2,
750 RPM
0.75 hp / 550W × 2,
210 RPM
BRUSH / CYLINDERICAL
DIMENSIONS (x2)
Dia: 150 mm / 6 in
Length: 700 mm / 28 in
Diameter:
355.6 mm / 14 in
Diameter:
406.4 mm / 16 in
VACUUM MOTOR 0.8 hp / 600 W
WATER LIFT - AIR FLOW 65 in / 1650 mm
BATTERIES Lithium-ion Batteries, 240 AH
RUN TIME PER CHARGE 3.5~4 Hours
VOLTAGE DC 24 V
DECIBEL RATING AT
OPERATOR'S EAR,
INDOORS
68 dB(A)
GRADE LEVEL, MAX 5% (3°)

ICE i28BTL+ / i28BTL+-CY / i32BTL+ 17
PARTS LIST
RECOVERY TANK GROUP

18 ICE i28BTL +/ i28BTL+-CY / i32BTL+
PARTS LIST
RECOVERY TANK GROUP
DIA
NO.
PART
NUMBER DESCRIPTION SERIAL NUMBER NO REQ'D
1 8111001 GASKET 1
2 8131003 CAP 1
3 8210102 RECOVERY TANK 1
4 8131031 DRAIN HOSE 60305100425~ 1
5 1962050 CLAMP 1
6 8111300 HINGE ASSEMBLY 2
7 1421618 FLAT WASHER M6×18×1.6 10
8 1021616 HEX BOLT M6 X 16 12
9 8210207 CABLE 1
10 1421612 FLAT WASHER M6×12×1.6 5
11 8112005 GASKET, VACUUM MOTOR 1
12 1121605 HEX NUT M6 3
13 8210209 STUD M6×110 3
14 8210299 VACUUM MOTOR 24VDC, KIT 1
8112008 CARBON BRUSH, VACUUM MOTOR 2
15 1123608 LOCK NUT M6 3
16 1914300 TIE, NYLON, 5X300 1
17 8132007 MUFFLER, VACUUM MOTOR 1
18 4010316 ICE LOGO 1
19 8111008 BRACKET 1
20 1421816 FLAT WASHER M8×16×1.6 2
21 8111007 RECOVERY TANK SUPPORT 1
22 8115404 SLEEVE, P/M 1
23 1021830 HEX BOLT M8×30 1
24 8111016 PLATE 2
25 1221512 SCREW M5×12 2
26 8111015 FLOAT, SHUT-OFF 1
27 8111014 FLOAT ADAPTER 1
28 8210201 RECOVERY TANK COVER SEAL 1
29 8011005 CAP 1
30 8210103 RECOVERY TANK COVER 1
31 8111022 WARNING LABEL 1
32 8310238 SENSOR, SOLUTION LEVEL 1
* No.5: Supplier change for drain hose, part number change to 8131031 from 8131010.

ICE i28BTL+ / i28BTL+-CY / i32BTL+ 19
PARTS LIST
SOLUTION TANK GROUP

20 ICE i28BTL +/ i28BTL+-CY / i32BTL+
PARTS LIST
SOLUTION TANK GROUP
DIA
NO.
PART
NUMBER DESCRIPTION SERIAL NUMBER NO REQ'D
1 6210131 NYLON, CLAMP 12
2 1421510 FLAT WASHER M5×10×1 32
3 1221520 SCREW M5×20 24
4 1123507 LOCK NUT M5 6
5
8210127 BRACKET, BATTERY CHARGER
MNTG
60305100101~60305100470
603041100101~60304100256 1
8210119 BRACKET, BATTERY CHARGER
MNTG
60305100470~
60304100256~ 1
6 8210117 CAP, CHARGER 1
7 1421612 FLAT WASHER M6×12×1.6 12
8 1021616 HEX BOLT M6 X 16 10
9
8311720 ON BOARD LI-ION BATTERY
CHARGER
~60305100187
~60304100194 1
8350509 ON BOARD LI-ION BATTERY
CHARGER
60305100187~
60304100194~ 1
10
8312060US POWER CORD, BATTERY
CHARGER, US 1
8312060EU POWER CORD, BATTERY
CHARGER, EU 1
8312060JP POWER CORD, BATTERY
CHARGER, JP 1
8312060 POWER CORD, BATTERY
CHARGER, CH 1
8312060UK POWER CORD, BATTERY
CHARGER, UK 1
11 1222641 SCREW M6 X 40 2
12 8210112 HOOK, CORD 2
13 1321213 SELF-TAPPING SCREW ST4.2X13 2
14 8210113 CAP, SOLUTION FILL 1
15 8210101 SOLUTION TANK 1
16 4010316 ICE LOGO 2
17 8130099 I-SYNERGY LOGO 2
18 8210145 CLEAN TUBING 1
19 1962025 CLAMP 16-25mm 1
20 8210151 LABEL, LEFT SIDE 1
