Ice ICE-1324 Manual

USER MANUAL
&
INSTALLATION INSTRUCTIONS
HEAVY DUTY 24’’ GAS GRILL
ICE-1324
IMPORTANT SAFETY INSTRUCTIONS
Carefully read the following important information regarding installation safety and
maintenance.
Keep these instructions for future reference
2015-03-12 MAICE-1324-4

Table of Contents
Safety Requirements ............................................................................................................................3
Introduction...........................................................................................................................................4
Specifications........................................................................................................................................4
Features & Operating Controls .............................................................................................................5
Precautions and General Information ...................................................................................................6
Agency Listing Information....................................................................................................................7
Conversion to Liquid Propane Gas.......................................................................................................7
Installation.............................................................................................................................................9
Operation............................................................................................................................................16
Cleaning Instructions ..........................................................................................................................19
Troubleshooting..................................................................................................................................22
INTERNATIONAL COOKING EQUIPMENT LIMITED PRODUCT WARRANTY................................23
2

Safety Requirements
FOR YOUR SAFETY
Do not store gasoline or other flammable liquids in the vicinity of this or any other appliance.
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or
death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing
this equipment.
IMPORTANT
The purchaser of this equipment must post in prominent location instructions to be followed in the event the
user smells gas. This information shall be obtained by consulting the local gas supplier.
IMPORTANT: DO NOT DISCARD THIS
MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or MANAGER of the
restaurant, or to the person responsible for TRAINING OPERATORS of this appliance.
3

Introduction
Proper installation, professional operation and consistent maintenance of this appliance will ensure that it gives
you the very best performance and a long, economical service life.
This manual contains the information needed to properly install this appliance, and to use and care for the
appliance in a manner which will ensure its optimum performance.
Specifications
MODEL STYLE FUEL
MANIFOLD
PRESSURE
B.T.U.
per HOUR
ICE-1324
4 Burners w/
Individual Control
Natural Gas 4.0” W.C.
100,000
Propane (LP) 10” W.C.
4

Features & Operating Controls
Figure 1
5

Precautions and General Information
•This appliance is intended to prepare food for human consumption
•No other use is recommended or authorized by the manufacturer or its agents.
•This appliance must be installed by a technician qualified and certified or licensed to install gas-fired
equipment. A licensed technician must perform the initial start-up and adjustment of the appliance.
•Operators of this appliance must be familiar with the appliance use, limitations and associated
restrictions. Operating instructions must be read and understood by all persons using or installing this
appliance.
•Cleanliness of this appliance is essential to good sanitation. Read and follow all included cleaning
instructions and schedules to ensure the safety of the food product.
•DO NOT submerge appliance or burners in water. This appliance is not jet stream approved. DO NOT
direct water jet or steam jet at this appliance, or at any control. DO NOT splash or pour water on, in or
over any controls. DO NOT wash counter around this appliance with water jet. Burners which have
become wet must be thoroughly dried before use.
•Grill surface will be very hot when in use. Contact will cause severe injury.
•This appliance must be operated with the supplied 4” legs properly installed.
•Do not operate this appliance if the smell of gas is present. Turn off all gas supply valves and move to a
remote location
•The technical content of this manual, including any parts breakdown illustrations and/or adjustment
procedures, is intended for use by qualified technical personnel only.
•Any procedure which requires the use of tools must be performed by a qualified technician.
•This manual is considered to be a permanent part of the appliance.
•This manual and all supplied instructions, diagrams, schematics, parts breakdown illustrations, notices
and labels must remain with the appliance if it is sold or moved to another location.
FIRE HAZARD
All servicing of the gas supply and combustion components of this appliance must be performed by a
technician trained and certified in the maintenance of gas appliances.
Improper servicing of gas equipment can result in fire and explosion.
HOT SURFACE
Exposed surfaces can be hot to the touch and may cause burns.
6

Agency Listing Information
This appliance conforms to NSF Standard 4 for sanitation only if installed in accordance with the supplied
Installation Instructions and maintained according to the instructions in this manual.
This appliance meets ANSI Z.83.11 specifications for gas-fired food service equipment.
This appliance is Canadian Standards Association design certified for gas operation.
Conversion to Liquid Propane Gas
NOTE: DO NOT discard the carton or other packing materials until you have inspected the appliance for
hidden damage and tested it for proper operation.
HEALTH HAZARD
This appliance must be properly ventilated. Failure to provide and maintain proper ventilation of exhaust
gasses can result in severe injury or death.
FIRE HAZARD
•Do not store gasoline or any other flammable or combustible material near this appliance. The open
flame can cause such materials to ignite.
•The area where the grill is installed must be kept clear of combustibles and flammables. This includes
mops, rags, grease, wrapping paper and electric cords.
NOTICE: Manufacturer’s warranty on this grill is in effect only when the grill is installed in accordance with
these instructions and local codes and ordinances or, in the absence of local codes, the National Fuel Gas
Code, ANSI Z223.1 (current edition). The manufacturer of this grill assumes no liability for any damage or
injury resulting from failure to comply with this notice.
FIRE HAZARD
IF YOU SMELL GAS:
•DO NOT try to light any appliance.
•DO NOT touch any electrical switch
•DO NOT use any telephone in your building.
7

In the event a gas odor is detected, shut down the unit at the main gas shutoff valve and contact your local gas
supplier from a neighboring location.
Follow the instructions received from the gas supplier immediately and exactly.
STEP 1 – Remove the cooking surface and then change the nozzle:
STEP 2 – Reset the supplied regulator:
1
1. Using a wrench remove the 300 Nozzle.
2. Carefully pull out the supply tube.
3. Attach the 150 Nozzle.
4. Carefully replace the supply tube and tighten.
5. Remove yellow cap.
6. Unscrew the white plastic seal.
2
3
4
5
6
8

STEP 3 - Proceed with installation as shown in the Installation Instructions.
Installation
NOTE: DO NOT discard the carton or other packing materials until you have inspected the appliance for
hidden damage and tested it for proper operation.
HEALTH HAZARD
This appliance must be properly ventilated. Failure to provide and maintain proper ventilation of exhaust
gasses can result in severe injury or death.
FIRE HAZARD
•Do not store gasoline or any other flammable or combustible material near this appliance. The open
flame can cause such materials to ignite.
•The area where the grill is installed must be kept clear of combustibles and flammables. This includes
mops, rags, grease, wrapping paper and electric cords.
NOTICE: Manufacturer’s warranty on this grill is in effect only when the grill is installed in accordance with
these instructions and local codes and ordinances or, in the absence of local codes, the National Fuel Gas
Code, ANSI Z223.1 (current edition). The manufacturer of this grill assumes no liability for any damage or
injury resulting from failure to comply with this notice.
7. Remove the spring.
8. Replace the yellow cap
7
8
9

UNPACKING & INSPECTION
•Carefully remove the appliance from the carton. Remove all protective plastic film, packing materials
and accessories from the appliance before connecting performing any installation procedure.
•Carefully read all instructions in this manual and the Installation Instructions packed with the appliance
before starting any installation.
•Read and understand all labels and diagrams attached to the appliance.
•Carefully account for all components and accessories before discarding packing materials. Store all
accessories in a convenient place for later use
COMPONENTS:
•Grates (4 each)
•Radiant (4 each)
•Burner Assembly (4 each)
•Adjustable Legs (Set of 4)
•Grease Tray (1 each)
SETUP:
1. Setup the grill only on a firm, level, non-combustible surface.
2. Verify local codes for requirements. Concrete, tile, terrazzo or metal surfaces are recommended. Metal
or tile over combustible material may not meet code for non-combustible surfaces.
3. Install the provided adjustable legs, one on each corner of the appliance, in the holes provided.
4. Verify that the unit sits firmly ON
5. With the adjustable legs, adjust as required to level the appliance.
6. All four legs must be adjusted to firmly contact the countertop in order to prevent tipping.
•Adequate clearance for air openings in the cabinet must be provided.
•Refer to your local codes and ordinances for required clearances.
•Maintain required clearances between the appliance and adjacent combustible surfaces.
Figure 2
10

•The grill must be installed in an area with sufficient make-up air for proper combustion, and must be
installed such that the flow of combustion and ventilation air will not be obstructed.
•When used with an exhaust fan, special precautions must be observed to avoid interference with the
operation of the grill, such as drafts and air starvation.
GAS APPLIANCE CODE COMPLIANCE
The installation of gas piping from the outlet side of the gas meter or service regulator to the grill must be
performed by a technician qualified and certified or licensed to install gas-fired equipment.
A licensed and qualified technician must perform the initial startup and adjustment of this appliance.
The installation of this gas-fired appliance must conform to local codes, or in the absence of such codes, with
the current edition of National Fuel Gas Code ANSI Z223.1.
The installation of this gas-fired appliance must comply with applicable portions of NFPA 96 for ventilation. The
current edition of NFPA 96 (Standard for the Installation of Equipment for the Removal of Smoke and Grease
Laden Vapors from Commercial Cooking Equipment) specifies ventilation requirements to ensure the removal
of exhaust gasses and products of combustion.
IT IS THE RESPONSIBILITY OF THE INSTALLER TO ENSURE THAT THIS GAS GRILL INSTALLATION
CONFORMS TO ALL APPLICABLE CODES AND ORDINANCES.
The venting of this appliance must not be obstructed, nor may such venting interfere with the flow of
combustion air required for proper operation of the gas burners.
Additionally:
1. The gas supply line used to connect the grill to the gas supply system must be black iron pipe, or other
material as approved by local ordinance for gas piping.
2. Gas supply piping must be inside 3/4” diameter or greater.
3. Use pipe sealant made specifically for gas piping on all pipe joints. Apply sealant sparingly to the male
threads only. Sealant must be resistant to the action of LP gas.
4. Verify that all supply piping is clean and free of obstructions, dirt, chips and pipe sealant compound prior to
installation.
11

5. All pipe joints must be checked for leaks before lighting. Leak checks should be performed with a soap and
water solution.
NEVER CHECK FOR LEAKS WITH AN OPEN FLAME.
FIRE AND EXPLOSION HAZARD
NEVER use an open flame to check for gas leaks. Fire and explosion may result.
RISK OF INJURY:
Installation procedures must be performed by a qualified technician with full knowledge of all applicable gas-
fired appliance codes. Failure can result in personal injury and property damage.
IMPORTANT:
All pipe joints must be checked for leaks before lighting. Leak checks should be performed with a soap and
water solution.
IMPORTANT:
Information on the construction and installation of ventilating hoods may be obtained from the current edition of
NFPA 96 Standard for the Installation of Equipment for the Removal of Smoke and Grease Laden Vapors from
Commercial Cooking Equipment.
Copies of this standard are available from the Nation Fire Protection Assn.
FIRE AND EXPLOSION HAZARD
NEVER use an open flame to check for gas leaks. Fire and explosion may result.
IMPORTANT
All pipe joints must be checked for leaks before lighting. Leak checks should be performed with a soap and
water solution.
FIRE HAZARD
This grill is supplied with a gas pressure regulator.
Failure to properly install the supplied regulator will result in an extremely hazardous condition.
Flow arrow stamped on body of regulator must point toward the grill.
Vent hole must point UP.
12

IMPORTANT:
•Verify fuel gas type. If the available fuel does not match the nameplate specification, exchange the
hotplate for the correct type.
•The appliance and its individual manual shutoff valve must be disconnected from supply system piping
during any pressure testing of that system at pressures in excess of 1/2 p.s.i. (3.5 kPa).
•The appliance must be isolated from the gas supply piping system by closing its individual manual
shutoff valve during any pressure testing of the gas supply piping at test pressures equal to or less than
1/2 p.s.i. (3.5 kPa).
INSTALLING THE GAS GRLL
Refer to the nameplate. Verify the fuel type and pressure, which must match the nameplate specifications.
Connecting the hotplate to the wrong fuel type and/or pressure will compromise the safety and/or performance
of the appliance.
BE SURE TO MAINTAIN REQUIRED CLEARANCES TO COMBUSTIBLE SURFACES.
•The grill must be placed in its final operational position and leveled front-to-back and side-to-side, with
a spirit level, prior to beginning the gas piping installation. Re-check the level of the unit at the
conclusion of the gas piping installation.
•Each gas grill is supplied with a separate gas pressure regulator, which must be installed on the
manifold pipe protruding from the rear of the grill. Ensure that the regulator is installed such that the
flow arrow stamped on the body of the regulator points toward the grill.
•Failure to properly install the supplied regulator will result in an extremely hazardous condition.
•A moisture trap (drip leg) consisting of a tee, 4” nipple pointing down and cap must be installed
upstream of the gas pressure regulator.
•A manual gas shut-off valve may be required by local codes and is, in any case, strongly
recommended. The shut-off valve must be installed between the gas supply piping and the gas
pressure regulator.
13

•It is the responsibility of the gas piping installer to identify the code requirement for a shut-off valve.
•Shut-off valves, moisture trap and all associated piping must be supplied by the gas piping installer.
SET GAS PRESSURE:
Gas pressure regulator is factory set.
SET PILOT FLAME:
1. Remove all burner control knobs, and then remove the front panel.
2. The pilot adjustments are near the control valve for each set of burners.
3. Using a small, flat-blade screwdriver, turn the screw clockwise to decrease the flame size, or
counter-clockwise to increase the flame size.
4. Adjust the pilot flame to 1/4” high. Test for operation: all sections of the burner must light without
undue delay. Drafty conditions may require a higher flame to allow the pilot to remain lit.
5. Replace the front panel and all knobs before returning the unit to service.
ADJUST BURNER FLAME:
1. Remove all burner control knobs, and then remove the front panel.
2. Turn an individual burner on.
3. Loosen the locking screw on the shutter
4. Turn the shutter to admit more or less air as required. Adjust the air shutter until the flame is
mostly blue in color.
5. Tighten the locking screw when finished. Replace the front panel and all knobs before returning
the unit to service.
Figure 3
14

IMPORTANT:
Adjustments must be performed by a qualified technician only.
IMPORTANT:
•The appliance is shipped from the factory equipped for natural gas and adjusted for sea level to 2000
feet elevation.
Figure 4
15

Operation
FIRE HAZARD
IF YOU SMELL GAS:
•DO NOT try to light any appliance.
•DO NOT touch any electrical switch
•DO NOT use any telephone in your building.
In the event a gas odor is detected, shut down the unit at the main gas shutoff valve and contact your local gas
supplier from a neighboring location.
Follow the instructions received from the gas supplier immediately and exactly.
GENERAL OPERATIONAL NOTES
•Carefully read the description of the grill operation on the specification sheet.
•Do NOT use this appliance if it has been submerged in water.
•Call a qualified technician to examine the appliance and to service or replace any component which has
been submerged. Burners which have been allowed to become wet must be thoroughly dried before
use.
•For initial startup, and any time the gas supply has been shut-off, it may take several minutes to light
the pilot while air in the piping and manifolds is purged.
•The burner control knobs must be turned by hand only. Never use tools to turn the control knob. If the
knob will not turn by hand, DO NOT attempt to force or repair it. Forced or improperly repaired valves
pose the risk of fire and/or explosion.
•Make sure burners, pilot burner and grease tray are properly installed before attempting to operate.
LIGHTING THE PILOT LIGHT
1. Before lighting the pilot light, smell all around the appliance area for gas. Be sure to smell near floor
level because some gas is heavier than air and will settle to the floor.
2. For initial startup, and any time the gas supply has been shut-off, it may take several minutes to light
the pilot while air in the piping and manifolds is purged.
16

The pilot light must be lighted by hand:
1. Turn all control knobs to the full OFF position.
2. The pilot is located adjacent to one leg of the burner, and is accessible through the front panel
opening.
3. Be sure the gas shut-off valve is ON and the appliance has had time for the air to be purged
from the lines. Attempt to light the pilot every 15 seconds after the gas valve is turned on.
4. Light the pilot with a long match or fireplace lighter.
5. DO NOT use a cigarette lighter.
SHUT DOWN INSTRUCTIONS
1. Turn all burner knobs to OFF.
2. Turn all pilots OFF.
3. Turn the main gas supply OFF.
OPERATION
1. Inspect the unit for cleanliness before use. Clean as necessary. See Cleaning Instructions.
2. Be sure the pilot light is lit before operation.
3. The burner control knobs must be turned by hand only. Never use tools to turn the control knob.
4. The control used in this gas grill provides a continuous range of settings from OFF to ON.
5. Light the burner by turning the control knob to the ON position until fire forms completely in all sections
of the burner. Set the control knob to the desired position. The setting can be readjusted at any time.
Cooking Recommendations:
•Save energy by turning the temperature control knob OFF any time the grill is not in use. Gas burners
provide full heat instantly, making it unnecessary to leave the unit on during intermittent.
•To decrease the amount of grease contacting the radiants, the grate may be raised. Invert the grate so
that the rear grate hooks are at the bottom and the grate sits at a slight angle.
Figure 5
17

FIRE HAZARD
NEVER attempt to force or repair a stuck control valve.
Forced or improperly repaired valves pose the risk of fire and/or explosion.
FIRE AND EXPLOSION HAZARD
If the pilot light should be extinguished, turn off the gas shut-off valve.
Allow the appliance to vent for five minutes before attempting to re-light.
HOT SURFACE
Exposed surfaces can be hot to the touch and may cause burns.
Figure 6
18

Cleaning Instructions
FIRE HAZARD
Shut off the gas supply valve before cleaning.
BURN HAZARD
Allow hotplate to cool completely before cleaning.
IMPORTANT:
•DO NOT spill or pour water into controls.
•DO NOT submerge cabinet in water. Damage to internal components will occur. Damage to internal
components from water damage is NOT covered by warranty.
•DO NOT allow gas control valves, main burners or pilot burners to become wet. Never pour or splash
water into cabinet. Wet burners must be thoroughly dried before use.
•DO NOT use steel wool or metal scouring pads to clean cabinet or grease tray.
•Good sanitation is vital to the quality of the final food product. Be sure to clean in all corners and
crevices where grease and other cooking debris can accumulate.
PREPARATION:
1. Turn both temperature control knobs OFF.
2. Allow grill to cool completely.
3. Disconnect grill from electric power.
FREQUENCY:
Daily
TOOLS:
•Bristle Brush
•Clean Cloth or Sponge
•Mild Detergent
•Cleaner Formulated for Stainless Steel
•Warm Water
19

CLEANING
1. Remove the grates from the grill. Clean grates:
a. Grate may be washed in sink or dishwasher.
b. Dry the grate and apply a light coating of cooking oil.
2. Remove and clean the drip pan:
a. Stubborn food particles maybe removed with a plastic scouring pad.
b. Drip pan may be washed in a sink or dishwasher.
3. Clean grill cabinet:
a. Use a plastic scouring pad to remove any remaining food particles from the cabinet.
b. Clean the cabinet with a soft damp cloth or sponge and mild detergent. Rinse by wiping with a soft
cloth moistened with clean water. Dry with a soft cloth.
5. Reassemble grill:
a. Reinstall drip pan.
b. Reinstall grates.
CLEANING BURNERS
PREPARATION:
1. Turn gas shut-off valve OFF.
2. Allow grill to cool before cleaning.
FREQUENCY:
As Needed
TOOLS:
•Plastic Scouring Pad, Soft-Bristled Fiber Brush
•Clean Cloth or Sponge
•Mild Detergent
•Cleaner Formulated for Stainless Steel
•Warm Water
20
