Lokkii PERFECTION PLUS 828B User manual

ASSEMBLY INSTRUCTION
PRODUCT GUIDE
Model. 828B
Features
• AllWeatherPowderCoatedFrame
• PorcelainCoatedlid,PorcelainCoatedBowl
• HingedLid
• OnePieceStainlessSteelFrameJoints
• PorcelainCookingSurface
• StainlessSteelTemperatureGauge
• StainlessSteelAirVent
• UpperRack
• OneClick™AirControlAshPan
• LiftoutGrillCentrewithRemovableHandle
• AllTerrainRubberWheels
• EasyAssembly
Assembled Size
Width: 22”/56cm
Height:37”/94cm
CookingHeight:30.7”/78cm
PERFECTION PLUS
Thebrand“Lokkii”,“PerfectionBarbecue”andallTradeMarksUnderthebrandarethepropertyofGHHCL.
www.lokkii.com

Safety Instructions
Non-observanceofthesesafetyinstructionsandprecautionscanleadtoseriousinjuryandvoidofwar-
ranty.
Pleasereadthefollowinginstructionsbeforeusingyourbarbecue.
1. Thisbarbecuemayonlybeusedoutdoors,neverindoors.
2. Beforeusingthebarbecue,positiontheBBQonaatsurface,awayfromoverhangsandtreesoutof
thewindasmuchaspossible.
3. Keepasecuredistanceof1.5metersfromcombustiblematerials.
4. Donotuseuidssuchaspetrolorsimilarhighlyammablespiritstolightorre-lightthebarbecueor
addtowarmorhotcharcoal!
5. Donotleavehotgrillorhotcoalsandashesunattended.
6. ThemaximumamountoffuelfortheseBBQsis3.6KG(8Lb)
• Followinstructionsonthefuelbagcarefully.
• DonotputthelidontheBBQbeforetheamehasdiedout.
• “Donotcookbeforethefuelhasacoatingofash”.
Warning:
1. TheCharcoalwillbeveryhot,takesuitableprecautions.
2. Donotlightandoperategrillwithouttheashpaninplace.
3. Wearheatresistantovenmittswhengrillingoradjustingtheventholes.
4. Whenextinguishingcharcoalbriquettes,placethelidonthebowlandcloseallairvents.
Donotusewater.
5. Donotremoveashesuntilallcharcoalbriquettesarecompletelyburnedoutandfullyextinguished.
6. Removeashesbeforegrillingagain.Insuretheashesarecold.
7. Alwayskeepchildrenandpetsawayfromthebarbecue.
Maintenance:
• Cleanthegrillwithacleanersuitableforporcelainsurfaces.Cleanthedroppanwithsoapand
water.
• NEVERusesteelbrushes,aggressivedetergentsorsharpobjectsonporcelainsurfaces!
Thiswilldamagethesurface!
• Toextendthelifeofyourbarbecue,useasuitablecover.
• StoretheBBQinadryarea.
“ATTENTION!
This barbecue will become very hot, do not move it during operation”
“Do not use indoors”
“CAUTION!
Do not use spirit, petrol or comparable uids for lighting or re-lighting”
“WARNING! Keep children and pets away”
P. 2

Preparing to use your grill
Lighting
Beforecookingwithyourgrill,thefollowingstepsshouldbefollowed.
• Cleanallinteriorsurfacesincludinggrillsandgrateswithmildsoapandwater,anddrythesurfaces.
• Buildasmallreonthecharcoalpan.
• Oncethecharcoalhasturnedgrey,closelid,positionallventstofullyopen.
• Allowthecharcoaltoburnforatleasttwohours.
NEVERPAINTTHEINTERIOROFTHEGRILL!Yourgrillisporcelaincoatedandifcaredforcorrectly,willgive
youmanyyearsofuse.
NOTE:
• Thegrateiscoatedwithporcelain,whichisafragilecoating.Handlewithcaretoavoiddamage.Do
notcoolthegrateincoldwaterwhileitisstillhotorthecoatingmaycrack.Letgratecoolonit’s
own.
• Somepartsofthegrillhavebeenpre-oiledatthefactory.Pleaseburnotheoilbeforecooking.
Please see information regarding Uncoated Cast Iron Inserts below.
Cast Iron Inserts: (Sold Separately)
Beforeusingacastirongrateorothercastironcookinginserts,washitthoroughlywithamildsoapand
water.Rinsewithhotwateranddrycompletelywithasoftclothorpapertowel.NEVERALLOWTODRAIN
DRYORWASHINDISHWASHER.Nowseasonthegrateswithvegetablecookingoiltopreventrustand
sticking.
RegularBriquette’s,InstantLightBriquettesorLumpwoodmayuseasafuelsourceforgrilling.When
ignitingregularbriquettesorlumpwoodcharcoal,donotuserelightersthathavepetroleumbasesor
thelikeasthesewilltaintthefoodyoueat.
DonotuseaChimneystarterforinstantlightbriquettes
Building Your Fire:
1. FormthecharcoalbriquettesorLumpwoodintoapyramidonthecharcoalgrate.
Themaximumamountofcharcoalforthisgrillis3.6KG(8LBS).
2. SolidFirestarters:           
A:Placetherestarterinthebaseofthepyramid.LighttheFirestartesinseverallocationstoensure
anevenburn.
3. LiquidorGelFirestarters,coatthebriquettesorlumpwoodwiththeliquidorgelandlightaccording
tothemanufacturer’sinstructions.
4. Always light the re with the grill lid open.
Leavelidopenuntilbriquettesarefullylit.
Caution:Failuretoleavethelidopencouldtrapfumesfromcharcoallighteruidingrillandmay
resultinaashrewhenlidisopened.
P. 3

Grill Maintenance
5.Neveraddcharcoallighteruidortheliketohotorwarmcoalsthiscanbeextremelydangerous.
6.Oncetherehasburnedoutthecharcoalhasturnedgrey,spreadthecharcoaloutusingalong
HandledBBQtool
7.Youarereadytocook
*Always use caution when handling hot coals to prevent injury.
• Allowenoughtimeforproperlybuildingthereandgettingthegrilluptodesiredtemperature
beforeattemptingtocook.
• Risingheatwillmoveupandoutofthegrillpullingincoolerairbehinditwhichprovidesoxygen
forthere.Yourgrillhasairventsthatcontrolairowwhichletsyounetunethetemperature.
Afterthereisestablishedandthegrillreachesthedesiredcookingtemperature,theairventscan
beleftcompletelyopen,providingmaximumairowforahighertemperatureorclosedasneeded
todecreaseairowforalowertemperature.
• IfyourBBQistoohot,spreadthecoalsoutabitmore,thismakestherelessintense.
• Partiallyclosingthegrillventsreducestheamountofoxygenthatfeedsthere.
• Whenaddingbriquettes,allowthecoalstoashoverbeforecooking.
• Direct Grilling,theignitedcoalsarespreadinasinglelayerunderthefood.Thisiscalleddirectgrill-
ingandisappropriateforquick-cookingitemssuchashamburgers,steaksandmostseafood.
• Indirect Grilling,thismethodisforlong,slowcookinginacoveredgrill.
• Indirectgrillingmethod,withcoalstoeithersideofadrippanandthefoodoverthepanratherthan
directlyoverthecoals.Thecoalsarepiledtwoorthreecoalsdeepononesideofthegrill,ordivided
andpiledontwosides.Leaveanemptyspacenexttothecoalsorbetweenthem.Placeadrippan
inthecentreofthegrillingrack,llthiswithwater,wineorbeer,thiswillenhancetheavourofthe
foodandstopthefoodfromdryingout.Indirectgrillingtakeslongertocookyourfood.
Makesurecoalsarecompletelyextinguishedandcoldbeforecleaninginsideofthegrill.
Cleanoutallremainingashes,Ashescollectmoisture,whichcanleadtodecayofyourgrill.
Wipeouttheinsideofthegrillwithadampclothorpapertowels.
ItisadvisabletocoveryourBBQtoprotectitfromtheelements.
Porcelain Cooking Surface:
Thecookingsurfaceofyourgrillisporcelain.Donotusescrapers,sharpinstrumentsortheliketoclean
thegrillingsurface,thiswilldamagetheporcelain.Oncethegrillingsurfacehascooleddownthesurface
canbewashedwithmilddetergentandwater,besuretothoroughlydrythesurfaceonceclean.
Grilling
P. 4

Package Contents
PART
A
B
C
D
E
F
G
H
J
L
M
N
O
DESCRIPTION
Temperature Gauge
Lid
Handle
Warming Rack
Centre Grill
Main Grill
Charcoal Rack
Insert Vent
Left Leg
Front Leg
Ash Pan
QUANTITY
1
1
3
1
1
1
1
1
1
1
1
PART
P
Q
R
S
U
V
W
X
Y
Z
A1
A2
DESCRIPTION
Bottom Back
Wheel Hub
Wheel
Right Leg
Bottom Bowl
Right Hinge Bowl
Left Hinge Bowl
Grill Lifter
Right Hinge Lid
Left Hinge Lid
Top Upper Vent
Bottom Upper Vent
QUANTITY
1
2
2
1
1
1
1
1
1
1
1
1
P. 5

Hardware List
PART
AA
BB
CC
DD
EE
FF
GG
Qty
7 pcs
11 pcs
7 pcs
1 pc
6 pcs
2 pcs
19 pcs
NAME
M6 Flange Nut
M6 x 12 Bolt
M6 x 20 Bolt
M6 Nut
Cotter Pin
Hinge Pin
Flat Washer
Preparation
Beforebeginningassemblyofproduct,makesureallpartsarepresent.Comparepartswithpackage
contentslistandhardwarecontentslist.Ifanypartismissingordamaged,donotattempttoassemble
theproduct.
Estimated Assembly Time: 30minutes.
ToolsRequiredforAssembly(notincluded):PhilipsHeadScrewdriverandAdjustableWrench.
P. 6

Assembly Instructions
1
2
Hardware Used:
M6x12Boltx3
Hardware Used:
CotterPinx2
P. 7

3
4
Hardware Used:
M6x20Boltx6
FlatWasherx6
Hardware Used:
M6FlangeNutx2
M6x12Boltx4
FlatWasherx6
P. 8

5
6
Hardware Used:
M6FlangeNutx2
M6Nutx1
P. 9

Nut
7
8
Hardware Used:
M6FlangeNutx2
FlatWasherx2
P.10

Hardware Used:
CotterPinx2
HingePinx2
9
10
Hardware Used:
M6FlangeNutx1
M6x12Boltx4
M6x20Boltx1
FlatWasherx5
P.11

11
12
Hardware Used:
CotterPinx2
P.12

13
TightenAllHardware.
P.13

Warranty
Date Purchased:
Retailer: Serial Number:
5 Years Limited Warranty
* To activate your warranty, register your products within 7 days of purchase.
Go to www.lokkii.com to register your BBQ.
Thiswarrantyonlyappliestounitspurchasedfromanauthorizedretailer.Manufacturerwarrantstotheoriginal consumer-purchaser onlythatthisproductshall
befreefromdefectsinworkmanshipandmaterialsaftercorrectassemblyandundernormalandreasonablehomeusefortheperiodsindicatedbelowbeginning
onthedateofpurchased*.Themanufacturerreservestherighttorequirethatdefectivepartsbereturned,postageandorfreightpre-paidbytheconsumerfor
reviewandexamination.
*Note: A dated sales receipt WILL be required for warranty.
The original consumer-purchaser will be responsible for all shipping charges for parts replaced under the terms of this limited warranty.
ThislimitedwarrantyisapplicableintheEU,UK,Australia,NewZealandandScandinaviaonlyandisonlyavailabletotheoriginalowneroftheproductandisnot
transferable.
Manufacturer requires proof of your date of purchase. Therefore keep your sales slip or invoice.
ThislimitedwarrantyappliestothefunctionalityoftheproductONLYanddoesnotcovercosmeticissuessuchasscratches,dents,corrosionsordiscolourationby
heat,abrasiveandchemicalcleanersoranytoolsusedintheassemblyorinstallationoftheappliance,surfacerust,orthediscolourationofsurfaces.
RUST is not considered a manufacturing or materials defect.
This limited warranty will not reimburse you for the cost of any inconvenience, food, personal injury or property damage.
This Limited Warranty Covers:-
1. Bowl and Lid against Burn through 5 Years
2. Frame 2 Years
3. Cooking Grates – Porcelain - Against Burn through 2 Years
4. Charcoal Grate – Steel - Against Burn through 2 Years
5. Ash Pan - Steel - Against Burn through 2 Years
6. All other Parts 2 Years
ITEMS MANUFACTURER WILL NOT PAY FOR:
1. Shippingcost,standardorexpedited,forwarrantyorreplacementparts.
2. Repairswhenyourproductisusedforotherthannormal,single-familyhouseholdorresidentialuse.
This warranty does not cover commercial use of this unit.
3. Damage,failures,oroperatingdicultiesresultingfromaccident,alteration,carelesshandling,misuse,abuse,re,ood,actsofGod,improperinstallationor
maintenance,installationnotinaccordanceoruseofproductsnotapprovedbythemanufacturer.
4. Anyfoodlossduetoproductfailuresoroperatingdiculties.
5. Repairstopartsresultingfromunauthorizedmodicationsmadetotheproduct.
DISCLAIMER OF IMPLIED WARRANTIES and LIMITATION OF REMEDIES
Repairorreplacementofdefectivepartsisyourexclusiveremedyunderthetermsofthislimitedwarranty.Intheeventofpartsnolongerbeingavailable,theman-
ufacturerreservestherighttosubstitutelikeorsimilarpartsthatareequallyfunctional.
Manufacturerwillnotberesponsibleforanyconsequentialorincidentaldamagesarisingfromthebreachofeitherthislimitedwarrantyoranyapplicableimplied
warranty,orforfailureordamageresultingfromactsofGod,impropercareandmaintenance,greasere,accident,alteration,replacementofpartsbyanyoneother
thanManufacturer,misuse,transportation,commercialuse,abuse,hostileenvironments(inclementweather,actsofnature,animaltampering),improperinstallation
orinstallationnotinaccordancewithlocalcodesorprintedmanufacturerinstructions.
THISLIMITEDWARRANTYISTHESOLEEXPRESSWARRANTYGIVENBYTHEMANUFACTURER.NOPRODUCTPERFORMANCESPECIFICATIONORDESCRIPTIONWHER-
EVERITMAYAPPEARISWARRANTEDBYMANUFACTUREREXCEPTTOTHEEXTENTSETFORTHINTHISLIMITEDWARRANTY.
ANYIMPLIEDWARRANTYPROTECTIONARISINGUNDERTHELAWSOFANYCOUNTRY,INCLUDINGIMPLIEDWARRANTYOFMERCHANTABILITYORFITNESSFORA
PARTICULARPURPOSEORUSE,ISHEREBYLIMITEDINDURATIONTOTHEDURATIONOFTHISLIMITEDWARRANTY.
Neither dealers nor the retail establishment selling this product has any authority to make any additional warranties or to promise remedies in addition to
or inconsistent with those stated within this warranty.Manufacturer’smaximum liability,inanyevent,shallnotexceedthepurchasepriceoftheproductpaid
bytheoriginalconsumer.
If you wish to obtain information or Warranty Issues
Contact:
perfec[email protected]
ConsumerreturnswillnotbeacceptedunlessavalidReturnAuthorizationisrstacquired.Authorizedreturnsmustbeclearlymarkedontheoutsideofthepack-
agewithReturnAuthorizationnumberandthepackageisshippedfreight/postagepre-paid.Consumerreturnsthatdonotmeetthesestandardswillberefused.
PERFECTION PLUS
M.828B
P.14
L
I
M
I
T
E
D
W
A
R
R
A
N
T
Y
