ICI GAS DETECTIR Series User manual
Guide
2105 W. Cardinal Dr. Beaumont, TX 77705
Phone: (409) 861-0788
Toll Free: (866) 861-0788
infraredcameras.com
suppor[email protected]
We Are IR ™
ICI cameras fall under US Federal Law and Export Control.
GAS DETECTIR SERIES
QUICK START GUIDE
Edit Text Outlines
IndustryIndustry
2
©Copyright 2022, Infrared Cameras, Inc. - All rights reserved. The
contents of this document may not be reproduced in whole or in parts
without the written consent of the copyright owner.
Printed in the United States of America.
2105 W. Cardinal Dr.
Beaumont, TX 77705
(866) 861-0788
www.infraredcameras.com
THE MANUFACTURER RESERVES THE RIGHT TO ALTER THE
SPECIFICATIONS OF THE PRODUCT WITHOUT PRIOR NOTIFICATION. THE
MANUFACTURER ALLOWS HIMSELF THE RIGHT TO MODIFY WITHOUT
ANY PRELIMINARY OPINION THE TECHNICAL SPECIFICATIONS OF THE
PRODUCT. THIS MANUAL MAY CONTAIN TECHNICAL INACCURACIES OR
TYPOGRAPHICAL ERRORS.
NOTICE ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN
THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED
WITHOUT WARRANTY OF ANY KIND. NOTWITHSTANDING ANY OTHER
WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE ARE
PROVIDED “AS IS” WITH ALL FAULTS. ICI DISCLAIMS ALL WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND
NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE,
OR TRADE PRACTICE.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE
ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION
PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED
HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE
SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR ICI
REPRESENTATIVE FOR A COPY.
IN NO EVENT SHALL ICI BE LIABLE FOR ANY INDIRECT, SPECIAL,
CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT
LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING
OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF ICI HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
3
Package Includes
Gas DetectIR Device
Battery
Power Adapter
ENSURE ALL SYSTEM EQUIPMENT AND COMPONENT ITEMS ARE
PRESENT BEFORE BEGINNING INSTALLATION
SD Card
AV Cable
Power Adapter Cable Charger Cable
USB Cable
Charging Base
4
or Mount the fully charged device
to a tripod using the ¼”-20
mount located on the body.
The camera can be used as
a handheld device.
Set Up
A.
MAKE SURE TRIPODS DO NOT BLOCK THE DIRECT PATH OF
THROUGH TRAFFIC TO ENSURE THE EQUIPMENT WILL NOT BE
MOVED OR KNOCKED DOWN. USING A DIVIDING BARRIER WILL
HELP KEEP TRIPODS SEPARATE FROM THE PATH.
5
B.
Power on device.
THE INTERNAL SOFTWARE MAY TAKE UP TO 5 MINUTES TO
LAUNCH. DO NOT POWER OFF THE DEVICE OR PRESS BUTTONS
WHILE SOFTWARE IS LAUNCHING. PRESSING BUTTONS OR
TURNING OFF THE DEVICE MAY CORRUPT THE FILE SYSTEMS.
TURN ON THE CAMERA BY PRESSING AND HOLDING THE POWER
BUTTON FOR AT LEAST THREE SECONDS.
PRESS AND HOLD THE POWER BUTTON FOR MORE THAN 5
SECONDS TO SHUT DOWN THE CAMERA.
THE THERMAL IMAGER NEEDS SUFFICIENT WARM-UP TIME
FOR THE MOST ACCURATE TEMPERATURE MEASUREMENTS
AND BEST IMAGE QUALITY. THIS TIME CAN OFTEN VARY BY
ENVIRONMENTAL CONDITIONS. IT IS BEST TO WAIT A MINIMUM
OF 10 MINUTES AFTER THE SOFTWARE HAS FULLY LAUNCHED
BEFORE MEASURING TEMPERATURES.
6
SET THE THERMAL DEVICE UPRIGHT ON A LARGE FLAT SURFACE
WHEN REMOVING OR REPLACING THE BATTERY.
DO NOT FORCE THE BATTERY INTO THE BATTERY BAY. IF USER
FEELS SIGNIFICANT RESISTANCE REMOVE THE BATTERY AND
ENSURE METAL CONTACTS ARE ALIGNED BEFORE TRYING TO
PLACE BATTERY INTO THE BATTERY BAY.
Battery Installation
ENSURE BATTERY IS INSERTED PROPERLY. IMPROPER INSERTION
OF BATTERY MAY EXPOSE THE BATTERY AND INTERNAL
ELECTRONICS TO ELEMENTAL DAMAGE.
B.
A.
Ensure metal contacts are aligned;
then, push the battery into the
battery bay until the battery is fully
seated in the battery bay. User
should hear a click sound.
Pinch the battery bay buckles
simultaneously. Battery will be
released from the battery bay.
C.
Pull battery from battery bay.
7
Charging Instructions: Option 1
A.
While a battery is inside the
device, align the power adapter
prongs; then, plug the power
adapter cable into the device.
CHARGE THE BATTERY FOR A MINIMUM OF 3 HOURS BEFORE
USING THE DEVICE.
ICI DOES NOT RECOMMEND CHARGING THE DEVICE WHILE IT IS
ON A TRIPOD. LAY DEVICE FACE DOWN ON A FLAT AND STABLE
DESK OR TABLE WHILE CHARGING.
ENSURE THE IMAGER IS NEAR ROOM TEMPERATURE BEFORE
CHARGING THE DEVICE. DO NOT CHARGE IN EXTREMELY HOT OR
COLD AREAS. THE BATTERY CAPACITY MAY BE DECREASED IF
CHARGED IN AN EXTREME TEMPERATURE ENVIRONMENT.
B.
D.
Plug the power adapter cord
into the power adapter.
Plug power cord into a
110/120V electrical outlet.
8
B.
Plug power cord into a
110/120V electrical outlet.
Charging Instructions: Option 2
A. B.
REMOVE THE BATTERIES FROM THE DEVICE BEFORE CONTINUING
WITH THIS METHOD OF CHARGING.
Ensure metal contacts are
aligned; then, insert batteries
into the battery charging base.
Plug charger cable into the
battery charging base.
IF YOU DO NOT USE THE IMAGER FOR A LONG PERIOD OF TIME,
PUT THE DEVICE IN A COOL AND DRY ENVIRONMENT. THE
BATTERY WILL DISCHARGE OVER TIME; THEREFORE,THE IMAGER
SHOULD BE CHARGED OCCASIONALLY TO PREVENT DAMAGE TO
THE BATTERY OR THE DEVICE.
9
SET THE THERMAL DEVICE UPRIGHT ON A LARGE FLAT SURFACE
WHEN REMOVING OR REPLACING THE BATTERY.
Memory Card
DO NOT FORCE SD CARD INTO THE SLOT. THE SIDE OF THE CARD
WITH CONTACT PINS MUST BE INSERTED FIRST. IF THERE IS
RESISTANCE FLIP THE CARD AROUND AND TRY AGAIN.
B.
A.
C.
Slide the connector bay latch lock and
open the connector bay latch door.
Close the battery bay lock. User
should hear a click sound.
Slide the battery bay cover latch.
10
Infrared Cameras, Inc.
2105 W. Cardinal Dr.
Beaumont, TX 77705
Phone: Toll Free: International:
Website: www.infraredcameras.com
ICI manufactures complete systems and software. We can provide complete
engineering, software, and OEM solutions. Our Fortune 500 clients rely on us
for infrared equipment and thermography training (which we offer through the
Infrared Training Institute).
In addition to providing custom germanium, silica, and sapphire optics, we also
build windows for enclosures, as well as custom pan and tilt units. We can even
provide customizable explosion-proof systems.
Our knowledge and experience stems from years of using infrared imaging
and temperature measurement instruments to provide solutions to: managers,
engineers, scientists, inspectors and operators in space, power companies,
medical, pulp and paper, food industry, research and development, and various
process industries. You can see our products and services used in industrial,
commercial, and government applications worldwide. Originally named Texas
Thank you for your dedicated and continued support.
