ICON ITSOH56R Assembly instructions

SAFETY

Page 1
TOOL STORAGE SAFETY
For technical questions, please call 1-888-866-5797.
IMPORTANT SAFETY
INSTRUCTIONS
When using your garage equipment,
basic safety precautions should always be
followed, including the following:
1. To prevent serious injury and DEATH from tipping,
Do not have more than one drawer open at a time.
2. DO NOT SIT, STAND OR CLIMB ON THIS ITEM.
DO NOT STEP IN OR ON DRAWERS.
3. Do not allow children to play with or near this
item. This item is NOT children’s furniture.
4. Do not exceed weight capacity. Do not exceed
drawer weight capacity, based on connected pair
of slides. Evenly distribute load from bottom up.
Uneven loading causes tipping. Be aware of
dynamic loading! Sudden load movement may
briefly create excess load causing tipping.
5. Close and lock drawer(s) before moving.
Do not pull, push to move.
6. Center an overhead or chest securely
within lip on top of chest or cabinet.
7. Place an overhead or chest on top of
matching chest or cabinet only.
8. Do not place objects on top of an
overhead or hang objects off side.

Page 2
TOOL STORAGE SAFETY
For technical questions, please call 1-888-866-5797.
9. Have assistant help place an overhead or
chest on top of chest or cabinet.
10. Use only on a flat, level, hard and smooth surface capable
of safely supporting a fully loaded unit.
Use care when rolling unit over concrete seams.
11. Do not lift a roll cab using handle(s).
Do not lift while loaded.
12. Do not use as a stand-alone unit.
13. Wear ANSI-approved safety goggles and
heavy-duty work gloves during assembly.
14. Read instruction manual before assembly and/or use.
15. Close lid when not in use. Lid must be
open for drawers to be unlocked.
16. Lock swivel casters after moving.
17. Do not mount on truck bed or any other moving object.
18. Assemble only according to these instructions.
Improper assembly can create hazards.
19. Do not operate equipment with a damaged cord or if
the equipment has been dropped or damaged – until
it has been examined by a qualified service person.
20. Do not let a cord hang over the edge of the
table, bench, or counter or come in contact
with hot manifolds or moving fan blades.

Page 3
TOOL STORAGE SAFETY
For technical questions, please call 1-888-866-5797.
21. If an extension cord is necessary, a cord with a current
rating equal to or more than that of the equipment should
be used. Cords rated for less current than the equipment
may overheat. Care should be taken to arrange the
cord so that it will not be tripped over or pulled.
22. Always unplug equipment from electrical outlet when
not in use. Never use the cord to pull the plug from
the outlet. Grasp plug and pull to disconnect.
23. Loop cord loosely around equipment when storing.
24. To reduce the risk of electric shock or fire,
never overload receptacles. Refer to markings
for the proper load on receptacles.
25. To reduce the risk of electric shock, do not
use on wet surfaces or expose to rain.
26. To reduce the risk of fire, do not operate equipment in the
vicinity of open containers of flammable liquids (gasoline).
27. Adequate ventilation should be provided when
working on operating internal combustion engines.
28. Keep hair, loose clothing, fingers, and all
parts of body away from moving parts.
29. Weight capacity and other product capabilities apply
to properly and completely assembled product only.
30. Use only as described in this manual. Use only
manufacturer’s recommended attachments.
31. Keep assembly area clean and well lit.

Page 4
TOOL STORAGE SAFETY
For technical questions, please call 1-888-866-5797.
32. Do not assemble when tired or when under the
influence of alcohol, drugs or medication.
33. Keep bystanders out of the area during assembly.
34. To reduce the risk of injury, close supervision is necessary
when this product will be used around children.
35. Use as intended only.
36. Inspect before every use;
do not use if parts are loose or damaged.
37. Maintain product labels and nameplates. These carry
important safety information. If unreadable or missing,
contact Harbor Freight Tools for a replacement.
SAVE THESE
INSTRUCTIONS.

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
TM
ITSOH56 series shown.
OVERHEAD
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 22h
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using
this product.
Failure to do so can result in
serious injury.
SAVE THIS MANUAL.

Page 1
OVERHEAD
For technical questions, please call 1-888-866-5797.
Model Size Color Item
ITSOH56R 56″ Red 56136
ITSOH56BLU 56″ Blue 56285
ITSOH56BLK 56″ Black 56286
ITSOH56GN 56″ Green 56287
ITSOH73R 73″ Red 56141
ITSOH73BLU 73″ Blue 56305
ITSOH73BLK 73″ Black 56306
ITSOH73GN 73″ Green 56307
Assembly Instructions
Read the ENTIRE IMPORTANT SAFETY
INFORMATION section at the beginning of this
document including all text under subheadings
therein before set up or use of this product.
1. Assemble on a flat, level, hard and smooth surface
capable of safely supporting a fully loaded Roll Cab.
2. Bolt Handles (2) to each end of the Housing using two
M8 Handle Bolts (3) each. Tighten hardware securely.
Housing Handle (2)
Handle
Bolt (3)
Figure A:

Page 2
OVERHEAD
For technical questions, please call 1-888-866-5797.
3. Place Overhead atop Top Chest/Work
Center mounted to a Roll Cab.
Figure B:
4. If mounting to Top Chest, remove its top Drawers.
5. Use four Bolts (15) from within the Top Chest/
Work Center to attach the Overhead to the top.
6. If removed, reinstall the top Drawers into the Top Chest.

Page 3
OVERHEAD
For technical questions, please call 1-888-866-5797.
Operation Instructions
Read the ENTIRE IMPORTANT SAFETY
INFORMATION section at the beginning of this
document including all text under subheadings
therein before set up or use of this product.
1. Do not exceed weight capacities.
2. Close and lock Overhead compartment
before moving assembled Roll Cab.
Maintenance and Servicing
Procedures not specifically explained
in this manual must be performed
only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If any part becomes
damaged, have the problem corrected before further use.
1. PERIODICALLY, inspect the general
condition of the Overhead. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• brake operation,
• caster swivel function and movement,
• cracked or broken parts,
• any other condition that may affect its safe operation.
2. Wipe external surfaces of the Overhead with clean cloth.

Page 4
OVERHEAD
For technical questions, please call 1-888-866-5797.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS
PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS DOCUMENT AS A REFERENCE TOOL ONLY.
NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY
KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED
TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT
HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF
THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS
AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN
BY CERTIFIED AND LICENSED TECHNICIANS, AND
NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS
TO THE ORIGINAL PRODUCT OR REPLACEMENT
PARTS THERETO, OR ARISING OUT OF HIS OR HER
INSTALLATION OF REPLACEMENT PARTS THERETO.
Record Serial Number Here:
Note: If product has no serial number, record
month and year of purchase instead.
Note: Some parts are listed and shown for illustration
purposes only, and are not available individually as
replacement parts. Parts may not be interchangeable.
Specify UPC number when ordering:
56″ Red: UPC 792363561365
56″ Blue: UPC 792363562850
56″ Black: UPC 792363562867
56″ Green: UPC 792363562874
73″ Red: UPC 792363561419
73″ Blue: UPC 792363563055
73″ Black: UPC 792363563062
73″ Green: UPC 792363563079

Page 5
OVERHEAD
For technical questions, please call 1-888-866-5797.
Parts List and Diagram
Parts List
Part Description Qty
1 Housing 1
2Handle 2
3M8x65 Handle Bolt 4
4Drawer Trim End Cap 2
5Badge 1
6Front Trim 2
7Strip Protector 4
8Door 1
9Door Trim 1
10 Cushion Rubber 2
11 Gas Strut 2
12 90° Lock 1
13 Lock Bar 1
14 Lock Bar Protector 2
15 M8x 20 Bolt 4

Page 6
OVERHEAD
For technical questions, please call 1-888-866-5797.
Assembly Diagram

Page 7
OVERHEAD
For technical questions, please call 1-888-866-5797.
ICON™ TOOL STORAGE LIMITED
LIFETIME WARRANTY
Harbor Freight Tools makes every effort to assure that its
products meet the highest quality and durability standards.
Harbor Freight Tools warrants to the original purchaser of
this ICON™ Tool Storage that the parts and components of
the ICON™ Tool Storage will be free from defects in material
and manufacturing workmanship during the ICON™ Tool
Storage’s useful life. If the parts or components do not
perform in accordance with this warranty, Harbor Freight Tools
will provide the parts necessary to put the ICON™ Tool
Storage back in working order. Replacement parts may
be obtained by calling 1-888-866-5797 or by e-mailing
[email protected]. Proof of purchase
(original sales receipt) from the original consumer
purchaser must accompany all warranty claims.
This warranty does not apply to damage due directly or
indirectly, to misuse, abuse, negligence or accidents,
unauthorized repair, improper installation, improper storage,
normal wear and tear, neglect, alteration or modification, or
to lack of maintenance. Abnormal use of tool storage units
also includes, without limitation, situations when a unit is
pulled using a vehicle, rolled over large drops, used in a highly
corrosive environment, used as a step stool, overloaded
or modified in any way. This warranty is in lieu of all other
warranties, express or implied, including the warranties of
merchantability and fitness. Harbor Freight Tools is not liable
for incidental, indirect, special, consequential, or punitive
damages or costs arising from the use of this product. Some
states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply
to you. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.

Page 8
OVERHEAD
For technical questions, please call 1-888-866-5797.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
