Icop VDX3-6755 User manual

User Manual
VDX3-6755
with
DM&P Vortex86DX3
1GHz processor
Version 1.0

VDX3-6755 User Manual
ICOP Technology Inc. I
Copyright
The information in this manual is subject to change without notice for
continues improvement in the product. All rights are reserved. The
manufacturer assumes no reasonability for any inaccuracies that may be
contained in this document and makes no commitment to update or to keep
current the information contained in this manual.
No part of this manual may be reproduced, copied, translated or transmitted,
in whole or in part, in any form or by any means without the prior to written
permission of ICOP Technology Inc.
Copyright ⓒ2016 ICOP Technology Inc
Trademarks Acknowledgement
Vortex86DX3TM is the registered trademark of DM&P Electronics Inc.
Other brand names and product names that appear in this document are the
properties and registered trademarks of their respective owners. All names
mentioned herewith are served for identification purpose only.

VDX3-6755 User Manual
ICOP Technology Inc. II
Revision History
Revision Date Remark
1.0 April 1st First version release

VDX3-6755 User Manual
ICOP Technology Inc. III
Table of Contents
1 General Information ............................................................................................................ 1
1.1 Overview ............................................................................................................................ 1
1.2 Block diagram .................................................................................................................... 1
1.3 Specifications ..................................................................................................................... 2
1.4 Ordering Information ...................................................................................................... 4
1.4.1 VDX3-6755 ................................................................................................................... 4
1.4.2 Cable Set ........................................................................................................................ 4
1.4.3 SATA DOM ................................................................................................................. 5
2 Hardware Information ........................................................................................................ 6
2.1 Dimension .......................................................................................................................... 6
2.2 Board Outline .................................................................................................................... 7
2.3 Connector Location .......................................................................................................... 7
2.4 Connector and Jumper Summary ................................................................................... 8
2.5 Pin Assignments & Jumper Settings .............................................................................. 9
J1: JTAG ................................................................................................................................. 9
J3: PS/2 Mouse ...................................................................................................................... 9
J4: Buzzer ................................................................................................................................ 9
J5: SATA DOM ..................................................................................................................... 9
J6: SATA DOM Power ......................................................................................................... 9
J7: LAN ................................................................................................................................... 9
J8: Giga LAN.......................................................................................................................... 9
J9: USB 0&1 ......................................................................................................................... 12
J10: VGA .............................................................................................................................. 12
J11: Power Connector ......................................................................................................... 12
J12: Reset .............................................................................................................................. 12

VDX3-6755 User Manual
ICOP Technology Inc. IV
J13: LCD Control Port ........................................................................................................ 12
J14: PS/2 Keyboard............................................................................................................. 12
J15: Console Redirection .................................................................................................... 12
J17: COM1 (Isolated RS232) .............................................................................................. 13
J18: COM2 (Isolated RS232) .............................................................................................. 13
J20: Isolated RS485 .............................................................................................................. 13
J21: TTL COM4 (for SerialCAN only) ............................................................................. 13
J22: CANBus ........................................................................................................................ 13
J24: PC/104 Connector – 64 pin ....................................................................................... 14
J25: PC/104 Connector – 40 pin ....................................................................................... 14
J26: 4P Power Source (Interconnect to PC/104 J24) ..................................................... 15
J27: LVDS ............................................................................................................................. 15
3 Software Resources ............................................................................................................ 15
3.1 ICOP Technical Resource Website .............................................................................. 15
4 Technical support ............................................................................................................... 16
4.1.1 Display Introduction ...................................................................................................... 16
4.1.2 Pin Assignment of 24-bit LVDS ................................................................................... 16
4.2.1 BIOS Introduction ......................................................................................................... 16
4.2.2 CPU Clock Adjusting ..................................................................................................... 16
4.2.3 Console Direction ........................................................................................................... 17
4.2.4 Serial Ports Switching ..................................................................................................... 18
4.2.5 IDE Configuration ......................................................................................................... 19
4.2.6 Advanced Configuration ................................................................................................ 20
4.2.7 ACPI Enable.................................................................................................................... 21
5 Basic LCD Panel Setting ................................................................................................ 22
5.1 Introduction .................................................................................................................. 22
5.2 Basic BIOS Setting for LCD ....................................................................................... 23

VDX3-6755 User Manual
ICOP Technology Inc. V
Technical Support Directly from ICOP ................................................................................... 25
User Manual Feedback ............................................................................................................... 25
Warranty ....................................................................................................................................... 26

VDX3-6755 User Manual
ICOP Technology Inc. 1
1 General Information
1.1 Overview
The VDX3-6755 PC/104 family of low-power x86 embedded controller is
designed to meet PC/104 specification with backward compatibility to
provide migration path for projects facing end-of-life challenges with their
existing x86 based PC/104 controller.
In addition, the VDX3-6755 family of controller is designed as a plug in
replacement, with backward compatibility to support legacy software to help
extend existing product life cycle without heavy re-engineering.
The VDX3-6755 is suitable for broad range of data-acquisition, industrial
automation, process control, automotive controller, AVL, intelligent vehicle
management device, medical device, human machine interface, robotics,
machinery control and more
1.2 Block diagram

VDX3-6755 User Manual
ICOP Technology Inc. 2
1.3 Specifications
Processor DM&P SoC CPU Vortex86DX3 - 1GHz
Real Time Clock with Lithium Battery Backup
Cache L1:32K I-Cache, 32K D-Cache, L2 Cache:512KB
Bus PC/104 Standard Compliant
System Memory
1GB/2GB DDR3 Onboard
Watchdog Timer
Software programmable from 30.5us to 512 seconds x2
sets (Watchdog 1 fully compatible with M6117D)
VGA
Integrated 2D VGA chip with dual display support (VGA + LVDS)
VGA: Maximum resolution up to 1920x1080 @ 60Hz
LVDS: Maximum resolution up to 1024x768 @ 60Hz
Single channel 24-bit LVDS
LAN Integrated 10/100Mbps Ethernet
Realtek 8111F 10/100/1000Mbps Ethernet
I/O Interface
SATA 7P Connector x1
Isolated RS-232 port x2
Isolated RS-485 port x1
CAN bus port x1 (Need additional COM to CANBus module)
USB port (Ver. 2.0) x2
10/100Mbps Ethernet port x1
10/100/1000Mbps Ethernet port x1

VDX3-6755 User Manual
ICOP Technology Inc. 3
Connectors
SATA 7P for SATA x1
2.0mm 20-pin header for LVDS x1
2.0mm 10-pin box header for USB x1
2.0mm 10-pin box header for RS232 x2
2.0mm 10-pin box header for VGA x1
2.0mm 10-pin header for COM to CANBus module x1
2.0mm 12-pin header for GbE x1
2.0mm 8-pin header for Ethernet x1
2.0mm 4-pin header for COM to CANBus module x1
2.54mm 5-pin box header for Keyboard x1
2.54mm 5-pin header for Mouse x1
2.54mm 4-pin header for -5V, -12V, +12V, GND x1
2.54mm 3-pin header for RS485 x1
2.54mm 3-pin header for CANBus x1
(Need additional COM to CANBus module)
2.54mm 2-pin header for Reset x1
Power
Requirement Single Voltage +5V @1.15A (Typical)
Weight 80g
Dimensions 90mm x 96mm (3.54 x 3.77 inches)
Operating Temp.
-20℃ ~ +70℃
-40℃ ~ +85℃ (Optional)
Operating
System Support
Free DOS, DOS 6.22, PCDOS 7.1, DR-DOS, x-DOS, OS/2, Windows 7,
Windows Embedded Standard 7, Windows Embedded Compact 7,
Windows Embedded Compact 6, Windows XP Professional, Windows
Embedded Standard(XPE), POS Ready(WePOS), Embedded Linux,
X-Linux, QNX, Vxworks and FreeBSD.

VDX3-6755 User Manual
ICOP Technology Inc. 4
1.4 Ordering Information
1.4.1 VDX3-6755
Product Name 1GB DDR3 onboard 2GB DDR3 onboard
VDX3-6755-1G V /
VDX3-6755-2G / V
SerialCAN / /
Cable-set-6755 / /
1.4.2 Cable Set
Product Name Contents
Cable-set-6755
NET4X2(2.0)-LED x1
NET6X2(2.0)-LED x1
RS232(2.0) x2
USB(2.0) x1
VGA(2.0) x1
PS2KB x1
PS2KB(TEST) x1
SerialCAN

VDX3-6755 User Manual
ICOP Technology Inc. 5
1.4.3 SATA DOM
Product Name MLC SLC 0℃ ~ +70℃ -40℃ ~ +85℃
SDM-SST-2G-H-M V
V
SDM-SST-4G-H-M V
V
ISATA-8G-H-M V
V
ISATA-16G-H-M V
V
ISATA-32G-H-M V
V
ISATA-4G-H-M-X V
V
ISATA-8G-H-M-X V
V
ISATA-16G-H-M-X V
V
ISATA-32G-H-M-X V
V
ISATA-1G-H-S
V V
ISATA-2G-H-S
V V
ISATA-4G-H-S
V V
ISATA-8G-H-S
V V
ISATA-16G-H-S
V V
SDM-SST-2G-H-S-X
V
V
SDM-SST-4G-H-S-X
V
V
SDM-SST-8G-H-S-X
V
V
ISATA-16G-H-S-X
V
V

VDX3-6755 User Manual
ICOP Technology Inc. 6
2 Hardware Information
2.1 Dimension

VDX3-6755 User Manual
ICOP Technology Inc. 7
2.2 Board Outline
2.3 Connector Location

VDX3-6755 User Manual
ICOP Technology Inc. 8
2.4 Connector and Jumper Summary
Nbr. Name Type of Connections Pin Nbr
J1 JTAG Wafer, 1.25mm, 1x6 6
J3 PS/2 Mouse Box Header, 2.54mm, 1x5 5
J4 Buzzer Pin Header, 2.54mm, 1x2 2
J5 SATA SATA 7P Connector, 7x1 7
J6 SATA DOM Power Box Header, 2.0mm, 1x2 2
J7 LAN Pin Header, 2.0mm, 4x2 8
J8 Giga LAN Pin Header, 2.0mm, 6x2 12
J9 USB Pin Header, 2.54mm, 5x2 10
J10 VGA Pin Header, 2.0mm, 5x2 10
J11 Power Connector Terminal Block, 5.omm, 2x1 2
J12 Reset Pin Header, 2.54mm, 1x2 2
J13 LCD Control Port Pin Header, 2.0mm, 1x3 3
J14 PS/2 Keyboard Box Header, 2.54mm, 1x5 5
J15 Console Redirection Pin Header, 2.0mm, 1x2 2
J17 COM1 (Isolate RS232) Box Header, 2.0mm, 5x2 10
J18 COM2 (Isolate RS232) Box Header, 2.0mm, 5x2 10
J20 Isolate RS485 Box Header, 2.54mm, 1x3 3
J21 TTL COM4
(for CANBus module only) Pin Header, 2.0mm, 5x2 10
J22 CANBus Box Header, 2.54mm, 1x3 3
J24 PC/104 Connector - 64 pins Box Header, 2.54mm, 32x2 64
J25 PC/104 Connector - 40 pins Box Header, 2.54mm, 20x2 40
J26 4P Power Source
(Interconnect to PC/104 J24) Pin Header, 2.54mm, 4x1 4
J27 LVDS Pin Header, 2.0mm, 10x2 20
J28 TV-In (Optional) Box Header, 2.0mm, 12x2 24
PWR
LED Power Active LED (Red) SMD LED
LED3 Link LED (Yellow) SMD LED
LED4 Duplex LED (Green) SMD LED

VDX3-6755 User Manual
ICOP Technology Inc. 9
2.5 Pin Assignments & Jumper Settings
J1: JTAG
For JTAG use only
J3: PS/2 Mouse
Pin#
Single Name
Pin # Single Name
1. MSCLK 2 MSDATA
3 NC 4 GND
5 VCC
J4: Buzzer
Pin#
Single Name
Pin # Single Name
1. Buzzer 2 VCC
J5: SATA DOM
Pin#
Single Name
Pin #
Single Name
1. GND 2 TX+
3 TX- 4 GND
5 RX- 6 RX+
7 GND
J6: SATA DOM Power
* The pin 7 support +5V (Optional)
J7: LAN
Pin#
Single Name
Pin #
Single Name
1. LTX+ 2 LTX-
3 LRX+ 4 DUPLEX
5 LED0+ 6 LRX-
7 LED1+ 8 LINK/ACTIVE
J8: Giga LAN
Pin#
Single Name
Pin # Single Name
1. GTX+1 2 GTX-1
3 GRX+1 4 GTXC+1
5 GTXC-1 6 GRX-1
7 GRXD+1 8 GRXD-1
9 LED0+1 10 LED01
11 LED1+1 12 LED1/EESK1
Pin#
Single Name
Pin # Single Name
1. VCC 2 GND

VDX3-6755 User Manual
ICOP Technology Inc. 12
J9: USB 0&1
Pin#
Single Name
Pin # Single Name
1. VCC 2 VCC
3 LUSBD1- 4 LUSBD0-
5 LUSBD1+ 6 LUSBD0+
7 GND 8 GND
9 FGND 10 FGND
J10: VGA
Pin#
Single Name
Pin # Single Name
1. ROUT 2 GND
3 GOUT 4 GND
5 BOUT 6 GND
7 HSYNC 8 GND
9 VSYNC 10 GND
J11: Power Connector
Pin# Single Name
1 +5V
2 GND
J12: Reset
Pin#
Single Name
Pin # Single Name
1. RST_SW 2 GND
J13: LCD Control Port
Pin# Single Name
1 GND
2 Backlight Control Enabled
3 Backlight Control PWM
J14: PS/2 Keyboard
Pin#
Single Name
Pin # Single Name
1. KBCLK 2 KBDATA
3 NC 4 GND
5 VCC
J15: Console Redirection
Pin#
Single Name
Pin # Single Name
1. ENABLE 2 GND

VDX3-6755 User Manual
ICOP Technology Inc. 13
J17: COM1 (Isolated RS232)
Pin#
Single Name
Pin # Single Name
1. NC 2 RXD1
3 TXD1 4 NC
5 GND-ISO-COM1 6 NC
7 NC 8 NC
9 NC 10 NC
J18: COM2 (Isolated RS232)
Pin#
Single Name
Pin # Single Name
1. NC 2 RXD3
3 TXD3 4 NC
5 GND-ISO-COM3 6 NC
7 NC 8 NC
9 NC 10 NC
J20: Isolated RS485
Pin#
Single Name
Pin # Single Name
1. 2RS485+ 2 2RS485-
3 GND
J21: TTL COM4 (for SerialCAN only)
Pin#
Single Name
Pin # Single Name
1. DCD4 2 RXD4
3 TXD4 4 DTR4
5 GND 6 DSR4
7 RTS4 8 CTS4
9 RI4 10 VCC
J22: CANBus
Pin#
Single Name
Pin # Single Name
1. CANH 2 CANL
3 GND

VDX3-6755 User Manual
ICOP Technology Inc. 14
J24: PC/104 Connector – 64 pin
Pin#
Single Name
Pin #
Single Name
1. IOCHCHK* 2 GND
3 SD7 4 RESETDRV
5 SD6 6 VCC
7 SD5 8 IRQ9
9 SD4 10 -5V
11 SD3 12 RDQ2
13 SD2 14 -12V
15 SD1 16 OWS
17 SD0 18 +12V
19 IOCHRDY 20 GND
21 AEN 22 SMEMW*
23 SA19 24 SMEMR*
25 SA18 26 IOW*
27 SA17 28 IOR*
29 SA16 30 DACK3*
31 SA15 32 DRQ3
33 SA14 34 DACK1*
35 SA13 36 DRQ1*
37 SA12 38 REFRESH*
39 SA11 40 SYSCLK
41 SA10 42 IRQ7
43 SA9 44 IRQ6
45 SA8 46 IRQ5
47 SA7 48 IRQ4
49 SA6 50 IRQ3
51 SA5 52 DACK2*
53 SA4 54 TC
55 SA3 56 BALE
57 SA2 58 VCC
59 SA1 60 OSC
61 SA0 62 GND
63 GND 64 GND
J25: PC/104 Connector – 40 pin
Pin#
Single Name
Pin #
Single Name
1. GND 2 GND
3 MEMCS16* 4 SBHE*
5 IOCS16* 6 SA23
7 IRQ10 8 SA22
9 IRQ11 10 SA21
11 IRQ12 12 SA20
13 IRQ15 14 SA19
15 IRQ14 16 SA18
17 DACK0* 18 SA17
19 DRQ0 20 MEMR*
21 DACK5* 22 MEMW*
23 DRQ5 24 SD8
25 DACK6* 26 SD9
27 DRQ6 28 SD10
29 DACK7 30 SD11
31 DRQ7 32 SD12
33 VCC 34 SD13
35 MASTER* 36 SD14
37 GND 38 SD15
39 GND 40 NC

VDX3-6755 User Manual
ICOP Technology Inc. 15
J26: 4P Power Source (Interconnect to PC/104 J24)
Pin#
Single Name
1. -5V
2 -12V
3 +12V
4 GND
J27: LVDS
Pin#
Single Name Pin #
Single Name
1. VCC3 (+3.3V) 2 VCC3 (+3.3V)
3 GND 4 GND
5 Y0P 6 Y0M
7 Y1M 8 Y1P
9 Y2P 10 Y2M
11 GND 12 GND
13 CLKOUTM 14 CLKOUTP
15 Y3M 16 Y3P
3 Software Resources
3.1 ICOP Technical Resource Website
In the following website, you will find our latest user manuals, including OS
support resources systems such as evaluation images for Windows
Embedded Compact 7, Windows Embedded CE 6.0, Windows Embedded
CE 5.0, and Windows XP Embedded (Win XPe). For details, please kindly
visit the following link: http://tech.icop.com.tw/
