ICP Electronics ROCKY - 058HV User manual

ROCKY –058HV
Pentium® & VGA SBC
Ver 3.0
@Copyright 1999
All Rights Reserved.
Manual second edition April.1, 2000
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does not
represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability
to use the product or documentation, even if advised of the possibility
of such damages.
This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by
any mechanical, electronic, or other means in any form without prior
written permission of the manufacturer.
Trademarks
ROCKY-058HV is registered trademarks of ICP Electronics Inc., IBM
PC is a registered trademark of International Business Machines
Corporation. Intel is a registered trademark of Intel Corporation. Other
product names mentioned herein are used for identification purposes
only and may be trademarks and/or registered trademarks of their
respective companies.

1
Contents
1. Introduction...........................................................3
1.1 Specifications..............................................................................4
1.2 What You Have...........................................................................5
2. Installation.............................................................6
2.1 ROCKY-P058HV .........................................................................7
2.2 Setting the CPU of ROCKY-P058HV............................................8
2.3 System Memory DRAM..............................................................10
2.4 Watch-Dog Timer......................................................................10
2.5 DiskOnChip™ Flash Disk ..........................................................10
2.6 Clear CMOS Setup....................................................................11
2.7 System Memory Address Information ........................................11
3. Connection..........................................................12
3.1 Floppy Disk Drive Connector......................................................12
3.2 PCI E-IDE Disk Drive Connector................................................13
3.3 Parallel Port...............................................................................15
3.4 Serial Ports................................................................................15
3.5 Keyboard/Mouse Connector.......................................................16
3.6 External Switches and Indicators ...............................................16

2
3.7 USB Port Connector .................................................................17
3.8 IrDA Infrared Interface Port........................................................17
3.9 VGA Connector .........................................................................17
3.10 Fan Connector...........................................................................18
3.11 External Power Connector..........................................................18
4. AWARD BIOS Setup..........................................19
4.1 Getting Start..............................................................................19
4.2 Standard CMOS Setup ..............................................................20
4.3 BIOS Features Setup.................................................................22
4.4 Chipset Features Setup..............................................................23
4.5 Integrated Peripherals ...............................................................24
4.6 Power Management Setup.........................................................25
4.7 PNP/PCI Configuration..............................................................26
Appendix A. Watch-Dog Timer...............................27
Appendix B. I/O Address Map.................................29

3
1
Introduction
Welcome to the ROCKY-058HV Pentium® w/ VGA Single Board
Computer. The ROCKY-058HV board is an ISA bus form factor
board, which equipped with high performance Pentium® CPU and
advanced high performance multi-mode I/O, designed for the
system manufacturers, integrators, or VARs that want to provide
all the performance, reliability, and quality at a reasonable price.
This board built-in DiskOnChip™(DOC) Flash Disk Socket for
embedded application. The DOC Flash Disk is 100% software
compatible to hard disk. User can use any DOS command without
any extra software utility.
An advanced high performance super AT I/O chip –Winbond
W83877F is used in the ROCKY-058HV board. Both on-chip
UART are compatible with the NS16C550.
In addition, the ROCKY-058HV provides one 168-pin DIMM
socket for it’s on-board DRAM. DIMM module is 3.3V
SDRAM.and max. 128MB for one module.
ROCKY-058HV uses the advanced SIS Chipset,5598 which is
100% ISA compatible chipset.

4
1.1 Specifications :
The ROCKY-058HV Pentium w/ VGA Single Board Computer
provides the following specifications:
•CPU : Pentium® MMX up to 233Mhz, AMD K5/K6/K6-2/K6-3
processor up to 400Mhz, Cyrix 6x86MX processor
•Bus Interface : ISA bus
•Bus Speed : ISA 8MHz
•DMA Channels : 7
•Interrupt Levels : 15
•Chipset : SIS 5598
•VGA : Built-in the SIS 5598 Chipset
Resolution : 1280x1024,256 colors,75Hz
1024x768, 64K colors,75Hz
800x600,full colors,90Hz
More information : www.sis.com.tw
•Real-time clock / calendar : SGS M4T28 or equivalent device.
•RAM memory : up to 128MB SDRAM
•Second Cache memory : 512KB Pipelined Burst SRAM on board
•Ultra DMA/33 IDE Interface : up to two PCI Enhanced IDE hard
drives. The Ultra DMA/33 IDE can handle data transfer up to 33MB/s.
The compatibility with existing ATA-2 IDE specifications is its best
advantage, so there is no need to do any change to users current
accessories.
•Floppy disk drive interface : Support up to two floppy disk drives,
5.25”(360KB and 1.2MB) and/or 3.5” (720KB, 1.44MB, and 2.88MB) .
•Series ports : Two RS-232 ports with 16C550 UART ( or compatible)
with 16-byte FIFO buffer. Support up to 115.2Kbps. Ports can be
individually configured to COM1, COM2 or disabled.

5
•
Bi-directional Parallel Port : Configurable to LPT1, LPT2, LPT3 or
disabled. Supports EPP/ECP/SPP
•IrDA port : Supports Serial Infrared(SIR) and Amplitude Shift
Keyed IR(ASKIR) interface.
•USB port : Supports USB port for future expansion.
•Watch-dog timer : can be set by 1~255 seconds period. Reset or
NMI is generated when CPU does not periodically trigger the timer.
•Flash Disk Socket: the DiskOnChip™ compatible 32-pin dip socket
is provided for Flash Disk ( DiskOnChip™ ) application which will let
users to use the Flash Disk with DOS command. without any extra
software utility.
•Keyboard and PS/2 mouse connector : A 6-pin mini DIN connector
is located on the mounting bracket for easy connection to a keyboard
or PS/2 mouse. For alternative application, a keyboard pin header
connector is also available on board, located on CN13.
•Power Consumption : +5V @ 6A ,+12V @ 170mA , -12V@60mA
( Pentium® MMX-200,32MB SDRAM)
•Operating Temperature : 0°~ 55°C ( CPU needs Cooler)
1.2 What You Have
In addition to this User's Manual, the ROCKY-058HV package
includes the following items:
•ROCKY-058HV Pentium® w/ VGA SBC
•One RS-232 and Printer Cable with bracket
•One FDD Cable
•One HDD Cable
•One 6-pin Mini-Din converts to two 6-pin Din cables for
keyboard and mouse connection.
If any of these items are missing or damaged, contact the dealer
from whom you purchased the product. Save the shipping
materials and carton in case you want to ship or store the product
in the future.

6
2
Installation
This chapter describes how to install the ROCKY-058HV. At first,
the layout of ROCKY-058HV is shown, and the unpacking
information that you should be careful is described. The jumpers
and switches setting for the ROCKY-058HV's configuration, such
as CPU type selection, system clock setting, and watch dog timer
are also included.
2.1 ROCKY-058HV's Layout
< Please refer to the next page >

7
2.1 ROCKY-058HV's Layout
BZ1
1
ROCKY-058HV
JP5
JP4
JP7
JP8
COMA
Disk On Chip
USB CN8
VGA CN7
DIMM1 CN1 LPT
CN3 FDC
CN2 IDE
V3.0

8
2.2 Setting the CPU of ROCKY-058HV
Bold line is the factory setting jumper.
•CPU Clock Setting :
CPU Speed/Clock JP1
1-2JP1 3-4JP1 5-6
55MHz CLOSE
CLOSE
OPEN
60MHz CLOSE
OPEN OPEN
66MHz OPEN OPEN OPEN
75MHz OPEN CLOSE
CLOSE
•CPU frequency ratio :
Multiplier JP2
1-2JP2 3-4JP2 5-6
1.5 x OPEN OPEN OPEN
2x CLOSE OPEN OPEN
2.5x CLOSE CLOSE OPEN
3 x OPEN CLOSE
OPEN
3.5 x OPEN OPEN OPEN
4 x CLOSE OPEN CLOSE
4.5 x CLOSE CLOSE CLOSE
5 x OPEN CLOSE CLOSE
5.5 x OPEN OPEN CLOSE
6 x CLOSE OPEN OPEN
CPU Frequency = CPU Clock x Multiplier for example
Pentium® 200MHz = 66MHz CPU Clock x 3
•CPU Core Voltage Selection :
Please check the CPU Core Voltage before you install the CPU.
Right now new Intel MMX CPU is dual voltage for core and I/O,
the I/O is 3.3V but the core is 2.8V. This kind of CPU design
will enhance the low power consumption capability. As for the
general Pentium® CPU is one voltage for I/O and Core –3.3V,
3.4V,or 3.5V.

9
•JP8 CPU Core Voltage Setting :
CPU Core
Voltage JP8 1-2JP8 3-4JP8 5-6JP8 7-8
3.5V(P54C/CS)
VRE CLOSE CLOSE CLOSE CLOSE
3.4V(P54C/CS)
STD OPEN
CLOSE CLOSE CLOSE
3.3V CLOSE OPEN CLOSE CLOSE
3.2V OPEN OPEN CLOSE CLOSE
3.1V CLOSE CLOSE OPEN CLOSE
3.0V OPEN CLOSE OPEN CLOSE
2.9V CLOSE OPEN OPEN CLOSE
2.8V (P55C)
OPEN OPEN OPEN CLOSE
2.7V CLOSE CLOSE CLOSE OPEN
2.6V OPEN CLOSE CLOSE
OPEN
2.5V CLOSE OPEN CLOSE OPEN
2.4V OPEN OPEN CLOSE OPEN
2.3V CLOSE CLOSE OPEN OPEN
2.2V OPEN CLOSE OPEN OPEN
2.1V CLOSE OPEN OPEN OPEN
2.0V OPEN OPEN OPEN OPEN
•
JP7 Dual / Single CPU Voltage setting :
Vcore & VIO
1-32-43-54-6
Pentium
(P54C) OPEN OPEN CLOSE CLOSE
Pentium MMX
AMD K6
Cyrix 6x86MX
Dual Voltage
CLOSE
CLOSE
OPEN OPEN

10
2.3 System Memory DRAM (DIMM1)
There is one 168-pin DIMM socket to accept 3.3V non-buffered
SDRAM. The max. Memory size is 128MB.
2.4 Watch-Dog Timer (JP3)
The Watch-Dog Timer is enabled by reading port 443H. It should
be triggered before the time-out period ends, otherwise it will
assume the program operation is abnormal and will issue a reset
signal to start again, or activate NMI to CPU. The Watch-Dog
Timer is disable by reading port 843H.
•JP3 : Watch-Dog Active Type Setting
JP3 DESCRIPTION
2-3RESET WHEN WDT TIME-OUT
1-2ACTIVATE NMI TO CPU WHEN WDT TIME-
OUT
OPEN
DISABLE WDT
2.5 DiskOnChip™ Flash Disk
The DiskOnChip™ Flash Disk Chip(DOC) is produced by M-
Systems. Because the DOC is 100% compatible to hard disk and
DOS. Customer don‘t need any extra software utility. It is just
“plug and play”, easy and reliable. Right now the DOC is available
from 2MB to 144MB. The MD-2200-Xmb series DOC will share
only 8KB memory address.

11
•JP4 & JP14 : DiskOnChip Memory Address Setting
ADDRESS JP14
JP4
1-2
3-4
5-6
7-8
1-2
3-45-6
CC000 OPEN
OPEN
CLOSE
OPEN
OPEN
CLOSE
CLOSE
CE000 OPEN
OPEN
OPEN
CLOSE
OPEN
CLOSE
CLOSE
D0000 CLOSE
OPEN
OPEN
OPEN
CLOSE
OPEN
CLOSE
D2000 OPEN
CLOSE
OPEN
OPEN
CLOSE
OPEN
CLOSE
D4000 OPEN
OPEN
CLOSE
OPEN
CLOSE
OPEN
CLOSE
D6000 OPEN
OPEN
OPEN
CLOSE
CLOSE
OPEN
CLOSE
D8000 CLOSE
OPEN
OPEN
OPEN
OPEN
OPEN
CLOSE
DA000 OPEN
CLOSE
OPEN
OPEN
OPEN
OPEN
CLOSE
DC000 OPEN
OPEN
CLOSE
OPEN
OPEN
OPEN
CLOSE
DE000 OPEN
OPEN
OPEN
CLOSE
OPEN
OPEN
CLOSE
2.6 Clear CMOS Setup (JP5)
If want to clear the CMOS Setup ( for example forgot the
password you should clear the setup and then set the password
again.), you should close the JP5 about 3 seconds, then open
again. Set back to normal operation mode, open JP5.
•JP5: Clear CMOS Setup (Reserve Function)
JP5DESCRIPTION
OPEN Normal Operation
CLOSE
Clear CMOS Setup
2.7 System Memory Address Information
This board’s chipset SIS 5598 provides share memory VGA
function to lower system cost, which will use the system memory
address from C0000 to CBFFF(total 48KB memory address) for
VGA BIOS. If customers use external VGA or LCD drive card in
the system, the ROCKY-058HV will automatic disable the on
board VGA function and free the C0000 to CBFFF memory
address.

12
3
Connection
This chapter describes how to connect peripherals, switches and
indicators to the ROCKY-058HV board.
3.1 Floppy Disk Drive Connector (CN3)
ROCKY-058HV board is equipped with a 34-pin daisy-chain driver
connector cable.
•CN3 : FDC CONNECTOR
PIN NO. DESCRIPTION
PIN NO. DESCRIPTION
1GROUND 2REDUCE WRITE
3GROUND 4N/C
5GROUND 6N/C
7GROUND 8INDEX#
9GROUND 10 MOTOR ENABLE A#
11 GROUND 12 DRIVE SELECT B#
13 GROUND 14 DRIVE SELECT A#
15 GROUND 16 MOTOR ENABLE B#
17 GROUND 18 DIRECTION#
19 GROUND 20 STEP#
21 GROUND 22 WRITE DATA#
23 GROUND 24 WRITE GATE#
25 GROUND 26 TRACK 0#
27 GROUND 28 WRITE PROTECT#
29 GROUND 30 READ DATA#
31 GROUND 32 SIDE 1 SELECT#
33 GROUND 34 DISK CHANGE#

13
3.2 PCI E-IDE Disk Drive Connector (CN2, CN6)
You can attach four IDE (Integrated Device Electronics) hard disk
drives to the ROCKY-058HV IDE controller.
CN2 (IDE 1) :40-pin Primary IDE Connector (3.5”HDD)
CN6 (IDE 2) :44-pin Secondary Mini-pitched IDE Connector
(2.5”HDD)
•CN2 : Primary IDE Interface Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1RESET# 2GROUND
3DATA 7 4DATA 8
5DATA 6 6DATA 9
7DATA 5 8DATA 10
9DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 N/C
21 IDE DRQ 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 IDE CHRDY 28 GROUND
29 IDE DACK 30 GROUND –DEFAULT
31 INTERRUPT 32 NC
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GROUND

14
•CN6 : Secondary IDE Interface Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1RESET# 2GROUND
3DATA 7 4DATA 8
5DATA 6 6DATA 9
7DATA 5 8DATA 10
9DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 N/C
21 IDE DRQ 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 IDE CHRDY 28 GROUND
29 IDE DACK 30 GROUND –DEFAULT
31 INTERRUPT 32 N/C
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GROUND
41 VCC 42 GROUND
43 GROUND 44 GROUND

15
3.3 Parallel Port (CN1)
This port is usually connected to a printer. The ROCKY-058HV
includes an on-board parallel port, accessed through a 26-pin flat-
cable connector CN1.
•CN1 : Parallel Port Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1STROBE# 2DATA 0
3DATA 1 4DATA 2
5DATA 3 6DATA 4
7DATA 5 8DATA 6
9DATA 7 10 ACKNOWLEDGE
11 BUSY 12 PAPER EMPTY
13 PRINTER SELECT 14 AUTO FORM FEED #
15 ERROR# 16 INITIALIZE
17 PRINTER SELECT LN#
18 GROUND
19 GROUND 20 GROUND
21 GROUND 22 GROUND
23 GROUND 24 GROUND
25 GROUND 26 N/C
3.4 Series Ports (CN12, CN11)
The ROCKY-058HV offers two high speeds NS16C550
compatible UARTs with 16 byte FIFO serial ports.
•CN12 : Serial Port DB-9 Connector( COMB )
PIN NO.
DESCRIPTION
1DATA CARRIER DETECT (DCD)
2RECEIVE DATA (RXD)
3TRANSMIT DATA (TXD)
4DATA TERMINAL READY (DTR)
5GROUND (GND)
6DATA SET READY (DSR)
7REQUEST TO SEND (RTS)
8CLEAR TO SEND (CTS)
9RING INDICATOR (RI)
•CN11 : Serial Port 10-pin Header( COMA)
Pin No.
Description Pin No.
Description
1 DCD 2. DSR
3 RXD 4 RTS
5 TXD 6 CTS
7 DTR 8 RI
9 GND 10 NC

16
3.5 Keyboard & PS/2 Mouse Connector (CN14,CN13)
A 6-pin mini DIN connector (CN14) is located on the mounting
bracket for easy connection to a keyboard or PS/2 mouse. The
card comes with a cable to convert from the 6-pin mini-DIN
connector to two 6-pin mini-DIN connector for keyboard and
mouse connection
•CN14 : 6-pin Mini-DIN Keyboard & Mouse Connector
PIN NO. DESCRIPTION
1KEYBOARD DATA
2MOUSE DATA
3GROUND
4+5V
5KEYBOARD CLOCK
6MOUSE CLOCK
For alternative application , a keyboard pin header connector are
also available on board , located on CN13.
•CN13 : 5-pin Header Keyboard Connector
PIN NO. DESCRIPTION
1KEYBOARD CLOCK
2KEYBOARD DATA
3N/C
4GROUND
5+5V
3.6 External Switches and Indicators (CN5)
There are several external switches and indicators for monitoring
and controlling your CPU board. All the functions are in the CN5
connector.
•
CN5 : General Connectors
1
5V 2.
Speaker Signal
3.
NC 4.
NC
Power
LED
5
GND 6
5V
7.
KEYLOCK 8.
GND
Speaker
Key
Lock
9.
GND 10.
GND
11.
GND 12.
RESET Reset
Button
13.
NC 14.
HDD LED
15.
PSON 16.
5V IDE LED
17.
AUX5V 18.
To JP9 Pin 2
ATX
Control
19.
AUX5V 20.
GND ATX Power
Button

17
3.7 USB Port Connector (CN8,CN9)
The ROCKY-058HV provides two USB interfaces, which gives the
completed plug and play, for up to 127 external devices. One
standard USB connector located on the central of metal bracket,
while the other was via pin head connector located on the board
at CN9, next to the CN8.
•
CN8 : External USB Connector
15V
2. -DATA1
3. +DATA1
4. GND
•
CN9 : Internal USB pin head Connector
15V
2. -DATA0
3. +DATA0
4. GND
3.8 IrDA Infrared Interface Port (CN4)
The ROCKY-058HV built-in and IrDA port which support Serial
Infrared (SIR) or Amplitude Shift Keyed IR (ASKIR) interface.
When use the IrDA port has to set SIR or ASKIR model in the
BIOS’s Peripheral Setup’s COM2. Then the normal RS-232
COM2 will be disabled.
•CN4 : IrDA connector
PIN NO. DESCRIPTION
1VCC
2NC
3IR-RX
4Ground
5IR-TX
3.9 VGA Connector (CN7)
The ROCKY-058HV built-in 15-pin VGA connector directly to your
CRT monitor.

18
•CN7 : 15-pin Female Connector
1RED 2GREEN
3BLUE 4NC
5GROUND 6GROUND
7GROUND 8GROUND
9NC 10 GROUND
11
NC 12 DDC DAT
13
HSYNC 14 VSYNC
15
DDCCLK
3.10 Fan Connector (FAN1)
The ROCKY-058HV provides CPU cooling fan connector FAN1
which can supply 12V/500Ma max. to the cooling fan. It is limited
in fan using, thus, don’t use it for other purpose.
•FAN1 : Fan Connector
PIN NO.
DESCRIPTION
1NC
2. 12V
3. Ground
3.11 External Power Connector (CN10)
The ROCKY-058HV has an on board external power connector
CN10. You can connect power directly to the CPU board without
passive backplane application.
•CN10 : External Power Connector
PIN NO.
DESCRIPTION
1VCC
2VCC
3GROUND
4GROUND
5+12V
6-12V
