ICP Electronics ROCKY-3732EVS User manual

1
ROCKY-3732EVS
Dual Pentium® III with
Dual 10/100Mb Ethernet , VGA, Audio,
Dual Ultra-160 SCSI Port
Ver 2.x
@Copyright 2001
All Rights Reserved.
Manual first edition Jan 14, 2001
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of the
possibility of such damages.
This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be
reproduced by any mechanical, electronic, or other means in any
form without prior written permission of the manufacturer.
Trademarks
ROCKY-3732EVS is registered trademarks of ICP Electronics Inc.,
IBM PC is a registered trademark of International Business Machines
Corporation. Intel is a registered trademark of Intel Corporation.
AWARD is registered trademarks of AWARD SOFTWARE
INTERNATIONAL, Inc. Other product names mentioned herein are
used for identification purposes only and may be trademarks and/or
registered trademarks of their respective companies.

2
Contents
1. Introduction........................................................ 5
1.1 Specifications.................................................................................. 6
1.2 What You Have............................................................................... 7
2. Installation ......................................................... 8
2.1 ROCKY-3732EVS's Layout............................................................. 9
2.2 Clear CMOS Setup....................................................................... 10
2.3 CompactFlash Card Master/Slave Mode Setting........................ 10
2.4 CPU Type Selection Setting ......................................................... 10
2.5 SCSI A/B Terminator Selection Setting ........................................ 11
3. Connection....................................................... 12
3.1 Floppy Disk Drive Connector........................................................ 12
3.2 PCI E-IDE Disk Drive Connector .................................................. 13
3.3 Parallel Port.................................................................................. 14
3.4 USB Port Connector ..................................................................... 15
3.5 Power Button Switch..................................................................... 15
3.6 Serial Ports................................................................................... 16
3.7 Keyboard/Mouse Connector......................................................... 16
3.8 IrDA Infrared Interface Port .......................................................... 17
3.9 Fan Connector ............................................................................. 18

3
3.10 VGA Connector............................................................................. 18
3.11 Audio Connectors ........................................................................ 19
3.12 CompactFlash Storage Card Socket ........................................... 20
3.13 ATX Connector ............................................................................ 21
3.14 External Switches and Indicators ................................................. 22
3.15 PS-ON Connector ........................................................................ 22
3.16 LAN RJ45 Connectors ................................................................. 23
3.17 External LED Connector .............................................................. 23
3.18 Ultra-2/3 68pin SCSI Connectors ................................................. 24
4. BIOS Setup...................................................... 25
4.1 Introduction................................................................................... 25
4.2 Starting Setup............................................................................... 25
4.3 Using Setup.................................................................................. 26
4.4 Main Menu.................................................................................... 27
4.5 Standard CMOS Setup ................................................................ 30
4.6 Advanced BIOS Setup.................................................................. 34
4.7 Advanced Chipset Setup .............................................................. 38
4.8 Integrated Peripherals .................................................................. 41
4.9 Power Management Setup ........................................................... 45
4.10 PnP/PCI Configuration Setup ....................................................... 49
4.11 PC Health Status .......................................................................... 51
4.12 Frequency/Voltage Control........................................................... 52
4.13 Defaults Menu............................................................................... 53
4.14 Supervisor/User Password Setting.............................................. 54

4
4.15 Exit Selecting................................................................................ 55
Appendix A. WatchDog Timer.............................. 56
Appendix B. E2Key™Function........................... 57
Appendix C. Address Mapping............................. 59
Appendix D. ATX Power Supply .......................... 61
Appendix E. How to used Wake Up Function ...... 63
Appendix F. Dimensions...................................... 64

5
1
Introduction
The ROCKY-3732EVS ATX/AT mainboard is a high-
performance computer mainboard based on VIA ®
VT82C694X/T chipset. The ROCKY-3732EVS is designed for
Intel ® Pentium ® III (FC-PGA) processor for cost-effective
server markets.
The Apollo Pro133A (VT82C694X/T) is a Socket-370 system
logic north bridge with the addition of 133 MHz capability for
both the CPU and SDRAM interfaces. Apollo Pro133A may be
used to implement both desktop and notebook personal
computer systems from 66MHz to 133MHz based on Socket-
370 (Pentium® III processor). The primary features of the
Apollo Pro133A-North Bridge are: Slot-1 or Socket-370 CPU
(Front Side Bus) Interface (66 / 100 / 133MHz), DRAM
Memory Interface (66 / 100 / 133MHz), AGP Bus Interface
(66MHz), PCI Bus Interface (33MHz), Mobile Power
Management.
The VT82C686B PSIPC (PCI Super-I/O Integrated
Peripheral Controller) is a high integration, high performance,
power-efficient, and high compatibility device that supports
Intel and non-Intel based processor to PCI bus bridge
functionality to make a complete Microsoft PC99-compliant
PCI/ISA system.

6
1.1 Specifications :
•CPU : Dual Pentium® III (FC-PGA / FC-PGA2 (694T only)) &,
Celeron™(PPGA )
•FBS : Support 66/100/133 MHz(Auto Detect)
•Bus : PICMG Bus(Support PCI Master x 4)
•DMA channels : 7
•Interrupt levels : 15
•Chipset : VIA VT82C694X/T / VT82C686B
•RAM memory : Four 168-pin DIMM sockets support DRAM/VCM
module. Support 8 banks up to 2GB at 100MHz (PC133
specifications, however, recommend a limit of 3 DIMMs or 6 banks
at 133MHz for 1.5GB max memory). Support ECC(1-bit Error Code
Correct) function
•Ultra ATA/33/66/100 IDE Interface : Two PCI Enhance IDE hard
drives. The south bridge VT82c686B supports Ultra
ATA/33/66/100 IDE interface.
•Floppy disk drive interface : Single 2.88 MB, 1.44MB, 1.2MB,
720KB, or 360KB floppy disk drive.
•Two high speed Series ports : NS16C550 compatible UARTs
•Bi-directional Parallel Port
• Built-in VT82C686B to monitor power supply voltage and fan
speed status.
•IrDA port : Support Serial Infrared(SIR) and Amplitude Shift
Keyed IR(ASKIR) interface.
•USB port : Support two USB ports for future expansion.
•AC’97 Codec : Support two channel Left/Right Line IN/OUT, MIC
IN, CD IN, and PC beep sound for buzzer.
•VGA Controller : SIS 6326 VGA controller, 4MB main memory .
Screen Resolution : up to 1600x1200 in 8-bit Color at 85Hz
Refresh.

7
•Dual Intel 82559 Fast Ethernet Multifunction PCI
Controller : IEEE 802.3u Auto-Negotiation support for 10BASE-
T/100BASE-TX standard. Fast back-to-back transmission support
with minimum interframe spacing. Connected to your LAN through
RJ45 connector.
•SYM53C1010R PCI-Dual Channel Ultra-160 SCSI
Controller(ROCKY-3732EVS Only)
•Keyboard connector
•Mouse : PS/2 Mouse Port on-board.
•Operating Temperature : 0°~ 55°C ( CPU needs Cooler)
1.2 What You Have
In addition to this User's Manual, the ROCKY-3732EVS
package includes the following items:
•ROCKY-3732EVS Celeron®, Pentium® III Single Board
Computer
•RS-232/LPT Cable x 1
•FDD Cable x 1
•Audio(MIC,LINE IN)/RS-232 x 1
•IDE HDD DMA66 Cable x 1
•Ultra160 SCSI Cable x 1(ROCKY-3732EVS Only)
•CD-ROM Driver x 1
•6-pin Mini-Din to 5-pin Din Keyboard & PS2 Mouse Adapter
Cable x 1
If any of these items is missing or damaged, contact the dealer
from whom you purchased the product. Save the shipping
materials and carton in case you want to ship or store the
product in the future.

8
2
Installation
This chapter describes how to install the ROCKY-3732EVS. At
first, the layout of ROCKY-3732EVS is shown, and the
unpacking information that you should be careful is described.
The jumpers and switches setting for the ROCKY-3732EVS's
configuration, such as CPU type selection, system clock
setting, and watch dog timer, are also included.

9
2.1 ROCKY-3732EVS's Layout
CN5
CN6
CN2
CN15
CN11
CN23
CN9
CN10
U1 U2
U3
VT82C694X
JP1
JP2
CN7 CN8
DIMM1
DIMM2
DIMM3
DIMM4
CN1
U4
VT82C686B
JP4
U7
CN12
BZ1
CN13
CN14
CN16 CN18
CN17
CN22
CN26
CN27
JP5
JP6
CN24
CN25
U35
U27
U30
CN3
CN21
CN19
CN20
JP3

10
2.2 Clear CMOS Setup
If want to clear the CMOS Setup(for example forgot the
password you should clear the setup and then set the
password again.),you should close the JP3(2-3) about 3
seconds, then open again. Set back to normal operation mode.
•JP3 : Clear CMOS Setup
¦
¦
¨
3
2
1
JP3 DESCRIPTION
1-2 Keep CMOS Setup
(Normal Operation)
2-3 Clear CMOS Setup
2.3 CompactFlash Card Master/Slave Mode Setting
The CompactFlash socket is type II, and used IDE 2.
•JP4 : Master/Slave Mode Setting
¨
¦
1
2
JP4 DESCRIPTION
SHORT MASTER
OPEN SLAVE
2.4 CPU Type Selection Setting
•JP1, JP2 : CPU Type Selection
¨
¦
¦
1 2 3
JP1, JP2 DESCRIPTION
2-3 FC-PGA(Celeron/P III)
1-2 PPGA(Celeron)

11
2.5 SCSI Port A/B Terminator Selection Setting
Two SCSI terminators Port A and Port B are supported, JP5 is
for Terminator Port A and JP6 is for Terminator Port B
•JP5, JP6 : Terminator Enable/Disable Setting
¦
¦
¨
3
2
1
JP5, JP6 DESCRIPTION
2-3 Enable
1-2 Disable

12
3
Connection
This chapter describes how to connect peripherals, switches
and indicators to the ROCKY-3732EVS board.
3.1 Floppy Disk Drive Connector
ROCKY-3732EVS board is equipped with a 34-pin daisy-chain
driver connector cable.
•CN2 : FDC CONNECTOR
2 4 6 …30 32 34
¡ ¡ ¡ … ¡ ¡ ¡
¨ ¡ ¡ … ¡ ¡ ¡
1 3 5 …29 31 33
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1GROUND 2REDUCE WRITE
3GROUND 4N/C
5GROUND 6N/C
7GROUND 8INDEX#
9GROUND 10 MOTOR ENABLE A#
11 GROUND 12 DRIVE SELECT B#
13 GROUND 14 DRIVE SELECT A#
15 GROUND 16 MOTOR ENABLE B#
17 GROUND 18 DIRECTION#
19 GROUND 20 STEP#
21 GROUND 22 WRITE DATA#
23 GROUND 24 WRITE GATE#
25 GROUND 26 TRACK 0#
27 GROUND 28 WRITE PROTECT#
29 N/C 30 READ DATA#
31 GROUND 32 SIDE 1 SELECT#
33 N/C 34 DISK CHANGE#

13
3.2 PCI E-IDE Disk Drive Connector
You can attach four IDE( Integrated Device Electronics) device
to the VT82C686B IDE controller.
IDE2 shares the same IDE channel with CompactFlash, so
you must refer JP4 before setting the IDE2’s device.
CN5 (IDE1) : Primary IDE Connector
CN6 (IDE2) : Secondary IDE Connector
•CN5/CN6 : IDE Interface Connector
2 4 6 …36 38 40
¡ ¡ ¡ … ¡ ¡ ¡
¨ ¡ ¡ … ¡ ¡ ¡
1 3 5 …35 37 39
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1RESET# 2GROUND
3DATA 7 4DATA 8
5DATA 6 6DATA 9
7DATA 5 8DATA 10
9DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 N/C
21 N/C 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 N/C 28 BALE - DEFAULT
29 N/C 30 GROUND - DEFAULT
31 INTERRUPT 32 IOCS16#-DEFAULT
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GROUND

14
3.3 Parallel Port
This port is usually connected to a printer, The ROCKY-3732EVS
includes an on-board parallel port, accessed through a 26-pin flat-
cable connector CN11.
•CN11 : Parallel Port Connector
2 4 6 …22 24 26
¡ ¡ ¡ … ¡ ¡ ¡
¨ ¡ ¡ … ¡ ¡ ¡
1 3 5 …21 23 25
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1STROBE# 2DATA 0
3DATA 1 4DATA 2
5DATA 3 6DATA 4
7DATA 5 8DATA 6
9DATA 7 10 ACKNOWLEDGE
11 BUSY 12 PAPER EMPTY
13 PRINTER SELECT 14 AUTO FORM FEED #
15 ERROR# 16 INITIALIZE
17 PRINTER SELECT
LN# 18 GROUND
19 GROUND 20 GROUND
21 GROUND 22 GROUND
23 GROUND 24 GROUND
25 GROUND 26 NC

15
3.4 USB Port Connector
The ROCKY-3732EVS built in two USB(Spec. 1.1) ports for
the future new I/O bus expansion.
CN3 : 2 ports USB Connector
Pin 1-4 for USB 1
Pin 5-8 for USB 0
5 6 7 8
¡
¡
¡
¡
¨
¡
¡
¡
1 2 3 4
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1. GROUND 5. VCC
2. DATA1+ 6. DATA0-
3. DATA1- 7. DATA0+
4. VCC 8. GROUND
3.5 Power Button Switch
CN26 : 2 Pin Power Button Switch
1
¨
¦
2
PIN NO. DESCRIPTION
1Power Button
2Ground

16
3.6 Serial Ports
The ROCKY-3732EVS offers two high speed NS16C550 compatible
UARTs with 16 byte Read/Receive FIFO serial ports.
CN9 : COM1
CN10 : COM2
•CN9/CN10 : Serial Port 10-pin Connector
6 7 8 9 10
¡
¡
¡
¡
¡
¨
¡
¡
¡
¡
1 2 3 4 5
PIN NO. DESCRIPTION
1DATA CARRIER DETECT (DCD)
2RECEIVE DATA (RXD)
3TRANSMIT DATA (TXD)
4DATA TERMINAL READY (DTR)
5GROUND (GND)
6DATA SET READY (DSR)
7REQUEST TO SEND (RTS)
8CLEAR TO SEND (CTS)
9RING INDICATOR (RI)
10 N/C
3.7 Keyboard/Mouse Connector
The ROCKY-3732EVS provide 6-pin DIN keyboard/mouse
connector and 5-pin keyboard connector..
•CN14 : 6-pin DIN Keyboard/Mouse Connector
PIN NO. DESCRIPTION
1KEYBOARD DATA
2MOUSE DATA
3GROUND
4+5V
5KEYBOARD CLOCK
6MOUSE CLOCK

17
•CN13 : 5-pin External Keyboard Connector
¨
¦
¦
¦
¦
5
4
3
2
1
PIN NO. DESCRIPTION
1KEYBOARD CLOCK
2KEYBOARD DATA
3NC
4GROUND
5+5V
3.8 IrDA Infrared Interface Port
The ROCKY-3732EVS built in a IrDA port which supports
Serial Infrared(SIR) or Amplitude Shift Keyed IR(ASKIR)
interface. When you use the IrDA port, you have to set COM2
as SIR or ASKIR mode in the BIOS’s Peripheral Setup. Then
the RS-232 mode of COM2 will be disabled.
•CN1 : IrDA connector
¦
¦
¦
¦
¨
5 4 3 2 1
PIN NO. DESCRIPTION
1VCC
2N/C
3IR-RX
4Ground
5IR-TX

18
3.9 Fan Connector
The ROCKY-3732EVS provides CPU with cooling fan
connector and chassis fan connector. These connectors can
supply 12V/500mA to the cooling fan. There is a “rotation”pin
in fan connector. This rotation pin is to get the fan’s rotation
signal to system. So the system BIOS could recognize the fan
speed. Please be noted that only specific fan offers the
rotation signal.
•CN7/CN8 : CPU Fan Connector
¨
¦
¦
1 2 3
PIN NO. CPU FAN
1Ground
212V
3Rotation Signal
3.10 VGA Connector
•CN15 : 15-pin Female Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1RED 2GREEN
3BLUE 4NC
5GROUND 6GROUND
7GROUND 8GROUND
9NC 10 GROUND
11 NC 12 DDC DAT
13 HSYNC 14 VSYNC
15 DDCCLK

19
3.11 Audio Connectors
The onboard AC’97 Codec supports several audio functions.
The audio connectors are described as below.
CN19/CN20/CN21/CN22 Connector
¦
¦
¦
¨
4
3
2
1
CN19 : LINE IN
PIN NO. DESCRIPTION
1. LEFT SIGNAL
2. GROUND
3. GROUND
4. RIGHT SIGNAL
CN21 : CD IN
PIN NO. DESCRIPTION
1. CD LEFT SIGNAL
2. GROUND
3. GROUND
4. CD RIGHT SIGNAL
CN20 : MIC IN
PIN NO. DESCRIPTION
1. SIGNAL
2. GROUND
3. GROUND
4. Vref
CN22 : LINE OUT
PIN NO. DESCRIPTION
1. GROUND
2. LEFT SIGNAL
3. NC
4. RIGHT SIGNAL
5. NC

20
3.12 CompactFlash Storage Card Socket
The ROCKY-3732EVS configures CompactFlash Storage
Card in IDE Mode(Used IDE 2).
•CN4 : CompactFlash Storage Card Socket pin
assignment
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1GROUND 26 CARD DETECT1
2D3 27 D11
3D4 28 D12
4D5 29 D13
5D6 30 D14
6D7 31 D15
7CS1# 32 CS3#
8N/C 33 N/C
9GROUND 34 IOR#
10 N/C 35 IOW#
11 N/C 36 OBLIGATORY
TO PULL HIGH
12 N/C 37 IRQ15
13 VCC 38 VCC
14 N/C 39 MASTER/SLAVE
15 N/C 40 N/C
16 N/C 41 RESET#
17 N/C 42 IORDY
18 A2 43 N/C
19 A1 44 OBLIGATORY
TO PULL HIGH
20 A0 45 ACTIVE#
21 D0 46 PDIAG#
22 D1 47 D8
23 D2 48 D9
24 N/C 49 D10
25 CARD
DETECT2 50 GROUND
