id-Technik VR Series User manual

General information
ASSEMBLY INSTRUCTIONS
Dear User,
in the following instructions, step by step descriptions are provided for the installation of the îd-Technik
Cable Clamps and accessories. It is important that the sequence of the assembly steps is adhered to,
without any deviations or changes. Only employ trained staff.
Important: For an appropriate use and to guarantee an optimized installation all components, such as
Cable Clamps, Elastic Inlays, cables, trailing cables etc. need to be clean and dust free!
Liability and warranty
The information shown in these assembly instructions describes approved methods for safe and proper
handling of îd-Technik products. They incorporate the requirements of applicable industry standards
and regulations, as well as state-of-the-art cable support and restraint developments and the experien-
ce gained by îd-Technik through many years of assisting in a wide range of cable system applications.
It should be noted that the illustrations are not drawn to scale. These assembly instructions must be read
in their entirety and fully understood before starting any work! The manufacturer assumes no liability for
damage and malfunctions resulting from the use of non-approved installation methods.
Intended use
The operational safety of the îd-Technik products is guaranteed provided the products are used as
intended. In order to ensure optimum performance and avoid hazards, these products must not be
modied, extended or changed in any manner without the express approval of the manufacturer. Any
use of these products other than in the manner described in these instructions is prohibited and is con-
sidered to be improper use.
îd-Technik GmbH and/or its authorised representatives are not liable for any claims resulting from impro-
per use of the products. The operator alone is liable for any damage or injury caused by improper use
of, or changes to, the products.
The manufacturer reserves the right to make technical changes to the instructions.
The special Elastic Inlays must ONLY be inserted into îd-Technik Clamps, not xed, with the ribs facing the
cable and running parallel to the cable.
Changes to the products
In order to avoid hazards and to ensure optimum performance, the products may not be modied,
extended or changed if not expressly approved by the manufacturer.
In order not to jeopardise the retention, the Elastic Inlays should not be xed. On-site xing with any form
of adhesive (e.g. glue, silicone or paste) and / or use with third-party products will void the warranty
immediately.
For further details contact îd-Technik, please. Technical changes and errors reserved. The information
presented in these manuals is intended for the guidance of authorized users of the îd-Technik products.
Copyright law and intellectual property rights protect all of the content of the îd-Technik manuals and
catalogues, including all text, drawings, pictures and other product representations. Reproduction,
communication, or other use of this proprietary information is not permitted without prior written consent
from îd-Technik GmbH.
îd-Technik GmbH, Hohe Strasse 34-36, 68526 Ladenburg, Germany,
Tel.: [phone], Fax: [phone], www.id-technik.com, [email protected]
Technical changes and errors reserved. Page 1 of 2 Date 10/2020

Assembly instructions for VR Series
ASSEMBLY INSTRUCTIONS
Selection of fastening material:
Material and corrosion resistance:
the choice of material for the fasteners is
dependent on the installation environment
and operating conditions (e.g. galvanised,
stainless steel, etc.), strength grade 4.8 - 8.8
Type of screw:
depends on the substructure (e.g. hexagon
screws, T-head screws, rod threaded, etc.);
not included in delivery
Fastener diameter:
depends on the Cable Clamp
(dimension: metric screw thread [M])
Fastener Length:
depends on the number of stacked
VR-Series. Cable Clamp dimension and
type of substructure
Application with Elastic Inlays:
on-site xing with any form of adhesive (e.g.
glue, silicone or paste) will void the warranty
immediately
Alternating, tighten nuts with an appropriate torque wrench. Do not
use self-securing/self-locking nuts, this prohibits a dened tightening
torque. Tightening Torque for more rows of VR-Series: 8 Nm
Only at washers may be used.
No spring or snap rings!
Tightening Torque: 20 Nm
2x 2x
Tightening Torque: 8 Nm
2x 2x
List of individual components:
Clamps for parallel
fastening type
Outer diameter
of cable Metric screw thread (M) Recommended length of thread*
VR2 12-45 21-45 mm** M12 125 mm + x
VR3 12-45 21-45 mm** M12 125 mm + x
* For maximum permited outer cable diameter (can be reduced accordingly for smaller diameters)
** Contact îd-Technik for diameter 12-21 mm, please.
xcorresponds to the height of the substructur.
It is essential to respect the specied tightening torques, especially for the top part, to guarantee
perfect and reliable functioning of the cable installation for the long-term.***
îd-Technik GmbH, Hohe Strasse 34-36, 68526 Ladenburg, Germany,
Tel.: [phone], Fax: [phone], www.id-technik.com, [email protected]
Technical changes and errors reserved. Page 2 of 2 Date 10/2020
*** Contact îd-Technik for trailing cables (EPDM, rubber, etc.), please.
