Performance Tool M564DB User manual

3/8 in. Dr. Air Ratchet
Stock Number M564DB
LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These
warranties give specific legal rights. Except where prohibited by local law, the law of the State of Washington
governs all warranties and all exclusions and limitations of warranties and remedies. There may be other rights
which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal
use and service. A defective product may be returned for a free replacement within 90 days from the date of
purchase, provided that product is returned to place of purchase immediately after discovery of defect. After 90
days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which
our examination shall disclose to be defective and under warranty. These warranties shall be valid only when a
sales receipt showing the date of purchase accompanies the defective product or defective part (s) being returned.
For part (s) after 90 days, please remit your request, postage prepaid to:
PERFORMANCE TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be
replaced under normal use and service. These warranties shall not apply to any product or part which is used for a
purpose for which it is not designed, or which has been repaired or altered in any way so as to affect adversely its
performance or reliability, nor shall these warranties apply to any product or part which has been subject to
misuse, neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in
connection with its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no
express or implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL® makes
no implied warranty of merchantability and no implied warranty of fitness for any particular purpose, except that for
goods purchased primarily for personal, family or household use and not for commercial or business use,
PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied
warranty of fitness for a particular purpose), but only for the particular qualities or characteristics, and for the
duration, expressly warranted above.
The laws on limitation of implied warranties may differ from state to state, so the above limitations may not apply in
all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in any
manner related to any product, or to the design, use, or any inability to use the product. The sole and exclusive
remedy for a defective product or part shall be the repair, or replacement thereof as provided above. The laws on
limitation of remedies or on consequential, incidental or special damages may vary from state to state, so the above
limitations may not apply in all cases.
© Copyright 2016 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138
SPECIFICATIONS:
Square Drive (IN.) ........................................3/8
Working torque (FT./LBS) ...............................10-50
Air pressure (P.S.I.) ........................................90
Average air consumption (C.F.M.) .............................4
Free speed (R.P.M.) ......................................150
Bolt capacity (IN.) ........................................3/8
Air inlet (N.P.T.) .........................................1/4 in.
Hose size (I.D.) ........................................3/8 in.
Weight (LBS)...........................................2.65
Specifications are subject to change without notice.
WARNING!
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO
MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND
WILL VOID WARRANTY.
Some dust created by power sanding contains chemicals known to the State of California to cause cancer, birth defects or other reproductive
harm. An example of this type of chemical is lead from lead based paints, Crystalline Silica from bricks and cement or other masonry, Arsenic
and Chromium from chemically treated lumber. Your risk from these exposures varies, depending on how often you do this type of work. To
reduce your exposure: work in a well ventilated area and work with approved safety equipment, such as dusk masks that are specially designed
to filter out microscopic particles.
OWNER’S MANUAL

REPLACEMENT PARTS
1 Housing 1
2 Housing Adaptor 1
3 Trigger 1
4 Trigger pin 1
5 Pin 1
6 O-ring 1
7 Spring 1
8 Copper head 1
9 Washer 1
10 O-ring 1
11 Gear ring 1
12 Clamp nut 4
13 Gear 3
14 Gear pin 3
15 Idler gear plate 1
16 Crank shaft 1
17 Ratchet anvil 1
18 Ratchet housing 1
19 Anvil bushing 2
20 Drive bushing 1
21 Ratchet yoke 2
22 Cylinder 1
23 Rotor 1
24 Rotor blade 4
25 Front plate 1
26 Front bearing 1
27 Read plate 1
28 Read bearing 1
29 Cylinder pin 2
30 Thrust washer 1
31 Spring 1
32 Pin 1
33 Ratchet pawl 1
34 Ratchet pin 2
35 Reverse button 1
36 O-ring 1
37 Spring 2
38 Steel ball 2
39 Washer 1
INDEX DESCRIPTION QTY INDEX DESCRIPTION QTY

1. This air ratchet is designed to speed productivity, not for high torque applications such
as head bolts, lug nuts, etc. DO NOT USE THIS RATCHET UNDER POWER TO
BREAK FASTENERS LOOSE. Loosen fasteners by hand without depressing throttle.
Once loose, depress throttle to speed fasteners in or out. Always perform final torque
tightening by hand.
2. Use only impact sockets designed for impact wrenches.
3. This ratchet is rated to 3/8" USS bolt size. Rating will decrease for U-Bolts, Long Cap
Screws, Spring Fasteners and rusted or corroded fasteners. All of these factors absorb
power and reduce torque capability.
4. Always use approved eye and ear protection when using air powered tools. If
raising dust/debris, wear a suitable mask. Do not wear loose clothing or jewelry.
5. Always operate tool a safe distance from yourself and others in the work area. Keep
footing and balance at all times.
6. Make sure work piece is secure to allow safe operation of the tool with both hands. Do
not hold the work piece in your hand, lap or against any part of your body.
7. Make sure trigger is in the “off” position before connecting or disconnecting the
tool from air source. Disconnect tool from air source before changing
accessories, performing service and when not in use.
8. Follow air source manufacturer's directions for connection of regulators, filters and
other accessories to air source. Do not install quick couplers directly at tool air inlet.
This causes inlet failure due to excess weight and vibration. Use a whip hose between
tool and quick couplers.
9. DO NOT OVERLOAD! Do not force tool. Match tool capacity to work load requirement.
Use tool within its rated capacity and only for its designated purpose. Overloading air
tools will cause premature wear and/or permanent damage of internal and
external drive parts and will void warranty.
10. Inspect hoses and fittings for wear and damage prior to using tool. Do not carry or
drag tool by the air hose. Keep air hose free from obstruction, twisting and binding.
1. This air ratchet is designed to speed productivity, not for high torque applications such
as head bolts, lug nuts, etc. DO NOT USE THIS RATCHET UNDER POWER TO
BREAK FASTENERS LOOSE. Loosen fasteners by hand without depressing throttle.
Once loose, depress throttle to speed fasteners in or out. Always perform final torque
tightening by hand.
2. This ratchet is rated to 3/8” USS bolt size. Rating will decrease for U-Bolts, Long Cap
Screws, Spring Fasteners and rusted or corroded fasteners. All of these factors absorb
power and reduce torque capability.
3. Use the simplest socket to wrench hook-up. Any additional extensions, u-joints or
adaptors will absorb power and reduce torque capability.
4. Forward/Reverse Lever. Select “F” for Forward (Clockwise) or “R” for Reverse (Counter-
clockwise) operation. Do not attempt to change direction while tool is running.
5. If fastener bogs, slows or binds the tool, use a larger size ratchet tool with a higher
torque rating. Overloading this tool will cause premature wear and/or permanent
damage to internal and external drive parts and will void warranty.
IMPORTANT SAFETY INFORMATION
OPERATION
Clean air of correct air pressure is recommended for the power supply for this tool. A
maximum of 90 PSI at the tool is recommended for most air tools of this class. Check
specifications section for recommended pressure. (Depending on length of air hose and
other circumstances, air pressure at compressor may need to be increased to 100 PSI to
ensure 90 PSI at the tool.)
Water in the air hose and compressor tank contributes to reduced performance and
damage of the air tool. Drain the air tank and filters before each use and as necessary to
keep the air supply dry.
Hose length over 25’ causes loss in line pressure. Increase hose I.D. or increase
compressor pressure to compensate for the pressure loss. Use an in-line pressure
regulator with gauge if air inlet pressure is critical.
AIR SOURCE
Oil tool before each use. 4 to 5 drops of a good grade Air Tool Oil placed in the air inlet
is sufficient. Use proper air pressure and CFM rating listed for this tool.
Drain water from hoses and compressor tank. Water in the air supply line will cause
gumming and loss of power. Clean the air filter on the supply line and flush the tool with
gum solvent or a 50/50 mix of air tool oil and kerosene. It may be necessary to
disassemble the tool to properly clean and re-lubricate.
LUBRICATION & MAINTENANCE
Forward/Reverse Lever
Air Inlet
Trigger
INSUFFICIENT POWER:
Probable Cause Solution
Dirty or clogged air passages......... Flush and lubricate tool, drain air tank and supply line
Insufficient air supply...................... Increase line pressure, Make sure compressor
matches tool's air pressure and consumption needs
Air leakage...................................... Use teflon tape at all fittings and joints. Check tool for
worn or damaged O-rings & seals.
Worn/damaged wear & tear parts .. Replace as necessary.
Tool matching ................................. Be sure you are using a tool suited for the torque
requirements of the job at hand.
TROUBLESHOOTING
Motor
Oil
Trans.
Fluid
Brake
Fluid
Water
Whip
hose
Air Tool
Oil
YesNo
