Idealight HT-LM-60S Mini User manual

1
LED SPOT MOVING HEAD
USER MANUAL
（
（（
（60W White)
Order Code: HT-LM-60S Mini

2
Product Instruction
Working votage:AC90-240V/50Hz
Power Consumption:130W
Light Source:60W LED
Channel Signal: DMX 512, 15 channel
Palette:7palette+white+rainbow effect
Gobo wheel:7gobo+white+rainbow effect
Prism:1 *3-fice prism
Strobe:0-10/S,Adjustable
Dimmer:0%~100% Linear Dimming
All functions can be operated by manual without dmx controller.
Pan:540°8bit/16bit adjustable, Electronic correction
Titl:270°8bit/16bit adjustable, Electronic correction.
Special function: Built -in procedures for a variety of lighting
effects,can run simultaneously from sound control without controllers
Optical System: Combination of high-precision quartz lens, so that
optical loss is reduced to a minimum
Protection: All intelligent temperature thermal protection and
high-interference with electronic circuits.
Maintaining
1. The fixture should be kept dry to avoid working in wet conditions.
2. Intermittent use will effectively prolong the life of this fixture.
3. For a good ventilation and lightiing effects,please clean the
fans ,fan nets and lens usually .

6
Run DMX
Addr:001
Mode Set DMX
Reload
Reset
Displsy Ver.
Set LCD Light
Run
Manual
Pan (0-255)
Tilt (0-255)
Munaul Shut (0-255)
Dimmer (0-255)
Manual color (0-255)
Manual Gobo (0-255)
Gono Rota (0-255)
ManaulPrism (0-255)
P. Rota (0-255)
Focus (0-255)
Set Run Channel(0-255) 13/15 channel
Set Tilt Reverse Tilt(Forward/reverse)
3
4. To avoid damage this fixture, please don't use alcholol or other
organic solvents to clean the fixture shell.
Declaration
Before delivery,this fixture
have the performance intact, packaging integrity, and all users should
strictly observe the above warnings and operating instructions for the
matter, with any damage caused by misuse is not guaranteed wihtin
the tcompany,for damages caused by ignoring the munual instruction
is not withing the scope of the distributors or dealers.Thank you for
your cooperation!!
Precautions
1. In order to ensure the life of this fixture,pelase don't
place this fixture where is moisture or leakage,and don't
operate the fixture at temperatures higher than
40°please!
2. Don't place the fixture where is easy to loose or
vibration-prone
3. To avoid risk of electric shock,please ask the
professionals to maintain this fixture.
4. When connect the fixture to power, the changes of
popwer votage should be at-10% ~+10%,if higher, will
reduce the life of the fixture, but if lower,will effect the
lightness.
5. Should need 20 Min. to fulling cool the light before
re-use.
6. In order to ensure the normal use of this product, please read this
manual caresuly. Thank you very much for your cooperations.
DMX channell Values(15 channel)

4
Channel DMX values Functions
1 Pan 0~255 0~540°
3 Pan 16 Bit 0~255 16bit adjustable
1 Tilt 0~255 0~270°
4 Tilt 16 Bit 0~255 16bit adjustable
5 Pan/Tilt Speed 0~255 From fast to slow
6:Strobe 0-255 Strobe efect from fast to slow
7 Dimming 0~255 From dark to light
0~15 White
16-30 Pink
31~45 Orange
46-60 Green
61~75 Blue
76~90 Yellow
91-105 Red
106~120 Sky blue
121~190 Forward speed of color change
From slow to fast
8 Color Wheel
191~255 Revise speed of color change
From slow to fast
5
Display Control Instruction
Channel
DMX values Functions
0~15 Open
16~30 Gobo 1
31~45 Gobo 2
46~60 Gobo 3
61~75 Gobo 4
76~90 Gobo 5
91~105 Gobo 6
106~120 Gobo 7
121~190 Forward speed of gobo change
From slow to fast
9 Gobo Wheel
191~255 Revise peed of gobo change
From slow to fast
0-127 Forward From slow to fast
10 Gobo auto-run 128-255 ReviseFrom slow to fast
11 Prism 0~225
12 Prism 0-255 Prism Auto-run
13 Focus 0-255
14 0-255 Built-in Program
15 Rest 245-250
