IDEC KW2D Series User manual

B-2163(1)
KW2D Series Smart RFID Reader
User’s Manual

Preface-1 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163
Thank you for purchasing this IDEC product. Before using this product, please confirm that there are no mistakes with your order.
Carefully read this manual and use this product correctly.
Safety Precautions
• Read the "KW2D Series User’s Manual" to ensure correct operation before starting installation, wiring, operation, maintenance, and
inspection of the KW2D Series.
•If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
• All KW2D Series modules are manufactured under IDEC’s rigorous quality control system, but users must add a backup or failsafe
provision to the control system when using the KW2D Series in applications where heavy damage or personal injury may be caused, in
case the KW2D Series should fail.
•Implement security measures, such as those for unauthorized access to this product from external devices, on the network system
side. IDEC Corporation bears no responsibility for losses, damages, and/or other expenses that occur directly or indirectly as a result of
unauthorized access or other security failures.
•As a security measure, always use a firewall or another tool and block accessible IP addresses and ports.
•In this manual, safety precautions are categorized in order of importance:
Warning notices are used to emphasize that improper operation may cause severe personal injury or death.
Caution notices are used where inattention might cause personal injury or damage to equipment.
•This product is not designed for use in applications requiring a high degree of reliability and safety, such as applications for
medical devices, nuclear power, railroads, aerospace, and automotive devices. The KW2D Series should not be used for
such applications.
•Turn off power to the KW2D Series before installation, removal, wiring, maintenance, and inspection of the KW2D Series.
Failure to turn power off may cause damage, electrical shocks or fire hazard. If such a circuit is configured inside the
KW2D Series, Failure of the KW2D Series may cause disorder of the control system, damage, or accidents.
•Special expertise is required to install, wire, and operate the KW2D Series. People without such expertise must not use
the KW2D Series.
• Install the KW2D Series according to the instructions described in the "KW2D Series User’s Manual". Improper installation
will result in falling, failure, or malfunction of the KW2D Series.
• Install the KW2D Series in environments described in the "KW2D Series User’s Manual". If the KW2D Series is used in
places where the KW2D Series is subjected to high-temperature, high-humidity, condensation, corrosive gases,
excessive vibrations, or excessive shocks, then electrical shocks, fire hazard, or malfunction will result.
•Prevent the KW2D Series from falling while moving or transporting the KW2D Series, otherwise damage or malfunction of
the KW2D Series will result.
•Wiring must use lead sizes that are appropriate for the applied voltage and current.
•Prevent metal fragments and pieces of wire from dropping inside the KW2D Series housing. Put a cover on the KW2D
Series modules during installation and wiring. Ingress of such fragments and chips may cause fire hazard, damage, or
malfunction.
•Use SELV power supply that is reinforced or double-insulated from MAINS without any risk of electric shock, and Limited
Energy (LIM) Circuit.
•Do not disassemble, repair, or modify the KW2D Series modules. There is a risk of serious accident, such as electric
shock, damage, fire, and malfunction.
This device complies with part 15 of FCC Rules and Innovation, Science and Economic Development Canada’s licence-
exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
Le présent appareil est conforme à la partie 15 des règles de la FCC et aux normes des CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'appareil doit accepter tout brouillage
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
• Electromagnetic waves are generated from the front unit, so—excluding when using tags—stay more than 5 cm away
from the front unit.
•When disposing of the KW2D Series, do so in accordance with national and local regulations.
•This telecommunication equipment conforms to the standard or technical requirements of NBTC (Thailand).
Warning
Warning
Caution
Warning
Warning
Caution

KW2D Series Smart RFID Reader User’s Manual Preface-2
KW9Y-B2163
Note:
•This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own
expense.
•Use a Category 5 or higher STP shielded cable for the LAN cable.
Introduction
This manual describes the functions, configuration methods, and safety precautions of the KW2D Series Smart RFID Reader and the KW
RFID Configurator configuration software.
Read this manual to ensure the correct understanding of the functions and performance of the KW2D Series Smart RFID Reader and the
KW RFID Configurator configuration software. Store this manual carefully so it can be read at any time.
IDEC Corporation makes the latest product manual PDFs available on our website at no additional cost. Please download the latest
product manual PDFs from our website.
Publication History
Notes
•IDEC Corporation holds all rights related to this manual and the KW RFID Configurator. Unauthorized duplication, reprinting, sales,
transfers, and leasing are prohibited.
•The contents of this manual and the KW RFID Configurator may change without prior notification.
•IDEC Corporation bears no responsibility for the results of using this manual or the KW RFID Configurator.
•We have taken all possible measures with the content of this product, but if you notice any portions that are unclear, or any mistakes,
please contact the dealer where purchased, an IDEC sales office, or the customer service line.
Trademarks
•Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the United State and other countries.
•FeliCa is a registered trademark of Sony Corporation.
•Mifare is a registered trademark of NXP Semiconductors.
•CC-Link, CC-Link IE Field Basic, and SLMP are registered trademarks of Mitsubishi Electric Corporation.
•EtherNet/IP is a registered trademark of ODVA, Inc.
•Other company names and product names used in this manual are the trademarks or registered trademarks of their respective
companies.
Symbol Meaning
Reference to web manual with QR code.
Ground the functional ground terminal to ensure stable operation fo the equipment.
September 2020 First Edition
December 2020 Second Edition

Preface-3 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163
Regarding Laws and Compatible Standards
This product adheres to the laws and compatible standards of all countries involved, as shown below.
European laws and standards
This product complies with the following EU directives.
- EMC Directive
- RoHS Directive
- Radio Equipment Directive
To comply with these directives, this product has been designed and evaluated on the basis of the following international and European
standard.
- IEC/EN 61131-2
- ISO/IEC 18000-3
- ISO/IEC 14443 Type A
- ISO/IEC 18092
- JIS X6319-4
- ISO/IEC 15693
North America laws and standards
This product complies with the following standards.
- UL61010-1/CAN/CSA C22.2 No. 61010-1-12
- UL 61010-2-201
RFID communication standards
- ISO/IEC 14443 Type A
- ISO/IEC 18092
- JIS X6319-4
- ISO/IEC 15693
Radio law certification
This product has received certification for the following radio laws.
- MIC (Japan)
- FCC/ISED (USA/Canada)
- NCC (Taiwan)
- Radio Equipment Directive (EU)
- NBTC (Thailand)
- WPC (India)
For details on applicable standards and EU directives, please contact the dealer where purchased or check the IDEC website.

KW2D Series Smart RFID Reader User’s Manual Preface-4
KW9Y-B2163
About the Warranty of the Products
1. Warranty Period
The Products are warranted for one year from the date of purchase, or from the date of delivery completion.
2. Extent of Warranty
IDEC CORPORATION is responsible for failures or defects of the Products during the above warranty period, either a replacement
part will be provided or the defective parts of the Products will be repaired free of charge.
If such failure or defects should occur, please offer them to the distributor, dealer or IDEC CORPORATION with the materials in which
the date of purchase is specified.
3. Start
September 1, 2020.
4. Indemnification
IDEC CORPORATION will not be liable under this Warranty and be indemnified and held harmless from any and all demands, suits,
expenses, claims, damages and liabilities in the following event that:
In addition, the indemnification means the warranty just for our product, and any damages caused by the failure of our product shall
be excluded from the warranty.
5. Extent of Service
The price of the Products will not include the fee for any service such as sending technicians and engineers, IDEC CORPORATION
will charge you the fee for the following:
* The expenses for installation and construction at the time of repair will not be borne.
1) The Products are used or operated beyond the conditions or environment range as described in catalog, specifications or
instruction; or
2) The failure or defects of the Products arise from the cause other than the Products; or
3) The Products are improved, modified or altered by the party other than IDEC; or
4) The failure or defects and damages of the Products arise from the usage of the Product in the way that is not intended; or
5) The failure or defects and damages of the Products arise from the cause beyond IDEC’s control including, but not limited to, fire,
earthquake, flood, lightning, other natural disasters, and acts of God; or
6) The failure or defects and damages of the Products arise from the relocation, transportation or drop after you purchase the
Products; or
7) The failure or defects and damages of the Products arise from improper installation; or
8) Maintenance and inspection are not carried out in accordance with instruction.
* The customer is responsible for checking the operation of programmable Products. IDEC CORPORATION bears no responsibility
for the operation of programs created by the customer and for damages that occur as a result of those programs.
1) Instruction for installment and visiting for test operation, including, but not limited to creating application software and operation
tests; and
2) Maintenance and inspection, arrangement and repair; and
3) Technical assistance and technical education; and
4) Product test and inspection based on you request.

Preface-5 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163
Abbreviations, Names, and Terms
Item Description
KW2D Series Smart RFID Reader The general term for this product.
KW2D-R100Q4E, KW2D-RH100Q4E
KW2D special tag The general term for this product's special tags.
KW9Z-T1**, KW9Z-T2**
RFID tag The general term for RF tags and non-contact IC cards that support IC tag standards.
Non-contact IC card The general term for card type RF tags that support IC tag standards.
IC tag standards Standards for RFID tags.
KW RFID Configurator The software for creating project data for the KW2D Series Smart RFID Reader.
Project data The KW2D Series Smart RFID Reader settings and tag list to which UIDs and authorities are
registered.
Tag list A list to which UIDs and authorities are registered.
UID
An abbreviation for unique identifier.
A unique ID number stored in the RFID tag that cannot be overwritten. It is a data string with a
maximum length of 10 bytes.
Tag information The general term for the UID, authority, Name1, and Name2 to register for a tag.
Authority One byte of information associated with the UID.
Verification result The information obtained as the result of verifying UIDs. This information includes the UID,
authority, and IC tag standard.
Host device The device that communicates with the KW2D Series Smart RFID Reader to control whether the
target system can be operated.
Shared memory Memory of KW2D Series Smart RFID Reader that can be accessed from the host device.
Name1, Name2 Text strings that can be set as desired in the tag list.
Lock operation The state in which the verification result is held in shared memory.
Host communication
Communication with Modbus TCP server (port number: 502), EtherNet/IP communication and
CC-Link IE Field Basic communication.
It does not include communication with Modbus TCP servers (port number: 503, 504).
EtherNet/IP Industrial communication network protocol advocated by ODVA (ODVA. Inc.). It has become an
international standard as IEC61158 and is also certified as SEMI standard E54.13.
EtherNet/IP communication Abbreviation for Ethernet Industrial Protocol. Industrial multi-vendor network using Ethernet.
EtherNet/IP Scanner·Adapter
In EtherNet/IP communication, the master side is called "scanner" and the slave side is called
"adapter". In general, the EtherNet/IP device that has the function requiring the CIP connection
to be established is called an adapter, and the EtherNet/IP device that also has the function
requiring to initiate a CIP connection is called a scanner.
EtherNet/IP device Generic term for devices that support EtherNet/IP communication. This product supports
EtherNet/IP communication (adapter).
CC-Link IE Field Basic
CC-Link IE Field Basic is an industrial communication network advocated by the CC-Link
Association. This network is suitable for small-scale devices that can perform cyclic
communication using universal 100 Mbps Ethernet.
CC-Link IE Field Basic device Gneral term for devices that support CC-Link IE Field Basic communication. This product
supports CC-Link IE Field Basic communication (slave).

KW2D Series Smart RFID Reader User’s Manual Preface-6
KW9Y-B2163
Symbols Used in the Manual
The following symbols are used in the manual to simplify the descriptions.
Notes
Symbol Meaning
Indicates information about items that carry the risk of death or serious injury if the product is used improperly.
Indicates information about items that carry the risk of personal injury or physical damage if the product is used improperly.
Indicates information about items that must be observed or that are easily mistaken when using the product.
Indicates supplemental information about an item or helpful information that you should know.
Warning
Caution

Preface-7 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163
Supplier's Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Unique Identifier: KW2D-R100Q4E or KW2D-RH100Q4E
Responsible Party – U.S. Contact Information
IDEC Corporation
1175 Elko Drive, Sunnyvale, CA 94089-2209, USA
Tel: [phone] o[email protected]
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.

KW2D Series Smart RFID Reader User’s Manual Preface-8
KW9Y-B2163
Contents
Safety Precautions.............................................................................................................................................................. Preface-1
Introduction ........................................................................................................................................................................ Preface-2
Publication History.................................................................................................................................................... Preface-2
Notes ....................................................................................................................................................................... Preface-2
Trademarks .............................................................................................................................................................. Preface-2
Regarding Laws and Compatible Standards............................................................................................................. Preface-3
About the Warranty of the Products ......................................................................................................................... Preface-4
Abbreviations, Names, and Terms ...................................................................................................................................... Preface-5
Symbols Used in the Manual .............................................................................................................................................. Preface-6
Notes ....................................................................................................................................................................... Preface-6
Chapter 1 Overview of the KW2D Series Smart RFID Reader ....................................................................................... 1-1
Introduction to the KW2D Series Smart RFID Reader .................................................................................................................1-1
Type Numbers ...........................................................................................................................................................................1-1
Type Numbers and Functions List..............................................................................................................................................1-2
KW2D Series Smart RFID Reader Type Numbers and Functions........................................................................................1-2
KW2D Special Tag Type Numbers and Functions ..............................................................................................................1-2
KW2D Series Smart RFID Reader Features ................................................................................................................................1-3
KW2D Series Smart RFID Reader Functions ..............................................................................................................................1-4
System Configuration.................................................................................................................................................................1-5
Introduction to the KW RFID Configurator ..................................................................................................................................1-6
Overview of Communication Functions ......................................................................................................................................1-7
Chapter 2 Product Specifications .................................................................................................................................... 2-1
Specifications.............................................................................................................................................................................2-1
Operating Environment Specifications ................................................................................................................................2-1
Electrical Specifications ......................................................................................................................................................2-2
Mechanical Specifications ..................................................................................................................................................2-2
Ethernet Communication Specifications .............................................................................................................................2-3
RFID Interface Specifications ..............................................................................................................................................2-3
KW2D Special Tag Specifications.......................................................................................................................................2-3
Names of LSIs in Tested Tags............................................................................................................................................2-4
Part Names and Functions.........................................................................................................................................................2-5
Dimensions ................................................................................................................................................................................2-7
Main Unit............................................................................................................................................................................2-7
Tag.....................................................................................................................................................................................2-8
Front Cover ........................................................................................................................................................................2-8
Chapter 3 Installation and Wiring ..................................................................................................................................... 3-1
Installation and Wiring Precautions .............................................................................................................................................3-1
Installation Space ...............................................................................................................................................................3-1
Attachment Methods .................................................................................................................................................................3-2
Back Unit Removal and Attachment Methods ....................................................................................................................3-2
Front Cover Removal and Attachment Methods .................................................................................................................3-4
Panel Mounting Method .....................................................................................................................................................3-7
Drilling the Mounting Hole ..........................................................................................................................................................3-9
Mounting Hole Layout ........................................................................................................................................................ 3-9
Mounting Centers Example ................................................................................................................................................3-9
Power Supply and Power Supply Wiring ..................................................................................................................................3-10
Power Supply...................................................................................................................................................................3-10
Power Supply Voltage ...................................................................................................................................................... 3-10
Power Supply Wiring ........................................................................................................................................................3-10
Power Supply Terminal Block Wiring Method ...................................................................................................................3-11
Terminals .................................................................................................................................................................................3-12
Terminals for the Terminal Block....................................................................................................................................... 3-12
Applicable Wire ................................................................................................................................................................3-14
Recommended Tools .......................................................................................................................................................3-15
Wiring Directions and Panel Indicators .....................................................................................................................................3-16

Preface-9 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163
Chapter 4 KW RFID Configurator......................................................................................................................................4-1
Overview of the KW RFID Configurator...................................................................................................................................... 4-1
Operating Environment ...................................................................................................................................................... 4-1
Installing the Software........................................................................................................................................................ 4-1
Uninstalling the Software.................................................................................................................................................... 4-1
Starting and Exiting the Software ....................................................................................................................................... 4-1
Checking the KW RFID Configurator Version Number ............................................................................................................... 4-2
Configuration and Functions...................................................................................................................................................... 4-3
Configuration of the KW RFID Configurator........................................................................................................................ 4-3
Menu Bar Commands........................................................................................................................................................ 4-4
File..................................................................................................................................................................................... 4-5
Online ................................................................................................................................................................................ 4-7
Help................................................................................................................................................................................. 4-16
Toolbar.................................................................................................................................................................................... 4-17
Settings Tabs .......................................................................................................................................................................... 4-18
Chapter 5 Functions and Settings.....................................................................................................................................5-1
Setup Using the KW RFID Configurator ..................................................................................................................................... 5-1
KW2D Series Smart RFID Reader Statuses and Operations ...................................................................................................... 5-2
Operation Mode................................................................................................................................................................. 5-2
Detection Mode ................................................................................................................................................................. 5-4
Lock Mode ........................................................................................................................................................................ 5-8
Adjusting the RFID Tag Detection Sensitivity .................................................................................................................... 5-13
Setup from the Host Device Using Coil Relays ................................................................................................................. 5-14
KW2D Series Smart RFID Reader Functions............................................................................................................................ 5-16
Read UID Function........................................................................................................................................................... 5-16
UID Verification Function .................................................................................................................................................. 5-17
Ethernet Communication Function ................................................................................................................................... 5-18
Shared Memory............................................................................................................................................................... 5-20
Projects ........................................................................................................................................................................... 5-21
Modbus TCP Server ................................................................................................................................................................ 5-22
Communication Specifications......................................................................................................................................... 5-22
Modbus TCP Communication Shared Memory ................................................................................................................ 5-23
EtherNet/IP Adapters............................................................................................................................................................... 5-26
Overview.......................................................................................................................................................................... 5-26
Configuration ................................................................................................................................................................... 5-28
EtherNet/IP Adapters....................................................................................................................................................... 5-29
EtherNet/IP adapter (Class 3/UCMM communication)...................................................................................................... 5-36
CC-Link IE Field Basic Slaves .................................................................................................................................................. 5-42
Overview.......................................................................................................................................................................... 5-42
Configuration ................................................................................................................................................................... 5-43
CC-Link IE Field Basic (Slave Station) .............................................................................................................................. 5-44
Maintenance Communication Server ....................................................................................................................................... 5-49
Communication Specifications......................................................................................................................................... 5-49
Functions......................................................................................................................................................................... 5-49
Chapter 6 Troubleshooting ................................................................................................................................................6-1
Errors ........................................................................................................................................................................................ 6-1
Checking Errors with the LED Indicator Colors................................................................................................................... 6-1
Checking Errors with the Input Relays................................................................................................................................ 6-1
Troubleshooting ........................................................................................................................................................................ 6-2
INDEX.............................................................................................................................................................................INDEX-1

KW2D Series Smart RFID Reader User’s Manual 1-1
KW9Y-B2163
Chapter 1
Chapter 1 Overview of the KW2D Series
Smart RFID Reader
This chapter describes an overview of the KW2D Series Smart RFID Reader and its system configuration.
Introduction to the KW2D Series Smart RFID Reader
The KW2D Series Smart RFID Reader is an RFID reader equipped with a verification function. Both card type and KEYFOB type RFID
tags are supported.
The KW2D Series Smart RFID Reader can work with a host device using communication functions, such as maintenance communication
server and Modbus TCP server. Use the KW RFID Configurator for the creation and management of RFID tags and projects that are used
with the KW2D Series Smart RFID Reader.
Type Numbers
This section gives the type numbers for the KW2D Series Smart RFID Reader.
•KW2D Series Smart RFID Reader
•KW2D Special Tag
*1 The authority for the CARD type is "T2X0: Authority 10" only.
•Cover
KW2D-R100Q4E
Communication type
E : Ethernet
Power supply
Q4: 24V DC power type
Version
1 : Version 1
KEYFOB Front cover
R : Without holder
RH: With holder
KW9Z-T1X1G
Authority (KEYFOB color)
X1G: Authority 1 (green)
X2Y : Authority 2 (yellow)
X3R: Authority 3 (red)
X4S: Authority 4 (blue)
X5B: Authority 5 (black)
Tag type
T1 : KEYFOB
T2 : CARD*1
KW9Z-CV
Type
CV : For KW2D-R (Standard type cover)
CVH: For KW2D-RH (Holder type cover)

Chapter 1 Overview of the KW2D Series Smart RFID Reader
1-2 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163
Type Numbers and Functions List
KW2D Series Smart RFID Reader Type Numbers and Functions
KW2D Special Tag Type Numbers and Functions
Type No. Power Supply Ethernet Port Holder
KW2D-R100Q4E 24V DC Yes None
KW2D-RH100Q4E 24V DC Yes Yes
Type No. Tag Type Tag Color
Default Authority
1 2 3 4 5 10
KW9Z-T1X1G
KEYFOB
Green Yes - - - - -
KW9Z-T1X2Y Yellow - Yes - - - -
KW9Z-T1X3R Red - - Yes - - -
KW9Z-T1X4S Blue - - - Yes - -
KW9Z-T1X5B Black - - - - Yes -
KW9Z-T2X0 CARD - - - - - - Yes
For details on product specifications, see "Chapter 2 Product Specifications" on page 2-1.

KW2D Series Smart RFID Reader User’s Manual 1-3
KW9Y-B2163
Chapter 1 Overview of the KW2D Series Smart RFID Reader
Chapter 1
KW2D Series Smart RFID Reader Features
This section describes the features of the KW2D Series Smart RFID Reader.
The KW2D Series Smart RFID Reader is a compact RFID reader equipped with an Ethernet port and can be installed on a ø22 hole panel.
•Panel Surface Mounted
This RFID reader can be mounted in a 22-mm diameter hole.
•Communication Functions
The KW2D Series Smart RFID Reader supports the following communication functions to communicate with the host device.
•Modbus TCP server
•EtherNet/IP adapter
•CC-Link IE Field Basic slave
The following communication functions are supported for maintaining the KW2D Series Smart RFID Reader.
•Maintenance communication server
•RFID reader search
The KW2D Series Smart RFID Reader can be connected to programmable displays, host devices such as PLCs, and the computer in
which KW RFID Configurator is installed.
•Verification Function
The KW2D Series Smart RFID Reader can verify UIDs in RFID tags against UIDs that were registered in advance.

Chapter 1 Overview of the KW2D Series Smart RFID Reader
1-4 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163
KW2D Series Smart RFID Reader Functions
This section describes the functions of the KW2D Series Smart RFID Reader.
•Read UID Function
This function reads the UID of KW2D special tags and general-purpose card type RFID tags.
•UID Verification Function
The KW2D Series Smart RFID Reader is equipped with an RFID antenna (13.56 MHz band) and can verify UIDs read from RFID cards
against UIDs that were registered in advance. The following three types of IC tag standards are supported.
•Read Confirmation Function
The read status of the RFID tag can be confirmed with the buzzer.
•Status Confirmation Function
The operating status and error status of the KW2D Series Smart RFID Reader can be checked with the three colors of LED indicators
(white, green, and red) on the front of the KW2D Series Smart RFID Reader.
IC Tag Standard Non-contact IC Card/Tag Name
ISO/IEC 14443 Type A MIFARE (NXP)
ISO/IEC 18092 FeliCa (Sony)
ISO/IEC 15693 Tag-it (Texas Instruments), I-CODE (NXP)
The buzzer and LED indicators can be enabled or disabled. The buzzer and LED indicators can also be controlled from the host
device. For more information on remote control of the buzzer and LED indicators, see "Chapter 5 Remote Control of Buzzer and
LEDs" on page 5-15.

KW2D Series Smart RFID Reader User’s Manual 1-5
KW9Y-B2163
Chapter 1 Overview of the KW2D Series Smart RFID Reader
Chapter 1
System Configuration
There are two system configurations for using theKW2D Series Smart RFID Reader: the system configuration used for actual operation
and the system configuration for creating a project for operation.
Use the KW RFID Configurator dedicated configuration software to create a project.
•System Configuration During Operation
The KW2D Series Smart RFID Reader can be used in the following system configuration. The devices that can be connected depend on
the model. For details, see "Chapter 2 Product Specifications" on page 2-1.
•System Configuration During Project Creation
To use the KW2D Series Smart RFID Reader, you must download a project to it.
Use the KW RFID Configurator to create the project. You can connect the KW2D Series Smart RFID Reader to a computer and download
the created project over Ethernet communication.
RFID tag Shared memory in
KW2D Series Smart RFID Reader Host device
Read UID Read result
The KW2D Series Smart RFID Reader also supports EtherNet / IP communication and CC-Link IE Field Basic communication
protocols.
KW2D Series Smart RFID Reader
Host device
Shared
memory KW RFID Configurator
Ethernet
Ethernet hub
UID, authority, and IC tag standard (Device that supports Modbus TCP client)
(Supports Modbus TCP server)
Ethernet hub
KW2D Series Smart RFID Reader
Ethernet cable
KW RFID Configurator

Chapter 1 Overview of the KW2D Series Smart RFID Reader
1-6 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163
Introduction to the KW RFID Configurator
The KW RFID Configurator is dedicated software for the KW2D Series Smart RFID Reader to monitor tag information read by the KW2D
Series Smart RFID Reader, configure the KW2D Series Smart RFID Reader settings, and create tag lists. The collection of settings and
created data is called a project.
Build the environment required for operation by using the KW RFID Configurator to create a project and downloading that project to the
KW2D Series Smart RFID Reader.
The KW RFID Configurator has the following functions.
•Find RFID Readers
If you do not know the IP address of a KW2D Series Smart RFID Reader, you can search for its IP address. The default IP address of the
KW2D Series Smart RFID Reader is 192.168.1.50.
•Create Project
Create the tag list and configure the KW2D Series Smart RFID Reader settings.
If necessary, create the tag list while monitoring the KW2D Series Smart RFID Reader.
•RFID Reader Monitor
You can monitor the status of the KW2D Series Smart RFID Reader and the UIDs.
KW2D Series Smart RFID Reader
Find IP addresses
Download (project)
Monitor
Computer
(KW RFID Configurator)
Project

KW2D Series Smart RFID Reader User’s Manual 1-7
KW9Y-B2163
Chapter 1 Overview of the KW2D Series Smart RFID Reader
Chapter 1
Overview of Communication Functions
The Ethernet port is standard equipment on the KW2D Series Smart RFID Reader to enable communication using Ethernet.
•Communication Functions
•Maintenance Function
•Communication Interface
Modbus TCP Server
Modbus TCP server can be used to exchange data between the KW2D Series Smart RFID Reader and a
host device that supports the Modbus TCP client protocol. For details, see "Chapter 5 Modbus TCP
Server" on page 5-22.
EtherNet/IP Communication
It is possible to exchange data between a host device supporting CC-Link IE Field Basic communication
and the KW2D Series Smart RFID Reader. For more information, please refer to "Chapter 5 EtherNet/IP
Adapters" on page 5-26.
CC-Link IE Field Basic
communication
It is possible to exchange data between a host device supporting EtherNet/IP communication and the
KW2D Series Smart RFID Reader. For more information, please refer to "Chapter 5 CC-Link IE Field Basic
Slaves" on page 5-42.
Maintenance Communication
Server
Using a PC, you can upload and download the project or monitor UIDs detected by the KW2D Series
Smart RFID Reader. For details, see "Chapter 5 Maintenance Communication Server" on page 5-49.
Find RFID Readers You can find the RFID readers connected to the network. For details, see "Chapter 4 [RFID Reader List]
Dialog Box" on page 4-15.
Ethernet Port Through this port, the KW2D Series Smart RFID Reader can communicate with programmable displays,
PLCs, and host devices that support Ethernet communication.

Chapter 1 Overview of the KW2D Series Smart RFID Reader
1-8 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163

KW2D Series Smart RFID Reader User’s Manual 2-1
KW9Y-B2163
Chapter 2
Chapter 2 Product Specifications
This chapter describes the part names and specifications of the units that make up the KW2D Series Smart RFID Reader.
Specifications
The specifications of this product are as follows.
Operating Environment Specifications
*1 IP ratings are not applicable to UL certification.
*2. Front of panel only
*3. The protective structure of the operating part after this product is mounted on the panel. Although this poduct complies with various
testing conditions, normal operation in all environments is not guaranteed. The oil-proof structure of IP67F complies with the oil-proof
test conditions of Japanese Industrial Standards JIS C 0920 appendix. There is no guarantee for long-term use in an oil-filled
environment or use of out of specification oil. Please check by testing in advance.
Be careful when using card type KW2D special tags. These tags have a smaller temperature range than the KW2D Series
Smart RFID Reader itself. If card type KW2D special tags are used outside the specified temperature range, there is a risk
of deformation, damage, or malfunction.
Warning
Caution
Ambient Operating Temperature -25 to +55°C (no freezing)
Ambient Storage Temperature -40 to +80°C (no freezing)
Ambient Operating Humidity 10 to 95% RH (no condensation)
Storage Humidity 10 to 95% RH (no condensation)
Pollution Degree
Front of panel 3 (IEC 60664-1)
Inside panel 2 (IEC 60664-1)
Degree of Protection*1 Front unit*2 IP65 or IP67 (IEC 60529), IP67F(JIS C 0920)*3
Back unit IP20 (IEC 60529)
Corrosion Resistance No corrosive gas
Altitude or Air Pressure
During use 1013 to 795 hPa (0 to 2000 m)
During transport 1013 to 701 hPa (0 to 3000 m)
Installation Location Indoors
Overvoltage Category II
Vibration Resistance 5 to 55Hz, half amplitude 0.5mm, each direction XYZ
Shock Resistance 100m/s2, 11ms, XYZ, 3 axes, 6 directions
EMC Immunity IEC/EN 61131-2 Zone B, EN 301-489-3 compatibility

Chapter 2 Product Specifications
2-2 KW2D Series Smart RFID Reader User’s Manual
KW9Y-B2163
Electrical Specifications
Mechanical Specifications
*1 This holder is for mounting the KEYFOB type tag (KW9Z-T1X**).
*2. For details on illumination conditions, see "Chapter 5 KW2D Series Smart RFID Reader Statuses and Operations" on page 5-2.
*3. For details on buzzer operation conditions, see "Chapter 5 KW2D Series Smart RFID Reader Statuses and Operations" on page 5-2.
Rated Input Voltage 24V DC
Voltage Fluctuation Range 20.4 to 28.8V DC (including ripple)
Current Draw 100mA maximum (24V DC)
Allowable Momentary Power
Interruption 1ms or longer (at rated power supply voltage)
Withstand Voltage
Between power and FE terminals 500V AC, 1 minute
Between LAN port and internal circuit 500V AC, 1 minute
Insulation Resistance
Between power and FE terminals 100 MΩor higher (500V DC insulation resistance tester)
Between LAN port and internal circuit 100 MΩor higher (500V DC insulation resistance tester)
Inrush Current 25 A maximum
Isolation Between LAN port and internal circuit Transformer isolation
Ground D-type ground (Class 3 ground)
Functional Ground Wire See "Chapter 3 Power Supply and Power Supply Wiring" on page 3-10.
Power Supply Wire See "Chapter 3 Power Supply and Power Supply Wiring" on page 3-10.
Effect of Improper Power Supply
Connection
Reverse polarity Normal operation
Improper voltage or frequency Permanent damage may be caused
Improper lead connection Permanent damage may be caused
Weight (approx.) 70 g
Power Supply Terminals
Terminal configuration Push-in terminals
Wire pull force
AWG24: 10N maximum
AWG22: 15N maximum
AWG20: 20N maximum
AWG18: 30N maximum
AWG16: 40N maximum
Insertion/removal durability 25 times minimum
Recommended operation force of Pusher 20 N (40 N maximum)
Tag Holder*1 Insertion/removal durability 10,000 times minimum
Indicators*2 Three colors of LEDs (red: 2, green: 2, white: 4)
Buzzer*3 Single tone with fixed volume
Case Materials
Front cover, back cover PBT
Front base, back base PA66
Lens PCT
